Digifly AIR Pro BT User Manual

AIR Pro BT
Firmware 142 IT
Rev. 53 a UK
Page 2
CONGRATULATIONS
Thank you for choosing Digifly!
You have purchased a high technology instrument designed expressly for free flight. The multiple functions
and flight data it provides, effectively make it an on board computer. Learning to use this instrument will make your flying easier in terms of performance and safety. It will enable you to improve your flying technique and make piloting decisions more quickly thanks to the comprehensive flight information that is provided. Another benefit is the ability to download and analyze your flight data afterwards.
Our designing effort foresees also to the future software developments, so the software at the heart of this
instrument can be updated at any time via the Internet using the Digifly PC cable.
DIGIFLY INTERNATIONAL GUARANTEE Dear Customer,
Thank you for purchasing this Digifly product which has been designed and manufactured to the highest
quality standards. Digifly warrants this product to be free from defects in materials and workmanship for 3 years from the date of purchase.
The Digifly guarantee applies provided the product is handled properly for its intended use, in accordance
with its operating instructions and upon presentation of the original invoice or cash receipt, indicating the date of purchase, the dealer’s name, the model and the serial number of the instrument.
The customer is however, responsible for any transportation costs. The unit must be securely packaged for
return.
The Digifly guarantee may not apply if:
- The documents have been altered in any way or made illegible.
- Repairs or product modifications and alterations have been executed by unauthorized person or service.
- Damage is caused by accidents including but not limited to lightning, water or fire, misuse or neglect, or every malfunction not related to manufacturing defects of your instruments.
If your Digifly product is not working correctly or is defective, please contact your Digifly dealer. In order to
avoid unnecessary inconvenience.
Digifly Europe s.r.l. Bologna
Italy www.digifly.com
info@digifly.com
Page 3
1 INDEX
1 INDEX .................................................................................................................................................................. 3
2 GETTING STARTED ............................................................................................................................................ 6
2.1 CONNECTIONS ................................................................................................................................................................... 6
2.2 BATTERY ............................................................................................................................................................................. 6
2.2.1 BATTERY RECHARGE ............................................................................................................................................... 6
2.2.2 EXTERNAL POWER SUPPLY .................................................................................................................................... 6
2.3 KEYBOARD - NORMAL OR LONG KEY PRESS ............................................................................................................... 6
2.4 TURNING ON & OFF ........................................................................................................................................................... 7
2.5 DISPLAY CONTRAST ADJUSTMENT ................................................................................................................................. 7
2.6 MENU................................................................................................................................................................................... 7
2.6.1 DISPLAY’S FIELS EDITING ....................................................................................................................................... 7
2.6.2 ALPHANUMERICAL FIELDS EDITING ..................................................................................................................... 8
2.7 MULTI LANGUAGE HELP ................................................................................................................................................... 8
2.8 RESTORE FACTORY SETTINGS ........................................................................................................................................ 8
2.9 RESET .................................................................................................................................................................................. 8
3 QUICK REFERENCE GUIDE ................................................................................................................................. 9
3.1 SYMBOLS MENU ................................................................................................................................................................ 9
3.2 PLOTTER SCREEN ........................................................................................................................................................... 10
3.3 COMPASS SCREEN ......................................................................................................................................................... 11
4 DISPLAY .......................................................................................................................................................... 12
4.1 MAIN SCREENS .............................................................................................................................................................. 12
4.2 PLOTTER AND COMPASS SCREENSINSTRUMENTS FIELDS ............................................................................ 13
4.2.1 VARIOMETER ....................................................................................................................................................... 13
4.2.2 ANEMOMETER ..................................................................................................................................................... 13
4.2.3 GRAPHIC ALTIMETER ........................................................................................................................................ 13
4.2.4 COMPASS SCREEN ESSENTIAL INSTRUMENTS ........................................................................................... 13
4.2.5 PLOTTER PAGE ESSENTIAL INSTRUMENTS ..................................................................................................... 13
4.2.6 NAVIGATION PLOTTER SCREEN ...................................................................................................................... 14
4.2.7 HSI NAVIGATION PLOTTER PAGE ................................................................................................................... 14
4.2.8 BEARING COMPASS .......................................................................................................................................... 14
COMPASS SCREEN MAIN FIELDS .......................................................................................................................................... 14
4.2.9 COMPASS SCREEN, NAVIGATION TO THE START LINE ................................................................................. 14
5 BASIC FUNCTIONS ........................................................................................................................................... 15
5.1 ALTIMETERS .................................................................................................................................................................... 15
5.1.1 ALTIMETERS SETTINGS ........................................................................................................................................ 15
5.2 VARIOMETERS ................................................................................................................................................................ 15
5.2.1 SUPERFAST INTELLIVARIO ................................................................................................................................... 15
5.2.2 VARIO SENSIBILITY ............................................................................................................................................... 15
5.2.3 VARIO REACTIVITY ................................................................................................................................................ 16
5.2.4 ANALOGICAL VARIO .............................................................................................................................................. 16
5.2.5 INTEGRATED AVERAGE VARIO ............................................................................................................................ 16
5.2.6 ACOUSTIC VARIO ................................................................................................................................................... 16
5.2.7 ACOUSTIC VARIO PRE-THERMAL ADVIDSE ...................................................................................................... 17
5.2.8 VARIO SIMULATOR ................................................................................................................................................ 17
5.3 AIR SPEED (ANEMOMETER WITH OPTIONAL PITOT TUBE) .................................................................................. 17
5.4 ANEMOMETER SETTING (WITH OPTIONAL PITOT TUBE) ....................................................................................... 17
5.5 TIME & CHRONOGRAPH ................................................................................................................................................ 17
5.6 DISTANCES ...................................................................................................................................................................... 18
Page 4
5.7 AIR EFFICIENCY (GLIDE RATIO) .................................................................................................................................... 18
5.8 TRACKING & BEARING .................................................................................................................................................. 18
5.9 BAROMETER ................................................................................................................................................................... 18
5.10 TIME/CHRONOGRAPH SETUP ..................................................................................................................................... 18
5.11 PILOT’S NAME & GLIDER’S DATA ................................................................................................................................. 19
6 ADVANCED FUNCTIONS .................................................................................................................................. 19
6.1 TOTAL ENERGY COMPENSATION ................................................................................................................................. 19
6.2 POLAR (WITH OPTIONAL PITOT TUBE) ......................................................................................................................... 19
6.3 SPEED TO FLY (WITH OPTIONAL PITOT TUBE) ........................................................................................................... 20
6.4 MCCREADY (WITH OPTIONAL PITOT TUBE) .............................................................................................................. 21
6.5 EQUIVALENT CCREADY (WITH OPTIONAL PITOT TUBE) ............................................................................................. 21
6.6 NETTO VARIO (WITH OPTIONAL PITOT TUBE) ............................................................................................................ 21
7 GPS FUNCTIONS .............................................................................................................................................. 22
7.1 INTEGRATED 99 CHANNELS GPS RECEIVER ............................................................................................................ 22
7.2 GPS STATUS INFORMATION ......................................................................................................................................... 22
7.3 GPS INFORMATION DISPLAY ........................................................................................................................................ 22
7.4 LATITUDE & LONGITUDE COORDINATES OPTIONS .................................................................................................... 22
7.5 GPS ALTITUDE ................................................................................................................................................................. 22
7.6 GPS GROUND SPEED ................................................................................................................................................... 22
7.7 GPS DIRECTION (TRK) .................................................................................................................................................... 23
7.8 GROUND EFFICIENCY (GLIDE RATIO) ........................................................................................................................... 23
7.9 WIND SPEED AND DIRECTION INDICATION USING GPS ...................................................................................... 23
7.10 LAST THERMAL DIRECTION, DISTANCE, HEIGHT INFORMATION ......................................................................... 23
8 WAYPOINT MANAGEMENT ............................................................................................................................ 23
8.1 DATABASE WAYPOINT COMPETITION AND WAYPOINT USER ............................................................................... 23
8.1.1 CREATING A NEW WAYPOINT MANUALLY .................................................................................................... 24
8.1.2 CREATING A NEW WAYPOINT USING THE CURRENT POSITION (MARK) .............................................. 24
8.1.3 EDIT WAYPOINT .................................................................................................................................................... 24
8.1.4 DELETE WAYPOINT............................................................................................................................................... 24
9 NAVIGATE TO A WAYPOINT (GOTO) ........................................................................................................... 25
9.1 ACTIVATING NAVIGATION TO A WAYPOINT (GOTO) ............................................................................................... 25
9.1.1 NAVIGATION TO WAYPOINT HOME (GOTO HOME) ....................................................................................... 25
9.1.2 NAVIGATION TO THE NEAREST LANDING ZONE (GOTO LANDING) ................................................................ 25
9.1.3 NAVIGATION TO THE NEAREST WAYPOINT (GOTO NEAREST) ................................................................... 25
