Digital Watchdog x39, DWC-PTZ37X, DWC-PTZ37XAL, DWC-PTZ37XFM, PTZ39X User Manual

Wall(Ceiling) Mount Camera
Analog PTZ Outdoor
Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference.
User’s Manual
x39
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO
USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
:
To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain or moisture.
1. Be sure to use only the standard adapter that is specified in the specification sheet. Using any other adapter could cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or damage to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat generation or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
5. When installing the camera, fasten it securely and firmly. A falling camera may cause personal injury.
6. Do not place conductive objects (e.g. screw drivers, coins, metal things, etc.) or containers filled with water on top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately disconnect the power source and contact the service center. Continued use in such a condition may cause fire or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way.
10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
11. When ambient temperature is below the freezing point, the dome cover will frost and the power. will fail. In this case, install or reboot the system, and the frost will disappear 3 hours after turning on the power. [Note that the lowest guaranteed operating temperature is -45°C (-49°F) without wind.]
WARNING
WARNING
2
1. Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to excessive vibration or magnetic interference.
2. Do not install in a location subject to high temperature (over 50°C), low temperature (below -10°C), or high humidity. Doing so may cause fire or electric shock.
3. If you want to relocate the already installed product, be sure to turn o the power and then move or reinstall it.
4. Remove the power plug from the outlet when there is a lightning. Neglecting to do so may cause fire or damage to the product.
5. Keep out of direct sunlight and heat radiation sources. It may cause fire.
6. Install it in a place with good ventilation.
7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the CCD image sensor.
8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
9. The Main plug used to disconnect the device shall stay readily operable at any time.
CAUTION
3
WARNING
1. Read these instructions.
2. Keep these instructions.
3. Regard all warnings.
4. Follow all instructions.
5. Do not use this camera near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the camera.
13. Unplug this camera when a cart is used. Use caution when moving the
cart that contains the camera to avoid injuries that can result from the camera falling over.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has spilled on the camera, objects have fallen into the camera, the camera has been exposed to rain or moisture, the camera does not operate normally, or the camera has dropped.
Safety Instructions
4
Contents
6 7 8
Features Product & Accessories Parts Name & Function
24Safety Information
Important Safety Instructions
INTRODUCTION
9 11 15
DIP Switch Setup Cabling Installation
INSTALLATION
21 22 23 28 29 30 31 32 33 35 37 39 40 41 43 45 46 48 49 51
Check Points before Operation Reserved Presets Moving Around the OSD Menu Functions OSD Display of Main Screen General Rules of Key Operation for Menu OSD - ROOT MENU & SYSTEM INFORMATION OSD - DISPLAY SETUP > CAMERA ID OSD - DISPLAY SETUP > PRIVACY ZONE OSD - MOTION SETUP OSD - FUNCTION SETUP > PRESET SETUP OSD - FUNCTION SETUP > SCAN SETUP OSD - FUNCTION SETUP > PATTERN SETUP OSD - FUNCTION SETUP > GROUP SETUP OSD - FUNCTION SETUP > SCHEDULE SETUP OSD - CAMERA SETUP > WB SETUP OSD - CAMERA SETUP > AE SETUP OSD - CAMERA SETUP > SPECIAL OSD - SYSTEM SETUP OSD - SYSTEM INITIALIZE
OSD MENU
52 53 54 55 56
Dimension Specification Troubleshooting Warranty Information & Limits and Exclusions Appendix I Camera IDs
SPECIFICATIONS
x39
5
Features
CAMERA SPECIFICATIONS
• CCD Sensor: EX-View HADTM CCD
Zoom Magnification: ×39 Optical, ×12 Digital Zoom
• Wide Dynamic Range
Day & Night Function: ICR (IR Cut filter Removal)
• Various Focus Mode: Auto Focus/Manual Focus/
Semi-Auto Focus
Independent or Global Camera Settings for Each Preset Location
POWERFUL PAN/TILT FUNCTIONS
• Maximum 360°/SEC High Speed Pan/Tilt Motion
• Vector Drive Technology: Pan/Tilt Motions are
accomplished in the shortest path. As a result, time to target view is reduced dramatically and the video on the monitor is very natural to watch.
• Ultra low speed (0.05°/SEC) enables operator to
locate camera to desired target view with accuracy and ease.
Zoom-Proportional Pan/Tilt speed helps operator to move the camera easily.
PRESET, PATTERN, SCAN, GROUP, PRIVACY ZONE, SCHEDULE, AND MORE...
Maximum 127 presets are assignable. Each of them have independent characteristics, such as white balance, auto exposure, label, alarm input/output, etc.
• Maximum 8 set of scans can be stored. This
enables user to move camera repetitively between two preset positions with designated speed.
Maximum 4 patterns can be recorded and played back. This enables the camera to follow any trajectory operated by the joystick as closely as possible.
• Maximum 8 set of group actions can be stored.
This enables the camera to move repetitively between dierent combination of preset, pattern, or scan. A group is composed of maximum 20 entities of preset, pattern, or scan.
Maximum 8 privacy zones can be set up to protect
privacy of other people.
7 rules of schedule can be assigned by day and time. Appropriate actions (such as home, preset, scan, pattern, and group) can be defined for each rule. Also, it is possible to use weekday and all days to simplify the rule.
PTZ (PAN/TILT/ZOOM) CONTROL
• With RS485 communication, a maximum of 255
cameras can be controlled at the same time.
Auto, Pelco-D, Pelco-P, Samsung, Panasonic, Kalatel, AD(American Dynamics) protocol can be selected as a control protocol in the current version of firmware.
OSD(ON-SCREEN DISPLAY) MENU
• OSD Menu is provided to display the status of
camera and to configure the functions interactively.
Camera ID, Pan/Tilt/Zoom/Direction
, Alarm Input/ Output, Date/Time, Current Temperature, and Preset are displayed on screen.
• Each display item can be turned on or off
independently.
ALARM I/O FUNCTIONS
• 8 Alarm sensor inputs and 4 relay output are
available.
To reject external electric noise and shock perfectly,
alarm sensor input is decoupled with photo coupler.
The signal range of sensor input is from DC 5.0 to
12.0 Volts to adopt various applications.
If an external sensor is activated, camera can be set to move to the corresponding preset position.
Relay outputs can be assigned to work with a certain
Preset.
RESERVED PRESETS FOR SPECIAL PURPOSE
• Most of camera settings are directly changed by
calling reserved presets, not entering into OSD Menu. For more information, refer to “Reserved Presets”(page 18) of this manual.
6
Product & Accessories
Housing Safety
Cable Hanger
Waterproof Tape
Hole Template
Hexagonal Wrench
User’s Manual
Anchor Bolt (4pcs)
Safety Wire
Product
Accessories
Additional Tools for Installation:
1. AC Power Adapter + Cable
2. Dual Cable for RS485 (PTZ Remote Control)
3. At Least Two (2) Terminal Boxes (Matching the camera’s RS-485 Terminal and your Joystick Controller DVR, Alarm Sensor, and Audio In and Out)
4. Drill
5. Screw Driver
1. PTZ Mechanism
2. Sunshield & Upper Housing
3. Mounting Box
4. Inner Box Switches
5. Dome Cover
1
3
52
4
7
Part Name & Function
Wall/Pendant Mount Bracket
The Wall/Pendant Mount Bracket is used to secure the camera onto a wall or ceiling. It includes a built-in junction box. Depending on the camera’s model, the Junction box may include the inner box. The junction box accommodates the inner box.
Sunshield & Upper Housing
PTZ Mechanism
Dome Cover
Inner Box
Wall Mount Bracket
1
1
2
3
4
Inner Box
The inner box includes the dip switches and terminal locks. See page 9-10 for further information on what are dip switches and how to set them up. The inner box also includes the camera’s power supply outlet, and video, communication, and alarm input/output.
Sunshield & Upper Housing
The Sunshield protects the PTZ mechanism from the sun rays and rain fall. The upper housing, which is attached to the sunshield, accommodates the PTZ mechanism. The Upper housing is also connected to both the mounting brackets and the dome cover. The upper housing has a built-in fan and heater to remove moisture on the bubble dome.
Dome Cover
Do not detach protection vinyl from dome cover until the installation process is completed. The vinyl will protect the dome cover from scratches and dust.
4
3
2
8
DIP Switch Setup
The DIP Switch is a control panel that is setup to a specific protocol so the camera can communicate with other devices, such as: Joystick Controller, DVR, PTZ Remote Controlling, Alarm Sensor, etc. Before installing the camera, you should set the DIP Switch to configure the Camera ID and Communication Protocol.
Inner Box
1. Communication Protocol Setup
Congure the appropriate protocol using the DIP switch combination.
- If you set the protocol as AUTO protocol (factory default), camera
will automatically recognize the type of protocol being used; however, this will not recognize the AD protocol.
-
If you want to control the camera using the DVR or
system
keyboard, the protocol set in the camera’s inner box must be identical to the camera protocol setup in the DVR. Otherwise, you will not be able to control the camera. See page ____ for further information.
- If you change the camera protocol by adjusting the DIP switch, the change will be eective after you reboot the camera.
Protocol Setup Baud Rate Setup
RS-485
Termination Resistor
ON
8J
21 3 4 5 6 7 8
ON
8J
21 3 4 5 6 7 8
AUTO- Factory Default
1
ON
8J
21 3 4 5 6 7 8
PELCO-D
2
ON
8J
21 3 4 5 6 7 8
PELCO-P
3
ON
8J
21 3 4 5 6 7 8
SAMSUNG
4
ON
8J
21 3 4 5 6 7 8
PANASONIC
5
ON
8J
21 3 4 5 6 7 8
GE(Kalatel)
6
ON
8J
21 3 4 5 6 7 8
AD (American Dynamics)
7
9
DIP Switch Setup
2. Communication Baud Rate Setup
Select the appropriate Baud Rate with DIP switch combination. As factory Default, the camera’s Baud Rate is set to 2400 BPS. See page ____ for further information.
4. Camera ID Setup
ID number of camera is set using binary number.
The example is shown below.
Inner Box
3. RS-485 Termination Resistor
- The last Pin on the top line on the right, is used to turn ON/OFF RS-485 termination. Normally, if you are connecting only one PTZ camera connected, keep the Switch on the OFF state. This will allow the camera to communicate with the controller. By default, the RS-485 Termination Resistor is OFF.
- When you have a long daisy chain style connection, turn ON this termination switch for the camera furthest from the controller.
ON
8J
21 3 4 5 6 7 8
2400 BPS
1
ON
8J
21 3 4 5 6 7 8
4800 BPS
2
ON
8J
21 3 4 5 6 7 8
9600 BPS - Factory Default
3
ON
8J
21 3 4 5 6 7 8
19200 BPS
4
38400 BPS
5
ON
8J
21 3 4 5 6 7 8
Pin 1 2 3 4 5 6 7 8
1 2 4 8 16 32 64 128ID Value
ex) ID=5
ex) ID=10ONOFF
OFFONON
OFF
OFFONOFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
-
If you want to control a certain camera, you must match the Camera ID with CAM ID, setting of DVR or controller.
- The range of ID is 0~255. Factory default of Camera ID is 1.
- For a full list of all the ID numbers and their corresponding Pin Switches, please see Appendix I
ON
8J
21 3 4 5 6 7 8
10
Cabling
RS-485
(Keyboard Controller/DVR)
RS-485 Communication (DVR/Keyboard)
Inner Box
Keyboard Controller/DVR
RS-485
#1 #2 #n
~
RS-485
Before you can begin mounting
the PTZ39X, the cabling must be completed.
