Image Moments
8” and 5.7” Digital Photo Frame
User ’s Guide
Digital Foci, Inc. reserves the right to make improvements and/or changes to the products and
programs described in this User’s Guide at any time without notice. Please read the entire
User’s Guide before operating the device.
Digital Foci, Inc. assumes no responsibility for errors or omissions in this User’s Guide. Nor
does Digital Foci, Inc. make any commitment to update the information contained herein.
Trademarks
Image Moments and Digital Foci are trademarks of Digital Foci, Inc.
All names and products mentioned within this document are registered trademarks of their
respective companies.
©2008 Digital Foci, Inc. All rights reserved. This publication is intended for sole use by the
owner of the associated device. Neither this publication nor any part of this publication may
be printed and distributed, electronically distributed, reproduced, translated, or reduced to any
other electronic medium or machine readable form without the prior written permission of
Digital Foci, Inc.
Digital Foci, Inc., 3111 Via Mondo, E. Rancho Dominguez, CA 90221 USA
Limited Warranty
As the original purchaser of this product, you receive these warranties from Digital Foci,
Inc.
Your Image Moments (hereafter referred to as “Device”) will be free from defects in
material and workmanship and will perform in substantial compliance with your user
documentation accompanying Device for one year from the purchase date providing proper
use of Device.
Your warranty rights will be honored so long as you read and follow your user
documentation for all aspects of operating Device. Any unauthorized or improper use of
Device may cause your warranty to become void.
If there is a problem or defect with your Device, please contact Digital Foci, Inc.
Disclaimer
This limited warranty is the only warranty Digital Foci, Inc. makes for Device. To the
extent allowed by Law, no other warranty applies, whether expressed, implied, or statutory,
including any warranty of merchantability, of fitness for a particular purpose, or of
non-infringement. This warranty does not cover accidental damage, wear and tear, or
consequential or incidental loss. Under no conditions is Digital Foci, Inc. liable for loss of
or damage to, a computer; nor loss of, or damage to, programs, records, or data; nor any
consequential or incidental damages, even if Digital Foci, Inc. has been informed of their
possibility.
Additional Rights
Some states or countries do not allow exclusion or limitation of incidental or consequential
damages, or limitations on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or country to country.
Caring for Image Moments
To keep Image Moments in good condition and working properly,
follow these basic guidelines:
• Do not drop, jar, bump, shock or expose Image Moments to
severe vibration.
• Do not operate or store Image Moments in dusty environments.
• Do not leave Image Moments under direct sunlight, in a parked
car, or in other situations where the temperature may be above
140°F (60°C).
• To prevent risk of heat buildup, place Image Moments in a well
ventilated location.
• To prevent risk of short circuit and damage, do not expose Image
Moments to liquids, precipitation, or moisture.
• To avoid bodily injury or damage to internal components, do not
take apart Image Moments.
• Never force insertion of the memory card if it does not insert
smoothly. Instead, examine to see if the memory card orientation
and slot is correct.
• Use only power adapters and cords provided by the manufacturer.
Image Moments
User’s Guide
Page iv
Table of Contents
1. Welcome!.......................................................................................................1
1.1. General Features......................................................................................................1
1.2. Image Moments 6 (IMT-063) ..................................................................................3
1.3. Image Moments 8 (IMT-083) ..................................................................................5
2. Getting Started..............................................................................................7
2.1. Placing Image Moments..........................................................................................7
2.2. Powering Image Moments.......................................................................................7
2.3. Using Control Buttons.............................................................................................8
2.4. Using Remote Control .............................................................................................9
2.5. HOME Screen - Main Navigation Screen............................................................11
2.6. Inserting Memory Cards.......................................................................................13
2.7. Copying Files to Internal Memory.......................................................................14
3. Setting Up Image Moments........................................................................17
3.1. Setting Playback Options......................................................................................19
3.2. Setting Clock Options............................................................................................24
3.3. Setting Screen Options ..........................................................................................26
3.4. Setting Language....................................................................................................26
3.5. Viewing System Settings........................................................................................26
4. Enjoying Photos .........................................................................................27
4.1. Viewing Photos in Icon View and List View ........................................................27
4.2. Selecting Photos to Display ...................................................................................30
4.3. Playing Photo Slideshow........................................................................................31
4.4. Pausing Slideshow, Scrolling Photos Manually, Zooming, Rotating Photos....34
4.5. Deleting Photos.......................................................................................................36
4.6. Sorting Photos........................................................................................................36
5. Enjoying Music...........................................................................................37
5.1. Selecting Music Files to Play.................................................................................38
Image Moments
User’s Guide
Page v
5.2. Playing Music.........................................................................................................39
6. Enjoying Photo Slideshow with Music......................................................40
6.1. Playing a Photo Slideshow with All Music Files..................................................40
6.2. Playing a Photo Slideshow with Music from a Specific Folder .........................40
7. Enjoying V ideo............................................................................................41
7.1. Selecting Vi deo Files to Play..................................................................................41
7.2. Playing Videos........................................................................................................42
8. Playing from Photos & Video Mode..........................................................43
9. Using Folder View (to Access and Manage Folders and Files)...............44
9.1. Navigating in Folder View.....................................................................................45
9.2. Playing Files from a Specific Folder.....................................................................45
9.3. Deleting Files or Folders........................................................................................46
9.4. Renaming a File or Folder ....................................................................................46
9.5. Creating a New Directory/Folder.........................................................................46
10. Managing Playlists.....................................................................................47
10.1. Adding Entries to a Playlist ..................................................................................47
10.2. Playing a Playlist....................................................................................................47
10.3. Changing the File Sequence of a Playlist.............................................................48
10.4. Removing an Entry from a Playlist......................................................................49
10.5. Renaming a Playlist ...............................................................................................49
10.6. Creating a New Playlist.........................................................................................49
10.7. Deleting a Playlist...................................................................................................50
10.8. Setting Auto-Start Playlist.....................................................................................50
11. Additional Features....................................................................................51
11.1. Updating Firmware ...............................................................................................51
11.2. Changing Frame Orientation................................................................................51
11.3. Connecting Image Moments to External Speakers.............................................51
11.4. Tying down Image Moments with Security Cable..............................................52
Image Moments
User’s Guide
Page vi
11.5. Mounting Image Moments on the Wall (Image Moments 8 Only)....................53
11.6. Changing Outer Frame & Mat (Image Moments 8 only)..................................54
11.7. Creating Your Own Custom Frame (Image Moments 8 only)...........................56
12. Tips and Techniques...................................................................................58
12.1. Utilizing Auto-S tart Feature..................................................................................58
12.2. Utilizing Memory Source Select Feature.............................................................58
12.3. Using Playlist to Create Virtual Collections........................................................58
12.4. Organizing your Photos by Folders/Events.........................................................59
12.5. Organizing Your Files to Play in a Specified Order............................................60
12.6. Displaying a Microsoft PowerPoint Presentation...............................................60
13. Frequently Asked Questions ......................................................................61
14. Troubleshooting and Technical Support...................................................64
15. Digital Foci LCD Display Pixel Policy......................................................66
16. Appendix – Image Moments Technical Specifications.............................67
17. Regulatory Compliance..............................................................................69
Image Moments
User’s Guide
Page vii
Image Moments
User’s Guide
Page 1
Version 1.0.1-R0
1. Welcome!
Congratulations on purchasing Image Moments – Digital Photo Frame.
This section describes product features of the Image Moments series and
the specific details about Image Moments 6 and Image Moments 8.
1.1. General Features
Screen and Sound Quality:
• Leading technology LCD with LED backlight.
• High-quality stereo speakers with frequency response range of
300-20,000 Hz, resulting in deep and rich sounding audio.
• Audio output to external speakers for special events.
Memory Sources:
• 450 MB internal memory.
• Built-in memory card slots (3) provide native support for:
1) CF
2) SD/HC Card, MMC, xD-Picture Card
3) Memory Stick, MS PRO, MS Duo, MS PRO Duo
(* Supports mini-SD, RS-MMC, miroSD, MMCmicro, M2 with adapter.)
• Copies photos directly from memory cards to Internal Memory
without needing a computer.
• USB 2.0 connection for transferring photos between your computer
and device.
• Memory Source Select allows you to select any combination of a
single or multiple memory sources for playback.
• File management features:
Organize, copy, delete, rename files and folders; sort files by name or
date; create new folders; copy between memory cards and Internal
Memory.
Image Moments
User’s Guide
Page 2
Version 1.0.1-R0
Playback Options:
• Selective playback: Navigate and select specific photos and videos
from all available memory sources to playback.
• Folder structure: Select specific folders to playback folder contents
as a collection.
• Versatile playback modes: Select to playback slideshow by photo
only, video only, both photo and video, or photo with music.
• On-device Playlist management: Create, edit, and playback unique
Playlists of favorite photos in desired sequence directly on the device.
• Advanced multimedia format support:
o Image formats – JPG, BMP, TIFF, GIF, RAW image files* from a
wide selection of DSLR cameras
(* See
Section 16 Appendix – Technical Specifications for details.)
o Audio formats – MP3, AAC, WMA
o Video formats – MJPEG, MPEG-1, MPEG-4 SP
• Automatic photo orientation based on EXIF data: Photos will be
automatically rotated to the correct orientation based on the EXIF data
captured by the camera.
• Landscape and portrait positioning with auto-rotate orientation
sensor: Photos will automatically be displayed in the correct
orientation according to landscape or portrait positioning of the device.
• Automatic photo slideshow with adjustable time intervals, multiple
transition effects, and random option.
• Multiple photo viewing options: Zoom, pan, rotate photos, view
EXIF information, and view photos as thumbnails.
• Automatic on/off timer for scheduled operation with 3 schedule
settings available.
• Versatile control options: Operate device by onboard joystick and
buttons or wireless remote control.
Physical Design:
• Tension hinged easel leg allows adjustment for optimal display angle.
• Lanyard fixture for tethering device in public areas to prevent theft.
Image Moments
User’s Guide
Page 3
1.2. Image Moments 6 (IMT-063)
1.2.1. Image Moments 6 Unique Features
• 5.7” VGA (640 x 480) digital LCD with pixel density of 140 PPI
(Pixels per Inch)
• Elegant two-tone, mirror-polished chrome finish
• Small footprint allows for versatile placement
1.2.2.
Package contents
• Image Moments 6
• Remote control
• AC power adapter
• User’s Guide
• Quick Start Guide
Version 1.0.1-R0
Image Moments
User’s Guide
Page 4
1.2.3. Device layout
Front View
Side View
Remote Control Sensor
Digital LCD Display Area
Bottom View
Memory Card
Slots
Joystick & Control
Buttons
Easel Leg
Power LED
Indicator
Security Lock Slot
Power Adapter
Jack
Audio Out Jack
Speakers
USB Port to
Computer
Power Button
Reset Button
Version 1.0.1-R0
Image Moments
User’s Guide
Page 5
1.3. Image Moments 8 (IMT-083)
1.3.1. Image Moments 8 Unique Features
• 8” SVGA (800x640) digital LCD with high contrast ratio of 500:1
• Brackets for easy wall-mounting in both landscape and portrait
orientation
• Hinged memory card door hides memory cards from view
• Proprietary interchangeable frame & mat design
1.3.2.