9.1.4 NAVIGATION TO A GENERIC WAYPOINT (GOTO) .......................................................................................... 25
9.1.5 DEACTIVATING NAVIGATION TO A WAYPOINT (GOTO)................................................................................ 26
9.2 NAVIGATION’S FUNCTIONS TO A WAYPOINT (GOTO) ............................................................................................ 26
9.2.1 DIRECTION, DISTANCE, HEIGHT TO CURRENT WAYPOINT (GOTO) .......................................................... 26
9.2.2 NEEDED GLIDE RATIO TO THE CURRENT WAYPOINT (GOTO) ................................................................... 26
9.2.3 ARRIVAL HOUR, ARRIVAL TIME TO THE CURRENT WAYPOINT (GOTO) ................................................ 26
9.2.4 HSI GRAPHIC INDICATION TO THE CURRENT WAYPOINT (GOTO) .......................................................... 26
10 ROUTE MANAGEMENT ................................................................................................................................... 26
10.1 PREFIXED GENERAL ROUTES .................................................................................................................................... 26
10.1.1 VISUALIZING WAYPONT DATA OF A ROUTE ................................................................................................. 27
10.1.2 INSERT A WAYPOINT IN A ROUTE .................................................................................................................. 27
10.1.3 SUBSTITUTE A WAYPOINT IN A ROUTE ......................................................................................................... 27
10.1.4 MODIFY A WAYPOINT IN A ROUTE (PARAMETER CHANGE) ...................................................................... 27
10.1.5 DELETE A WAYPOINT IN A ROUTE ................................................................................................................. 29
10.2 ACTIVATING A ROUTE ................................................................................................................................................... 29
10.3 DE-ACTIVATING A ROUTE ............................................................................................................................................. 29
10.4 DELETING A ROUTE ...................................................................................................................................................... 29
11 OPERATION CHECKLIST BEFORE A TASK .................................................................................................. 30
Page 5
12 NAVIGATION ROUTE ........................................................................................................................................ 30
12.1 DIRECTION, DISTANCE & HEIGHT ON THE WAYPOINTS ............................................................................................ 30
12.2 NEEDED GLIDE RATIO TO CURRENT WAYPOINT / NEXT WAYPOINT / GOAL .................................................... 30
12.3 OPTIMIZED NAVIGATION .............................................................................................................................................. 31
12.4 NAVIGATION TO START PYLON WAYPOINT ............................................................................................................. 31
12.5 NAVIGATION TO STANDARD WAYPOINT ..................................................................................................................... 33
12.6 NAVIGATION TO CONCENTRIC WAYPOINT ............................................................................................................... 33
13 FLIGHT RECORDER ......................................................................................................................................... 34
13.1 ACTIVATING / DE-ACTIVATING FLIGHT RECORDER .................................................................................................. 34
13.1.1 AUTOMATIC START RECORD MODE “AUT” ........................................................................................................ 34
13.1.2 ALWAYS ACTIVE RECORD MODE “ALW” ............................................................................................................ 34
13.1.3 RECORD MODE OFF “OFF” ................................................................................................................................... 34
13.2 RECORD RATE ................................................................................................................................................................. 34
13.3 LOG BOOK MANAGEMENT (LOG BOOK ) ................................................................................................................... 35
14 CONNECTIONS, INTERFACES & MEMORY CARD .......................................................................................... 35
14.1 USB CABLE CONNECTION .............................................................................................................................................. 35
14.2 BLUETOOTH CONNECTION............................................................................................................................................ 36
14.2.1 DEVICES CONNECTION “PAIRING” ...................................................................................................................... 36
14.2.2 BLUETOOTH DATA TRANSFER ACTIVATION ....................................................................................................... 37
14.3 ADDITIONAL MEMORY ................................................................................................................................................ 37
15 SOFTWARE ...................................................................................................................................................... 38
15.1 SOFTWARE COMPATIBILITY ......................................................................................................................................... 38
15.2 SOFTWARE: DIGIFLY AIRTOOLS .................................................................................................................................. 38
15.3 SOFTWARE: GPSDUMP PC & GPSDUMP MAC ......................................................................................................... 38
15.4 FIRMWARE UPDATE (INSTRUMENT'S SOFTWARE) .................................................................................................... 39
15.5 FIRMWARE UPDATING PROCEDURE ........................................................................................................................... 39
15.6 TELEMETRY DATA OUTPUT .......................................................................................................................................... 40
15.6.1 TELEMETRY DATA SELECTION ........................................................................................................................... 40
15.7 LK8000 ............................................................................................................................................................................ 42
15.8 XCSOAR ........................................................................................................................................................................... 42
16 APPENDIX ........................................................................................................................................................ 43
16.1 DIGIFLY AIR STANDARD ACCESSORIES ................................................................................................................... 43
16.2 OPTIONAL ACCESSORIES ............................................................................................................................................. 43
16.3 TECHNICAL FEATURES .................................................................................................................................................. 43
16.3.1 STANDARD FUNCTIONS ........................................................................................................................................ 43
16.3.2 ADVANCED FUNCTIONS ........................................................................................................................................ 43
16.3.3 GPS FUNCTIONS .................................................................................................................................................... 43
16.3.4 GENERAL SPECIFICATIONS ................................................................................................................................. 44
16.4 MAIN SET UP MENU PARAMETERS .............................................................................................................................. 45
16.5 VARIOMETER SETUP PARAMETERS .......................................................................................................................... 45
16.6 ADV-SETUP PARAMETERS MENU (ADVANCED SETUP) ........................................................................................... 46
16.7 RESTORE FACTORY SETTINGS (DEFAULT PARAMETERS) ........................................................................................ 46
16.8 RESET ............................................................................................................................................................................... 46
Page 6
2 GETTING STARTED
2.1 CONNECTIONS
The mini USB socket provides the battery charge and the link to a Personal Computer. Micro SD card slot. Bluetooth connection.
2.2 BATTERY
The main power is supplied by an internal rechargeable high capacity lithium battery. This battery has no
memory effect, so it can be partially recharged, without affecting the battery’s time life. It also has a very low
self-discharge rate (more than one year) and works very well at low temperatures. A fully charged battery life
ranges over 30 hours.
When the battery’s icon starts to blink there are roughly 4 hours use remaining.
2.2.1 BATTERY RECHARGE
To recharge the instrument insert the charger plug or other mini USB accessory and wait till the battery level
indicator is totally filled.
The required time for a full charge is about 8 hours. There are no problem if you leave the vario charging for more than 8 hours, as the vario automatically
switches to a “maintain mode” to prevent the battery’s overcharge.
The Digifly AIR’s lithium battery has no “memory effect”, so it can be also partially charged.
2.2.2 EXTERNAL POWER SUPPLY
The mini USB socket can be used to power the instrument and simultaneously charge the internal battery for
unlimited time.
With the instrument turned on, it is necessary an external stabilized 5VDC power supply (e.g. a solar panel)
and a minimum of 150mA to properly power the instrument. The exceeding electric current will be used
charge the internal lithium battery. Proper solar panels are suitable to power the instrument.
2.3 KEYBOARD - NORMAL OR LONG KEY PRESS
The time length you press the keys on your Digifly instrument selects the available functions. Normal press key means to press the button for less than a second For a long key press, you must keep the button pressed down for at least 2 seconds When not specified, the key press has to be considered as a normal key press (less than a second).
mini USB connector
micro SD slot
Page 7
2.4 TURNING ON & OFF
To turn on your Digifly instrument, press the key at least for 4 seconds. To turn off your Digifly instrument, press the key at least for 4 seconds.
After switching off your Digifly instrument, you must wait at least 5 seconds before to be able to turn it on
again. This prevents unwanted operation e.g. during the transit in your glider bag.
After turning on your Digifly instrument, the first screen briefly shows the vario model, pilot name (if set),
logger status, vario serial number, software version, date, time and battery voltage.
2.5 DISPLAY CONTRAST ADJUSTMENT
The LCD display contrast can be adjusted to suit ambient light conditions using the keys: ‘arrow UP’ or
‘arrow DOWN’ , operating from the pages ‘plotter’ or ‘compass’.
To change the contrast of the display, press the key to enter in the “MAIN SETUP” menu, select the menu
(MAIN SETUP \ n. 1 CTRS), go to the edit mode pressing the key , set the preferred contrast using the keys:
‘arrow UP’ or ‘arrow DOWN’ , then save the changes pressing the key .
2.6 MENU
To navigate the menus of your instrument press the key (“MENU”
function).
To select the sub-menus navigate the list UP or DOWN using the
arrow keys then confirm your choice pressing the key (“ENT”
function).
To exit and come back to the main screen press the key (“ESC”
function).
2.6.1 DISPLAY’S FIELS EDITING
To change parameters and settings, select the parameter you want to
change navigating UP or DOWN using the keys, press the
key (“EDIT” function) to enter in the edit mode.
To change the value of the selected parameter use the keys, every parameter’s change is
automatically saved (“AUTOSAVE” function), a longer press of the keys activate the quick parameter’s
change (“AUTOREPEAT” function).
To exit from the edit function press the key (“ESC” function).
MENU
Wpt Airfields
Wpt Nearest
Wpt Competitions
Wpt Users
Routes
Altimeters
Logbook
AirTools
Main Setup
Advanced Setup
Variometer Setup
Bluetooth pairing
Page 8
2.6.2 ALPHANUMERICAL FIELDS EDITING
The alphanumerical fields editing is different from the standard one described in the above paragraph,
because it is possible to modify every single character of the field.
To modify the field press the key (“EDIT” function) to activate the edit mode. Use the arrow keys to change the character shown in reverse mode on the display, every parameter’s
change is automatically saved (“AUTOSAVE” function), a longer press of the arrow keys activate the quick
parameter’s change (“AUTOREPEAT” function),
Pressing the key, it is possible to shift to the character on the right to edit it, repeatedly pressing key it
is possible to scroll toward right all the field’s characters to come back to the first of the field. A longer press
of the key comes back toward left. To exit press the key.
2.7 MULTI LANGUAGE HELP
In the menus are visible some help messages, e.g.: help to set the parameters. For these messages it is
possible to set the preferred language entering in the MAIN SETUP menu (MAIN SETUP \ n. 2 LANG) then
select the language you prefer and confirm.
IMPORTANT: after every firmware update, it is necessary to update also the help file containing the messages.
The help file update can be done from your PC using the Digifly AirTools, function: “upload HELP”.
2.8 RESTORE FACTORY SETTINGS
To restore the factory settings (default values for all parameters), turn on the instrument pressing at the same
time and holding down the keys & until the message “FACTORY SET?” appears. To confirm press the
key and the display will show the “SETUP RESET” message, to avoid the restore press the key.
2.9 RESET
If a system crash would occur with a consequent instrument’s block, to reset its functions press at the same
time the keys: and holding them pressed for more than 4 seconds.
