Silencing an Alarm
When the alarm bell or siren is sounding, enter your user code or present your
card to a keypad or reader during the Status List display.
All/Perimeter or Home/Sleep/Away System
CANCEL VERIFY displays.
• Ifaburglaralarmisvalid,pressVERIFYtosendavericationmessage
to the Central Station.
• Ifavalidalarmhasnotoccurred,pressCANCELtocancelthealarm
and send an Abort or Cancel message to the Central Station. The
keypad displays ALARM CANCELLED and the security system will be
disarmed.
What to do when a trouble tone is sounding
You can silence the trouble tone by pressing any key. This only silences the
keypad and does not correct the condition that originally caused the problem.
XT30/XT50 User’s Guide i
XT Series™ User’s Guide
for XT30/XT50 Series Panels
Table of Contents
Section Page Section Page
Silencing an Alarm ......................... Inside Front Cover
Introduction ..............................................................1
About Your Security System ............................................. 1
Emergency Evacuation Plans ............................................2
DMP Keypads .................................................................. 3
Special Keypad Tones ......................................................7
DMP Wireless ................................................................. 8
Special Wireless Displays ................................................ 8
Special Keypad Displays ...................................................8
Email/Cell Phone Messages .............................................. 9
Text Messaging Commands .............................................. 9
Understanding Security System Terms .............................. 9
Arming and Disarming .............................................12
How Your System Operates ............................................ 12
Arming Functions .......................................................... 12
Key Fob Arming .............................................................13
Key Fob Disarming ........................................................ 13
Area System Arming ...................................................... 13
Area System Disarming .................................................. 14
All/Perimeter System Arming .......................................... 15
All/Perimeter System Disarming ...................................... 16
Home/Away System Arming ........................................... 17
Home/Away System Disarming ....................................... 18
Keypad Shortcut Keys .................................................... 19
User Menu ...............................................................21
Accessing the User Menu ............................................... 21
User Menu Options ........................................................ 21
User Check-in ................................................................ 22
Zone Activity Check ....................................................... 22
Sensor Reset ................................................................. 23
Outputs On Off ............................................................ 23
Bypass Zones ................................................................ 24
Zone Monitor ................................................................ 24
Using the Zone Monitor Function .................................... 25
System Test .................................................................. 25
User Codes ................................................................... 26
Schedules ..................................................................... 29
Permanent Schedules .................................................... 29
Extending Schedules ..................................................... 30
Output Schedules .......................................................... 30
Date and Time .............................................................. 31
Display Events ..............................................................31
Request Service? ........................................................... 31
ii XT30/XT50 User’s Guide
System Setup ..........................................................32
System Setup Record..................................................... 32
Protection Areas ............................................................ 32
Output Record .............................................................. 32
Key Fob Button Programming ........................................ 33
User Codes ................................................................... 33
Appendix A ..............................................................35
About the Display Events Section.................................... 35
Zone Activity Check Event Display .................................. 35
Zone Bypass Event Displays ........................................... 35
Zone Event Displays ...................................................... 36
Arming and Disarming Event Displays ............................. 36
User Check-in Event Displays ......................................... 36
User Code Change Event Displays .................................. 36
Supervisory Event Displays ............................................ 37
System Monitor Event Displays ....................................... 37
Wireless Jamming Event Displays ................................... 37
Wireless Trouble Event Displays ...................................... 37
Appendix B ..............................................................38
DMP Wireless Description ............................................. 38
Appendix C ..............................................................39
User’s Guide .................................................................39
Entering User Names .................................................... 41
Appendix D ..............................................................42
Email/Cell Phone Message User’s Guide ..........................42
PhoneAccess™ User’s Guide .......................................... 43
Text Messaging Commands ............................................ 44
Check Armed Status Text Command ............................... 45
Subscribe to Text Messages ........................................... 45
Common Keypad Displays .............................................. 46
Quick Reference Wallet Cards ................................. 49
XT30/XT50 User’s Guide 1
Introduction
About Your Security System
Your system is designed with your safety and comfort in mind.
It uses the latest in computer technology to create the most
advanced,user friendly,security, re, andaccess control system
available.
The system combines ease of use with a simple to understand
keypad display to offer the full range of features requested by
today’s security system owners. Your security system can protect
both the interior and perimeter of your home or business while you
are away or just the perimeter when you are inside, giving you a
wall of security and peace of mind.
