Aquatic Fitness System
2005 Owner’s Manual
Spa Information
It is very important that you gather the following information on your spa and enter it in the blanks provided
below. This information can then be used to complete your Warranty Registration, which you can do by
completing and mailing the Warranty Registration Card included in your information packet or by visiting our
website at
information will be needed if you want to purchase additional items for your spa, or if service is ever required. Be
sure to consult with your Dealer to ensure the accuracy of this important information.
My Spa:
http://www.D1Spas.com and clicking on Warranty Registration on the Customer Service menu. This
Model Name: Serial Number:
Date Purchased: Date Installed:
Gallons/Liters:
Notes:
Dealer Information:
Dealer’s Name:
Address:
City: State: Zip:
Telephone: Fax:
ii
Aquatic Fitness System
2005 Owner’s Manual
Table of Contents
SPA INFORMATION................................................................................................................................................. II
My Spa:................................................................................................................................................................ii
Dealer Information .............................................................................................................................................ii
AQUATIC FITNESS SYSTEM FEATURES .............................................................................................................. 1
SWIM JETS.......................................................................................................................................................... 1
HYDROTHERAPY JETS .....................................................................................................................................1
HYDROSPORT® AQUATIC FITNESS GEAR .................................................................................................... 1
Swim System ..................................................................................................................................................... 1
Optional Equipment .......................................................................................................................................... 1
Rowing Seat.......................................................................................................................................................2
Swim Tether Mounts.........................................................................................................................................2
Built-in OptiMounts®.........................................................................................................................................2
Multiple Training Stations..................................................................................................................................2
Dynamic LED underwater lighting ..................................................................................................................2
Additional fea ures are: ....................................................................................................................................3
AQUATIC FITNESS SYSTEM PROFESSIONAL MODEL EQUIPMENT PACK .............................................. 3
SAFETY FIRST......................................................................................................................................................... 5
AMERICAN SAFETY INFORMATION ............................................................................................................... 5
IMPORTANT SAFETY INSTRUCTIONS...........................................................................................................5
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY........................................................................5
CANADIAN SAFETY INFORMATION.................................................................................................................7
IMPORTANT SAFETY INSTRUCTIONS (CSA SAFETY INFORMATION)....................................................7
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY........................................................................7
INTERNATIONAL SAFETY INFORMATION...................................................................................................... 9
IMPORTANT SAFETY INSTRUCTIONS...........................................................................................................9
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY........................................................................9
HYPERTHERMIA................................................................................................................................................11
DO’S AND DON’T’S...........................................................................................................................................11
Do’s................................................................................................................................................................11
Don’ts............................................................................................................................................................11
DANGER SIGN .................................................................................................................................................. 12
USING YOUR AQUATIC FITNESS SYSTEM........................................................................................................ 13
BEFORE YOU START....................................................................................................................................... 13
USING THE “POOL-SIDE” TOP SIDE CONTROL........................................................................................... 13
Temperature Set Buttons ..............................................................................................................................14
Jets 1 Button ....................................................................................................................................................14
Jets 2 and Jets 3 Buttons.............................................................................................................................. 15
Light Button...................................................................................................................................................... 15
LED Display Window....................................................................................................................................... 16
PROGRAMMING THE FILTRATION CYCLE ...................................................................................................16
Filtration.............................................................................................................................................................16
Filter Cycles...................................................................................................................................................... 17
Standard Mode........................................................................................................................................... 17
Economy Mode.......................................................................................................................................... 18
Lockout Mode ............................................................................................................................................19
SPA “INCLUDED” –
Additional Features ........................................................................................................................................ 20
Hea er and Circula ion Pump Control......................................................................................................... 20
t t
Smart Heat ...................................................................................................................................................... 20
Operation of the Spa ......................................................................................................................................21
Using The Top Side Control ...................................................................................................................... 21
LED Digital Display Window................................................................................................................. 22
Jets Button ............................................................................................................................................ 22
Light Button........................................................................................................................................... 23
Up and Down Buttons ......................................................................................................................... 24
Program Button.................................................................................................................................... 24
Clock:................................................................................................................................................. 25
Filter Cycle Start Time:..................................................................................................................... 25
:
t
DUAL-TEMP ONLY
........................................................................................................ 20
iii
Aquatic Fitness System
2005 Owner’s Manual
Filter Cycle Duration:........................................................................................................................ 25
Number of Filter Cycles:.................................................................................................................. 25
Temperature Unit: ............................................................................................................................ 26
Heat Indicator Ligh .............................................................................................................................. 26
Dimension One Spas Icon (Logo) Button ......................................................................................... 26
Digital Display Messages.......................................................................................................................... 27
“OH” – Overheat Protection................................................................................................................ 27
Flashing LED on the Control Panel .................................................................................................... 27
Flashing LED on the Control Panel .................................................................................................... 28
Erroneous Temperature on the Display............................................................................................ 28
ROUTINE EQUIPMENT MAINTENANCE............................................................................................................ 29
DRAINING YOUR AQUATIC FITNESS SYSTEM............................................................................................ 29
FILTER CLEANING........................................................................................................................................... 29
AquaFit™ Dual Temp ...................................................................................................................................... 29
AquaFit™ and AquaPro™ ............................................................................................................................... 30
LIGHT BULB REPLACEMENT ........................................................................................................................ 30
SURFACE CARE – SHELL................................................................................................................................31
Care for the Wood Spa Cabinet ...................................................................................................................31
SPECIAL COLD WEATHER INSTRUCTIONS .................................................................................................31
Items Required for Win erizing ..................................................................................................................... 32
r
P ocedure for Winterizing .............................................................................................................................32
Spring Time Startup........................................................................................................................................ 34
WARRANTY SERVICE INFORMATION............................................................................................................... 35
GLOSSARY OF TERMS ....................................................................................................................................... 36
TROUBLESHOOTING GUIDE.............................................................................................................................. 39
HEATING SYSTEM........................................................................................................................................... 39
ELECTRICAL SYSTEM .................................................................................................................................... 39
WATER SYSTEM.............................................................................................................................................. 39
SELF-DIAGNOSTIC CONTROL SYSTEM ...................................................................................................... 40
AquaFit™, AquaFit™Dual Temp (Pool-Side), AquaPro™ ......................................................................... 40
AquaFit™Dual Temp (Spa-Side)...................................................................................................................42
t
t
iv
Aquatic Fitness System
2005 Owner’s Manual
Aquatic Fitness System Features
Congratulations! You have purchased the finest Aquatic Fitness System available. Take the time to
read these instructions carefully. When installed and maintained properly, your Aquatic Fitness
System will provide many years of enjoyable, trouble-free operation. If you have any questions,
please contact your local authorized Aquatic
Fitness System dealer.
Swim Jets
Special high volume swim jets are included
for your swimming pleasure and can also be
used to change the dynamics of your
exercise programs.
HydroTherapy Jets
Special adjustable HydroTherapy Jets are
included so you can relax and enjoy the
pleasures of a spa within your
Aquatic Fitness System.
HydroSport® Aquatic Fitness Gear
The Aquatic Fitness
System is designed to
provide you with a
wide range of aquatic
exercises using
HydroSport® Aquatic
Fitness Gear, such as
the Swim System,
Rowing System,
OPTIMounts®,
HydroSport® Exercise
Bars, and the Aquatic
Fitness Bar.
Swim System
The Swim System,
which is included with
your Aquatic Fitness System,
consists of the Swim Tether, six highvolume Swim Jets and a Swim Kick Bar.
The AquaFit DT 19’ also includes a marked
swim lane to help guide you to a much
improved swimming experience.
Optional Equipment
The remaining components of the HydroSport® Aquatic Fitness Gear are optional equipment
designed to increase the benefits of therapeutic value of the jets with exercise. These items may be
purchased separately from your dealer.
Because swimming and exercising must be done in pairs for safety reasons, the Aquatic Fitness
System is designed to accommodate an additional person for some exercises. Many of the
HydroSport® Aquatic Fitness Gear components may be used simultaneously. For example, a Swim
Tether mount is located at both ends for your convenience in accommodating multiple users.
1
Rowing Seat
A rowing area is
designed into the
Aquatic Fitness
System for use with
the HydroSport®
Rowing System.
Swim Tether Mounts
Swim Tether Mounts
are located at each
end of the Aquatic
Fitness System.
Built-in OptiMounts®
Aquatic Fitness System
2005 Owner’s Manual
Multiple OptiMount®
locations are installed
to provide easy
installation of the
HydroSport® Aquatic
Fitness Gear
components.
Multiple Training Stations
Your Aquatic Fitness
System is equipped
with multiple
OptiMounts® to
accommodate
different
HydroSport®
exercise stations.
Using the
HydroSport® Aquatic
Fitness Gear, you and
your exercise
partner(s) can rotate from station to station. Details on using the included HydroSport® Swim
System are in the accompanying HydroSport® Owner’s Manual.
Dynamic LED underwater lighting
Special lighting effects are created by the underwater Dynamic LED Light which provides
V
isual
Therapy using special customizable lighting effects. Set the mood with easily adjustable
sequences and let these special lighting effects enhance your party atmosphere, or encourage your
quiet relaxation.
2
Aquatic Fitness System
2005 Owner’s Manual
Additional features are:
• Meets or exceeds the requirements of UL1563
Standard for Safety for Electrical Spas as
evaluated and inspected by Edison Test Labs
(ETL).
• Self-contained with load sharing capabilities
• Programmable Digital control
• Automatic high/low speed filtration cycles
• Exclusive, custom hand-set ceramic tile adds
a distinctive touch
• 50 sq. ft. (4.6 m
[150 sq. ft (13.9 m
pool side and 75 sq. ft (6.9
2
) of filtration
2
) of filtration AquaFit DT 19
2
) of filtration spa
side]
Aquatic Fitness System Professional Model Equipment Pack
The Aquatic Fitness System Equipment Pack contains all of the equipment required to provide you
with a safe and pleasurable swimming or aquatic exercise experience. The following equipment will
be located under the skirt panels:
Equipment Control System The electronic control system that governs all of the functions
of your Aquatic Fitness System utilizes an advanced
microprocessor and solid-state electronic switches to activate
all user and maintenance options. A backlit, highly reliable
liquid crystal display gives you a complete update of the
Aquatic Fitness System status at any time of the day or night.