Page 9
3 QUICK REFERENCE GUIDE
3.1 SYMBOLS MENU
Battery level
Bluetooth activated
GPS connected
Flight recorder on
Volume level
Direction toward the center of the current Waypoint
Direction toward the current WP accordingly to the optimized route
Direction to the current WP for optimized route, HIS representation
Closest START line direction
Last thermal direction
Wind direction
Page 10
3.2 PLOTTER SCREEN
Mini USB connector Batt. charge / PC
McCready
Digital vario
Altimeter A1
WP name Current glide ratio
McCready equivalent
Direction to WP center
Analogical vario scale
Analogical avg. vario
Volume level
Contrast +
● ● Instrument On/Off
Contrast -
● ● Volume level 1-2-Off
Bluetooth ON
Analogical G-meter
Analogical vario
Memory card slot micro SD
Compass
Ground speed GPS
Height to WP
Optimized route to WP
Required glide ratio to the next WP
Digital anemometer
Analogical
Battery level
GPS signal
Flight recorder ON
Menu / Return
Change page
● ● Reset altimeter A2
Distance to WP
Optimal spd to fly STF
Direction symbols
Wind direction /speed
Page 11
3.3 COMPASS SCREEN
● = Normal key pressure ● ● = Long key Pressure (2 seconds)
McCready equivalent
Digital Vario
Analogical altimeter
A1 digital altimeter
McCready
Volume level
Analogical vario scale
Analogical avg. vario
Compass main points
Contrast +
● ● Instrument On/Off
Contrast -
● ● Volume level 1-2-Off
External compass ring (direction to WP)
Bluetooth ON
Internal compass ring (thermal & wind)
Analogical G-meter
Analogical Vario
Syspem, symbols
battery, GPS, recorder
GPS ground speed
Time to START
Optimal spd to fly STF
Distance to WP
Req.glide ratio to next
Distance to GOAL
Analogical Anemometer
Clock
Digital anemometer
START line distance
START direction
Current glide ratio
Menù / Return
Change page
● ● Reset alimeter A2
Page 12
4 DISPLAY
4.1 MAIN SCREENS
The Digifly Air features a lot of different main screens (page), to manually change the pages press the key.
PLOTTER PAGE
COMPASS PAGE
INFO GPS PAGE
LatLon ddmmss.ss
05 43’46.5N
005 43’46.5E
141 Tracking
00 Ground Speed
245 Altitude GPS
03/11/13 16:12:03
Page 13
4.2 PLOTTER AND COMPASS SCREENS – INSTRUMENTS FIELDS
4.2.1 VARIOMETER
In the variometer’s informations area can be seen:
o Digital variometer; o Average vario / Netto vario; o Mc Ready value; o Mc Ready equivalent value
4.2.2 ANEMOMETER
In the shown anemometer’s informations area can be seen:
o Analogical gauge - roll type- of Indicated Air Speed (IAS); o Indicated Air Speed (IAS) digital value; o Ground speed GS; o Optimal glide speed STF;
If the optional Pitot tube is not installed, it will be shown analogically and
digitally the ground speed (GS) only.
4.2.3 GRAPHIC ALTIMETER
In the COMPASS page, the altimeter’s digital information is integrated with a
graphic sliding scale. This scale is intuitive to be understood and feature a
numeric indication of the 500 and 1000 m altitude’s gap in a graphic design that
enables, at a glance, a visual distinction of the height. It features also a simple
graduated scale for the hundreds meters.
4.2.4 COMPASS SCREEN ESSENTIAL INSTRUMENTS
In the COMPASS page the essential flight info are simply shown aligned in a
raw.
Aligned with the digital variometer you can find the altimeter A1 value, the
current glide ratio and the Indicated Air Speed (if the optional pitot tube is
installed) or the GPS ground speed
4.2.5 PLOTTER PAGE ESSENTIAL INSTRUMENTS
In the PLOTTER page, the essential info are slightly different from the compass
page, to allow the availability of a larger amount of info for the navigation.
Aligned to the digital variometer, on the display’s opposite side is located the
IAS/GS indicator, while the altimeter A1 and the glide ratio are positioned on the
left-upper side of the display.
Page 14
4.2.6 NAVIGATION PLOTTER SCREEN
In the PLOTTER page the navigation is based on a graphic perspective plotter that
features:
o Graphic representation of the flight track toward the current WP; o Graphic representation of the current WP cylinder; o Optimized course line to the current WP cylinder; o Optimized course line to the next WP; o Wind’s direction and intensity;
The following info are listed in digital format:
o Required glide ratio to the current WP and its distance; o Expected height of arrival above the Current WP and current glide ratio; o Current WP name.
4.2.7 HSI NAVIGATION PLOTTER PAGE
In the center of the PLOTTER page are represented two dotted lines crossed,
where the crossing point indicates the current WP with its real altitude. During
the glide to WP the “plane” symbol, moves toward the right or the left of the
vertical dotted line to indicate a wrong route to the cylinder’s center and moves
above or below the horizontal dotted line to indicate if with the current glide will
arrive above or below the WP.
Along the horizontal line, the symbol represents the optimized direction to the current WP.
4.2.8 BEARING COMPASS
On the bottom of the PLOTTER page there is a bearing compass showing also all
the navigation’s info with graphics symbols (WP direction, wind etc.…).
If the GPS signal is valid, the direction is the TRK of the GPS track, otherwise it is
represented the AIR’s internal magnetic compass.
COMPASS SCREEN MAIN FIELDS
In the COMPASS page, the navigation info are represented with a series of
concentric circles with some rotating symbols:
- Outside the circle there are the N-E-S-W points;
- In the outer ring are rotating the direction to WP symbols;
- In the inner ring are rotating the direction to the last thermal, the wind direction
and wind speed symbols.
4.2.9 COMPASS SCREEN, NAVIGATION TO THE START LINE
In the COMPASS page, during the task’s phase preceding the Start, the pilot finds some
specific info to navigate to the Start line.
On the top section there is a clock and below a field with the countdown timer to start.
Page 15
Below the glide ratio indicator is shown the distance of the Start Line closest to the pilot and its direction. After the Start and once correctly passed the Start line, these fields can be optionally used for other info on
pilot’s choice.
5 BASIC FUNCTIONS
5.1 ALTIMETERS
The Digifly AIR features 7 different altimeters: A1, A2, AG, A3, H1, HA.
- A1: Barometric altimeter.
- A2: Altimeter A2.
- AG: Altimeter GPS.
- A3: Last thermal height gain
- H1: Estimated height over current WP
- HA: Estimated height over goal.
5.1.1 ALTIMETERS SETTINGS
Enter in the “ALTIMETERS” menu and select which altimeter to set (A1 or A2). The A2 altimeter is suitable for general purpose. To reset the A2 altimeter hold pressed the key from the
PLOTTER or COMPASS pages;
The A3 altimeter is automatically reset while entering in a thermal. The altimeters can be displayed in meters (mt) or feet (ft). To change the altitude’s unit of measure enter the
setup from (MAIN SETUP \ n. 15 U-AL).
5.2 VARIOMETERS
5.2.1 SUPERFAST INTELLIVARIO
The Intellivario is a revolutionary digital system designed by Digifly, based on sophisticated integrated circuits
combining info coming from the atmospheric pressure sensor joined with the inertial platform data
(accelerometer, magnetometer and gyroscopes). This allows to obtain a highly precise and sensible vario,
exempt from radio interferences. All the vario data are subject to this filter.
The Digifly AIR utilizes an extremely sensible pressure sensor and an excellent data acquisition sys providing a
very quick and extremely precise vario (updated 24 times each second).
5.2.2 VARIO SENSIBILITY
Three different electronic filters are available to change the vario’s sensibility. These settings allow the pilot to
get a strong instrument’s customization, to better adapt it to his flight habits and needs.
Filter 1, adjustable in the menu (VARIOMETER SETUP \ n. 10 FLT1), default value 80% , suggested use range
from 70% to 95%, reducing this value makes the vario very sensible to variations.
Filter 2, adjustable in the menu (VARIOMETER SETUP \ n. 11 FLT2), default value 72, suggested use range
Page 16
from 48 to 96, reducing this value makes the vario very sensible to variations.
Filter 3, adjustable in the menu (VARIOMETER SETUP \ n. 12 FLT3), default value 0%, suggested use range
from 0% to 10%, reducing this value makes the vario very sensible to variations.
5.2.3 VARIO REACTIVITY
To adjust the vario’s reactivity, enter in the menu: (VARIOMETER SETUP \ n. 13 RVAR). The default value is 0.
To slow the reactivity, increase this parameter.
5.2.4 ANALOGICAL VARIO
Indicates the instant vario values. It is displayed by the analogical bar indicator on the left of the screen, it
shows the sink or climb rate within a +/- 5 m/s range.
5.2.5 INTEGRATED AVERAGE VARIO
Shows the integrated vario values. This means an average data reading (slowed down in the time) of the
instant vario.
Can be set slowed down or immediate. Setting to the minimum the integrated vario value, the shown value
will be the same of the instant vario (factory setting).
It can be used to monitor the proceeding of the climb to see if it is getting better or worse. For example: if the
integrated vario value is higher of the instant vario one, means that previously the climb was stronger. It can
be used therefore to better core the thermal.
To change the integration time, set the parameter: (VARIOMETER SETUP \ n. 14 INTE) from 0 to 60 seconds.
It is analogically displayed on the right of the instant variometer, with a bar showing the climb or sink rate with
a range +/- 5 m/s. During the glide the gauge alternates with the “NETTOVARIO”.
5.2.6 ACOUSTIC VARIO
The acoustic vario represents the instantaneous values of the vario with a modulated acoustic tone. Pressing the key (long pressure) the sound’s volume changes into three levels: “HIGH”, “OFF” & “LOW”.