Package contents
• Image Moments 8
• 3 interchangeable mats
• Remote control
• AC power adapter
• User’s Guide
• Quick Start Guide
Version 1.0.1-R0
Image Moments
User’s Guide
Page 6
1.3.3. Device layout
Front View
Side View
Remote Control Senso
r
Interchangeable Frame
Digital LCD Display Area
Bottom View
Memory Card
Slots
Joystick & Control
Buttons
Speakers
Easel Leg
Wall Mounting
Brackets
Frame Mounting
Clips
Card Slot Door
USB Port to
Computer
Interchangeable Mat
Power LED
Indicator
Power Adapter Jack
Audio Out Jack
Power Button
Security Lock Slot
Reset Button
Version 1.0.1-R0
Image Moments
User’s Guide
Page 7
Version 1.0.1-R0
2. Getting Started
2.1. Placing Image Moments
Image Moments can be placed in either landscape or portrait orientation.
Extend the Easel Leg by pivoting it away from the device. If you would
like for Image Moments to have a steeper viewing angle, adjust the Easel
Leg to be closer to the device.
Tip: Be careful not to set the Easel Leg too close to the device as this will make Image
Moments unstable and increase the possibility of it tipping over.
2.2. Powering Image Moments
1. Plug the supplied AC power adapter to the AC Adapter Jack on the
bottom-right corner of the device under the Easel Leg.
2. Connect the AC power adapter to a wall socket.
Note: The AC power adapter supports a universal voltage range of 100~240V.
3. Turn on the device by pressing the Power Button on the back of the
device or on the Remote Control. --- The Power LED will turn green
and the Digital Foci splash screen will appear while Image Moments
initializes and powers on.
4. Turn off Image Moments by pressing and holding for 5 seconds the
Power Button on the back of the device or on the Remote Control. --Image Moments will briefly show a message saying “Device will turn
off.” before powering down.
Image Moments
User’s Guide
Page 8
2.3. Using Control Buttons
Operate Image Moments by using the control buttons on the device or
the Remote Control. Note that the buttons may have different functions
in different operation modes.
Image Moments Control Buttons & Joystick Layout
V
alue
Decrease
Play/Pause Menu
V
alue
Increase
Directional
Joystick &
Select Button
Control Buttons Function
- / +
- Folder navigation to move Up/Down directory levels
- Skip to Previous/Next page
- Value Decrease/Increase
- Volume Down/UP
- Zoom Out/In
Joystick
|
4 Directional buttons: Tilt the joystick in
up/down/left/right directions to move the cursor.
Enter/Stop/Select button: Press center of the joystick
to:
- Execute action
- Select/deselect highlighted item
- Stop playback and return to selection screen
MENU
Show/Close Menu
PLAY/PAUSE
Start or Pause playback
Version 1.0.1-R0
Image Moments
User’s Guide
Page 9
2.4. Using Remote Control
Follow these instructions to prepare Remote Control for first use:
1. Remove the Remote Control from the packaging.
2. Slide out the battery tray on the bottom of the Remote Control.
3. Insert the supplied battery (CR2025 – 3 volts) into the battery tray
with text side facing up.
4. Slide battery tray back into Remote Control. --- The Remote Control
is ready for use.
Tip: For best performance, point the Remote Control towards the Remote Control
Sensor at the bottom-left corner on the front of Image Moments.
Remote Control Button Layout
Toggle
Info Display
Repeat
Toggle
Random
Toggle
Value
Increase/
Decrease
Change
Transition
Effect
Directional
Control Pad
Go to HOME
Go to Playlist
Power
On/Off
Toggle
Date/Time
Go to
Setup
Show/Close
Menu
Play/Pause
Enter/Stop/
Select
Version 1.0.1-R0
Image Moments
User’s Guide
Page 10
Version 1.0.1-R0
Control Buttons Function
POWER
Turn on and off device
PLAYLIST
Go to Playlist screen
HOME
Return to HOME screen
REPEAT
Toggle repeat on/off option
TRANSITION
Toggle transition effect
INFO
Toggle display option (Counter/File name/Both/None)
RANDOM
Toggle random on/off option
MENU
Show/Close Menu
CONTROL PAD
4 Directional buttons: Tilt the joystick in
up/down/left/right directions to move the cursor.
Enter/Stop/Select button: Press center of the joystick
to:
- Execute action
- Select/deselect highlighted item
- Stop playback and return to selection screen
PLAY/PAUSE
Start or Pause playback
-/ +
SELECT
- Folder navigation to move Up/Down directory levels
- Skip to Previous/Next page
- Value Decrease/Increase
- Volume Down/UP
- Zoom Out/In
SETUP
Go to Setup screen
CLOCK
Toggle clock display (Time/Time and Date/None)
Image Moments
User’s Guide
Page 11
2.5. HOME Screen - Main Navigation Screen
The diagram below shows the Image Moments HOME screen.
Browse Mode:
Select to view files from Playback Sources by
Photo, Video, Photo/Video, Music, or Folder View
Device Management:
Go to File Copy, Playlist Manager,
or Setup screens
Playback Sources:
Select desired memory source(s)
to Browse and playback
HOME Screen - Navigation Keys
Previous
Navigation
Section
Previous
Section
Select
Item
Next
Section
Cursor
Right
Cursor
Left
Next
Navigation
Section
N/A
N/A
Version 1.0.1-R0
Image Moments
User’s Guide
Page 12
2.5.1. Selecting Browse Mode
From the Browse Mode Navigation Section, you can select the desired
browsing mode among: Photo, Video, Photo/Video, Music, or Folder
View.
Files from the selected Playback Sources will be displayed depending on
the Browse Mode.
Browse Mode Image Moments will…
Show photos only
Video
Show videos only
Photo/Video
Show photos & videos
Music
Show music files only
Folder
Show Folder View – In Folder View, you can navigate
through the folder directory structure on the Internal
Memory and all inserted memory cards.
2.5.2. Selecting Playback Sources
On Image Moments, you can select to playback contents from a specific
memory source or any combination of multiple memory sources (from
Internal Memory and inserted memory cards) at the same time.
By default, all available sources (Internal Memory and inserted cards)
will be automatically selected and shown with an X in the Playback
Sources section.
The Internal Memory on Image Moments is represented by the Frame
icon
and the memory cards are represented by their respective
memory card icon. The Internal Memory and any memory cards inserted
in Image Moments will be automatically selected when the device is
powered on. If you insert a memory card into Image Moments when the
device is powered on, the card will also be automatically included in
Playback Sources.
To select memory sources to include in Playback Sources:
1. Navigate to Playback Sources on the HOME screen.
2. Press LEFT/RIGHT to highlight the desired memory source.
3. Press ENTER to select or deselect the highlighted memory source.
4. Press ENTER on “Select All” to select and deselect all available
memory sources.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 13
2.5.3. Accessing Device Management Features
The Device Management section allows you to access the File Copy
Mode, Playlist Manager, and Setup options on Image Moments.
Device Management This option lets you…
Copy to Frame
Access File Copy Mode (See Section 2.7.2 Copying Files
from Memory Card to Internal Memory.)
Playlist Manager
Manage and select Playlist for playback (See Section 10.
Managing Playlists)
Setup
Access Setup options (See Section 3 Setting Up Image
Moments.)
2.6. Inserting Memory Cards
For Image Moments 8 users, open the memory card door to access the
memory card slots.
Insert your memory card in the designated memory card slot with the
memory card label side facing towards the back of Image Moments as
shown in the following drawing.
MS/MS Pro/MS Duo
SD / MMC
Compact Flash
xD
CF Card Slot Eject Button
Note: To remove cards from the CF card slot, carefully press the square black button at
the bottom of the card slot. The CF card will be ejected as the button is depressed.
Warning: Do not force the memory card in the slot if it does not slide in smoothly.
Instead, remove the card, check the card orientation and slot, and try again.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 14
Version 1.0.1-R0
2.7. Copying Files to Internal Memory
You can copy photos, videos, and music files to the Internal Memory on
Image Moments from your computer by using the USB connection or
from your memory cards by using the memory card slots on the device.
2.7.1.
Copying Files from Computer to Internal Memory
Connect Image Moments to your computer using the included USB cable.
Image Moments will display a computer “Connect” icon on its screen to
indicate that it is connected to your computer.
Once connected, your computer will automatically recognize Image
Moments and show four devices on your computer:
• Three of the devices will be ‘Removable Device’ corresponding to
the three memory card slots on Image Moments.
• One of the devices will be the Image Moments Internal Memory
with device label ‘Frame’.
For Windows users, the devices will be listed in this sequence (Drive
letters may vary based on your specific computer configuration):
(F:) CompactFlash memory card slot
(shown as a removable disk)
(G:) Secure Digital/MMC/xD memory card slot
(shown as a removable disk)
(H:) Memory Stick/MS PRO/MS Duo memory card slot
(shown as a removable disk)
(I:) Image Moments Internal Memory (default label is ‘Frame’)
Note: The Image Moments Internal Memory and memory card icon labels may vary
and can be renamed.
For Mac users, an icon for ‘Frame’ will appear on the computer desktop.
Icons for the memory card slots will only appear if a memory card is
present.
These devices will function like any other storage device on your
computer. You can transfer photos, music, and video files from your
computer to the Internal Memory of the Image Moments by copying the
files into the device labeled ‘FRAME’. Similarly, you can transfer files to
any memory card that is present by copying the files into the
corresponding device for the memory card.
Image Moments
User’s Guide
Page 15
Version 1.0.1-R0
2.7.2. Copying Files from Memory Card to Internal Memory
You can copy photo, music, and video files from your memory card to the
Internal Memory on Image Moments directly without needing a computer.
1. Insert the memory card containing the files you want to copy.
2. From the HOME screen, select Copy to Frame under Device
Management to access the File Copy screen (see opposite page).
3.
Select files/folders to copy – On the Source side of the File Copy
screen, select the folder(s) or file(s) you would like to copy.
Press + to enter into a folder and press – to go up one
directory/folder level from the current folder location.
Press RIGHT/LEFT to go to the next/previous page.
A preview of the highlighted file will appear in the preview box.
Press ENTER to select the file for copying.
The total number of files selected and the total size will be
displayed on the top-right corner of the screen.
Note: If you select a folder to copy, the entire folder contents will be copied
including all its files and subdirectories.
4. Select Target Location – Once you have selected the files you want to
copy, navigate to Target side of the File Copy screen by pressing
MENU and selecting “
Go to Target”.
Navigate to the folder location to copy the selected files.
Note: Your files will be copied into the folder that is showing in the Target
side of the File Copy screen.
Press PLAY to start the copy task.
A confirmation message, “Copy selected item(s) to Target
location?” will pop up. Click “
Yes” to confirm.