1. Connect RS-485 cable to terminal box matching the camera’s Inner box RS-485 Terminals. Connect the other end of the cable to a terminal box matching the DVR or keyboard controller RS-485 Terminals.
2. Make sure not to ip negative and positive parts of the cable from one terminal box to the other and connect each terminal box to its matching device.
3. To control multiple cameras at the same time, the RS-485 communication lines are connected in parallel as here.
1
2
3
11
Cabling
Power Connection Requirements
Please check the voltage and the current capacity of the rated power carefully.
Rate Power
Current
Consumption
Input
Voltage Range
AC 24V 2.5AAC 19V ~ 29V
Power
2
~
~
1. Connect AC power adapter to the camera’s inner box.
2. Make sure to connect positive and negative in their corresponding locations.
+ -G
1
2
12
Video Output
1. Connect BNC coaxial cable to camera’s inner box.
2. Connect the other end of the BNC Coaxial cable to a DVR or Monitor.
Video Output
BNC Video
Cabling
1
2
13
N.C
Activation
Activation
N.O
In 2
COM
In 2
COM
In 2
COM
In 2
COM
Alarm Output
Alarm Input
Inner Box
Alarm Input/Sensor
It is noted that short circuit between GND and Input Pin means alarm activation.
Sensor Input
To use alarm input, select the type of sensor you wish to use. The sensor types are “Normal Open” and “Normal Close.” If sensor type is not selected properly, the alarm can be activated reversely.
Alarm Output
The 4 alarm outputs are the relay contact type. Therefore, you do not have to worry about the polarity, AC/DC, and isolations between channels. However, care must be taken for the power capacity of the relay contact written above.
COM
In 1
COM
In 1
In 8
Alarm Output
ALARM INPUT
GND1
2 3 4 5 6 7 8
OUT1
OUT2
OUT3
OUT4
OUT1
OUT2
OUT3
OUT4
Out Out
ALARM INPUT
GND1
2 3 4 5 6 7 8
Cabling
14
Installation
1. Unscrew the top cover of the Mounting Box.
2. Remove the protective plastic to expose the four (4) screw holes.
3. Using the Mounting Box or the Mounting Template, locate on the wall/ ceiling the locations for the four (4) bolts.
Note: the Anchor bolts included in with the camera kit are for concrete. Be sure to
consult with your installer what bolts are necessary depending on the wall/ ceiling surface.
4. Using a drill, drill four (4) holes for the bolts. Mount the Mounting box on the wall/ceiling.
Note: If your camera model includes the inner box inside the Mounting Box,
make sure the cables remain intact during installation.
1
2
3
4
15
5. Remove the PTZ mechanism from the upper housing. To detach camera mechanism, press down and hold both black handles on the camera mechanism. Pull them up to detach the camera.
6. Pass the cable connector from the inner box through the upper housing pipe.
7. If inner box is located in the upper housing, connect the desired bracket and run the wires through the bracket.
Installation
5
7
6
16
Installation
8. For outdoor installations, wind the weatherproof tape around the pipe of the upper housing.
9. Hook the safety wire to the safety hook on the upper housing and using the safety hanger, secure it to the mounting box/bracket.
10. Screw in the upper housing to the Mounting box/bracket. Turn the upper housing at least seven (7) times to secure a tight connection.
11. Plug cable connector from the inner box to the upper housing.
9
8
10
11
17
Installation
12. Snap camera back into the upper housing. Make sure the two black handles marked ‘A’ and ‘B’ correspond with the ‘A’ and ‘B’ markings on the sides of the upper housing.
Note: Before snapping the camera back into the housing, make sure the cables are
properly secured.
13. Remove protecting gear from the camera’s lens
14. Connect the cover dome to the upper housing by securing the safety wire.
12
13
14
14
18
Installation
Connect camera to power and make sure it is operating properly.
15. Camera will show Initializing Setup screen.
Note: Please record the information on this screen, especially the Protocol (If
set to Auto, it is probably Pelco-D), Baud Rate, and Camera’s Address.
16. When initializing System is complete, screen will display camera’s video.
15
16
19
Installation
17. If no adjustments need to be made to the wiring, place the dome cover on the upper housing.
18. Secure dome to camera by fastening the screws on the dome in the order shown below.
Note: This order of fastening the screws guarantees optimal sealing and
protects the camera mechanism from the elements.
17
18
20
Check Points Before Operation
1. Before you can start controlling your PTZ39X camera, you need to make sure the Camera’s ID, Baud Rate and Protocol are setup in the DVR or Joystick Controller.
2. In the DVR, go to Menu --> Device --> PTZ
3. Setup the Protocol, Baud Rate and Address to match the information collected from the Initializing System page.
Note: If you do not have the information from the Initializing System screen, go to the PTZ39X’s
OSD menu, System Information. Please see page ____ for further information on how to navigate in the OSD menu using a DVR’s mouse.
4. Since the operation method can be dierent for each controller available, refer to the manual for your controller if camera can not be controlled properly
2
3
21
What is a Preset?
A Preset is a unique command users can assign the camera.
The PTZ39X supports up to 255 different Presets.
Users can use 127 Presets to setup dierent positions for the camera Users can setup 1~128 Presets for dierent camera positions, except for preset 95. Preset 95 is reserved for starting the camera’s OSD menu. For a complete list of all the reserved presets, see below.
Reserved Preset
Some preset numbers are reserved to special functions.
Preset key + 95: Enters into OSD menu Preset key + 131~134: Runs pattern function 1 ~ 4 Preset key + 141~148: Runs scan function 1 ~ 8 Preset key + 151~158: Runs group function 1 ~ 8 Preset key + 161~164: Sets relay 1~ 4 output to OFF Set key + 161~164: Sets relay 1~ 4 output to ON Preset key + 165: Sets auto calibration to ON Preset key + 166: Sets auto calibration to OFF Preset key + 167: Zoom proportional jog ON Set key + 167: Zoom proportional jog OFF Preset key + 170: Sets camera BLC mode to OFF Preset key + 171: Sets camera BLC mode to HIGH Preset key + 174: Sets camera focus mode to AUTO Preset key + 175: Sets camera focus mode to MANUAL Preset key + 176: Sets camera focus mode to SEMI-AUTO Preset key + 177: Sets day & night mode to AUTO Preset key + 178: Sets day & night mode to NIGHT Preset key + 179: Sets day & night mode to DAY Preset key + 190: Sets OSD display mode to AUTO (except privacy mask) Preset key + 191: Sets OSD display mode to OFF (except privacy mask) Preset key + 192: Sets OSD display mode to ON (except privacy mask) Preset key + 193: Sets all privacy mask display to OFF Preset key + 194: Sets all privacy mask display to ON Preset key + 200: Sets digital zoom to ON Preset key + 201: Sets digital zoom to OFF
1
2
Reserved Presets
Auto Calibration
If the camera is continuously subjected to very high temperatures (over 50°C or 122°F) for a long period, the camera can lose focus and produce blurry images. In this case, it is recommended to turn on AUTO CALIBRATION by running preset 165.
If you execute AUTO CALIBRATION, the camera will calibrate its focus for 10 seconds every 24 hours. To turn OFF this function, please run preset 166.
Auto Calibrate
22
Start OSD Menu
Using the OSD menu, preset, pattern, scan, group, and alarm input function can be configured for each application.
How to Move Around the OSD Menu
1. Select Full Screen view on the selected PTZ camera
2. Right-Click the screen & Select ‘PTZ’
3. Right-Click the screen again, & select ‘Preset’
4. Enter 95 to access the OSD menu
2
3
4
23
5. Using the mouse, click on the are of the screen labeled: UP: to scroll up the menu DOWN: to scroll down the menu Left: Vertically move from one edit tab to the one to its left RIGHT: Vertically move from one edit tab to the one to its right.
6. Using the mouse’s wheel, move: Forward: to save changes and enter from the Root menu to a sub-menu Backwards: to cancel changes and exit a sub-menu back to the Root menu
How to Move Around the OSD Menu
Le
Up
Down
Right
5
6
24
To move to a sub-menu
1. Click on the top/bottom of the screen to select the desired sub-menu from the list.
2. Once you have selected the sub-menu you want to enter, scroll the mouse’s wheel forward
To exit a sub-menu
3. When you have completed all desired modifications, scroll the mouse’s wheel backwards to return to the Root menu.
How to Move Around the OSD Menu
3
2
1
Note: Different controllers may have different instructions.
Please consult your controller’s manual for safe handling of your controller.
25
To move between input tabs
1. Using previous instructions, select the sub-menu and category you wish to modify
2. Scroll the mouse’s wheel forward to enter edit mode
3. The system will show it is in edit mode by highlighting the first tab
How to Move Around the OSD Menu
2
1
3
26
4. Click on the top/bottom of the screen to increase/reduce the values of the data you are modifying
5. When you have completed modifying the first data tab, click on the left side of the screen to move to the next data tab.
6. The system will show it is in edit mode by highlighting the second tab Repeat as necessary
7. When editing is complete, scroll the mouse’s wheel forward to save all changes, or backwards to cancel all changes.
How to Move Around the OSD Menu
4
5
6
7
27
28
Functions
1. Set Preset Method 1) Use keyboard controller:
Refer to your system keyboard manual. Method 2) Use OSD menu.
2. Run Preset
Method 1) Use keyboard controller:
Preset key + Number key (1~128)
3. Delete Preset
To delete preset, use OSD menu.
Preset
Maximum 127 positions can be stored as preset positions. The preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu.
See section “ROOT MENU > FUNCTION SETUP > PRESET SETUP.”
1
Scan
The scan function allows camera to move repeatedly between 2 preset positions.
See section “ROOT MENU > FUNCTION SETUP > SCAN SETUP.”
2
1. Set Scan
To set scan, use OSD menu.
2. Run Scan
Method 1)
Scan key + Scan no. (1~8) + Enter key
Ex. Run scan 2 = Scan key + [2] + Enter key Method 2) Preset key + [Scan no. (1~8) + 140]
Ex. Run scan 2 = Preset key + [142]
3. Delete Scan
To delete scan, use OSD menu.
Pattern
Pattern function is where the camera memorizes a path created by a joystick controller and revives the path exactly as it memorized for an assigned time.
See section “ROOT MENU > FUNCTION SETUP > PATTERN SETUP.”
3
1. Set Pattern
To set pattern, use OSD menu.
2. Run Pattern
Method 1)
Pattern key + Patter no. (1~4) + Enter key
Ex. Run pattern 2 = Pattern key + [2] + Enter key Method 2) Preset key + [Pattern no. (1~4) + 130]
Ex. Run pattern 2 = Preset key + [132]
3. Delete Pattern
To delete pattern, use OSD menu.
Group
The group function allows you to run sequence of presets,
pattern, and/or scans.
See section “ROOT MENU > FUNCTION SETUP > GROUP SETUP.”
4
Schedule
The schedule function allows you to run an appropriate function like preset, scan, group, pattern, home, or move at a designated day and time.
See section “ROOT MENU > FUNCTION SETUP > SCHEDULE
SETUP.”
5
When the pattern is saved/executed, the pan/tilt is operated with “AUTO FLIP-OFF.”
1. Set Group
To set group, use OSD menu.
2. Run Group
Method 1) Group key + Group no. (1~8) + Enter key Ex. Run group 2 = Group key + [2] + Enter key
Method 2) Preset key + [Group no. (1~8) + 150] Ex. Run group 2 = Preset key + [152]
3. Delete Group
To delete group, use OSD menu.
