Digitus WP-S1100 User manual

Wireless 300N Presentation Server

User Manual

1 2

Table of Contents

Chapter I Product Introduction..................................................................................4

1-1 Package Contents........................................................................................4

1-2 Safety Instructions........................................................................................5

1-3 System Requirements.................................................................................7

1-4 Highlights of this Wireless Presentation Server ......................................8

1-5 Familiar with Wireless Presentation Server / Remote Controller..........9

1-6 Install Wireless Presentation Server.......................................................17

Chapter II Using Presentation Server....................................................................20

2-1 Switch the Presentation Server On and Check IP address.................20

2-2 Connect to Presentation Server by Wireless Ethernet.........................22

2-3 Set the IP address of the Computer........................................................22

2-3-1 Windows 2000 IP address setup:........................................22

2-3-2 Windows XP IP address setup:...........................................23

2-3-3 Windows Vista IP address setup: .......................................25

2-4 Download and Install Client Software.....................................................28

2-5 Launch Client Software.............................................................................34

2-6 Using Client Software................................................................................40

2-6-1 Presentation Server .............................................................40

2-6-2 On-Screen Keyboard............................................................42

2-6-3 About.....................................................................................42

2-6-3 Exit.........................................................................................43

2-7 Using Remote Controller...........................................................................43

2-8 Select User..................................................................................................44

2-8-1 ‘User Switch’ Button ............................................................44

2-8-2 Use Remote Controller ........................................................46

Chapter III Configure Presentation Server............................................................47

3-1 Connect to Web Configuration Menu......................................................47

3-2 Utility Download..........................................................................................50

3-3 Basic Setting...............................................................................................51

3-3-1 Change Time Zone Setting..................................................52

3-3-2 Password ..............................................................................53

3-4 Network Setting ..........................................................................................55

3-5 Wireless Setting ..........................................................................................57

3-5-1 ‘Basic’ Settings.....................................................................58

3-5-2 ‘Advanced’ Settings.............................................................61

3-5-3 ‘Security’ Settings................................................................64

3-5-3-1 Encryption: Disabled .......................................................66

3-5-3-2 Encryption: WEP...............................................................68

3-5-3-3 Encryption: WPA pre-shared key..................................70

3-5-3-4 Encryption: WPA RADIUS...............................................72

3-5-4 ‘WPS’ Settings......................................................................74

3-6 Presentation Control..........................Fehler! Textmarke nicht definiert.3

3-7 Display Setting....................................Fehler! Textmarke nicht definiert.4

3-8 Black Out.............................................Fehler! Textmarke nicht definiert.6

3-9 Configuration Tools ....................................................................................80

3-9-1 Configuration Tools.............................................................80

3-9-2 Firmware Upgrade................................................................82

3-9-3 Reset .....................................................................................84

4-1 Hardware Specification..............................................................................85

4-2 Troubleshooting..........................................................................................86

Chapter I Product Introduction

1-1 Package Contents

Thank you for purchasing this Wireless Presentation Server! Before you start to use this product, please check every item in the package. If any of them is missing, please ask your dealer of purchase for a new package.

Packaging List

Item No. 1 Wireless Presentation Server 1 2 Antenna 2 2 A/C Power Adapter 1 3 Ethernet Cable 1 4 Remote Controller 1

Name Quantity

5 CR-2302 Lithium Battery

(Installed in Remote Controller) 6 Rubber Foot Pad 4 7 CD(Manual) 1

1-2 Safety Instructions

Please follow the following safety instructions when you’re using this Wireless Presentation Server, or you may damage this Presentation Server and / or yourself!

1. THIS PRESENTATION SERVER IS NOT A TOY! Keep out of reach of children!

2. Do not place this Wireless Presentation Server in humid and / or hot environment, like bathroom or kitchen. Please refer to the specification of this Wireless Presentation Server to understand the environmental requirements of this Wireless Presentation Server.

3. This Wireless Presentation Server is designed to be used indoor . Do not use this Wireless Presentation Server at places like garden or any other outdoor environment.

4. Do not put any part or any component, accessories of this Presentation Server into your body.

5. If any part or any component is dropped into water, return it to your dealer of purchase and ask for an examination; never use it again before it has been properly processed by certified technician.