The chosen volume is shown by the ‘loudspeaker’ icon on the center left of the display.
To set the sound’s threshold level to indicate lift, go to parameter (VARIOMETER SETUP \ n. 1 V.UP), for the
sink, go to (VARIOMETER SETUP \ n. 3 V.DN).
It is possible to set the preferred acoustic profile with the parameter (VARIOMETER SETUP \ n. 4 PROF). Three
pre-set profile are available: FAS, STD, SFT, Two fully customizable profile: USR1, USR2 are available via PC
using the AirTools software; moreover, there is a new manual ‘MAN’ mode, that allows to directly customize
the instrument using the following parameters.
Style, (VARIOMETER SETUP \ n. 5 STYL) relation among sound/pause, values from 1 to 3. Modulation, (VARIOMETER SETUP \ n. 6 MODH) increases the tone frequency from 1 to 30 Hz. Pitch, increases ascending the tones rhythm (VARIOMETER SETUP \ n. 7 PITC) values from 1 to 4. Climb start tone’s frequency (VARIOMETER SETUP \ n. 8 UPHZ) Sink start tone’s frequency (VARIOMETER SETUP \ n. 9 DWHZ) Autosilence, (VARIOMETER SETUP \ n. 19 AUTV) activates the acoustic vario only after the takeoff and stops it
Page 17
60 seconds after the landing.
5.2.7 ACOUSTIC VARIO PRE-THERMAL ADVIDSE
If activated, an acoustic signal with a tone and modulation significantly different of the acoustic vario,
indicates that the instantaneous sink rate is better of the glider’s minimum sink rate, therefore indicating an
area of slightly climbing air. To set the pre-thermal sound’s start threshold go to: (VARIOMETER SETUP \ n. 2
V.PT) value from 0,00 to 1,00 m/s. Suggested value 0,4 m/s.
5.2.8 VARIO SIMULATOR
For a perfect tuning of the acoustic vario without flying, it is possible to set the ‘vario simulator’ mode, setting
“ON” the parameter (VARIOMETER SETUP \ n. 18 SIMV). Then exit from menu and use the arrow keys
to set the preferred vario sound.
To deactivate the simulator set to “OFF” the parameter “SIMV”. Anyway, for safety reasons the simulator is
automatically deactivated when the instrument power on.
5.3 AIR SPEED (ANEMOMETER WITH OPTIONAL PITOT TUBE)
This sensor measures the glider’s air speed (Indicated Air Speed) that can be visualized in km/h or mph. To
change this parameter use the menu (MAIN SETUP \ n. 16 U-SP).
This function is available only installing the Pitot tube sensor module (optional). The tube will have to be
inserted in the specific housing hole located on the instrument’s top, and the parameter (ADVANCED SETUP \
n. 1 PITO) have to be set to “ON”.
The minimum speed indication is 18 km/h.
5.4 ANEMOMETER SETTING (WITH OPTIONAL PITOT TUBE)
It is possible to perform a fine tuning of the anemometer using the parameter (ADVANCED SETUP \ n. 3 KIAS)
it indicates the anemometer’s correction value (100%=no correction, 110%=increase, 90%=decrease).
Warning: a wrong use of this parameter makes less reliable the anemometer’s indications, the calibration of
the anemometer with the Pitot tube should have done at the sea level in standard atmosphere conditions.
5.5 TIME & CHRONOGRAPH
The Digifly AIR can visualize the expected hour and time referred to a route’s waypoint, or a goal arrival. Relative time (hour/min or min/sec with blinking points)
- ero: relative time – expected arrival time to the start pylon cylinder shown in seconds. Negative value if it’s
too early (wrong), positive value if it’s late (right).
- es: countdown to the start time gate
- e1: expected arrival time to the current Waypoint
- eA: expected arrival time to the goal (accordingly to the route)
- ch: chronograph
Page 18
Absolute time (hour/min)
- ts: absolute time to start pylon gate
- t1: Expected absolute time to the current Waypoint.
- tA: Expected absolute time to goal.
- rt: Absolute time UTC (hours/min).
5.6 DISTANCES
It is possible to set the distance’s unit of measure using the parameter (MAIN SETUP \ n. 16 U-SP) the same
used also for the speed value.
- dstT: Distance to last thermal.
- dst1: Distance to last Waypoint.
- dstA: Distance to goal (along the route).
- dst0: Distance to the cylinder
5.7 AIR EFFICIENCY (GLIDE RATIO)
- efrT: Needed glide ratio to the last thermal.
- efr1: Needed glide ratio to current Waypoint.
- efrA: Needed glide ratio to goal (along the route).
- effA: Glide ratio referred to air.
5.8 TRACKING & BEARING
- BRT: Direction (bearing) to last thermal.
- BR0: Direction (bearing) to the center of the currrent Waypoint.
- BR1: Direction (bearing) to the optimized point of current Waypoint.
- TRK: Tracking (current direction referred to North)
5.9 BAROMETER
The barometric pressure can be visualized on every one of the customize fields. It is possible to rectify the shown pressure value modifying the calibration with the parameter (ADVANCED
SETUP \ n. 4 KBAR).
Warning: a wrong use of this parameter makes the barometric altimeter data less reliable.
5.10 TIME/CHRONOGRAPH SETUP
rt: UTC time (clock). ch: Chrono (chronometer).
To zero the chronograph, press the (long press).
Page 19
The vario time and date are automatically synchronized with the GPS data at the instrument’s power on. To set the time zone for your country go to (MAIN SETUP \ n. 7 UTCO). To manually adjust the time and date, go to (MAIN SETUP \ n. 8 HOUR), (MAIN SETUP \ n. 9 MIN), (MAIN
SETUP \ n. 10 DAY), (MAIN SETUP \ n. 11 MONT), (MAIN SETUP \ n. 12 YEAR).
5.11 PILOT’S NAME & GLIDER’S DATA
To set the pilot name, the glider type and the glider id, go to (MAIN SETUP \ n. 17 PILO), (MAIN SETUP \ n. 18
GTYP), (MAIN SETUP \ n. 19 GID).
6 ADVANCED FUNCTIONS
6.1 TOTAL ENERGY COMPENSATION
To use this function it is necessary to install the optional Pitot tube. Generally a variometer works as follows: it feels the atmospheric pressure change rate considering it as an
altitude change, but, if during the flight the pilot slows the glider (and even more if he does it quickly) there is
a real change of pressure, so a vario ‘without compensation’ records it as a climb, but this variation is caused
by a change of speed (cinetic energy) not a true thermal.
With the total energy compensation, the part of the climb due to the change in velocity is ignored, allowing you
to identify “real” thermals.
To properly set the TOTAL ENERGY
compensation value go to (VARIOMETER
SETUP \ n. 17 TEC), to do it you should fly in
calm air conditions and slow down as if you
are entering a thermal. If the vario shows a
change in lift, you have to increase the total
energy compensation value, until the
change in velocity isn’t recorded as lift.
A typical value for hang gliders is 65. The default setting of “0” deactivates the total energy compensation
function
6.2 POLAR (WITH OPTIONAL PITOT TUBE)
A polar curve (shown in bold on the figure) is the graph of
your glider’s sink rate over its speed range.
The black bold curved line represents the polar. The
glider’s stall speed is shown at point S on the left and the
glider’s max speed at point T on the right of the graph.
On the graph, you can also see three pairs of relative
speed readings and sink rates. The graph shows at point A,
the lowest sink rate achieved at the top of the curve.
Therefore SinkA is the minimum sink rate and VA is the speed at which this is achieved.
Page 20
The glide ratio is the ratio between the glider’s horizontal speed and the sink rate. To find the best glide rate
on the graph, it is necessary to draw a straight line from the origin of the graph (point O) tangent of the curve.
The intersection of the tangent with the curve (point B) shows the speed to fly at to achieve the best glide (air
related) is therefore VB and the glide ratio is VB/SinkB.
On your Digifly AIR you can insert three different polars using the function (ADVANCED SETUP \ n. 10 - 18 Px-
A/B/C). To choose which polar to use, go to (ADVANCED SETUP \ n. 9 POLA).
If this parameter (ADVANCED SETUP \ n. 6 POLA) is set to “OFF”, all information relating to McCready,
McCready Equivalent, and Netto Vario are not displayed on the instrument.
On the instrument there are three preloaded polars, (2 for hang gliders and 1 for a paraglider). Using the
Digifly AirTool software, available on the Digifly web site (www.digifly.com), it is possible to see the values of
the three default polars and to set your own polar.
We suggest that you insert your own polar curve data which best reflects the actual performance of your
glider.
6.3 SPEED TO FLY (WITH OPTIONAL PITOT TUBE)
If this parameter (ADVANCED SETUP \ n. 9 POLA) is set to “OFF”, all information
related to McCready, McCready Equivalent, and Netto Vario are not displayed
on the instrument.
Speed to Fly (STF) is the best anemometric speed to obtain the best glide ratio.
This value depends on performance of your glider as well as vertical and
horizontal airflow. In calm air, the optimum flying speed is the same as the best
glide speed (point B).
The diagram shows different values of speed to fly value related to different
flight conditions
The X-axis shows horizontal speed, the Y-axis shows sink rate. With head wind or sink conditions, the best
glide speed increases. In order to find the optimum speed to fly value in sink conditions, add the sink rate of
the air to the polar of your glider, drawing a new polar and a new tangent line from the initial point of axes.
The new tangent (point D) meets the polar at the point giving a higher optimum flying speed VD.
To fly at the correct “Speed to fly” you have to adjust your anemometric speed “IAS” to overlap the triangle
symbol with the numeric value of the optimal anemometric speed.
Speed to Fly
Optimal STF
indicator
position
Page 21
6.4 McCREADY (WITH OPTIONAL PITOT TUBE)
If this parameter (ADVANCED SETUP \ n. 9 POLA) is set to “OFF”, all
information related to McCready, McCready Equivalent, and Netto Vario are
not displayed on the instrument.
