Digital Projection THUNDER 9000gv User Manual
THUNDER 9000gv
Super High Brightness Digital Video Projector
User Manual
CAUTION: To turn off main power, be sure to remove the plug from
power outlet. The power outlet socket should be installed as near to
the equipment as possible, and should be easily accessible.
Precautions: Please read this manual carefully before using your Digital
Projection THUNDER 9000gv Projector and keep the manual handy
for future reference.
3. GSGV Acoustic Noise Information Ordinance:
The sound pressure level is less than 70 dB(A) according to ISO 3744
or ISO 7779.
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE THIS
UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS, UNLESS THE PRONGS CAN BE
FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS
THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
OPEN COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol warns the user that uninsulated voltage
within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any
kind of contact with any part inside of this unit.
This symbol alerts the user that important literature
concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully
in order to avoid any problems.
WARNING
This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
AVERTISSEMENT
POUR EVITER UN FEU OU UN RISQUE D’ELECTROCUTION
NE PAS EXPOSER CET ENSEMBLE A LA PLUIE OU A
L’HUMIDITE; DE MEME, NE PAS BRANCHER LA PRISE POLAIRE
AVEC UNE RALLONGE A MOINS QUE LES DENTS DE LA PREMIERE NE S’Y INSERENT PLEINEMENT.
EVITER D’OUVRIR LE COFFRET CAR IL Y A, A L’INTERIEUR,
DES COMPOSANTS SOUMIS A UNE HAUTE-TENSION; POUR
LES REPARATIONS, S’ADRESSER A UN PERSONNEL
QUALIFIE.
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
ATTENTION: POUR EVITER LES RISQUES D’ELECTROCUTION, NE
PAS OUVRIR LE COUVERCLE. AUCUN DES ELEMENTS
INTERNES NE DOIT ETRE REPARE PAR L’UTILISATEUR.
NE CONFIER L’ENTRETIEN QU’A UN PERSONNEL
QUALIFIE.
L’éclair fléché dans un triangle équilatéral est destiné à
avertir l’utilisateur de la présence, dans l’appareil, d’une
zone non-isolée soumise à une haute-tension dont
l’intensité est suffisante pour constituer un risque
d’electrocution.
Le point d’exclamation dans un triangle équilatéral est
destiné à attirer l’attention de l’utilisateur sur la présence
d’informations de fonctionnement et d’entretien
importantes dans la brochure dccompagnant l’appareil.
DOC compliance Notice
This Class A digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences
du Réglement sur le Matériel D’interférence du Canada.
DOC avis de conformation
CAUTION
* In order to reduce any interference with radio and television reception use a signal cable with ferrite core attached.
Use of signal cables without a ferrite core attached may cause interference with radio and television reception.
* This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the installation manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
E – ii
Important Safeguards
These safety instructions are to ensure the long life of your projector
and to prevent fire and shock. Please read them carefully and heed all
warnings.
Installation
1. Place the projector on a flat, level surface and in a dry area free from
dust and moisture.
2. Do not place the projector in direct sunlight, near heaters or heat
radiating appliances.
3. Exposure to direct sunlight, smoke or steam could harm internal components.
4. Handle your projector carefully. Dropping or jarring your projector could
damage internal components.
5. Do not place heavy objects on top of the projector.
6. If you wish to have the projector installed on the ceiling:
a Do not attempt to install the projector yourself.
b The projector must be installed by qualified technicians in order to ensure
proper operation and reduce the risk of bodily injury.
c In addition, the ceiling must be strong enough to support the projector
and the installation must be in accordance with any local building codes.
d Please consult your dealer for more information.
e Do not attempt to stack projectors on the ceiling.
To Dealer or Installer:
To prevent the projector from falling, install it in a place and fasten it in a
way with sufficient strength to support the combined weight (107 kg/
236 lb) of the projector (84 kg/185.3 lb), the lens (10 kg/22 lb) and the
ceiling mount(13 kg/28.7 lb) for an extended period of time as well as to
withstand earthquakes.
Power Supply
1. The projector is designed to operate on a power supply of 2.8 KW
AC200-240V 50/60Hz. Ensure that your power supply fits this requirement before attempting to use your projector.
Fire and Shock Precautions
1. Ensure that there is sufficient ventilation and that vents are unobstructed to prevent potentially dangerous concentrations of ozone
and the build-up of heat inside your projector. Allow at least 8 inches
(20cm) of space between your projector and a wall. Allow at least 20
inches (50 cm) of space between the ventilation outlet and object.
2. Prevent foreign objects such as paper clips and bits of paper from
falling into your projector. Do not attempt to retrieve any objects that
might fall into your projector. Do not insert any metal objects such as
a wire or screwdriver into your projector. If something should fall into
your projector, disconnect it immediately and have the object removed
by a qualified your service person.
3. Do not place any liquids on top of your projector.
CAUTION: High Pressure Lamp May Explode if Improperly Handled.
Refer Servicing to Qualified Service Personnel.
Lamp Caution: Please read before operation
Due to the lamp being sealed in a pressurized environment, there is
a small risk of explosion, if not operated correctly. There is minimal
risk involved, if the unit is in proper working order, but if damaged or
operated beyond the recommended 750 hours, the risk of explosion
increases.
Please note that there is a warning system built in, that displays the
following message when you reach 750 hours of operation” Lamp
Running Time is Over 750 Hours!!” When you see this message
please contact your Digital Projection Dealer for a replacement.
If the lamp does explode, smoke will be discharged from the vents
located on the side of the unit. This smoke is comprised of glass in
particulate form and Xenon gas, and will not cause harm if kept out
of your eyes. If your eyes have been exposed to this gas, please
flush your eyes out with water immediately and seek immediate
medical attention. Do not rub your eyes! This could cause seri-
ous injury.