You can turn portions of your protection on or off at any time by
pressing a few keys. You can add, delete, and change personal user
codes at any time or check the status of all protection devices in
the system.
DMP Keypads
This is the device we have placed at certain locations throughout
the premises that allows you to turn the system protection on and
off using your personal user code.
Keypad User Menu
The keypad provides a simple User Menu containing all of the
functions you need to fully operate your system such as changing
the time of day or a personal user code.
A Note About False Alarms
One of the most important concerns facing the security industry
today is false alarms. The accidental dispatching of police and
re agencies places others in jeopardy by limiting the response
capability of those emergency service units.
As part of our commitment to reducing false alarms, we would like
to encourage you to read this guide thoroughly. All the information
contained here can help you quickly, and comfortably, learn the XT
Series™ system operation.
Note: There may be a 30-second alarm communication delay
pre-programmed at installation to allow disarming if a false alarm
occurs. This delay is optional and can be removed or increased to
45 seconds by your alarm dealer.
Test Your System Weekly
It is recommended that you test the burglary portion of your system
at least once each week. Testing should involve an active test of all
doors, windows, and motion detectors connected to your system.
Ifyoursystemalsohasreprotection,calltheservicedepartment
tondouthowthisportionofyoursystemshouldbetested.
Refer to the System Test section of this guide for instructions on
testing the burglary portion of your system.
2 XT30/XT50 User’s Guide
Practice your escape plans
Devising an escape plan is only the beginning. For the plan to be
effective everyone should practice escape routes from each room.
Second Floor
Building Front
Building Back
First Floor
Fire Escape
Window Ladder
Figure 1: Sample Escape Route Map
Early detection
The best way tosurvive a re or other emergency is to get out
early. A re alarm system installation, with smoke and carbon
monoxide detectors in each room, can greatly decrease your risk
of loss or injury.
Emergency Evacuation Plans
Overview
The National Fire Protection Association recommends that you
establish an emergency evacuation plan to safeguard lives in the
eventofareorotheremergency.
Draw a floor plan of your home or business
On a clean sheet of paper, draw the walls, windows, doors, and
stairs. Also draw any obstacles that a person may encounter while
exiting the building such as large furniture or appliances.
Develop escape routes
Determine at least two routes the occupants in each room can
take to safely escape. One route can be the most obvious such
as the door. Another can be through an easily opened window.
If the window is high off the ground, an escape ladder should be
provided.
Draw arrows on theoor plan to show escaperoutes from each
room.
Decide where to meet
Prearrange a meeting place outside and away from where
emergency personnel are likely to be working. A neighbor’s house
or across the street in front of the house are good locations. Always
perform a head count to make sure all occupants safely exited.
NEVER ENTER A BURNING BUILDING. If the head count shows one
or more persons missing, give this information immediately to the
authorities. Never enter a building to look for someone.
Introduction XT30/XT50 User’s Guide 3
DMP Keypads
Your system may have one or more easy to use LCD keypads that allow you to properly operate the system.
•SecurityCommand™Keypads •Thinline™, Aqualite™,IconKeypads •Clear Touch™ Keypads
AB C D E F G H I JK L
VWX
MN O
P Q R
ST U
YZ
COMM AND
90
1 234
5678
R
ABC PRINTING
FRI 2:51 AM
ARMED
32-Character Display
Armed LED
Power LED
Select Keys
Data Entry Digit keys
COMMAND Key
Back Arrow Key
!
Security Command™ Keypad
32-Character Display
Armed LED
Power LED
Data Entry Digit keys
COMMAND Key
Back Arrow Key
Select Keys
1 2 3 4
9 0 CMD
5 6 7 8
ABC PRINTING
FRI 2:51 AM
Backlit Logo
and Proximity
Antenna
Thinline™/Aqualite™ Keypad
Icon Display
Shortcut and Digit keys
Backlit Logo
and Proximity
Antenna
COMMAND Key
Back Arrow Key
Select Keys
Thinline™ Series Icon Keypad
AC Power/Armed LED
Three Panic Icons
32-Character
Display with
Four Touch
Select Areas
Data Entry
Digit Keys
COMMAND KeyBack Arrow Key
Logo
Icon
51
Clear Touch™ Keypad
4 XT30/XT50 User’s Guide Introduction
The Select keys
Security Command™, Th i n l i n e ™ , A q u a l i t e ™ , a n d I c o n
Keypads:
There are four keys under the display called the Select keys. These
keys are one of the features that make your system so easy to
operate. They allow you to make selections by pressing the Select
key under a choice shown in the display.