Upon completion, you will see a confirmation message showing
the number of files copied and total size of data copied.
5. Repeat Steps 3 and 4 to copy more files. Press MENU to navigate
between Source Location and Target Location.
6. To exit from File Copy screen, press MENU and select “
Exit File
Copy” or press HOME on the remote control.
Note: You can also copy from memory card to memory card or from Internal Memory
to memory card by selecting the desired Source and Target locations.
Image Moments
User’s Guide
Page 16
File Copy Screen Description
Preview of highlighted
image on Source side
Copy Source:
Select files to copy
Number and size of files
selected on Source side
Copy Target:
Select folder location to copy files
File Copy Screen - Navigation Keys
Navigate Up
One Folder
Level
Cursor
Up
Select/
Deselect
Cursor
Down
Next
Page
Previous
Page
Navigate Down
One Folder
Level
Show/Close
Menu
Start copy of
selection to
Target Location
Version 1.0.1-R0
Image Moments
User’s Guide
Page 17
3. Setting Up Image Moments
From the HOME screen, press DOWN until navigation is at the Device
Management section. Next, press RIGHT to highlight Setup and press
ENTER to select it. Alternatively, you can press SETUP on the Remote
Control to access the Setup menu.
The following screen shows the main page of the Setup screen:
Version 1.0.1-R0
Image Moments
User’s Guide
Page 18
Setup - Navigation Keys
Cursor
Up
Version 1.0.1-R0
1. Press UP/DOWN to move the cursor up and down.
2. Press RIGHT to navigate to the next menu level of the highlighted
option.
3. When a setup option value is highlighted, press ENTER to select the
value for changing. The highlight of the selected value will turn white,
indicating that you can change the value.
4. Press UP/DOWN (or – /+) to change the value. When you are done,
press ENTER to accept your setting. --- The highlight will return to
the standard blue color.
5. To exit Setup, press LEFT until the Exit option is highlighted and
press ENTER. Or, you can press HOME on the Remote Control to
return to the HOME screen.
Value Down
Change
Value
Option
Back
Option
Select
Cursor
Down
Value Up
N/A
N/A
Image Moments
User’s Guide
Page 19
Version 1.0.1-R0
3.1. Setting Playback Options
With Playback Options highlighted, press RIGHT to move the cursor to
Slideshow Settings. Press RIGHT again to enter Slideshow Setting
options.
The following screen shows the setup options under Slideshow Settings:
SETUP MENU – Slideshow Settings –
SUBMENU SELECTION Description
Image Moments will automatically start
playing all photos on the Internal Memory
in a slideshow when powered on.
Video
Image Moments will automatically start
playing all videos on the Internal Memory
when powered on.
Photo/Video
Image Moments will automatically start
playing all photos and videos on the
Internal Memory when powered on.
Playlist
Image Moments will automatically start
playing the first Playlist (by alphabetical
order) when powered on.
Auto-Start
Mode
Off
Image Moments will not automatically
start a slideshow when powered on. The
HOME screen will be displayed.
Slideshow Time
Interval
1, 5,
10, 30 sec
1, 3, 5, 10, 30 min,
1, 2, 3, 4, 5, 6,12,
24 hrs
Time interval between photo transitions in
the slideshow.
Transition
Effects
No Effect, Fly In,
Erase, Blocking,
Random
Transition effect for slideshow.
ON
Music will play in the background with
slideshow – music to be provided by user.
Background
Music
OFF
Music will not play in the background with
slideshow.
ON
Play photos in random order.
Slideshow
Random
OFF
Play photos in sequential order (default is
by alphabetical order of file name).
Image Moments
User’s Guide
Page 20
Version 1.0.1-R0
SETUP MENU – Slideshow Settings –
SUBMENU SELECTION Description
ON
Slideshow will repeat in a continuous
loop.
Slideshow
Repeat
OFF
Slideshow will stop at the end of the last
photo and will return to selection screen.
None
No photo information will display during
slideshow.
Counter
Display sequence number and total
number of photos during slideshow.
File Name
Display the file name of the photo during
slideshow.
Information
Display
Both
Display both counter and file name during
slideshow.
* Underlined bold selections indicate the default settings.
3.1.1. Setting Auto-Start Options
The Auto-Start feature will let you set Image Moments to automatically
start a photo slideshow when it is powered on.
You can choose among the following modes for the Auto-Start feature:
Photo, Video, Photo & Video, Playlist, and Off.
For the Auto-Start Photo/Video/Photo & Video options, Image Moments
will automatically start a slideshow and play all of the Photos or Videos or
Photos & Videos
on its Internal Memory when powered on.
For the Auto-Start Playlist option, Image Moments will automatically start
a slideshow of the first Playlist (by alphabetical order) of all Playlists
when powered on.
For the Auto-Start Off option, Image Moments will not start a slideshow
when powered on. The HOME screen will be displayed.
Image Moments
User’s Guide
Page 21
Version 1.0.1-R0
To change the Auto-Start option:
1. From the Setup screen with Playback Options highlighted, press
RIGHT to move the cursor to Slideshow Settings.
2. Press RIGHT again to enter Slideshow Setting options. Auto-Start
Mode will be highlighted.
3. With Auto-Start Mode highlighted, press ENTER. The selection will
change to a white highlight, indicating that you can change the value.
4. Press UP/DOWN (or – /+) to change the value; in this case, Photos,
Videos, Photos & Videos, Playlist, or Off.
5. When you have selected the desired value, press ENTER again to
accept your setting.
3.1.2.
Setting Slideshow Playback Options
You can also change the slideshow playback settings including: Slideshow
Time Interval, Transition Effect, Background Music, Random, Repeat, and
Information Display.
Refer to the chart in Section 3.1 Setting Playback Options for more details
about each of these options.
Note: You will also be able to change the settings while the photo slideshow is playing.
Refer to Section 4.3.1 Changing Slideshow Options.
Image Moments
User’s Guide
Page 22
Version 1.0.1-R0
3.1.3. Setting Photo Playback Options
The following screen shows the setup options under Photo Settings:
SETUP MENU – Photo Settings –
SUBMENU SELECTION Description
Fit Screen
Image Moments will automatically
resize the photo for best display without
changing the aspect ratio**.
Fill screen
Image Moments will stretch the photo
horizontally and vertically to fill the
letterbox (black space). The photo may
become distorted.
Max Visible
Image Moments will automatically
rotate the photo if a different orientation
will fill more of the screen.
Photo Display
Fit Width
Image Moments will rescale the photo
so that the width of the photo extends
to the width of the screen.
ON
Display EXIF information*** and
histogram when playing photos.
EXIF info
OFF
Hide EXIF information*** and
histogram when playing photos.
* Underlined bold selections indicate the default settings.
** Most digital cameras will capture photos with a 4:3 aspect ratio. This figure
determines the length and height of the photo. The aspect ratio of the Image
Moments screen is 4:3 and will display 4:3 photos full screen without any distortion
or letterboxing. Some cameras capture photos in 3:2 or 16:9 aspect ratios. Photos of
these aspect ratios will show a black letterbox when displayed as Fit Screen.
*** EXIF information is additional information associated with each photo that
your digital camera captures when you take the photo. It identifies information such
as digital camera model, camera settings, exposure, resolution, date, and time.
Image Moments
User’s Guide
Page 23
Version 1.0.1-R0
3.1.4. Setting V ideo Playback Options
The following screen shows the setup options under Video Settings:
SETUP MENU – Video Settings –
SUBMENU SELECTION Description
Video Scale
50%, 100%,
Fit Screen,
Fill Screen
Select display resolution for video
playback.
* Underlined bold selections indicate the default settings.
3.1.5. Setting Music Playback Options
The following screen shows the setup options under Music Settings:
SETUP MENU – Music Settings –
SUBMENU SELECTION Description
ON
Play music in random order.
Music Shuffle
OFF
Play music in sequential order (default
is by alphabetical order of file name).
Repeat Single
Repeat the current song.
Repeat All
Repeat all songs in a continuous loop.
Music Repeat
OFF
Stop playing after last song is finished.
* Underlined bold selections indicate the default settings.
Image Moments
User’s Guide
Page 24
Version 1.0.1-R0
3.2. Setting Clock Options
3.2.1.
Setting System Time
To access Clock Settings:
1. From the Setup screen, press UP/DOWN until Clock Setting is
highlighted.
2. Press RIGHT to move the cursor to Date Time.
3. Press RIGHT again to enter Date Time option.
You will see 3 options: Clock set, Date Set, and Clock Display.
To set the time:
1. With Clock Set highlighted, press ENTER. The selection will change
to a white highlight, indicating that you can change the value.
2. Press UP/DOWN (or – /+) to change the hour. When the correct hour
is selected, press RIGHT to move to the minute field.
3. With the minute field highlighted, press UP/DOWN (or – /+) to
change the minute setting. Press RIGHT to move to the AM/PM field.
4. Press UP/DOWN (or – /+) to change between AM and PM.
5. When you are finished, press ENTER to accept your setting.
To set the date:
1. Navigate to Date Set and press ENTER. The selection will change to
a white highlight, indicating that you can change the value.
2. Press UP/DOWN (or – /+) to change the value, and LEFT/RIGHT to
navigate between the different date fields.
3. When you are finished, press ENTER to accept your setting.
Image Moments
User’s Guide
Page 25
Version 1.0.1-R0
To set Clock Display setting:
The Clock Display setting will determine whether to show the time or time
and date information on the screen during the slideshow.
You can choose among the following options:
•
Time Only: Displays Time on the bottom right-hand corner of the
screen while playing the slideshow.
•
Time and Date: Displays both Tim e and Date on the bottom
right-hand corner of the screen while playing the slideshow.
•
Hide: Does not display either Time or Date while playing the
slideshow.
3.2.2.
Setting Schedule On/Off Timer
Before setting the Schedule On/Off timer, make sure that the system
clock is set to the correct time and date. (See Section 3.2.1 Setting System
Time.)
To access Schedule On/Off Timer:
1. From the Setup screen, press UP/DOWN until Clock Setting is
highlighted.
2. Press RIGHT to move the cursor to DateTime.
3. Press DOWN to move the cursor to Schedule, and press RIGHT again
to enter Schedule.
You can set three different schedules on Image Moments.
To set Schedule On/Off Timer:
Navigate to one of the three available Schedules and press ENTER. The
selection will change to a white highlight, indicating that you can change
the value. Press UP/DOWN (or – /+) to change the value, and press
LEFT/RIGHT to navigate between each field.
1.
Enable: Select ON to make the schedule active. Select OFF to make
the schedule inactive.
2.
On T ime: Set the desired time that the device will turn on.
3.
Off Time: Set the desired time that the device will turn off.
4.
Mode: Select Once to have the schedule activate only once and then
automatically become inactive. Select EveryDay to have the schedule
activate everyday and remain active.
Image Moments
User’s Guide
Page 26
Version 1.0.1-R0
5. After the schedule is set according to your requirements, press
ENTER to accept your setting.