WARNING: Do not look into the lens while the projector is on. Serious damage to your eyes could result.
2. Handle the power cable carefully and avoid excessive bending. A
damaged cord can cause electric shock or fire.
3. If the projector will not be used for an extended period of time, disconnect the plug from the power outlet.
4. Placing the power cord and the RGB cable closely to each other can
cause beat noise. If this happens, keep the two separated so that
beat noise is not generated.
Cleaning
1. Unplug the projector before cleaning.
2. Clean the cabinet periodically with a damp cloth. If heavily soiled,
use a mild detergent. Never use strong detergents or solvents such
as alcohol or thinner.
3. Use a blower or lens paper to clean the lens, and be careful not to
scratch or mar the lens.
CAUTION
Do not unplug the power cable from the wall outlet under any one of
the following circumstances. Doing so can cause damage to the
projector:
• While the message "Please wait a moment" appears. This message will be displayed after the projector is turned off.
• Immediately after the power cable is plugged into the wall outlet
(the POWER indicator has not changed to a steady orange glow).
• Immediately after the cooling fan stops working (After the projector is turned off with the POWER OFF button the cooling fan continues to work for 3 minutes while the Two Digit INDICATOR "--"
flashes).
E – iii
Recommandations importantes
Ces instructions de sécurité ont pour but d'assurer une longue vie à
votre projecteur et d'éviter un incendie ou une décharge électrique. Prière
de les lire avec attention et de tenir compte de tous les avertissements.
Installation
1. Placer le projecteur sur une surface plate et de niveau, et dans un
endroit sec et à l'abri des poussières et de l'humidité.
2. Ne pas exposer le projecteur aux rayons directs du soleil, ni le placer
près d'un chauffage ou de dispositifs de radiation de chaleur.
3. L'exposition aux rayons directs du soleil, à la fumée ou à la vapeur
pourrait endommager des composants internes.
4. Manipuler le projecteur avec précautions. Laisser tomber le projecteur
ou lui donner des chocs pourrait endommager des composants internes.
5. Ne pas poser d'objets lourds sur le dessus du projecteur.
6. Si vous voulez installer le projecteur au plafond:
a. N’essayez pas d’installer le projecteur vous-même.
b. Le projecteur doit être installé par un technicien qualifié pour garantir une
installation réussie et réduire le risque d’éventuelles blessures corporelles.
c. De plus le plafond doit être suffisamment solide pour supporter le projecteur
et l’installation doit être conforme aux réglementations locales de con-
struction.
d. Veuillez consulter votre revendeur pour de plus amples informations.
e. Ne pas superposer les projecteurs accrochés au plafond.
A l’attention du revendeur ou de l’installateur:
Afin d’empêcher une chute éventuelle du projecteur, veuillez prendre
en compte lors de son placement et de sa fixation de la force nécessaire
pour supporter le poids total (107 kg), celui du projecteur (84 kg), de
l’objectif (10 kg) et de l’ensemble de fixation au plafond (13 kg), pour de
longues périodes et de façon à lui permettre de résister aux
tremblements de terre.
Alimentation
1. Le projecteur est conçu pour fonctionner sous une tension
d'alimentation de 2,8 KW CA 200-240 V 50/60 Hz. S'assurer que la
tension du secteur soit conforme à ces caractéristiques avant d'utiliser
le projecteur.
2. Manipuler le cordon d'alimentation avec précautions et éviter des
flexions excessives. Un cordon endommagé peut occasionner une
décharge électrique ou un incendie.
3. Si le projecteur ne doit pas être utilisé pendant une longue période,
débrancher la fiche de la prise de courant.
4. Placer le cordon d'alimentation et le câble RGB tout près l'un de
l'autre peut occasionner un bruit de battement. Si cela se produit, les
maintenir séparés jusqu'à ce que le bruit de battement disparaisse.
Nettoyage
1. Débrancher le projecteur avant de le nettoyer.
2. Nettoyer régulièrement le boîtier extérieur avec un chiffon humide.
S'il est très sale, utiliser un détergent doux. Ne jamais utiliser de
détergent forts ou de solvants tels que de l'alcool ou du diluant.
Précautions contre l'incendie ou la décharge
1. S'assurer qu'il y ait une ventilation suffisante et que les ouvertures
ne soient pas obstruées afin d'éviter des concentrations
potentiellement dangereuses d'ozone et l'accumulation de chaleur à
l'intérieur du projecteur. Laisser au moins 20 cm d'espace entre le
projecteur et un mur. Veuillez laisser un espace libre d’au moins 50
cm (20 pouces) entre les orifices de ventilation et l’objet.
2. Empêcher tous objets étrangers tels que des attaches trombones ou
des morceaux de papier de tomber à l'intérieur du projecteur. Ne pas
essayer de récupérer des objets qui seraient tombés dans le
projecteur. Ne pas introduire d'objets métalliques tels qu'un fil ou un
tournevis dans le projecteur. Si quelque-chose doit tomber dans le
projecteur, le débrancher immédiatement et faire enlever l'objet par
un technicien agréé Digital Projection.
3. Ne pas poser de liquides sur le dessus du projecteur.
ATTENTION: La lampe à haute pression peut exploser si elle est
manipulée incorrectement. Confier l'entretien à du personnel
d'entretien qualifié.
Précautions avec la lampe : lire avant l'utilisation
La lampe a été scellée dans un environnement sous pression, et il y
a donc un petit risque d'explosion, si elle n'est pas utilisée
correctement. Le risque est minime si l'appareil est en bon ordre de
marche, mais s'il est endommagé ou utilisé au-delà des 750 heures
recommandées, le risque d'explosion augmente alors.
