Dimplex DX4130 User Manual

Installation and Operating Instructions

Passive Infra-Red Detector Switch

Model No. DX4130

Height Width Depth

130mm 85mm 145mm

130mm

85mm

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

IMPORTANT SAFETY ADVICE

• The installation of this product should be carried out
by a competent person or electrician in strict
accordance of the current IEE Wiring Regulations

• The DX4130 is designed to be used in conjunction
with Dimplex heaters up to 3kW electrical loading.

• Only to be used on a 220-240Volt A.C. ~ electricity
supply

• Electricity supply must be isolated before
commencement of installation

• Always isolate the detector switch and the heater
from the electricity supply before undertaking any
maintenance work

• Must not be installed and used in the vicinity of a
bathroom or swimming pool

Installation

(Please also refer to the IMPORTANT SAFETY ADVICE)
Before undertaking installation work, ensure the electricity supply is disconnected from any relevant fixed wiring.

Supply cable is not provided with this product, and it should therefore be installed by a competent person or electrician
This PIR detector must be used on an A.C. ~ supply only
Dimplex Quartz and ceramic heaters operate by emitting radiant heat within a specific area or zone.

The beam of radiant heat will interfere with the correct performance of the PIR detector unless the PIR detector is mounted outside the ‘throw’ of
radiant heat. It is therefore essential that the PIR detector is mounted as outlined below:

1. For installation of Quartz and ceramic heaters, please refer to the relevant installation instructions.

2. The PIR should be positioned to cover the desired sensing area without obstruction, avoiding the direct ‘throw’ of the heater.

3. The PIR should be wired directly back to a type C MCB or 13 amp re-wireable fuse. The cable should not exceed 2.5mm².

4. Remove screws and disconnect the plug connecting the detector to the key box. When removing the detector head, the latch on plug
should be released as indicated. (see Fig.1.)

Detector Head Plug

Press Down

Fig.1.

General

The Dimplex passive infra –red detector switch has been designed to
enable Dimplex Quartz and ceramic heaters (or any other heater up to
3kW) It automatically switches the heater on and off, depending on
whether the area below the heater is occupied.

Features

• Time delay adjustment

• Full 180º coverage over 15m if required

• Size of detection area can be reduced

• Approved to VDE 0632 and IEC 669-2-1

• Separate wall-box and plug in detector lead to simplify installation

• IP54 rated

Contents

X 1 Instruction sheet
X 1 grey wall box with fixed terminal block
X 1 PIR switch with pre-wired plug in connection
X 2 screws to affix PIR switch to wall box
X 3 screw caps
X 1 lens mask

Issue 3 November 2006

Installation continued

5. Insert top screw into the w all, allowing it to protrude by approximately 3mm.

6. Hook wall box on to screw using keyhole slot prov ided.

7. Mark position of remaining fixings, remove box and complete fixing.

8. Fix the wall box to the wal l, ensuring the drain hole is at the bottom.

9. Cable entries are made to the base of the box, using the holes provided.

10. Connect circuit wiring to terminal block. (see Fig.2.)

N N SLI L

N = Neutral to load
N = Supply Neutral

= Earth terminal

SLI = Supply to load

L = Supply live

11. Plug detector head into the back box socket.

Secure detector to wall box with screws provided and cover screws with screw caps.

Adjusting PIR Range

Limit the range and angle o f detection as appropriate by adjusting the detector head and by using the lens masking plates
provided. Cut the appropriate segments from the lens m ask to cover the area of the lens that requires masking.

A1 A2 A3 A4 Long Range 6-15 metres
B1 B2 B3 B4 Inner Range 3-12 metres
C1 C2 C3 C4 Short Range 0-3 metres

90º 45º 0 45º 90º

15m 12m 3m 3m 12m 15m

C1

B1

A1

B2

C2

C3

C4

B4

A4

B3

90º

45º

A2

A3

45º

0

15m

90º

Masked Areas Masked Areas

AC A4 A1 A2 A4

15m

45º

B3 B4 B1 B2 B4

C3 C4

C1 C2 C4

Testing

1. Set the light level 5 to maximum (clockwise), and the time on  to minimum (anti-clockwise).

2. Move in and out of detection pattern checking the PIR detector switches load on and then off. Once the detection area has been set
satisfactorily, adjust the time (blue knob) to the desired level. For your convenience optimum settings have been indicated.

3. If the unit does not operate, refer to the check list and fault finding list.

Check List

1. Check the supply to the detector

2. If the unit is being tested during daylight , ensure that the photocell has been adjusted in accordance with point 1 in the ‘Testing’
section.

3. Check detector is connected to the heater correctly

Fault Finding List

Problem Solution

The unit will not switch on

Unit is detecting at too long a range

Unit switches on for no apparent
reason

Unit will not switch off

• Check power is supplied to the unit

• Check the plug in connection from the detector head is inserted in to the wall box correctly

• Check to see that the lamps are fitted correctly to the heater(s)

• Check mounting height and adjust angle of the unit downwards to reduce range (note the unit is

designed to switch at a maximum of 15 metres with 170Ib (77kg) person walking at 90º to the
unit. Alternatively fit an appropriate mask.

IMPORTANT: at 10ºC this unit may detect in excess of 20 metres.

• Check the unit is not sited near any vents or heating flues

• Infra-red patterns are given off by electrical appliances

NOTE: to reduce sensitivity, blank off areas C1, C2, C3, C4 of the lens mask

• Are you standing by the detection zone? Whilst you are moving in and out of the detection area
the unit will continue to detect. The heater on time is from the last moment detection was made.

Technical Specification

Switching capability – Up to 3kW
Operating Power – 3kW
Detection Range – 15 metres maximum
Detection Angle - 180º
Heater on time – Adjustable to 10 seconds, 60 seconds, 3.5 minutes, 6 minutes, 9 minutes, 12 minutes, 13.5 minutes,
16 minutes, 21 minutes (approximately)

IMPORTANT: When unit is first connected to the mains the light will switch on – even in daylight.
Allow unit to reset before testing

After Sales Care

Your product is guaran teed for one year from the date of purchase.
Within this period, we undertake to repair or excha ng e this product free of charge (subject to availability) provid ed it has been

installed and operated in accordance with these instructions.
Your rights under this guarantee are additional to your statutory rights, which in turn are not affected by this guarantee.
Should you require after sales service you should contact the supplier through whom you purchased the product or contact our

customer service help desk on 0845 600 5111. It would assist us if you can quote the model number, series, date of purchase,
and nature of the fault at the time of your call. The customer service help desk will also be able to advise you should you need to
purchase any spares.

Please do not retu rn a faulty product to us in the first instance as this may result in loss or damage and delay in providing you
with a satisfactory service.

Please retain your receipt as proof of purchase
