Digisol DG-CH1130 Quick Installation Manual

DVR SERIES

8 CHANNEL AHD MINI

DIGITAL VIDEO RECORDER

DG-CH1130

1

V2.0
2016-05-13

2

Copyright

Copyright 2016 by Smartlink Network Systems Ltd. All rights reserved.
Company has an ongoing policy of upgrading its products and it may be possible that information in
this document is not up-to-date.
Please check with your local distributors for latest information.
No part of this document can be copied or reproduced in any form without written consent from the
company.

Trademark

DIGISOLTM is a trademark of Smartlink Network Systems Ltd. All other trademarks are the property
of the respective manufacturers.

3

The following items should be present in your package:

1 DG-CH1130 DVR (8 channel)
Power adapter (12V DC, 2A)
Quick Installation Guide
1 USB Mouse
Installation Guide CD

Make sure that the package contains above items. If any of the listed items is damaged or missing,
please contact your retailer immediately.

Thank you for purchasing DIGISOL DG-CH1130 DVR!
This QIG is a reference guide for the installation and operation of your DVR. The DG-CH1130 is a 8
channel DVR. Before installation and operation please read the safeguards and warnings mentioned
in the sections below carefully.

4

Provides H.264 high efficiency video Compression.
Supports 8CH.
Supports 8CH playback at the same time.
8CH with total 200FPS (supports 8CH AHD-NH@25FPS);
Supports up to 4TB HDD.
Supports two USB 2.0 ports for USB mouse.
Provides HDMI/VGA Output.
Supports 1 SATA port.

The following system requirements are recommended:

Windows XP, Vista or Win 7 operating system (both 32 or 64 bits version)
2GB of system memory
1GB of Display card memory
20GB of available hard disk space on system drive
At least one SATA Hard Disk for recording the video

5

Important Safety Information and Warnings

Do not place heavy objects on the DVR.
Do not let any solid or liquid fall into or infiltrate the DVR.
Please brush the printed circuit boards, connectors, fans, machine box and so on regularly.

Before the dust cleaning please switch off the power supply and unplug it.

Do not disassemble or repair the DVR yourself.
Do not replace the components yourself.

Environment

Please place and use the DVR between 0ºC and 40ºC. Avoid direct sunlight & keep the DVR

away from heat source.

Do not install the DVR in damp environment.
Do not use the DVR in smoky or dusty environment.
Avoid collision or strong fall.
Please ensure the DVR level installation in a stable workplace.
Please install in ventilated place. Keep the vent clean.
Use within the rating input and output scope.

Accessories

Be sure to use accessories recommended by the manufacturer. Before installation, open the
accessory kit and check if all the components are included. If any components are missing, contact
your vendor ASAP.
