Digifly DU8 User Manual
OSD
Open System Digifly
DIGIFLY
Display Unit 8
INSTRUMENTATION
SW 2.02
USER MANUAL
User Manual
User Manual
TABLE OF CONTENTS
Chapter 1 - Introduction
Chapter 2 - Getting started
- Front panel ..................................................... par. 2.1
- The display ..................................................... par. 2.2
- The keyboard .................................................. par. 2.3
- Turning On / Off ................................... par. 2.3.1
- Contrast ............................................. par. 2.3.2
- Brightness ............................................ par. 2.3.3
- Page toggle .......................................... par. 2.3.4
- Basic functions ..................................... par. 2.3.5
Chapter 3 - INSTRUMENTATION
- Main functions ................................................ par. 3.1
- Altimeters ........................................... par. 3.1.1
- Recorder .............................................. par. 3.1.2
- Switching the central window ............... par. 3.1.3
- Functions menù .............................................. par. 3.2
- Replay ............................................................ par. 3.3
- Agenda ........................................................... par. 3.4
- Set Up ............................................................ par. 3.5
- In lines set up ...................................... par. 3.5.1
- Measure units ...................................... par. 3.5.2
- Warnings ............................................. par. 3.5.3
Chapter 4 - System test
Chapter 5 - Installation
- General warnings ........................................... par. 5.1
- Electrical wiring .............................................. par. 5.2
- Technical features .......................................... par. 5.3
5.3 - Technical features.
- Monochrome, high resolution, 8", 480 x 640 pixel LCD,
backlighted;
- Antiscratch protection;
- Contrast and brightness regolation;
- Lighted keyboard;
- Digifly OSD interface;
- External GPS interface;
- Power source: 10-28 V DC ( 0.4 Amp );
- Weight 850 gr.;
- Size :
1
2
0
User Manual
User Manual
chapter 1
INTRODUCTION ( Open System Digifly )
The Digifly viewing units were designed also to co-operate with each
other in the same system. This is known as “multiscreen” system
and it is made up of different Display Units (DU7-DU8) linked to the
flight recorder. Among all the connected units, only one must be set
up in MASTER mode, whereas all the others must be set up in SLAVE mode. In this manner, the viewing device (MASTER) will direct
data transmission operations and one or more devices (SLAVE) will
operate only as viewers. Only the MASTER device will be capable
of adjusting the flight-recorder settings. The MASTER/SLAVE mode
can be set in Set Up.
Therefore the Digifly Open System is now even more advanced and
complete in order to meet any need of pilots and flight enthusiasts,
significantly increasing the precision and safety standards supplied
by the instruments presently available in the market.
19
2
5.2 - Electrical wiring.
User Manual
User Manual
chapter 2
GETTING STARTED
2.1 - Front panel.
2.2 - The display.
chapter 5
INST ALLATION
5.1 - General warnings.
3
18