Temperature settings, as well as control of lights, jets, filtration,
and time of day display, are all instantly available from, and
controllable at, the Top Side Control.
Heater An 11kw 230v thermostatically controlled electric heater
equipped with a high-limit temperature safety shut-off switch.
The high-limit switch automatically shuts the heater off if the
temperature reaches 118
switch trips, contact your authorized Aquatic Fitness System
Dealer.
Depending on your particular installation, you may have elected to utilize a remotely
installed gas heater to heat your Aquatic Fitness System water. Please review the
applicable gas heater manufacturer’s owner’s manual for operating instructions.
• 100% foam insulated
• Built-in, automatic freeze protection
• Water level referencing weir skimmer
• A variety of interchangeable jets
• CrystalZone™ Water Management
System
• Long life HydraMax pumps
o
F (≅47.8°C). If the high-limit safety
3
Aquatic Fitness System
2005 Owner’s Manual
Primary Pump Produces water flow through the heater, filter, sanitation
system and the jets in the Aquatic Fitness System. The
primary pump will operate automatically during filtration and
heat cycles. This pump can also be operated manually by
depressing the “jets” button on the Top Side Control which will
allow you to choose between two speeds
• Low speed for efficient water circulation during
heating and filtration modes, and for gentle jet
resistance or massage action.
• High speed for maximum jet action.
Swim Jet Pumps Produce water flow only through the swim jets. The swim jet
pumps are high-speed pumps only. The second and third
pump buttons control these pumps.
4
Aquatic Fitness System
2005 Owner’s Manual
Safety First
Your safety, and the safety of your family and friends, is very important! It is vital to everyone’s safety
that you read and heed the following safety precautions. Review them often.
American Safety Information
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
The following basic safety precautions should always be followed when you are installing, or are
using, this equipment:
•
Safeguard All Children At All Times. Never permit children to use this Aquatic Fitness System
without adult supervision. Always ensure that there is a responsible adult who is competent
in the operation of the Aquatic Fitness System accompanying any child who may use this
Aquatic Fitness System. Always ensure that children are closely supervised at all times in
the vicinity of the Aquatic Fitness System.
•
Risk of Accidental Drowning. Extreme caution must be exercised to prevent unauthorized
access by children. To avoid accidents, ensure that children cannot use this Aquatic Fitness
System unless they are supervised at all times.
•
Risk of Serious Injury or Death. To prevent hair or body entrapment, never operate or use
the Aquatic Fitness System if any of the suction fittings is broken or missing. The suction
fittings of this Aquatic Fitness System are sized to match the specific water flow created by
the circulation and jet pumps. Never replace a suction fitting with one rated less than the
flow rate marked on the original suction fitting. Should the need arise to replace any suction
fittings or the pump(s), be sure that any work if performed by an authorized Aquatic Fitness
System service agent and that flow rates are compatible.
•
Danger: A wire connector marked “Ground” is provided within the power box. To reduce
the risk of electric shock, connect this terminal of connector to the grounding terminal of
your electrical service or supply panel with a continuous green insulating copper wire
equivalent in size to the circuit conductors supplying this equipment, but no smaller than No.
8 AWG (8.4 mm
ground points. To reduce the risk of electrical shock, this connector should be bonded with
a No. 8 AWG (8.4 mm
five feet (1.52 m) of the spa.
•
Risk of Electric Shock. Install at least 5 FEET (1.5m) from all metal surfaces. As an
alternative, an Aquatic Fitness System may be installed within 5 feet (1.5m) of metal surfaces
if each metal surface is permanently connected by a minimum No. 8 AWG (8.4mm²) solid
copper conductor attached to the wire connector on the grounding lug, inside the
equipment compartment on the equipment can.
•
Risk of Electric Shock. Do not permit any electrical appliance, such as a light, telephone,
radio, television, etc., within 5 feet (1.5m) of the Aquatic Fitness System.
•
To Reduce the Risk of Injury. The water in an Aquatic Fitness System should never exceed
104°F (≅40°C). Water temperatures between 100°F (≅38°C) and 104°F (≅40°C) are
considered safe for a healthy adult. Lower water temperatures are recommended when
using the Aquatic Fitness System for exercise, swimming, when total use will exceed 10
minutes, or anytime young children are present in the Aquatic Fitness System.
To Reduce the Risk of Injury. Excessive water temperatures have a high potential for
•
causing fetal damage during the early months of pregnancy. Pregnant or possibly pregnant
women should limit spa water temperatures to 100°F (≅38°C). It is recommended that a
physician be consulted before using an Aquatic Fitness System if you are or possibly could
be pregnant.
•
To Reduce the Risk of Injury. Before entering an Aquatic Fitness System the user should
measure the water temperature with an accurate thermometer since the tolerance of water
temperature-regulating devices may vary as much as +- 5°F (≅2°C).
To Reduce the Risk of Injury. The use of alcohol, drugs or medication before or during
•
Aquatic Fitness System use may lead to unconsciousness with the possibility of drowning.
2
). In addition, a second wire connector is provided for bonding to local
2
) copper wire to any metal ladders, water pipes, or other metal within
5
Aquatic Fitness System
To Reduce the Risk of Injury. Persons suffering from obesity or with a medical history of
•
heart disease, low or high blood pressure, circulatory system problems, or diabetes should
consult a physician before using an Aquatic Fitness System.
To Reduce the Risk of Injury. Persons using medication should consult a physician before
•
using an Aquatic Fitness System because some medications may induce drowsiness, while
other medications may affect heart rate, blood pressure, and circulation.
•
Risk of Electric Shock. The electrical supply for this Aquatic Fitness System must include a
suitably rated switch or circuit breaker to open all ungrounded supply conductors to comply
with Section 680-42 of the National Electrical Code, ANSI/NFPA 70-1993. The disconnect
must be readily accessible and visible to the Aquatic Fitness System occupants from the
Aquatic Fitness System or the surrounding area, but it must be installed at least 5 feet (1.5m)
from the spa water.
•
Risk of Accidental Drowning. Never Enter, Use, Swim or Exercise alone in the Aquatic
Fitness System. Never allow anyone to enter, use, swim or exercise in the Aquatic Fitness
System unsupervised.
•
Risk of Serious Injury of Death. Diving or Jumping Into the Aquatic Fitness System is
Forbidden. Serious injury, paralysis or death can occur if user jumps of dives into the Aquatic
Fitness System. The Aquatic Fitness System is not designed for jumping of diving. Extreme
caution must be exercised to prevent anyone from jumping or diving into the Aquatic
Fitness System.
•
Risk of Serious Injury or Death. Do not remove the “No Jumping / No Diving Appliqués from
the Aquatic Fitness System!
Risk of Serious Injury or Death. Do not walk, stand or sit on the top rail of the Aquatic Fitness
•
System. Serious injury, paralysis or death can occur is user falls from the top rail of the
Aquatic Fitness System to the ground or into the Aquatic Fitness System.
To Reduce the Risk of Injury. Do not exercise in water temperature above 90°F (≅32.2° C).
•
Recommended water temperature for hydrotherapy is higher than the recommended
temperature for aquatic exercise.
•
To Reduce the Risk of Injury. Prolonged immersion in an Aquatic Fitness System may be
injurious to your health
•
To Reduce the Risk of Injury. Always consult with a physician prior to beginning any exercise
regimen utilizing the Aquatic Fitness System. Do not overexert yourself. Take frequent
breaks.
To Reduce the Risk of Injury. Always wear shatterproof swim goggles when using
•
HydroSport® resistance exercise or rowing equipment. Improper use of HydroSport®
equipment or use of aged or worn equipment could result in an eye injury if protective
eyewear is not used. Every HydroSport®equipment package includes protective eyewear.
If your protective eyewear is missing or defective, do not use the HydroSport® equipment
until you have replaced the protective eyewear with similar shatterproof swim goggles.
•
To Reduce the Risk of Injury. Do not use an Aquatic Fitness System immediately following
strenuous exercise.
•
To Reduce the Risk of Injury. People with infectious diseases should not use Aquatic Fitness
System.
To Reduce the Risk of Injury. Wet surfaces can be slippery. To avoid injury exercise care
•
when entering or exiting the Aquatic Fitness System.
To Reduce the Risk of Injury. Maintain water chemistry in accordance with manufacturer’s
•
instructions. Proper chemical maintenance of Aquatic Fitness System water is necessary to
maintain safe water and prevent possible damage to Aquatic Fitness System components.
•
To Reduce the Risk of Injury. Use the Aquatic Fitness System straps and clip tie downs to
secure the cover when not in use. This will help to discourage unsupervised children from
entering the Aquatic Fitness System and keep the Aquatic Fitness System cover secure in
high wind conditions. There is no representation that the cover, clip tie downs or actual
locks will prevent access to the Aquatic Fitness System.
•
To Reduce the Risk of Injury. Never attempt to change the light without draining the water
completely below the light fitting.
•
WARNING: The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in
an Aquatic Fitness System.
SAVE THESE INSTRUCTIONS
2005 Owner’s Manual
6
Aquatic Fitness System
2005 Owner’s Manual
Canadian Safety Information
IMPORTANT SAFETY INSTRUCTIONS (CSA SAFETY INFORMATION)
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
When using this electrical equipment, basic safety precautions should always be followed, including
the following:
• A green colored terminal or a terminal marked G, GR, Ground, Grounding, or the symbol * is
located inside the supply terminal box or compartment. To reduce the risk of electric shock,
this terminal must be connected to the grounding means provided in the electric supply
service panel with a continuous copper wire equivalent in size to the circuit conductors
supplying this equipment.
o IEC Publication 417, Symbol 5019.