The McCready value is the average lift value of the last “nn” minutes To adjust the average lift time go to (ADVANCED SETUP \ n. 19 MCRA).
6.5 EQUIVALENT cCREADY (WITH OPTIONAL PITOT TUBE)
If this parameter (ADVANCED SETUP \ n. 9 POLA) is set to “OFF”, all information related to McCready,
McCready Equivalent, and Netto Vario are not displayed on the instrument.
This value indicates the Equivalent McCready value: this means the McCready value considering the current air
speed as the optimal speed.
The equivalent McCready, based on the glider’s polar, the sink rate and the current anemometric airspeed
(IAS), indicates in real time at with which true McCready value we are flying compared to the optimal speed.
When this value coincides with the one estimated in the thermal, this means that the current airspeed (IAS)
coincides with the optimal speed (see “speed to fly” paragraph).
To set the reaction time of the Equivalent McCready indicator go to (ADVANCED SETUP \ n. 20 MCRE).
6.6 NETTO VARIO (WITH OPTIONAL PITOT TUBE)
If this parameter (ADVANCED SETUP \ n. 9 POLA) is set to “OFF”, all information related to McCready,
McCready Equivalent, and Netto Vario are not displayed on the instrument
It is shown thru an analogic scale on the right of the instant variometer that shows the climb or sink rate
within a range +/- 5 m/s. This indicator, during the glide, alternates with the “NETTOVARIO”.
To use this function it is necessary to set the proper polar of your glider.
Equivalent
McCready
McCready
Page 22
7 GPS FUNCTIONS
7.1 INTEGRATED 99 CHANNELS GPS RECEIVER
Digifly AIR features an extremely sensible, and state-of-the-art, 99 channels integrated GPS receiver.
7.2 GPS STATUS INFORMATION
The GPS status icon is located in the status bar, on the right lower part of the display (plotter screen) or on the
lower edge of the display (compass screen) and has different meanings:
1) Fixed GPS icon = GPS FIX valid ( GPS position available)
2) Blinking GPS icon = insufficient signal (GPS position NOT AVAILABLE)
7.3 GPS INFORMATION DISPLAY
This page shows in real time: Waypoint and symbol, Latitude,
Longitude, GPS direction (“TRK”), Ground speed (“GS” in km/h or
mph), GPS Altitude (“GPS-ALT” in mt or feet), Satellite’s number
(“SAT”), GPS Signal power (“hdp”).
In the status bar is visible also the flight recorder status and the
battery level
Pressing the key (long pressure) it is possible to memorize a
Waypoint (“MARK” function), holding pressed the key activates the
navigation function “HOME”.
7.4 LATITUDE & LONGITUDE COORDINATES OPTIONS
Three different kinds of coordinates are available:
DMS = grade, minute & second (dd° mm’ ss.s) (default)
DMM = grade & minute (dd° mm.mmm’)
UTM Universal Transverse Mercator (utm x, y, zone).
To set the coordinates DMM, DMS or UTM use the parameter (ADVANCED SETUP \ n. 23 CORD).
The coordinates latitude and longitude are referred to map datum WGS84.
7.5 GPS ALTITUDE
The GPS altitude is the height above the sea level accordingly to the satellite system (“AG”), it is visible in the
page GPS INFO.
7.6 GPS GROUND SPEED
The GPS ground speed is the glider speed related to the ground (“Gs”). When a navigation is activated, the ground speed is visualized in reverse mode if the glider is moving away
from the waypoint.
LatLon ddmmss.ss
05 43’46.5N
005 43’46.5E
141 Tracking
01 Ground Speed
245 Altitude GPS
03/11/13 16:12:03
Page 23
7.7 GPS DIRECTION (TRK)
The GPS direction (“TRK”) is the glider’s direction related to the ground.
7.8 GROUND EFFICIENCY (GLIDE RATIO)
It shows the efficiency (glide ratio) related to the ground. To set the time over which the average efficiency (glide ratio) is calculated, go to (ADVANCED SETUP \ n. 7
EFF).
If the “ground speed” slows below the 2km/h or the GPS signal is not valid, the indicator shows: “ 0.00 ”. If you are in lift, the efficiency indicator is in reverse mode and shows the average efficiency calculated during
the last glide, go to (ADVANCED SETUP \ n. 8 EFFA) to set the time to be used to calculate the medium
efficiency (glide ratio) to be used for the glide calculation to WP
The average efficiency value is very important because it is the value used by the glide computer.
7.9 WIND SPEED AND DIRECTION INDICATION USING GPS
The wind speed and its direction are automatically computed and displayed using the direction info coming
from the GPS (“TRK”) and the “ground speed (“Gs”).
To determine the wind speed and its direction, you should make a “normal” turn, which has to be neither too
tight, nor too wide.
It is also important to maintain constant airspeed during the turn. For an accurate calculation, a 360º turn must be completed. The wind direction related to the glider and its speed are visualized in the both main screens COMPASS and
PLOTTER.
This function uses the parameter (ADVANCED SETUP \ n. 22 WSEN) for the wind calculator sensibility (default
WSEN = 5)
7.10 LAST THERMAL DIRECTION, DISTANCE, HEIGHT INFORMATION
The data: direction “brt”, distance “dst T” and altitude gain “A3” are shown on the display when it is detected a
thermal.
To define a thermal, this function uses two parameters: the variometer value (VARIOMETER SETUP \ n. 15
THEV) to define the vertical speed (vario), and the lift’s minimum duration in seconds (VARIOMETER SETUP \ n.
16 THET) to define how many consecutive seconds this vertical speed has to be detected.
8 WAYPOINT MANAGEMENT
8.1 DATABASE WAYPOINT COMPETITION AND WAYPOINT USER
Two waypoint databases are available:
Competition Waypoints (“WPT COMP”) and User Waypoints (“WPT USER”). For every one of the two databases
there is memory room up to 186 Waypoints
To visualize the Waypoint list press the key (“MEN” function) and select the desired WP list.
Page 24
The Waypoints can be manually created or can be downloaded from PC using the AirTools or GpsDump
software or also from MAC using GpsDump ‘MAC’ version . It is also possible to transfer the Waypoints from
one instrument to the other via BT.
8.1.1 CREATING A NEW WAYPOINT MANUALLY
To create a new Waypoint, in the menu, put the cursor on the first database’s dotted line, and then press the
key (“EDIT” function).
The “EDIT” function is described in the chapters 2.6.1 and 2.6.2. Name: 6 characters, format aaaNNN (aaa = 3 alphanumeric characters, NNN = waypoint altitude above sea
level, in tens of meters). Note: if the field NNN doesn’t contain three numbers, then the navigation uses the
field Altitude.
Sym : numbers from 0 to 9 or the letter A to identify an official landing zone (Airfield) Note : alphanumerical, 16 characters available Lat / Lon: Latitude and longitude. Altitude: altitude in meters. Note: this field is used only if the field NNN of the waypoint’s name doesn’t
contains three numbers.
Near: distance in meters that activates the fast frequency flight recorder (one second scan). Radius : radius in meters of the waypoint’s cylinder
8.1.2 CREATING A NEW WAYPOINT USING THE CURRENT POSITION (MARK)
When the GPS acquires a valid position (UTC sync) it is possible to save it in the instrument’s memory using
the function “MARK”.
Press the key (long press) to enter in the “MARK” page. To save the current position press again the key
(“SAV” function). The current position will be saved as a new Waypoint in the User Waypoint list (“WPT
USER”) with the format nnMaaa (aaa= altitude A1 in tens of meters).
8.1.3 EDIT WAYPOINT
To modify (edit) an existing Waypoint, scroll though the list using the arrow keys or until the cursor is
on the desired one, then press the key (“EDIT” function).
The “EDIT” function is described in the chapters 2.6.1 and 2.6.2. For the field’s layout see the chapter 8.3.
8.1.4 DELETE WAYPOINT
To delete a Waypoint from the list, enter in the desired Waypoint as like to edit it ( key), then press the key
(long press) and confirm the delete request pressing the key , or cancel the procedure using the key
To delete all the Waypoints of a list: while you are inside a WP list press the key (long press), and confirm
Page 25
the delete request of ALL THE WP with the key , or cancel the procedure using the key
9 NAVIGATE TO A WAYPOINT (GOTO)
9.1 ACTIVATING NAVIGATION TO A WAYPOINT (GOTO)
9.1.1 NAVIGATION TO WAYPOINT HOME (GOTO HOME)
This function allows to create a waypoint having position “HOMxxx” (xxx = altitude in tens of meters) and at the
same time activating the navigation (GOTO) to it.
To activate this function, enter into the page GPS INFO and wait till the GPs position is valid, then press and
hold the key till the message “HOME ACTIVE” appears.
9.1.2 NAVIGATION TO THE NEAREST LANDING ZONE (GOTO LANDING)
To activate this function wait till the GPS position is valid, enter in the menu with the key , select the sub-
menu “Wpt Near Airfield”.
In it there is a list of all the landing fields get from both the WP database (USER+COMP) having the symbol “A
.
This list is sorted from the nearest to the farther one; nearby every landing it is shown at what distance it is
from the current GPS position,
The cursor is automatically set on the nearest landing if necessary scroll the list using the arrow keys
to select the wished one, press the key (long press) then confirm the choice to activate the navigation to
the WP pressing again the key , or cancel the procedure using the key .
9.1.3 NAVIGATION TO THE NEAREST WAYPOINT (GOTO NEAREST)
To activate this function wait till the GPS position is valid, enter in the menu with the key , select the sub-
menu “Wpt Nearest”.
In it there is a list of all the nearest waypoints get from both the WP database (USER+COMP).
The cursor is automatically set on the nearest Waypoint, if necessary scroll the list using the arrow keys
to select the wished one, press the key (long press) then confirm the choice to activate the navigation
to the WP pressing again the key , or cancel the procedure using the key .