3.3. Setting Screen Options
1. Under Setup, move the cursor to highlight Screen Options. Press
RIGHT to move the cursor to Brightness and press ENTER.
2. Press UP/DOWN (or – /+)
to change the brightness value between 1
and 10. The brightness of the screen will be adjusted real-time.
3. When you finish setting the desired brightness, press ENTER to
accept your setting.
3.4. Setting Language
1. Under Setup, move the cursor to highlight Language. Press RIGHT to
move the cursor to Language and press ENTER.
2. Use UP/DOWN (or – /+) to change the language.
The available options are: English, Japanese, Spanish, and French.
3. When you finish selecting the desired language, press ENTER to
accept your setting.
3.5. Viewing System Settings
Under System, you can view technical information of the device such as
total Internal Memory size, current firmware version, and technical
support contact information.
Image Moments
User’s Guide
Page 27
Version 1.0.1-R0
4. Enjoying Photos
The following image file formats are supported by Image Moments:
File Format Details
JPEG Baseline
TIFF 1 & 8 bit Grayscale; 8, 16, & 24 bit Color
BMP Monochrome, 8 bit Color
GIF Standard format
RAW Refer to Section 16 Appendix – Technical
Specifications for details on RAW formats supported.
When Photo Mode is selected from the HOME screen, Image Moments
will scan through all of the selected Playback Sources* and show only
the supported photo files. By default, all of the images files will be listed
in alphabetical order regardless of which memory location they are
stored.
* Navigate to Playback Sources on the HOME screen and select a specific memory
source or any combination of multiple memory sources (including Internal Memory
and inserted memory cards) that you would like to include. For more information,
see Section 2.5.2 Selecting Playback Sources.
4.1. Viewing Photos in Icon View and List View
Selecting Photos from the HOME screen will take you to the Photo Icon
View. You can toggle between Icon View and List View by pressing the
MENU and selecting the desired view option under View Mode.
Press PLAY from either Icon View or List View to start the photo
slideshow. The slideshow will play according to your slideshow settings.
Note: The cursor must be highlighting a selected photo when you press PLAY for the
slideshow to start. If the cursor is highlighting an unselected photo, nothing will
happen when you press PLAY.
Image Moments
User’s Guide
Page 28
Photo Icon View:
In this view, all available photos will be shown in a 4 by 3 matrix of
photo thumbnails (icons). You can browse through the photos and select/
deselect the photos to be included in the slideshow.
The following screen layout shows the Photo – Icon View.
Total number of files selected
Sort mode: File name, File size, Date
- Location of highlighted file
-Memory sources selected
Current selection:
Shown in dashed box
Selected:
Shown in solid box
- Photo X of total # photos
- Page X of total # pages
Clock
Photo Icon View - Navigation Keys
Skip to
Previous Page/
Exit to HOME
Cursor
Up
Select/
Deselect
Cursor
Down
Cursor
Right
Cursor
Left
Skip to
Next page
Show/Close
Menu
Play
Selected Files
Version 1.0.1-R0
Image Moments
User’s Guide
Page 29
Photo List View:
In Photo List View, photos are listed in a vertical list according to the
selected Sort Mode. As you browse though each photo, a larger photo
thumbnail will display on the right side along with file information.
The following screen layout shows the Photo – List View.
Total number of files selected
Sort mode: File name, File size, Date
- Location of highlighted file
- Memory sources selected
Selected: Shown with X in the box
- Photo X of total # photos
- Page X of total # pages
Clock
Current selection:
Shown with highlight
Preview of
highlighted photo
File information
Photo List View - Navigation Keys
Skip to
Previous Page/
Exit to HOME
Cursor
Up
Select/
Deselect
Cursor
Down
Next
Page
Previous
Page
Skip to
Next Page
Show/Close
Menu
Play
Selected Files
Version 1.0.1-R0
Image Moments
User’s Guide
Page 30
Version 1.0.1-R0
Menu Options under Icon View & List View:
Press MENU to access the Menu screen. Press UP/DOWN to browse
through selection, and press ENTER to make your selection.
Tip: Press MENU again to cancel menu selection.
MENU – PHOTO THUMBNAIL / LIST VIEW
SUBMENU SELECTION Description
Icon/List V iew
Toggle between Icon View & List View
Only Show Music
Change Browse Mode to Music
Only Show Video
Change Browse Mode to Video
View Mode
Show Photo/Video
Change Browse Mode to Photo/Video
File Name
Sort by file name
File Date
Sort by file date*
Sort Mode
File Size
Sort by file size
Select All
Select all files
Deselect All
Deselect all files
Selection
Copy Selection
Jumps to File Copy with selected items in Source
Delete Current
Delete highlighted file
Delete
Delete Selected
Delete all selected files
Playlist Add to Playlist
Add current file to Playlist
* The file creation date will be used for sorting, not the photo taken date.
4.2. Selecting Photos to Display
On Image Moments, you can browse through your photos and select
specific photos to display in a slideshow.
By default, all photos are selected. In Icon View, the selected photos are
shown with a solid blue box around the photo thumbnail. In List View,
the selected photos are shown with a check mark in the checkbox.
1. To select or deselect a photo, press ENTER with photo highlighted.
2. To select / deselect all photos, press MENU, select
Selection, and
select
Select All / Deselect All.
Once you have made the desired selection of photos to view, press PLAY
with cursor highlighting a selected photo to start the slideshow.
Image Moments
User’s Guide
Page 31
4.3. Playing Photo Slideshow
From either Photo Icon View or Photo List View, press PLAY to start the
slideshow. This will play a slideshow of all the photos you selected.
Note: The cursor must be highlighting a selected photo when you press PLAY for the
slideshow to start. If the cursor is highlighting an unselected photo, nothing will
happen when you press PLAY.
To stop the slideshow, press ENTER and navigation will return to the
previous Icon View or List View screen.
The following screen layout shows the photo slideshow screen with all
available display options.
EXIF Info & Histogram
File name
Clock
File counter:
Photo X of total # photos
Photo Playback Screen - Navigation Keys
Volume Down
Previous
Stop
Slideshow
Next
Interval
Increase
Interval
Decrease
Volume Up
Show/Close
Menu
Pause/Resume
Slideshow
Version 1.0.1-R0
Image Moments
User’s Guide
Page 32
Version 1.0.1-R0
4.3.1. Changing Slideshow Options
While the photo slideshow is playing, you can change the slideshow
intervals, transition effects, information display, view mode, repeat
setting, and random setting.
Changing slideshow intervals:
You can adjust the slideshow interval among:
1, 5, 10, 30 seconds; 1, 3, 5, 10, 30 minutes; and 1, 2, 3, 4, 5, 6,
12, 24 hours.
Press RIGHT or LEFT to increase or decrease the time interval
between photo transitions.
Changing transition effects:
You can change the transition effects among:
No Effect, Fly In, Ease, Blocking, and Random.
Press MENU and select
Transition Effect to access these options.
Next, scroll to the desired transition effect and press ENTER to
select the option.
You can also use the TRANSITION button on the Remote
Control to change the transition effect.
Changing display settings (information display):
You can select among the following display settings:
o
Show EXIF: Displays EXIF information and histogram. EXIF
information is additional information associated with each
photo that your digital camera captures when you take the
photo. It identifies information such as digital camera model,
camera settings, exposure, resolution, date, and time.
o
Show File Counter: Displays the sequence number of the photo
displayed relative to total number of photos in the slideshow.
o
Show File Name: Displays the file name of the photo.
Press MENU and select Display Settings to access these options.
Scroll to the desired display setting and press ENTER to turn
each option on or off.
You can also use the INFO button on the Remote Control to
toggle the File Counter and File Name settings.
Image Moments
User’s Guide
Page 33
Version 1.0.1-R0
Changing view mode:
You can change the view mode among:
Fit Screen, Fill Screen, Max Visible, and Fit Width.
o
Fit Screen: The image will be automa tically resized to fit the
screen while keeping its original aspect ratio. If the aspect ratio
of the photo is not the common 4:3 aspect ratio, the photo will
be displayed in a letterbox view.
o
Fill Screen: The image will be stretched horizontally and
vertically to fill the screen while eliminating any black bars
showing on top/bottom or sides of the screen. This will cause
the image to be distorted if it is not in a 4:3 aspect ratio.
o
Max Visible: The image will be rotated if a larger area can be
shown.
o
Fit W idth: The image will be rescaled so that the width of the
photo extends to the width of the screen.
Press MENU and select
View Mode to access these options. Next,
scroll to the desired view mode and press ENTER to select the
option.
Changing slideshow repeat options:
Press REPEAT on the Remote Control to toggle between
Slideshow Repeat On and Repeat Off.
Changing random option:
Press RANDOM on the Remote Control to toggle between
Random On and Random Off.
You can also change the slideshow settings under Setup. Refer to Section
3 Setting Up Image Moments for details.
4.3.2.
Photo Slideshow with Music
If you have music files on any of the selected memory locations, you can
have music playing in the background while playing a photo slideshow.
For detailed instructions on how to play music with your slideshow, refer
to Section 6 Enjoying Photo Slideshow With Music.
Image Moments
User’s Guide
Page 34
4.4. Pausing Slideshow, Scrolling Photos Manually, Zooming,
Rotating Photos
During the slideshow, you can pause the slideshow to view a particular
photo. While the photo is paused, you can manually scroll through the
other photos in the slideshow, zoom and pan to see the specific detail of
the photo, and rotate the photo.
Photo Playback Screen Pause Mode - Navigation Keys
Zoom Out
Previous
Return to
Thumbnail
Next
Interval
Increase
Interval
Decrease
Zoom In
Show/Close
Menu
Resume
Slideshow
4.4.1. Scrolling Through Photos Manually
While the slideshow is paused, you can manually scroll through the
photos at your full control.
1. Press PLAY/PAUSE to pause the slideshow.
2. Next, press Down/UP to go to the next/previous photo.
3. Press PLAY again to resume the slideshow.
4.4.2.
Zooming Photos
From the Pause Mode, you can zoom and pan the photo.
1. While the slideshow is paused, you can zoom in and out on the
photos by pressing + / – . A ‘zoom window’ will appear that
indicates the zoomed display relative to the entire photo.
2. While zooming, you can use the directional joystick or control pad
on the Remote Control to pan to a specific part of the photo.
3. Press ENTER to cancel the zoom and return to the normal view.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 35
The following screen layout shows the View Photo – Zoom View.
Zoom window
File counter:
Photo X of total # photos
File name
Clock
Photo Playback Screen Zoom Mode - Navigation Keys
Zoom Out
Pan
Up
Cancel
Zoom
Pan
Down
Pan
Right
Pan
Left
Start Zoom/
Zoom in
Show/Close
Menu
Resume
Slideshow
Version 1.0.1-R0
Image Moments
User’s Guide
Page 36
Version 1.0.1-R0
4.4.3. Rotating Photos
Photos on Image Moments will be displayed according to the photo
orientation information available in the EXIF data captured with the
photo. Most digital SLR cameras will have this photo orientation
information. Photos taken with portrait orientation will be automatically
rotated when displayed. If this information is not captured with the photo,
the photo will be displayed in its original orientation.