• At least two lugs marked “BONDING LUGS” are provided on the external surface or on the
inside of the supply terminal box/compartment. To reduce the risk of electric shock,
connect the local common bonding grid in the area of the hot tub or spa to these terminals
with an insulated or bare copper conductor not smaller than No. 6 AWG.
• All field-installed metal components such as rails, ladders, drains or other similar hardware
within 3 meters of the spa or hot tub shall be bonded to the equipment grounding bus with
copper conductors not smaller than No. 6 AWG.
• Children should not use spas or hot tubs without adult supervision.
• AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION
SANS SURVEILLANCE
• Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair
entrapment.
• AVERTISSEMENT: POUR ÉVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS
PUISSENT TRE ASPIRÉS, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DE
PRISE D’ASPIRATION NE SONT PAS TOUTES EN PLACE.
• People using medications and/or having adverse medical history should consult a physician
before using a spa or hot tub.
• AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MÉDICAMENTS OU ONT DES
PROBLÈMES DE SANTÉ DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER USE
CUVE DE RELAXATION.
• People with infectious diseases should not use a spa or hot tub.
• AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE
DEVRAIENT PAS UTILISER UNE CUVE DE RELAXATION.
• To avoid injury, exercise care when entering or exiting the spa or hot tub.
• AVERTISSEMENT: POUR ÉVITER DES BLESSURES, USER DE PRUDENCE EN ENTRANT
DANS UNE CUVE DE RELAXATION ET E SORTANT.
• Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid
unconsciousness and possible drowning.
• AVERTISSEMENT: POUR ÉVITER L’ÉVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE
PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI
QUAND ON S’Y TROUVE.
• Pregnant or possibly pregnant women should consult a physician before using a spa or hot
tub.
• AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMÉE
OU NON, DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE DE
RELAXATION.
• Water temperature in excess of 38° C may be injurious to your health.
• AVERTISSEMENT: IL PEUT TRE DANGEREUX POUR LA SANTÉ DE SE PLONGER DANS DE
L’EAU À PLUS DE 38°C.
• Before entering the spa or hot tub, measure the water temperature with an accurate
thermometer.
• AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE RELAXATION MESURER LA
TEMPÉRATURE DE L’EAU À L’AIDE D’UN THERMOMÈTRE PRÉCIS.
• Do not use a spa or hot tub immediately following strenuous exercise.
• AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION IMMEDIATEMENT APRÈS
UN EXERCICE SATIGANT.
.
7
Aquatic Fitness System
2005 Owner’s Manual
• Prolonged immersion in a spa or hot tub may be injurious to your health.
• AVERTISSEMENT: L’UTILISATION PROLONGÉE D’UNE CUVE DE RELAXATION PEUT TRE
DANGEREUSE POUR LA SANTÉ.
• Do not permit electric appliances (such as a light, telephone, radio, television, etc.) within
1.5m of this spa or hot tub.
• AVERTISSEMENT: NE PAS PLACER D’APPAREIL ÉLECTRIQUE (LUMINAIRE, TÉLÉPHONE,
RADIO, TÉLÉVISEUR, ETC.) À MOINS DE 1.5 M DE CETTE CUVE DE RELAXATION.
• Maintain water chemistry in accordance with manufacturer’s instructions.
• ATTENTION: LA TENEUR DE L’EAU EN MATIERÈS DISSOUTES DOIT TRE CONFORME AUX
DIRECTIVES DU FABRICANT.
• The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in hot tubs
and spas.
• AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE
CONSIDÈRABLEMENT LES RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE
RELAXATION.
• Persons suffering from heart disease, diabetes, high or low blood pressure, any condition
requiring medical treatment, pregnant women, the elderly, or infants should consult with a
physician before using a spa.
• The consumer products safety commission has stated that the water temperature in a spa
or hot tub should not exceed 104° F (40° C). Immersion in water in excess of 104° F (40° C)
can be hazardous to your health.
• Observe a reasonable time limit when using the spa. Long exposures at higher
temperatures can cause high body temperature. Symptoms may include dizziness, nausea,
fainting, drowsiness, and reduced awareness. These effects could result in possible
drowning.
• Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use of the spa
under these conditions may lead to serious consequences.
• Always test the hot tub water temperature before entering the spa. Enter and exit the spa
slowly. Wet surfaces can be very slippery.
• Never bring any electrical appliances into or near the spa. Never operate any electrical
appliances from inside the spa or when you are wet.
• Proper chemical maintenance of spa water is necessary to maintain safe water and prevent
possible damage to spa components.
• Use the spa straps and clip tie downs to secure the cover when not in use. This will help to
discourage unsupervised children from entering the spa and keep the spa cover secure in
high wind conditions. There is no representation that the cover, clip tie downs, or actual
locks will prevent access to the spa.
SAVE THESE INSTRUCTIONS.
8
Aquatic Fitness System
2005 Owner’s Manual
International Safety Information
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
When using this electrical equipment, basic safety precautions should always be followed, including
the following:
•
DANGER:
unauthorized access by children. To avoid accidents, ensure that children cannot use this
spa unless they are supervised at all times.
DANGER:
•
the specific water flow created by the pump. Should the need arise to replace the suction
fittings or the pump, be sure that the flow rates are compatible.
Never operate the spa if the suction fittings are broken or missing. Never replace a suction
fitting with one rated less than the flow rate marked on the original suction fitting.
•
DANGER:
As an alternative, a spa may be installed within 5 feet of metal surfaces if each metal surface
is permanently connected by a minimum 8.4 mm
attached to the wire connector on the grounding lug, inside the equipment compartment on
the equipment can.
DANGER:
•
telephone, radio, television, etc. within 1.5 meters (5 feet) of a spa.
•
DANGER: The electrical supply for this spa must include a suitably rated switch or circuit
breaker to open all ungrounded supply conductors to comply with local or national wiring
requirements. The disconnect must be readily accessible and visible to the spa occupant
but installed at least 1.5 meters (5 feet), from the spa water.
•
DANGER: A grounding wire connector is provided on this spa to connect a minimum 8.4
mm
metal enclosures of electrical equipment, metal water pipe, or conduit within 1.5 meters (5
feet) of the spa.
•
WARNING:
(104°F). Water temperatures between 38° C (100° F) and 40° C (104° F) are considered safe
for a healthy adult. Lower water temperatures are recommended for young children and
when spa use exceeds 10 minutes.
•
WARNING:
potential for causing fetal damage during the early months of pregnancy, pregnant or
possibly pregnant women should limit spa water temperatures to 38° C (100° F).
•
Risk o Accidental D owning.
f r
Risk of Serious Injury or Death.
Risk o Electric Shock.
f
Risk o Electric Shock.
f
2
(No. 8 AWG) solid copper conductor between this unit and any metal equipment,
To Reduce the Risk of Injury:
To Reduce the Risk of Injury:
Extreme caution must be exercised to prevent
The suction fittings in this spa are sized to match
Install at least 1.5 meters (5 feet), from all metal surfaces.
2
(No. 8 AWG) solid copper conductor
Do not permit any electrical appliance, such as a light,
The water in a spa should never exceed 40° C
Since excessive water temperatures have a high
9
Aquatic Fitness System
WARNING
water temperature with an accurate thermometer since the tolerance of water
temperature-regulating devices may vary as much as +/- 2° C (5° F).
WARNING:
•
during spa use may lead to unconsciousness with the possibility of drowning.
•
WARNING:
history of heart disease, low or high blood pressure, circulatory system problems, or
diabetes should consult a physician before using a spa.
•
WARNING:
physician before using a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.
•
WARNING: Do not attempt to remove the light housing cover without lowering the water
level below the light housing cover.
WARNING: The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in
•
hot tubs and spas.
•
CAUTION: Persons suffering from heart disease, diabetes, high or low blood pressure, any
condition requiring medical treatment, pregnant women, the elderly, or infants should
consult with a physician before using a spa.
•
CAUTION: The consumer products safety commission has stated that the water
temperature in a spa or hot tub should not exceed 40° C (104° F). Immersion in water in
excess of 40° C (104° F) can be hazardous to your health.
CAUTION: Observe a reasonable time limit when using the spa. Long exposures at higher
•
temperatures can cause high body temperature. Symptoms may include dizziness, nausea,
fainting, drowsiness, and reduced awareness. These effects could result in possible
drowning.
•
CAUTION: Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use
of the spa under these conditions may lead to serious consequences.
•
CAUTION: Always test the hot tub water temperature before entering the spa. Enter and
exit the spa slowly. Wet surfaces can be very slippery.
CAUTION: Never bring any electrical appliances into or near the spa. Never operate any
•
electrical appliances from inside the spa or when you are wet.
•
CAUTION: Proper chemical maintenance of spa water is necessary to maintain safe water
and prevent possible damage to spa components.
•
CAUTION: Use the spa straps and clip tie downs to secure the cover when not in use. This
will help to discourage unsupervised children from entering the spa and keep the spa cover
secure in high wind conditions. There is no representation that the cover, clip tie downs, or
actual locks will prevent access to the spa.
:
To Reduce the Risk of Injury:
To Reduce the Risk of Injury:
To Reduce the Risk of Injury:
To Reduce the Risk of Injury:
SAVE THESE INSTRUCTIONS.
2005 Owner’s Manual
Before entering a spa, the user should measure the
The use of alcohol, drugs, or medication before or
Persons suffering from obesity or with a medical
Persons using medication should consult a
10
Aquatic Fitness System
2005 Owner’s Manual
Hyperthermia
Prolonged immersion in hot water may induce hyperthermia. A description of the causes,
symptoms, and effects of hyperthermia are as follows: Hyperthermia occurs when the internal
temperature of the body reaches a level several degrees above the normal body temperature of
98.6° F, or 37° C. The symptoms of hyperthermia include dizziness, drowsiness, lethargy, and
fainting. The effects of hyperthermia include:
• Failure to perceive heat
• Failure to recognize the need to exit spa
• Unawareness of impending hazard
• Fetal damage in pregnant women
• Physical inability to exit spa
• Unconsciousness resulting in the danger of drowning
DO’S AND DON’T’S
Do’s
• DO read all operating instructions.
