DL6799 - CombiVolt™5
200A TrueRMS Current,
Voltage & Continuity Tester
Instruction Manual
DL6799 OPERATING MANUAL
Certicate of conformity
As per the supplier of the apparatus listed, declare
under our sole responsibility.
Instrument Identication:
Di-LOG DL6799 - CombiVolt™ 5
Declaration of Conformity:
To which this declaration relates are in conformity
with the relevant clauses of the following standard.
Standards:
EN 61010-1
EN 61010-2-032
EN 61010-2-33
EN 61010-031
EN 61326-1
EN 61326-2-2
Performance:
The instrument operates within specication
when used under the conditions in the above
standards and EMC safety standards.
The product identied above conforms to the
requirements of council directive 89/336/EEC
and 73/23 EEC.
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Contents
I. Overview ------------------------------------------- 1
II. DL6799 Box Contents ------------------------- 1
III. Safety Notices ----------------------------------- 2
IV. Electrical Symbols ----------------------------- 4
V. Appearance Overview ------------------------- 5
VI. Function Keys ------------------------------------ 6
VII. Technical Index ---------------------------------- 9
1. General Specication ---------------------------- 9
2. Environmental Limits ---------------------------- 10
3. Electrical Specication -------------------------- 10
VIII. Measurement Operation ---------------------- 13
1. Measuring of AC Current (ACI) --------------- 13
2. Measuring of DC Current (DCI) --------------- 15
3. Measuring of AC Voltage (ACV) -------------- 17
4. Measuring of DC Voltage (DCV) -------------- 19
5. Measurement of Resistance (OHM) --------- 21
6. Continuity Testing (CON) ----------------------- 23
7. Diode Measurement (DIO) --------------------- 25
8. Measuring of Capacitance (CAP) ------------ 27
9. Non-Contact Voltage Detection (NCV) ------ 29
10. Single Pole Detection (SPD) ------------------ 31
IX. Maintenance, Repair & Calibration -------- 33
1. General Maintenance --------------------------- 33
2. The installation or replacement of batteries 33
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
1
l. Overview
Thank you for purchasing a Di-Log DL6799 current,
voltage and continuity tester. The tester has been
designed in accordance with the latest international
safety standards.
200A AC/DC current
1000 V DC, 750 V AC
Continuity test with audible indication.
Warning:
The instruction manual includes relevant safety
information and warnings. Please read all relevant
contents carefully and strictly observe all warnings
and safety notices.
If the equipment is used in a manner not specied
by the manufacturer, the protection provided by
the equipment may be impaired.
ll. Contents
1. DL6799 CombiVolt 5
2. Carry Case
3. Instruction Manual
Please contact your supplier if any of the contents
are missing or damaged.
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
2
Ill. Safety Notices
This instrument is to be used only by trained
and competent persons.
The instrument is designed and produced in strict
accordance with the safety requirements for Electronic
Measuring Apparatus and EN61010-1, EN61010-2-032,
EN61010-2-033, EN61010-031, EN61326-1 and
EN61326-2-2 standards, and complies with the safety
standard of double insulation, over-voltage CATII
1000V, CAT III 600V and pollution level 2. If you fail
to use the instrument according to relevant operation
instructions, the protection provided by the CombiVolt 5
instrument is likely to be weakened or undermined.
CAT II: Applicable to test and measuring circuits
connected directly to live voltage (socket outlets or
similar points) of the low voltage mains installation.
CAT Ill: Applicable to test and measuring circuits
connected to the distribution part of the building's
low-voltage MAINS installation.
1. Prior to using, please check the CombiVolt 5 and
integrated test lead & probe set for any damage or
abnormality. If any of the probes insulating layer or
lead are obviously damaged, the display screen fails
to display or you consider there is a fault with the
instrument, please do not use and contact Di-log for
further assistance.
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
3
2. It is strictly prohibited to use the CombiVolt 5
without the rear cover or battery cover, otherwise a
potential shock hazard may occur.
3. When carrying out any measurement, please
keep ngers behind the nger guards on both the
instrument and the test probes.
4. Before measurement, the instrument must be
switched to the correct functional position. It is prohibited
to switch the rotary dial to an alternative position
during measurement, so as to prevent the instrument
being damaged.
5. Do not apply in excess of 1000V DC/750V AC
between the CombiVolt test probes or between line
and ground so as to prevent electric shock and
instrument damage.
6. When the instrument is used to measure a DC
voltage (in excess of) >42V or AC TRMS voltage (in
excess of) >30V, it is necessary to operate the
instrument carefully as there may be danger of electric
shock.