From the Pause Mode, you can manually rotate the photo.
1. Press MENU and select
Rotate.
2. Select CW Rotate to rotate the photo 90 degrees clockwise. Select
CCW Rotate to rotate the photo 90 degrees counter-clockwise.
When the slideshow transitions to the next photo, the rotated photo will
return to its original orientation the next time it is displayed.
Note: Rotating the photo will only change the display on the Image Moments screen
and will not alter your original photo file.
4.5. Deleting Photos
You can delete photos from Photo Icon View or List View.
1. Navigate to and select the photo(s) you would like to delete. To select
or deselect an image, move the cursor to the image and press ENTER.
Note: To select / deselect all photos, press MENU, select Selection, and select
Select All / Deselect All.
2. Once the photo(s) to delete are selected, press MENU and select
Delete.
3. Select
Delete Current to delete the individual photo that is currently
highlighted. Select
Delete Selected to delete all selected photos.
4. At the confirmation pop-up, ‘Delete?’ select
Yes and press ENTER to
confirm the deletion.
4.6. Sorting Photos
By default, photos will be sorted by File Name. You can choose to sort
the files by File Date (created date) or File Size in ascending order.
1. From Icon View or List View, press MENU and select
Sort Mode.
2. Next, select the desired Sort Mode.
The screen will refresh and display the photos by the selected sort mode.
Image Moments
User’s Guide
Page 37
Version 1.0.1-R0
5. Enjoying Music
The following music file formats are supported by Image Moments:
File
Extension
Audio
Codec
Sampling
Rate
Bit Rate Notes
.mp3 MP3 Max 48KHz Max 384kbps
CBR/VBR
MPEG-1 L1/2/3
MPEG-2 L1/2/2.5
.wma WMA Max 44KHz Max 192kbps
CBR
WMA v7/8/9
.aac/.m4a AAC Max 44KHz Max 320kbps
CBR/VBR/ABR
MPEG-4 AAC
You can play music through the built-in speakers or by connecting Image
Moments to a stereo or set of external speakers through the Audio Out
Jack.
When Music Mode is selected from the HOME screen, Image Moments
will scan through all of the selected Playback Sources* and show only
the supported music files. By default, all of the music files will be listed
in alphabetical order regardless of which memory location they are
stored.
* Navigate to Playback Sources and select a specific memory source or any
combination of multiple memory sources (including Internal Memory and
inserted memory cards) that you would like to include. For more information,
see Section 2.5.2 Selecting Playback Sources.
Image Moments
User’s Guide
Page 38
5.1. Selecting Music Files to Play
You can select specific music files from the entire list for playback.
By default, all music files are selected. To select or deselect a specific
music file, scroll to the file and press ENTER. To select / deselect all files,
press MENU, select
Selection, and select Select All / Deselect All.
Note: By default, all music files will be sorted by File Name. You can also choose to
sort the files by File Date (created date) or File Size in ascending order. You can do
so by pressing MENU, select Sort Mode, and select the desired Sort Mode. The
screen will refresh and display the music files by the order of the selected criteria.
Music List Screen - Navigation Keys
Skip to
Previous Page
Cursor
Up
Select/
Deselect
Cursor
Down
Next
Page
Previous
Page
Skip to
Next Page
Show/Close
Menu
Play
Selected Files
Once you have made the desired selection of music files, press PLAY to
start playing the music.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 39
5.2. Playing Music
While the music is playing, you can perform the following functions:
Music Playback Mode - Navigation Keys
Volume Down
Previous
Song
Return to
Music List
Next
Song
Forward
Scan
Reverse
Scan
Volume Up
Show/Close
Menu
Pause/Resume
Music
As the song is playing you can press MENU to access different playback
options:
Sequence: Select Sequence to change the play mode. Turn Shuffle
on to play songs in a random order; turn it off to play songs in the
order shown on the Music List screen. You can also select desired
play modes among
Repeat All, Repeat Single, and Play All.
Equalizer: Select the equalizer mode from:
Normal, Bass, Classic, Dance, Live, Rock, and Treble.
Time Display: Select Time Display to change desired time display
between
Time Elapsed and Time Remaining for the song.
Press ENTER to stop the music and return to the Music List screen.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 40
Version 1.0.1-R0
6. Enjoying Photo Slideshow with Music
You can have music playing in the background while playing a photo
slideshow. To do so, you will need to do two things:
1. Copy one or more music files of the supported music file formats to
the Internal Memory or a memory card. Make sure the memory
source containing your music files is selected under Playback Sources
on the HOME screen.
2. Set the Background Music setting in Setup > Playback Options >
Slideshow Settings to ON. Refer to Section 3.1 Setting Playback
Options for details.
As long as these two conditions are satisfied, music will play along with
your photo slideshow.
6.1. Playing a Photo Sli deshow with All Music Files
Browse to Photo Mode and start playing a photo slideshow as you
normally do. All available music files will play in the background with
your photo slideshow.
If you have set Auto-Start Option to Photos, Image Moments will
automatically start playing a photo slideshow along with all music files
on the Internal Memory when powered on.
6.2. Playing a Photo Sli deshow with Music from a Specific Folder
You can also play specific music files with different photo collections to
customize your slideshow by organizing your files in folders.
In Folder View Mode, you will be able to select a specific folder and play
only the photos and music files in that folder together as a collection.
For details on using Folder View, refer to Section 9 Using Folder View.
Note: If Background Music is set to ON but there is no music files in the folder,
Image Moments will play all music available on its Internal Memory along with the
photo slideshow.
Image Moments
User’s Guide
Page 41
Version 1.0.1-R0
7. Enjoying Video
The following video file formats are supported by Image Moments:
File Extension Video Codec Audio Codec Resolution
.mp4/.avi MPEG-4 SP
(Simple Profile)
MP3, AAC, PCM 720x480@30fps
.avi/.dat/.vob./.mpg MPEG-1 MP2 720x480@30fps
.avi/.mov MJPEG MP3, PCM 720x480@30fps
* Sample frequency (audio): 48 KHz
* Max bit rate (video): 8 Mpbs
* Max bit rate (audio): 1536 Kpbs
When Video Mode is selected from the HOME screen, Image Moments
will scan through all of the selected Playback Sources* and show only
the supported video files. By default, all of the video files will be listed
in alphabetical order regardless of which memory location they are
stored.
* Navigate to Playback Sources and select a specific memory source or any
combination of multiple memory sources (including Internal Memory and
inserted memory cards) that you would like to include. For more information,
see Section 2.5.2 Selecting Playback Sources.
7.1. Selecting Video Files to Play
Selecting Video from the HOME screen will take you to the Video Icon
View. You can toggle between Icon View and List View by pressing
MENU and select the desired view option under View Mode.
Video Icon View & List View
In Video Icon View Mode, you can view thumbnails of all the videos.
In Video List View, videos are listed by file name in a vertical list. As
you browse though each video, the video thumbnail will display on the
right side along with file information.
The Video Icon/List View is similar to the Photo Icon/List View. See
Section 4.1 Viewing Photos in Icon View and List View for more details.
By default, all video are selected. To select or deselect an video, move
the cursor to the video and press ENTER. To select / deselect all videos,
press MENU, select
Selection, and select Select All / Deselect All.
Image Moments
User’s Guide
Page 42
Note: By default, all videos will be sorted by File Name. You can also choose to sort
the files by File Date (created date) or File Size in ascending order. You can do so by
pressing MENU, select Sort Mode, and select the desired Sort Mode. The screen will
refresh and display the videos by the order of the selected criteria.
Once you have made the desired selection of videos to play, press PLAY
start playing the videos.
Note: The cursor must be highlighting a selected video when you press PLAY for the
slideshow to start. If the cursor is highlighting an unselected video, nothing will
happen when you press PLAY.
7.2. Playing Videos
While the video is playing, you can perform the following functions:
Video Playback - Navigation Keys
As the
Volume Down
Fast
Forward
Stop
Video
Rewind
Forward
Scan
Reverse
Scan
Volume Up
Show/Close
Menu
Pause/Resume
Video
video is playing press MENU to access different playback options:
Audio Mode: Select to play the audio as Stereo, Left Channel only,
or Right Channel only.
Video Scale: Select desired video display size. The available
options are –
50% displays the video as half of original resolution,
100% shows the video in its original resolution, Fit Screen*
enlarges the video to fit the full screen size while keeping the
aspect ratio the same,
Fill Screen** enlarges the video to fill the
box.
** Videos recorded in a letterbox style will still display in a letterbox.
entire screen even if the aspect ratio is changed.
* Videos with an aspect ratio other than 4:3 will be displayed in a letter
Version 1.0.1-R0
Image Moments
User’s Guide
Page 43
Version 1.0.1-R0
8. Playing from Photos & Video Mode
When Photos & Video Mode is selected from the HOME screen, Image
Moments will scan through all of the selected Playback Sources* and
show only the supported photos and videos. By default, all of the photos
and videos will be listed in alphabetical order regardless of which
memory location they are stored.
* Navigate to Playback Sources and select a specific memory source or any
combination of multiple memory sources (including Internal Memory and inserted
memory cards) that you would like to include. For more information, see Section
2.5.2 Selecting Playback Sources.
Note: By default, all photos and videos will be sorted by File Name. You can also
choose to sort the files by File Date (created date) or File Size in ascending order.
You can do so by pressing MENU, select Sort Mode, and select the desired Sort
Mode. The screen will refresh and display the photos and videos by the order of the
selected criteria.
You can select the specific photos and video to play just as you would
under Photo Mode or Video Mode. Once you have made the desired
selection of photos and videos to play, press PLAY button to start playing
the selection.
Note: The cursor must be highlighting a selected photo or video when you press
PLAY for the slideshow to start. If the cursor is highlighting an unselected photo or
video, nothing will happen when you press PLAY.
Note: When Background Music setting in Setup > Playback Options > Slideshow
Settings is set to ON, available music files will play in the background along with the
photos. When the video starts, Image Moments will stop playing the music file and
play the audio of the video. When the video finishes and the slideshow returns to a
photo, music will start over to play in the background from the first music file.
Image Moments
User’s Guide
Page 44
9. Using Folder View (to Access and Manage Folders and Files)
When Folder Mode is selected, Image Moments will show the Folder
View screen where you can navigate through the folder directory on the
Internal Memory and inserted memory cards.
As you move the cursor over each file, a preview image of the
highlighted file will show in the preview window on the screen.
