DIGILINK GROUP DM302 Users Manual

USER MANUAL

Model Name: DM302

1

Functions summarize ……………………………………………………………………………………1-2
Notice …………………………………………………………………………………………………3-4
Understand the model……………………………………………………………………………………5
Key definetion……………………………………………………………………………………………5
Main interface …………………………………………………………………………………………6
Music mode………………………………………………………………………………………………7-8
Video mode…………………………………………………………………………………………………9
Picture mode………………………………………………………………………………………………10
E-book…………………………………………………………………………………………………10-13
Programme …………………………………………………………………………………………… 14-15
Record………………………………………………………………………………………………………16
FM radio …………………………………………………………………………………………………17
Explorer……………………………………………………………………………………………………18
settings …………………………………………………………………………………………………19
USB disc ………………………………………………………………………………………………19
Troubleshooting …… ……………………………………………………………………………………20
Declare ……………………………………………………………………………………………………22

In order to tell you play the player freely as soon as spossible, please read the user

Content

2

manual carefully. In which including the way to operate, the products specifications
etc.

Functions summarize

z High clear TFT，support 400×240
z Support MP3、WMA、WAV、FLAC and so on
z Support MPEG-4(AVI)、RMVB、RM directly
z Support JPEG,BMP,GIF picture browse
z Voice record，A-B repeat function
z Power save setting：brightness adjust，user-defined power off time
z Support auto power off setting，power on setting。
z Support 3D steoro tone effect、Micro soft playFX、user-defined EQ
z Milti playing mode：once、repeat、all、all repeat、audition、order play
z Support multi-languages
z Capacitance touch screen
z Support FM transmitter
z Position of the menu change by finger moving
z USB2.0 high speed
z Support E-book，bookmark
z Support calculator,calendar, watch function
z U-disk，firmware upgrade
z Compatible systems：Windows98/SE/ME/2K/XP
z Operate temperature：-5 to 40 centigrade

3

Notice

This user manual including important safety precautions and the right way to

operate.In order to avoid the accident,please read it carefully.

z Do not put the player under high temperature,wet or dusty.
z Avoid it be fallen down or collide fierce, do not let the TFT display be knocked
z Please choose the suitable volume, do not choose too big volume so as not to damage

your ears, if you feel un comfortable,please adjust the volume smaller or power off
the player

z Charge the player under below conditions:

A、battery volume shows empty
B、power off automaticly，power off again quickly after power on
C、touch screen no response

z This player is built in rechargeable Li-battery, please charge it for 8 hours for more

than three times after you bought it,and charge it after the player run out of battery,
so the battery life can be longer

z Battery life is affected by the different volume, difference types of files etc

1. when charge it by USB cable, when the battery volume shows full, the charging has
been finished

2. if you use the charger,first use the charger connect to the power, then connect
the USB cable to the charger and the player. when the battery volume shows full,
the charging has been finished

3. during the charging,the charger and the player maybe a little high temperature,it

is normal phenomenon

注: do not use other charge if it is not the same as the original one. If you want to,please

4

comfirm it with the whole seller or service team.

z Do not disconnect the player from the computer when it is being formatted or down

loading/up loading files, otherwise the programme maybe appears problems.

z Do not disassemble the player yourself, or use the alcohol,thinner or benzene to scrub

away the face of the player

z Do not use the play when forbidden, such as on the plane
z Do not use it when you are walking on the street or driving, otherwise maybe cause

accident

z Software will cost some capacity. So the capacity available will be less than the

rated capacity

z Some video maybe not support beyond the chip,please try to change it by the movie

converter

z This product is not dampproof or waterproof
z Please do not change the battery if you are not a professional man to fix it, so as

to avoid the blast

Understand the model

5

Key definitions
⑴：USB slot ⑵：
⑸：reset button ⑹：earphone slot

lock button ⑶：power on/off button ⑷: MIC slot

6

Main interface：

This interface shows all the functions which the model has. If you want to enter the
submenu,you can touch the icon which you need. The position of the icon can be changed
by finger.

1. power on/off
2． Power on：push the power on/off button for 3 seconds

Power off：puch the power on/off button for 3 seconds again。（the player will be shut
down when low battery）
Puch the lock button, the player will be locked

3. connect to the computer and file transfer
Connect the USB cable to the computer, then the player can be charged or transfer the

files, this player can be used as a U-disk, you can copy the files to the player
easily.

7

System menu

Music playing

After power on the player,you can enter the submenu by touch the music,
video,photo,e-book,recorder,explorer,settings,programme,radio

※note：after you copy or delete some music files,please update media library, then

enter to the music list,short press the

operation：
一． Under play/pause mode，connect the earphone to the player,，choose the music from

touch the music icon again to play the music

the list, short press the
click the

is as below:

to open the sbmenu，then find the settings you need, the picture

start playing,short press the music pause。You can

come back to the main interface,then

8