OSD Display of Main Screen
PATTERN
1
PRESET LABEL CAMERA ID_TOP CAMERA ID_TOP
CAMERA ID_BOT CAMERA ID_BOT
23/MAR/2009 24 00 00 CAM 1
O 1234
I 12345678
359/180/x100/SE
F
Preset Label
- The label stored for a specific preset.
- See section “ROOT MENU > FUNCTION SETUP > PRESET SETUP > LABEL.”
Camera ID_Top
- If CAMERA ID is set to TOP, Camera ID will display in this area.
- See section “ROOT MENU > DISPLAY SETUP > CAMERA ID.”
Camera ID_Bottom
- If CAMERA ID is set to BOT, Camera ID will display in this area.
- See section “ROOT MENU > DISPLAY SETUP > CAMERA ID.”
Date / Time
- Shows the current date and time.
- See section “ROOT MENU > SYSTEM SETUP > DATE/TIME SETUP.”
Image Flip
- Shows images that are currently reversed by the auto flip function.
- See section “ROOT MENU > CAMERA SETUP > IMAGE FLIP.”
Address
- Shows the current RS-485 address information.
-
See section “ROOT MENU > SYSTEM INFORMATION.”
Action Title
The following are possible action titles and their descriptions.
Action Title Description
SET PRESET 123
PRESET 123 PATTERN 9
SCN 1/PRESET 123 RANGE OVER
Store preset 123.
It reached preset 123. The camera is running pattern 9.
The camera is running scan 1. The action received is not within the
range supported.
UNDEFINED The action received is not defined.
Alarm I/O Information
- This information shows the current status of alarm input and output.
- “I” means input, and “O” means output.
- If the alarm input is ON, it will show the number of the input. If an input is OFF, “-” will be displayed. “O:1 - - -” means output 1 is ON and other outputs are OFF.
- Ex. When input 2 is ON and output 1 is ON, OSD will display as below.
Compass Direction
- Shows the current compass direction of the camera.
- The direction is shown as N(North), S(South), E(East), W(West), NE(Northeast), NW(Northwest), SE(Southeast), SW(Southwest).
- See section “ROOT MENU > SYSTEM SETUP > SET NORTH DIRECTION.”
Zoom Magnification
Shows the current zoom magnification.
Tilt / Pan Angle in Degree
Shows the current tilt (0 ~ 180) and pan(0 ~ 359) angle.
1
2
3
4
5
6
7
8
9
111012
23/MAR/2009 24 00 00
CAM
1
O 1---
I -2------
359/180/x100/SE
Date / Time
Action Title
Preset Label
Camera ID_Top
Camera ID_Bottom
1
2
3
Compass Direction
Zoom Magnification
Tilt Angle in Degree
Pan Angle in Degree
Alarm I/O Information
5
6
Image Flip
Address
4
8
9
10
11
12
7
29
General Rules of Key Operation for Menu
30
The menu items surrounded with < > always has a sub menu.
Move among the different selections in the menu using the joystick in the Up/Down or Left/Right direction.
To go into the sub-menu from all menu level, press Near or Enter key.
To go back a menu, press Far key.
To change a value of an item, move the joystick in the Up/Down direction.
Press Near or Enter key to save values and press Far key to cancel values.
1
2
3
5
6
4
6
Press Near/Enter or Far Key
>
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON AUTO AUTO AUTO AUTO ON
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON AUTO AUTO AUTO AUTO ON
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
OFF AUTO AUTO AUTO AUTO ON
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION> <DISPLAY SETUP> <MOTION SETUP> <FUNCTION SETUP> <CAMERA SETUP> <SYSTEM SETUP> <SYSTEM INITIALIZE>
EXIT
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION> <DISPLAY SETUP> <MOTION SETUP> <FUNCTION SETUP> <CAMERA SETUP> <SYSTEM SETUP> <SYSTEM INITIALIZE>
EXIT
Joystick Down
Joystick Down
Joystick
Up
Joystick
Up
>
>
Press Near/Enter Key
Press
Far Key
>
>
Press Near/Enter Key
Press Far Key
>
>
>
>
5
1
3
4
2
OSD
-
ROOT MENU & SYSTEM INFORMATION
31
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION> <DISPLAY SETUP> <MOTION SETUP> <FUNCTION SETUP> <CAMERA SETUP> <SYSTEM SETUP> <SYSTEM INITIALIZE>
EXIT
FIRMWARE VER
Shows the current firmware version.
COLOR SYSTEM
Shows the current analog video system.
PROTOCOL
Shows the current PTZ control protocol.
BAUD RATE
Shows the current baud rate of the PTZ control.
ADDRESS
Shows the current camera ID of the PTZ control.
<SYSTEM INFORAMTION>
Shows information and current system configuration.
<DISPLAY SETUP>
Enable/Disable OSD display on main screen.
<MOTION SETUP>
Configures motion related settings.
<FUNCTION SETUP>
Configures various functions such as preset, scan, pattern, group, and schedule.
<CAMERA SETUP>
Configures camera related functions and data.
<SYSTEM SETUP>
Configures the basic system setup.
<SYSTEM INITIALIZE>
Initializes system configuration and sets all data to factory default configuration.
EXIT
Exit the OSD setting.
SYSTEM INFORMATION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FIRMWARE VER COLOR SYSTEM PROTOCOL BAUD RATE ADDRESS
BACK EXIT
1
.0
NTSC AUTO 9600
1
1
1
ROOT MENU
1
SYSTEM INFORMATION
1
OSD
-
DISPLAY SETUP > CAMERA ID
32
5
1
2
4
3
> > >>
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ADDRESS CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON BOT ON ON ON ON ON
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ADDRESS CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON BOT ON ON ON ON ON
Press Near/Enter Key
Press Near/Enter Key
Press Near/Enter Key
Joystick Right
DISPLAY SETUP
This menu defines what is displayed on the OSD of the main screen. If an item is se as AUTO, the item is displayed only when it is changed.
ADDRESS
CAMERA ID
Select the camera ID location. Refer to “OSD Display of Main Screen.”
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
Starts Privacy Zone Mask Setup Menu.
ON / OFF
BOT / TOP / OFF
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF
1
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ADDRESS CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON
BOT
ON ON ON ON ON
CAMERA ID
- - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - -
OK CANCEL
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
CAMERA ID
- - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - -
OK CANCEL
CAMERA ID
- - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - -
OK CANCEL
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
AAAAAAAAAAAAAAAAAAAAAAAA BBBBBBBBBBBBBBBBBBBBBBBB
CAMERA ID - Alphabet Input
- Set the Camera ID to display on top (TOP) or bottom (BOT). Give the Camera ID a unique name. The menu will appear when TOP or BOT is selected.
- Maximum 48 characters, including space, are allowed.
3
CAMERA ID - Complete Editing
When you complete the camera ID editing, move the cursor to OK and press Near key to save the completed camera ID. To abort the current change, move the cursor to CANCEL and press the Near key.
4
a
b
c
d
Current Cursor Position: In the CAMERA ID menu, a black box functions as a cursor. As soon as a character is selected, cursor moves to the next digit.
Selecting Alphabet: Move the joystick Up/Down/Left/Right to the appropriate character from the character set you wish to select. To choose the character, press the Near or Enter key.
Space: If you want to use blank, choose the space character. Backspace:
If you want to delete a character in front, use
backspace character.
d
a
b
c
OSD
-
DISPLAY SETUP > PRIVACY ZONE
33
5
1
2
4
3
DISPLAY SETUP
See the previous page.
1 ~ 12
ON / OFF
CANCEL / OK
<COLOR> / MOSAIC 1 ~ 4
EDIT MASK - Move to Target Position
Move camera to the area you wish to mask. Then, the menu to adjust the mask size will be displayed.
If the tilt angle is located in the range between 0° to 90°, you can not set up privacy zone mask.
If a tilt angle over 90° (image flipped region) is designated, camera will automatically move to that position by moving the pan angle 180° and then adjusting the tilt angle as necessary.
3
PRIVACY ZONE
Selects area in image to mask.
MASK NO.
Selects mask number. If the selected mask has already been saved, camera moves as it was set. Otherwise, UNDEFINED will be displayed under MASK NO.
DISPLAY
Sets the camera to display or hide the masks on images.
CLEAR MASK
Deletes data in the selected mask no.
STYLE
Sets the style of the mask. See the next page.
Move Camera to Area to Mask, Press Near/Enter Key
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
<
EDIT MASK>
BACK EXIT
1
UNDEFINED
EDIT MASK 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION [ENTER : SELECT]
0/0/x1/E
> > >>
Select <EDIT MASK>, Press Near/Enter Key
EDIT MASK 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ADJUST MASK WIDTH] [ ADJUST MASK HEIGHT] [ENTER : SELECT]
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
<
EDIT MASK>
DISPLAY CLEAR STYLE
BACK EXIT
1
ON CANCEL
<
COLOR>
Press Near/Enter Key
Press Near Key to Save
1
EDIT MASK - Adjust Mask Size
Adjust mask size. Use joystick or arrow buttons to adjust mask size.
- Move Joystick Left/Right( ): Adjust Mask Width.
- Move Joystick Up/Down( ): Adjust Mask Height.
To hide a certain zone completely regardless of high speed pan/ tilt motions, it is recommended that the size of mask must be 20% bigger than original target size.
It is noted that during pan/tilt control like jog action, the object behind the privacy mask can be disclosed in a short period of time.
4
5
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ADDRESS CAMERA ID PTZ INFORMATION ACTION TITLE PRESET LABEL ALARM I/O DATE/TIME <
PRIVACY ZONE>
BACK EXIT
ON BOT ON ON ON ON ON
OSD
-
DISPLAY SETUP > PRIVACY ZONE
34
5
6
8
7
PRIVACY ZONE - STYLE > COLOR
Set the color of the mask.
0 ~ 100
0 ~ 100
0 ~ 100
Y-LEVEL
Set the color “Y-LEVEL” of the mask.
RED ADJUST
BLUE ADJUST
> >>
Press Near/Enter Key
Press Near/Enter Key
Press Near/Enter Key
7
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
<
EDIT MASK>
DISPLAY CLEAR STYLE
BACK EXIT
1
ON CANCEL
<
COLOR>
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
<
EDIT MASK>
DISPLAY CLEAR STYLE
BACK EXIT
1
ON CANCEL
<
COLOR>
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
STYLE Y-LEVEL RED ADJUST BLUE ADJUST
BACK EXIT
COLOR 0 0 0
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
STYLE Y-LEVEL RED ADJUST BLUE ADJUST
BACK EXIT
COLOR 0 0 0
OSD
-
MOTION SETUP
35
PRESET LOCK
If motion lock is set to ON, it is impossible to set up or delete preset, scan, pattern, and/or group. It is only possible to run those functions. To set up and delete those functions, go to OSD menu.
PWR UP ACTION
This function enables you to resume the last action executed before the power went down. Most actions such as preset, pattern, scan, and group work for this function, but jog action does nto resume with this function.
AUTO FLIP
When the tilt angle arrives to the top of tilt orbit (90°), zoom module camera continues moving opposite of the tilt direction (180°) to continue tracing targets. As soon as zoom module camera passes through the top of the tilt direction (90°), images should be reversed automatically
and F
appears on the screen. If this function is set to OFF, tilt movement
range is 0° ~ 90°.
