SERVICE MANUAL
InfoTag 2.13
InfoTag 2.13
COPYRIGHT © 2010 DIGI SINGAPORE PTE. LTD.
Table of Content
i) Notice ................................................................................................................................................. 1
ii) Safety Information .............................................................................................................................. 2
iii) Safety Regulations ............................................................................................................................. 2
1. General ............................................................................................................................................................. 5
1.1 Model Specification ............................................................................................................................ 5
1.2 Operating Specification ...................................................................................................................... 5
2. InfoTag 2.13 Setup Diagram........................................................................................................................... 6
2.1 Overall Layout and Label design ......................................................................................................... 6
2.2 Replacement of Info Tag Battery .......................................................................................................... 8
2.3 Button Cell Specifications ...................................................................................................................... 9
2.4 ESL Attachment (Refer to ESL Attachment Catalogue) ........................................................................ 9
2.5 Product Handling of Info Tag ................................................................................................................. 9
3. Revision Records .......................................................................................................................................... 10
i) Notice
DIGI®
The material contained in this document is proprietary and for information only and is subject to change without
notice. Digi Singapore Pte. Ltd. assumes no responsibility for any errors or damages arising from
misinterpretation of any procedure.
Screen displays, operating procedures and supporting features might vary with different software version
releases.
This document shall not be reproduced whether in part or whole without the written consent from Digi
Singapore Pte. Ltd.
Digi Singapore Pte. Ltd.
4, Leng Kee Road
#06-01 SIS Building
Singapore 159088
1
InfoTag 2.13 Service Manual
FOR PLUGGABLE EQUIPMENT, THAT THE SOCKET-OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
POUR LE MATÉRIEL RACCORDÉ PAR PRISE DE COURANT, LE SOCLE DE PRISE DE
COURANT DOIT Ê TRE
INSALLÉ À PROXIMITÉ DU MATÉRIEL ET DOIT ÊTRE AISÉ MENT ACCESSIBLE.
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE
AND RATING OF FUSE.
POUR NE PAS COMPROMETTRE LA PROTECTION CONTRE LES RISQUES D’INCENDIE,
REMPLACER PAR UN FUSIBLE DE MÊME TYPE ET DE MÊME CARACTÉRISTIQUES
NOMINALES.
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD
USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS
IL Y A DANGER D’EXPLOSION S’IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE.
REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D’UN TYPE
RECOMMANDÉ PAR LE CONSTRUCTEUR. METTRE AU RÉ BUT LES BATTERIES USAGÉES
CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT.
ii) Safety Information
The operator of the equipment shall comply with the safety and warning indications and procedures outlined in this
document. Digi Singapore Pte. Ltd. assumes no responsibility or liability for failure to comply with these
requirements.
Repair and servicing of product, shall only be carried out by trained and qualified personnel.
Disclaimer:
Specifications are subject to change without notice. All dimensions shown are approximate. Please be aware that
Teraoka has indicated that its hardware and software used in the product may require additional updates in the
future as our product is continually under development. The need for such updates most likely applies to the Printer
software.
CAUTIONS:
iii) Safety Regulations
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
2
InfoTag 2.13 Service Manual
Actual size
9mm (H) x 17mm (W)
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
The product comply with the US portable RF exposure limit set forth for an uncontrolled environment and
are safe for intended operation as described in this manual. The further RF exposure reduction can be
achieved if the product can be kept as far as possible from the user body or set the device to lower output
power if such function is available.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IDA Compliance Statement: (Singapore)
This equipment registered to comply with IDA (Info-Communications Development Authority of Singapore)
Standard under Dealer’s Class License.
Industry Canada statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may cause undesired operation of the
device
Cet appareil contient des émetteurs / récepteurs exempts de licence qui sont conformes au (x) RSS (s) exemptés
de licence d'Innovation, Sciences et Développement économique Canada. L'opération est soumise aux deux
conditions suivantes:
(1) Cet appareil ne doit pas causer d'interférences
(2) Cet appareil doit accepter toute interférence, y compris les interférences pouvant provoquer un fonctionnement
indésirable de l'appareil
IMPORTANT NOTE:
Radiation Exposure Statement:
The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are
safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the
product can be kept as far as possible from the user body or set the device to lower output power if such function is
available.