The following screen layout shows the Folder View screen:
Total number of files selected
Sort mode: File name, File size, Date
Preview of highlighted file
- Photo X of total # photos
- Page X of total # pages
File information
Directory path
Folder View Screen - Navigation Keys
Navigate
Up One
Folder Level
Cursor
Up
Select/
Deselect
Cursor
Down
Next
Page
Previous
Page
Navigate
Down One
Folder Level
Show/Close
Menu
Play
Selected Files
Version 1.0.1-R0
Image Moments
User’s Guide
Page 45
Version 1.0.1-R0
9.1. Navigating in Folder View
When you enter the Folder View screen, you will be at the topmost level
(root level) of navigation. From this level, you will see a folder named
“Frame” and a folder for each inserted memory card. The folder named
Frame is the Internal Memory on Image Moments.
9.1.1.
Browsing Through Folders / Changing Directory Level
Navigating down one folder level
:
To show the contents of (navigate into) a specific folder, highlight the
folder and press the + button.
Note: If you select a folder by pressing ENTER with the folder highlighted, an X
will appear to the left of the folder to indicate that it is selected. When you navigate
into a selected folder, all the contents within that folder will automatically be
selected.
Navigating up one folder level:
To return to the previous folder level, either:
(1) Press the – button, or
(2) Navigate to the topmost icon that shows “…(Select to go up one
level)” and press ENTER.
9.1.2. Navigating Within a Folder
1. Press UP/DOWN to move cursor up/down.
2. Press LEFT/RIGHT to skip to previous/next page.
3. Press ENTER to select or deselect an item.
9.2. Playing Files from a Specific Folder
You can select a specific folder and play some or all of the files in that
folder as a collection.
1. Navigate to the folder you wish to play and select the folder by
pressing ENTER. A check mark will appear to the left of the folder
to indicate that it is selected.
2. Next, press the + button to enter the folder. You will see that all files
in that folder are selected. Fine tune your selection by deselecting
files you do not want to include.
3. Press PLAY with the cursor highlighting a selected file to start
playing the files you selected in that folder.
Image Moments
User’s Guide
Page 46
Version 1.0.1-R0
Note: If Background Music is set to ON in Setup, all the music files in the folder
will play in the background with the slideshow. If there are no music files in the
folder, Image Moments will play all music available on its Internal Memory in the
background.
Note: You can only play the actual files located in that level of the selected folder.
Files in the subdirectories (files inside folders within the selected folder) will not
play.
9.3. Deleting Files or Folders
1. Select the file(s) or folder(s) you want to delete.
2. Press MENU and select Delete
.
3. Select Del ete Current to delete the individual file/folder that is
currently highlighted. Select Delete Selected
to delete all files/folders
selected.
4. At the confirmation message, ‘Delete?’ select Yes
and press ENTER
to confirm the deletion.
9.4. Renaming a File or Folder
1. Navigate to the file or folder you wish to rename.
2. With the file or folder highlighted, press MENU and select Rename
.
3. An on-screen keyboard will pop up. Use the directional keys to move
the cursor on the keyboard. Press ENTER to select each letter.
4. Select the (
) left-arrow to go back and make a correction.
5. Select the green checkmark (9) to accept the new file or folder name.
6. Select the red (U) to cancel the renaming.
9.5. Creating a New Directory/Folder
1. Navigate to the location where you want to create the new folder .
2. Press MENU and select New Directory
.
3. An on-screen keyboard will pop up. Use the directional keys to move
the cursor on the keyboard. Press ENTER to select each letter.
4. Select the (
) left-arrow to go back and make a correction.
5. Select the green checkmark (
9
) to accept the new file or folder name.
6. Select the red (U) to cancel the entry.
Image Moments
User’s Guide
Page 47
Version 1.0.1-R0
10. Managing Playlists
Image Moments supports user-created Playlists. You can create, edit, and
sequence multiple Playlists directly on the device and select a specific
Playlist to play.
Use the Playlist feature to create virtual collections of photos, music, and
videos to playback. One benefit of using the Playlist feature is that you
can have the same copy of a specific file included in different Playlists.
This will save you the trouble of making multiple copies of the same file
to include in each collection.
Note: The Playlist contains the locations of the files rather than the actual files. Make
sure the actual file is available on the Internal Memory or the inserted memory card
for the Playlist to play. If Image Moments cannot find a specific file, it will skip over
it and play the next available file.
10.1. Adding Entries to a Playlist
You can add entries to a Playlist from Folder View or any Icon/List
View.
1. Navigate to the file you want add to the Playlist so it is highlighted.
2. Press MENU and select Playlist
.
3. Select Add to Playlist
.
4. A selection of all Playlists list will pop up. Select the target Playlist
for the highlighted file and press ENTER to confirm the entry.
Note: By default, 5 Playlists named Playlist_1 to Playlist_5 are created on Image
Moments for your convenience. You can rename the Playlists (see Section 10.5) and
create new Playlists (see Section 10.6).
10.2. Playing a Playlist
1. From the HOME screen, select the Playlist Manager icon. Or, press
PLAYLIST on the Remote Control.
2. The Playlist Manager screen will display the available Playlists and
the number of entries in each Playlist.
3. Navigate to the Playlist you would like to play and press PLAY.
4. While the Playlist is playing, you can press MENU to access the
playback options.
5. To stop the slideshow, press ENTER to return to Playlist Manager.
Image Moments
User’s Guide
Page 48
Note: If Background Music is set to ON in Setup, all the music files in the Playlist
will play in the background with the slideshow. If there are no music files in the
selected Playlist, Image Moments will play all music available on its Internal
Memory in the background.
10.3. Changing the File Sequence of a Playlist
1. From the Playlist Manage screen, press ENTER to see the Playlist
Detail of the highlighted Playlist.
2. Navigate to the entry you want to re-sequence so it is highlighted.
3. Press + to move the selected entry up 1 position.
Press - to move the selected entry down 1 position.
The following screen layout shows the Playlist Detail screen:
Preview of highlighted file
- File X of total # files
- Page X of total # pages
File information
File name
Source location of file
Playlist Detail Screen - Navigation Keys
Move Entry
Down One
Position
Cursor
Up
Select/
Deselect
Cursor
Down
Next
Page
Previous
Page
Move Entry
Up One
Position
Show/Close
Menu
Play
Playlist
Version 1.0.1-R0
Image Moments
User’s Guide
Page 49
Version 1.0.1-R0
10.4. Removing an Entry from a Playlist
1. From the Playlist Manager screen, navigate to the Playlist you would
like to edit and press ENTER. This will take you to the Playlist Detail
screen.
2. Navigate to the entry you want to remove so it is highlighted.
3. Press MENU and select Playlist
.
4. Select Remove from List.
Note: The entry is only removed from the Playlist; the actual file will not be deleted.
10.5. Renaming a Playlist
1. From the Playlist Manager screen, navigate to the Playlist you would
like to rename.
2. Press MENU and select Rename
.
3. An on-screen keyboard will pop up. Use the directional keys to move
the cursor on the keyboard. Press ENTER to select each letter.
4. Select the (
) left-arrow to go back and make a correction.
5. Select the green checkmark (9) to accept the new file or folder name.
6. Select the red (U) to cancel the renaming.
10.6. Creating a New Playlist
1. From the Playlist Manager screen, press MENU and select New
Playlist.
2. An on-screen keyboard will pop up. Use the directional keys to move
the cursor on the keyboard. Press ENTER to select each letter.
3. Select the (
) left-arrow to go back and make a correction.
4. Select the green checkmark (9) to accept the new file or folder name.
5. Select the red (U) to cancel the entry.
Image Moments
User’s Guide
Page 50
Version 1.0.1-R0
10.7. Deleting a Playlist
1. From the Playlist Manager screen, navigate to the Playlist you would
like to delete.
2. Press MENU and select Delete
.
3. Select Del ete Current to delete the Playlist.
4. At the confirmation message, ‘Delete?’ select Yes
and press ENTER
to confirm the deletion.
Note: Delete a Playlist will only delete the Playlist and all its entries, the actual files
will not be deleted.
10.8. Setting Auto-Start Playlist
You can set Image Moments to automatically start playing a Playlist
when powered on. The Playlist that Image Moments will play in the
Auto-Start is the first Playlist by alphabetical order.
Note: To have Image Moments play a specific Playlist from Auto-Start, rename the
desired Playlist so that it appears at the top of the list in the Playlist Manager screen.
For details on how to set Auto-Start to Playlist, refer to Section 3.3.1
Setting Auto-Start Options.
Image Moments
User’s Guide
Page 51
Version 1.0.1-R0
11. Additional Features
Image Moments has many special features that will help you get the most
enjoyment out of it.
11.1. Updating Firmware
New versions of the Image Moments firmware will be periodically
released with improved features to further enhance your user experience.
Any available updates will be available for download from the Digital
Foci website support page.
Please make sure to register your Image Moments so that you will receive
product support emails regarding new firmware releases and other
important product information.
To register your product, go to:
www.digitalfoci.com/registration
Alternatively, periodically check the Digital Foci website
(
www.digitalfoci.com/support/) for the latest firmware update.
11.2. Changing Frame Orientation
Image Moments can be placed in either landscape or portrait orientation.
As with a traditional photo frame, the Easel Leg lets you position the
frame in both positions.
With its built-in auto-rotate orientation sensor, Image Moments will
automatically rotate the images so that they are displayed in the correct
orientation according to landscape or portrait positioning of the device.
11.3. Connecting Image Moments to External Speakers
In addition to enjoying audio from its built-in high quality stereo speakers,
you can also connect Image Moments to external speakers for special
events.
1. Plug in the plug from the external speakers to the Audio Out Jack
(next to the Power Adapter jack) on the back of Image Moments.
2. Adjust the Image Moments volume using the – / + buttons to achieve
the desired sound quality.
The sound from Image Moments will be played through the attached
speakers and the Image Moments speakers will be muted.
Image Moments
User’s Guide
Page 52
11.4. Tying down Image Moments with Security Cable
Image Moments has a built-in security lock slot that you can utilize to
prevent theft by tethering it down with a Kensington style lock and
security cable.
Security Lock Slot
IMT-063
Security Lock Slot
IMT-083
Version 1.0.1-R0
Image Moments
User’s Guide
Page 53
11.5. Mounting Image Moments on the Wall (Image Moments 8 Only)
Two sets of wall mounting brackets on the back of Image Moments 8
make it easy to hang Image Moments 8 on the wall in both landscape and
portrait orientation.
See diagram below for an illustration of the wall mounting bracket
placement.
Landscape Orientation Portrait Orientation
Wall Mounting Brackets
Landscape Orientation –
To mount Image Moments 8 on the wall in Landscape Orientation,
position the 2 mounting screws with centers 4 inches (10 cm) apart.
Portrait Orientation –
To mount Image Moments 8 on the wall in Landscape Orientation,
position the 2 mounting screws with centers 3 1/8 inches (8 cm) apart.
Note: The most effective screws are flat-head type screws with head diameter between
5 mm and 7 mm.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 54
11.6. Changing Outer Frame & Mat (Image Moments 8 only)
Image Moments 8 is designed with an easily removable outer frame and
interchangeable mats. In addition to the standard outer frame, you also get
three different mats in gray, cream, and black. The unique interchangeable
frame and mat design helps you create the best effect in matching Image
Moments with your décor.