JOG MAX SPEED
Sets maximum jog speed. Jog speed is inversely proportional to zoom magnification. As zoom magnification goes up, pan/tilt speed goes down.
JOG DIRECTION
If you set this to NORMAL, the view on the screen is moving in the same direction with jog tilting. If INVERSE is selected, the view on the screen is moving reversely.
FRZ IN PRESET
When present movement begins, the camera captures the image of the beginning point. Camera will display the captured image during the present movement and will not display the images the camera receives during the movement. As soon as the camera stops at the preset end point, the camera begins to display the live images it receives at the end point.
<PARKING ACTION SETUP>
Opens PARKING ACTION SETUP screen.
<ALARM INPUT SETUP>
Opens ALARM INPUT ACTION screen.
MOTION SETUP
Setup the general functions of pan/tilt motions.
ON / OFF
ON / OFF
ON / OFF
2/SEC ~ 200/SEC
INVERSE / NORMAL
ON / OFF
PARKING ACTION SETUP
If PARK ENABLE is set to ON, camera runs assigned function automatically if there is no PTZ command during assigned WAIT TIME.
2
PARK ENABLE
WAIT TIME
The time is displayed in "hh:mm:ss" format, and the time can be
changed by 1 second unit.
1. To place the cursor on the time marked as shown below, press Near key.
2. Move joystick left/right to adjust hours, minutes and seconds.
3. Move joystick up/down to select the digit.
4. By pressing near key, save the current setting.
PARKING ACTION
Ex.` If HOME is selected for park action, camera will move to home position when there is no PTZ command during the assigned WAIT TIME.
00:10:0 0
MOTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET LOCK PWR UP ACTION AUTO FLIP JOG MAX SPEED JOG DIRECTION FRZ IN PRESET <
PARKING ACTION SETUP>
<ALARM INPUT SETUP> BACK EXIT
OFF ON ON
140/SEC
NORMAL OFF
PARKING ACTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PARK ENABLE WAIT TIME PARK ACTION
BACK EXIT
>
OFF 00:
10:00
HOME
Press Near/Enter Key
1
2
1
ON / OFF
00:00:05 ~ 04:00:00
HOME / PRESET 1~128 / SCAN 1~8 / PATTERN 1~4 / GROUP 1~8
OSD
-
MOTION SETUP
36
ALARM INPUT SETUP
If an external sensor is activated, camera will move to the corresponding action.
5
1
2
4
3
2
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O ALARM 2 N.O ALARM 3
N.O
ALARM 4 N.O ALARM 5
N.O ALARM 6 N.O ALARM 7 N.O ALARM 8 N.O BACK EXIT
MOTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET LOCK PWR UP ACTION AUTO FLIP JOG MAX SPEED JOG DIRECTION FRZ IN PRESET <
PARKING ACTION SETUP>
<ALARM INPUT SETUP> BACK EXIT
>
OFF ON ON
1
40/SEC NORMAL OFF
NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED
> >
NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O ALARM 2 N.O ALARM 3
N.O
ALARM 4 N.O ALARM 5
N.O ALARM 6 N.O ALARM 7 N.O ALARM 8 N.O BACK EXIT
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O ALARM 2 N.O ALARM 3
N.O ALARM 4 N.O ALARM 5
N.O ALARM 6 N.O ALARM 7 N.O ALARM 8 N.O BACK EXIT
NOT USED
NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED
>
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O ALARM 2 N.O ALARM 3
N.O ALARM 4 N.O ALARM 5
N.O ALARM 6 N.O ALARM 7 N.O ALARM 8 N.O BACK EXIT
PRESET 1
NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED
Press Near/Enter Key
Press Near/Enter Key
Joystick Right
Joystick Down
Alarm Type:
Sets the sensor input type.
Alarm Action
For each alarm input, you can assign the counteraction functions (Preset, Scan, Pattern, Group).
N.O (Normal Open) / N.C (Normal Close)
NOT USED / HOME / PRESET 1~128 / SCAN 1~8 / PATTERN 1~4 / GROUP 1~8
OSD
-
FUNCTION SETUP > PRESET SETUP
37
1
FUNCTION SETUP
Configure 5 special functions with this menu.
PRESET SETUP - Undefined
127 presets (1 ~ 128) can be assigned excluding the number 95, which is reserved for menu.
PRESET NO.
If a selected preset is already defined, camera moves to pre-defined position, and preset characteristics such as label and relay outputs appear on monitor. (Refer to screen ) If a selected preset is not defined, UNDEFINED will appear on monitor.
<EDIT SCENE>
Redefine the current preset scene position (i.e. PTZ).
1 ~ 128 (Excluding 95)
1 ~ 128 (Excluding 95)
GENERAL / SPECIAL
- - - - ~ 1 2 3 4
PRESET SETUP
If the preset is defined, the information will be shown on the OSD menu with the setting, and the alarm device (if defined) will be activated.
PRESET NO.
<EDIT SCENE>
<LABEL>
Edits Label to show on the monitor when the preset runs. Maximum 10 characters are allowed.
CAM ADJUST
- WB(White Balance) and AE(Auto Exposure) can be set independently for each preset.
- GENERAL: WB or AE can be set completely and simultaneously for all presets in “ROOT MENU > CAMERA SETUP” menu.
- SPECIAL: WB or AE can be set independently or separately for each preset in each preset setup menu.
- Each special WB/AE value should be activated correspondingly when camera arrives at each preset location. During jog operation, general WB/AE value should be applied.
- The special WB/AE value should not be changed when the general WB/AE value is changed. If SPECIAL is selected, the menu to set the special WB/AE appears on the monitor.
ALARM OUT
The status of four alarm outputs can be freely controlled in conjunction with preset run. The character “-” means the alarm output is OFF, and the number representing the alarm means ON.
Ex. “ - 2 3 - ” means output relay 2 and 3 will be ON, and 1 and 4 will be be OFF, when you run this preset.
EDIT SCENE
1. Using thejoystick, move camera to the desired position.
2. By pressing Near key, save the current PTZ data.
3. Press Far key to cancel.
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP> <SCAN SETUP> <PATTERN SETUP> <GROUP SETUP> <SCHEDULE SETUP>
BACK EXIT
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<
EDIT SCENE>
BACK EXIT
1
UNDEFINED
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<
EDIT SCENE>
<LABEL> CLR PRESET CAM ADJUST ALARM OUT
BACK EXIT
1
CANCEL GENERAL
- - - -
> > >
EDIT SCENE -PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]
0/0/x1/E
Press Near/Enter Key
Press Near/Enter Key
Select <EDIT SCENE>, Press Near/Enter Key
1
2
4
3
2
3
4
4
OSD
-
FUNCTION SETUP > PRESET SETUP
38
LABEL
Edits the label to show on monitor when camera arrives at presets.
2
1
2
1
3
2
CAM ADJUST
Edits label to show on monitor when the camera arrives at presets.
2
LABEL - Complete Editing
If you complete the label editing, move the cursor to “OK” and press Near key to save the completed label. To abort the current change, move the cursor to “CANCEL” and press the Near key.
3
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK CANCEL
- - - - - - - - - -
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
a
b
c
d
Current Cursor Position: In edit label menu, a reverse rectangular is cursor. As soon as finishing selecting alphabet, cursor moves to the next digit.
Selecting Alphabet: Using left/right/up/down of joystick, move to an appropriate character from the character set. To choose the character, press the Near or Enter key.
Space: If you want to use blank, choose the space character. Backspace:
If you want to delete a character in front, use
backspace character.
<WHITE BALANCE SETUP>
See the section “ROOT MENU > CAMERA SETUP > WB SETUP.”
<AUTO EXPOSURE SETUP>
See the section “ROOT MENU > CAMERA SETUP > AE SETUP.”
d
a
b
c
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<
EDIT SCENE>
<LABEL> CLR PRESET CAM ADJUST ALARM OUT
BACK EXIT
1
CANCEL GENERAL
- - - -
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<
EDIT SCENE>
<LABEL> CLR PRESET CAM ADJUST ALARM OUT
BACK EXIT
1
CANCEL
<
SPECIAL>
- - - -
CAM ADJUST -PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP>
BACK EXIT
>
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK CANCEL
- - - - - - - - - -
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
>
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK CANCEL
S K Y
- - - - - - - - - -
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
Press Near/Enter Key
Press Near/Enter Key
Press Near/Enter Key
OSD
-
FUNCTION SETUP > SCAN SETUP
39
1
2
2
1st POS.
1. CW direction
2. CCW direction
2nd POS.
SCAN SETUP
By using the scan function, you can make the camera to move between
2 preset positions repeatedly.
When the scan function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction. Then the camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in CCW(Counterclockwise) direction.
In case that the preset assigned as the 1st point is same as the preset assigned as the 2nd point, the camera turns on its axis by 360° in CW direction and then it turns on its axis by 360° in CCW direction.
SCAN NO.
Selects the scan number to edit. If a selected scan has not defined, ‘NOT USED’ is displayed in 1st position and 2nd position.
1ST POS. / 2 ND POS.
Set up the 2 position for scan function. If a selected preset is not defined, ‘UNDEFINED’ will be displayed as shown below.
SCAN SPEED
Sets the scan speed.
CLEAR SCAN
Deletes the current scan data.
1 ~ 8
PRESET 1 ~ 128 / NOT USED
1/SEC ~ 180/SEC
CANCEL / OK
SCAN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SCAN NO.
1ST POS.
2ND POS.
SCAN SPEED
1
PRESET 1 NOT USED
30
/SEC
UNDEFINED
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP> <SCAN SETUP> <PATTERN SETUP> <GROUP SETUP> <SCHEDULE SETUP>
BACK EXIT
SCAN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SCAN NO. 1
ST POS.
2ND POS.
SCAN SPEED CLEAR SCAN
BACK EXIT
1
NOT USED NOT USED
30
/SEC
CANCEL
>
Press Near/Enter Key
OSD
-
FUNCTION SETUP > PATTERN SETUP
40
PATTERN SETUP
Pattern function is when a camera memorizes the path (mostly curve path) created by a joystick controller and revives the path exactly as it memorized for an assigned time.
4 patterns are available and maximum 1000 communication commands can be stored in a pattern.
2
1
2
1
3
2
3
PATTERN NO.
Select pattern number to edit. If a selected pattern number is not defined, “UNDEFINED” will be displayed under the selected pattern number.
CLEAR PATTERN
Deletes data in the current pattern.
<EDIT PATTERN>
Starts editing pattern.
1 ~ 4
CANCEL / OK
EDIT PATTERN - Selects the Position
1.
By using joystick, move to the start position with appropriate
zoom.
2. To start the pattern recording, press Near or Enter key.
3. To exit this menu, press Far key.
EDIT PATTERN - Recording
1. Move the camera with joystick controller or run preset function to memorize the path (mostly curve path) in a selected pattern.
2. The total memory size and the rest memory size is displayed in the form of bar.
3. To save data and exit, press Near key.
4. To cancel recording and delete the recorded data, press Far key.
EDIT PATTERN 1
[NEAR:SAVE / FAR:DELETE]
0/0/x1/E
EDIT PATTERN 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO START POSITION [NEAR:START/ FAR:CANCEL]
0/0/x1/E
EDIT PATTERN 1
[NEAR:SAVE / FAR:DELETE]
0/0/x1/E
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP> <SCAN SETUP> <PATTERN SETUP> <GROUP SETUP> <SCHEDULE SETUP>
BACK EXIT
PATTERN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PATTERN NO.