Il est à noter l'existence d'un système d'avertissement intégré, lequel
affiche le message "Lamp Running Time is Over 750 Hours!! (Le
temps de fonctionnement de la lampe a dépassé 750 heures !!)"
lorsque les 750 heures de fonctionnement sont atteintes. Lorsque
ce message apparaît, prière de contacter son revendeur Digital
Projection pour un remplacement.
Si la lampe explose, de la fumée peut être produite par les fentes
d'aération situées sur le côté de l'appareil. Cette fumée est composée
de verre sous forme de particules et de gaz de Xenon, et n'est pas
nuisible si elle est maintenue à distance des yeux. Si les yeux sont
exposés à ce gaz, les rincer immédiatement à l'eau courante et consulter tout de suite un médecin. Ne pas frotter les yeux ! Cela
pourrait provoquer une grave blessure.
AVERTISSEMENT:
Ne pas regarder dans l'objectif lorsque le projecteur est allumé. De
sérieux dommages aux yeux pourraient en résulter.
ATTENTION
Ne pas débrancher le câble d’alimentation de la prise du secteur
dans les circonstances suivantes car cela risque d’endommager le
projecteur:
• Lorsque le message “Veuillez patientez un instant“ apparaît. Ce
message sera affiché après que le projecteur soit éteint.
• Immédiatement après que le cordon d'alimentation électrique ait
été branché sur la prise du mur (l'indicateur POWER n'est pas
encore devenu orange).
• Immédiatement après que le ventilateur de refroidissement de
soit arrêté de fonctionner. (Après que le projecteur ait été mis
hors tension à l’aide du bouton POWER OFF, le ventilateur
d’aération continue à tourner durant 3 minutes tandis que le
TÉMOIN à deux chiffres "--" clignote).
3. Utiliser un souffleur ou du papier pour objectif pour nettoyer l'objectif,
et faire attention de ne pas griffer ou endommager l'objectif.
E – iv
Declaration of Conformity
Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC.
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.
Products covered by this Directive
Large Screen Projector type THUNDER 9000gv Chassis EURO
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU
directives, and the manufacturer has applied the following standards:-
EN55022:1998 - Limits and Methods of Measurements of Radio Disturbance Characteristics
Information T echnology Equipment.
EN 55024:1998 - Limits and Methods of Immunity Characteristics of Information
Technology Equipment.
EN 61000-3-2:1998 - Harmonic Current Emissions.
EN 61000-3-3:1995 - Immunity to Voltage Fluctuations and Flicker.
The technical documentation required to demonstrate that the products meet the requirements
of the Low Voltage directive has been compiled by the signatory below and is available for
inspection by the relevant enforcement authorities. The CE mark was first applied in April 2002.
Signed:
Authority: D.J . Quinn, Director - Product Development
THUNDER 9000gv Chassis USA
Date: 17th April 2002
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and limitations
to use which must be observed when these products are taken into service to maintain compliance
with the above directives. Details of these special measures are available on request, and are also
contained in the product manuals.
E – v
TABLE OF CONTENTS
INTRODUCTION
Introduction to the 9000gv Projector ....................................... E-1
Getting Started ....................................................................... E-1
What's in the Box? .................................................................. E-1
1. PART NAMES AND FUNCTIONS
Projector ................................................................................. E-2
Controls............................................................................ E-3
Te r minal Panel ................................................................. E-4
Remote Control ...................................................................... E-6
Remote Control Features ................................................ E-6
Remote Control Precautions ........................................... E-7
Remote Control Battery Installation ................................ E-7
2. INSTALLATION
Setting up Your Projector ....................................................... E-8
Screen Size and Projection Distance .................................... E-8
Ta ble of Throw Distance and Screen Sizes
for Optional Lenses ............................................................. E-8
Lens Shift Adjustable Range ................................................. E-9
Moving the Projector ............................................................ E-10
Selecting a Location............................................................. E-10
3. SETUP
Connecting the Power Cable and Tu rning on the Projector .....
Set up the Projector ............................................................. E-12
Keystone ............................................................................... E-13
Setting up for Double Stacking in Link Mode ...................... E-13
Projector Orientation ............................................................ E-15
4. CONNECTIONS
When Used in Standalone Operation .................................. E-16
When Used with One Switcher (ISS-6020/ISS-6020G) ...... E-17
When Used with Two or More Switchers (100 Inputs) ........ E-18
REMOTE 1 Connector ......................................................... E-20
Operating Multiple Projectors with the Remote Control ...... E-22
Using the RGB DIGITAL Connectors................................... E-23
5. OPERATION
General Controls .................................................................. E-24
Using the Menus .................................................................. E-24
Shutter Mechanism .............................................................. E-24
A List of Direct Key Combinations ....................................... E-25
Menu Tree ............................................................................. E-26
Menu Elements .................................................................... E-28
Menu Descriptions & Functions ........................................... E-29
Source Select ....................................................................... E-29
Switcher ......................................................................... E-29
Entry List ........................................................................ E-29
Entry Edit Command ............................................... E-29
Adjust (Source) .................................................................... E-30
Picture ............................................................................ E-30
Brightness................................................................ E-30
Contrast ................................................................... E-30
Saturation ................................................................ E-30
Color ........................................................................ E-30
Hue .......................................................................... E-30
Sharpness ............................................................... E-30
V-Aperture ............................................................... E-30
Gamma Correction .................................................. E-30
White Balance ................................................................ E-30
Color Temperature ................................................... E-30
Brightness R/G/B..................................................... E-30
Contrast R/G/B ........................................................ E-30
Signal Level ............................................................. E-30
Image ............................................................................. E-30
Pixel Adjust .............................................................. E-30
Clock/Phase .......................................................... E-30