Outer Frame –
To remove the outer frame
:
1. Place the device face down on a soft surface that won't scratch the
frame. We recommend using a towel or other soft padded cloth.
2. Depress both clips at the top of the frame to detach the main unit.
3. Lift and rotate the main unit from the top and remove it from the frame.
To replace/install the outer frame:
1. Position the main unit to receive the 2 tabs at the bottom edge by
inserting it at an angle with the bottom edge going in first. The 2 tabs on
the frame will fit into the 2 slots at the bottom of the main unit.
2. Rotate the top of the main unit down to fit the frame until the 2 clips at
the top snap into place.
3. Press each of the 2 clips firmly until you hear a clicking sound that
indicates the main until is clipped into the frame.
2 clips at
top edge
Removing & Installing Outer Frame
2 tabs at
bottom edge
Version 1.0.1-R0
Image Moments
User’s Guide
Page 55
Mat –
To remove the mat
:
Depress both clips at the sides of the mat to detach it from the main unit.
Lift the mat up from the main unit to remove it.
To install the mat
:
Place the mat on top of the main unit so that the 2 tabs on the mat fit into
the 2 clips on the main unit. Make sure that the hole for the Remote Control
sensor is at the lower right hand corner of the front of the main unit. Press
down the mat into the main unit until the 2 clips snap into place.
Mat clip
Mat clip
Changing the Mat
Version 1.0.1-R0
Image Moments
User’s Guide
Page 56
11.7. Creating Your Own Custom Frame (Image Moments 8 only)
The proprietary Adapter Ring design of Image Moments 8 gives you a
high degree of flexibility to customize your Image Moments 8 to match
any décor.
Premade interchangeable frames are available from Digital Foci and
authorized Image Moments retailers. Alternatively, your local custom
framer can make the frame of your choice with the Image Moments 8
Adapter Ring Kit.
Premade Frame Styles –
A06-012
A06-013
A06-014
A06-021
A06-022
A06-031
A06-041
A06-051
A06-061
A06-071
A06-081
A06-091
* Some styles may not be available at time of purchase.
Visit www.digitalfoci.com/image_moments to see all frame styles
available.
Version 1.0.1-R0
Image Moments
User’s Guide
Page 57
Version 1.0.1-R0
Custom Framing Option –
The proprietary Adapter Ring design of Image Moments 8 supports
limitless custom framing options. With the Image Moments 8 Adapter
Ring Kit, your local customer framer can fit any frame style to your Image
Moments 8.
For more information, email us at
service@digitalfoci.com or call toll-free
1-888-NOW-FOCI (669-3624).
Image Moments
User’s Guide
Page 58
Version 1.0.1-R0
12. Tips and Techniques
12.1. Utilizing Auto-Start Feature
Utilize the Auto-Start feature to have Image Moments automatically start a
photo slideshow when it is powered on. You can set it to Auto-Start and
play Photos, Videos, Photo & Videos, or a Playlist.
For the Auto-Start Photo/Video/Photo & Video options, Image Moments
will automatically start a slideshow and play all of the Photos or Videos or
Photos & Videos on the Internal Memory
of Image Moments.
For the Auto-Start Playlist option, Image Moments will automatically start
a slideshow of the first Playlist (by alphabetical order) of all Playlists.
Change the desired Auto-Start option under Setup > Playback Options >
Slideshow Settings according to your preference.
12.2. Utilizing Memory Source Select Feature
On Image Moments, you can select to playback files from a specific
memory source or any combination of available memory sources at the
same time. This gives you flexibility in how you organize your photos
and allows you full access to all memory sources.
By default, all available memory sources will be automatically selected.
Under Playback Sources section on the HOME screen, you can specify
which memory source(s) you would like to include.
For example, if you select CF as the only memory source and choose
Photo in Browse Mode, only the photos on the CF card will appear.
12.3. Using Playlist to Create Virtual Collections
You can use the Playlist feature on Image Moments to create collections of
specific photos and videos to playback. The benefit of using the Playlist
features is that you can have the same copy of a specific photo, video, or
music file included in different Playlists. This will save you the trouble of
making multiple copies of the same file to include in each collection.
To learn more about how to use the Playslist feature, see Section 10
Managing Playlists.
Image Moments
User’s Guide
Page 59
12.4. Organizing your Photos by Folders/Events
The Folder View Mode of Image Moments lets you browse and access
your files on the Internal Memory or memory cards by folder structure.
You can use this feature to view and play slideshows of only the contents
of a chosen folder.
By organizing your collection of files into separate folders, you will be
able to easily organize playback of specific sets of photos, videos, and
music to suit your needs.
A good way to organize your photos is to include a date code at the
beginning of each folder name. By doing this, you will be able to see your
folders on Image Moments in date sequence. As you collect years and
years of memories on your Image Moments Internal Memory or memory
card, you will be able to scan through them quickly by date to find exact
events for playback.
One recommendation to do this is to use the first four digits of the file
name to identify the year and month of the event. Then use the remainder
to identify the event so you can recognize and find it more easily.
Version 1.0.1-R0
YYMMeventname
Example:
By starting with the year first and then the month, Image Moments will be
able to list the folders starting from the earliest year and month to the most
recent.
Now you can easily identify the different photo collections you have and
select the photos you want to view.
Last 2 Digits of Year
2 Digits for Month
event description
Image Moments
User’s Guide
Page 60
Version 1.0.1-R0
12.5. Organizing Your Files to Play in a Specified Order
By default, Image Moments plays your files in alphabetical order. Photos
and videos on your memory card inserted directly into Image Moments
from your digital camera will play in the order they were taken.
If you want to arrange your photos so that they playback in a specific
sequence, you can use the computer to rename the files with some kind of
sequential naming pattern to match your desired playback sequence.
For instance, if you rename your files to start with 001, 002, 003, … ,
Image Moments will play the files in numerical sequence starting with the
lowest number first.
Alternatively, you can use alphabetical characters (I.e., A, B, C, …) to
organize your files.
Note: If you choose to do this, make sure that each file name has the same number of
characters in the name. You may need to fill in leading zeros to do this.
On Image Moments, you can also choose to sort files by File Date (created
date) and File Size.
12.6. Displaying a Microsoft PowerPoint Presentation
Image Moments can display your Microsoft PowerPoint presentations.
1. In PowerPoint with your presentation open, select Save As
from the
File menu and chose JPEG for the file type – PowerPoint will create a
folder and save each slide of your presentation as a JPEG file.
2. Copy the folder and the created JPEG slides to the Internal Memory
of Image Moments or to a memory card.
3. On Image Moments, navigate to the folder in Folder V iew Mode and
play the JEPG slides in that folder.
Note: PowerPoint will not add leading zeros to the file name of the JPEG files that it
creates. To make the presentation play in the correct order, you may need to manually
rename the files so all the slide file names all have the same number of characters.
(E.g., rename slide1.jpg to slide01.jpg to match slide10.jpg ~ slide99.jpg.)
Image Moments
User’s Guide
Page 61
Version 1.0.1-R0
13. Frequently Asked Questions
Questions about capacity, memory card, USB port:
How many photos can I store on Image Moments?
Image Moments has 450 MB built-in Internal Memory. Using
images with a resolution of 1024 x 768 (average file size under
150KB), you can store more than 3,000 images on Internal
Memory.
In addition, you can keep a dedicated memory card attached to
your Image Moments if you need more storage space. This way,
the number of photos you can display will not be limited by the
storage space on the Internal Memory.
Will I need a memory card adapter to access any of the supported
memory card formats?
You can directly insert into Image Moments memory cards of the
following formats:
1) CompactFlash
2) SD/HC Card, MultiMedia Card, xD-Picture Card
3) Memory Stick, MS PRO, MS Duo, MS PRO Duo
For microSD, MMCmicro, miniSD, RS-MMC, and M2 formats
you will need to use the adapter that came with the memory card.
Does Image Moments have a USB port for reading from a digital
camera or from a flash drive?
The USB port on Image Moments connects to your computer. It
does not connect to a flash drive or a digital camera.
I have photos stored on my computer. How do I go about displaying
those photos on Image Moments?
You can connect Image Moments to your computer via USB and
copy your photos from your computer onto the Internal Memory
of Image Moments.
Similarly, you can copy the photos from your computer to a
memory card using a card reader or using Image Moments and
play the memory card on Image Moments.
Image Moments
User’s Guide
Page 62
Version 1.0.1-R0
Questions about screen size, resolution, and display:
What is the screen size and resolution of the LCD screen?
Image Moments 8:
8” diagonal (6.4” x 4.8”) LCD screen with 800 x 600 (SVGA)
resolution.
Image Moments 6:
5.7” diagonal (
4.6” x 3.4”) LCD screen with 640 x 480 (VGA)
resolution.
What is the optimal resolution of photos to be played back on Image
Moments?
The recommended resolution for the images is the actual screen
resolution as indicated in the previous question. Please note that
images of higher resolution will be automatically resized for
display according to the screen resolution.
By resizing image that have a higher resolution than the screen
resolution, you will create smaller file sizes and will be able to
store more photos in on the Internal Memory or memory cards.
Alternatively, the zoom feature will provide sharper looking
zoomed images on higher resolution photos.
What is the aspect ratio of the screen? If I have photos with 3:2 or
16:9 aspect ratios, how will they be displayed on the device?
The aspect ratio on Image Moments is 4:3. If you have photos in a
3:2 or 16:9 aspect ratio, the photo will be displayed in a letterbox
with black bars on top and bottom of the screen in the default view
mode. There will be no rescaling or distortion of your photos.
If you want to eliminate the black bars on the top and bottom of
the screen, you can select View Mode: Fill Screen
. Under the Fill
Screen Mode, the image will be ‘stretched’ to fill the screen.
Please note that if you choose to do this, there will be distortion of
your 3:2 and 16:9 aspect ratio photos.
Can I adjust the screen brightness on Image Moments?
Yes, you can adjust screen brightness on the screen under Setup >
Screen Options.
Image Moments
User’s Guide
Page 63
Version 1.0.1-R0
Questions about slideshow and photo display options:
How can I adjust the slideshow interval?
You can change the slideshow interval during a slideshow
on-the-fly by tilting the joystick right or left or by pressing the
RIGHT/LEFT buttons on the Remote Control.
Available slideshow intervals times are:
1, 5, 10, 30 seconds; 1, 3, 5, 10, 30 minutes;
and 1, 2, 3, 4, 5, 6, 12, 24 hours.
How can I scroll through the photos manually?
During a photo slideshow, press PLAY/PAUSE to pause the
slideshow. Next, press DOWN/UP to select the next/previous.
Can I rotate photos on Image Moments? How does Image Moments
handle photos shot in portrait?
Photos on Image Moments will be displayed according to the
photo orientation information available in the EXIF data captured
with the photo. Most digital SLR cameras will have this photo
orientation information. Photos taken in portrait orientation will be
automatically rotated when it is displayed on Image Moments. If
the digital camera does not capture this information with the photo,
the photo will be displayed in its original orientation.
