FFXX22 MMIIBB™
RReeffeerreennccee MMaannuuaal
Revision: January 14, 2009
Note: This document applies to REV A of the board.
™
l
Overview
The Digilent FX2 Module Interface Board (MIB)
offers a ready-made solution for interfacing
peripheral modules to Digilent system boards.
Features include:
• FX2 peripheral board connector
• four 12-pin and two 6-pin Pmod
connectors
• access to JTAG scan chain
• access to signals for test points
• provision for oscillator for clock input to
system board
Functional Description
Power Connections
The FX2 MIB provides two power busses and
a ground bus. The two power busses are
labeled VCC and VCCFX2. These two busses
are made available at each connector position
on the board. There is also a ground plane that
connects the ground pins from all connectors.
The usual Digilent convention is to power the
VCC bus at 3.3V and the VCCFX2 bus at 5.0V.
However, depending on the system board
connected and the power supply used, other
voltages may be present. Use caution when
using any voltage other than 3.3V on the VCC
bus. Most Digilent system boards will be
damaged if the voltage on the VCC bus is
greater than 3.3V.
FX2 connector J10 is provided on one side of
the board for connection to Digilent system
boards, like the Nexys2, that contain an FX2style connector. The Digilent FX2 connector
signal convention provides for forty generalpurpose I/O signals, three clock signals, JTAG
signals, and power busses.
®
www. d i g i l e n t i n c . c om
215 E Main Suite D | Pullman, WA 99163
(509) 334 6306 Voice and Fax
FX2 MIB Block Diagram
Doc: 502-161 page 1 of 4
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
FX2 MIB Reference Manual
The forty general-purpose I/O signals from the
FX2 connector are brought out to connector
J7. These signals are labeled IO1-IO40. See
Table 1 for a description of the relationship
between FX2 connector pins and signal names
on J7. The remaining signals from the FX2
connector are brought out to connectors J8,
J9, J11, and J12. See Table 1 for a description
of the relationship between FX2 connector pins
and connectors J8 and J9 signal names.
In addition to the FX2 connector signals,
connector J11 and J12 also provide access to
the power and ground busses.
Pmod Connectors
Digilent Pmods provide various peripheral
functions. These can be as simple as buttons
or switches for inputs and LEDs for outputs, or
as complex as graphical LCD display panels,
accelerometers, and keypads.
All Digilent Pmods use either a six-wire
interface or a twelve-wire interface. The sixwire interface provides four I/O signals, power,
and ground. The twelve-wire interface provides
eight I/O signals, two powers, and two
grounds. The signal definitions for the I/O
signals as well as the voltage requirements for
the power supply depend on the specific
module.
The FX2 MIB provides four twelve-pin and two
six-pin Pmod connectors.
The twelve-pin connector provides access
such that the top set of four pins are the odd
labeled signals while the bottom set are even
labeled signals. See Table 2.
The signals for Pmod connectors J1-J6 are
brought out to connector J7. These signals are
labeled IO1-IO40.
Each Pmod connector has an associated
power select jumper. The power select jumper
for J1 is JP1, and so on. These jumpers are
used to select one of the two power busses on
the FX2 MIB to provide power to the power
supply pin on a Pmod plugged into that
connector position. Placing a shorting block in
the 3V3 position provides VCC power to the
Digilent, Inc.
www.digilentinc.com
Pmod. Placing a shorting block in the 5V0
position provides VCCFX2 power to the Pmod.
Place a shorting block so that it hangs off of
the center pin only to disconnect power to the
Pmod.
FPGA Configuration
The FX2 MIB provides JTAG access via
unloaded jumper J9. Given that the jumper
JP7 labeled JTSEL is shorted, this jumper
allows a connected board to be programmed
via a JTAG cable.
See Table 1 for a description of the
relationship between the FX2 connector pins
and the connections on the JTAG jumper J9.
Clocks
The FX2 MIB provides an oscillator clock input
to a system board via socket connector IC1.
This socket can be used to input a clock signal
to a system board when an external oscillator
is placed on it. It will then output a clock signal
on the CLKIO pin of the FX2 connector.
The unloaded jumper J8 provides access to all
possible clock signals into and out of the FX2
MIB. This includes the signal CLKIO from the
external oscillator socket connector as well as
CLKIO and CLKOUT signals directly from the
FX2 connector.
See Table1 for more details.
www.digilentinc.com page 2 of 4
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
FX2 MIB Reference Manual
Table 1 FX2 Signals and Connector Pinout
A Pinout B Pinout
1 VCC 1 SHLD
2 VCC 2 GND
3 TMS 3 TDI
4 JTSEL 4 TCK
5 TDO 5 GND
6 IO1 6 GND
7 IO2 7 GND
8 IO3 8 GND
9 IO4 9 GND
10 IO5 10 GND
11 IO6 11 GND
12 IO7 12 GND
13 IO8 13 GND
14 IO9 14 GND
15 IO10 15 GND
16 IO11 16 GND
17 IO12 17 GND
18 IO13 18 GND
19 IO14 19 GND
20 IO15 20 GND
21 IO16 21 GND
22 IO17 22 GND
23 IO18 23 GND
24 IO19 24 GND
25 IO20 25 GND
26 IO21 26 GND
27 IO22 27 GND
28 IO23 28 GND
29 IO24 29 GND
30 IO25 30 GND
31 IO26 31 GND
32 IO27 32 GND
33 IO28 33 GND
34 IO29 34 GND
35 IO30 35 GND
36 IO31 36 GND
37 IO32 37 GND
38 IO33 38 GND
39 IO34 39 GND
40 IO35 40 GND
41 IO36 41 GND
42 IO37 42 GND
43 IO38 43 GND
44 IO39 44 GND
45 IO40 45 GND
46 GND 46 CLKIN
47 CLKOUT 47 GND
48 GND 48 CLKIO
49 VU 49 VU
50 VU 50 SHLD
Digilent, Inc.
www.digilentinc.com
www.digilentinc.com page 3 of 4
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
FX2 MIB Reference Manual
Table 2 Pmod Connector Pin Layouts
J1 Top Set of Pins
Pin Pinout
1 IO1
2 IO3
3 IO5
4 IO7
5 GND
6 VDD
J2 Top Set of Pins
Pin Pinout
1 IO9
2 IO11
3 IO13
4 IO15
5 GND
6 VDD
J3 Top Set of Pins
Pin Pinout
1 IO17
2 IO19
3 IO21
4 IO23
5 GND
6 VDD
J4 Top Set of Pins
Pin Pinout
1 IO25
2 IO27
3 IO29
4 IO31
5 GND
6 VDD
J5 Pins
Pin Pinout
1 IO33
2 IO34
3 IO35
4 IO36
5 GND
6 VDD
Digilent, Inc.
www.digilentinc.com
J1 Bottom Set of Pins
Pin Pinout
7 IO2
8 IO4
9 IO6
10 IO8
11 GND
12 VDD
J2 Bottom Set of Pins
Pin Pinout
7 IO10
8 IO12
9 IO14
10 IO16
11 GND
12 VDD
J3 Bottom Set of Pins
Pin Pinout
7 IO18
8 IO20
9 IO22
10 IO24
11 GND
12 VDD
J4 Bottom Set of Pins
Pin Pinout
7 IO26
8 IO28
9 IO30
10 IO32
11 GND
12 VDD
J6 Pins
Pin Pinout
1 IO37
2 IO38
3 IO39
4 IO40
5 GND
6 VDD
www.digilentinc.com page 4 of 4
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
