Digital Watchdog DW-BJCUBE18T, DW-BJCUBE9T-LX, DW-BJCUBE6T-LX, DW-BJCUBE4T, DW-BJCUBE4T-LX Specsheet

CUBE

BLADE

E-RACK

Automatic Device Discovery

Simple Enterprise Scalability

Instant Motion-Based Smart Search

Easy Drag-n-Drop Camera Management

Dual Stream Recording

Cross-Platform: Windows and Linux

Graphical System Health Monitoring

Seamless Transition from Live to Search

BUILT FOR THE USER

Up to 16 2.1MP Cameras (1080P True HD Resolution)

Up to 64 2.1MP Cameras (1080P True HD Resolution)

Up to 128 2.1MP Cameras (1080P True HD Resolution)

What is DW Spectrum™?

Powerful and user-friendly video management solution, highly optimized to provide

unlimited scalability, unmatched bandwidth savings, and simplied system setup and management.

Toll Free: 866.446.3595 www.dwblackjack.com www.digital-watchdog.com [e-mail]

VISIT OUR WEBSITE

FOR A COMPLETE LIST OF

COMPATIBLE

CAMERA MODELS

SPYGLASS (REGION OF INTEREST)

The Spyglass feature lets you zoom into any area within a camera’s
field-of-view and watch the selected region as a separate display, allowing you
to monitor smaller regions of interest separately from the overall camera's
image.

RULES & ACTIONS CUSTOMIZATION

Quickly setup alerts and notifications from network and storage failure, to motion
detection or sensor activation on a camera. Setup to receive popup notifications,
voice alerts, or an e-mail with the event link.

FISHEYE
SCREEN DE-WARPING

DW Spectrum is built to be fully compatible with
the market’s leading Hemispheric cameras and
is able to translate the camera’s feed into
multiple viewing methods including panoramic
screens that de-warp the camera's image for a
fully detailed view.

ADVANCED SEARCH
CAPABILITIES

DW Spectrum offers a number of ways to quickly
and accurately isolate the critical video security
evidence users need, including calendar search and
panoramic search.

AUTO NETWORK
CONFIGURATION

DW Spectrum will automatically discover, populate,
and configure cameras on the network. Easily drag
and drop cameras across servers and observe
seamless enterprise recording!

GRAPHICAL SYSTEM
HEALTH MONITORING

Access vital information about the HDD, CPU, and
RAM health through informative, easy-to-understand
graphical format.

LOG REPORT
& SEARCH

Any operational issues that may arise in your
surveillance setup can be traced through the
advanced log system provided by DW Spectrum,
which comes fully equipped with detailed filtering
methods to help you identify a specific problem
and exporting options for your personal records.

ADVANCED PTZ CONTROL

The intuitive radial controller can be used to alter
the camera’s direction in all 3 axis, or simply draw a
box within any region to immediately focus and
zoom onto the area.

CUSTOMIZABLE LAYOUTS

DW Spectrum allows users to fully customize their
layout views. No more limited pre-set views. As a
user, you are free to customize a layout that fits your
individual viewing and management preferences.

THUMBNAIL SEARCH

Chronologically narrow down your search to
frame-by-frame detail for finding that critical
moment.

MOTION/ SMART SEARCH

Easily pinpoint and identify general motion, missing
and foreign objects. Quickly and continuously watch
video on user-selected areas (marked in red).

PANORAMIC CAMERA
SINGLE LICENSING

DW Spectrum offers seamless simplicity with our
single license requirement for all cameras including
Arecont’s SurroundVideo 20 Megapixel IP Cameras
(180° and 360° Coverage)

INSTANT VIDEO EXPORT

Mark your selection and export as an avi, mkv, and
executable file in a quick, simple, and intuitive
timeline interface.

SEAMLESS TRANSITION
FROM LIVE TO RECORDED

Easily switch between live and review mode by
simply scrolling back in time.

PLAYBACK

LIVE

DUAL STREAM RECORDING

Cameras can be set to record at high resolution when motion is detected and lower resolution at all other times.
This highly optimized feature saves hard drive space while the recording process remains uninterrupted.

For more information, please visit www.dwblackjack.com and www.dwspectrum.com

Extreme Bandwidth Optimizer NVR

Summary

The Blackjack NVR powered by DW Spectrum is a powerful and user-

friendly video management solution, highly optimized to provide

unlimited scalability, unmatched bandwidth savings and simplified

system setup and management. The architecture is cross-platform

supporting both Windows and Linux.

Features

• Cross-Platform: Windows and Linux Supported

• Graphical System Health Monitoring

• Simple Enterprise Scalability

GENERAL

• Fully Customizable Layouts

• Easy Drag-n-Drop Camera Management and Recording

• Advanced Motion Masking and Sensitivity Settings

LIVE

• PTZ Control

• Region of Interest with Forensic Spyglass

• Instant Motion-Based Smart Search

• Advanced Thumbnail Search and Calendar Search

• Dual Stream Recording

PLAYBACK

• Events Log & Search

• Automatic Device Discovery and Display

• HD (1080p) Screen Recording

• ONVIF Conformant

• E-Mapping

SPECIAL

• Hybrid Capable via Software Integration

• Full Support and de-interlace of panoramic and fisheye cameras

• Email Notification with playback link and JPEG image

• Pop-up Notification

• Event (Motion, Sensor)

• Network Troubleshooting Notification

ALARM

• Storage Failure

NOTIFICATION

• Camera Disconnection

Compatible IP Cameras & Encoders

Video Monitoring System

Unlimited Cameras, Advanced Motion Detection, Easy to use GUI,

Enterprise Scalability, Extreme Bandwidth Savings

Hardware Specification

Blackjack Blade Blackjack Cube Blackjack E-Rack

# Cameras 16 64 128

Recording
Performance

CPU Atom D2700 i-5 3550 i-7 3rd gen.

Memory 2GB 8GB 16GB

Network

Video On Board On Board (Intel) ATi

Video Port

OS

HDD Up to 2TB Up to 9TB Up to 144TB

Optional - -

Dimensions
(in)

Weight

Power
Consumption

Specifications are subject to change without prior notice.

Max 80 Mbps Max 360 Mbps Max 600 Mbps

1000 Mbps

VGA / HDMI

Linux 64bit

10 (L)

1.6 (W)

6.4 (H)

4.53 lbs

40 Watts,
19V DC,

2.1 Amps

1000 Mbps (2x)
Dual NIC Card

DVI-I (for Analog)
DVI-D (for Digital)

Windows 7 64bit Windows 7 64bit

12.8 (L)

8.5 (W)

7.5 (H)

Depends on
HDD Space

250 Watts,
100 AC,

2.5 Amps

1000 Mbps (2x)
Dual NIC Card

VGA / 2x HDMI /
4x DP

RAID 5, Redundant
Power Supply, Hot­Swap HDD Bays

2U: 25.5(L) x 17.2(W) x 3.5(H)
3U: 25.5(L) x 17.2(W) x 5.2(H)
4U: 27.5(L) x 17.2(W) x 7(H)

Depends on
HDD Space

Dual Power,
2U + 3U: 1000W
4U: 1280W

*See Website for Complete List and Details

Client Hardware Recommendations:

Processor

Graphics

Ram

NIC

OS

MOBILE ACCESS

Web

Intel Core i5 or greater

1920 x 1080

4GB

10/100/1000 Base-T Ethernet

Windows 7, Server 2008, Vista, Linux Ubuntu 10.0

Windows Explorer, Firefox, Safari, Opera, Chrome
