Digisol Ranger Series, DG-LB1054UV Quick Installation Manual

1

RANGER SERIES

LOAD BALANCING ROUTER WITH 2xFE

WAN, 1x3G/4G ENABLED USB, 3xFE LAN

DG-LB1054UV

V2.0
2018-08-28

2

Copyright

Copyright 2018 by DIGISOL Systems Ltd. All rights reserved.
Company has an ongoing policy of upgrading its products and it may be
possible that information in this document is not up-to-date.
Please check with your local distributors for latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.

Trademark

DIGISOLTM is a trademark of DIGISOL Systems Ltd. All other
trademarks are the property of the respective manufacturers.

3

The following items should be present in your package:

 DG-LB1054UV (1 No.)
 Power Adapter
 Patch Cord
 Quick installation guide
 Installation software CD (includes User Manual & QIG)

Make sure that the package contains above items. If any of the listed
items is damaged or missing, please contact your retailer immediately.

Congratulations on your purchase of this outstanding product DG­LB1054UV. This device is specifically designed for SMB & SOHO
offices, small shops and chain stores. No matter offices are located at
wire unreachable area, it can connect to Intranet of headquarter
instantly via fixed line and/or cellular network. No need to apply for
expensive leased line in advance. With multiple WAN load balance and
fail-over, it guarantees non-interrupt operation.

By IPSec/PPTP/L2TP VPN tunneling and failover technology, it can
establish a secure non-stop connection with headquarter even IP is
changing all the time. Firewall protection is useful to avoid hackers
attacking. With embedded robust security and firewall function, it’s
suitable for remote branch offices to access the corporate database &
servers located in headquarter data center through internet. Besides,
this device also provides VoIP feature to enable secure and cost
effective Intranet voice communication through internet.

Instructions for installing and configuring this product can be found in
this manual. Before you install and use this product, please read this
manual carefully for fully exploiting the functions of this product.

4

Safety Instructions

 Do not use the product in high humidity or

high temperatures.

 Only use the power adapter that comes with

the package. Using a different voltage rating
power adaptor may damage the product.

 Do not open or repair the case yourself. If the

Product is too hot, turn off the power
immediately and have it repaired at a
qualified service center.

 Place the Product on a stable surface and

avoid using this product and all accessories
outdoor.