Horizontal/Vertical Position ..................................... E-31
Aspect Ratio ............................................................ E-31
Resolution................................................................ E-31
Overscan ................................................................. E-31
Video Filter .............................................................. E-31
Blanking ................................................................... E-31
E-11
Video Adj ........................................................................ E-31
Noise Reduction ....................................................... E-31
Color Matrix ............................................................. E-32
Y/C Delay ................................................................. E-32
Telecine .................................................................... E-32
Motion Select ........................................................... E-32
Motion Level ............................................................. E-32
YTR Adjustment ....................................................... E-32
CTR Adjustment ....................................................... E-32
Option Adj ....................................................................... E-32
Clamp Timing ........................................................... E-32
Sync Protection ........................................................ E-32
VD Delay .................................................................. E-32
Lens Memory ................................................................. E-33
Switcher ......................................................................... E-33
Switcher Gain .......................................................... E-33
Volume ..................................................................... E-33
Ref Adj .................................................................................. E-33
Keystone ........................................................................ E-33
Lamp .............................................................................. E-34
Lamp Mode .............................................................. E-34
Reference White Balance ............................................... E-34
Factory Default ..................................................................... E-34
Projector Options .................................................................. E-34
Timer .............................................................................. E-34
On/Off Timer ............................................................ E-34
Sleep Timer .............................................................. E-35
Menu .............................................................................. E-35
Menu Mode/Language/Menu Display Time/
Display Select/Date Format/Date, Time Preset .... E-35
Setup .............................................................................. E-36
Page 1:
Orientation/Background/S-Video Mode Select. E-36
Page 2:
Signal Select(RGB1/2) /Sync Termination
(RGB 1/2) .......................................................... E-36
Page 3:
Signal Select (Video 1/2, S-Video 1/2 and Switcher)
Page 4:
Auto Adjust (RGB Only)/Power Management/
Power Off Confirmation..................................... E-36
Keystone Save/Lens Memory/
User Name ........................................................ E-37
Page 5:
Communication Speed/Projector ID /
Default Source Select ........................................... E-37
Link Mode ...................................................................... E-37
Switcher Control ............................................................ E-37
PC Card Files ....................................................................... E-38
Help ...................................................................................... E-38
Contents ......................................................................... E-38
Source Information ........................................................ E-38
Source Name/Input Terminal/Entry No./
Horizontal & Vertical Frequency/Sync Polarity/Signal Type/
Video Type/ Sync Type/ Interlace/Resolution/Direct Key/
Aspect Ratio/ Gamma Correction/Noise Reduction/Color Matrix/
Matrix Type
Projector Information ..................................................... E-38
User Name/Serial Number/Lamp Hour Meter/ Projector Usage/
Projector ID/Version/Bios/Firmware/Data/SUB-CPU/
Formatter Version ................................................................
Link Mode ................................................................ E-39
Test Pattern .......................................................................... E-39
Cross Hatch,Gray Bars,Color Bars,Black Raster,GrayRaster,White Raster,
ANSI Checker,Focus,Aspect Ratios (Red/Green/Blue)
Selecting a new signal that is close to one of hte listed
signals in horizontal and vertical frequency ........................ E-39
........................ E-39
E-36
E-38
6. SPECIFICATIONS ............................................. E-40
7. Optional Accessories ............................................... E-42
SD-SDI BOARD LA00105 .................................................... E-42
REMOTE 3 (XLR) Pin Assignments and Signals ................. E-42
8. Compatible Input Signal List ........................... E-43
9. List of Menu Items Available on Link Mode ..... E-44
Appendix ............................................................. E-45
Dimensions........................................................................... E-45
Tips on Adjusting Focus for Lens Memory Function ........... E-46
E – vi
INTRODUCTION
This section introduces you to your new THUNDER 9000gv Projector,
provides a list of materials that comes with your projector and describes
the features and controls.
Introduction to the THUNDER 9000gv Projector
The THUNDER 9000gv is one of the finest, most technically advanced
projectors available today. The THUNDER 9000gv enables you to project
exceptionally bright, precise images up to 500 inches across (measured
diagonally) from your PC or Macintosh computer (desktop or notebook),
VCR, document camera, laser disc player, DVD player and even an HD
VCR or HD laser disc player.
You can use the projector on a tabletop or cart, you can permanently
mount it on a ceiling*, or you can use the projector to project images
from behind the screen. The remote control can be used in a wired or
wireless configuration.
Features you'll enjoy :
•A high-performance 2.0 KW Xenon lamp that delivers 10000 ANSI
lumens with a lamp life of 750 hours.
• DIGITAL PROJECTION’s unique DLPTM based light engine offers true
color reproduction.
• The THUNDER 9000gv can accommodate any picture size from 80 to
500 inches (measured diagonally).
• The THUNDER 9000gv projects images with uniform brightness while
colors remain true to their original source.
• The projector can be double stacked without an external frame, producing bright images of 16,000 ANSI lumens. In addition, double stacking offers built-in redundancy.
• An image can be projected from in front or behind a screen, and the
projector can even be installed on the ceiling*.
• Supports RGB digital, HDTV and DVD signals as well as most IBM
VGA, S-VGA, XGA, SXGA, UXGA (scaling), Macintosh or any other
RGB signals within a horizontal frequency range or 15 to 107 kHz
and a vertical frequency range of 24 to 120 Hz. This includes
NTSC3.58, PAL, PAL60, SECAM, NTSC4.43, Y/C and 1080p, 1080i,
720p and 480p HDTV standard video signals.
• Built-in telecine detection enables 3:2 pull-down correction with no
external processing necessary, eliminating jitter and artifacts to allow
for original film source motion quality.
•A newly designed menu system provides for easy setup and operation of the projector.
• The remote control can be used wired or wireless.
