Multifunction AC/DC Voltage Tester
Model 20250-59
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 1 8/8/2017 1:37:47 PM
Introduction
The Digi-Sense AC/DC Voltage Tester (Model 20250-59) is
versatile and easy to use. The instrument is a must-have
on your electrical tool belt. It safely measures AC/DC
voltage, polarity direction, and circuit continuity. The
instrument also provides rotary field indication and low
impedance testing. Careful use of this meter will provide
years of reliable service.
Safety Precautions
• Do not exceed the maximum allowable input range of any
function.
• Wear insulated body protective equipment rated to 690 V.
• Close attention must be paid when testing any electrical
circuits.
International Safety Symbols
This symbol, adjacent to another symbol or
terminal, indicates the user must refer to the
manual for further information.
This symbol, adjacent to a terminal, indicates
that, under normal use, hazardous voltages
may be present.
Meter is protected throughout by double
insulation.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 2 8/8/2017 1:37:47 PM
2
WARNINGS
In order to avoid electrical shock, valid safety regu-
lations regarding excessive contact voltages must
be followed. These include voltages exceeding
60 VDC and 25 VAC RMS.
Prior to measurement, make sure that the test
leads and instrument are in working order.
When using this instrument only the handles of
the probes may be touched – do not touch the
probe tips.
This instrument may only be used within the
ranges specified and within low voltage systems
up to 690 V.
Prior to use, make sure the instrument function
intended for use is in working order. Do not use
the instrument if one or more functions are not
working properly.
Do not use this instrument in damp conditions.
Proper operating conditions for this instrument are
-10 to 55°C, <85% RH.
This instrument should not be used if the operator’s
safety cannot be assured.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 3 8/8/2017 1:37:47 PM
3
Safe operation can no longer be assured if the instrument:
• Shows obvious damage
• Does not perform desired measurements
• Has been stored too long under unfavorable conditions
• Has been subjected to mechanical stress during transport
• All relevant statutory regulations must be adhered to
when using this instrument
Appropriate Usage
This instrument may only be used under those conditions
and for those purposes for which it was conceived. For this
reason, the safety references, the technical data including
environmental conditions and the usage in dry environ-
ments must be followed. When modifying or changing the
instrument, the operational safety is no longer ensured.
The instrument may only be opened by an authorized
service technician, e.g. for repair.
Unpacking
Check individual parts against the list of items below.
If anything is missing or damaged, please contact your
instrument supplier immediately.
1. Instrument with integrated probes
2. Carrying case
3. Two AAA batteries
4. User manual
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 4 8/8/2017 1:37:47 PM
4
Meter Description
1. Handle test probe – (L1)
2. Instrument test probe + (L2)
3. Measurement point illumination
4. 2000-count LCD
5. LED for single-pole phase test
6. LED for low impedance test
7. LED for continuity
8. Low impedance switch (L2)
9. Measurement point lighting button
10. Battery case
11. Low impedance switch (L1)
Explanation of Symbols
DC DC voltage
AC AC voltage
–
DC voltage negative potential (DC)
•))) Phase display from 100 to 690 V to 50/60 Hz
Continuity test symbol when used as a single-pole phase tester
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 5 8/8/2017 1:37:47 PM
R Rotating field display clockwise
L Rotating field display counterclockwise
Device for work to be performed with voltage present
Battery replacement symbol
5
Setup and Operation
Measuring Point Lighting
The voltage tester has a battery-operated measuring point
lamp. Press button (9) to switch this lamp on. The lamp
stays on as long as this button is pressed. When the button
is released, the lamp goes off. The lighting button is
arranged in such a way that it can also be pressed during
low impedance measurements.
Carrying Out Measurements
The twin-pole voltage tester has two handle components
connected by a cable. Always hold the voltage tester in
such a way that you get a vertical view of the display.
Strong incidence of light may have an adverse effect on
the display. For DC measurements, test tip (L2) is the
positive pole, and test tip (L1) is the negative pole.
