Dual Card Reader Hub
USB-C™ / USB 3.0, OTG
Quick Installation Guide
DA-70886
2
The DIGITUS® Dual Card Reader with an integrated SUSB hub (OTG) can either be connected to your smartphone, tablet or notebook. This allows you to access inserted storage media such as USB sticks, SD or MicroSD memory cards. You can connect the device via the hub’s USB A (USB 3.0) or the USB-C™ plug. The USB hub and the memory card reader can be used simultaneously. This allows you to move or copy files between both ports. Thanks to Plug and Play, there is no need for any driver or app installations. Perfect e.g. to back up your holiday pictures directly on-site, eliminating the need for a notebook.
Note: Only one card reader can be used at a time. Smartphones / tablets must support OTG.
3
Structure Diagram
1
USB 3.0 connections
2
SD/ Micro SD slots
3
USB Type-C™ connection
4
Features
1. Direct data backup from your smartphone / tablet without the need for a buffer.
2. USB port and card reader can be used in parallel.
3. It is possible to copy and move between USB A device and memory card.
4. Can connect to your notebook, tablet or smartphone via USB-C™ or USB A.
5. Plug and Play - no driver installation required
6. Perfect for on the go.
7. Compact aluminum housing with protective caps for the ports.
8. USB-C™ port data transfer rate: 480 Mbps (USB 2.0)
9. USB 3.0 port data transfer rate: 5 Gpbs SuperSpeed (USB 3.0)
10. Card reader data transfer rate: 480 Mbps (USB 2.0)
11. Supports SD / MicroSD memory cards up to 2 TB
12. Connection 1: USB 3.0 (USB A)
13. Connection 2: USB-C™ USB 2.0
14. Supported operating systems: Windows 10/8/7, macOS® 10.2.8 or higher, iPadOS®, Android with OTG support
5
Operating System Support
macOS® 10.2.8 or higher, iPadOS®, Android with OTG Windows 7/8/10 32 and 64 bit and future release
Application Examples
6
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the shipping content. If the Declaration of Conformity is missing, you can request it by post under the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH Auf dem Schüffel 3 58513 Lüdenscheid Germany