7. Do not measure voltage or current higher than
the stated input limits. Before measuring resistance,
diode or continuity, it is essential to isolate all power
supplies in the circuit and discharge all capacitors,
otherwise, it may lead to incorrect measurement
results.
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
4
8. When the “ “ symbol is displayed on the LCD, it
is necessary to replace the batteries.
10. Do not store or use the clamp meter in an
environment with high-temperature, high-humidity,
inammable, explosive or with a strong electromagnetic
eld.
11. During maintenance, please clean the case of
the instrument with a soft cloth soaked with neutral
detergent, and not use abrasive solvents.
12. Instrument must be proved working before
use on a known voltage source to conrm instrument
is operating correctly.
IV. Electrical Symbols
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
5
V. Appearance Overview
1. Clamp head
2. Clamp body
3. Rotary dial
4. Function key
5. Display screen
6. Test lead input terminal
Figure 1
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
6
VI. Function Keys
Key:
ACI/DCI - AC/CD Current ACV/DCV - AC/DC Voltage
RES - Resistance CON - Continuity
DIO - Diode CAP - Capacitance
SELECT: Function selection button, which works
on ACI/DCI, ACV/DCV, and RES/CON/DIO/CAP
measurement.
REL: Measurement of relative values, enabling
quick and easy dierential measurement on: ACV,
DCV, ACI and RES functions.
A short press of the REL button whilst performing a
measurement will allow the instrument to zero the
displayed value. The instrument will display ∆ to
indicate you have entered relative mode. The next
measured value will display the dierential value in
relation to the previously measured value.
To exit REL mode, a short press of the REL button,
will enable the instrument to return to normal operation.
ZERO: The DCI Zero button: this function is used
with REL and works on the DCI measurement.
A short press of the ZERO button before performing a DCI measurement will allow the instrument
to zero any displayed values caused by terrestrial
magnetism . The instrument will display ZERO in
the secondary display to indicate you have entered
zero mode.
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
To exit REL mode, a short press of the REL button,
will enable the instrument to return to normal operation.
HOLD: the data hold button works in all measurement
positions. A short press of the “HOLD” button under
normal measurement will enter the data-hold mode,
the instrument will not update the measurement and
the displayed value will remain unchanged. The “H”
symbol will be displayed on the top left of the display
screen, to indicate the instrument has entered the
data—hold mode. The data-hold feature can be
cancelled, with either a short press of the “HOLD”
button, a turn the rotary dial or a press of the “SELECT”
button.
SCREEN BACKLIGHT :
A long press of the “ “ button will turn on the
backlight . A long press of the “ “ button again will
increase the brightness. A long press of the“ “
button again will turn the backlight o.
FLASHLIGHT :
A short press of the LED ashlight button will switch
the light on, and another short press of the LED
ashlight button will switch the light o.
7
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Page left blank for notes:
8
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Vll. Technical Index
1. General specications
Liquid crystal display: Maximum display up to 5999;
Polarity display: Automatic positive and negative
polarity display;
Over-load display: Display “OL” or “–OL”;
Battery voltage display: When the battery voltage is
below 2.4V the instrument will display the low battery
symbol;
Sampling rate; Approximately 3 times/second;
Sensor Types: Hall-eect sensor for AC/DC
measurement;
Measured position error: When measuring the
current, ±1.0% additional error may occur if the
source to be measured is not centred at the base of
the clamp jaw;
Impact-resistant Strength: 1m height impact can be
borne;
Maximum opening dimension of clamp head:
Diameter of conductor 14.7mm;
Electromagnetic eld eect: When any electromagnetic
eld interference exists, the instrument may displays
unstable or incorrect readings;
Power supply: 2 x AA 1.5 V batteries;
Auto OFF function: 15 min;
Dimensions: 210mm x 53mm x35mm;
Weight approximately 163.7g (battery included);
9
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
2. Environmental limits
Working environment: Indoor use;
Altitude: <2,000 m:
Safety standards: EN61010-1, EN61010-2-032, EN
61010-2-033, EN61010-031
CATII 1000V, CATIII 600V;
Pollution degree 2;
Operating temperature and humidity. 0ºC - 30ºC
(maximum of 80%RH), 30ºC - 40ºC (maximum of
75%RH), 40ºC - 50ºC (maximum of 45%RH);
Storage temperature and humidity: -20ºC - +60ºC
(maximum of 80%RH) (not larger than 80%RH);
3. Electrical specication
Accuracy: ±(% of reading plus number of digits),
calibration period is 1 year
Ambient temperature: 23ºC ±5ºC;
Ambient humidity: ≤80%RH;
Temperature coecient: 0.1x(accuracy)/ºC;
DCI base number shall be reset by pressing ZERO key
10
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
11
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
12
CON
sound
sound
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Vlll. Measurement Operation
Before measuring, it is necessary to ensure that
the instrument has been switched to correct
measurement position. Measurement shall be in
strict accordance with the guidance herein, and it
is prohibited to switch the rotary dial position during
measurement, in order to avoid injury to users or
damage to the instrument.