Note: For the purposes of this guide, when instructed to press
the rst Select key, press the far left Select key; the second
Select key is the second from the left; third Select key is second
from the right; and the fourth Select key is the far right key.
Clear Touch™ K e y p a d s :
There are four Select Areas in the display. These Select Areas are
one of the features that make your system so easy to operate.
They allow you to make selections by touching the area to choose
the item in the display.
Note: For the purposes of this guide when using Clear Touch™
Keypads, when instructed to press the rst Select key, touch
Select Area 1; the second Select key touch Select Area 2; third
Select key touch Select Area 3; and the fourth Select key touch
Select Area 4.
Power/Armed LED
Security Command™, Thinline™, and Aqualite™ Keypads:
The Power LED indicates the panel Power status. It is recommended
you contact the service department when the Power LED is off or
blinks.
LED Operation AC Battery
ON (Steady) OK OK
OFF Trouble N/A
BLINKS OK Trouble
The Armed LED is ON steady anytime any burglary protection area
is armed and is OFF when ALL areas are disarmed.
Clear Touch™ K e y p a d s :
The LED indicates the Power and Armed status of the panel.
Depending on the operation, the LED displays in Red or Blue as
listed in the table.
Color and Activity LED Operation
Blue Steady Panel Disarmed, AC Power OK, Battery OK
Blue Blinking Panel Disarmed, AC Power OK, Battery Fault
No Light Panel Disarmed, AC Power Fault, Battery OK
Red Steady Panel Armed, AC Power OK, Battery OK
Red/Blue Alternate Panel Armed, AC Power OK, Battery Fault
Red Blinking Panel Armed, AC Power Fault, Battery OK
32-Character Display
Select Area 1
Select Area 2
Select Area 3
Select Area 4
Touch Select Areas
Introduction XT30/XT50 User’s Guide 5
Panic Functions
Your keypad may be set up to send a Panic, Emergency, or Fire
report to the central station. This function is optional. If this
option is programmed for your keypad, icons display below the top
row Select keys/areas.
Security Command™, Th i n l i n e ™ , A q u a l i t e ™ , a n d I c o n
Keypads:
Press and hold the two Select keys adjacent to the desired icon for
2 seconds, until a beep from the keypad is heard.
Top Row Select Keys
Police EmergencyFire
!
Security Command™ Keypad Panic Keys
Top Row Select Keys
PoliceEmergency
Fire
Thinline™/Aqualite™/Thinline™ Icon Keypad Panic Keys
With Shaded Buttons To Indicate Police Panic Keys
Clear Touch™ K e y p a d s :
Touch the icon for 2 seconds until a beep is heard.
Clear Touch™ Keypad Panic Icons
7/0
Panic Function
Security Command™, Thinline™, and Aqualite™ Keypads:
Security Command™, Thinline™, and Aqualite™ Keypads may also be
programmed at installation to allow the user to initiate an optional
Panic alarm by simultaneously pressing and holding the 7 and 0
(zero) keys. When the 7 and 0 keys are pressed for a short time,
the keypad sends a Panic alarm report to the central station.
Note: The 7/0 Panic Function is not available on Clear Touch™ or
Thinline™ Icon keypads.
Police Emergency Fire
Touch Select Areas
6 XT30/XT50 User’s Guide Introduction
Backlighting Brightness
At the SET BRIGHTNESS display, use the left Select key to lower
the keypad brightness. Use the right Select key to increase the
brightness. On Thinline™ Icon Series keypads, enter the desired
brightness from the range of off (0) to maximum (8).
Note: If the brightness level is lowered, it temporarily reverts back
to maximum intensity whenever a key is pressed.
On Security Command™, Thinline™, or Aqualite™ keypads this
sets the LCD display, AC LED, and keyboard backlighting brightness
level.
On Clear Touch™ keypads the user selected brightness may be set
to off which allows the backlighting to turn off (clear glass). Simply
touch the glass anywhere and the backlight illuminates for data
entry. When the speaker is sounding, the backlight illuminates at
one-half (1/2) brightness.
On Thinline™ Series Icon keypads this sets the LCD display,
keyboard, and logo backlighting brightness level.
