Digitag Bluetooth Digital Scale Instructions Manual

Barkeep – October 2014

Barkeep – Instructions for the Digitag Bluetooth Digital Scale

These instructions are for users of the Digitag Bluetooth digital scale purchased from barkeepapp.com.

Users of any other digital scales and/or scales where users will enter weight manually should refer to the

BarkeepApp User Guide for instructions. Users of an approved Reflex Bluetooth digital scale

should refer to the Instructions for using a Reflex Bluetooth Digital Scale.

Contents

Systems Requirements ....................................................................................................................... 2!

Getting Started .................................................................................................................................... 3!

The Digitag Scale .............................................................................................................................. 3!

Setting up Your Digitag Scale in Barkeep ......................................................................................... 4!

Estimating vs. Weighing – Why weigh your bottles? ......................................................................... 6!

Changing the Weight Display Format ................................................................................................ 7!

Setting Full and Empty Bottle Weight ................................................................................................ 7!

How does Barkeep calculate amounts based on Weight? ................................................................ 8!

Using a Digitag Bluetooth Digital Scale ............................................................................................ 9!

Are you connected? .......................................................................................................................... 9!

Troubleshooting ............................................................................................................................... 10!

Weighing the Bottles ....................................................................................................................... 11!

Adding Multiple Entries for the same Item ....................................................................................... 12!

Weighing Items with Incomplete Information ................................................................................... 14!

Note: There are many other models of the Digitot, Digitag Bluetooth and Reflex

Bluetooth

digital scales available. Only those purchased from barkeepapp.com are certified
to work with BarkeepApp. Other models will not work with BarkeepApp and are not
supported by Barkeep. We are not able to provide assistance with or answer questions
about scales purchased elsewhere.

2

Systems Requirements

for the Digitag Bluetooth Digital Scale

To purchase a Digitag Bluetooth digital scale, see barkeepapp.com.

Your iOS Device must have Bluetooth capability.

Digitag Bluetooth

The following iOS Devices are compatible with one of our Digitag Bluetooth digital scales when they
are used with a Linea-Pro scanner with Bluetooth:

• iPhone 4 or later

• iPod Touch (4th generation) or later

The following iOS Devices are compatible with one of our Digitag Bluetooth digital scale when they
are used with an Infinea Tab scanner with Bluetooth:

• iPad or iPad Mini

Note: You must use a Digitag Bluetooth digital scale either with a Linea-Pro scanner with Bluetooth
support or an Infinea Tab scanner with Bluetooth support.

3

Getting Started

The Digitag Scale

Status Lights

There are four status lights on the front of your Digital Scale.

• Power Light - Just to the right of the Power input plug is a red light located directly above the

symbol of a power cord. This light is on when the scale is plugged into a power source.

• Bluetooth Light - There are three lights grouped together just to the left of the on/off switch. The

first of these is a blue light located directly above a Bluetooth symbol. This blue light is on when your
scale is communicating with another device.

• On/Off Light - The middle green light is on when your scale is powered on. To turn the scale on/off

press the on/off switch. It is the only button on the front of the scale.

• Battery Light - The rightmost red light is on when the scale is low on battery and needs to be

recharged.

Turning Your Scale On

To turn your scale on:

1. Press the power switch located between the three status lights and the Serial Number label.

2. If the green On/Off Light does not come on, please try recharging the scale’s battery.

3. If the battery does not charge, please see below regarding connecting the rechargeable battery.

Connecting the Rechargeable Battery

We will typically connect the scale’s rechargeable battery before shipping it to you. However, occasionally
customers may receive a scale with the rechargeable battery disconnected. If you can’t seem to turn on or
charge your scale, the battery may have become disconnected.

If you believe that your scale’s battery is not connected, you should remove the scale’s top metal case. The
components of the scale fit snugly into the top metal case, however it is possible to remove the scale from the
metal case. You simply have to grasp the “legs” on the scale and pull firmly on the upper case until the scale
components slide out of the metal case. There are two wires that connect the scale to the rechargeable
battery. Make certain that both wires are firmly connected to the rechargeable battery and replace the metal
cover on the scale.

Note: Be very careful when replacing the metal cover to make sure that the power switch is lined up with
the slot on the front of the metal cover. If you try to put the metal cover on and the power switch is
misaligned, you can break the power switch off and have to use the tip of a pen to turn the scale on and off in
the future.

4

Setting up Your Digitag Scale in Barkeep

The first step is to register the Digitag Bluetooth scale with Barkeep.

1. Turn on the Digitag XHBMS digital scale.

2. Launch BarkeepApp. Press “Settings” and select Bluetooth Scale.

3. A pop-up menu will ask you to “Choose Your Scale.” Select Digitag.

4. Check that “Autodetect Bluetooth LE Scales” is set to

.

5. Press “Search for Devices.”

6. You should see a Device named “Sensor” displayed. Select that Device and press Save.

continue to next page

5

Setting up Your Digitag Scale (cont.)

7. Press “Pair”

8. Once you've paired BarkeepApp with the scale, the Device Status should change to Paired.

9. The PIN should be left blank – the XHBMS does not require a PIN.

Note: When your iOS Device is searching for the Digitag Bluetooth scale it might also detect other

Bluetooth devices nearby. An older iPhone or iPod Touch might detect a new Reflex Bluetooth digital

scale, but it will not be compatible with the Reflex Bluetooth unless it is an iPhone 4S and later or an

iPod Touch 5th generation and later.

Reminder: You must use a Digitag Bluetooth scale with a Linea-Pro scanner with Bluetooth support or an

Infinea Tab scanner with Bluetooth support.

Setting the Digitag Bluetooth Scale to Zero

Before beginning to weigh Items, we recommend setting the scale to Zero.

You will not need to do this

for each Item, but should set the scale to Zero every time you begin a session of weighing Items.

Reminder: There are many other models of the Digitag Bluetooth digital scales available. Only those
purchased from barkeepapp.com are certified to work with BarkeepApp. Other models will not work with
BarkeepApp and are not supported by Barkeep. We are not able to provide assistance with or answer
questions about scales purchased elsewhere.