• DO read, understand and follow all Safety, Danger and Warning instructions before use.
• DO test water temperature with your hand before entering to be sure that it is comfortable.
• DO keep the Aquatic Fitness System cover closed when the Aquatic Fitness System is not
in use. This is also the key to economical Aquatic Fitness System operation.
Don’ts
• DON’T allow horseplay or unsupervised use of your Aquatic Fitness System.
• DON’T block or sit on the filter recess area.
• DON’T allow anyone to tamper or play with any of the safety or suction fittings of your
Aquatic Fitness System.
11
Aquatic Fitness System
2005 Owner’s Manual
DANGER SIGN
Every Aquatic Fitness System has been
provided with a warning sign, which outlines
safety precautions. Read and familiarize
yourself with all warnings listed on this sign and
install the sign in a conspicuous place
accessible to all who use your Aquatic Fitness
System.
This sign must be permanently placed in a
location that is visible to the Aquatic Fitness
System user. Replacement signs may be
obtained from:
Dimension One Spas, Inc.
2611 Business Park Drive
Vista, CA 92081
Be sure to use your Serial Number whenever
contacting your dealer or Dimension One Spas
Inc. The Serial Number can be found on the
bottom of the frame, beneath the skirt paneling,
directly below the Top Side Control.
12
Aquatic Fitness System
2005 Owner’s Manual
Using Your Aquatic Fitness System
Before you Start
To complete the installation of your Aquatic Fitness System you must add
water. Your dealer cannot complete safety checks, test equipment
operation, or conduct initial training until you have added water. The
Aquatic Fitness System should be filled until the water level is
approximately in the middle of the tile line.
Do not attempt to use your Aquatic
Fitness System until your dealer has
completed all required tests.
When your dealer has completed required testing and determined the
Aquatic Fitness System is ready for your use, he will show you how to
operate the Top Side Control and change the filter.
Using The “Pool-Side” Top Side Control
The Top Side Control is used to monitor and manage your Aquatic Fitness System.
13
Aquatic Fitness System
2005 Owner’s Manual
Temperature Set Buttons
Tem ase
perature Set Buttons: Press the “Warmer” Up Arrow button to incre
the
desired temperature. Press the “Cooler” Down Arrow button to decrease
the
temperature. The temperature set point can be adjusted in 1°F (≅0.5°C)
incr
ements from 65°F to 104°F (≅18.3°C to ≅40°C). The new setting will remain
on
the display for 5 seconds as a confirmation.
This
new temperature setting is referred to as the “set
tem
perature” setting throughout this document. It refers to the
wa
ter temperature that you want the system to maintain for you
(e.g
. 99°F or ≅37.2°C).
Wh
en the temperature drops to 2°F (≅1.1°C) below the set temperature, the
ea
ter will turn on until the temperature is 2°F (≅1.1°C) above the set
h
em
perature.
t
In a
ddition to setting the desired water temperature, these two buttons are
also d in
used to change the filter cycles. More information on this is containe
the
section on “
Programming the Filtration Cycle.”
The
Heat Indicator Light, located between the UP and DOWN Arrow Buttons, will light
up w s not
hile the heater is on and flash when there is a call for heat and the heater ha
yet
been activated.
Jets 1 Button
JETS 1 Button: Press the button once to turn on Pump 1 to Low Speed. A
second press will turn it to High Speed. A third press will typically turn the
pump off, unless the pump has been automatically activated during a heating
cycle – in which case a third press will return the pump to Low Speed. A built-in
timer will automatically shut the pump off after 20 minutes of operation unless
you manually shut if off sooner. The Jets 1 Indicator light will be lit next to the
Jets 1 Button while the pump is running.
Pump 1 provides low or high volume water flow to both the Swim Jets and
HydroTherapy Jets on the AquaFit™ and AquaPro™. The Diverter Valve
controls which set of jets gets the water, and how much is provided. The
AquaFit™ Dual Temp has separate pumps for the Swim Jets and the
HydroTherapy Jets.
Pump 1 also runs on low speed during all filter and heating cycles. If the system is in a
filter cycle, the indicator light for JETS 1 will be on. If you manually press the JETS 1
button, this specific filter cycle will be disabled.
14
Aquatic Fitness System
2005 Owner’s Manual
Jets 2 and Jets 3 Buttons
JETS 2 and JETS 3 Buttons: Press the appropriate button once to turn on
Pumps 2 or 3. The pumps work independently, thus allowing you to control
the total volume of water pumped to the Swim Jets. Pressing either button a
second press will turn that pump(s) off.
A built-in timer will shut the pump(s) off after 20 minutes of operation unless
you manually shut them off earlier. The Jets 2 or Jets 3 Indicator light will be lit
next to the Jets 2 or Jets 3 Button whenever that Jet is running.
Pumps 2 and 3 provide high volume water flow to the Swim Jets.
If you are operating with a 60-amp service for heat and pumps, the heater will turn
off if any of the pumps are operated at high speed. If you are running a separate 50amp service for heat and a separate 50-amp service for the pumps, you can
continue to heat your water while operating the pumps at high speed.
Light Button
Push the Light Button to control your Dynamic LED lighting. This includes both
Spa lights, which are synchronized to operate together. The lights have three
basic Color Effects you can choose. Simply press the Light Button until you
find the one you want. The Color Effects are:
For your convenience and cost savings, the lights will automatically turn off after
one hour. To reactivate the lights after the timer has shut them off, simply press the
Light Button again. The lights will always start in the Color Fade Slow sequence
after they have been off for more than 5 seconds. This ensures they always remain
synchronized in multiple light spas.
• Color Fade Slow: This sequence rotates through all colors
approximately once per minute.
• Color Hold: Hold on any of the colors.
• Color Fade Fast: This sequence rotates through all colors
approximately three times per minute.
The default Color Effect is Color Fade Slow. Use the Light Button to change
Color Effects as follows:
• Start on Color Fade Slow (default)
• Turn off for 1 second, back on again for Color Hold
• Turn off for 1 second, back on again for Color Fade Fast
• Turn off for 1 second, back on again for Color Hold
• Turn off for 1 second, back on repeats to Color Fade Slow
• Turn off for 5 or longer: start on Color Fade Slow
(Start up default)
15
Aquatic Fitness System
2005 Owner’s Manual
LED Display Window
LED Display Window: This window displays the actual water temperature.
However when you are setting the “target temperature” for your water, this
window will display the SET temperature. After a brief pause, about 5 seconds,
the window will return the display to the actual water temperature.
Programming the Filtration Cycle
Filtration
Proper filtration is an important key to maintaining the clarity of your spa’s water. The filter system is
designed for unsurpassed effectiveness at removing debris and suspensions from the water
anytime the water is circulating.
The Aquatic Fitness System comes with six pre-programmed filtration cycles (F1-F6) and two
lockout (L1 & L2) modes. Of the six filter cycles, three cycles are in the standard mode and three
cycles are in the economy mode.
To change the filter cycle or to enable or disable a lockout mode, press and
hold both the WARMER and the COOLER buttons for 3 seconds. This enters
the programming mode and allows you to select your filtration cycle. The
display will show F1 through L2. The current filter setting
will be displayed in the window.
Use the WARMER and COOLER buttons to scroll up or
down between the filtering modes. The filter cycles are as
follows:
• Standard Mode: F1, F2, F3
• Economy Mode: F4, F5, F6
• Lockout Mode: L1, L2
Standard Mode and Economy Mode are used primarily to determine how to heat your water. When
you select a filter cycle of F1, F2, or F3, you are selecting Standard Mode. In Standard Mode the
temperature of the water is used to determine the need for heat. Whenever the temperature of the
water drops to 2°F (≅1.1°C) below your SET temperature, the pump will start and the water will heat
until the water is 2°F (≅1.1°C) above your SET temperature. In Standard Mode, heating the water is
independent of the filter cycles.
When you select a filter cycle of F4, F5, or F6, you are selecting Economy Mode. In Economy Mode,
the water only heats when the filter us running. In Economy Mode, heating the water is dependent
on the filter cycle.
When you select options L1, or L2, you are selecting the
suspend filter operation or control unauthorized access to your system.
Lockout Mode, which allows you to
16
Aquatic Fitness System
2005 Owner’s Manual
Filter Cycles
Standard Mode
Standard Mode heating is automatically controlled by the loss of water temperature. If the spa
water drops 2°F (≅1.1°C) below the set temperature, the low speed pump and the heater will
automatically turn on. They will both remain on until the water temperature reaches the
temperature set point.
In this mode, the filter cycle operates independently of the need for heat to ensure
proper filtration.
Set the display to F1 to receive two (2) hours of filtration twice a day. To select
filter cycle F1, press and hold the Warmer and Cooler Buttons for three (3)
seconds. Then press the Warmer (Up) Button, or the Cooler (Down) Button
until you see F1 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration twice
a day and maintain your water temperature separately. The programming
mode will automatically store your choice and exit if you don’t make another
change within three (3) more seconds.
Set the display to F2 to receive two (2) hours of filtration three times a day. To
select filter cycle F2, press and hold the Warmer and Cooler Buttons for three
(3) seconds. Then press the Warmer (Up) Button, or the Cooler (Down)
Button until you see F2 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration three
times a day and maintain your water temperature separately. The
programming mode will automatically store your choice and exit if you don’t
make another change within three (3) more seconds.
Set the display to F3 to receive two (2) hours of filtration four times a day. To
select filter cycle F3, press and hold the Warmer and Cooler Buttons for three
(3) seconds. Then press the Warmer (Up) Button, or the Cooler (Down)
Button until you see F3 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration four
times a day and maintain your water temperature separately. The
programming mode will automatically store your choice and exit if you don’t
make another change within three (3) more seconds.
17
Aquatic Fitness System
2005 Owner’s Manual
Economy Mode
In this mode, the timer determines when the filtering and heating take place.
If the LED Digital Display Window displays COL and ICE, Cool or Ice conditions have
been discovered. These conditions take precedence over the Economy Mode. Heat
will be applied as required by the identified condition regardless of the filter cycle. See
the
Troubleshooting Guide for more information.
