ADVANCED HD NETWORK
FIXED DOME CAMERA
USER MANUAL
Please read instructions thoroughly before operation and retain it for future reference.
IMPORTANT SAFEGUARD
All lead-free products offered by the company comply with the requirements of the
European law on the Restriction of Hazardous Substances (RoHS) directive, which means
our manufacture processes and products are strictly “lead-free” and without the hazardous
substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product
must be collected separately at the product end-of-life. This applies to your product and
any peripherals marked with this symbol. Do not dispose of these products as unsorted
municipal waste. Contact your local dealer for procedures for recycling this equipment.
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at
his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device mat not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Trademark Acknowledgements
iPad® & iPhone® are the registered trademarks of Apple Inc.
Android™ is a trademark of Google Inc. Use of this trademark is subject to Google Permissions.
Microsoft®, Windows® & Internet Explorer® are registered trademarks of Microsoft Corporation in the United
States and/or other countries.
Disclaimer
We reserve the right to revise or remove any content in this manual at any time. We do not warrant or assume
any legal liability or responsibility for the accuracy, completeness, or usefulness of this manual. The content of
this manual is subject to change without notice.
This product doesn’t have a standby / shutdown mode.
MPEG4 Licensing
THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN
COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING
MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND
NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY
MPEG LA TO PROVIDE MPEG4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL INTERNAL
AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, LLC. SEE
HTTP://WWW.MPEGLA.COM.
GPL Licensing
This product contains codes which are developed by Third-Party-Companies and which
are subject to the GNU General Public License (“GPL”) or the GNU Lesser Public License
(“LGPL”).
The GPL Code used in this product is released without warranty and is subject to the
copyright of the corresponding author.
Further source codes which are subject to the GPL-licenses are available upon request.
We are pleased to provide our modifications to the Linux Kernel, as well as a few new
commands, and some tools to get you into the code. The codes are provided on the FTP
site, and please download them from the following site or you can refer to your distributor:
http://download.dvrtw.com.tw/GPL/076D_Series/arm-linux-2.6.tar.gz
TABLE OF CONTENTS
1. OVERVIEW ......................................................................................................................................... 1
1.1 Product Features ....................................................................................................................................... 1
1.2 Package Content ....................................................................................................................................... 1
1.3 Product Overview ...................................................................................................................................... 1
1.4 Connectors ................................................................................................................................................ 1
1.5 External I/O Port ........................................................................................................................................ 2
1.6 Status Indicator.......................................................................................................................................... 2
2. CAMERA ACCESS WITH INTERNET EXPLORER ............................................................................ 3
2.1 Camera Login ............................................................................................................................................ 3
2.2 Control Panel Overview ............................................................................................................................ 3
2.3 Digital PTZ (DPTZ) Operations ................................................................................................................. 5
2.4 Event Record Search & Playback ............................................................................................................. 6
3. CAMERA CONFIGURATIONS ............................................................................................................ 7
3.1 System configuration menu ....................................................................................................................... 7
3.2 Network ..................................................................................................................................................... 8
3.2.1 Network ............................................................................................................................................................ 8
3.2.2 QoS .................................................................................................................................................................. 8
3.2.3 DDNS ............................................................................................................................................................... 8
3.2.4 SNTP ................................................................................................................................................................ 9
3.2.5 FTP ................................................................................................................................................................... 9
3.2.6 MAIL ................................................................................................................................................................. 9
3.2.7 SMS ................................................................................................................................................................ 10
3.2.8 Filter ............................................................................................................................................................... 11
3.2.9 UPnP / Bonjour ............................................................................................................................................... 11
3.2.10 RTP .............................................................................................................................................................. 12
3.3 Camera ................................................................................................................................................... 13
3.3.1 Camera ........................................................................................................................................................... 13
3.3.2 Video .............................................................................................................................................................. 13
3.3.3 Color ............................................................................................................................................................... 14
3.3.4 Audio .............................................................................................................................................................. 14
3.3.5 Advance .......................................................................................................................................................... 14
3.4 Record ..................................................................................................................................................... 15
3.4.1 Record ............................................................................................................................................................ 15
3.4.2 Record Timer .................................................................................................................................................. 15
3.5 Storage .................................................................................................................................................... 15
3.5.1 Memory .......................................................................................................................................................... 15
3.6 Trigger ..................................................................................................................................................... 16
3.6.1 Trigger ............................................................................................................................................................ 16
3.7 General ................................................................................................................................................... 17
3.7.1 General ........................................................................................................................................................... 17
3.7.2 Time ................................................................................................................................................................ 18
3.7.3 Server Log ...................................................................................................................................................... 18
3.7.4 Online ............................................................................................................................................................. 19
3.7.5 Account ........................................................................................................................................................... 19
3.7.6 Google Maps .................................................................................................................................................. 20
3.7.7 Maintenance ................................................................................................................................................... 20
APPENDIX 1 PRODUCT SPECIFICATIONS ........................................................................................ 22
APPENDIX 2 BIT RATE TABLE FOR REFERENCE ............................................................................ 23
APPENDIX 3 POE CONNECTION ....................................................................................................... 25
APPENDIX 4 API ID APPLICATION FOR SMS MESSAGING .............................................................. 26
APPENDIX 5 Q&A ................................................................................................................................ 28
APPENDIX 6 RECORDING TIME TABLE ............................................................................................ 29
1
1. OVERVIEW
1.1 Product Features
Easy network setup with your iPhone / iPad
1.3 Megapixel SONY sensor with HDTV 720p quality, allowing users to notice minor details more easily
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
ONVIF standard supported to simplify system integration
External alarm I/O device connection
Supports external microphone & speaker connection for audio transmission
Remote Surveillance
--
Fully compatibility on iPhone & iPad, and Internet Explorer® on Windows® operating system
1.2 Package Content
□ Network camera □ Screws & Wall Plugs □ 3-pin Terminal
□ Quick Setup with iPhone / iPad □ Adapter
□ Audio Cable
1.3 Product Overview
1.4 Connectors
Ethernet: Connect a RJ45 network cable.