CLEAR PATTERN <
EDIT PATTERN>
BACK EXIT
1 UNDEFINED CANCEL
> > > >
Select <EDIT PATTERN>, Press Near/Enter Key
Press Near/Enter Key
Move Camera to Area, Press Near/Enter Key
Record the Path of the Pattern by Camera Control
4
OSD
-
FUNCTION SETUP > GROUP SETUP
41
2
GROUP SETUP
The group function allows you to run sequence of presets, pattern, and/or scans. Maximum 8 group can be stored. Each group can have
max 20 action entities which can be preset, pattern, or scan.
The preset speed and the repeat number of pattern & scan can be set in group setup. Dwell time between actions can also be adjusted.
EDIT GROUP - Initial Screen
Press Near or Enter key in “NO” list to start group setup.
EDIT GROUP – Select Function Sequence
Note that maximum 20 functions are allowed in a group. Move cursor up/down and press Near or Enter key to set.
EDIT GROUP - Assign Function
Set up ACTION, DWELL and OPT. Note that selected item is displayed in reverse. Move cursor left/right to select items and move cursor up/down to change each value.
GROUP NO.
Selects group number to edit. If a selected group number is not defined, “UNDEFINED” will be displayed under the selected group number.
CLEAR GROUP
Deletes the data in the current group.
<EDIT GROUP>
Starts editing group.
1 ~ 8
CANCEL / OK
ACTION NO.
DWELL TIME
Sets dwell time between function by moving joystick up/down.
OPT
Represents preset speed (2~360) when preset is selected. It should be the number of repetition (1~255) when pattern or scan is selected for “ACTION.”
NONE / PRESET 1~128(Excluding 95) / PATTERN 1~4 / SCAN 1~4
00:03 ~ 04:00 (min:sec)
PRESET: 2~360 / PATTERN & SCAN: 1~255
Preset
1
Preset
120
Pattern5
1 Times
Pattern5
n Times
Dwell Time
Max. 20 Entities
Scan3
1
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP> <SCAN SETUP> <PATTERN SETUP> <GROUP SETUP> <SCHEDULE SETUP>
BACK EXIT
GROUP SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
GROUP NO.
CLEAR GROUP <
EDIT GROUP>
BACK EXIT
1 UNDEFINED CANCEL
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
NONE 2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL [NEAR:EDIT]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
NONE 2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL
[NEAR:EDIT ACT] [FAR :EDIT END]
Select <EDIT GROUP>, Press Near/Enter Key
> > > >
[ :
MOVE CURSOR
]
[ : CHANGE VAL.]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
NONE 2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL
Press Near/Enter Key
Press Near/Enter Key
Press Near/Enter Key
3
4
5 6
5
1
2
4
3
OSD
-
FUNCTION SETUP > GROUP SETUP
42
6
7
8
> >
[ :
MOVE CURSOR
]
[ : CHANGE VAL.]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 0 0 : 0
3 1
2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 0 0 : 0
3 1
2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL
[NEAR:EDIT ACT] [FAR :EDIT END]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 0 0 : 0
3 1
2 NONE 3 NONE 4 NONE 5 NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE CANCEL
Press Near/Enter Key
Press Far Key
EDIT GROUP - Selects Function Sequence
When you finish setting up an ACTION, press Near or Enter key to one-upper-level menu. Move cursor up/down to select ACTION NO. and repeat to step 4 ~ step 6 to edit the selected group.
EDIT GROUP - Saves the Setting
After completing the setup of all actions, press Far key to exit. Then cursor should be moved to SAVE. Press Near or Enter key to save the data.
64
7
8
OSD
-
FUNCTION SETUP > SCHEDULE SETUP
43
2
5
1
2
4
3
SCHEDULE SETUP SCREEN
The schedule function allows running an appropriate function like preset, scan, pattern, group, home move at designated day and time.
EX. If you setup a rule “Tuesday at 9:00AM” and “Preset 1(say main
gate),” the camera will move to main gate every Tuesday at 9:00 AM. If you choose weekday, camera will move to main gate everyday except weekend.
It is noted that due to the real time clock (ROOT MENU > SYSTEM SETUP > DATA/TIME SETUP), the time data will be kept regardless of blackout. The initial time and day setup is essential to proper schedule function.
SCHEDULE SETUP - Assign Value
Each field (DAY, TIME, ACT, NO., ON) can be selected by left/ right keys and the values in the field are changed using up/ down keys.
MASTER ENABLE
Decide whether schedule function is active or not.
DAY
Set the day for scheduling.
- Undefined: Inactivate.
- All: Applies to every day.
- WKD: Applies to every day except for Saturday and Sunday.
- SUN-MON: Applies to designated day only.
TIME
Set the time.
ACT NO
Set the function and no.
ON
Decide to make this rule effective or not.
ON / OFF
UNDEFINED / ALL / WKD / SUN ~ MON
00:00 ~ 23:59 (hour:min)
HOM(HOME) / PRS(Preset) 1~255(Excluding 95) / SCN(Scan) 1~8 / PTN(Pattern) 1~4 / GRO(Group) 1~8
ON /OFF
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP> <SCAN SETUP> <PATTERN SETUP> <GROUP SETUP> <SCHEDULE SETUP>
BACK EXIT
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF DAY TIME ACT NO ON 1
UNDEFINED 2 UNDEFINED 3 UNDEFINED 4 UNDEFINED 5 UNDEFINED 6 UNDEFINED 7 UNDEFINED BACK
> > > >
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF DAY TIME ACT NO ON 1
UNDEFINED 2 UNDEFINED 3 UNDEFINED 4 UNDEFINED 5 UNDEFINED 6 UNDEFINED 7 UNDEFINED BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF DAY TIME ACT NO ON 1
ALL 0 0: 0 0 HOM OFF 2 UNDEFINED 3 UNDEFINED 4 UNDEFINED 5 UNDEFINED 6 UNDEFINED 7 UNDEFINED BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF DAY TIME ACT NO ON 1
ALL 12 :0 0 PRS 128 ON 2 UNDEFINED 3 UNDEFINED 4 UNDEFINED 5 UNDEFINED 6 UNDEFINED 7 UNDEFINED BACK
Press Near/Enter Key
Joystick Down
Assign Value
Joystick Down, Press Near Key
4
5
OSD
-
FUNCTION SETUP > SCHEDULE SETUP
44
EX.
The second rule means camera will move to preset 12 at 7:00 every Wednesday.
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE ON DAY TIME ACT NO ON 1
MON 01: 20 HOM ON
2 WED 07: 00 PRS 1
2 ON
3 THU 11
:4 0 SCN 3 ON
4 ALL 1
2:00 SCN 1 ON
5 UNDEFINED 6 UNDEFINED 7 UNDEFINED BACK
If the rules conflict with each other, the higher number will have priority over the others.
If you assign undefined function, there will be no action. Using reserved preset, you can make various schedules.
For example, PRS179 and PRS178 are “DAY” and “NIGHT” mode respectively. (Refer to “Reserved Preset” list on page 18 in this manual.)
OSD
-
CAMERA SETUP > WB SETUP
45
WB SETUP - DAY
DAY/NIGHT
The day/night mode can be set independently. Night mode will only be deactivated if “AGC” in “CAMERA SETUP”
is set to “OFF” or “FIX.”
WB MODE
- ATW1: The color temperature is adjusted automatically between
2500K and 9300K.
- ATW2: The color temperature is adjusted automatically between 2000K and 10000K.
- AWC: The color temperature is adjusted automatically once, then adjusted value of “R-GAIN, B-GAIN” are maintained. Gain value can be adjusted manually by the user. It can be fixed as 3200K or 5600K.
- OFF: Only activated when “NIGHT” is selected. At night, the setting will be same as day’s setting.
RED/BLUE ADJUST
In every mode except “OFF,” users can adjust the red/blue adjust value to have the image they want.
R/B - GAIN
If AWC is on, the adjusted value will be marked. Also, the user can adjust the values after it was adjusted automatically.
DAY / NIGHT
ATW1 / ATW2 / AWC / 3200K / 5600K / OFF
-32 ~ +32
0 ~ 1023
>
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DAY/NIGHT
- WB MODE
- RED ADJUST
- BLUE ADJUST
BACK EXIT
DAY ATW2 0 0
Press Near/Enter Key
> >
2
WB SETUP - NIGHT
6
BRIGHTNESS
When “NIGHT” is selected, it sets the criterion of the automatic day/night selection. If set to “LOW,” the image has to be very dark to be recognized as night among 3 settings. If set to “HIGH,” the image will be recognized as night even though it is a little dark.
LOW / MIDDLE / HIGH
ZOOM CAMERA SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FOCUS MODE DIGITAL ZOOM IMAGE FLIP FLICKERLESS DIS MODE <
WHITE BALANCE SETUP>
<AUTO EXPOSURE SETUP> <SPECIAL> BACK EXIT
SEMIAUTO ON OFF OFF OFF
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DAY/NIGHT
- WB MODE
- RED ADJUST
- BLUE ADJUST
BACK EXIT
DAY ATW2 0 0
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DAY/NIGHT
- WB MODE
- RED ADJUST
- BLUE ADJUST
- R-GAIN
- B-GAIN
BACK EXIT
DAY AWC
>
0 0 0 0
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DAY/NIGHT
- WB MODE
- RED ADJUST
- BLUE ADJUST
- R-GAIN
- B-GAIN
BACK EXIT
DAY AWC
>
0 0 74
52
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DAY/NIGHT
- WB MODE
- BRIGHTNESS
- RED ADJUST
- BLUE ADJUST
- R-GAIN
- B-GAIN
BACK EXIT
NIGHT AWC
>
MIDDLE 0 0 74
52
>
Joystick Down, Press Near Key
Joystick Down
Joystick Right
5
1
2
4
3
1
DIS MODE
Sets the digital image stablization mode.
<SPECIAL>
Goes to “SPECIAL SETUP” screen.
ON / OFF
ZOOM CAMERA SETUP
Basically the camera setup is same as x27, x33, x36, x37 except for “DIS MODE,” “<SPECIAL>.”
OSD
-
CAMERA SETUP > AE SETUP
46
>
Press Near/Enter Key
>
Select ‘BACKLIGHT>BLC’, Press Near/Enter Key
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS DAY/NIGHT MOTION SHUTTER SPD SENS-UP
BACK EXIT
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS
- IRIS LEVEL
- BACKLIGHT
BACK EXIT
<ALC> <AUTO>
F.FAST
- - ­AUTOx4
<
ALC>
0 OFF
<ALC> 0 BLC CENTER
>
Select ‘AREA>USER’, Press Near/Enter Key
>
Move Camera to BLC Area, Press Near/Enter Key
AE SETUP
IRIS
See bellow AE SETUP - IRIS > ALC.
DAY/NIGHT
Color filter or B/W filter can be selected. If DAY/NIGHT is set to <AUTO>, the DAY/NIGHT editing screen will appear. See the next page DAY/NIGHT.
This is changed to AGC or MOTION according to the SENS-UP setting.
AGC
Enhances the brightness of the image by amplifying gain when the illumination is low.
MOTION
If MOTION is set as S.SLOW, the shutter speed will be slower to obtain more light. There will be less noise, but this can cuase the ghost effect of the moving object. If MOTION is set as F.FAST, there will be more noise, but this will reduct the ghost effect for any moving objects.
SHUTTER SPD
If this speed is faster, the moving object can be photographed without the ghost effect. However, the images can be dark if the scene lacks sufficient lighting.