Before each voltage measurement, check that
the device is working properly by measuring a
known voltage source. If the tester’s LCD remains
defective voltage tester must not be used. Do not operate
the device with flat batteries or without batteries. Observe
the regulations regarding work with electrical systems.
Voltage Measurement with High Internal Impedance
Always hold the voltage tester by the handles designed for
this purpose. Never touch the device beyond the handle
ends. Hold the two test tips into the measuring points to be
tested. The voltage tester switches on automatically with
voltages higher than 4.5 V AC/DC. The voltage measured is
shown on the LCD. If the measured voltage falls below
4.5 V AC/DC, the voltage tester switches off automatically.
blank, take the voltage tester out of operation. A
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 6 8/8/2017 1:37:47 PM
6
The LCD shows the voltage values numerically and in the
form of a bar graph. The type of voltage (alternating current = AC, direct current = DC) and the polarity are also
shown on the LCD. In the event of negative DC voltage, the
numeric voltage value is preceded by “-“. Positive DC voltage is shown without a positive sign preceding the
numeric value.
Thanks to the input impedance of approximately
1 MΩ, it is possible to perform voltage tests with
high input impedances without time restrictions.
The voltage tester also indicates a rotating direction (L or
R) with measurements on single phase mains (L1 against
N). This is not a device malfunction.
Voltage Measurement with Low Internal Impedance
This function is particularly useful for testing installations.
Due to the lowered internal impedance, capacitive voltage
is suppressed. The reading shows the actual voltage
applied. Similarly, measuring phase (L1) on earth wire (PE)
may trigger fault-current circuit breakers (FI or RCI). This
measuring procedure can be used for measurements
above 12 V. Always hold the voltage tester by the handles
designed for this purpose. Never touch the device beyond
the handle ends. Hold the two test tips on the measuring
points to be tested. Press the two push-buttons simultane-
ously. The applied voltage is shown on the LCD. The
Low-Imp LED signals low impedance measurement.
The maximum permitted duty cycle in low imped
ance operating mode is 5 seconds for voltages up
to 250 V and 3 seconds for voltages up to 690 V.
When this time has elapsed, wait for 10 minutes before
taking the next measurement.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 7 8/8/2017 1:37:48 PM
7
Rotating Field Direction Display
The voltage tester can show the direction of the rotating
field with three-phase systems. Always hold the voltage
tester by the handles designed for this purpose. Never
touch the device beyond the handle ends. Hold the two
test tips on the measuring points to be tested. Test tip cor-
responds to L1 and test tip corresponds to L2. The applied
voltage and the rotating field direction is shown on the
LCD. The rotating eld symbols (D) show the corresponding eld direction (L = counterclockwise, R = clockwise).
Continuity Check
The voltage tester can also be used as a continuity checker.
Always hold the voltage tester by the handles designed for
this purpose. Never touch the device beyond the handle
ends. The continuity checker switches itself on automatically when the test starts, and switches itself back off when
the test has been completed. Check for correct functioning
before beginning the test. If you connect the two test clips
to each other, you should hear a beep, and the continuity
LED should light up. If this does not happen, then replace
the batteries as described on page 12. The continuity tester
indicates resistances up to 400 kΩ.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 8 8/8/2017 1:37:48 PM
8
Using Voltage Tester as a Single-Pole Phase Tester
The voltage tester can also be used as a single-pole
phase tester. Always hold the voltage tester by the
handles designed for this purpose. Never touch the
device beyond the handle ends. This phase test serves as a
quick test only. Check for zero potential with the twin-pole
measuring method as described above before doing work
on this circuit. Observe regulations regarding work on
electrical circuits.
Before beginning the test, check the conditions of the
batteries by touching the two tips together. Check for
correct functioning at a known alternating voltage source.
