INSTRUCTION MANUAL
10L Evaporative Cooler
Model: DCEVP10
For domestic household use only.
IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR
FUTURE REFERENCE. Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/
OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your
evaporative cooler for the rst time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate surroundings of a
bath, a shower or a swimming pool.
• If the mains lead is damaged it must only be replaced by the manufacturers
service agent or a similarly qualied person in order to avoid a hazard.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the
appliance.
• Disconnect the appliance from mains power whenever it is not in use,
before relocating it, during lling, and before cleaning.
• Never immerse the appliance in water or other liquids.
• Operate this unit only on a rm, at surface to avoid the risk of water
leakage. Ensure that the unit is kept upright at all times.
• Do not place on soft, unstable or non-horizontal/angled surfaces.
• Never operate the appliance if a cable or connector has been damaged,
after appliance malfunction or if the appliance was dropped or is
otherwise damaged.
• Please ask a professional service agent to repair the product. Improper
repair may cause danger to users.
• Operate the appliance only at the voltage specied on the rating label.
• Only connect the unit to a properly installed and easily accessible socket
so that you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension lead.
• This evaporative cooler is only intended for INDOOR RESIDENTIAL
applications. This evaporative cooler should not be used for commercial
or industrial or leisure applications or in small enclosed spaces.
2
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a re or electrocution hazard, NEVER put the cord near heat
registers, radiator, stoves or heaters.
• DO NOT cover cord with carpeting, throw rugs, runners, or similar
coverings.
• DO NOT route cord under furniture or appliances. Take care to position
the cord away from trac areas and where it will not be a tripping
hazard.
• DO NOT use the unit near windows or where water collects. Rain and
water collection may lead to a risk of re or electric shock.
• Only operate this appliance with a minimum of 50cm clearance all
around i.e. away from walls, furniture and overhanging objects such as
curtains or a shelf.
• To prevent spillage, empty the water tank before lifting or relocating the
appliance.
• WARNING: To avoid danger of suocation please remove all packaging
materials particularly plastic and EPS and keep these away from
vulnerable people, children and babies.
• NEVER drop or insert any object or ngers into any openings.
• Do not use the appliance in locations where paint, petrol or other
ammable liquids are used or stored.
• Do not use bug sprays or other ammable cleansers/vapour sprays on
or around the unit.
• Always switch o the unit and take the plug out of the socket:
•
•
•
•
If you are not using the unit
Before you clean or carry out maintenance on the unit
If a fault occurs
In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away
from electrical appliances such as televisions & radios.
3
Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
On a slope or
uneven surface
If an extension
lead may become
overloaded
Where there is risk
of re or close to
a naked ame
Where the power
cable may be
damaged
Where it may be
damaged by
chemicals
Where there is a risk
of interference by
This product is not
made for DIY repair
foreign objects
4
If there is a risk
of water falling on
the unit
Specication
Model no. DCEVP10
Colour
Power supply
Rated power
Speed settings
Modes 3 (natural, normal & sleep)
Turbo air speed 8m/s
Water tank capacity 10L
Remote control Y
Timer 0-15 hours
Swing function Y - Auto
Controls
Max. room size
Water consumption
White/Black
220-240V~, 50Hz
68W
4
Button with LED display
20m²
1.1L/h (high speed)
Weight (net) 9.92kg
Dimensions (w x d x h) 380 x 310 x 760mm
• For greater precision, please always refer to the rating label placed on the product.
5
Parts
Control panel
Horizontal louvers
Display panel
Filter
Water tank
ll opening
Water Tank
Castors
TIMER
OSC.
PRESET
MODE
HUM.
Ice pack x 2Remote
6
Display & Control Panel
Normal
Remote Control
Fan Speed Increase
Left/right swing
Fan Speed Decrease
Mode
OSC.
MODE
TIMER
PRESET
HUM.