9.1.4 NAVIGATION TO A GENERIC WAYPOINT (GOTO)
To activate this function wait till the GPS position is valid, enter in the menu with the key , select the
database Waypoint, “Competition“ or Waypoint User”, accordingly where is recorded the chosen WP.
Scroll the list using the arrow keys and set the cursor on the wished Waypoint, to select it press the
key (long press) then confirm the choice to activate the navigation to the WP pressing again the key ,
Page 26
or cancel the procedure using the key .
9.1.5 DEACTIVATING NAVIGATION TO A WAYPOINT (GOTO)
To deactivate the current navigation, from the page GPS INFO, press the key (long press) then confirm the
choice to deactivate the navigation pressing again the key , or cancel the procedure using the key .
9.2 NAVIGATION’S FUNCTIONS TO A WAYPOINT (GOTO)
The following navigation’s functions are available only if a navigation toward a single waypoiny (GOTO) is active:
9.2.1 DIRECTION, DISTANCE, HEIGHT TO CURRENT WAYPOINT (GOTO)
It is a very useful function that indicated the direction "br1", distance "dst1" and estimated height (H1) of
arrival on the current waypoint;
The arrival altitude on the current (H1) is computed integrating the following info: Altimeter A1, distance to the
Waypoint "dst1" , Waypoint altitude and medium glide ratio.
The Waypoint’s altitude have to be included in the Waypoint’s name:
o aaaNNN visible on the bottom of the waypoint’s page. o aaa = 3 alphanumeric characters for the Waypoint’s name. o NNN = waypoint altitude above sea level, in tens of meters. Note: if the field NNN doesn’t contain three
numbers, then the navigation uses the Altitude field.
The medium glide ratio is continuously update during the glide and stored in the memory during the thermal
flight.
9.2.2 NEEDED GLIDE RATIO TO THE CURRENT WAYPOINT (GOTO)
It is the estimated requested glide ratio to reach the current Waypoint efr1".
9.2.3 ARRIVAL HOUR, ARRIVAL TIME TO THE CURRENT WAYPOINT (GOTO)
It is the expected arrival hour "t1" and the expected arrival time "e1" to the current waypoint.
9.2.4 HSI GRAPHIC INDICATION TO THE CURRENT WAYPOINT (GOTO)
This info is available in the PLOTTER page and provides to the pilot a
quick and intuitive navigation’s graphic instruction to the WP, see
paragraph 4.2.7.
This indication is deactivated if the current turn point is a “start
pylon”.
10 ROUTE MANAGEMENT
10.1 PREFIXED GENERAL ROUTES
Page 27
From the main menu enter in the sub menu "ROUTES”. The first visualized route is the “Rt 1 ”, to select other routes use the arrow keys .
It is possible to memorize up to 12 routes from "Rt 1" to "Rt 12" containing each one up to 20 Waypoints A route allows you to automatically navigate toward the last WP going through all the inserted WP. On the
bottom of the route screen is visualized the route’s total distance in km.
For every route it is possible to insert both Waypoint Competition and Waypoint User in any combination. The routes can be created manually or can be downloaded from PC using the software Digifly AirTools. It is
possible also to transfer the routes from one instrument to another.
In the page route is also listed the optimized total distance of the route in km “Tot dst km”.
10.1.1 VISUALIZING WAYPONT DATA OF A ROUTE
Using the arrow keys set the cursor on the desired waypoint’s line. Press the key to open the drop down menu containing the possible action, then select “EDIT – VIEW” and
confirm with the key .
Press the key to go back the route’s page.
10.1.2 INSERT A WAYPOINT IN A ROUTE
Using the arrows keys , set the cursor on the desired waypoint’s line where you want to insert another
Waypoint
Press the key to open the drop down menu containing the possible action, then select “INSERT WPT
xxxxxx” and confirm with the key .
From the Waypoints list select the desired one and confirm with the key .
10.1.3 SUBSTITUTE A WAYPOINT IN A ROUTE
Using the arrows keys set the cursor on the desired waypoint’s line where you want to substitute an
existing Waypoint.
Press the key to open the drop down menu containing the possible action, then select “CHANGE WPT
xxxxxx” and confirm with the key .
From the Waypoints list select the desired one and confirm with the key .
10.1.4 MODIFY A WAYPOINT IN A ROUTE (PARAMETER CHANGE)
To modify a Waypoint included into a route is necessary to assign to it the start function and to modify the
cylinder’s validation radius.
Press the key set the cursor on the desired waypoint’s line that you want to modify. Press the key to open the drop down menu containing the possible action, then select “EDIT – VIEW” and
Page 28
Start radius
WP start
Waiting side
Start OK
confirm with the key .
It appears a page with all the Waypoint data, use the arrow keys to navigate the field you want to
modify and confirm with the key .
The function “EDIT” is described in the chapters 2.6.1 and 2.6.2. The waypoint fields that have generaIly to be EDITED in a route are:
o Sym : number from 0 to 9 or the letter A to identify a landing
field (Airfield).
o Note : alphanumerical, 16 characters o Near : distance in meters from the cylinder where it is activated
the one second oversample of the flight recorder.
o Radius : radius in meters of the turn point cylinder o Start Pilon Type : IN = entering, OUT = leaving, REV o Start Gate Time : time of the first start (hours:min) o Next Gate : time to the next start (minutes) o N. Gates : total number of Start gate
Press the key to go back to the route’s page
ENTERING START PYLON ( IN )
Page 29
Start radius
WP start
Waiting side
Start OK
LEAVING START PYLON (OUT)
10.1.5 DELETE A WAYPOINT IN A ROUTE
Using the arrows keys set the cursor on the waypoint to be deleted. Press the key to open the drop down menu containing the possible action, then select “DELETE”, confirm
with the key , or cancel the procedure using the key .
Confirm to accept the cancellation of the WP pressing the key , or cancel the procedure using the key .
10.2 ACTIVATING A ROUTE
To activate a route, from the Menu Routes enter into the route to be activated and press the key (long
press) and confirm with the key , or cancel the procedure using the key .
10.3 DE-ACTIVATING A ROUTE
To de-activate a route, from the page GPS INFO, press the key (long press) accept the request to de-
activate the navigation, pressing again the key , or cancel the procedure using the key .
10.4 DELETING A ROUTE
To delete a route from the Menu Routes enter into the route to be activated and press the key (long press)
and confirm with the key , or cancel the procedure using the key .
Page 30
11 OPERATION CHECKLIST BEFORE A TASK
Be certain that the batteries are fully charged Download the waypoints from the competition organization web site Upload them on the Digifly Air with the software AirTools (PC) or GpsDump (PC e MAC), or copy them
transferring the file from one instrument to the other using the direct connection cable.
Edit a route accordingly to the task’s director instruction Insert correctly the turn points cylinders radius Insert correctly the start info (entering or leaving) Insert correctly the start hour If existing, insert also the ulterior gate time ( how may and when) In the route page verify that the total distance is corresponding (“Tot dst km”) Activate the route Set the barometric altimeter, it is top important because it used also by the glide’s computer. Before the takeoff, provide to turn on the instrument with the proper advance to acquire the proper GPS
position
After the GPS point acquisition, verify that the time is correct, in case correct the time zone (pay attention to
the summer time shift) otherwise the start time will be totally wrong.
12 NAVIGATION ROUTE
To have these info available it has to be activated a route’s navigation.
12.1 DIRECTION, DISTANCE & HEIGHT ON THE WAYPOINTS
This function indicates the direction, distance and the estimated arrival height above the current waypoint
(H1); the next Waypoint (H2) and the goal’s Waypoint (HA).
The arrival height above the current Waypoint (H1) is computed accordingly of the following info: Altimeter A1,
distance to Waypoint, Waypoint’s altitude and medium glide ratio.
The medium Glide Ratio is constantly updated during the glide and memorized during the thermal flight, to
change the GR media calculation time (in seconds) go to (ADVANCED SETUP \ n. 5 EFFA).
12.2 NEEDED GLIDE RATIO TO CURRENT WAYPOINT / NEXT WAYPOINT / GOAL
It is the estimated needed glide ratio to reach the current waypoint.
This info is available in all the three screens (Thermal, Glide Compass, and Glide Plotter) using the tools
“efr1”, “efr2”, “efrA”.
Page 31
12.3 OPTIMIZED NAVIGATION
The optimized navigation shows to the pilot the shortest way of the task’s route:
12.4 NAVIGATION TO START PYLON WAYPOINT
If the current waypoint is a Start Pylon, on the info bar appears the message “START PILON” and 3 minutes
before the start time it appears the message " 3 min to go! " emphasized by a beep.
3 minutes before of the start time some fields of the screen are automatically changed by the instrument
itself.
More: in the screen Glide Plotter, 3 minutes before the start time are changed also the first field from the top
showing the distance from the start “dst1” and the second one from the top where it is shown the tool “er0”,
that indicates in seconds the estimated arrival time to the start, based on the current medium speed referred
to the countdown. E.G: if this field shows “10” means that the pilot twill arrive at the start with a 10 second
late, if it shows “-15”, this means that he will arrive 15 second early (penalty).
Still in this condition, it is disabled the graphic indicator of the HSI.
When expires the time to the start (e.g. =00:00), it appears the message “Gate Opened” followed by a long
beep, advising the pilot that the start gate is opened and it is possible to cross the start line.
When the start time gate is open "Gate Opened" it is allowed to cross the start’s cylinder line (entering or
leaving accordingly of the selected IN / OUT option).
If the start’s pylon cylinder is crossed before the open start gate time, the start pylon distance’s indicator
blinks to show that the pilot is in the wrong side of the start pylon cylinder.
This instrument constantly drives the pilot toward the start line of the “start pylon” till t is properly crossed
from the right side, IF the start time gate is opened; if everything is correct it appears the message: "Start is
OK" and the navigator switches to the next waypoint.