Internal Speaker Tone
Set the tone of the keypad internal speaker. At the SET TONE
display, use the top left Select key to make the tone lower. Use the
right Select key to make the tone higher. On Thinline™ Icon Series
keypads, enter the desired speaker tone from the range of 1-8.
Volume level
Set the volume level of the keypad internal speaker for key presses.
During alarm, trouble, and prewarn conditions, the volume is always
at maximum level. At SET VOLUME LEVEL, use the left Select key
to lower the keypad volume. Use the right Select key to raise
the volume. On Thinline™ Icon Series keypads, enter the desired
speaker volume level from the range of off (0) to maximum (8).
Common Keys on All Keypads
Data Entry Digit keys
These keys allow you to enter your user code when arming or
disarming or enter other information into the system.
COMMAND (CMD) key
The COMMAND key allows you to advance through the keypad
displays, User Menu, or complete a data entry function.
Back Arrow
(<—) key
The Back Arrow (<—) key is used to go back through the keypad
displays while operating your system. You can press the Back Arrow
key to back up through the list of functions in the User Menu or to
erase the last character you entered.
Keypad User Options
The User Options menu allows you to make adjustments to your
keypadtobesttyourenvironmentandneeds.
On Security Command™, Thinline™, Aqualite™, or Thinline™ Series
Icon keypads, press and hold the Back Arrow and COMMAND keys
for two seconds. The keypad display changes to SET BRIGHTNESS.
Press the COMMAND key to display the next option or the Back
Arrow key to exit.
On Clear Touch™ keypads, touch and hold the center of the logo
icon for two seconds. The display changes to SET BRIGHTNESS.
Touch the COMMAND (CMD) key to display the next option or touch
the Back Arrow (<—) to exit the User Options function.
Introduction XT30/XT50 User’s Guide 7
Model Number
Thekeypadmodelnumber,rmwareversion,anddatedisplay,but
cannot be changed.
Keypad Address
The current address assigned to the keypad displays, but cannot
be changed. Press the Back Arrow key to exit the User Options
function.
Special Keypad Tones
Your keypad also contains a small speaker that alerts you about
events as they occur on your system. For burglary alarms, the tone
willsilenceassoonastherstusercodedigitkeyispressed.Ifa
valid user code is not entered within 5 seconds or an invalid user
code is entered, the tone begins sounding again.
Below are brief descriptions of the different tones you hear from
the keypad.
Fire alert: An intermittent sweeping siren from LCD keypads only
thatcontinuouslyrepeatsuntiltherealarmissilenced.Thisisin
addition to the bell output from the alarm panel.
Burglary alert: A siren tone from LCD keypads only that continues
until the alarm is silenced. This is in addition to the bell output
from the alarm panel.
Key press tone: A short beep as you press a key on the keypad.
Prewarn tone: A continuous pulsed tone that sounds when you
open an entry delay door on a system that is armed (turned on)
reminding you to disarm the burglary protection.
Your system will silence the tone as soon as the rst user code
digit key is pressed. If a valid user code is not entered within 5
seconds or an invalid user code is entered, the prewarn tone begins
sounding again.
Exit tone: When fully arming your system to leave, a continuous
pulsing tone sounds during the exit countdown just after arming to
remind you to exit the premise. At ten seconds prior to the end of
the countdown, the rate of pulsing increases.
Monitor tone: A pulsed tone that sounds one time for one second
each time a door or window is opened while you are using the zone
monitor function from the User Menu. See Zone Monitor.
Trouble tone: A steady tone indicating a trouble condition on your
system. Press any key to silence the trouble tone.
What to do when the trouble tone sounds
You can silence the trouble tone by pressing any key.
This only silences the keypad and does not correct the
condition that originally caused the trouble.
8 XT30/XT50 User’s Guide Introduction
DMP Wireless
Your system may include DMP wireless devices such as key fob(s).
There are three types of DMP wireless key fobs available:
4-Button Model 1145 Key Fob
2-Button Model 1146 Key Fob
1-Button Model 1147 Key Fob
The drawing shows the button
layout for all three models for your
reference. Each button on the key
fob is programmed to perform a
specic action. The button names
are listed for your reference.
TOP = the Key Fob Top button
BTM = the Key Fob Bottom button
LFT = the Key Fob Left button
RGT = the Key Fob Right button
The button programming list for the
key fob(s) connected to your system
is located in the System Setup section
of this guide. Refer to Appendix B for
LED Status operation information.