Set the display to F4 to receive two (2) hours of filtration and heat twice a day.
To select filter cycle F4, press and hold the Warmer and Cooler Buttons for
three (3) seconds. Then press the Warmer (Up) Button, or the Cooler (Down)
Button until you see F4 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration twice
a day and heat your water only during filter cycles. The programming mode
will automatically store your choice and exit if you don’t make another change
within three (3) more seconds.
Set the display to F5 to receive two (2) hours of filtration and heat three times
a day. To select filter cycle F5, press and hold the Warmer and Cooler Buttons
for three (3) seconds. Then press the Warmer (Up) Button, or the Cooler
(Down) Button until you see F5 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration three
times a day and heat your water only during filter cycles. The programming
mode will automatically store your choice and exit if you don’t make another
change within three (3) more seconds.
Set the display to F6 to receive two (2) hours of filtration and heat four times a
day. To select filter cycle F6, press and hold the Warmer and Cooler Buttons
for three (3) seconds. Then press the Warmer (Up) Button, or the Cooler
(Down) Button until you see F6 displayed in the window.
You have now successfully selected to receive two (2) hours of filtration four
times a day and heat your water only during filter cycles. The programming
mode will automatically store your choice and exit if you don’t make another
change within three (3) more seconds.
18
Lockout Mode
Aquatic Fitness System
2005 Owner’s Manual
LOCKOUT – This special feature can be used when cleaning or changing the
filter cartridge, or when doing any type of non-electrical servicing that requires
the pump operation to be suspended while the work is completed.
To select Lockout Mode L1, press and hold the Warmer and Cooler Buttons
for three (3) seconds. Then press the Warmer (Up) Button, or the Cooler
(Down) Button until you see L1 displayed in the window.
You have now successfully selected Lockout Mode. The programming mode
will automatically store your choice and exit if you don’t make another change
within three (3) more seconds. The temperature display flashes in this
function.
If the control is heating when the system is put into the lockout mode, the heater will
immediately turn off and the pump will cycle water for thirty seconds, then turn off.
This will assist in cooling the heat element
PANEL LOCKOUT – Special feature to prevent unauthorized use of your spa.
The Top Side Control incorporates a unique panel locking system that disables
the control buttons on the panel.
To select Panel Lockout L2, press and hold the Warmer and Cooler Buttons
for three (3) seconds. Then press the Warmer (Up) Button, or the Cooler
(Down) Button until you see L2 displayed in the window.
You have now successfully selected Panel Lockout. The programming mode
will automatically store your choice and exit if you don’t make another change
within three (3) more seconds.
The temperature display flashes in this function.
In this mode the system will only operate as if the filter cycle had been set to
F1.
19
Aquatic Fitness System
2005 Owner’s Manual
Spa “Included” –
Congratulations, AquaFit™Dual Temp Owners! You not only get the pleasures of aquatic exercise in
the “pool side,” you also have a “dedicated spa” on the other side. Take the time to read these
additional instructions carefully because they contain information specific to the spa portion of your
Aquatic Fitness System. If you have any questions, please
One Spas Dealer.
The spa side is completely “self-contained” from the pool side. This means that the water in the spa
circulates through its own closed system – including pumps and jets. It contains a separate filtration
system and the water chemistry must also be managed separately using the guidelines contained in
the
Water Care Guide Part No. 01513-192
The following features are included on your spa:
• Meets or exceeds the most stringent requirements of UL1563 Standard for Safety for Electrical
Spas as evaluated and inspected by Edison Test Labs (ETL).
• Completely self-contained with load sharing capabilities
• 100% foam insulated
• Top access, easy to clean filter systems
• Water level referencing weir skimmer
• Proportional FastFlo™ Heater
• A variety of interchangeable jets
• Exclusive, custom hand-set ceramic tile adds a distinctive touch
• Built-in, automatic freeze protection
• Automatic high/low speed filtration cycles
Dual-Temp Only
.
contact your local Authorized Dimension
Additional Features
• Programmable Digital control with digital display
• CrystalZone® Water Management System
• Long life, dual speed HydraMax pump
• Dynamic LED Lighting
• 75 sq. ft. (6.97 m
2
) of filtration
Heater and Circulation Pump Control
On all Dimension One Spas, when the water temperature is 1° F (≅0.55° C) below the set
temperature the heater will turn on and remain on until the water temperature rises to 1° F (≅0.55° C)
above the set temperature. To prevent the spa from overheating, the circulation pump turns off
when the water temperature rises 2° F (≅1.1° C) above the set temperature. When the water
temperature cools down to the set temperature, the circulation pump will turn on.
The circulation pump will run for short periods when the water temperature is 2° F
(≅1.1° C) above set temperature to provide optimum operation.
Smart Heat
Smart Heat optimizes heat recovery using the amperage that you have available. Along with
computerized load sharing, that automatically recognizes the number of jet pumps in use,
compares it with the available power, Smart Heat recognizes the difference between the set
temperature and the actual water temperature, and adjusts the heater to optimize the heater
output.
20
Aquatic Fitness System
2005 Owner’s Manual
Operation of the Spa
Using The Top Side Control
Advanced microprocessor technology has been utilized to produce the Programmable Digital
Control. Easy to use and understand, Dimension One Spas has put every hot tub function within
fingertip control.
Temperature setting, jet power control, and the
hot tub light are all spa-side accessible. That
means you don’t have to get out of the hot tub
to enjoy complete control of all hot tub
functions. Safety is assured through design
concepts and materials that meet or exceed
the most stringent requirements of UL1563
Standard for Safety for Electrical Spas as
evaluated and inspected by Edison
Test Labs (ETL).
Digital
Control lets
you relax and enjoy
everything your spa has to
offer.
21
LED Digital Display Window
Jets Button
Pushing the JETS Button will disable any concurrent filter cycle.
Aquatic Fitness System
2005 Owner’s Manual
LED Digital Display Window: This window displays the actual
water temperature in either °F or °C. It will also display time, filter
cycle start time, filter cycle duration time, and the number of filter
cycles.
When you are setting the “target temperature” for your water,
this window will display the target temperature. After a brief
pause, about 5 seconds, the window will return the display to
the actual water temperature.
Jets Button: Press the button once to turn on the pump
to Low Speed. A second press will turn it to High Speed.
A third press will typically turn the pump off, unless the
pump has been automatically activated during a heating
cycle – in which case a third press will return the pump to
the Low Speed. The Jets Indicator Light, next to the Jets
Button, will be lit while the pump is running. A Jet Pump
Icon will also display in the upper left corner of the LED
Digital Display Window whenever the pump is running.
A built-in timer will automatically shut the pump off after
30 minutes of operation unless you turn it off manually.
When the pump is first turned on, a small scale will be
displayed in the lower left corner of the LED Digital Display
Window.
This Jet Button controls water flow only for the spa side of
the AquaFit™ Dual Temp.
When the Jets Indicator Light, the Light Indicator Light,
and the Heat Indicator Light are flashing, they indicate a
problem with your spa. See the
for more details.
Troubleshooting Section
22
Light Button
Aquatic Fitness System
2005 Owner’s Manual
Push the Light Button to control your Dynamic LED
lighting. The light hase three basic Color Effects you can
choose. Simply press the Light Button until you find the
one you want. The Color Effects are:
• Color Fade Slow: This sequence rotates through
The default Color Effect is Color Fade Slow. Use the Light
Button to change Color Effects as follows:
When the Light Indicator Light, the Jets Indicator Light,
and the Heat Indicator Light are flashing, they indicate a
problem with your spa. See the
for more details.
For your convenience and cost savings, the light will automatically turn off after
one hour. To reactivate the light after the timer has shut off, simply press the
Light Button again. The light will always start in the Color Fade Slow sequence
after it hase been off for more than 5 seconds.
all colors approximately once per minute.
up default)
• Color Hold: Hold on any of the colors.
• Color Fade Fast: This sequence rotates through
all colors approximately three times per minute.
• Start on Color Fade Slow (default)
• Turn off for 1 second, back on again for Color
Hold
• Turn off for 1 second, back on again for Color
Fade Fast
• Turn off for 1 second, back on again for Color
Hold
• Turn off for 1 second, back on repeats to Color
Fade Slow
• Turn off for 5 or longer: start on Color Fade Slow
Troubleshooting Section
(Start
23
Up and Down Buttons
Program Button
Aquatic Fitness System
2005 Owner’s Manual
Up (+) and Down (-) Buttons: Pushing the UP (+) Button
increases the temperature and pushing the DOWN (-) Button
decreases the temperature. Push the respective button one
time for each degree of temperature change you want, or “push
and hold” the button for rapid adjustment.
The actual spa water temperature is normally displayed in the
LED Digital Display Window until you push the UP (+) or DOWN () Button or the Program Button. If you push the UP (+) Button or
the DOWN (-) Button the LED Digital Display Window will change
to indicate your target temperature setting. The LED Digital
Display Window will also display the SET TEMPERATURE Icon in
the lower right side of the Window to indicate the temperature
shown in the window is a target setting and not the actual
temperature. The Temperature Icon will also be displayed along
the top of the window if your new setting requires more heat.
Once the new temperature is set, the actual spa water
temperature will again be indicated. The spa will heat to the new
temperature automatically.
Program Button: The PROGRAM Button is used to set several
different functions including:
Programmable Item Program Button Action
Clock Press & Hold 5 seconds
Filter Cycle Start Time 2nd Press
Filter Cycle Duration 3rd Press
Number of Filter Cycles 4th Press
Temperature Unit 5th Press
Quit Program sequence 6th Press or wait 60 seconds
When you have successfully entered the programming
sequence, the word “PROGRAM” will be displayed in the LED
Digital Display Window.
You can now start to program your spa controls.
24
Clock:
Filter Cycle Start Time:
Filter Cycle Duration:
Number of Filter Cycles:
Long and/or numerous filter cycles could cause overheating of the hot tub especially in hot climates.
