Digitus USB 2.0 WebCam User guide

USER MANUAL

USB 2.0 WebCam

Version 1.0

2/11

Features & Specification:

x Idea for notebook users, small and compact with integrated clamp/stand
x LED lighting for taking pictures in the dark
x Maximum resolution: 1280 x 960 Pixels
x Picture resolution: 640 x 480 Pixels
x Sensor specification: 1/4” CMOS

Package Contents:

x USB Webcam
x User manual
x Software CD-ROM

System Requirements:

x One available USB port
x IBM Compatible PC
x Windows 98SE/ME/2000/XP
x System equipped with Pentium II 200/MMX/AMD K6 or above
x DRAM: 32 MB or above
x Sound card, speaker and microphone are required for video and audio recording
x A modem or Lan card is required for application of video conferencd and video mail

Before installation note:

Do not connect the Camera to the computer system first. Install the driver and applications first.
Insert the VP-Eye CD-ROM to the system and you can change the target group name, target directory and
folder, and run the installation options first before the driver and VP-Eye installation.

1

Installing the Driver and Software:

1. Place the CD-ROM disc into the CD-ROM drive.

2. Do not plug in the camera first. Click on the Driver menu to install the drivers first.

3. Select the installation language and click on OK. The
installation process begins.

4. Click on “Next” button to proceed.

2

4/11

5. Next select the “Complete” option to install all the drivers into the hard disk and click on “Next” to begin.

6. Click on “Next” again to begin the driver installation.

3