6. If the Presentation Server is dropped into water when it’s powered on, DO NOT ATTEMPT TO GET IT BACK BY YOURSELF! Switch the electrical power switch off, and call a qualified electrical technician or us immediately for help.

7. If you want to hang this Wireless Presentation Server at high places, please make sure that the Wireless Presentation Server is properly secured. Falling down from high places will damage this Wireless Presentation Server, and may cause serious injury to people!

8. Do not drag any connected cord with force; the terminal and cord will be damaged.

9. Only use dry cloth with water to clean this Wireless Presentation Server; do

not use alcohol or other chemical solution to clean this Wireless Presentation Server.

10. There’s no user-serviceable part inside this Wireless Presentation Server; if the Wireless Presentation Server is not working properly, please contact the dealer of purchase to ask for help.

11. Do not put the Wireless Presentation Server and / or A/C adapter on p aper, cloth, or other flammable materials. After hours of use, this Presentation Server will become hot, and may cause flammable materials placed under it to burn.

12. Do not cover the Wireless Presentation Server with cloth or any material; the Presentation Server will become overheat and cause malfunction, even cause fire.

13. When the Presentation Server is powered on, do not connect or disconnect any connection cable.

14. Do not display the same video content on projector, CRT / LCD display, and plasma TV for too long time. The image may remain PERMENTALY. Use screen saver to prevent to display the same video content for too long time.

15. If you smell something strange or even see smoke coming out from the Wireless Presentation Server or A/C adapter, disconnect the power cord immediately, and call your dealer of purchase for help.

1-3 System Requirements

Video Display:

A projector, CRT display, LCD display, or plasma TV that support VGA or



HDMI video input.



The display should support at least one resolution listed below:

800 x 600 1024 x 768 1152 x 864 1280 x 720 1280 x 768 1280 x 960 1280 x 1024 1400 x 1050 1440 x 900 1600 x 1200 1680 x 1050 1920 x 1200 1920 x 1440



Audio amplifier or speaker that accepts 3.5 audio connector.



Computers support wired or wireless Ethernet connectivity.



Windows 2000 / XP / Vista32/64 operating system with Internet Explorer V6.0 above browser.

 At least 100MB of available hard disk space.

OTE: Please check the user manual or specification of the display

ou’re going to use with this Presentation Server for supported

resolution. Using an unsupported resolution may damage your

rojector, CRT / LCD display, or plasma TV.

7 8

1-4 Highlights of this Wireless Presentation Server

Thanks again for choosing this Wireless Presentation Server. This Presentation Server eases the procedure of sharing a single projector among many presenters; they don’t have to switch VGA video cables, just use wired or wireless network connection to connect the Presentation Server, and the video on their computer display will be projected on big-screen.

Other functions of this Wireless Presentation Server include:  Supports both wired (10/100Mbps Ethernet connection) and wireless

(802.11b / g / n 11Mbps / 54Mbps / 150Mbps connection).

 Wireless interface supports encryption - protects the content of

presentation from theft.

 Presenter needs to input a random 4-digit Presentation Server access

code as 2nd level security check.

 WPS (Wi-Fi Protected Setup) function provides fast, easy, and secure

wireless encryption setup.

 No pre-installed software required – new users can download application

from Presentation Server directly, and get it installed within 30 seconds.

 Works with any projector, LCD / CRT display, plasma display with VGA or

HDMI video input.

 Supports 4/3, 16/10, and 16/9 display aspect ratio.

 Supports all major LCD display / projector resolutions - from 800 x 600

SVGA to 1920 x 1440 Full-HD resolution.

 Also supports audio output!

 Presenter can use supplied IR remote controller to do presentation.