Contact test tip L2 with the measuring point to be tested. In
the response to a phase event (alternating voltage between
100 V to 690 V), the lighting symbol LED lights up.
The single-pole phase display can be adversely
affected by unfavorable ambient conditions
(electrostatic fields, good insulation, etc.). In all
cases, conduct an additional twin-pole voltage test.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 9 8/8/2017 1:37:48 PM
9
Specifications
Voltage test
Voltage range 6, 12, 24, 50, 120, 230, 400 VAC/DC, 690 VDC
Resolution 1 VAC/DC
Tolerances
400 VAC Max. measuring current Approximately ≤1.0 mA
690 VDC Max. measuring current Approximately ≤1.5 mA
Voltage detection Automatic
Polarity detection Full range
Range detection Automatic
Response time Updates 2 to 3 sec
Operation time 30 sec
Recovery time 240 sec
ACV frequency range 50/60 Hz
Internal impedance Approximately ≤1 MΩ
Operation time Long
LCD on >4.5 VAC/DC
Single-pole phase test
Voltage range 100 to 400 VAC
ACV frequency range 50/60 Hz
Continuity test
Resistance range <200 kΩ
Test current <1 µA
Overvoltage protection 400 VAC/690 VDC
Rotary field indication
Voltage range (LEDs) 100 V to 400 V
Frequency range 50/60 Hz
Measurement principle Double pole and contact electrode
DCV: +1.0% rdg + 3 digits
ACV: +1.5% rdg + 5 digits
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 10 8/8/2017 1:37:48 PM
10
Low impedance test
Voltage range 12 to 230 VAC/DC
Low impedance <6 kΩ
Operation time
5s <250 VAC/DC, 1s ≤0.2 A (690 V) /
30s Max.
Overvoltage protection 3s <400 VAC/690 VDC
General
LCD
2000 counts (3½ digits) LCD with bar graph
and backlight
Housing IP64
Safety rating CAT III-1000 V / CAT IV-600 V
Dimensions (L x W x H): 97⁄16" x 31⁄16" x 19⁄16" (24 x 7.8 x 4 cm)
Operating conditions 14 to 131°F (–10 to 55°C), <85% RH
Power supply Two AAA batteries (included)
Temperature range –10 to 55°C
Humidity <85% RH
Overvoltage class CAT III 690 AC/DC
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 11 8/8/2017 1:37:48 PM
11
Maintenance and Repair
Maintenance and Disposal
Check the correct operation of the voltage tester regularly.
It can be assumed that risk-free operation is no longer
possible if:
• There is visible evidence that the device has been
damaged.
• The device has been stored under unfavorable conditions
for a long period of time.
• The device has been subjected to physical abuse.
The outside of the device should be cleaned with a soft
damp cloth or brush only. Do not use abrasive or chemical
cleaning agents which could damage the housing or impair
operation.
Note: Never try to open the housing except for the battery
compartment.
If the instrument has become unusable, dispose of it in
accordance with current statutory requirements.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 12 8/8/2017 1:37:48 PM
12
Battery Replacement
The voltage tester is powered by two AAA batteries
supplied with the instrument. They are replaced as follows:
1. Loosen the screw on the battery compartment lid (10)
with a screwdriver and remove it.
2. Insert two AAA batteries into the compartment observing the correct polarity information in the compartment.
Alkaline batteries are recommended.
3. Replace the compartment lid and retighten the screw.
The batteries need to be changed if the low battery symbol
lights up on the LCD or when the LCD stays dark when
touching the two probe tips together.
The voltage tester will show no reading if the
batteries are drained. The device must not be
operated with drained or removed batteries.
To prevent damage from leaking batteries, remove the
batteries if you will not be using the instrument for an
extended time. For the same reason, remove drained
batteries immediately once discovered.
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 13 8/8/2017 1:37:48 PM
13
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 14 8/8/2017 1:37:48 PM
14
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 15 8/8/2017 1:37:48 PM
15
For Product and Ordering Information, Contact:
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
1065DGMAN_20250-59 DS multifunctional voltage tester.indd 16 8/8/2017 1:37:48 PM
1065DGMAN_20250-59
Manual Part No. 00101-94
Loading...