DC5V IN: Connect the supplied regulated power supply.
RESET: With the power connected, press to reset all parameters, including the IP address to factory default
settings.
The camera will reboot after default reset. Please do not disconnect your camera during the reset
process.
Alarm I/O: A 3-pin I/O terminal is supplied with the camera for external alarm device connection. For details,
please refer to “1.5 External I/O Port” at page 2.
AUDIO: Plug in the supplied audio cable for speaker and microphone connection.
* The speaker and microphone are not supplied with the sales package and should be purchased separately.
2
1.5 External I/O Port
This camera supports external I/O device connection, and a 3-pin I/O terminal is supplied with this camera for
easy connection.
Below shows which input on the I/O terminal you should use for wiring when you want to connect an external
device to this camera.
3-pin I/O Terminal Alarm Out Connection
1.6 Status Indicator
ICON
LAN connection status Internet connection status
System Status
During powering on
A
lways on
A
lways on
Reset default
Blinking
(on 250 ms, off 250 ms)
Always off
Upgrade
Blinking
(on 250 ms, off 250 ms)
Blinking
(on 250 ms, off 250 ms)
Connection Status
LAN connected
A
lways on --
LAN disconnected
Blinking
(on 100 ms, off 500 ms)
--
Internet connected --
A
lways on
Internet disconnected --
Blinking
(on 100 ms, off 500 ms)
3G Connection Error on
iPhone / iPad / Android Mobile Device
3G Connection Setting
Uncompleted
--
Blinking
(on 5 sec, off 0.5 sec, on 0.5 sec, off 0.5 sec, on 5 sec)
--
* LED blinking frequency - LED on / LED off
3
2. CAMERA ACCESS WITH INTERNET EXPLORER
This network camera can be accessed via Microsoft® Internet Explorer® and iPhone / iPad / Android mobile devices
with our self-developed program “EagleEyes” installed depending on different using situations.
Note: For details about accessing network cameras via iPhone / iPad / Android mobile devices, please
refer to http://www.eagleeyescctv.com.
Before using the camera, make sure you have configured the network settings, and the network connection is fine.
For network configurations, please refer to:
“Quick Setup With iPhone / iPad” supplied with your camera if you’re using iPhone / iPad, and your network
environment is wireless.
“ADVANCED NETWORK SETUP” downloadable from www.surveillance-download.com/user/m328a.swf
if your
network environment is not wireless.
2.1 Camera Login
Step1: Open your web browser, and key in http://ipaddress:portnum in the URL address box.
For example, for the IP address 60.121.46.236 and port No. 888, please key in ”http://60.121.46.236:888” into
the URL address box, and press “Enter”.
Step2: In the login page, key in the user name and password, and enter the security code from the image below if any.
Then, click “LOGIN”.
Step3: The wizard is then started.
‧ To skip the wizard and directly access the camera live view, click “Close”.
‧ To directly access the camera live view without starting the wizard for the login next time, check “Do not start wizard at login”.
Note: If you’re prompted to install “VLC player”, “Software” or “H264 Streaming Viewer”, please agree
to proceed the installation. Or, you might not be able to see the live view properly.
Step5: When the login is successful, the live view is shown.
2.2 Control Panel Overview
Note: The buttons available depend on the model number used and the user level used to log in.
4
Function Icon User Level Description
Live
Supervisor / Power User
/ Normal User / Guest
Switch to the live view page.
Backup
Supervisor / Power User
Enter the event record list for video playback.
For details, please refer to “2.4 Event Record Search & Playback’ at page
6.
DPTZ*
Supervisor / Power User
/ Normal User
Switch to the DPTZ configuration page.
For details, please refer to “2.3 Digital PTZ (DPTZ) Operations” at page
5.
Config.
Supervisor
Switch to the system configuration page, and the functions available for
“Supervisor” and “Power User” are different.
For details, please refer to “3.1 System configuration menu” at page 7.