 USB port - You can connect USB wired or wireless mouse to assist your

presentation

1-5 Familiar with Wireless Presentation Server / Remote Controller

Front / Top

Remote

USB

Black. Out

Ready

WPS

WLAN

LAN

Power

WPS

User Switch

Power

Name Description Remote IR signal receiver (for remote controller), DO NOT block

the receiver, or remote controller will not function. USB Front USB slot. Blackout LED Indicated that Wireless Presentation Server is in

‘Blackout’ mode (no display output). When this LED

lights, nothing will be displayed on external display. Ready When this LED lights, indicates Wireless Presentation

Server is ready to serve incoming requests. WPS When this LED lights, indicates WPS mode is active. WLAN When this LED flashes, indicates wireless LAN activity. LAN When this LED lights, indicates wired LAN is connected. Power When this LED lights, indicates this Wireless

Presentation Server is correctly powered. WPS WPS (Wi-Fi Protected Setup) button: press this button to

start WPS pairing. Power Press this button to switch this Presentation Server on /

off. User Switch Press this button to switch to next presenter Heat Sink Heat generated by this Presentation Server will be

removed through these holes (DO NOT BLOCK THESE

HOLES

WHEN THIS PRESENTATION SERVER IS POWERED

ON!)

Back

Power Jack Reset

Name Description 5V Connect to 5V A/C power adapter (Use supplied A/C

Reset When this Presentation Server is not working properly,

Antenna (Left and Right) HDMI HDMI audio / video output (Connects to any

VGA VGA D-sub 15 pin video output (Connects to any

Audio Output Stereo audio output (Connects to external speaker or

VGA AV USB LAN

HDMI

power adapter only!).

you can use a pen or pin to press and hold this button for

5 seconds to reset the Presentation Server.

Transmits wireless signal. Please keep both antennas

perpendicular to the ground for best signal reception.

HDMI-compatible display).

VGA-compatible display).

audio amplifier). USB Back USB slot for wired or wireless mouse. LAN 10/100Mbps fast Ethernet port (Connects to your local

area network)

Bottom

Name Description Wall Mounting Hole

Foot Pad Sticks the 4 foot pads (supplied in product package) here

MAC Address Label Product Label Indicates the model name and serial number of this

If you want to hang this Presentation Server on the wall,

use these wall mounting holes to mount the Presentation

Server.

so the project server can be steadily placed on the desk

or other horizontal places. You don’t have to stick foot

pads here if you plan to mount the Presentation Server

on the wall.

Indicates the MAC address of this Presentation Server.

Presentation Server. This information is very useful when

you need to request for assistance from the dealer of

purchase.

Remote Controller - Front

Name Description ‘Black out’ Button Press this button to activate ‘Black Out’ function, which

will remove any display contents displayed on external

display; Press this button again to resume. ‘Menu’ Button Press this button to switch the display output of

Presentation Server between presenter’s computer

display content and Presentation Server’s configuration

menu. ‘Page down’ button ‘Page up’ button Equivalent to ‘Right’ key on your computer’s keyboard. ‘Prev.’ button Select previous user (presenter) in Presentation Server’s

Equivalent to ‘Left’ key on your computer’s keyboard.

configuration menu; Equivalent to ‘Up’ key on your

computer’s keyboard when presentation is in progress. ‘Next’ button Select next user (presenter) in Presentation Server’s

configuration menu; Equivalent to ‘Down’ key on your

computer’s keyboard when presentation is in progress.

button . Select user in Presentation Server’s configuration menu

Remote Controller - Top

IR Transmitter

Name Description IR Transmitter al transmitter. When using the remote

Infrared sign

controller, point the IR transmitter to the front of the

Presentation Server. DO NOT use your finger or othe

object to block the IR transmitter, or your command will

not be received by Presentation Server.

Remote Controller - Back

Battery Lid

Name Description Battery Lid Press battery lid and push it out to open battery

compartment (to install or remove CR-2032 lithium

battery).

16 17

1-6 Install Wireless Presentation Server

Please follow the following instructions to get the Presentation Server installed:

1. Unpack the Wireless Presentation Server’s package, and make sure no item in the package is missing.

2. Stick the foot p ads on the 4 locations indicated on the picture shown below if you plan to put the Presentation Server on the desk or other horizontal places.

You can skip this step if you plan to hang the Presentation Server on the wall, and use the 2 wall-mounting holes located at the bottom of the Presentation Server to do this.

3. Connect the Ethernet cable to the LAN port (this port is labeled as ‘LAN’ and located at the back of this Presentation Server)

4. Insert the audio cable which connects with external amplifier / speaker to ‘Audio Out’ port located at the back of this Presentation Server.

