HDMI Converter (VGA-HDMI), DS-40130
Dear customer
Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This kind of the Converter is a VGA video converter. It converts VGA input into HDMI and allows PC users to enjoy their larger image on TV. The conversion is along with the R/L audio. It offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
1.1 FEATURES
This HDMI converter has many features that enable it to perform in a superior manner. Among those features you will find:
l Easy to Use: Install in seconds, no need of setting. l Conversion: It could convert PC’s VGA video and R/L audio into complete
HDMI.
l Support highest video resolution 1280x1024. l Support 165MHz/1.65Gbps per channel (6.75Gbps all channel) bandwidth. l Support 8bit per channel (24bit all channel) deep color.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Output Video HDMI 1.2a
2
VGA Resolution 640x480 60Hz 75Hz
800x600 60Hz 75Hz 1024x768 60Hz 75Hz 1280x720 60Hz 75Hz 1280x768 60Hz 75Hz 1280x960 60Hz 75Hz
1280x1024 60Hz 75Hz Operating Frequency Vertical Frequency Range 50/60Hz Video Amplifier Bandwidth 1.65Gpbs/165MHz Mechanical Size(W-H-D) 88mmW x 25.5mmH x 68mmD Weight(Net) 0.68kgs Warranty Limited Warranty 1 Year Parts and Labor Environmental Operating Temperature
0 to +70 Operating Humidity 10% to 85 % RH (no condensation) Storage Temperature
-10 to +80 Storage Humidity 5% to 95 % RH (no condensation) Power Requirement External Power Supply 5V DC@2A Power consumption (Max) 5W Regulatory Approvals Converter Unit FCC,CE, Power Supply CE,FCC Accessories Adapter AC Power Adapter US standard, UK standard and so
on
User Manual English, German
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton:
l Main unit. l 5V DC Power Supply l User's Manual
3
4.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal input(s), output(s) and power requirements.
INPUT
VGA
OUTPUT
DC/5V
5.0 CONNECTION AND OPERATION
R/L
HDMI
Before installation, please make sure all devices you wish to connect have been turned off.
1) Connect the VGA video and R/L audio from computer to this product. (Input cables are optional)
2) Connect the HDMI output from this product to the TV which has HDMI
input.
3) Connect the VGA and R/L audio output of this product to the computer’s monitor and speaker if necessary.
4) Insert the DC side of 5v power supply into this product and then connect the AC side of the power supply into the wall outlet.
5) Power on the computer and TV, choose the input of TV to its HDMI channel.
4
6) The image does not need to be adjusted. This Converter will
position it automatically.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
5