If SENS-UP is set to AUTO, SHUTTER SPD is deactivated.
SENS-UP
Activates the slow shutter function when the liminance of image is too dark for the CCD to accumulate the amount of light it is set to obtain.
IRIS LEVEL
BACKLIGHT
This function improves the backlight effect, which is when the subject is dark on the monitor because the intensive backlight.
- BLC: You can select the desired area you wish to brighten. If it is set on a bright area, note that the area will appear even brighter.
- WDR: See AE SETUP - IRIS > ALC > BACKLIGHT > WDR on the next
page.
AREA
If set to USER, the user can set the specific area. See screen on this page.
ALC / MANUAL
DAY / NIGHT / AUTO
VERY LOW / LOW / MIDDLE / HIGH /
VERY HIGH / USER 1~16 / FIX 1~16
S.SLOW / SLOW / NORMAL / FAST / F.FAST
OFF / 1/100 ~ 1/10K
OFF / AUTO x2 ~ AUTO x256 /
FIX x2 ~ FIX x256
-32 ~ +32
OFF / BLC / WDR
TOP / BOTTOM / LEFT / RIGHT / USER
1
AE SETUP - IRIS>ALC
If ALC is selected, the iris will be controlled automatically.
2
BLC AREA
3
BLC AREA
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS
- IRIS LEVEL
- BACKLIGHT
- AREA
BACK EXIT
BLC AREA
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION [ENTER : SELECT]
BLC AREA
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ADJUST MASK WIDTH] [ ADJUST MASK HEIGTH] [ENTER : SELECT]
5
1
2
4
3
2
2
2
4 5
OSD
-
CAMERA SETUP > AE SETUP
47
1
2
2
1
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS DAY/NIGHT MOTION SHUTTER SPD SENS-UP
BACK EXIT
<
ALC>
<AUTO>
F.FAST
- - ­AUTOx4
DAY/NIGHT
- - - - - - - - - - - - - - - - - - - - - - - - - - -
-BURST
[
DAY NIGHT
]
-BRIGHTNESS
-DWELL TIME
[
NIGHT DAY
]
-BRIGHTNESS
-DWELL TIME
-MASK AREA BACK EXIT
OFF
MIDDLE 5 SEC
MIDDLE 5 SEC 1 2
AE SETUP - IRIS > ALC > BACKLIGHT > WDR
In WDR mode, the brightness is adjusted in all area of the picture by combining high speed shutter and low speed shutter.
2
>
Press Near/Enter Key
>
Joystick Down
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS
- IRIS LEVEL
- BACKLIGHT
BACK EXIT
<
ALC>
0 OFF
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS
- IRIS LEVEL
- BACKLIGHT
- WEIGHT
- WDR LEVEL
- WHITE BAL
BACK EXIT
<ALC> 0 WDR MIDDLE 0 INDOOR
BURST
If BURST is set to ON, the burst signal is produced although the camera is changed to B/W filter.
BRIGHTNESS
As the camera switches from Color to B/W with BRIGHTNESS set as LOW, the images will appear darker. As the camera switches from B/W to Color with BRIGHTNESS set as HIGH, the image will appear brighter.
DWELL TIME
When the switching criterions are satisfied, the filter is changed after the status is maintained during the dwell time.
MASK AREA
If streetlights or traffic lights are present, the mode might not be changed to B/W. In this incident, setting MASK AREAto those lights will correct the problem.
If BACKLIGHT is set to BLC, MASK AREA function is deactivated.
ON / OFF
LOW / MIDDLE / HIGH
2 SEC / 3 SEC / 5 SEC / 10 SEC / 15 SEC / 20 SEC / 25 SEC / 30 SEC
1 / 2
DAY/NIGHT
The camera automatically detects the change by the brightness of the scene.
2
WEIGHT
If WEIGHT is set to HIGH, the area applying high speed shutter is expanded.
WDR LEVEL
As WDR LEVEL gets higher, the speed of the high speed shutter becomes faster.
WHITE BAL
If WHITE BAL is set to INDOOR, the color temperature adjusts based on the darker areas. If WHITE BAL is set to OUTDOOR, the color temperature adjusts based on the brighter areas.
LOW / MIDDLE / HIGH
-9 ~ +9
INDOOR / OUTDOOR
When WDR is used, the internally operating VPS function stops.
OSD
-
CAMERA SETUP > SPECIAL
48
1
DIS MODE
Sets the Digital Image Stablization mode.
<SPECIAL>
Opens SPECIAL SETUP menu.
ON / OFF
OFF / LOW / MIDDLE / HIGH / USER 1~16
1 ~ 4
0 ~ 3
LOW / MIDDLE / HIGH
ON / OFF
+ / -
>
Press Near/Enter Key
1
2
ZOOM CAMERA SETUP
DNR
Reduces the noise caused by AGC. If set to HIGH, the noise will be reduced but the ghost effect on moving objects will increase.
ZOOM SPEED
The speed it takes to adjust zoom in/zoom out. 1 is the sloweset, and 4 is the fastest.
DETAIL
The distinction is separated into 4 levels. If the level is high, the outline is clear, but the noise is increased.
AGC COLOR SUP
The color range of the noise caused by AGC can be reduced. If set to HIGH, the color range of the noise will decrease, but the overall quality of the color will also decrease.
PIP
Turn ON to display the sub-screen. Sub-screen will appear on the bottom right corner of the main display. Even though the main display enables digital zoom, the sub-screen will only display with maximum optical zoom.
POSI/NEGA
If set as +, the camera will produce the normal image; however, if set as -, the brightness signal and color signal of the produced image will be reversed.
SPECIAL
Sets the special function related to the image.
ZOOM CAMERA SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FOCUS MODE DIGITAL ZOOM IMAGE FLIP FLICKERLESS DIS MODE <
WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP> <SPECIAL> BACK EXIT
SPECIAL
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DNR ZOOM SPEED DETAIL AGC COLOR SUP PIP POSI/NEGA
BACK EXIT
SEMIAUTO ON OFF OFF OFF
MIDDLE 4 2 MIDDLE OFF +
2
OSD
-
SYTEM SETUP
49
1
1
2
4
3
SYSTEM SETUP
DATE/TIME SETUP
After you press the Near or Enter key, move between the different fields using the left/right keys. Use the up/down keys to change the values of each field. To save the updated data, press the Near or Enter key again.
<DATE/TIME SETUP>
Opens DATE/TIME SETUP menu.
<RELAY TYPE>
Opens RELAY TYPE menu.
<PASSWORD>
Opens PASSWORD menu.
<SET HOME POSITION>
Opens SET HOME POSITION setup.
<SET NORTH DIRECTION>
Opens SET NORTH DIRECTION setup.
LANGUAGE
Select a preferred language for the OSD display. After selecting a language, press Near or Enter key.
DATE
Date is displayed in DD/MM/YYYY format. The day is automatically calculated, when you set the date.
TIME
Time is displayed in HH:MM:SS format.
ENGLISH / ESPAÑOL / FRANÇAIS / DEUTSCH / ITALIANO / РУССКИЙ / PORTUGUÊS
01 / JAN / 2000 ~ 31 / DEC / 2037
RELAY1, 2, 3, 4
Define the type of relay output for each of the four relays.
NORMAL OPEN / NORMAL CLOSE
SYSTEM SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<DATE/TIME SETUP> <RELAY TYPE> <PASSWORD> <SET HOME POSITION> <SET NORTH DIRECTION> LANGUAGE
BACK EXIT
>
ENGLISH
DATE/TIME SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DATE TIME
BACK EXIT
01/JAN/2008(TUE) 00:00:0
1(H/M/S)
RELAY TYPE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
RELAY1 RELAY2 RELAY
3
RELAY4
BACK EXIT
NORMAL OPEN NORMAL OPEN NORMAL OPEN NORMAL CLOSE
EDIT PASSWORD
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK CANCEL
- - - - - - - - - -
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d
e f g h i j k l m n o p q r s t u v w x y z
< >
- / : .
DISABLE
Press Near/Enter Key
2
RELAY TYPE SETUP
3
EDIT PASSWORD
Sets a password that consist of 4 characters. If this function is set as ENABLE, the password is required whenever you open the OSD menu.
The default password is ‘4321’, and the master password is ‘- - > g’.
4
OSD
-
SYTEM SETUP
50
5
6
Set Home Position?
When you replace the camera block or the orientation of camera is changed due to maintenance operations, it is very difficult to maintain the same pan orientation. Therefore, all function data depending on pan orientation such as preset, scan, pattern, group and privacy zone mask are not useful any more accordingly. However, even in this case, you can reuse the data if you redefine set home position on the previous home position.
SET NORTH DIRECTION
By using joystick, move the camera to the desired north position and press enter (near/save). The direction will be displayed in the screen
Direction will be displayed from:
N(North) / S(South) / E(East) / W(West) / NE(Northeast) / NW(Northwest) / SE(Southeast) / SW(Southwest).
SET HOME POSOTION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]
0/0/x1/E
SET NORTH DIRECTION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]
0/0/x1/N
SET HOME POSITION
Home position means the origin of pan angle calculation. The value of pan angle displayed on the screen is based on this home position.
By using joystick, move the camera to the desired position and press near key.
Home is not effective to tilt angle. If you change the location of the home position, all horizontal
location of functions such as preset, scan, pattern, group and privacy zone mask will be shifted based on the changed home position.
If there are no setup for those functions like preset, pattern, scan, group camera will automatically move to home position after rebooting.
If power up action is set to be on, camera will continue the function which is executed lastly after rebooting.
5
6
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/N
OSD
-
SYSTEM INITIALIZE
51
1
1
SYSTEM INITIALIZE
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
Initial Configuration Table
SYSTEM INITIALIZE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CLEAR ALL DATA CLR DISPLAY SET CLR CAMERA SET CLR MOTIOM SET CLR FUNCTION SET REBOOT CAMERA REBOOT SYSTEM
BACK EXIT
NO NO NO NO NO NO NO
CLEAR ALL DATA
Deletes all configuration data such as display, camera, motion setup and so on.
CLR DISPLAY SET
Initializes display configuration.
CLR CAMERA SET
Initializes camera configuration.
CLR MOTION SET
Initializes motion configuration.
CLR FUNCTION SET
Deletes preset data, scan data, pattern data, group data and schedule data.
REBOOT CAMERA
Reboots zoom camera module.
REBOOT SYSTEM
Reboots speed dome camera.