You can skip this step if you don’t have external audio amplifier / speaker.

5. Insert HDMI / VGA cable which connects with external video display to HDMI / VGA port located at the back of this Presentation Server.

You can only connect to HDMI or VGA port at the same time.

6. Adjust the antennas located at the back of the Presentation Server, so they’re perpendicular to the ground.

7. Connect the A/C power adapter to the electrical outlet on the wall

8. Insert the power connector of A/C power adapter to the power slot labeled as ‘5V’ at the back of Presentation Server.

9. Press ‘Power’ button located at the front of Presentation Server.

10. Please check the status of the ‘Power’ LED located at the front of the Presentation Server. If it does not light, please check all connections and the status of electrical power outlet, or refer to chapter 4-1 ‘Troubleshooting’ for possible solutions.

Chapter II Using Presentation Server

2-1 Switch the Presentation Server On and Check IP address

When the connection between Presentation Server and external display is established, you can switch the display’s power on, then press the ‘Power’ button of Presentation Server, which is located at the front of Presentation Server.

You should be able to see the following image displayed on external display; if not, please make sure the external display you used with Presentation Server accepts input video resolution ‘1024 x 768’, and horizontal refresh rate ‘60Hz’.

If you see above image shown on display for more than two minutes, please press ‘Power’ button to switch the Presentation Server off, and then switch the Presentation Server on again. If this still happens, refer to chapter 4-2 ‘Troubleshooting’ for possible solutions.

When the Presentation Server is powered on and connected to a LAN with DHCP server, it will get an IP address from DHCP server automatically; when there’s no DHCP server available, it will use default IP address ‘169.254.0.200’. Please refer to chapter 2-3 ‘How to set IP address for your computer’ to set the IP address for computers wish to connect to Presentation Server when there’s no DHCP server available.

The IP address of Presentation Server can be found on the connected external display, like following picture:

The IP Address (Wireless / Wired Ethernet) of Presentation Server can be found here.

The IP address of the WLAN (wireless Ethernet) and LAN (wired Ethernet) interface of Presentation Server can be found at the lower-left corner of video display. You can use one of these IP addresses to connect to the Presentation Server.

2-2 Connect to Presentation Server by Wireless Ethernet

2-3 Set the IP address of the Computer

If there’s no DHCP server available on your LAN, please follow the following instructions to set the IP address of the computer, so the computers wish to use the Presentation Server can connect to project server.

If the operating system of your computer is….

Windows 2000 - please go to section 2-3-1

Windows XP - please go to section 2-3-2

Windows Vista - please go to section 2-3-3

2-3-1 Windows 2000 IP address setup:

1. Click ‘St art’ button (it should be located at lower-lef t corner of your computer), then click control panel. Double-click Network and Dial-up Connections icon, double click Local Area Connection, and Local Area Connection Properties window will appear. Select ‘Internet Protocol (TCP/IP)’, then click ‘Properties’

2. Select ‘Use the following IP address’, then input the following settings in respective field:

IP address: 169.254.0.x (where x is an integer greater or less than 200, if there’s more than one computer need to use this Presentation Server on the same network, every computer should use an unique number)

Subnet Mask: 255.255.255.0

click ‘OK’ when finish.

2-3-2 Windows XP IP address setup:

1. Click ‘St art’ button (it should be located at lower-lef t corner of your computer), then click control panel. Double-click Network and Internet Connections icon, click Network Connections, and then double-click Local Area Connection, Local Area Connection Status window will appear, and then click ‘Properties’

2. Select ‘Use the following IP address’, then input the following settings in respective field:

Subnet Mask: 255.255.255.0

click ‘OK’ when finish.

2-3-3 Windows Vista IP address setup:

1. Click ‘St art’ button (it should be located at lower-lef t corner of your computer), then click control panel. Click View Network Status and Tasks, then click

Manage Network Connections..Right-click Local Area Netwrok, then select ‘Properties’. Local Area Connection Properties window will appear,

select ‘Internet Protocol Version 4 (TCP / IPv4), and then click ‘Properties’

2. Select ‘Use the following IP address’, then input the following settings in respective field:

Subnet Mask: 255.255.255.0

click ‘OK’ when finish.

27 27

+ 61 hidden pages
