Product Introduction:
With a VGA Splitter (Video Splitter) you can distribute a video signal to multiple VGA
output equipments synchronously, to let different displays show the same image. The
equipment includes an additional power adapter, which disposes the output signals, in
order to ensure and improve the signal output. Advantages: high bandwidth, resolution
and reliability. Both the long-distance signal transmission and the max long-distance can
reach 65 meters. It can be used in security businesses, computer exhibition halls, public
broadcasting as well as in education & training centers etc.
Safety Guide:
In order to ensure the correct use of the device and the security of the operator, please
follow these steps:
1. The power supply of the device is DC9V/300mA; DC9V/1000mA
2. Do not place the device into an area where it is too hot or too cold.
3. The power of the device will heat up when working. So keep the working
environment in good ventilation in order not to damage the machine with high
temperature.
4. Non-professionals should not take apart the machine or repair it without permission
in order to avoid accidents or aggravating damage extent of the device.
5. Do not spill any chemical product or liquid on the device or near to it.
Trouble Shooting:
1. If there is no output signal, please check the following:
A. Whether the power wire is plugged into the device.
B. Whether the connection wire is well.
C. Whether there is an input signal.
2. If the power light is off, the power supply may be incorrect.
3. If the output image is interfered, the device may not be grounded properly.
4. If the output image is not clear, please check whether the connection wire
has got a problem.
Specifications:
DS-41100
DIGITUS® Item no. DS-42140
Bandwidth 250MHz 350MHz 500MHz
Connector
Type
Min Input
Voltage
Signal
Max Input
Voltage
I/O
Impedance
Optimal
Resolution
Max
Resolution
Video
Horizontal
Frequency
Input HD15M; Output HD15F
0.5Vp-p
1.0Vp-p
75Ω
1280*1024 1920*1080 2048*1536
1920*1080 2048*1536
30-120KHz 30-120KHz 30-120KHz
DS-42100
DS-43100
DS-41110
DS-42110
DS-42130
Vertical
Frequency
Dimension
(mm)
Pertinence
Power
Housing Metal
40-120Hz 40-120Hz 40-120Hz
132*92*41 432*115*45 432*115*45
AC100-240V, DC9V/300mA, DC9V/1000mA