* Installing the projector on the ceiling must be done by authorized
DIGITAL PROJECTION technicians.
Consult your DIGITAL PROJECTION dealer for more information.
Getting Started
The fastest way to get started is to take your time and do everything
right the first time. Taking a few minutes now to review the manual may
save you hours later on. At the beginning of each section of the manual
you'll find an overview. If the section doesn't apply, you can skip it.
What's In The Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Please save the original box and packing materials if you ever need to ship the projector.
• THUNDER 9000gv Projector
• Remote Control with Remote Cable (wireless/wired).
•DVI-D Cable
•Power Cable (single phase)
•Two AA Batteries
• User Manual
• CompactFlash Memory Card (8MB) with Adapter
Digital Light Processing and DLP are trademarks of Texas Instruments.
Digital Projection Limited,
Greenside Way, Middleton, Manchester M24 1XX, UK.
Registered in England No. 2207264, Registered Office: As Above
Tel: +44 (0) 161 947 3300
Fax:+44 (0) 161 684 7674
E-Mail:enquiries@digitalprojection.co.uk, service@digitalprojection.co.uk
Web Site:www.digitalprojection.co.uk
Digital Projection Inc.
55 Chastain Road, Suite 115, Kennesaw, GA 30144. USA
Tel: (USA) 770 420 1350
Fax: (USA) 770 420 1360
E-Mail: powerinfo@digitalprojection.com
Web Site: www.digitalprojection.com
E – 1
1. Part Names and Functions
Stacking Pad (4 pcs)
Remote Sensor
PC Card Slot
Insert a PC memory card
here to upgrade the
projector system software
or copy data. To access
the slot, loosen the screw.
AC INPUT
Connect the supplied power
cable here (AC 200-240V).
Ventilation (out)
Power Switch (Main power)*
Lens (Optional)
*To turn on the main power to the projector, press the switch to the ON
position (I) and the POWER indicator on the rear panel will turn orange in color.
Press to the OFF position (0) to turn the main power off.
NOTE: When turning off the main power, first return the projector to the standby
condition by pressing the POWER OFF button on the remote control or the POWER
button on the rear panel and then turn off the main POWER switch. These procedures are necessary to protect your projector and the connected equipment.
Controls
Foot
Input Terminal Panel
Carrying Handle
Carrying Handle
E – 2
Controls
11 10 9 8 7 5 4 2
LENS SHIFT
1. Power Button
Press to turn the projector on when the projector is in the standby condition (Main Power switch must be on and the POWER indicator lit orange). Press and hold for 2 seconds to turn off the projector.
2. Power Indicator
When this indicator is green, the projector is on; when the indicator is
orange, it is in standby mode.
NOTE: After the projector is turned off, the indicator "--" flashes for three minutes to show that the cooling fan is working.
Do not turn off the main power during that time. After "--" stops flashing, the
POWER indicator will change to a steady amber glow and the projector will be in
the stand-by mode.
3. Status Indicator
When the On Timer is set and the projector is in the standby mode, the
Status indicator flashes green to show that the On Timer program is
active.
4. Two Digit Display
During normal operation the current projector ID (address) is shown in
this two digit display. In the event of an error, a projector error code will
be displayed. The display can be turned off using the ON/OFF Switch to
the left of the display.
FOCUS
ZOOM MENU SELECT
-
Remote sensor
ENTER
INDICATOR POWER
ON
ON/OFF
+
OFF
CANCEL
STATUS
136
6. Cancel Button
Press this button to exit the menu. Press this button to return the adjustments to the last condition while you are in the adjustment or setting
menu.
7. Select (Up/Down/Left/Right) Button
Up/Down: Use these buttons to select the menu of the item you wish to
adjust.
Left/Right: Use these buttons to change the level of a selected menu
item.
8. Menu Button
Displays the main menu for operation.
9. Zoom Button
Zoom the lens in and out.
10. Focus Button
Adjust the lens focus.
11. Lens Shift Button
Adjust the lens offset by shifting the projected image position horizontally and vertically.
5. Enter Button
Executes your menu selection and activates items selected from the
menu. When the slidebar or dialog box is displayed:
Pressing this button confirms adjustments/setting and returns to the
previous menu display.
E – 3
Terminal Panel
○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○
5
OUTPUT
RGB DIGITAL
INPUT9
6
INPUT3
RGB
INPUT2 INPUT1 INPUT4
R/Cr
R/Cr Cr
7
1
OPTION
IN
2
OUT
REMOTE1
G/Y G/Y
B/Cb
B/Cb
H/HVVVH/HV
Cb
OUTPUT
Y
SDI
INPUT0
For the optional SD-SDI board.
8
3
Y
C
INPUT7
IN
INPUT5 INPUT6
VIDEO1 VIDEO2
S-VIDEO2
INPUT8
LED
ON
OFF
9
10
11
12
REMOTE2
IN
S-VIDEO1
4
OUT
REMOTE3
OUT
13
E – 4
1. INPUT 3 RGB Connector (Mini D-Sub 15 pin)
Connect your PC or other analog RGB equipment such as a high-definition document camera.
This connector accepts RGB signals only.
Not compatible with component signals.
2. Option Connector (Mini D-Sub 9 pin)
For system expansion such as PC-control.
IN ................. connect to the external equipment such as PC or Third Party
Control System.
OUT ............. for daisy-chaining multiple projectors and operating them with
the same external equipment. To do so, connect to a second
projector's IN terminal to relay the input at the IN terminal of
the first projector until all the projectors are connected.
3. REMOTE 1 Connector (Mini D-Sub 15 pin)
This terminal allows external control of the projector from either the
Switcher or from an external control. When the Switcher is used, connect to the REMOTE 1 terminal on the back of the Switcher.
NOTE: This projector is compatible with the ISS-6020 Switcher.