1. Measuring of AC Current (ACI)
(1) Set the rotary dial to ;
(2)Place the conductor to be tested at the bottom of
the open jaw clamp “U”. The instrument will automatically
select the correct range and display the true virtual
value of AC current on the display.
Frequency range: 50Hz-60Hz.
Warning:
The largest measured current shall not be greater
than AC 200A during the measurement of AC
current.
13
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 2
14
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
2. Measuring of DC Current (DCI)
(1) Set the rotary dial to ; Press the “SELECT”
key to switch the function to DC current;
(2) A short press of the ZERO button before performing
a DCI measurement will allow the instrument to zero
any displayed values caused by terrestrial magnetism . The instrument will display ZERO in the
secondary display to indicate you have entered zero
mode.
(3) Place the conductor at the bottom of the open
jaw “U”. The instrument will automatically select the
correct range. If the current direction is the same as that
of clamp head, it will display the positive value of DC
current on the display screen, otherwise, it will display
the negative current value:
Warning:
The largest measured current shall not be greater
than DC 200A during the measurement of DC
current.
15
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 3
16
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
3. Measuring of AC Voltage (ACV)
(1) Set the rotary dial to ;
(2) Connect the red and black test probes to the
circuit to be measured, the instrument will automatically
select the correct range. The central screen will
display the current true visual value of AC voltage.
When the voltage value exceeds 30V AC, the
screen will display a high-voltage alarm signal to
warn against a potential shock hazard; frequency
response scope: 45Hz - 400Hz.
Warning:
AC voltage measuring range shall not be greater
than 750V AC.
17
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 4
18
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
3. Measuring of DC Voltage (DCV)
(1) Set the rotary dial to ; Press “SELECT” key to
switch the instrument function to DC voltage;
(2) Connect the red and black test probes to the
circuit to be measured, the instrument will automatically
select the correct range. The display screen will display
the current true virtual value of DC voltage; if the
potential at the red probe is higher than that at the
black probe, the screen will display the positive voltage
value, otherwise the negative value will be displayed;
when voltage exceeds 42V DC, the screen will display
the high-voltage alarm signal to warn against a
potential shock hazard.
Warning:
DC Voltage measuring range shall not be greater
than 1000V DC.
19
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 5
20
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
5. Measuring of Resistance (OHM)
(1) Set the rotary dial to “ Ω “;
(2) Connect the red and black test probes to the
component to be measured, the instrument will
automatically select the correct range. The central
screen will display the current value of resistance;
Warning:
During the measurement of resistance, the power
must be isolated before connecting, and the residual
electric charge of all capacitors should be fully
discharged. More accurate measurement will be
possible when the elements are separated from
circuit.
21
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 6
22
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
6. Continuity Testing (CON)
(1) Set the rotary dial to “ “; Press “SELECT” button
on the measuring function range once to select
Continuity.
(2) Connect the red and black test probes to the
component or circuit to be tested. If the measured
resistance is below 10Ω, the audible alarm will sound
continuously; If the measured value is between 10Ω
and 100Ω the audible alarm may not sound. If the
measured value is greater than 100Ω, the audible
alarm will not sound.
Warning;
When measuring on-o condition, the circuit power
must be isolated. All the residual electric charge of
all electric capacitors must be fully discharged before
the components or conductors are connected with
this product.
23
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 7
24
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
7. Diode Measurement (DIO)
(1) Set the rotary dial to “ “; Press “SELECT”
button on the measuring function range twice to select
Diode.
(2) Connect the red and black test probes to the positive
and negative poles of the diode to be tested. The
positive conductivity voltage value will be displayed
in the centre of the screen; If the probes are connected
to the incorrect polarity, the screen shall display the
measurement sign “OL”;
Warning:
When measuring the diode, the circuit power must
be isolated and electric charge of all electric capacitors
must be fully discharged before the diode is connected
with the product. More accurate measurement will
be possible when the components are separated
from the circuit.