Specicfunctionlabelscanbeadded
to each button to indicate button
operation.
For best operation, allow the LED
to turn on and then turn off before
pressing another button. The key
fob may not complete sending the
signal for the button press if another
button is pressed too soon.
Special Wireless Displays
Your system may use wireless transmitters to send alarm and trouble
information from the protection devices to the panel. Wireless
systems have a few unique keypad displays.
BACK DOOR -LOBAT - (Low Battery) The battery in a wireless
transmitter is low. (BACK DOOR is used as an example only.)
BACK DOOR -MISNG - (Missing) The panel is not receiving the
wireless transmitter periodic test report.
WIRELESS -TRBL - (Trouble) Some part of your wireless system is
operating improperly. Call the service department for assistance.
WIRELESS RECEIVER JAMMED -ALARM - Your system may be programmed
for wireless interference detection and, if displayed, your wireless
receiver has detected an interfering signal while the system is armed.
WIRELESS RECEIVER JAMMED -TRBL - (Trouble) Your system may be
programmed for wireless interference detection and, if displayed,
your wireless receiver has detected an interfering signal while the
system is disarmed.
Special Keypad Displays
As you use your system, you may occasionally see a keypad display
that asks you to enter a user code or describes a condition on the
system. Below are some examples of the displays you may see.
ALARM
A24-hourzone,suchasareorpaniczone,oranarmedburglary
zone is faulted. Your system may sound bells or sirens.
ALARM NOT SENT
The alarm signal was aborted and was not sent to the central station
because a user code was entered to disarm the system before the
alarm signal was sent to the central station. Also, your system may
be pre-programmed at installation to send an Abort signal to the
Central Station. Refer to the Introduction section.
Connect Keyring or Lanyard Here
LED
2-Button Layout 1-Button Layout
4-Button Layout
TOP
TOP
TOP
BTM
BTM
LFT
RGT
Key Fob Examples and
Button Names
Introduction XT30/XT50 User’s Guide 9
Email/Cell Phone Messages
Your system may be programmed at installation to send a variety of
messages to your personal email, PDA, and cell phone.
The message option uses your security system’s reporting capability
to send reports using an email address or cell phone number in
much the same way as someone sending an email would do. You
can receive reports of alarms, troubles, or system armings and
disarmings and know at a glance your system status. See Appendix
D for more information.
Text Messaging Commands
Your system may be programmed to allow simple text messages to
be sent to the security system and perform basic user operations.
By texting a message from your cell phone or PDA, the following
actions can be performed: Arm/Disarm, check Armed Status,
Cancel Alarm, and turn Outputs On/Off. See Appendix D for more
information.
Understanding Security System Terms
Throughout this guide, and in some displays on your keypad, you
may see certain words or phrases that might be unfamiliar.
Below are some terms you will see here and on the keypad
display.
Arming
This is the term used for turning on the burglary protection in one
or more areas of the system. Your system may require you to enter
a user code. When armed, the system can sound alarm bells or
sirens and, if monitored, send alarm reports to a central station
when a burglary zone is faulted.
Fire, panic, and other 24-hour devices are always turned on and do
not need to be armed.
ALARM CANCELLED
An Alarm signal just sent to the central station was cancelled
because a user code was entered after the alarm was sent. Also,
an Alarm Cancel signal is sent to the Central Station.
ALARM VERIFIED
Avalidburglaralarmhasoccurredandhasbeenmanuallyveried
by the user. The alarm system also transmits a VERIFY message to
the Central Station.
ENTER CODE
The system requires you to enter a personal user code. User codes
can be used for turning your system on (arming), turning your
system off (disarming), and other system options.
As you enter your user code, the keypad display shows an asterisk
(*) in place of each digit pressed. This prevents others from seeing
your user code on the display as you enter it.
TRY AGAIN
The user code you entered is not recognized by the system. Check
the user code and try again.
INVALID CODE
The user code you entered is considered invalid by the system.
TRBL (TROUBLE)
There is a problem with a protection device or system component.
This display is accompanied by a description of the problem.
SYSTEM TROUBLE or SERVICE REQUIRED
There is an electronic failure in your system. Contact the service
department as soon as possible.
TEST IN PROGRESS
The system is currently being tested by an installation or service
technician.
10 XT30/XT50 User’s Guide Introduction
Disarming
This means turning off one or more areas of the system. When
disarmed, the system does NOT sound alarms or send alarm reports
to a central station when a burglary zone faults.