Aquatic Fitness System
2005 Owner’s Manual
Program the Clock by pressing the PROGRAM button and
holding it for about 5 seconds. The LED Digital Display Window
will display the word PROGRAM and a digital clock with the
HOUR setting flashing. Use the UP or DOWN buttons to
change to the correct HOUR. When the HOUR is correct, press
the LIGHT Button to toggle to the MINUTES side of the time.
Use the UP or DOWN buttons to change to the correct
MINUTES. When the MINUTES are correct, press the LIGHT
Button to toggle the AM/PM.
Program the Filter Cycle Start Time by pressing the PROGRAM
Button a 2
setting, the FILTER Icon will be displayed next to the word
PROGRAM in the LED Digital Display Window.
To adjust the Filter Cycle Start Time use the UP or DOWN
buttons to change to the correct HOUR. When the HOUR is
correct, press the LIGHT Button to toggle to the MINUTES side
of the time. Use the UP or DOWN buttons to change to the
correct MINUTES. When the MINUTES are correct, press the
LIGHT Button to toggle the AM/PM.
Program the Filter Cycle Duration by pressing the PROGRAM
Button a 3
setting, the FILTER Icon will be displayed next to the word
PROGRAM in the LED Digital Display Window.
To adjust the filter cycle duration use the UP or DOWN buttons
to change to the correct amount of time you want the filter to
run. Your choices are 60, 90, 120, 150, or 180 minutes.
nd
time. Whenever you are programming a filtration
rd
time. Whenever you are programming a filtration
The
factory default is 60 minutes.
Program the Number of Filter Cycles by pressing the
PROGRAM button a 4
programming a filtration setting, the FILTER Icon will be
displayed next to the word PROGRAM in the LED Digital
Display Window.
To adjust the number of filter cycles to run during a 24hour period, simply use the UP or DOWN Buttons to select
the correct number. Your choices are 1, 2, 3, or 4 cycles
per day.
The fac ory default is 2 times per dayt .
th
time. Whenever you are
25
Temperature Unit:
Aquatic Fitness System
2005 Owner’s Manual
Program the Temperature Unit by pressing the PROGRAM button
th
a 5
time. The current Temperature Unit will be visible in the LED
Digital Display Window.
To adjust the Temperature Unit used to measure spa water
temperature, simply use the UP or DOWN Buttons to select
between Fahrenheit (ºF) and Celsius (ºC).
setting is Fahrenheit.
The factory default
Exit the Programming Sequence by pressing the PROGRAM
Button a 6
If you do not proceed with the programming within 60 seconds,
the spa will automatically exit the programming sequence and
revert to your previous settings. Any programming changes made
up to that point would be saved.
Heat Indicator Ligh t
Heat Indicator Light:
This Light is illuminated whenever the heater is on. Additionally,
the HEAT Icon will also be displayed in the upper left corner of
the LED Digital Display Window.
Dimension One Spas Icon (Logo) Button
Dimension One Spas ICON (Logo)®: The time of day can be
viewed by pushing the Dimension One Spas ICON logo on the
far right of the control. If no other button is pushed within 5
seconds, the display will revert to the spa water temperature
reading.
The pre-set fac ory default is Fahrenheit
Button can change the clock.
th
time. All changes will be saved.
t
. Using the PROGRAM
26
Aquatic Fitness System
2005 Owner’s Manual
Digital Display Messages
The following messages may appear in the LED Digital Display Window:
“OH” – Overheat Protection
DO NOT ENTER THE WATER when “OH” is displayed on the
control system’s LED Digital Display Window because the spa
is in a high temperature condition. If this happens, remove the
spa cover and allow the water to cool below 110° F (≅43.3° C).
Turn off all power to the system to reset.
If the problem persists, contact your local Authorized
Dimension One Spas Dealer, or authorized service center.
Flashing LED on the Control Panel
DO NOT ENTER THE WATER if you see 3 flashing LEDs on the
Digital Display Control. The system has detected a problem.
Check to see of your LED Digital Display Window is also
displaying an Overheat Protection condition (OH).
flashing lights and an OH in the display, your system has
detected a high limit condition. The water temperature has
reached 118° F (≅47.8° C). The entire system is disabled.
Contact your local Authorized Dimension One Spas Dealer, or
authorized service center.
If you have
27
Aquatic Fitness System
2005 Owner’s Manual
Flashing LED on the Control Panel
DO NOT ENTER THE WATER if you see 3 flashing LEDs on the
Digital Display Control. The system has detected a problem.
If you have flashing lights, but the LED Digital Display Window
shows the current water temperature, you have a water flow
problem. You will need to check the water level and/or clean
the filters.
Before checking the water level or cleaning
the filter be sure to test the water
temperature. Do not rely exclusively on the
accuracy of the temperature reading in the
LED Digital Display Window. Make sure the
water temperature is safe before cleaning
the filters.
The flashing lights should stop once the problem is fixed. If the
problem persists, reset the power to the spa by resetting the
GFCI breaker.
If the error is not resolved after resetting the spa, contact your
local Authorized Dimension One Spas Dealer, or authorized
service center.
E roneous Temperature on the Display r
DO NOT ENTER THE WATER if you see a temperature
reading of 32° F (≅0° C) or 136° F (≅57.8° C) without first
checking the actual water temperature with a separate
thermometer. The system has detected a Temperature
Probe Failure and the water may be too hot, or too cold, to
safely use.
Contact your local Authorized Dimension One Spas Dealer, or
authorized service center.
28
Aquatic Fitness System
2005 Owner’s Manual
Routine Equipment Maintenance
Draining Your Aquatic Fitness System
Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot
use this system unless they are supervised at all times.
All models are gravity drained. Do not drain water onto your lawn or plants unless all of the bromine
or chlorine has dissipated from the water. The sanitizer in your water will dissipate quickly by leaving
the cover off and exposing the water to direct sunlight. Drain and replace your water every six
months. For heavy use, you may wish to change the water more frequently.
You may purchase an optional submersible pump from your dealer or from our
Virtual Showroom at
www.d1spas.com to provide quicker drainage.
Filter Cleaning
AquaFit™ Dual Temp
Always turn off the power to the system before
cleaning the filter elements. Your system is equipped
with three top access filter cartridges – one on the
spa-side and two on the pool-side. We recommend
that you clean the filters every month as preventative
maintenance.
To clean the skimmer filter cartridge, remove the access lid covering the filter area. Lift the center
float of the skimmer assembly until it is fully extended. Hold the centerpiece of the assembly and
turn it counter clockwise until the flats of the basket are aligned with the securing tabs. Then pull the
basket assembly straight up to remove. Next, remove the E-Z Lock Filter cartridge by twisting the
cartridge ¼ turn counterclockwise to its stop. (Be careful not to overturn the filter.) Then lift the filter
out of its canister. Clean the cartridge with a high-pressure garden hose. Every other cleaning, soak
the cartridges in a filter-cleaning solution, rinse it thoroughly, and reinstall. Replace the skimmer
basket assembly and the access lid or cover. After cleaning, run the pump for a few minutes at high
speed, then return to the heating mode.
29
Aquatic Fitness System
2005 Owner’s Manual
AquaFit™ and AquaPro™
Always turn off the power to the Aquatic Fitness System before cleaning the filter elements. Refer
to the filter manufacturer’s manual for detailed instructions on removing the filter.
It is recommended that filters be cleaned every month as preventative maintenance. You should
clean the cartridge with a high-pressure garden hose. Every other cleaning, you should also soak
the cartridge in a filter cleaning solution, rinse it thoroughly, and then reinstall it. After cleaning, be
sure to run the pump(s) for a few minutes at high speed, and then return to the heating mode.
Be sure the slice valves and the shut off valve are closed before changing or
cleaning your Aquatic Fitness System filter.
Light Bulb Replacement
All systems are equipped with Dynamic LED Lights. To change the light:
1. Turn the power off and drain the system below the level of
the light.
2. Using the special tool provided in the owner’s manual
packet, unscrew the cover for the light housing.
3. Remove the old light and install the new light.
4. Use the special tool to replace the cover for the light
housing.
5. Check to ensure proper operation of the new light
before refilling the system.
Do not attempt to remove the light housing cover without lowering the water level
below the light housing cover.
Do not attempt to remove the light housing cover without the special tool. If you
are not able to locate it, contact your Dimension One Spas Dealer to have one
sent.
Be sure the O-ring is not damaged and is properly in place when replacing the
lens. Contact your dealer if a replacement O-ring is needed.
30
Aquatic Fitness System
2005 Owner’s Manual
Surface Care – Shell
Your equipment has a very high quality finish. Stains and dirt will generally not adhere to the surface.
We recommend cleaning the entire shell surface with Dimension One Spas’ Water Line Cleaner. You
may also use Dimension One Spas’ ph/Alkalinity Increaser or a 50/50 solution of denatured alcohol
and water. Be sure to thoroughly rinse the shell. After cleaning, you will want to restore your hot tub
shell’s original luster by using Dimension One Spas’ Poli-Gloss.
Do not use caustic solutions as they may damage the hot tub shell surface and
void the warranty. If you are using Dimension One Spas’ pH/Alkalinity Increaser to
clean your hot tub shell, be careful not to get it on the wood skirt. It may stain the
wood.
Do not use citrus-based cleaners on the shell surface.
Care for the Wood Spa Cabinet
When properly cared for, the wood cabinet of your hot tub will maintain its beauty for many years. All
woods react differently to the elements by expanding and contracting. To protect your beautiful
wood finish, re-stain it every 3-6 months, which serves as a good sealing agent for the wood.
Please note that the cabinet is not warranted against reaction to natural weather conditions. The
wood must be properly maintained. You may visit the Dimension One Spas website at
www.D1Spas.com to get the proper formula for your stain. This stain should be available from your
local hardware store.
Special Cold Weather Instructions
Slipping into your steamy water on a snowy, winter night is a refreshing experience. Many times,
people who could never imagine being outside in winter weather, find themselves spending their
winter nights doing just that, while relaxing in their spa with family and friends. Therefore, the best
winterizing tips of all are to enjoy use of your system year-round.