25
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 8
26
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
8. Measuring of Capacitance (CAP)
(1) Set the rotary dial to “ “; Press “SELECT” button on
the measuring function range three times to select
Capacitance.
(2) Connect the red and black test probes to the two
sides of the capacitor to be tested and the instrument
will select the correct range. The display screen will
display the current value of capacitance.
Warning:
During the measurement of capacitance, the power
must be isolated before connecting, and the residual
electric charge of all capacitors must be fully discharged.
More accurate measurement may be possible when
the elements are separated from the circuit. Before
measuring the capacitance, the “REL” key should be
pressed to clear the base number to eliminate the
eect of probe parasitic capacitance.
Note:
At the range 60nF, it is suggested to rstly press
the “REL” key to clear the short circuit base number
before measurement, to eliminate impact of probe
resistance.
27
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 9
28
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
9. Non-contact Voltage Indication (NCV)
(1) Set the rotary dial to “ NCV “;
(2) Connect the instrument to the conductor to be
checked. The top right end of the clamp head is
equipped with a sensor.
The screen will display “EF” if the induced voltage
is not detected. When the test distance is less than
10cm and the tested voltage is greater that 100Vrms
the instrument will emit an audible alarm the NCV
LED light will also start to icker. According to the
magnitude of voltage present, the display screen will
display four levels as “-”, “- -”, “- - -” or “- - - -”. The
greater the voltage, the higher the level displayed.
Warning:
This unit can only be used as a single pole voltage
detector when batteries are inserted. The single
pole test is intended only as a quick check, the circuit
must be checked again for the presence of voltage
using the AC voltage setting and 2 pole method.
29
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 10
30
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
10. Single Pole Voltage Detection (SPD)
(1) Set the rotary dial to “SPD“;
(2) Connect the red or black test probe to the conductor
to be checked making direct contact with either of
the probes. Detection of Single Pole Voltage can be
achieved with either the red or black test probe as
both are equipped to indicate if voltage is present in
excess of 100Vrms.
If an AC voltage above 100Vrms is present, the LED
is illuminated and the audible alarm will sound. The
screen will display “EF” if no voltage is detected.
When the contact voltage is greater than 100Vrms,
the meter will indicate with an audible alarm and the
NCV/SPD LED alarm light will also start to icker.
According to the magnitude of voltage present, the
central screen will display the four levels as “-”, “- -”,
“- - -” or “- - - -”. The greater the voltage, the higher
the level displayed.
Warning:
This unit can only be used as a single pole voltage
detector when batteries are inserted. The single
pole test is intended only as a quick check, the circuit
must be checked again for the presence of voltage
using the AC voltage setting and 2 pole method.
31
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 11
32
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
IX. Maintenance and Repair
Warning: please make sure the test probes
are disconnected from any measured circuit or
component before removing the battery cover so
as to avoid electric shock.
1. General Maintenance
a. The maintenance and other services of this instrument
must be carried out by qualied professional maintenance
sta.
b. Test leads are classed as a wear and tear item
and are replaceable for a charge at our service
department: contact us for more information.
c. The outer casing should be regularly cleaned by
a dry cloth. Detergent which contains abrasives or
solvents must not be applied.
2. The installation or replacement of batteries:
The power supply of this product is two 1.5V AA batteries,
please install or replace batteries following the guidance
below:
a. Turn o the product, and make sure the test probes
are disconnected from any conductor or component
b. Turn the instrument face down, unscrew the battery
holder and remove the battery cover. Remove the
batteries and install new batteries according to the
polarity indication.
c. Please use batteries of the same specication.
d. After installing new batteries, re-t the battery
cover, and lock the screws tight.
33
Di-LOG
...measurably better
DL6799 OPERATING MANUAL
Figure 12
Instructions are subject to change without prior notice.
24 Month Warranty
Di-log instruments are subject to stringent quality
controls. If in the course of normal daily use a fault
occurs we provide a 24 month warranty (only valid
with proof of purchase). Faults in manufacture and
material defects will be rectied by us free of charge,
provided the instrument has not been tampered with
and returned to us unopened. Damage due to dropping,
abuse or misuse are not covered by the warranty.
The tted test leads are deemed a wear and tear
item and are not covered by the warranty, however
replacement leads are available for a chargeable
repair and will be tted by our
service department.
Di-Log Ltd
Unit 28 Wheel Forge Way
Traord Park
Manchester M17 1EH
UK
Tel:+44 (0)161 877 0322
Email: sales@dilog.co.uk
Website: www.dilog.co.uk
34
Di-LOG
...measurably better
Loading...