Media Type -- Supervisor / Power User
/ Normal User / Guest
Select the image player from the drop-down list:
H.264 / MPEG-4 / Motion JPEG
QuickTime
QuickTime is Apple Inc.’s multimedia software. You need to have
QuickTime installed in your operating system before selecting “QuickTime”.
When it is selected, you will be promoted to enter the user name and
password to access the camera.
VLC
Quality -- Supervisor / Power User
/ Normal User
Click & drag the slider to select the video quality:
Basic / Normal / High / Best.
Video Resolution -- Supervisor / Power User
/ Normal User
Select the image resolution from the drop list:
SXGA (1280 x 1024) HD720P (1280 x 720)
VGA (640 x 480) QVGA (320 x 240)
Live View Size:
Supervisor / Power User
/ Normal User
Full Screen
Click to display the image in full screen.
To exit the full screen mode, press “Esc” on your keyboard.
This icon appears only when the selected resolution is SXGA, HD720P & VGA.
Double size
The QVGA resolution is resized to fit into the current live view size.
This icon appears only when the selected resolution is QVGA or CIF.
Normal Size
The current live view size is the same as the selected resolution.
This icon appear only when the selected resolution is SXGA or HD720P.
Fit to screen
The selected resolution is resized to fit into the current live view size.
This icon appear only when the selected resolution is SXGA or HD720P.
No Scale
Click and hold the movable square on the left bottom corner of the live
view to move
This icon appear only when the selected resolution is SXGA or HD720P.
Snapshot
Supervisor / Power User
/ Normal User
Click to take a snapshot of the current view on a new window. Right
click on the picture and re-save it to the location you want.
Audio On / Off
/
Supervisor / Power User
/ Normal User
Click to switch the audio-in on / off.
This function is available only when a microphone is connected.
Alarm Out
Supervisor / Power User
/ Normal User
Click to force your alarm-out device to work. For example, when your
alarm device is a buzzer, click this button and your buzzer will start to
sound even if there’s no alarm event.
Microphone
/
Supervisor
Click to switch the audio-out on / off.
This function is available only when a speaker is connected.
5
2.3 Digital PTZ (DPTZ) Operations
This camera has PTZ capability, i.e. digital PTZ (hereafter called “DPTZ”), for wide area monitoring.
STEP1: Click “DPTZ” to show the DPTZ control panel.
STEP2: Select the functions when needed:
FUNCTION ICON DESCRIPTION
Resolution
--
Select the video resolution for the DPTZ function. Only “VGA” and “QVGA” are available.
Take snapshots
Click to take a snapshot of the current view on a new window. Right click on the picture and re-save it to the
location you want.
Audio On / Off /
Click to switch the audio-in on / off.
This function is available only when a speaker is connected.
Alarm Out
Click to force your alarm-out device to work. For example, when your alarm device is a buzzer, click this button
and your buzzer will start to sound even if there’s no alarm event.
Microphone /
Click to switch the audio-out on / off.
This function is available only when a speaker is connected, and when you’re a “Supervisor”.
6
2.4 Event Record Search & Playback
This camera can only save up to three alarm recordings.
Note: To save more recorded data, it’s recommended to use this camera with the compatible NVR.
/
Previous / Next Hour
Click to jump to the next / previous time interval in an hour, for example, 11:00 ~ 12:00 or 14:00
~ 15:00, and start playing the earliest event video clip recorded during this whole hour.
Fast Forward Increase the speed for fast forward. Click to get 2X, 4X, 8X & 16X speed forward eventually.
Fast Rewind Increase the speed for fast rewind. Click to get 2X, 4X, 8X & 16X speed rewind eventually.
Play
Click to play the current video clip.
Pause
Click to pause the video playback.
Stop
Click to stop the video playback.
Step
In the pause mode, click to get one frame forward.
Audio
Click to mute the playback if necessary, and click again to restore.
This function is available only when a speaker is connected during recording.
Download
Click to download the current video clip to the specified path in your PC.
The downloaded video can only be opened by our own video player. Please go to “General” → “Maintenance” to
download the video player, or get the player from the CD supplied with the sales package.
7
3. CAMERA CONFIGURATIONS
Users can further configure this network camera by accessing via Internet Explorer.
3.1 System configuration menu
Click “Config.” to enter the configuration page.
The functions are categorized into six menus: Network, Camera, Record Timer, Storage, Trigger and General.
For details about “Network”, please refer to “3.2 Network” at page 8.
For details about “Camera”, please refer to “3.3 Camera” at page 12.
For details about “Record”, please refer to “3.4 Record” at page 15.
For details about “Storage”, please refer to “3.5 Storage”’ at page 15.
For details about “Trigger”, please refer to “3.6 Trigger” at page 16.
For details about “General”, please refer to “3.7 General” at page 17.
Main Menu Sub-Menu Reference
Network Network Configure network settings.
QoS Limit the data flow for live streaming.
DDNS Enter DDNS information when the network type is PPPOE or DHCP.
SNTP Synchronize your camera time with the networked computer systems.