Zone
A zone refers to one or more protected openings or pro tection
devices assigned the same zone number. Each door or window,
motion detec tor, smoke detector, or other device has a zone
number and a name.
Often, similar devices in the same general area share the same
zone. For example, the windows on the east side of the premises
can all be grouped together in a zone named E. WINDOWS.
Entry or Exit Zone
Almost all systems have one or more doors through which you can
enter or exit the premises. These doors are programmed with a
delay time to allow you to enter or exit while the system is armed
without setting off the alarm.
When you arm the system, activity on all burglary zones is ignored
until the programmed exit delay time expires. Once that time has
expired and the system is fully armed, opening the door causes the
panel to start the entry delay time. During the entry delay time,
enter a valid user code to disarm the system or an alarm occurs.
Instant Zone
Exterior windows and non-entry doors, or interior protection
devices, are typically not programmed with delay times. If these
zones fault while the system is armed, an alarm occurs instantly.
24-Hour Zone
A 24-hour zone is not turned on or off by arming or disarm ing your
system. Some examples of 24-hour zones are re zones, panic
zones, and temperature control zones.
Areas
An area is made up of burglary zones that can be armed or disarmed
together. The Perimeter area, for example, consists of all the doors
and windows on the outside of the building. When you arm the
Perimeter, these zones sound an alarm if tripped.
Central Station Monitoring
Your system can also be programmed to automatically send alarm,
trouble, and arming and disarming reports to a central station.
Operators at the central station can then dispatch the appropriate
authoritiesorcontactyouwiththespeciceventinformation.
Status
Status is a feature that automatically displays the system armed
or dis armed status on the keypads. Alarm or trouble con ditions
on a zone or a system monitor such as AC or battery trouble can
also display. There are two types of status information available:
Status List and Armed Status.
Status List
The keypad Status List displays any alarm or trouble condition on
a zone and any trouble condition that occurs with the AC power or
battery power. If your system contains any Panic zones, these do
not display on the keypad for security reasons.
Ifanalarmoccursonanon-re,24-hourzoneorasystemmonitor,
it remains in the Sta tus List until it re stores. If one or more armed
burglary zones trips, the last one to trip remains in the Status List.
The burglary zone alarm remains in the Status List until it is cleared
by disarming the system.
Zone Status
To display the status of a particular zone, enter the zone number
followed by the COMMAND key when the keypad displays the Status
List.
Introduction XT30/XT50 User’s Guide 11
Armed Status
With Armed Status, the keypad displays the current armed condition
of areas within your security system.
The keypad displays When
HOME SYSTEM ON The perimeter areas is armed in a Home/
Away system.
PERIMETER ON The perimeter is armed in an All/
Perimeter system.
ALL SYSTEM ON All areas are on.
SLEEP SYSTEM ON The perimeter and interior areas are on
but the bedroom area is off.
Also, for keypads that include an Armed LED, the Armed LED is ON
steady anytime a burglary protection area is armed and OFF when
ALL areas are disarmed.
Exit Error
This is an automatic panel function that occurs if an exit door does
not close all the way after the system is armed.
For example, if the front door is left ajar upon exit and the exit delay
time expires, the system attempts to arm the front door zone but
recognizes the open condition. The system sounds the alarm sirens
and starts the entry delay. If the open condition is not corrected, an
alarm and exit error is reported to the central station.
The Exit Error feature allows the central station to acknowledge
the arming error without dispatching the police on a false alarm.
12 XT30/XT50 User’s Guide Arming and Disarming
Arming and Disarming
How Your System Operates
Your system has been programmed to operate in one of three
modes: Area, All/Perimeter or Home/Sleep/Away.
• Area — Your burglary protection is divided into up to six
areas. Each area can have a custom name, be turned on or
off independently of other areas, and limit access to only those
users with proper authority.
• All/Perimeter — Your burglary protection is divided into two
areas: Interior and Perimeter.
Perimeter arming is for when you are staying inside but want
the comfort of knowing the exterior doors and windows are
armed. Perimeter arming allows you to move freely about
inside without setting off any interior alarms.
All arms both the Perimeter and the Interior of the system. You
want to arm both of these areas when leaving the building and
no one is left inside.
• Home/Sleep/Away — Your burglary protection is divided into
two or three areas: Perimeter, Interior, and Bedrooms.