The built-in orientation sensor will automatically rotate all your
photos to the correct orientation when you change the positioning
of the Image Moments between landscape and portrait
orientations.
You can also manually rotate the photo on the screen. When you
have the picture on display, you can press MENU and select
Rotate
to rotate the picture by 90 degrees. Note that the rotated
image will return to its original orientation the next time you view
it. To retain the orientation settings for the pictures, you can rotate
the images in your computer and copy the edited images onto the
Internal Memory or the memory card.
Can I play music in the background while viewing photo slideshow?
To play music along with your photos slideshow, copy your music
(MP3, WMA, or AAC) files onto the Internal Memory or the
memory card and make sure that Background Music is set to ON
under Setup. Refer to Section 6 Enjoying Photo Slideshow with
Music for details.
Image Moments
User’s Guide
Page 64
Version 1.0.1-R0
14. Troubleshooting and Technical Support
I set Auto-Start to the Photo option. When the Image Moments turns
on and automatically starts the photo slideshow, I don’t see the photos
I have on the inserted memory cards.
For Auto-Start Photos/Videos/Photo & Videos options, Image
Moments will automatically start the slideshow of all
Photos/Videos/Photo & Videos on the Internal Memory only
.
I made a selection of the photos I want to see and press PLAY, but the
slideshow won’t start.
When you press PLAY to start a slideshow or a music file, the
cursor must be highlighting a select file in order for the device to
start playing.
I have music files on the Internal Memory and/or memory cards, but I
can’t get them to play along with my photo slideshow.
Make sure you turn Background Music to ON under SETUP >
Playback Options > Slideshow Settings.
Also, refer to Section 6 Enjoying Photo Slideshow with Music for
details.
My photos are displayed with black bars on the screen.
The aspect ratio on Image Moments is 4:3. If you have photos in a
3:2, 16:9, or other aspect ratio, the photo will be displayed in a
letterbox with black bars on top and bottom of the screen in the
default view mode. There will be no rescaling or distortion of your
photos.
If you want to eliminate the black bars on the top and bottom of
the screen, you can select View Mode: Fill Screen
. Under the Fill
Screen Mode, the image will be ‘stretched’ to fill the screen.
Please note that if you choose to do this, there will be distortion of
your photos.
Image Moments will not recognize my memory card.
Check to see that your memory card is inserted in the correct slot
and with the correct orientation.
Image Moments
User’s Guide
Page 65
Version 1.0.1-R0
The Remote Control doesn’t seem to work properly.
The IR Sensor is located at the bottom left corner of the frame.
Make sure to point the Remote Control towards the sensor to
improve the reception.
The Remote Control may be low on battery. Refer to Section 2.4.
Using Remote Control for more details on the battery.
The slide interval is set to 1-Second, but it seems to take longer than 1
second to change the picture. Why is it like this?
Photos of larger file sizes will take more time to load. Selecting
1-Second does not mean that the next photo will appear in exactly
1 second. It means that the next photo will start the loading
process after 1 second. Large files may take longer than 1 second
to display.
Technical Support
If you have any questions about using your Image Moments, please
contact Digital Foci, Inc. technical support at
support@digitalfoci.com or
call (888) NOW-FOCI / (888-669-3624).
Image Moments
User’s Guide
Page 66
Version 1.0.1-R0
15. Digital Foci LCD Display Pixel Policy
This section defines the different types of pixel anomalies seen on LCD displays, explains
why such anomalies occur, and states standard pixel policy for warranty service. In order to
qualify for repair or replacement under warranty, the number of pixel anomalies on your
LCD panel must exceed these industry standards.
Why Pixel Anomalies Occur
Active-matrix LCD technology uses rows and columns of addressable locations (pixels) that
render text and images on the display. Each pixel location has three subpixels in the primary
colors of red, green, and blue that allow the image to be rendered in full color. Each subpixel
has a corresponding transistor responsible for turning the subpixel on and off.
The standard of production techniques for LCD manufacturing today cannot guarantee an
absolutely fault-free display. During the production process, it is not uncommon for one or
more pixels to be fixed in an unchanging state. The visible result is a pixel or subpixel with a
fixed color that does not change or one that is dark and does not light at all. In most
situations, these fixed pixels are unnoticeable and do not detract from the display quality or
usability.
Types of Pixel Anomalies
There are two types of pixel anomalies: bright pixel anomaly and dark pixel anomaly.
Bright pixel anomaly: A bright pixel anomaly is defined as a pixel or subpixel that is always
lit or ‘on’. The bright pixel anomaly will constantly show as red, green, blue, or white.
Dark pixel anomaly: A dark pixel anomaly is defined as a pixel or subpixel that is always
dark or ‘off’. The dark pixel anomaly will always be dark and will not show any color.
Standard Pixel Policy
Digital Foci warrants that any LCD display with an unacceptable number of pixel anomalies
will be repaired or replaced. To qualify for repair or replacement under warranty, the number
of pixel anomalies on the TFT LCD panel must exceed these industry standards.
Pixel Policy Standards Chart
Anomaly Type
Number of
anomalies
Bright pixel 2
Dark pixel 3
Any combination of bright and dark pixels 4
Technical Support
If you notice your display contains more than the number of pixel anomalies as stated on the
above chart, please contact Digital Foci, Inc. tech support at support@digitalfoci.com
.
Image Moments
User’s Guide
Page 67
Version 1.0.1-R0
16. Appendix – Image Moments Technical Specifications
Product Model IMT-063 IMT-083
LCD screen 5.7" color digital TFT LCD 8.0” color digi tal TFT LCD
Screen resolution 640 x 480 pixels (VGA) 800 x 600 pixels (SVGA)
Pixel pitch 0.1815 x 0.1815 (in mm) 0.2025 x 0.2025 (in mm)
Pixel density (pixel per 140 PPI 125 PPI
Picture aspect ratio 4:3
Effective display area 5.7” diagonal (4.6” x 3.4”) 8.0” diagonal (6.4” x 4.8”)
Contrast ratio 300:1 500:1
Brightness (cd/m2) 220 nits (cd/m2) 250 nits (cd/m2)
LCD backlight unit LED
Viewing angle 140 degrees H / 100 degrees V 140 degrees H / 120 degrees V
Internal Memory support 450 MB
Memory card supported
CompactFlash, SD Card, SDHC Card, MultiMedia Card,
xD-Picture Card (Standard & M-type),
Memory Stick, MS PRO, MS Duo, MS PRO Duo
(miniSD, RS-MMC with adapter)
USB USB 2.0 Device (for computer connection)
OS compatibility Windows Vista/XP/2000, Mac 10.01 & later
Image format support JPEG (up to 35 MP), RAW (*select DSLR – see list below), BMP, TIFF,
GIF - Displays EXIF information & histogram
Video format suppor
t
MJPEG, MPEG-1, MPEG-4 SP (Simple Profile
)
Music format suppor
t
MP3, AAC, WM
A
Photo viewing options Zoom, pan, rotate, thumbnail view, photo slideshow with random
Memory source select Yes (single or multiple memory sources
)
A
uto-rotate image Yes (from EXIF data
)
Slideshow intervals User adjustable time interval (1 second up to 24 hours)
Transition eff ects Yes
File management Yes (copy, delete, rename files and create new folders)
Image Moments
User’s Guide
Page 68
Version 1.0.1-R0
Product Model IMT-063 IMT-083
Playlist management Create, edit, rename, delete playlists, change playback sequence
Built-in stereo speakers Yes (2W + 2W); 28 mm diameter cone stereo speakers; Frequency
A
udio output jack Yes
Interchangeable frames No Yes (Interchangeable frames &
Wall mountable No Yes
Portrait & landscape Yes, with auto-rotate sensor
Controls On-device and wireless remote control operation
On/off timer Yes
Lock slot for security
Yes
Power
A
C 100-240V to DC 5V/2
A
Dimensions 6.5“ (W) x 5.4” (H) x 1.7” (D
)
11.4“ (W) x 9.8” (H) x 1.9” (D
)
Weight 0.9 lbs. 2.2 lbs.
*RAW image formats supported:
Canon
.CR2: 1Ds Mark2, 1IDs, 1D Mark3, 1D Mark2N, 1D Mark2, 1D, 5D, 10D, 20D, 30D, 40D,
D30, D60, D400, 300D(Rebel), 350D(Rebel XT), 400D(Rebel Xti)
.CRW: G1, G2, G3, G5, G6, S30, S40, S45, S50, S60, S70, Pro1
Nikon
.NEF: D300, D3, D2H, D2Xs, D2X, D1H, D1X, D1, D200, D100, D80, D70s, D70, D50,
D40, D40X, E5000, E5700, E8400
Kodak .DCR: DSC Pro SLR/c, DSC Pro SLR/n, DSC Pro 14n, P850, P880
Fujifilm .RAF: S2 Pro, S3 Pro, S5 Pro, S5600, S9500, S6500fd
Olympus .ORF: E-1, E-300, E-500
Minolta .MRW: DiMage 7, A1, A2, A200, DYNAX 5D, 7D, MAXXUM 5D, MAXXUM 7D, 7i, 7Hi
Sony
.SR2: DSC-R1
.ARW: Alpha A100
Pentax .PEF: *istD, *istDL, *istDS, K100D, K10D
Panasonic .RAW: DMC-FZ50, DMC-FZ30, DMC-LX1, DMC-LX2
Visit www.digitalfoci.com/image_moments for most current updates.
Image Moments
User’s Guide
Page 69
Version 1.0.1-R0
17. Regulatory Compliance
FCC Part 15 Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operations.
The device has been tested and verified to be within the energy emission limits for Class B digital
devices as defined in Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential situation. This device generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. Installed correctly, it probably will not interfere
with your radio or TV. However, we do not guarantee the absence of interference.
If you modify the device in any way, without approval from Digital Foci, Inc., your device may violate
FCC regulations. Violation of FCC regulations may cause the FCC to void your rights to use the
modified device.
If you suspect this device is causing interference, power off and on the device while your radio or TV is
showing interference. If the interference disappears when you turn the device off and reappears when
you turn the device on, something in the device is causing interference.
To reduce interference, try these suggestions
:
• Change the direction of the radi o o r TV antenna.
• Increase the separation between the device and radio or TV.
• Connect the device to a different outlet on a different circuit.
If these suggestions don’t help, consult your computer dealer or an experienced radio/TV technician.
CANADIAN DOC STATEMENT
This digital apparatus does not exceed the Class B limits for radio noise for digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de las classe B prescrites dans le Réglement sur le brouillage radioélectrique
édicté par les ministère des Communications du Canada.
CE Standards
Testing for compliance to CE standards was performed by an independent laboratory. The unit under
test was found compliant to CE Class B specifications.
UL/CSA
This product is recognized per Underwriter Laboratories and Canadian Underwriter
Laboratories 1950.
3111 Via Mondo, E. Rancho Dominguez, California, 90221 USA
Copyright 2008 Digital Foci, Inc. All rights reserved.
Loading...