IN = Validation of the start pylon entering in the turn point cylinder. OUT = Validation of the start pylon leaving the turn point cylinder.
Page 32
Start radius
WP start
Waiting side
Start OK
Start radius
WP start
Waiting side
Start OK
___________________________________________________________________
ENTERING START PYLON ( IN )
___________________________________________________________________
LEAVING START PYLON ( OUT )
The start-pylon function (with countdown) is activated only if it is set one of the two parameters: IN or OUT.
Page 33
12.5 NAVIGATION TO STANDARD WAYPOINT
If the current Waypoint is not set as a start pylon, the navigation is managed in ‘standard cylinder mode’ and
the Digifly Air will drive you providing constant
info about your posistion, distance, direction,
required glide ratio and expected arrival
height above the waypoint.
When you arrive near the cylinder (see the
Waypoint’s parameter NEAR) the flight
recorder rate is automatically set to one data
point per second. The parameter “NEAR” can
be modified from the page Waypoint’s edit.
Cylinder validation: entering in a cylinder the
Digifly air will alert you with a sound and will appear the messageo “WPOK”, then flight recorder rate returns
to the setup value (MAIN SETUP \ n. 5 RECR). .
12.6 NAVIGATION TO CONCENTRIC WAYPOINT
To properly manage a task’s route with concentric waypoints it is necessary to insert in the desired route the
same waypoint two-three or more times, accordingly to the task route, but with different cylinders radius.
R WP1
R WP3
R WP2
WP
Page 34
13 FLIGHT RECORDER
When the Digifly Air starts the flight recorder, it compares the message “REC ON” and the icon “rec”
on the bottom of the display starts blinking. The following parameters are continuously
recorded: Date and time, Latitude, longitude, number of satellite, tracking GPS, ground speed GPS, altimeter
GPS, barometric altimeter A1, variometer and anemometer.
IMPORTANT: the flight recorder is automatically deactivated if the setup is modified or the flights are deleted.
13.1 ACTIVATING / DE-ACTIVATING FLIGHT RECORDER
The flight recorder can operate in three different ways:
- “AUT” Automatic flight recorder.
- “ALW” Flight recorder always active
- “OFF” Flight recorder de-activated.
13.1.1 AUTOMATIC START RECORD MODE “AUT”
By default setting, the flight recorder starts automatically, MAIN SETUP \n. 3 RECM = AUT The flight recorder activates automatically only if it is available the GPS position and it is detected a takeoff
with an altitude variation of at least 0,5m for 3 consecutive seconds. To change the altitude variation
parameter go to: (MAIN SETUP \ n. 4 R.DS = 0,5) the change the detection time parameter go to (MAIN
SETUP \ n. 4 R.TI = 3).
The flight recorder is automatically de-activated 60 second after the landing or if the instrument is turned off.
13.1.2 ALWAYS ACTIVE RECORD MODE “ALW”
To set the always active record mode parameter go to (MAIN SETUP \ n. 3 RECM = ALW). The flight recorder is
activated once the instrument is turned on and is de-activated when it is turned off.
13.1.3 RECORD MODE OFF “OFF”
To de-activate the flight recorder set the parameter (MAIN SETUP \ n. 3 RECM = OFF), no data are recorded.
13.2 RECORD RATE
The recorder rate can be adjusted from 1 to 60 seconds, go to (MAIN SETUP \ n. 5 RECR). setting 1 data point per second you can record over 10 hours of flight data. Setting 1 data point per minute, you can record up to 600 hours of flight data. The recorder memory has room for up to 45,000 GPS data point and up to 250 flights. When you are near a ‘GO TO’ Waypoint, the recorder rate is automatically increased to 1 data point per
second.
When the recorder’s memory is full, the oldest flight is automatically deleted by the new one. The remaining free memory time and percentage are shown for 2 seconds as the instrument is turned on If a single flight fills the whole memory, it is no more possible to use the recorder and the message “MEM
FULL” appears every time that you try to use it. To activate again the flight recorder it is necessary to clear the
Page 35
whole recorder memory. To do it: from the menu “LOGBOOK press the key (long press) and confirm the
cancellation of ALL THE FLIGHTS pressing the key , or cancel the procedure using the key .
13.3 LOG BOOK MANAGEMENT (LOG BOOK )
To see the recorded flights select the menu “LOGBOOK”. It appears the list of all the recorded flights with the
date and take off time.
To see the flight detailed info, after the selection of the flight press the key .
o For every flight are shown the following info: o Take off date and time, flight duration, and total altitude gain. o Max and min value for : Altimeter (A1) , Vario and Ground speed GPS
To delete all the flights of a list: from the menu “LOGBOOK press the key (long press) and confirm the
cancellation of ALL THE FLIGHTS pressing the key , or cancel the procedure using the key ..
It is not possible to delete a single flight.
14 CONNECTIONS, INTERFACES & MEMORY CARD
It is possible to connect your Digifly Air to a PC, MAC, Smartphone, Tablet , PDA, via Bluetooth or using the
provided USB cable.
14.1 USB CABLE CONNECTION
To use the USB connection it is necessary to install the driver. If the computer is connected to internet,
generally the Window’s automatic research finds and installs it; otherwise it is possible to download the
updated drivers from the web site: www.digifly.com-> download -> PC USB Driver (DIGIFLYxxxxxx Driver.zip) .
To verify the correct driver’s installation:
1) In Windows 7 from Start menu go to Control Panel -> System and
Security -> System -> Device Management.
2) Click on the sign (+) nearby "Doors (COM e LPT)".
3) If the driver is correctly installed it is shown the message "USB Serial Port
(COMxx)" without any yellow indication of error. Note: that ’x’ is the number of
the COM port assigned to the PC USB.
4) The kind of driver is visible with a mouse’s right key click on "USB Serial Port"
then click on Properties', the driver is correct if it is “FTDI”.
If the driver is manually installed, be sure that the USB cable is
disconnected from the PC, download the updated driver from the web site
www.digifly.com-> download -> PC USB Driver (DIGIFLYxxxxxx Driver.zip),
Unzip the folder and run the proper installation program accordingly to
the used operation sys (e.g.: DIGIFLY_xxxxxxxxxxxxxx.exe).
Restart the PC
Page 36
Connect the USB cable to the PC and verify the correct installation. Some software require that the COM door number would be in the range from 1
to 9, if the PC assigns to the door and higher number, it is necessary to reassign
it manually as follows:
1) Right click on "USB Serial Port" and click on Properties'”.
2) Click on "Port settings", then click on "Advanced”.
3) In the window "Advanced Settings" set the "COM Door Number" on the lower number (from 1 to 9) among
the doors that aren’t already in use, then click "OK".
Note: the visualized value in the window "Device Management" is still the one previously shown, the right
number will be visualized closing and opening again this window.
Remember the COM port number, it will have to be used to set
the right COM number in the applications.
(Take care: the software Digifly AirTools and the software Digifly
for the firmware upgrade are automatically detected from the
COM port, so, they do not need this setting).
14.2 BLUETOOTH CONNECTION
14.2.1 DEVICES CONNECTION “PAIRING”
To connect the Digifly AIR Pro Bt and your device (PC, MAC, smartphone, Tablet or PDA) proceed as follows:
Set on the AIR Pro Bt the parameter (ADVANCED SETUP \ n. 25 BLUT = "ON"). For the AIR Pro BT, enter in the menu Bluetooth Pairing and wait. In your device, (PC, MAC etc…) start a research for new Bluetooth devices, the AIR Pro Bt will be recognized as
"Digifly AIR BT" .
In your device, when requested, enter the code for the pairing of the AIR Pro BT, it is 0000”. At this point, AIR Pro BT emits a sound to request a confirmation pressing the key “OK”, then exit from the
menu, the connection is now active.
If necessary create on your device a connection type Serial Port (SPP) to dialogue with the AIR Pro BT, be sure
to select also the correct COM port number.
To guarantee the use easiness, if the device allows it, create an association among your device and the AIR
Pro Bt, of authorized type, so, the Bluetooth connection will be automatically activated every time the two
devices will be turned on.
During the next connections among the AIR Pro BT and your device, normally, the acknowledgement
procedure above described will be no more necessary.
When the Bluetooth connection is OK, the Bluetooth icon in the AIR Pro BT status bar, is fixed turned on, not
blinking.
Page 37
14.2.2 BLUETOOTH DATA TRANSFER ACTIVATION
Set on AIR Pro Bt the parameter (ADVANCED SETUP \ n. 24 TELE) to choose the desired telemetry, see
paragraph 15.6.1.
To be able to exchange data with the software installed on your device (PC , MAC , SmartPhone , Tablet , or
PDA) to read the data from the door COM bluetooth, will be necessary to modify the properties of your
application.
For the app “XCSoar” proceed as follows: Enter in the devices configuration. Enable a device with the driver “Digifly Leonardo” from the
door Bluetooth Digifly AIR BT”.
If in correspondace of the device Digifly Leonardo su Bluetooth Digifly AIR BT” compares the message “Not
connectedenter in the XCSoar’s “Monitorand execute the following
procedure.
On the instrument AIR Pro Bt, enter in the menù “Bluetooth Pairingand wait
for about 15 seconds, till the instrument emits a sound to request a
confirmation, press the key “OK”, then exit from the menu.
After this procedure, in the XCSoar’s monitor screen appear the telemetry data transmitted from the Digifly
AIR.
the connection is now active, and this is visible also in the text: Connected;
Barometer; Airspeed; Variometer nearby the device Digifly Leonardo su
Bluetooth Digifly AIR BT”.
14.3 ADDITIONAL MEMORY
In the housing nearby the connector micro USB it is possible to connect a memory
card type Micro SD, having 2 GB of maximum capacity.