Home (Perimeter) arming is for when you are staying inside but
want the comfort of knowing the exterior doors and windows are
armed.
Sleep (Perimeter and Interior) arms all areas except those near
bedrooms and nighttime areas.
Away (Perimeter, Interior, and Bedrooms) arms all three areas
for when you leave the building and no one is left inside.
Regardless of which mode is programmed, much of the operation
is similar. Throughout this guide, any differences between the
systems are noted for your convenience.
Arming Functions
Arming:Duringarming,thesystemveriesthatalldoors,windows,
and other protection devices to be armed are in normal condition.
If everything is normal, the system arms. If there is a problem on
one or more burglary zones, the keypad displays the problem and
allows you to correct the problem or bypass those zones.
If the problem can be corrected by closing a door or window, do
not bypass the zone. Instead, correct the problem and try arming
again. If the problem cannot be corrected, you can bypass the zone
or wait until the zone can be repaired by a service technician. A
bypassed zone is ignored by the system during the armed period.
In some cases the keypad might display FRONT DOOR - FAULT.
The keypad may then display PRIORITY ZONE, which is a zone that
cannot be bypassed. The problem on the zone must be corrected
before the system can be armed.
After making your arming selection, the keypad displays any zones
that are currently bypassed. These zones remain bypassed until
the system is armed and then disarmed. Any 24-hour zones in a
faulted condition also display.
Armed Message: After completing all bypasses or correcting zone
faults, the areas selected are armed.
ForAll/PerimetersystemsthekeypadbrieydisplaysALL SYSTEM
ON if all areas in the system are arming or PERIMETER ON if only
selected areas are arming.
For Home/Away or Home/Sleep/Away systems the keypad displays
ALL SYSTEM ON if all areas in the system are arming, HOME SYSTEM
ON or SLEEP SYSTEM ON if only selected areas are arming.
Arming and Disarming XT30/XT50 User’s Guide 13
Exit Delay: The keypad then displays the exit delay time as it counts
down. If the entire system has been armed, your system beeps the
exit delay tone at eight-second intervals until the last 10 seconds
when the keypad beeps at three-second intervals. After exiting the
building, if you re-enter during the countdown the exit countdown
restarts, allowing additional time to then disarm or again exit the
building during the countdown. This restart can occur only one
time. When the exit delay time ex pires, all disarmed zones are
armed. If your system uses a keyswitch to arm an area, the exit
delay time does NOT count down on the keypad display.
When you arm both the Perimeter and Interior to leave the building
but then you do not exit by the time the exit delay ends, the
system automatically arms but the interior area(s) will remain
disarmed because you have not exited.
Should you exit the building and the door does not close properly,
your system may be programmed so that when the exit delay
countdown ends, then the entry delay starts and the bell will sound
to alert you to the situation. Enter your user code to stop the bell
and disarm the system. Rearm the system, exit the building, and
make sure the door is securely closed.
DIALING . . . Message: If your system is monitored, it may
be programmed to wait for the arming report to be sent to the
monitoring station before displaying the armed mes sage. (See
ArmingReportbelow.)Thisveries that the armingmessagewas
received by your monitoring station. While the system waits, the
display reads DIALING.... If the report is received, the keypad
buzzes for one second and displays the armed message. If the
report is not received, the keypad displays LOCAL ALARM ONLY
before displaying the armed message.
Arming Report: Your system may be pre-programmed at installation
to send arming or zone bypass reports to a central station.
Key Fob Arming
Press the key fob button programmed for Arming or Toggle (Arm/
Disarm) button. A Red LED two-second acknowledgement indicates
All System On. A Green/Red two-second acknowledgement indicates
System On with some areas armed.
Key Fob Disarming
Press the key fob button programmed for Disarming or Toggle
(Arm/Disarm) button. A Green LED two-second acknowledgement
indicates All System Off.
Area System Arming
Area Assignment: Your security system is programmed into separate
areas. The number of areas and their names are listed in the back
of this guide.
Arming or Disarming: You can arm and disarm all areas at one time or
each area individually. You can only arm or disarm areas authorized
for your user code.
All or Selective Arming: After entering your user code, the system
allows you to arm either all of the areas to which you have access
or one or more selected areas. If you choose to arm all areas, the
system begins verifying that all zones in those areas are in a good
condition. If you choose to arm selected areas, the system prompts
you to choose the areas you want to arm.
Loading...