4. REMOTE 2 Jacks
IN ................. wired remote control input.
OUT ............. for daisy-chaining multiple projectors and operating them with
the same remote control. To do so, connect to a second projector' s IN terminal to relay the input at the IN terminal of the
first projector until all the projectors are connected.
5. RGB Digital Input/Output Connectors (DVI-D 24 pin)
These connectors are used for double stacking.
Use the supplied DVI-D cable to connect the OUTPUT terminal of the
first projector to the second projector's INPUT until all the projectors
are connected.
The output is TMDS non-perfect.
The output connector is used for stacking.
7. INPUT 4 Y/Cb/Cr Terminal (RCA)
Connect component video outputs (Y/Cb/Cr, Y/Pb/Pr) of the external
equipment such as DVD player.
NOTE: This terminal accepts component signals only.
8. INPUT 5 VIDEO 1 Terminal (BNC)
Connect to the BNC video output of the external equipment such as a
VCR or laser disc player.
9. INPUT 6 VIDEO 2 Terminal (RCA)
Connect to the RCA video output of the external equipment such as a
VCR or laser disc player.
10. INPUT 8 S-VIDEO 2 Terminal (Mini DIN 4 pin)
Connect to the S-video output of the external equipment such as a
VCR with an S-video output. This terminal allows switching between S2
and S1 VIDEO input modes. See the "S-Video Mode Select" section on
page E-36 for more information.
11. INPUT 7 S-VIDEO 1 Terminal (BNC)
Connect to the Y/C separate BNC video outputs of the external equipment such as a VCR or laser disc player.
12. LED Switch
Lights up the panel on both the front and the rear at the same time.
13. REMOTE3 Connectors (XLR Connectors)
Connect an extension cable such as an audio cable to control two projectors or more using the remote control. See page E-42 for the pin
assignments.
IN ................. wired remote control input.
OUT ............. for daisy-chaining multiple projectors and operating them with
the same remote control. To do so, connect to a second projector' s IN terminal to relay the input at the IN terminal of the
first projector until all the projectors are connected.
6. INPUT 1 and INPUT 2 Terminals (BNC)
Connect R,G,B,H (Horizontal sync) and V (Vertical sync) outputs of the
external equipment such as the Switcher. If using a component with a
combined sync (SYNC) output, connect it to the H/V terminal.
Also connect component video outputs (Y/Cb/Cr) of the external equipment such as DVD player.
NOTE: The INPUT 2 terminal does not support SW1 Level and SW2 Level modes
for the ISS-6020 switcher.
E – 5
7
Remote Control
2
POWER INPUT
1
13
28
8
7
6
22
21
15
17
16
3
10
11
26
ON
TEST
PROJECTOR
IMAGE/
ON
OFF
ADJUST
R
KEY ST./
PIXEL SOUND
AUTO
MENU/
UNDO
CTL
OFF
WHITE BAL.
G
AMP
/
LENS
POSI/
ADDRESS
CANCEL
FOCUS
ABC1DEF2GHI
JKL4MNO5PQR
STU7VWX
8
0
B
E-LIST/
HELP
SHUT
PICT/
MUTE
ENTER
+
MAGNIFY/
-
ZOOM
3
6
9
INFO
OSD
7 ADJUST PICTURE
Press to display the Picture adjustment screen. Pressing this button
sequentially selects "Brightness" → "Contrast" → "Saturation" → "Color"
2
→ "Hue" → "Sharpness" → "V-Aperture" → "Gamma Correction".
8 IMAGE/PROJECTOR
Press to display the Image Option screen. Pressing this button sequentially selects "Pixel Adjust" → "Position" → "Aspect Ratio" → "Resolu-
tion" → "Overscan" → "Video Filter" → "Blanking".
While pressing and holding CTL, pressing this button rotates "On/Off
Timer" → "Sleep Timer" → "Menu" → "Setup" → "Link Mode" →
"Switcher Control".
YZ/
9
9 INPUT
Use to select an input, to name a signal, or to enter a passcode during
input registration.
1--INPUT 1 for RGBHV/Y, Cb/Pb, Cr/Pr
23
14
12
19
18
20
5
2--INPUT 2 for RGBHV/Y, Cb/Pb, Cr/Pr
3--INPUT 3 for RGB
4--INPUT 4 for Y, Cb/Pb, Cr/Pr
5--INPUT 5 for VIDEO 1
6--INPUT 6 for VIDEO 2
7--INPUT 7 for S-VIDEO 1
8--INPUT 8 for S-VIDEO 2
9--INPUT 9 for RGB DIGITAL input
0--INPUT 0 for SDI input on the optional SDI board
10 UNDO
Press to return the adjustments and settings to the previous condition.
While pressing and holding CTL, pressing this button clears all the menus
4
+
-
25
or adjustment/setting screen. At this time the adjustments/settings are
stored in memory.
11 CANCEL
Press to exit the menu.
Press this button with CTL to return to the previous menu while the
menus appear. This feature allows you to adjust several items concur-
24
rently.
1 POWER ON
Press to turn on the projector. The POWER indicator lights up green.
2 POWER OFF
Press and hold this button for a minimum of two seconds to turn off the
projector.
3 MENU
Press to display the main menu.
While pressing and holding CTL, press this button to display the Remote Control ID dialog box to specify the remote control ID.
4 ENTER
Executes the menu selection and activates items selected from the menu.
When the slidebar or dialog box is displayed:
Pressing this button confirms adjustments/setting and returns to the
previous menu display.
5 SELECT (Up/Down/Left/Right)
When pressed together, the CTL and 䊴 buttons work as a Back Space
key in the entry screen.
Pressing and holding CTL, then this button moves the menu, slidebar
or dialog box.