All systems manufactured by Dimension One Spas are designed for rigorous winter use. They are
insulated to keep operating costs down and to protect plumbing and equipment whenever the
products are operational. Each product line incorporates freeze protection mode to maintain water
circulation during freezing conditions whenever the system has proper electrical power and water
level. Therefore, a fully operational system is your number one defense against freeze-damage.
If you find it completely necessary to drain your water during the winter months, in an area where
freezing conditions may exist, please adhere to all of the instructions in this section to minimize the
risk of freeze damage. Failure to complete any of the steps satisfactorily will increase the chance of
freeze damage, as small amounts of water trapped in pipes will expand as it freezes, and may result
in damaged plumbing lines or fittings.
Dimension One Spas does not recommend that you drain your system for the
winter. Freeze damage is specifically not covered by Your Warranty.
31
Aquatic Fitness System
2005 Owner’s Manual
Items Required for Winterizing
• Phillips head screwdriver
• 16” Channel-lock pliers
• High pressure air blower
• Commercial grade wet-vacuum
• 3 to 6 gallons (11.4 to 22.7 liters) of Non-Toxic Antifreeze
• Enough time (and patience) to perform all steps.
Procedure for Winterizing
1. Shut the power off to the system and make sure that it cannot be accidentally turned back
on.
2. Remove filter elements from filter assembly.
3. Drain water from the system using the drain fitting and garden hose or you may use a
submersible pump for faster draining.
4. Open the equipment compartment and locate pumps and heater.
5. Remove all of the drain plugs from each pump.
6. Loosen unions on both sides of each pump, and the heater if applicable.
7. Close all jets, by turning jet faces counter clockwise.
8. Put on your protective goggles in order to protect eyes from air, water, antifreeze or debris
exiting the jets or drains.
9. Insert the hose of a high-pressure air blower into the filter element fitting. Some models
may have 2 filters. Begin with the left-hand filter fitting, which will help evacuate water from
the circulation pump system. Then proceed to the right-hand filter fitting. When using air
blower on single-filter systems or the right-hand fitting on dual filter systems, rotate each of
the jet faces clockwise to open and counter-clockwise to close again. Do this to each jet
face, one jet at a time. Be careful, as water will be coming out of each jet fitting as you
perform this maneuver. Perform this operation, until no more water is coming from the jets.
10. Remove jet faces and insert the hose of a high-pressure air blower into each jet fitting.
Continue this process, until no more water comes out of any jet fitting or drain fitting and you
no longer hear water gurgling within the plumbing. Place all jet faces in a plastic bag and set
aside until you are ready to use your system again.
11.
AquaFit™ DT 19’ Only: Remove bleeder valve from the top of the filter canister area in the
spa area. Place hose of a high-pressure air blower into the bleeder fitting first. Confirm that
water mist is blowing from one or both of the circulation system; return jets in the footwell of
the system. You may also get some water mist blowing from the filter canister. Repeat this
process with the front-most bleeder fitting. Confirm that water mist is blowing from the drain
fittings of the jet pumps.
12. Place the hose of a commercial grade, wet-vacuum over each jet fitting, bleeder valve
fitting, and drain fitting to draw out as much remaining standing water as possible.
13. Remove drain hose bib assembly from the outside bottom of the system.
14. Use the wet-vacuum to remove standing water from the pumps and any other fittings within
the equipment compartment.
15. Read all Directions and Safety Precautions on the Swimming Pool or Recreational Vehicle
antifreeze bottle before opening and using. Ensure that it is non-toxic and safe for this use.
Beware of and follow all safety precautions.
32
Aquatic Fitness System
2005 Owner’s Manual
16. Using a long funnel, begin pouring non-toxic swimming pool or recreational vehicle water
system antifreeze into the filter canister fittings, bleeder valve fittings and jet fittings of your
system. Continue adding antifreeze until it comes out of the drain fittings or from the
opening you are pouring it into. You must complete this task for every jet fitting in the
system. Some of the antifreeze will seep into the system from the drain or jet fittings, which
is okay, the goal is to have anti-freeze collect in the areas of the plumbing that would
normally trap water. Use the funnel to also place antifreeze into the pump housing(s).
When pouring antifreeze into the rear-most bleeder valve fitting, you may see
antifreeze pouring from one or both of the circulation system-return fittings.
DO NOT USE AUTOMOTIVE COOLING SYSTEM ANTIFREEZE IN YOUR SYSTEM.
IT IS TOXIC AND HARMFUL TO HUMANS AND ANIMALS. CHECK WITH YOUR
LOCAL SPA DEALER OR RV DEALER TO PURCHASE
THAT IS COMPATIBLE WITH DRINKING WATER SYSTEMS!
NON-TOXIC ANTIFREEZE
17. Replace all equipment access panels onto the system.
18. Replace thermal cover and secure locking tabs. If your system is located in an area of high
snowfall, you may want to take one more extra precaution to safeguard the life of your
system cover. Span the cover with (2 or more) 2x4’s cut to length to reach the outside
edges of your cover. Be sure to place the 2x4’s on top of the cover parallel to the cover
hinge. Next, place a sheet of plywood, cut to fit each half of the cover, over the 2x4’s; this
will carry the load of a heavy snow load and prevent the cover from warping or breaking.
You can even tarp the system at this point for maximum protection.
33
Aquatic Fitness System
2005 Owner’s Manual
Spring Time Startup
In the spring, or when you are ready to start the system back up, follow these instructions.
• Make sure o-rings for pumps are in place and undamaged.
• Make sure all the fittings that you had to loosen are tightened.
• Replace all jet fittings, pump drain plugs, hose bib drains and bleeder valves
• Fill the system up, as you would normally do.
• Turn the power back on.
• Run the jets on high speed for about 15 minutes.
• Drain the water.
• Put your filter(s) back in.
• Refill and treat chemically like you would during a normal water change.
Your system is equipped with automatic freeze protection. However, power
outages can cause your system equipment to freeze. During freezing
conditions, check your system frequently to ensure proper operation. Always
check your system after any power failure to ensure that it is operational.
Draining and not operating your system disables this feature.
For additional information about winterizing your Aquatic Fitness System, please contact your local
Authorized Dimension One Spas dealer.
34
Aquatic Fitness System
2005 Owner’s Manual
Warranty Service Information
Your Aquatic Fitness System warranty gives you specific coverage. Be sure to read the enclosed
warranty sheet carefully.
The warranty does not cover problems arising from misuse, abuse, or neglect, and it does not cover
problems caused by improper installation or “perceived” problems caused by failure to read the
Aquatic Fitness System Owner’s Manual. A service charge will be made if a service call is made for
any of the following:
1. Equipment failure due to improper/inadequate electrical service. All systems require
dedicated circuits as described in this manual. Low voltage can cause equipment failure and
seriously shorten equipment life. It is the owner’s responsibility to ensure proper electrical
service is available.
2. Failure of Aquatic Fitness System to reach desired temperature because the set
temperature is not turned up high enough. Maximum thermostat setting is approximately
104° F (≅40° C).
3. Burned out Aquatic Fitness System light. Bulbs are not covered.
4. Aquatic Fitness System water chemistry is the responsibility of the Aquatic Fitness System
owner. Cloudy, dirty or chemically unbalanced water and cleaning of the filters are also the
responsibility of the Aquatic Fitness System owner.
5. Aquatic Fitness System shell or equipment damage caused by improper water
maintenance. Serious damage can be caused if your Aquatic Fitness System water is not
maintained carefully and correctly.
6. Poor jet action because the jet Selector valve is in the middle position. For full performance,
turn the jet Selector valve to either the full clockwise or full counterclockwise position.
Do not block the air intakes.
The air intakes for the HydroTherapy Jets are located in
the equipment compartment.
For the Swim jets they are built into the lower portion of the Air
Selector Switches, below the shell.
Proper airflow is required for proper operation. Malfunctions resulting
from blocked air intakes are not covered under warranty.
35
Aquatic Fitness System
2005 Owner’s Manual
Glossary of Terms
Term Definition
Air Relief Valve Used for purging air from the filter system whenever servicing
the filter, during initial startup, and whenever you drain and fill
the Aquatic Fitness System.
Air Volume Controls Increase or decrease the amount of air drawn through the
jets. The intensity of jet action is varied by adjusting the
amount of air mixed with the water forced through the jets.
More air produces a more vigorous massage. Since air
bubbles tend to cool the Aquatic Fitness System, the air
controls should be closed while the Aquatic Fitness System is
heating.
Bleeder Valve A small valve used to relieve or expel air from the Aquatic
Fitness System’s plumbing or pump.
Circulation Pump A pump that circulates the water in the Aquatic Fitness
System continuously.
Diverter Valve Allows you to select either the therapy jets or swim jets with
pump number 1. Simply turn the valve to the desired position.
Dry Firing Turning the heater element on when there is no water in the
heater.
Equipment Access Panel Provides access to your Aquatic Fitness System’s equipment
for a qualified service technician.
Equipment Control System The electronic control system that governs all of the
electrically operated components of your Aquatic Fitness
System utilizes an advanced microprocessor and solid-state
electronic switches to activate all user and maintenance
options.
Filter Cartridge Your Aquatic Fitness System’s filters have been designed so
that you may repeatedly clean and maintain the filter cartridge
as needed. The cartridge is constructed of woven polyester
rather than paper to ensure long life and proper filtration.
Filter Housing The filter canister that houses the filter cartridge. It encloses
your Aquatic Fitness System’s cartridge filter element. This
filter cartridge removes dirt, oil and fine particles from your
Aquatic Fitness System’s water. The lock ring holding the filter
cover in place and the air relief valve in the filter cover must be
on and closed when the Aquatic Fitness System is running.
DO NOT OVER-TIGHTEN THE LOCK RING OR THE AIR
RELIEF VALVE. Also do not open filter housing while the
Aquatic Fitness System is running as the filter is under
pressure.
Gfci-Ground Fault Circuit
Interrupter
Gravity Drain Valve Used to drain your Aquatic Fitness System.