Display
Motion
Communication
Camera
Function
ON OFF AUTO AUTO AUTO AUTO ON Undefined
Address Camera ID PTZ Information Action Title Preset Label Alarm I/O Date/Time Privacy Zone
OFF ON ON 140°/sec NORMAL OFF OFF OFF
Preset Lock Power Up Action Auto Flip Jog Max Speed Jog Direction Freeze In Preset Park Action Alarm I/O Action
Intelligence
OFF OFF Undefined ON 4 3 ON ON
Motion Advanced Mask Area Display Sensitivity Resoluition Alarm Out>Motion Alarm Out>Fix/Move
AUTO 9600
Protocol Baud Rate
Focus Mode Digital Zoom Image Flip Flickerless DIS Mode
Day/Night WB Mode Red Adjust Blue Adjust Day/Night WB Mode
Iris Iris Level Backlight Day/Night Burst Brightness Dwell Time Mask Area Motion Sens-up DNR Zoom Speed Detail AGC Color Sup PIP Posi/Nega
Undefined Undefined Undefined Undefined Undefined
Preset 1~128 Auto Pan 1~8 Pattern 1~4 Scan 1~8 Schedule 1~7
AUTO ON OFF OFF Off
DAY ATW2 0 0 NIGHT OFF
ALC 0 OFF AUTO OFF MIDDLE 5 SEC Undefined F.FAST AUTOx4 MIDDLE 4 2 MIDDLE OFF +
Specications
-
Dimension
Unit: mm
170
101.5
260
52
38.1 (1.5”)
53
Specications
-
Specication_x39
Image Device
410K pixels [811 (H) x 508 (V)]
1/4” ExView-HAD PS CCD
380K pixels [768 (H) x 494 (V)]
470K pixels [795 (H) x 596 (V)]
440K pixels [752 (H) x 582 (V)]
Color: 550 TV Lines B/W: 600 TV Lines
52dB (AGC O)
Color / BW / Auto (D/N Filter)
Auto / Manual / Semi-Auto
Auto / Manual
1/60(1/50) ~ 1/10Ksec
x2 ~ x256
ATW1(2,500 ~ 9,500°K) / ATW2(2,000 ~ 10,000°K) / AWC / Manual
On / O
On / O
Yes (Moved/Fixed)
VBS: 1.0 V
p-p
(75ohm Terminated)
Frame Freeze Function, Detail, Reverse(H/V), Posi/Nega, PIP
Pan: 360° (Endless)
Tilt: 0° ~ 180° (Auto-Flip On), 0° ~ 90° (Auto-Flip Off)
Preset: 360°/sec
Manual: 0.05° ~ 200°/sec (Zoom Proportional)
Scan: 1° ~ 180°/sec
127 Presets with Labels / Independent Camera Setup
4 Patterns, 1000 Commands / Pattern, (Approx. 5 Minutes for Each Pattern)
8 Scans
8 Groups (Max. 20 Enters per Group)
7 Rules (Condition: Day, Time Action: Preset, Scan, Group, Pattern)
Image Auto Flip, Auto Parking, Power-up Action & etc.
RS-485
Auto, Pelco-D, Pelco-P, Samsung, Panasonic, Kalatel, AD(American Dynamics) Selectable
12 Zones
Built-in 8 Input / 4 Relay Output
Menu / PTZ Information etc, Support 7 Languages:
ENGLISH / ESPAÑOL / FRANÇAIS / DEUTSCH / ITALIANO / РУССКИЙ / PORTUGUÊS
Total Pixel
Eective Pixel
H. Resolution
S/N Ratio
Zoom
Focal Length
Angle of View
Min. Illuminance(Sens O)
Day & Night
Focus
Irisz
Shutter Speed
Sens Up(Low Shutter)
On / OFlickerless
On / OAGC
BLC
WDR
DNR
DIS
Intelligent Video
Video Out
Other Functions
Range
Pan/Tilt Speed
Preset
Pattern
Scan
Group
Schedule
Other Functions
Communication
Protocol
Privacy Zone
Sensor In/Out
OSD
Camera
Pan/Tilt
General
AC 24V, 24W(Heater O) / 57W(Heater On)
Net: 260 x 552 x 405 (mm)
Package: 580 x 390 x 500 (mm)
Net: about 6.4 Kg Package: about 11 Kg
-45°C ~ 50°C / -49°F ~ 122°F
Power
Dimension
Weight
Operating Temp.
IP 66/ Vandal Proof Structure
(Housing & Accessories : AL Die-cast), (Dome Cover: PC)
Outdoor Housing
Signal Format NTSC PAL
x39 Optical Zoom & x12 Digital Zoom
F 1.6 (W) 3.7 (T) f=3.4 ~ 132.6mm
H: 57.54° (W) ~ 1.56° (T) V: 44.44° (W) ~ 1.16° (T)
Color: 1.2 Lux / F1.6 (50 IRE) B/W: 0.12 Lux / F1.6 (50 IRE)
On / O
On / O
White Balance
54
Before sending your camera for repair, check the following or contact our technical support specialists.
PROBLEM SOLUTION
Notimage appears on the screen.
Check that the power cable is connected properly to the camera and that it meets the camera’s power requirements. Check that the line connection between the camera and monitor is fixed properly.Check that you have properly connected BNC cable to the camera.
The image on the screen is dim.
Is the lens stained with dirty? Clean your lens with a soft, clean cloth. Check the monitor and DVR settings. If the camera is exposed to very strong light, change the camera position.
The image on the screen is dark.
Adjust the contrast feature of the monitor . If you have an intermediate device, set the Ω75 / Hi-z properly.
The camera is properly, and the surface of the camera is hot.
Check that you have properly connected the camera to an appropriate power source.
The DAY/NIGHT menu does not work. Check that AGC under the CAMERA SETUP> AE SETUP menu is ‘OFF’.
Color is not correct.
Check the setting of CAMERA SETUP> WB SETUP menu .
The screen flickers continually.
Check that the camera is not pointing at the sun.
When RS485 communication is not available
Make sure that the camera and monitor are installed within the recommended distance. Make sure the cables are properly connected to the +/- on both the DVR and the Camera. Make sure you set the appropriate Baudrate pending on the distance between the camera and the DVR. When setting up the camera communications on the DVR side, make sure you enter the same protocol and baudrate as set in the camera. If your DVR supports more than one RS485 connection, make sure the cables are connected to the corresponding Channel.
The camera is out of focus.
Check that you have properly adjusted the zoom/focus adjustment lever of lens. Try setting the FOCUS to AUTO and see if the camera adjusts itself correctly. If necessary, change the FOCUS option to SEMI-AUTO or MANUAL and adjust the focus of the camera manually.
Troubleshooting
The OSD menu is frozen Reboot the camera (unplug from the power supply) to set camera
to INITIALIZE mode.
WARRANTY INFORMATION
Digital Watchdog (referred to as “the Warrantor”) warrants the Digital Watchdog Camera against
defects in materials or workmanship as follows:
LABOR : For the initial two (2) years and one (1) year on PTZ Zoom Module from the original
purchase date, if the camera is determined to be defective, the Warrantor will repair or replace the unit with a new or refurbished product at its option at no charge.
PARTS : In addition, the Warrantor will supply replacement parts for the initial two (2) years and one
(1) year on PTZ Zoom Module.
To obtain warranty or out of warranty service, please contact a Technical Support Representative
at 1-866-446-3595 Monday through Friday from 8:30AM to 8:00PM Eastern Standard Time.
A purchase receipt or other proof of the original purchase date is required before warranty service is rendered. This warranty only covers failures due to defects in materials and workmanship which arise during normal use. This warranty does not cover damage which occurs in shipment or failures which are caused by products not supplied by the Warrantor or failures which result from accident, misuse, abuse, neglect, mishandling, misapplication, alteration, modication, faulty installation, set-up adjustments, improper antenna, inadequate signal pickup, maladjustment of consumer controls, improper operation, power line surge, improper voltage supply, lightning damage, rental use of the product or service by anyone other than an authorized repair facility or damage that is attributable to acts of God.
LIMITS AND EXCLUSIONS
There are no express warranties except as listed above. The Warrantor will not be liable for incidental or consequential damages (including, without limitation or damage to recording media) resulting from the use of these products, or arising out of any breach of the warranty. All express and implied warranties, including the warranties of merchantability and tness for particular purpose, are limited to the applicable warranty period set forth above.
Some States do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the exclusions or limitations listed above may not apply to you. This warranty gives you specic legal rights, and you may also have other rights that vary from state to state.
If the problem is not handled to your satisfaction, then write to the Address listed on the next page.
Service calls which do not involve defective materials or workmanship as determined by the Warrantor, in its sole discretion, are not covered. Costs of such service calls are the responsibility of the purchaser.
55
1 ON OFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF OFF OFF
5 ON OFF ON OFF OFF OFF OFF OFF
6 OFF ON ON OFF OFF OFF OFF OFF
7 ON ON ON OFF OFF OFF OFF OFF
8 OFF OFF OFF ON OFF OFF OFF OFF
9 ON OFF OFF ON OFF OFF OFF OFF
10 OFF ON OFF ON OFF OFF OFF OFF
11 ON ON OFF ON OFF OFF OFF OFF
12 OFF OFF ON ON OFF OFF OFF OFF
13 ON OFF ON ON OFF OFF OFF OFF
14 OFF ON ON ON OFF OFF OFF OFF
15 ON ON ON ON OFF OFF OFF OFF
16 OFF OFF OFF OFF ON OFF OFF OFF
17 ON OFF OFF OFF ON OFF OFF OFF
18 OFF ON OFF OFF ON OFF OFF OFF
19 ON ON OFF OFF ON OFF OFF OFF
20 OFF OFF ON OFF ON OFF OFF OFF
21 ON OFF ON OFF ON OFF OFF OFF
22 OFF ON ON OFF ON OFF OFF OFF
23 ON
ON ON OFF ON OFF OFF OFF
24 OFF OFF OFF ON ON OFF OFF OFF
25 ON OFF OFF ON ON OFF OFF OFF
26 OFF ON OFF ON ON OFF OFF OFF
27 ON ON OFF ON ON OFF OFF OFF
28 OFF OFF ON ON ON OFF OFF OFF
29 ON OFF ON ON ON OFF OFF OFF
30 OFF ON ON ON ON OFF OFF OFF
31 ON ON ON ON ON OFF OFF OFF
32 OFF OFF OFF OFF OFF ON OFF OFF
33 ON OFF OFF OFF OFF ON OFF OFF
34 OFF ON OFF OFF OFF ON OFF OFF
35 ON ON OFF OFF OFF ON OFF OFF
36 OFF OFF ON OFF OFF ON OFF OFF
37 ON OFF ON OFF OFF ON OFF OFF
38 OFF ON ON OFF OFF ON OFF OFF
Setting the Camera’s ID using the DIP Switch
Appendix I
Use the following table as a quick reference to the Pin values and positions required for each individual ID number. The unique Pin combination equals a different ID you can use to define you camera in a situatoin where you want to control multiple cameras.