6 ADJUST WHITE BAL
Press to display the Color adjustment screen. Pressing this button sequentially selects "Color Temperature" → "White Balance - Brightness"
→ "White Balance - Contrast" → "Signal Level" → "Ref.White Bal" →
"Switcher-Gain".
12 INFO
Displays the "Source Information" or "Projector Information" window.
This button toggles between these two windows.
13 TEST
Press to display the test pattern. Pressing this button sequentially selects nine test patterns.
14 HELP
Provides online help.
15 PIXEL
Displays the Pixel Adjust screen to adjust the clock and phase.
16 AUTO (RGB only)
Press to adjust Position-H/V and Pixel Clock for an optimal picture.
NOTE: The Pixel Phase is not available.
17 POSITION
Press to display the Blanking screen; press again to display the Position screen.
While pressing and holding CTL, pressing this button displays the Lens
Shift adjustment screen.
18 MUTE SOUND
(available only when using with the ISS -6020 or IPS4000)
Tu r ns off the sound for a short period of time. Press again to restore the
sound.
E – 6
19 MUTE OSD
S
M
Press to turn off the on-screen display. Press again to restore the onscreen display.
NOTE: You can also turn off the on-screen display by pressing and holding CTL
and then pressing MUTE OSD; doing this again restores it. In this case any
adjustment will still change the projector's memory settings. This mode is available even when an input is switched to another or the power is turned off using
the POWER OFF button on the remote control.
20 MUTE PICTURE
Press to turn off the picture for a short period of time. Press again to
restore the picture. Pressing and holding CTL, then pressing this button
shuts off the light completely.
NOTE: This is also considered the LENS SHUTTER.
21 KEYSTONE (R)
Press to display the Keystone Correction screen.
22 AMPLITUDE (G)
Service personnel only.
23 ENTRY LIST (B)
Press to display the Entry List screen.
24 FOCUS (+/–)
While pressing and holding CTL, pressing this button allows you to adjust the lens focus.
Remote Control Precautions
• Use the remote control within a distance of about 7m (23feet) and at
an angle of 30˚ above, below, to the left and to the right of the remote
control sensor located at the front of the main unit.
• The remote control system may not function when direct sunlight or
strong illumination strikes the remote control sensor of the main unit,
or when there is an obstacle in the path.
• When remote control buttons are pressed and held, main unit function keys may not operate.
• Do not subject to strong shock.
• Do not allow water or other liquid to splash on the remote control. If
the remote control gets wet, wipe it dry immediately.
•Avoid exposure to heat and steam.
• Remove the batteries from the remote control when the remote control is not going to be used for a long period.
You cannot operate the projector using the remote control if:
• the remote ID is not set to [00].
• the remote ID is not the same as the projector ID.
See page E-22 for setting remote ID and page E-37 for setting projector ID.
Remote Control Battery Installation
Installing the Remote Control Batteries
When it comes time to replace the batteries, two "AA" type will be required.
25 MAGNIFY/ZOOM (+/–)
Magnify the size of a target portion.
While pressing and holding CTL, pressing this button allows you to zoom
the lens in and out.
26 CTL
Used in conjunction with other buttons, similar to a shift key on a computer.
INFO
SOUND
SHUT
HELP
PICT/
B
E-LIST/
G
WHITE BAL.
PROJECTOR
IMAGE/
/
ADJUST
ON
AMP
FF
O
YZ/
9
0
X
PQR
VW
6
8
NO
GHI
3
DEF
2
INPUT
STU
M
7
5
JKL
4
ABC
1
OFF
TEST
ON
POWER
ADDRES
UNDO
LENS
R
MENU/
AUTO
POSI/
PIXEL
KEY ST./
28
29 27
27 Remote Jack
Connect your remote control cable here for wired operation.
28 Backlight Switch
When using the remote control wirelessly:
Tu r ns the backlight on and off. If no button operation is made within 30
seconds with the Backlight ON, the Backlight will turn off to conserve
battery life.
When using as the wired remote control:
The light stays on in standby and power-on.
1. Press and open the cover.
2. Align and insert the batteries according to the (+) and (-) indications
inside the case.
3. Replace the cover.
29 Infrared Transmitter
Direct the remote control toward the remote sensor on the projector
cabinet.
E – 7
2. INSTALLATION
This section describes how to set up your projector and how to connect
video and audio sources.
Setting Up Your Projector
Your Projector is simple to set up and use. But before you get started,
you must first:
1. Determine the image size
2. Set up a screen or select a non-glossy white wall onto which you can
project your image.
3. Install the optional lens to the projector.
NOTE: The lens must be installed by service personnel only.
4. Connect the supplied power cable.
5. Set up the projector.
6. Connect a PC, VCR, DVD player, or other equipment.
7. Make settings or adjustments on the projector.
Throw Distance
Screen Size and Projection Distance
Applicable lens and throw distance/ List of screen sizes
Height
(V)
Formulas: Screen width H (m) = Screen Diagonal x 4/5 x 0.0254
Screen height V (m) = Screen Diagonal x 3/5 x 0.0254
Screen width H (inch) = Screen size x 4/5
Screen height V (inch) = Screen size x 3/5
Screen size (Diagonal)
Width (H)
TL-2Z (H x 2.5) – (H x 4.0)
TL-08SF (H x 0.84)
TL-1ZH (H x 1.5) – (H x 2.5)
Table of Throw Distances and Screen Sizes for Optional Lenses
Screen Size (4:3)
Diagonal
80"
100"
120"
150"
180"
210"
240"
270"
300"
350"
400"
450"
500"
For screen sizes between 80” and 500” not indicated on the above table, use formulas below.