On/O
Timer
Humidfy
7
Functions
Note: The buzzer will make a long sound when the power supply is rst
connected and the indicators will ash for 2s. The unit is in ‘standby’ until the ON/
OFF button is pressed.
ON/OFF
After connecting the cord to a power outlet press the ON/OFF button to turn the
unit ON. To turn the unit OFF press this button again.
FAN SPEED
The unit has 4 FAN SPEEDS and is adjusted from the lowest speed to the highest
speed. The selected fan speed LED indicator light will illuminate according to the
FAN SPEED selected.
TIMER / PRESET
The auto-o TIMER can be set in 1 hour increments up to a maximum of 15 hours.
Press the TIMER button while the unit is ON until the desired time is shown on the
LED indicators on the display panel. The unit will automatically turn OFF.
To activate the PRESET mode, press the button while the unit is in Standby mode,
and the unit will be set to turn ON after the PRESET time is complete. The PRESET
time will show on the indicator lights.
MODE
The unit has 3 dierent modes, as described below, and the default mode after
turning ON is normal. Press the MODE button to select modes in this sequence:
normal > natural > sleep. The MODE indicator light will illuminate accordingly.
Normal: Constant wind speed.
Natural: Changing wind speeds to simulate natural wind.
Sleep: Changing wind speeds to simulate natural wind, however the unit will
automatically turn o after 8 hours.
UP/DOWN SWING
Press the UP/DOWN button to start the horizontal swing function. The UP/DOWN
SWING LED indicator light will illuminate. Press the button again to turn o the
function.
LEFT/RIGHT SWING
Press the LEFT/RIGHT button to start the vertical swing function. The LEFT/RIGHT
SWING LED indicator light will illuminate. Press the button again to turn o the
function.
8
Functions
HUMIDIFY
To activate the HUMIDIFY function, press the HUMIDIFY button once to turn on.
Ensure there is enough water in the water tank. The LED indicator light will illuminate
once activated. Press this button again to turn o the HUMIDIFY function, and to
use as a fan only.
The unit is also equipped with the below functions.
LOW WATER PROTECTION
When there is insucient water in the water tank, the pump will stop working for
1 minute, and then the LOW WATER indicator will start to ash. It won't stop the
other functions from working, just the HUMIDIFY function. Fill the water tank if this
happens.
DIM DISPLAY
When the unit is working, after 40 seconds of any buttons being pressed, the
indicator lights will dim. Press any button (except for the ON/OFF button) and the
indicator lights will reactivate.
MEMORY FUNCTION
This unit has a memory function. When the fan is turned OFF, it memorises the
settings previously used. When the unit is turned ON again, it will start in the same
settings as previously used (unless the power supply was fully disconnected). If the
unit was in SLEEP mode previously, it will start in natural wind mode.
AUTO OFF
If there isn't any change in settings after 15 hours of constant use, the unit will turn
OFF automatically. This is an additional safety feature in case the unit is left ON
accidentally.
FILTER REMOVAL PROTECTION
If the lter has been removed during operation (not recommended!), the unit will
stop working until the lter is replaced. The unit will enter standby mode and will
need to be turned ON again if this happens.
REMOTE CONTROL
This unit comes with a remote control, and all settings can be control via the remote.
9
Set Up
IMPORTANT: Never remove the water tank or open the cover when the unit is ON
and operating!
ICE PACKS
The unit comes with 2 x ice packs. Ice packs are used to increase the cooling
capacity. Please place the ice packs in the freezer before use. It takes about 4 hours
to freeze completely - depending on the freezer.
1. Once the ice pack is frozen, place the ice pack in the position by the rear lter
screen - refer to below diagram.
2. Always ensure the unit is OFF before placing or removing the ice pack.
Ice Pack
FILLING THE WATER TANK
This unit has an integrated water tank,
to ll, follow the below directions.
1. Open the latch on the side of the
unit, and if the water tank is already
installed correctly, pour water slowly
and directly into the tank.
