Page 1
Audio Switch, 2x1
Manual
DS-40135
1.0 Introduction
With the DIGITUS Audio Switch, you can connect up to two devices with a Toslink
connector (e.g. receiver, computer, games console such as PS3/PS4 or Xbox/Xbox
One, Blu-Ray player, Apple TV etc.) to one terminal device (sound bar, receiver,
speakers, HiFi system). Switching between the connected devices can be
performed manually using the selection buttons on the switch or alternatively using
the included remote control. What’s more, the 1-to-1 transmission ensures a brilliant
sound quality without static or distortion.
Page 2
2.0 Feature
Connect up to 2 playback devices to your sound system
•
• Manual switching at the touch of a button or using the included remote control
• Lossless signal transmission without static or distortion
• Supports the S/PDIF standard for digital audio transmission
• Impervious to magnetic and electric interference
• Input: 2 x Toslink
• Output: 1 x Toslink
• Suitable for all devices with S/PDIF Toslink connector
• Power supply via supplied USB power cable
• Comfortable manual switching between the two channels at the touch of a
button using the “Select” button on the switch or using the remote control
• Supported audio formats: LPCM2.0/DTS/Dolby-AC3 and 5.1 Audio
• Cable range: up to 40 m to output source
• Surge protector
• Plug & Play Installation
• Status LEDs (connection indicator)
• Weight: 38 g
• Dimensions: 60.5 x 20.5 x 54 mm (WxHxD)
• Color: black
１
Page 3
3.0 Package Content
SPDIF/TOSLINK SWITCH
USB Power Cable
User Manual
Remote control
IR extender receiver
4.0 Panel Description
２
Page 4
5.0 Connection and Operation
Optical fiber Cable
Optical fiber Cable
Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the
requirements of Directive 2014/30/EU and the Directive 2011/65/EU for RoHS compliance. The
complete declaration of conformity can be requested by post under the below mentioned
manufacturer address.
Warning:
This device is a class B product. This equipment may cause some radio interference in living
environment. In this case, the user can be requested to undertake appropriate measures to
prevent interference.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
Optical fiber Cable
AMPLIFIER
３