Déclaration d'exposition aux radiations:
3
InfoTag 2.13 Service Manual
Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats-Unis et le Canada
établies pour un environnement non contrôlé. Le produit est sûr pour un fonctionnement tel que décrit dans ce
manuel. La réduction aux expositions RF peut être augmentée si l'appareil peut être conservé aussi loin que
possible du corps de l'utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible si une telle
fonction est disponible.Cet équipement est conforme avec l'exposition aux radiations IC définies pour un
environnement non contrôlé. Les utilisateurs finaux doivent suivre les instructions de fonctionnement spécifiques
pour satisfaire la conformité aux expositions RF. Pour respecter les exigences de conformité d'exposition RF IC, s'il
vous plaît suivez les instructions d'utilisation documenté dans ce manuel.
NCC 警語
◆第十二條:
經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變更頻率、加大功率或變更原設計
之特性及功能。
◆第十四條:
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時
方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻
射性電機設備之干擾。
4
Model
:
InfoTag 2.13
Dimensions (in mm)
:
Product size
-
70(L) X 39(H) X 16(W)
LCD Size
-
49mm (H) x 24mm (V))
LCD Resolution
-
212 x 104 dots (Dpi:111)
Weight
:
34g approx.
Power Source
:
DC Cell Button Battery 3.0V x 2
Operating Temperature
:
0 °C to + 40 °C; -25 °C to +10 °C (LT)
Humidity
:
85% Max. Non-condensing
IP Rating
:
IP55
Housing material
:
ABS plastic casing, PC battery cover
Battery Specification
:
Type
-
CR2450 (Cell Button Battery)
Nominal Voltage
-
3.0V
Life Time
-
5 years (2 update/day)
Weight
-
6.6g approx.
Frequency band
:
2402MHz - 2.480MHz
Transmit power
:
63.48dBuV/m (max)
Receiver sensitivity
:
-90dBm (typical)
RF range
:
18m ~ 22m to IB-3700 (*Max. up to 70m LOS)
*Note: The RF Range maybe varies in different environment.
Certification
:
CE, C-TICK, FCC, NCC, TELEC, SA
1. General
1.1 Model Specification
InfoTag 2.13 Service Manual
1.2 Operating Specification
5
InfoTag 2.13 Service Manual
Front View
Back View
2. InfoTag2.13 Setup Diagram
2.1 Overall Layout and Label design
6
Nameplate
InfoTag 2.13 Service Manual
7
Location of Battery in InfoTag
+
Battery
Battery Cover
InfoTag
Caution: Dispose of the Battery according the Safety Guideline.
i. Avoid placing the battery in reverse polarity.
ii. Do not heat or dispose of fire. May burst or release toxic material.
iii. Do not charge.
iv. Do not short circuit.
v. Do not solder the battery directly.
vi. Do not ingest battery, Chemical Burn Hazard
vii. Keep new and used batteries away from children
viii. If the battery compartment does not close securely, stop using the product and
keep it away from children
ix. Do not solder the battery directly.
2.2 Replacement of Info Tag Battery
InfoTag 2.13 Service Manual
i. Pull off the battery cover from back of the Info Tag.
ii. Replace the new battery. (Ensure the Battery polarity is correct)
8
InfoTag 2.13 Service Manual
2.3 Button Cell Specifications
2.4 ESL Attachment (Refer to ESL Attachment Catalogue)
For all information about the ESL Various Attachment type, function, installation etc. Please refer to ESL
Attachment Catalogue
http://www.digiesl.com.tw/digiesl/sys4.asp
http://www.teraoka.com.tw/digi/article.aspx?id=77
http://www.digiesl.com/
2.5 Product Handling of Info Tag
Handle product with care. Do not expose product to corrosive chemical solution, any organic solvent
acidic or alkaline. If cleaning is required, wash only water or mild soap solution.
Do not attempt to disassemble, apply force or heavy load to the product. No user serviceable parts inside
except battery
9
InfoTag 2.13 Service Manual
Serial
No.
Date
Edition
Status
Description of Changes
Software
Version
Remarks
001
FEB 19
00
First Release
F003
3. Revision Records
10