FTP
Enter the FTP information for event notifications when “FTP” is chosen in “Trigger” →
“Trigger”.
Mail Enter Email information for event notifications when “Email” is chosen in “Trigger” → “Trigger”.
SMS
Enter text messaging information for SMS notifications when “SMS” is chosen in “Trigger” →
“Trigger”.
Filter Choose to permit or block the IP address(es) which can access this camera.
UPnP
*Suitable for Windows-based operating system.
Allow this camera to be detected among devices within the same network area for easy and
quick usage.
Bonjour
*Suitable for Apple Mac-based operating system.
Allow this camera to be detected among devices within the same network area for easy and
quick usage.
RTP
Set the parameters for video data transmission when you’re using multimedia other than web
broswers and Video Viewer for remote access.
Camera Camera
1. Rename the camera.
2. Change the place where the camera name is shown on the screen.
Video Adjust video-related settings in different video format.
Color Adjust the color performance.
Audio Adjust the audio volume of the microphone and speaker.
Advance Adjust the camera parameters if necessary.
Record Record Configure the record function.
Record Timer Schedule external alarm recording.
Storage Memory Check the current storage capacity and clear all recorded data when needed.
8
Main Menu Sub-Menu Reference
3.2 Network
3.2.1 Network
You can set the network configuration of the network camera depending on your network type.
For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/m328a.swf.
3.2.2 QoS
QoS, Quality of Service, is the ability to control the data flow for real-time streaming. This function is important if
your network bandwidth is insufficient and you have other devices to share the network bandwidth.
Check “QoS Enable”, and set the max. upload rate from 256 to 10240 kbps.
3.2.3 DDNS
Select “On” when the selected network type in “Network” is “PPPOE” or “DHCP”.
For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/m328a.swf.
Trigger
Trigger
1. Enable / disable motion, alarm and PIR detection.
2. Set the motion detection area.
3. Configure how the camera reacts for any event.
General General
1. Select the language of the web browser.
2. Check the MAC address of the camera.
3. Lock camera access after the specified time.
4. Enable or disable LED status indication.
Time Set daylight saving time and the current time.
Server Log Check the system event logs.
Online Check the current online user(s).
Account
1. Create a new user account with different access privilege.
2. Modify or delete an existing user account.
Google Maps Allow you to know where the network camera is.
Maintenance
1. Check the current firmware version and upgrade your camera.
2. Copy system configurations.
3. Reboot the camera.
4. Download the video player to play the recorded data.
9
3.2.4 SNTP
SNTP (Simple Network Time Protocol) is used to synchronize your camera time with the networked computer
systems.
Function Description
GMT Once users choose the time zone, the network camera will adjust the local area time of the system automatically.
NTP Server Simply use the default SNTP server (For example, tock.stdtime.gov.tw) or change to another server with which users are
familiar.
Sync. Period Select “Daily” to synchronize the camera time with the network time every day or “None” to turn off this function.
Sync Click and the network camera will synchronize the time with the network time.
3.2.5 FTP
Enter the detailed FTP information and click “Save” to confirm. The information you set here will be applied
when “FTP” is selected in “Trigger” → “Trigger”.
3.2.6 MAIL
Enter the detailed e-mail information and click “Save” to confirm. The information you set here will be applied
when “Email” is selected in “Trigger” → “Trigger”.
Function Description
SMTP Server Enter the SMTP server address provided from your e-mail system supplier.
Port Enter the port number provided from your e-mail system supplier. If this column is left blank, the e-mail server will use
port 25 to send e-mails.
Mail From Enter the name of the sender.
SSL Encryption Select “Yes” if your e-mail server is using SSL encryption to protect your e-mail content from unauthorized access.
Verify Password Some mail servers are required to verify the password. Please enter the “user name” and “password”.
E-Mail Address List Add the e-mail address(s) of the assigned recipient(s).
10
Function Description
Test When all information is entered, click “Test Mail” to try if the receipt.
3.2.7 SMS
Note: Before using this function, you need to apply an API ID from the mobile messaging company,
Clickatell, and you will be charged starting from the 11th message. For details, please refer to
“APPENDIX 4 API ID APPLICATION FOR SMS MESSAGING” at page 26.
Enter the detailed information needed for text messaging, and click “Save” to confirm. The information you set
here will be applied when “SMS” is selected in “General” → "Trigger".
Function Description
System The text messaging service provider is Clickatell.
User name / Password Enter the account user name and password you created in Clickatell.
API ID Enter the API ID you applied from Clickatell.
Recipient Click “Add” to enter the phone number, including the country code, to receive the text
message. Five sets of phone numbers are allowed.
Transfer Interval Set the interval time in minutes between two-message sending.
The options are 0, 15, 30 & 60.
Reset Counter Click to restart the text messaging, and the SMS will be sent after the specified time interval
since you click this button.
Message Enter the text content (up to 70 characters) you want to send with the text message.
Test To know whether your SMS setting is correct, click this button to immediately send a SMS to
your phone.
Note: This testing is not free and you will be charged for SMS sending base on your
local rate.
