Digital Innovations Advanced Disc Repair System User Manual

USER'S GUIDE

Printed in U.S.A.

Form# LA062A1

Service and Warranty Information

LIFETIME WARRANTY

The Digital Innovations “Doctor Series” Advanced Disc Repair System is warranteed for life. If your device fails to perform to specifications for any reason, simply return your device directly to Digital Innovations, and we will repair or replace your unit at no cost. This lifetime warranty does not apply to resurfacing wheels, resurfacing fluid, fluid bottles, drying cloths, or felt buffing squares. Some restrictions apply outside the United States.

THIS WARRANTY IS IN LI EU OF ALL OTHER WARRANTIES, EXPR ESSED OR IMPLIE D, INCLUDING WARRANTIE S OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PUR POSE, AND NO PERSON OR REPRESENTATIVE IS AUTHORIZED TO ASSUME FOR THE COMPANY ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF TH IS PRODUCT.

THIS WARRANTY EXCLUDE S INCIDENTAL OR CONSEQUENTIAL DAMAGE S ARISING FROM THE USE OF THIS PRODUCT.

Some states in the U.S. do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you. This warranty gives you specific legal rights and you may also be entitled to other legal rights required by your state.

For more information on any or all of these tips, as well as troubleshooting suggestions

and Frequently Asked Questions, visit our website,

www.digitalinnovations.com

Patents #5,423,103 and #5,964,650

Digital Innovations, LLC • Arlington Heights, IL • Email: sales@digitalinnovations.com

Phone (Customer Support) 1-888-SMART-58 (Hours: 8:30 AM to 4:00 PM, CST Monday-Friday)

Getting StartedIntroduction

Congratulations! You’ve purchased the world’s leading disc repair solution. Digital Innovation’s “Doctor Series” Advanced Disc Repair System uses patented-radial wheel technology to quickly and easily fix most scratched optical discs including music CDs, DVDs, game discs, photo discs and data CD-ROMs. Your “Doctor Series” Advanced Disc Repair System will help your discs to maintain their optimal play condition for years to come!

Tips

Your “Doctor Series” Advanced Disc Repair System is proven to repair the primary causes of skipping and distortion in music, DVD, photo, data and game discs.

We have put together the following helpful hints and tips to ensure the optimal results to your disc repair. If after following

and reviewing this information, you are not completely satisfied, please call us at 1-888-SMART-58, between 8:30 am and 4:00 pm CST Monday through Friday. We want to hear from you!

Key Features and Benefits

• Safe and easy to use

• Effective-patented design fixes virtually any scratched disc

• Convenient desk top design

• Unique vertical disc load and ejection feature

• Integrated cloth and bottle storage

• Lifetime guarantee

Repair System Includes:

1- Resurfacing Unit 1- Resurfacing Wheel 1- Base 1- Disc Resurfacing Fluid Bottle 1- Drying Cloth 1- Felt Buffing Square 1- User’s Guide

Please be sure to register your

new device on-line at

www.digitalinnovations.com

Note: To ensure optimal repair for your damaged discs, please read all instructions thoroughly!

Disc

Disc Holder

Resurfacing Wheel

Storage for

Fluid Bottle,

Drying

Cloth, Felt

Buffing

Cloth

Base

Crank

Handle

1. Assemble Disc Repair

System by first snapping on base of Resurfacing Unit. Attach crank-handle with screw provided.

4. Gently insert disc into top of Repair System’s disc slot with play-side of disc facing Resurfacing Wheel.

2. Finish System assembly by inserting Resurfacing Wheel into Resurfacing Unit, ensuring that side with protruding center faces inward toward device.

Turn crank handle clockwise until disc makes one complete revolution. Disc moves at slower rate than crank handle. Respray the disc and repeat the process until the disc has made a second complete rotation.

3. Generously spray entire play-side of damaged disc (the opposite side of disc label), using provided Resurfacing Fluid. Resurfacing Fluid is completely safe and environmentally-friendly.

6. To remove disc, gently turn the crank handle counter clockwise. Remove any remaining moisture with Drying Cloth.

IMPORTANT!!! Place disc (play-side up) on protected flat surface. Using Felt Buffing Square, buff resurfaced, dry disc thoroughly. Buffing restores the disc’s shiny appearance, and ensures optimal disc performance. Scratches do not have to be removed completely for the disc to play perfectly.

When not in use, the Drying Cloth, Felt Buffing Square and Resurfacing Fluid Bottle can be stored conveniently inside provided storage tube and then placed inside device as shown.

Note: The Advanced Disc Repair System will not repair severe damage such as gouges and deep scratches, label side damage and warping

•The final buffing step will help prevent new problems and ensures best repair results. You can buff as hard as you want, as it will not harm the disc. Store buffing square as recommended to keep it clean and free from debris which could cause scratches. Replacement felt is available from your local retailer or directly from Digital Innovations.

•A disc’s play-side is usually the “shiny” side and the label side is the “dull” side.

•To remove and replace a Resurfacing Wheel:

- If a disc is in the Disc Slot, remove it.

- Gently pull the existing Resurfacing Wheel from the Resurfacing Unit. To do this, pull wheel away from wheel hub with

fingers and remove.

- Insert new Resurfacing Wheel, ensuring that protruding center of wheel is facing inward. Rotate wheel to align hub and

wheel and press firmly to seat.

• If the disc is not completely repaired on the first try, repeat until completely fixed or no further improvement is evident. If the disc still skips, your disc player may need cleaning or repair. Test with a disc that you know is not damaged.

•Discs with label side damage cannot be repaired by any method. To identify label side damage:

- Scratches visible on the label side of a disc are always due to label-side damage, but the reverse is not always true. Label

side-damage can look like play-side damage when viewed straight-on from the play-side. Here’s how to check:

- Method #1- Hold the disc a foot or so from a light source with the play (shiny) side facing you. If you can see through a

scratch, that scratch is definitely on the label side. If you can’t see through the scratch, it is probably on the play-side. Use Method #2 to be sure.

- Method #2- Tilt disc so you are looking at the scratch from an angle If the scratch has a reflection in the surface of the disc

then the scratch is on the play-side. If not, the scratch is on the label side.

• Circumferential scratches (curved scratches that lie in a direction around the disc) are more likely to cause problems than radial scratches (That run from inside center to outside rim of disc).

• Store the Doctor Series Disc Repair System in a dust-free environment at room temperature. If it is stored in a warmer or cooler temperature, allow it to return to room temperature before using.

• It is very important to keep discs wet during the resurfacing process, or discs may become damaged.

•To maximize resurfacing life, rinse wheel under cold water after each use.

•The same disc can be repaired multiple times

• Use only exact replacement parts and accessories as specified by Digital Innovations, as using not recommended parts may cause irreparable damage to the unit and disc.