2. Keep an eye on the water level
window indicator.
Add water
10
Highest
water level
Lowest
water level
Operation
1. Remove the unit from its packaging
2. To begin using the HUMIDFY function, ensure the water tank is lled with water
by checking the water level window indicator.
3. For extra cooling power, place the ice pack (supplied) into the unit as described
on page 10..
4. Plug into a power supply and press the ON/OFF button to start the appliance.
5. The unit will operate initially on a continual basis. If a set period of operation is
required, please follow the TIMER instructions on page 8.
6. Select the desired fan FAN SPEED by pressing the FAN SPEED button. Refer to
page 8 for dierent settings.
7. Select the operation MODE as required, by pressing the MODE button. Refer to
page 8 for dierent settings.
8. Press the LEFT / RIGHT swing function as required.
9. To switch the unit o at any time, press the OFF button.
Precautions
• Do not overll the water tank (check the MAX ll line).
• Use only cold, clean ltered water.
• The unit is equipped with a number of safety devices, including a water shortage
protection & lter removal protection.
• Do not allow the same water to sit in the machine for a prolonged period.
• It is recommended that any water left in the machine for 3 days or more be removed and replaced with clean water.
• The control panel must not come in contact with water or any other liquids.
Using the Remote Control
1. Open the battery cover of the remote control, and insert a 2 x AAA batteries.
2. Please point to the receiver when using the remote control.
3. If the battery voltage is low, please open the battery cover as per the diagram
and replace with new batteries (2 x AAA). Then replace the battery cover.
11
Cleaning
Your unit is designed to remove dirt and other atmospheric impurities by drawing air
through the air lter. DO NOT block the air lter, as this will impair the eciency of
the unit. Pushing the unit up against a wall or operating it in close proximity to long
window drapes will also impair the unit’s air ow and eciency.
Rear Air Filter
• This is easily accessible by removing the rear screen and lter.
• Disconnect the unit from the main supply & remove the lter. Gently wash the
lter in mild, soapy water, dry and replace. Be sure to re-t the rear screen
securely. No special tools are required for this.
Water tank lter screen
• While the rear air lter is removed, put your hand in the water tank and remove
the small water tank lter by pulling gently upwards.
• Clean the lter with a soft brush and warm water. Replace lter once clean.
Water Tank
The water tank is integrated, however it should be cleaned regularly. If not cleaned,
deposits may build up aecting the eciency of the unit. Cleaning the tank with
mild soapy water once every few weeks is recommended. To do this, follow the steps
below:
1. Disconnect the appliance from the main power supply.
2. Remove the rear air lter.
3. Remove the rubber plug and let any water drain out. Replace the rubber plug and
ll the tank with soapy water and use a cloth to gently wash around.
4. Flush out the soapy water and rinse with clean water until all soap suds are gone..
5. Replace the plug, ll with clean water, and reverse the procedure and ensure the
rear air lter is in place.
Outside Cabinet
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used
for any stubborn marks.
Do not use abrasive sponges, scouring pads, or a sti brush to clean the unit.
IMPORTANT
The control panel and other parts must not come into contact with water or any
other liquids.
12
Maintenance
Storage
If not using the unit for an extended period of time. After cleaning please:
• Turn the unit o, unplug and take care of the mains lead & plug.
•
Cover the unit and store it upright in a location where it will not receive direct sunlight.
NB- Prolonged exposure to direct sunlight will discolour the enclosure.
If you have lost your user manual of the unit fails to operate eciently, is broken or
other problems arise, unplug and do not operate. Ask for advice by calling your local
after sales service agent or the Customer Care Centre on 1300 556 816 (AU) / 0800
666 2824 (NZ).
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landlls or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
13
Customer Care: 1300 556 816
customer.care@glendimplex.com.au
www.dimplex.com.au
Supplied by Glen Dimplex Australia
1340 Ferntree Gully Road, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
14
Loading...