11
3.2.8 Filter
Choose to permit or block the IP address(es) which can access this camera, and click “Save” to confirm.
Function Description
Filter Configuration
Error Count Set the maximum count for login failure. When the maximum count is reached, the IP address trying to access the
network camera will be locked.
Error Lock Time Set the lock time in minutes when the maximum count of error login for an IP address is reached.
Echo Request Select “Non-Block” to allow other users to use the ping command to detect the IP address of your network camera, or
“Block” to deny the ping command request.
IP/MAC Filter Configuration
IP/MAC Filter Choose to enable or disable the filter function.
IP/MAC Filter Policy If “Enable” is selected, choose whether you want to permit (Allow) or block (Deny) the IP address list below.
IP/MAC Filter Rules
Rule
‧ To add an item to the IP address list, key in the IP address in “Rule”, and click “Add”.
‧ To remove an existing item in the IP address list, click the item you want to remove, and click “Delete”.
3.2.9 UPnP / Bonjour
“UPnP” stands for “Universal Plug and Play”, which allows devices to connect seamlessly in the home and
corporate environments and simplify installation of computer components, and is only suitable for Microsoft
Windows-based operating system.
“Bonjour” functions the same as “UPnP”, but it’s only suitable for Apple Mac-based operating system.
UPnP
Bonjour
Check “Enable” to allow the network camera to be detected among devices within the same network area, and
set the identification name of the camera in “Friendly name”.
When this function is activated, the other PC within the same domain as this camera will be able to search this
camera in:
“Network Neighbor” with the identification name set in “Friendly name” for Windows-based PC, or
“
” (finder) or “Bookmark” with the identification name set in “Device Name” for Mac-based PC.
12
Double-click it to quickly open the web browser for camera access.
Port Mapping (Available only in UPnP)
This function can eliminate the need to additionally access the router for port forwarding.
For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/m328a.swf.
Note: Before using this function, make sure your router supports UPnP, and this function is enabled. If
not, please access your router additionally for port forwarding.
When “Port Mapping” is set to “Enable”, the system will automatically assign an IP address or port number for
you if no IP address or port number is entered.
Note: When the configurations are saved successfully, you’ll see a message indicating the IP address
and port number assigned to this network camera.
3.2.10 RTP
The Real-time Transport Protocol (RTP) is an Internet protocol standard to manage the real-time transmission of
multimedia, such as VLC player.
The media player you want to use for remote access must support RTP transmission for this function to work
normally.
Note: When you’re about to end the remote access, please press the stop button on your media player
first, and then close the program. This is to ensure the server receives the stop command, and
also help to protect the server from redundant data transmission.
13
Function Description
Port Range
The port range used by RTP is limited, and preserving 100 ports between the start port and end port is necessary.
Start Port The range of the start port is 1024 ~ 65434.
End Port The range of the end port is 1124 ~ 65534.
Multicast
Address and port for
H264 / MPEG4 /
JPEG transmission
Set a specific address and port for multicast of each stream format (H264/ MPEG4/ JPEG).
The range of the address is limited between 224.0.0.1 ~ 239.255.255.255.
The port for multicast must be an even number.
Address and port for
audio transmission
Set a specific address and port for multicast of audio.
The range of the address is limited between 224.0.0.1 ~ 239.255.255.255.
The port for multicast must be an even number.
Time to Live (TTL) The range of Time to Live of the package is between 1 ~ 255. As soon as Time to Live of the
package is 0, it will be dropped.
3.3 Camera
3.3.1 Camera
Rename the camera, and change the place where the camera name is shown on the screen, UP-LEFT /
UP-RIGHT / DOWN-LEFT / DOWN-RIGHT.
3.3.2 Video
Adjust video-related settings in different video format.
“Quality” is related to image clearness.
“FPS” is related to the fluency of the video. The more the FPS, the more fluent the video.
“Max Bit Rate” is the maximum limitation of data transmission in the selected image format and resolution.
Note: QQVGA is for mobile surveillance only.
14
3.3.3 Color
Adjust the color performance from Brightness, Contract, Hue and Saturation. Click and drag the slider to preview
the color change on the right side of ths page and adjust the image color.
To restore the default values, click “Back to Default”.
3.3.4 Audio
Drag the slider to adjust the volume of the microphone and speaker.
3.3.5 Advance
Adjust the camera parameters if necessary.
Item Description
Shutter Speed Set the shutter speed based on your need.
The options are: Up to 1/10 sec, Up to 1/30, Up to 1/15, Up to1/6, Up to 1 and Up to 2.
Mirror Select “ON” to rotate the images horizontally based on your installation situation when necessary.
Flip Select “ON” to rotate the image 180° when necessary.
De-noise Click and drag the slider to adjust the level from 0 ~ 10 to decrease the noise shown in the dark environment.
IR Control Select “Auto” to automatically enable IR LEDs at night or in the dark environment, “On” to always enable IR LEDs, or “OFF”
to disable this function.
White Balance Process the current image to retain color balance over a color temperature range.