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
56
Setting the Camera’s ID using the DIP Switch
Appendix I
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
39 ON ON ON OFF OFF ON OFF OFF
40 OFF OFF OFF ON OFF ON OFF OFF
41 ON OFF OFF ON OFF ON OFF OFF
42 OFF ON OFF ON OFF ON OFF OFF
43 ON ON OFF ON OFF ON OFF OFF
44 OFF OFF ON ON OFF ON OFF OFF
45 ON OFF ON ON OFF ON OFF OFF
46 OFF ON ON ON OFF ON OFF OFF
47 ON ON ON ON OFF ON OFF OFF
48 OFF OFF OFF OFF ON ON OFF OFF
49 ON OFF OFF OFF ON ON OFF OFF
50 OFF ON OFF OFF ON ON OFF OFF
51 ON ON OFF OFF ON ON OFF OFF
52 OFF OFF ON OFF ON ON OFF OFF
53 ON OFF ON OFF ON ON OFF OFF
54 OFF ON ON OFF ON ON OFF OFF
55 ON ON ON OFF ON ON OFF OFF
56 OFF OFF OFF ON ON ON OFF OFF
57 ON OFF OFF ON ON ON OFF OFF
58 OFF ON OFF ON ON ON OFF OFF
59 ON ON OFF ON ON ON OFF OFF
60 OFF OFF ON ON ON ON OFF OFF
61 ON OF
F ON ON ON ON OFF OFF
62 OFF ON ON ON ON ON OFF OFF
63 ON ON ON ON ON ON OFF OFF
64 OFF OFF OFF OFF OFF OFF ON OFF
65 ON OFF OFF OFF OFF OFF ON OFF
66 OFF ON OFF OFF OFF OFF ON OFF
67 ON ON OFF OFF OFF OFF ON OFF
68 OFF OFF ON OFF OFF OFF ON OFF
69 ON OFF ON OFF OFF OFF ON OFF
70 OFF ON ON OFF OFF OFF ON OFF
71 ON ON ON OFF OFF OFF ON OFF
72 OFF OFF OFF ON OFF OFF ON OFF
73 ON OFF OFF ON OFF OFF ON OFF
74 OFF ON OFF ON OFF OFF ON OFF
75 ON ON OFF ON OFF OFF ON OFF
76 OFF OFF ON ON OFF OFF ON OFF
77 ON OFF ON ON OFF OFF ON OFF
78 OFF ON ON ON OFF OFF ON OFF
79 ON ON ON ON OFF OFF ON OFF
80 OFF OFF OFF OFF ON OFF ON OFF
81 ON OFF OFF OFF ON OFF ON OFF
82 OFF ON OFF OFF ON OFF ON OFF
83 ON ON OFF
OFF ON OFF ON OFF
84 OFF OFF ON OFF ON OFF ON OFF
85 ON OFF ON OFF ON OFF ON OFF
86 OFF ON ON OFF ON OFF ON OFF
57
Setting the Camera’s ID using the DIP Switch
Appendix I
87 ON ON ON OFF ON OFF ON OFF
88 OFF OFF OFF ON ON OFF ON OFF
89 ON OFF OFF ON ON OFF ON OFF
90 OFF ON OFF ON ON OFF ON OFF
91 ON ON OFF ON ON OFF ON OFF
92 OFF OFF ON ON ON OFF ON OFF
93 ON OFF ON ON ON OFF ON OFF
94 OFF ON ON ON ON OFF ON OFF
95 ON ON ON ON ON OFF ON OFF
96 OFF OFF OFF OFF OFF ON ON OFF
97 ON OFF OFF OFF OFF ON ON OFF
98 OFF ON OFF OFF OFF ON ON OFF
99 ON ON OFF OFF OFF ON ON OFF
100 OFF OFF ON OFF OFF ON ON OFF
101 ON OFF ON OFF OFF ON ON OFF
102 OFF ON ON OFF OFF ON ON OFF
103 ON ON ON OFF OFF ON ON OFF
104 OFF OFF OFF ON OFF ON ON OFF
105 ON OFF OFF ON OFF ON ON OFF
106 OFF ON OFF ON OFF ON ON OFF
107 ON ON OFF ON OFF ON ON OFF
108 OFF OFF ON ON OFF
ON ON OFF
109 ON OFF ON ON OFF ON ON OFF
110 OFF ON ON ON OFF ON ON OFF
111 ON ON ON ON OFF ON ON OFF
112 OFF OFF OFF OFF ON ON ON OFF
113 ON OFF OFF OFF ON ON ON OFF
114 OFF ON OFF OFF ON ON ON OFF
115 ON ON OFF OFF ON ON ON OFF
116 OFF OFF ON OFF ON ON ON OFF
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
117 ON OFF ON OFF ON ON ON OFF
118 OFF ON ON OFF ON ON ON
OFF
119 ON ON ON OFF ON ON ON OFF
120 OFF OFF OFF ON ON ON ON
OFF
121 ON OFF OFF ON ON ON ON OFF
122 OFF ON OFF ON ON ON ON
OFF
123 ON ON OFF ON ON ON ON OFF
124 OFF OFF ON ON ON ON ON
OFF
125 ON OFF ON ON ON ON ON OFF
126 OFF ON ON ON ON ON ON
OFF
127 ON ON ON ON ON ON ON OFF
128 OFF OFF OFF OFF OFF OFF OFF
ON
129 ON OFF OFF OFF OFF OFF OFF ON
130 OFF ON OFF OFF OFF OFF OFF
ON
131 ON ON OFF OFF OFF OFF OFF ON
132 OFF OFF ON OFF OFF OFF OFF
ON
133 ON OFF ON OFF OFF OFF OFF ON
134 OFF ON ON OFF OFF OFF OFF
ON
58
Setting the Camera’s ID using the DIP Switch
Appendix I
135 ON ON ON OFF OFF OFF OFF ON
136 OFF OFF OFF ON OFF OFF OFF ON
137 ON OFF OFF ON OFF OFF OFF ON
138 OFF ON OFF ON OFF OFF OFF ON
139 ON ON OFF ON OFF OFF OFF ON
140 OFF OFF ON ON OFF OFF OFF ON
141 ON OFF ON ON OFF OFF OFF ON
142 OFF ON ON ON OFF OFF OFF ON
143 ON ON ON ON OFF OFF OFF ON
144 OFF OFF OFF OFF ON OFF OFF ON
145 ON OFF OFF OFF ON OFF OFF ON
146 OFF ON OFF OFF ON OFF OFF ON
147 ON ON OFF OFF ON OFF OFF ON
148 OFF OFF ON OFF ON OFF OFF ON
149 ON OFF ON OFF ON OFF OFF ON
150 OFF ON ON OFF ON OFF OFF ON
151 ON ON ON OFF ON OFF OFF ON
152 OFF OFF OFF ON ON OFF OFF ON
153 ON OFF OFF ON ON OFF OFF ON
154 OFF ON OFF ON ON OFF OFF ON
155 ON ON OFF
ON ON OFF OFF ON
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
156 OFF OFF ON ON ON OFF OFF ON
157 ON OFF ON ON ON OFF OFF ON
158 OFF ON ON ON ON OFF OFF ON
159 ON ON ON ON ON OFF OFF ON
160 OFF OFF OFF OFF OFF ON OFF ON
161 ON OFF OFF OFF OFF ON OFF ON
162 OFF ON OFF OFF OFF ON OFF ON
163 ON ON OFF OFF OFF ON OFF ON
164 OFF OFF ON OFF OFF ON OFF ON
165 ON OFF ON OFF OFF ON OFF ON
166 OFF ON ON OFF OFF ON OFF ON
167 ON ON ON OFF OFF ON OFF ON
168 OFF OFF OFF ON OFF ON OFF ON
169 ON OFF OFF ON OFF ON OFF ON
170 OFF ON OFF ON OFF ON OFF ON
171 ON ON OFF ON OFF ON OFF ON
172 OFF OFF ON ON OFF ON OFF ON
173 ON OFF ON ON OFF ON OFF ON
174 OFF ON ON ON OFF ON OFF ON
175 ON ON ON ON OFF ON OFF ON
176 OFF OFF OFF OFF ON ON OF
F ON
177 ON OFF OFF OFF ON ON OFF ON
178 OFF ON OFF OFF ON ON OFF ON
179 ON ON OFF OFF ON ON OFF ON
180 OFF OFF ON OFF ON ON OFF ON
181 ON OFF ON OFF ON ON OFF ON
182 OFF ON ON OFF ON ON OFF ON
59
183 ON ON ON OFF ON ON OFF ON
184 OFF OFF OFF ON ON ON OFF ON
185 ON OFF OFF ON ON ON OFF ON
186 OFF ON OFF ON ON ON OFF ON
187 ON ON OFF ON ON ON OFF ON
188 OFF OFF ON ON ON ON OFF ON
189 ON OFF ON ON ON ON OFF ON
190 OFF ON ON ON ON ON OFF ON
191 ON ON ON ON ON ON OFF ON
192 OFF OFF OFF OFF OFF OFF ON ON
193 ON OFF OFF OFF OFF OFF ON ON
194 OFF ON OFF OFF OFF OFF ON ON
195 ON ON OFF OFF OFF OFF ON ON
196 OFF OFF ON OFF OFF OFF ON ON
197 ON OFF ON OFF OFF OFF ON ON
198 OFF ON ON OFF OFF OFF ON ON
199 ON ON ON OFF OFF OFF ON ON
200 OFF OFF OFF ON OFF OFF ON ON
201 ON OFF OFF ON OFF OFF ON ON
202 OFF ON OFF ON OFF OFF ON ON
203 ON ON OFF ON OFF OFF ON ON
204 OFF
OFF ON ON OFF OFF ON ON
205 ON OFF ON ON OFF OFF ON ON
206 OFF ON ON ON OFF OFF ON ON
207 ON ON ON ON OFF OFF ON ON
208 OFF OFF OFF OFF ON OFF ON ON
209 ON OFF OFF OFF ON OFF ON ON
210 OFF ON OFF OFF ON OFF ON ON
211 ON ON OFF OFF ON OFF ON ON
212 OFF OFF ON OFF ON OFF ON ON
213 ON OFF ON OFF ON OFF ON ON
214 OFF ON ON OFF ON OFF ON ON
215 ON ON ON OFF ON OFF ON ON
216 OFF OFF OFF ON ON OFF ON ON
217 ON OFF OFF ON ON OFF ON ON
218 OFF ON OFF ON ON OFF ON ON
219 ON ON OFF ON ON OFF ON ON
220 OFF OFF ON ON ON OFF ON ON
221 ON OFF ON ON ON OFF ON ON
222 OFF ON ON ON ON OFF ON ON
223 ON ON ON ON ON OFF ON ON
224 OFF OFF OFF OFF OFF ON ON ON
225 ON OFF OFF OFF OFF ON ON
ON
226 OFF ON OFF OFF OFF ON ON ON
227 ON ON OFF OFF OFF ON ON ON
228 OFF OFF ON OFF OFF ON ON ON
229 ON OFF ON OFF OFF ON ON ON
230 OFF ON ON OFF OFF ON ON ON
Setting the Camera’s ID using the DIP Switch
Appendix I
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
60
60
231 ON ON ON OFF OFF ON ON ON
232 OFF OFF OFF ON OFF ON ON ON
233 ON OFF OFF ON OFF ON ON ON
234 OFF ON OFF ON OFF ON ON ON
235 ON ON OFF ON OFF ON ON ON
236 OFF OFF ON ON OFF ON ON ON
237 ON OFF ON ON OFF ON ON ON
238 OFF ON ON ON OFF ON ON ON
239 ON ON ON ON OFF ON ON ON
240 OFF OFF OFF OFF ON ON ON ON
241 ON OFF OFF OFF ON ON ON ON
242 OFF ON OFF OFF ON ON ON ON
243 ON ON OFF OFF ON ON ON ON
244 OFF OFF ON OFF ON ON ON ON
245 ON OFF ON OFF ON ON ON ON
246 OFF ON ON OFF ON ON ON ON
247 ON ON ON OFF ON ON ON ON
248 OFF OFF OFF ON ON ON ON ON
249 ON OFF OFF ON ON ON ON ON
250 OFF ON OFF ON ON ON ON ON
251 ON ON OFF ON ON ON ON ON
252 OFF OFF ON
ON ON ON ON ON
253 ON OFF ON ON ON ON ON ON
254 OFF ON ON ON ON ON ON ON
Setting the Camera’s ID using the DIP Switch
Appendix I
Pin Pin Value ID
1 2 3 4 5 6 7 8 1 2 4 8 16 32 64 128
61
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government oce, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
5436 W Crenshaw St. Tampa, FL 33634
Tel : 866-446-3595 / 813-888-9555
Fax : 813-888-9262
www.Digital-Watchdog.com
technicalsupport@dwcc.tv
Technical Support Hours : Monday-Friday
8:30am to 8:00pm Eastern Time
53
Loading...