Halogens Free chlorine, bromine or iodine ions that are very strong
A type of Circuit Breaker that automatically disconnects
power to the Aquatic Fitness System when there is an
electrical power leakage to ground.
oxidizers used to sanitize water.
36
Aquatic Fitness System
2005 Owner’s Manual
Term (Cont.) Definition
Heater An 11kw 230v thermostatically controlled electric heater
equipped with a high-limit temperature safety shut-off switch.
If the high-limit safety switch trips, contact your authorized
Aquatic Fitness System Dealer. See the
Troubleshooting
Guide for more information.
Jets Return the water into the Aquatic Fitness System from the
equipment. The HydroTherapy Jets produce a turbulent flow
of water mixed with air to provide a concentrated body
massage. The Swim Jets produce a high volume flow to
provide a rapid current for swimming.
Light Illuminates the Aquatic Fitness System vessel.
Load Sharing When the circuit breaker size is smaller than the total power
needed to operate both the heater and the jet pump at the
same time, load sharing automatically turns off the heater
when a jet pump is turned onto high speed.
Lock-Ring Mechanism that affixes filter cover to filter housing. To
remove cover, turn lock-ring counter-clockwise until it
disengages with filter housing. When replacing the filter cover,
turn lock-wring clockwise to firmly secure the cover.
Ozone Generator A specialized ultraviolet light that changes oxygen into ozone
for use in the water sanitation process.
Pressure Switch Safety device that sends a signal to the electronic control
system that there is adequate water flow to turn the heater
on.
Primary Pump Produces water flow through the heater, filter, sanitation
system and the main jets in the Aquatic Fitness System. The
primary pump will operate automatically during filtration and
heat cycles. This pump can also be operated manually by
depressing the “jets” button on the Top Side Control which will
allow you to choose between two speeds
• Low speed for efficient water circulation during
heating and filtration modes, and for gentle jet
resistance or massage action.
• High speed for maximum jet action.
Pump Union A removable fitting that connects the pump to the Aquatic
Fitness System’s plumbing.
Selector Valve Located on the top edge of the Aquatic Fitness System or
spa, it diverts jet power from one area of the Aquatic Fitness
System or spa to another.
Serial Number Please use the serial number in communication with your
dealer.
Servicing Filter Element To clean or replace the filter element, shut off power to the
Aquatic Fitness System, loosen the lock-ring, remove the filter
cover and pull the filter element from the filter housing.
Depending upon use, you may simply rinse the filter element
with a garden hose, or you may be required to soak the
element in Filter Cleaner Solution. Replace any worn or
damaged filter elements. It is always good practice to have a
spare filter element, so that you can perform cleaning at your
convenience.
37
Aquatic Fitness System
2005 Owner’s Manual
Term (Cont.) Definition
Skimmer Door Removes floating debris from the water surface. This inlet
provides a water return path to your Aquatic Fitness System’s
equipment and flow through the filter element.
Slice Valves / Shutoff Valves Valves located within the Aquatic Fitness System’s internal
plumbing, which are used by service personnel to shut off
water flow to the heater and pumps. All valves must be
completely open during normal operations.
Smart Heat Smart Heat optimizes heat recovery using the amperage that
you have available. Along with computerized load sharing, that
automatically recognizes the number of jet pumps in use,
compares it with the available power, Smart Heat recognizes
the difference between the set temperature and the actual
water temperature, and adjusts the heater to optimize the
heater output.
Suction Fitting Fitting located in the footwell of the Aquatic Fitness System
where water is pulled from the Aquatic Fitness System to the
jet pump.
Swim Jet Pumps Produce water flow through the swim jets. The swim jet
pumps are single speed pumps that operate on high speed.
The second and third pump buttons control the booster
pumps.
Temperature Sensor Measures the temperature of the water inside the Aquatic
Fitness System. This temperature sensor is used to control
the Aquatic Fitness System heater and the temperature is
displayed on the Aquatic Fitness System side control panel.
Top Side Control Used to monitor and manage temperature, pumps for jets,
light, system clock, automatic filtration cycles, and other
advanced functions. A backlit, highly reliable liquid crystal
display gives you a complete update of the Aquatic Fitness
System status at any time of the day or night.
Unions Connects the Aquatic Fitness System plumbing to the
equipment. The unions allow a service technician to remove
equipment without cutting plumbing.
Venturi A device used to inject air into the water.
Vision Cartridge A safe, halogen-free water sanitizer that can be used in place
of chlorine or bromine.
Water Return Fittings In addition to the skimmer, the water return fittings provide
water inlets to your Aquatic Fitness System’s equipment.
DANGER – Never Block Or Remove Any Of The Water Return
Fittings.
Weir Skimmer A floating water referencing device that skims debris from the
surface of the water.
38
Aquatic Fitness System
2005 Owner’s Manual
Troubleshooting Guide
Heating System
Symptom Problem Corrective Action
Does not heat
Flashing temperature of 34°F or
134°F appears on the display
Electrical System
Symptom Problem Corrective Action
Will not turn on – in any mode No power Check circuit breaker and/or GFCI
Turns on by itself Normal automatic daily power
Light is out Burned out bulb Replace bulb
Pump shuts down unexpectedly
while in use
3 flashing LEDs appear on the
Top Side Control
1. Temperature setting is too low 1. Turn up the thermostat
2. Dirty filter 2. Clean filter
3. Flow switch out of adjustment 3. Call for service
1. Temperature setting is to high 1. Turn down the thermostat Too hot
2. High limit tripped 2. Call for service
Possible temperature sensor failure Call for service
filtration, or anti-freeze cycle
1. Automatic 30-minute timer has
shut pump off
2. Motor over-heated and
automatic protective device
has shut down pump(s)
Possible sensor errors
No action required
1. Push JETS pad again to start
another 30-minute cycle
2. If pump(s) will not restart when
JETS pad is pushed, call for
service
Make sure that the equipment
panel vent area is not blocked.
Vent blockage can cause
serious damage to your
equipment.
1. Check water level
2. Clean filter
If problem persists:
1. Turn off power
2. Restart the system
If problem persists:
Call for service
Water System
Symptom Problem Corrective Action
Pulsating jets Water level too low Fill with water to 1” to 2” (2 to 5
No Jet Action, or action is poor
The water is cloudy or has a smell The water has a chemical
1. HydroTherapy Jets closed 1. Open Jets
2. Diverter Valve turned 2. Turn the Diverter Valve
3. Dirty Filter 3. Clean Filter
4. Air lock 4. Loosen pump union to allow air
5. Gate valve closed 5. Open gate valve
imbalance.
centimeters) above the bottom of
the tile line
clockwise or counter
clockwise
to escape
1. Check TA/pH
2. Test and adjust
3. Change Water if necessary
39
Aquatic Fitness System
2005 Owner’s Manual
Self-Diagnostic Control System
AquaFit™, AquaFit™Dual Temp (Pool-Side), AquaPro™
Symptom Problem Corrective Action
Non-functional
High Temperature Sensor:
Open high temperature sensor.
Heater is deactivated.
Call your dealer for service.
Non-functional temperature
sensor:
Open temperature sensor. Heater
is deactivated.
Water Flow Problem:
Pressure switch is not closed when
the pump is activated. Heater is
deactivated. Proper flow of water
is inhibited or pressure switch has
malfunctioned. Check for proper
water level, ensure pump is primed
and/or check for clogged filter.
Pressure switch may need to be
adjusted.
Pressure switch problem:
Pressure switch is closed, while
pump is deactivated. Pressure
switch may need to be adjusted.
Cool condition:
If the water temperature drops 20°F
(≅11°C) below the set temperature, the
low speed pump and the heater will
activate to bring the temperature within
15°F (≅8°C) of the set temperature.
Call your dealer for service.
Call the dealer for service.
Call your dealer for service.
No corrective action is required.
Freeze condition:
A potential freeze condition has been
detected (55°F / ≅12.8°C.)
40
No action is required.
The low speed pump will be activated along
with the heater. The spa will automatically
heat, until the spa is out of danger (65°F /
≅18.3°C.)
Aquatic Fitness System
2005 Owner’s Manual
Symptom (Cont) Problem Corrective Action
No action required unless the water
High temperature condition:
Do not enter the spa water. The water
temperature is above acceptable limits.
Water temperature has reached 110°F
(≅43.3°C.) The air blower and low speed
pump are activated to assist in lowering
water temperature.
temperature fails to return to
acceptable levels – in which case,
call your dealer for service.
Call your dealer for service.
High limit condition:
Do not enter the spa water.
The water temperature has
reached 118°F (≅47.8°C.) The entire
system is disabled.
41
AquaFit™Dual Temp (Spa-Side)
Symptom Problem Corrective Action
Aquatic Fitness System
2005 Owner’s Manual
“OH” on LED Digital Display
Window
High Temperature Condition:
Do not enter spa water. The water
temperature is above acceptable limits.
The water temperature has reached
110°F (≅43.3°C.). The system will shut
down.
3 Flashing Lights
“OH” on LED Digital Display
Window
High Limit Condition:
Do not enter spa water. The water
temperature is above acceptable limits.
The water temperature has reached
118°F (≅47.8°C.). The system will shut
down.
AND
1. Remove the cover and
allow the water to cool.
2. Reset the power to the spa
by resetting the GFCI
breaker.
No further action is required
unless the water temperature
fails to return to acceptable
levels – in which case, call your
dealer for service.
Call your dealer for service.
3 Flashing Lights
System Error:
1. Check the water level
2. Clean the filters.
3. If the problem persists, reset
the power to the spa by
resetting the GFCI breaker.
Temperature Probe Failure:
If the LED Digital Display shows
32°F (≅0.0°C) or 136°F (≅57.8°C),
you have an open temperature
sensor. The heater is
deactivated.
If the error is not resolved after
resetting the spa, call your dealer
for service.
Call the dealer for service.
42
Aquatic Fitness System
2005 Owner’s Manual
43
Aquatic Fitness System
2005 Owner’s Manual
44
Loading...