The options are: Auto, Incandescent Light, Cool Light, sun Light, Cloudy & Sun Shade.
Sharpness Sharpness enhances the clarity of image detail by adjusting the aperture and sharpening the edges in the pictures.
Hold and drag the slider to adjust the level of sharpness from 0 ~ 100. The higher the value, the sharper the image.
15
3.4 Record
3.4.1 Record
In “Record Configuration”, you can:
Enable or disable the alarm record function. When “Enable” is set to “No”, the alarm record function is
disabled even if you enable it in other configuration pages.
Select if the data should be overwritten when the memory storage is full.
Enable or disable the audio record function.
Note: This function is available only when a microphone is connected to this camera.
Select the video resolution for event recording: SXGA / HD720P, VGA and QVGA.
Note: The higher resolution you choose, the more accuracy and higher image quality the recording will
be, but the faster the memory storage is consumed and become full.
3.4.2 Record Timer
To schedule alarm recording, enable it, and select the day and time for recording.
Note: The timer must be enabled for the record function to work properly.
3.5 Storage
3.5.1 Memory
In “Memory”, you can check the remaining capacity for recording, or clear all recorded data saved if needed.
Note: The recorded data will be removed also when you reset or reboot this camera.
This camera can only save up to three alarm recordings.
Note: To save more recorded data, it’s recommended to use this camera with the compatible NVR.
Note: To know the total recording time per recording resolution, please refer to “APPENDIX 6
RECORDING TIME TABLE” at page 29.
16
3.6 Trigger
3.6.1 Trigger
You can configure how this camera reacts when there’s an alarm, a motion or a PIR event.
Detect
Item Description
External Alarm Enable or disable detection from external alarm-in device, and click the title “External Alarm” (in blue) to set “N.O.”
or “N.C.” depending on the configuration of your alarm-in device.
Motion Enable or disable motion detection.
Motion detection is not supported when the stream format is Motion JPEG.
When “Enable” is selected, click “Detection” to enter the motion detection area setting page as follows:
Sensitivity:
Set the detection sensitivity from the drop-down list: High, Normal or Low.
Area Setting:
Set the motion detection area by selecting the area grids with your mouse. Pink grids represent the area that is not being
detected while the transparent grids are the area under detection. You can set multiple areas under detection.
Click “Clear All” to set the whole area undetected.
Click “Select All” to set the whole area under detection.
PIR Enable (ON) or disable (OFF) PIR detection.
For Push Video to work properly, make sure this function is enabled.
Duration Set the duration time for trigger recording (5 / 10 / 20 / 40 seconds).
17
Action
Here defines how the camera delivers alerts to you for any event.
Item Description
E-Mail Select the event type you want to receive E-mail notifications when it occurs.
Then, click the title “E-Mail” (in blue) to configure the media type (H264 / JPEG / MPEG4), file format (AVC / AVI),
and record time (1 ~ 5 seconds) for the event video clip.
The camera will send the captured video clip to the E-mail address(s) you assigned in “Network” “Mail” once the
selected event type occurs.
FTP Select the event type you want to receive FTP notifications when it occurs.
Then, click the title “FTP” (in blue) to configure the media type (H264 / JPEG / MPEG4), file format (AVC / AVI), and
record time (1 ~ 5 seconds) for the event video clip.
The camera will upload the captured video clip to the FTP site you assigned in “Network” “FTP” once the
selected event type occurs.
SMS Select the event type you want to receive a text message when it occurs.
The camera will send a text message to the mobile phone number you assigned in “Network” “SMS” once the
selected event type occurs.
Alarm Out
Select the event type you want to trigger the alarm-out device to work when it occurs.
Then, click the title “Alarm Out” (in blue) to configure the trigger rule (LOW / HIGH).
Record Select the event type you want to enable event recording when it occurs.
Audio Alert Select the event type you want to enable audio alert when it occurs.
3.7 General
3.7.1 General
To change the language of UI interface, select from the drop-down list in “Language”.
To allow the status LED indicators to show the status as indicated in “1.6 Status Indicator” at page 2, select
“Enable” in “Status LED Mode”; to hide the status, select “OFF”; to only show the error status, select “Temporary
Disable”.
Note: The status LED mode will be restored to “Enable” after camera reboot when “Temporary OFF” is
selected.
To lock camera access when it’s not used after the specified time, select “5 MIN”, “15 MIN” or “30 MIN” from the
drop-down list of “Auto Lock Time”, or select “NEVER” to disable this function.
Note: When the camera access is locked after the specified time, to resume camera access, please
enter the password.
18
3.7.2 Time
Set daylight saving time and the current time, and click “Save” to confirm.
Function Description
Time Configuration
Date
Set the current date.
Time
Set the current time.
Daylight Saving Time Configuration
Daylight Saving Time
Specify whether to use daylight saving time (Enable / Disable).
If this function is enabled, set the time period (Start Time / End Time), and adjust the daylight
saving time in hours (Adjust Time).
