Digi-Sense 20250-07 Instruction Manual
User Manual
Professional Dual-Laser Infrared Thermometer
with 30:1 Distance-to-Sight Ratio, USB Output,
Single Type K Input, and Temperature Alarm
with NIST-Traceable Calibration
Model 20250-07
THE STANDARD IN PRECISION MEASUREMENT
Introduction
The Digi-Sense Professional Dual-Laser Infrared Thermometer (Model
20250-07) with 30 to 1 distance-to-sight ratio offers fast response and high
accuracy. This heavy-duty meter is ideal for a wide range of applications
including food preparation, safety and fire inspection, plastic molding,
marine, HVAC, and fleet maintenance. Advanced features include USB
interface for data transmission, temperature alarm, adjustable emissivity,
temperature differential, data Hold, Max/Min/Avg readings, and auto
power-off. The meter also supports contact measurement through a
type K thermocouple input. The instrument is fully tested and calibrated
to NIST-traceable standards. Careful use of this meter will provide years
of reliable service.
Unpacking
Check individual parts against the list of items below. If anything is missing
or damaged, please contact your instrument supplier immediately.
1. Meter
2. One type K flexible probe
3. USB cable
4. Software
5. Tripod
6. Carrying case
7. One 9 V battery
8. User manual
9. NIST-traceable calibration report with data
2
Key Features
• 30:1 Distance-to-sight ratio
• 1.5% basic accuracy
• Dual laser sighting
• USB interface for transmission of data to PC
• Contact measurements via type K thermocouple input
• Precise noncontact IR measurements
• Rapid detection function
• Adjustable emissivity from 0.10 to 1.0
• User-selectable ºC or ºF units
• Automatic data Hold
• MAX/MIN/AVG temperature displays
• Temperature differential
• High and low alarms (audible)
• Automatic selection range and display resolution
• Trigger lock
• Backlight LCD
• Automatic power-off to conserve battery life
3
Meter Description
1. IR sensor
2. Laser pointer beam
3. Type K thermocouple input
4. USB computer interface
5. LCD
6. Up button
7. Backlight
/ Laser button
8. Down button
9. MODE button
10. Lens cover with magnetic lock
11. Measurement trigger
12. Battery cover
13. Handle grip
10
2
1
3
4
4
5
6
7
8
9
11
12
13