Projection Distance = Screen Width (H) x Lens Magnification
Throw distance for TL-08SF (LA00111)lens =H x 0.84
Throw distance for TL- 1ZH (LA00263) lens =H x 1.5 - H x 2.5
Throw distance for TL- 2Z (LA00108)lens =H x 2.5 - H x 4.0
Throw distance for TL- 4Z (LA00109) lens =H x 4.0 - H x 7.0
Width (W)
1.6 (64)
2.0 (80)
2.4 (96)
3.0 (120)
3.6 (144)
4.2 (168)
4.8 (192)
5.4 (216)
6.0 (240)
6.9 (280)
7.9 (320)
8.9 (360)
9.9 (400)
Height (V)
1.3(48)
1.6(60)
1.9(72)
2.4(90)
2.9(108)
3.3(126)
3.8(144)
4.3(162)
4.8(180)
5.6(210)
6.4(240)
7.1(270)
7.9(300)
SF Fixed Lens
TL-08SF
0.84:1
1.3 (52.5)
1.7 (65.6)
2.0 (78.8)
2.5 (98.4)
3.0 (118.1)
3.5 (137.8)
4.0 (157.5)
4.5 (177.2)
5.0 (196.9)
5.8 (229.7)
6.7 (262.5)
7.5 (295.3)
8.3 (328.1)
TL-1ZH
1.5-2.5
2.4 (94) - 3.9 (156)
3.0 (118) - 4.9 (195)
3.6 (141) - 5.9(234)
4.5 (176) - 7.4 (292)
5.4 (211) - 8.9 (351)
6.3 (247) - 10.4 (410)
7.2 (282) - 11.9 (468)
8.1 (317) - 13.3 (527)
9.0 (352) - 14.8 (585)
10.5 (411) - 17.3 (683)
12.0 (469) - 19.8 (781)
13.4 (528) - 22.3 (878)
14.9 (586) - 24.8 (976)
NOTE: Distances may vary +/- 5%.
Zoom Lens
2.5 - 4.0
4.0 (157) - 6.3 (249)
5.0 (196) - 7.9 (312)
6.0 (235) - 9.5 (375)
7.5 (293) - 11.9 (468)
9.0 (352) - 14.2 (562)
10.5 (411) - 16.6 (656)
12.0 (469) - 19.0 (749)
13.4 (528) - 21.4 (843)
14.9 (586) - 23.8 (937)
17.4 (684) - 27.7 (1093)
19.9 (782) - 31.7 (1249)
22.4 (879) - 35.7 (1406)
24.9 (977) - 39.6 (1562)
TL-2Z
TL-4Z (H x 4.0) – (H x 7.0)
Unit: m (inch)
TL-4Z
4.0-7.0
6.4 (250) - 11.1 (437.5)
8.0 (313) - 13.8 (546.8)
9.6 (375) - 16.6 (656.2)
12.0 (469) - 20.8 (820.3)
14.3 (563) - 25.0 (984.3)
16.7 (657) - 29.1 (1148.4)
19.1 (750) - 33.3 (1312.5)
21.5 (844) - 37.5 (1476.5)
23.9 (938) - 41.6 (1640.6)
27.8 (1094) - 48.6 (1914)
31.8 (1250) - 55.5 (2187.5)
35.8 (1407) - 62.5 (2460.9)
39.7 (1563) - 69.4 (2734.3)
NOTE: Do not use another optional lens TL-1Z on THUNDER 9000gv.
Doing so will not deliver the performance of the projector.
E – 8
Lens Shift Adjustable Range
Lens Shift Adjustable Range for Desktop and Ceiling Mount Application
The diagram below shows the location of the image position in the lens. The lens can be shifted within the shaded area as shown using the normal
projection position as a starting point.
Maximum Possible Range for TL-1ZH, TL-2Z and TL-4Z
Parenthesized values for the ceiling mount application
Up: 0.5 V (0.32 V) Right: 0.3 H (0.23 H)
Down: 0.32 V (0.5 V) Left: 0.23 H (0.3 H)
(H: width of projected image, V: height of projected image)
Desktop/ Front
Vertical
Max. 0.5V
1V
(V)
0.23H
0.3H
0.5V
Normal position
Normal Projection
position
Ceiling/ Front
Vertical
Example for Stack
Normal position
Max. 0.5V
Screen center
Normal Projection
position
1V
0.23V
(V)
0.5V
0.3H
(H)
(H)
0.23H
Fixed Lens TL-08SF
Maximum Possible Range for TL-08SF
Up: 0.15 V Right: 0.08 H
Down: 0.15 V Left: 0.08 H
(H: width of projected image, V: height of projected image)
NOTE: To reduce the distortion of an image, it is recommended that the projector is horizontally positioned at a projection angle of 0 degree.
0.32V
Normal position
Max. 0.15V
1V
Normal Projection
position
E – 9
(V)
0.08H
0.08H
0.15V
0.15V
(H)
Moving The Projector
Always carry your projector by the handle. Ensure that the power cable
and any other cables connecting to video sources are disconnected
and the lens is removed from the projector before moving the projector.
When moving the projector or when it is not in use, cover the lens with
the lens cap.
Selecting A Location
The further your projector is from the screen or wall, the larger the image. The minimum size the image can be projected is 80" (2 m) measured diagonally. The largest the image can be is 500" (12.7 m).
500"
400"
300"
200"
100"
80"
WARNING
• Only use your projector on a solid, level surface. If the projector falls
to the ground, you can be injured and the projector severely damaged.
• Do not use the projector where temperatures vary greatly. The projector must be used at temperatures between 40 degrees F (5 degree C) and 95 degrees F (35 degree C).
• Do not expose the projector to moisture, dust, or smoke. This will
degrade the screen image.
• Ensure that you have adequate ventilation around your projector for
proper heat dissipation. Do not cover the vents on the projector cabinet.
E – 10