3.7.3 Server Log
To quickly search the system logs you want by event type, click “Prev. Page” or “Next Page” to find the logs you
want, or check the event type(s) and click “Reload” to start searching.
To clear all system event logs, click “Clear All”.
19
3.7.4 Online
You can check the current online user(s) with respective online information. To refresh the list, click “Reload”.
To allow anonymous login, select “Enable” in “Anonymous Viewer Login”.
To disable image code verification at login, select “No” in “Login with CAPTCHA Image”.
3.7.5 Account
You can create a new account with different user access privilege, or delete or modify an existing account
setting.
How to create a new account
Step1: Click “New”, and fill in the following columns.
Column Description
User Name Set a user name that will be used for camera access. The user name allows up to 16 alphanumeric characters.
Password Set the password that will be used for remote login. The password allows up to 16 alphanumeric characters.
Confirm Password Enter the password again to confirm.
User Level Set the security level of an account to give the permission to control different functions. There are four user levels:
SUPERVISOR, POWER USER, NORMAL USER and GUEST.
Life Time Select how long this account is allowed to stay online (1 MIN / 5 MIN / 10 MIN / 1 HOUR / 1 DAY / INFINITE)
Step2: Then, click “Save” to save your setting and create a new account.
How to modify or delete an existing account
Step1: Select the account you want to modify or delete.
Step2: To modify the account, click “Edit” to change the settings, and click “Save”.
To remove the account, click “Delete”.
Note: It’s not allowed to remove an account when there’s only one account in the account list.
20
3.7.6 Google Maps
This function is used to let you know where the network camera is.
The system will prompt you to apply a Goole Maps Key if your access is denied. Please follow the instructions
below when you’re denied:
Step1: Click “Sign up for a Google Maps key” to enter the application page.
Step2: Check the terms and conditions, and enter the IP address of the network camera. Then, click “Generate
API Key”.
Step3: Copy the generated API key, and click “Update Google Maps Key” on the web browser to paste it.
3.7.7 Maintenance
Firmware Upgrade
This function is used when users need to upgrade the camera for function scalability.
Note: Before using this function, make sure you have the correct upgrade files provided by your
installer or distributor.
Note: The event videos saved in the camera will be removed after firmware upgrade. Make sure you’ve
copied important events to your PC before firmware upgrade.
Step1: Select “ ” to browse to where you save the upgrade files, and select them one by one until all files are
selected (up to four files).
21
Step2: Select “Upgrade” to start system upgrading.
Note: You’ll be prompted to keep current configurations. It’s recommended to keep them, or all
configurations will be restored to default values after upgrade.
Note: It takes a few minutes to finish the upgrade process. Do not disconnect the power during
firmware upgrade, or the upgrade may be failed. The camera will reboot after the upgrade.
System Configuration Backup
This function is used to copy your system configuration to a “System.bin” file.
You may import the same system configuration to another camera, or restore your system configuration when
the camera is reset to default values.
Select “System.bin” in “Firmware Upgrade”, and select “Upgrade” to import the system configuration.
System Reboot
Select “Reboot” to restart your camera if needed.
Player Download
To see the event video clips downloaded to your PC, you need to first install our own video player in your PC.
Select “Free Download” to download the video player, and double click the file to install it.
22
APPENDIX 1 PRODUCT SPECIFICATIONS
AVM328A
▓ Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video Streaming
(Encode Modes, IPS, Resolution)
3 (H.264, MJPEG, MPEG4)
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP,
HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS
Frame Rate 30 FPS
Number of Online Users 10
Security
1. Multiple user access levels with password
2. IP address filtering
3. Digest authentication
Remote Access
1. Internet Explorer on Windows operating system
2. EagleEyes on iPhone, iPad and Android mobile devices
ONVIF Compatible YES
▓ Camera
Image Sensor 1/4" SONY H.R. image sensor
Video Resolution SXGA / HD720P / VGA / QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (IR LED ON)
Shutter Speed 1 / 2 to 1 / 10,000 sec.
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 62.7°(Diagonal)
IR LED 12 units (10 meters)
IR Shifter YES
White Balance ATW
AGC Auto
IRIS Mode AES
POE YES (IEEE 802.3af)
PIR Sensor
Detection Range 76 wide angle with up to 6m long distance at 2m height
(under 30C)
External Alarm I/O
YES
External Audio In / Out YES
Power Source (±10%) 5V / 1A
Operating Temperature 0℃~40℃
▓ Others
Mobile Surveillance iPad / iPhone / Android mobile device
RTC (real-time clock) YES
Motion Detection YES
Digital Pan / Tilt / Zoom YES
Event Notification FTP / Email / SMS
Minimum Web Browsing Requirements
Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
256 MB RAM
AGP graphics card, Direct Draw, 32MB RAM
Windows 7, Vista & XP, DirectX 9.0 or later
Internet Explorer 7.x or later
* The specifications are subject to change without notice.
** Dimensional tolerance: ± 5mm
23
APPENDIX 2 BIT RATE TABLE FOR REFERENCE
The data below is for reference only.
