Digium Phone User Guide
Digium Phone firmware version 1.4
©2012-2013 Digium, Inc.
All rights reserved. This document is the sole property of Digium, Inc. It contains proprietary
information of Digium. Digium reserves the right to make changes to the specifications described
herein at any time and without notice in order to improve design or reliability of the product. The
information in this document has been carefully checked for accuracy; however, Digium makes no
warranty pertaining to the correctness of this document.
All product and company names are trademarks or registered trademarks of their respective
holders.
613-00019-E
FCC Part 15 Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
* RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
* 15.21 Information to user:
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Label of FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
IC Statement
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Bluetooth
-BT interface
--UART(up to 4 Mbps)
--PCM
-Bluetooth V4.0(HS) with integrated Class 1.5 PA and Low Energy (BLE) support
-Frequency Band :2402MHz ~ 2480MHz(79 channels)
-Modulation:FHSS, GFSK, DPSK, DQPSK
-Bluetooth Standard:Bluetooth V4.0 of 1, 2 and 3 Mbps.
-Antenna Reference:Small antennas with 0~2 dBi peak gain
Contents
Overview 5
1 Network & System Tools 7
Setting the Network Information 7
IP Configuration 7
Quality of Service Settings 8
VLAN Settings 8
Getting the Phone Configuration 8
Option 66 9
Fetch Configuration File From URL 9
Web User Interface Tool 10
Resetting, Reconfiguring, or Restarting 10
Reset to Factory Defaults 10
Reconfigure 10
Restart 10
Enable App Development 11
Tech Support 11
2 Web User Interface Settings 12
Lines Tab 12
Alternate Host 13
SIP Outbound Proxy 13
General Tab 14
Preferences Tab 14
Contacts Tab 15
Network Tab 16
Virtual LAN 16
Quality of Service 16
Digium Phone User Guide 3
Ethernet Port Modes 16
Advanced Network Settings 16
Logging Tab 17
Ringtones Tab 17
3 Phone Apps & Calling 18
Phone Apps 18
Contacts 18
Status 18
Voicemail 18
Call Log 18
Forward Calls 18
Calling 19
Dialing Calls 19
Receiving Calls 19
Redial 19
Hold 19
Transfer 19
Conference (3-way Calls) 20
Digium Phone User Guide 4
Overview
This guide provides information about the setup and use of Digium Phones when a
Digium Configuration Server is not being used. Below is an overview of this process.
See the Digium website for information about using Digium Phones with Switchvox
or the Digium Phone Module for Asterisk (DPMA).
1. Get On the Network
Automatic. Phone uses DHCP and LLDP-MED to get IP address and
VLAN membership information. If successful, it attempts to find a configuration file.
Manual. If not successful, enter the information as described in Setting the
Network Information on page 7 or as described in Web Us er In terf ace Settings on page 12.
2. Configure the Phone (two choices)
Web UI tool to enter all of the configuration information as described in
Web Us er I nter face Sett ings on page 12.
Create XML configuration file and make it available to the phone as
described on Getting the Phone Configuration on page 8.
3. Get Acquainted with Phone Apps & Calling Features
Phone Apps, page 18.
•Contacts are used for rapid dialing, and for finding detailed information about
someone in your list of contacts.
•Status indicates Do Not Disturb (DND) or Available.
•Msg button calls the voicemail system as indicated in your phone configura-
tion.
Digium Phone User Guide 5
•Call Log displays your call activity for received, dialed, and missed calls.
•Forward Calls forwards all of your incoming calls to another number.
Calling Features, page 19.
•Dialing Calls
•Receiving Calls
•Redial
•Hold
•Transfer
•Conference (3-way Calls)
Digium Phone User Guide 6