The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the
complexity of your monitoring area, and how often the moving objects show in your monitoring area.
Testing Environment
Place: Office Entrance
Network translation: H.264
Camera type: Megapixel camera
Static: No one coming in and out Dynamic: One or two people coming in and out
Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps
SXGA Best FULL 3253 3216
High 2375 2160
Normal 1571 1266
Basic 1465 873
VGA Best 2010 1261
High 1042 1034
Normal 685 572
Basic 457 350
QVGA Best 646 366
High 482 350
Normal 302 286
Basic 168 161
SXGA Best 1/4 1163 1076
High 989 715
Normal 855 534
Basic 719 443
VGA Best 789 571
High 451 447
Normal 349 237
Basic 217 165
QVGA Best 269 147
High 182 131
Normal 164 113
Basic 97 71
24
Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps
SXGA Best 1/15 581 374
High 405 342
Normal 487 248
Basic 337 141
VGA Best 358 79
High 201 63
Normal 180 28
Basic 92 15
QVGA Best 111 84
High 99 68
Normal 97 54
Basic 58 42
25
APPENDIX 3 POE CONNECTION
This device supports PoE (Power-over-Ethernet), developed by the IEEE802.3af task force, and power can be
supplied over the same network (Ethernet) cable as the one used to connect to Internet. No power cable is needed.
Below shows two examples of POE application for reference.
When your router / hub supports POE connection
When your router / hub doesn’t support POE connection (An optional POE connected required)
26
APPENDIX 4 API ID APPLICATION FOR SMS MESSAGING
To allow the camera automatically sending a text message when an event happens, you need to
apply an API ID from Clickatell, one mobile messaging company, first.
Note: The SMS messaging is not totally free. You will be charged starting from the 11th
message.
Please follow the steps below for application.
Step1: Go to http://www.clickatell.com/login.php. In “New Customers”, select “Clickatell Central
(API)” from the drop-down list.
Step2: Fill in your information to create an account, and click “CONTINUE”.
Note: Note down the user name and password, and the mobile phone number you
specified here for SMS notification setting later.
Step2: When the account is created, the system will automatically send an Email to your specified
Email address and ask you to activate your account.
27
Click the link in the Email to complete account activation, and enter the login page as follows.
Enter the password you set, and click “Login”.
Step3: Enter the mobile phone number (including your country code) you want the text message to
be sent, and click “SEND ACTIVATION CODE”. The system will send an activation code to
that number for verification.
Check if you receive a text message from Clickatell.
Step4: Go back to Clickatell, and click the tab “Manage my Products”.
Then, select “HTTP” from the drop-down list “My Connections”.
Step5: In “Add HTTP API”, enter a descriptive name for this service, and make sure the dial prefix is
correct and callback type is “HTTP GET”. Then, click “Submit”.
Step5: You will get an API ID as follows.
Note: Note down the API ID for SMS notification setting later.
28
APPENDIX 5 Q&A
For more details about EagleEyes Q&A, please visit our official website: www.eagleeyescctv.com/supp_QnA.aspx.
Question Answer
I can connect to this camera in my house
or office where it’s installed with wireless
network.
But when I leave my house or office, I
can’t connect to it from my mobile phone
(with 3G network), or other PC
(connected to Internet). Why?
You didn’t configure this camera to Internet, but only in LAN.
Please follow the steps in the advanced network setup guide to
complete network configurations, or it’s recommended for you to check
with your local installer or reseller for this service because it’s usually
hard for a person who doesn’t have network knowledge to set network
configurations.
My live images are not fluent. Why?
Image fluency could be affected by the local network upload
bandwidth, router efficiency, client network download bandwidth,
complexity of live view, and more.
(Recommended) To have the best image fluency, select QVGA; to
have the best image quality, select “HD1080P” or “SXVGA” based on
the model you have; to have normal image fluency and quality, select
“VGA”.
My image is vague. Why? The camera might lose its focus. Please rotate the lens to adjust.
The live video keeps flickering. Why?
Please try adjusting the power line frequency to “60 Hz” or “50 Hz” for
the camera.
For iPhone users, access the camera, and select “ ” on the top
right corner to enter IPCAM Configuration page. Then, go to “Advance
Setup” “Camera” to change setting.
For access from Internet Explorer, log into the camera, and select
“Config.” “Camera” “Video”.
29
APPENDIX 6 RECORDING TIME TABLE
Below shows the estimated total recording time for each recording resolution.
The recording time per resolution is the average value collected from the both alarm trigger conditions indicated in
“Testing Environment”, and is for reference only.
The time may vary depending on the resolution, image quality & frame rate you choose, the complexity of your
monitoring area, and how often the moving objects show in your monitoring area.
Testing Environment
Place: Office
Monitoring area: 1.5 meters away from the camera
Alarm trigger conditions:
(1) One person walks by the monitoring area and leaves immediately.
(2) Two persons walk by the monitoring area. One goes away immediately, and the other one stays a while and
goes away.
Recording Resolution SXGA VGA QVGA
Recording time (second) 25 115 211
Loading...