To insert the memory cars, place the card with the label toward the instrument’s
keyboard side and insert the connector card’s side inside the instrument, to lock the memory card it is
necessary to gently press it with the nail till it will be locked in the housing.
Page 38
To extract the memory card press it and release. Warning: if the card is wrongly inserted, it is possible that the instrument would be damaged.
15 SOFTWARE
15.1 SOFTWARE COMPATIBILITY
Your Digifly Air uses a protocol Digifly v66, this protocol allows to communicate at high speed with the
applications having it embedded in their interface (e.g. Digifly AirTools, GpsDump for PC and GpsDump for
MAC). Thanks to this protocol it is possible have from remote the complete instrument’s control.
15.2 SOFTWARE: DIGIFLY AIRTOOLS
It is an official Digifly software, it integrates the protocol Digifly v66 The Digifly AirToolsis an application available for free, to be used on PC Windows; it allows the full
management of: flights, routes, waypoint, the help language of the “SETUP parametersand the complete
personalization of the vario’s acoustic profile
Connect the PC to the Digifly AIR and turn on both. On the instrument press the key “menu” and enter
with the key “ent” in the menu “AitTools”, till it
appears the blinking message “LINK”.
On your PC execute the Digifly program AitTools
and click the key “CONNECT”.
Verify the confirmation of the connection showing
the model; the serial number, and instrument’s
firmware version; meanwhile the AirTools
application enables the usable window’s function
keys.
15.3 SOFTWARE: GPSDUMP PC & GPSDUMP MAC
It is the most diffused software among the free flight organizations to manage competitions, it integrates the
Digifly v66
Turn on the Digifly AIR and enter in
the menu "AirTools", the blinking
message "LINK" indicates that the
instrument is waiting for commands
from the PC (or MAC).
These images are some examples
of the program’s functions.
Page 39
15.4 FIRMWARE UPDATE (INSTRUMENT'S Software)
The software (firmware) of your Digifly instrument can be updated in new versions released on the web site
www.digifly.com. This allows for free to acquire new functions and improvements of your instruments.
The updates can be installed with the provided USB cable (it is not possible to update the firmware through
the Bluetooth connection)
15.5 FIRMWARE UPDATING PROCEDURE
Verify the full charge of the instrument’s battery Exit from all the PC programs in execution included the antivirus &/o firewall
Ensure that the instrument is turned off and connect the USB cable.
Press and hold the key , then press also the key , wait with the two key presses till the instrument
emits a long acoustic “beep”. Now the instrument is turned on and is in boot loader mode, waiting for the
firmware upload.
Note: the screen will be totally empty.
Release first the key and then the key . Run on your PC the Digifly firmware’s updating program
(e.g. Upgrade_661a_All.exe” )
Press the button Start. Be sure to run only one session of the update program
Upgrade_661a_All.exe at a time.
When the program Upgrade_661a_All.exe is running, the
update progress phases are visible.
The update requires roughly 5 minutes, once finished your
computer will provide an acoustic and visible message.
When the new firmware upload is finished, press the key to turn off the instrument and disconnect the
USB cable.
Important! If the update would fail, the instrument’s memory could be deleted, so, not working. If this occurs
the instrument would quickly discharge the battery BUT IT IS NOT BROKEN.
To restore the normal functions it is enough to do the update once again (in a case, try to do it from a different
PC).
Using the Digifly AitTools software it is also possible to upload the help info. This is suggested if the new
firmware uploaded on the instruments offers also new parameters in the menu “MAIN-SETUP” e/o ”ADV-
SETUP”.
Page 40
15.6 TELEMETRY DATA OUTPUT
The models AIR Plus, AIR Pro and AIR Pro BT have the possibility to send data at high speed rate to external
devices (up to 8 updates per second). This function is very important, as the instrument can send in “real time”
all the flight’s info about altitude, anemometer, variometer and GPS data to various devices such as
Smartphone, Tablet, PDA , Car Navigators, Palm, and Pocket PC, to provide the pilot’s remote monitoring or,
through alert SMS for “search and rescue”.
The data can be sent via serial cable, USB or through Bluetooth, find further details on connections and
interfaces at chapter 14 "CONNECTIONS, INTERFACES & MEMORY CARD”.
To activate the real time telemetry output go to ADVANCED SETUP \ n. 24 TELE and select the data format
CAR, FL1 or FL2 .
15.6.1 TELEMETRY DATA SELECTION
Select the telemetry data type with the parameter (ADVANCED SETUP \ n. 24 TELE) : TELE=CAR : $GPGGA , $GPRMC sent one time per second TELE=FL1 : $GPGGA , $GPRMC , $PDGFTL1 sent one time per second TELE=FL2 : $GPGGA , $GPRMC sent one time per second, $PDGFTL1 sent 8 times per second SETTINGS DATA COMMUNICATION : 38400 baud , no parity , 8 data bit , 1 stop bit SENTENCES DESCRIPTION : The field Nmea checksum is composed by "*" and 2 hex digits representing the' "exclusive OR " $GPGGA,
161229.487, 3723.2475, N, 12158.3416, W, 1, 07, 1.0, 9.0, M, , , ,0000*18<CR><LF>
Name
Example
Unit
Description
Message ID
$GPGGA
GGA protocol header
UTC Position
161229.487
hhmmss.sss
Latitude
3723.2475
ddmm.mmmm
N/S Indicator
N N=north or S=south
Longitude
12158.3416
Dddmm.mmmm
E/W Indicator
W E=east or W=west
Position Fix Indicator
1
See Note 3
Satellites Used
07 Range 0 to 12
HDOP
1.0
Horizontal Dilution of Precision
MSL Altitude
9.0
meters
Units
M
meters
Geoid Separation
meters
Units
M
meters
Page 41
Age of Diff. Corr.
second
Null fields when DGPS is not used
Diff. Ref. Station ID
0000
Checksum
*18
Nmea checksum
<CR><LF>
End of message termination
Note 3 :
0 Fix not available or invalid
1 GPS SPS Mode, fix valid
2 Differential GPS, SPS Mode, fix valid
3-5 Not Supported GPS PPS Mode, fix valid
6 Dead Reckoning Mode, fix valid
$GPRMC, 161229.487, A, 3723.2475, N, 12158.3416, W, 0.13, 309.62, 120598, ,A*10<CR><LF>
Name
Example
Unit
Description
Message ID
$GPRMC
RMC protocol header
UTC Position
161229.48
hhmmss.sss
Status
A A=data valid or V=data not valid
Latitude
3723.2475
ddmm.mmmm
N/S Indicator
N N=north or S=south
Longitude
12158.341
dddmm.mmmm
E/W Indicator
W E=east or W=west
Speed Over Ground
0.13
knots
Course Over Ground
309.62
degrees
True
Date
120598
ddmmyy
Magnetic Variation
degrees
E=east or W=west
Mode
A A=Autonomous, D=DGPS, E=DR
Checksum
*10
Nmea checksum
<CR><LF>
End of message termination
$PDGFTL1,2025,2000,250,-14,45,134,28,65,382,153*3D<CR><LF>
Name
Example
Unit
Description
Baro Altitude QNE(1013.25)
2025
meter
2025 mt
Baro Altitude QNH
2000
meter
2000 mt
Vario
250
cm/sec
+2,50 m/s
Netto Vario
-14
dm/sec
-1,40 m/s
Indicated Air Speed
45
km/h
45 km/h
Ground Efficiency
134
ratio
13,4 : 1
Page 42
Wind Speed
28
km/h
28 km/h
Wind Direction
65
degree
65 degree
Main Lithium Battery Voltage
382
0.01 volts
3,82 volts
Backup AA Battery Voltage
153
0.01 volts
1,53 volts
Checksum
*3D
Nmea checksum
<CR><LF>
End of message termination
15.7 LK8000
The AIR models can interface directly the free software
LK8000 For every info visit: www.lk8000.it
15.8 XCSOAR
The AIR models can interface directly the free software
XCSOAR. For every info visit: www.xcsoar.org
Page 43
16 APPENDIX
16.1 DIGIFLY AIR STANDARD ACCESSORIES
The model Digifly Air is shipped with the following standard accessories: Protective case. Internal rechargeable lithium battery. Battery charger (110-220Vca 50-60Hz). USB PC cable to download flights, manage other functions and update the firmware directly from Internet
16.2 OPTIONAL ACCESSORIES
The following optional accessories are available from Digifly: Anemometric Sensor Pitot tube Hang gliding vario mount Paragliding protective case 12V plug car recharger cable
16.3 TECHNICAL FEATURES
16.3.1 STANDARD FUNCTIONS
Graphic altimeter Altimeters 9,000 m (29527 ft) Super-fast vario with dynamic filter ‘IntelliVario’ Acoustic vario with adjustable levels, volume and tone Acoustic vario with “pre-thermal” function Analogue vario +/- 24 m/s (4800 ft/min). Digital vario +/- 25 m/s (5000 ft/min). Vario integrator adjustable from 0 to 60 sec. Total energy compensation (with optional Pitot tube) Ready for installation of the optional Pitot tube and sensor kit Barometer (range 300 to 1200 mB) with user calibration Constant battery monitoring. Date and time with GPS synchro, chronometer, flight timer. Adjustable units of measure. 14 Language for help setup
16.3.2 ADVANCED FUNCTIONS
3 adjustable polar curves. McCready and Equivalent McReady function (with optional Pitot tube). Speed To Fly (with optional Pitot tube). Netto Vario (with optional Pitot tube).
Auto zero thermal altimeter
16.3.3 GPS FUNCTIONS
Integrated high sensitivity GPS receiver 99 channels and 10hz
Page 44
Latitude, Longitude, Altitude GPS, Direction GPS (TRK), Ground Speed GPS. Wind speed and direction indicator (with GPS). Efficiency (Glide Ratio) related to the ground (with GPS ground speed). Direction and distance to the last thermal. Glide calculator. Direction, distance and height to the current Waypoint. Direction, distance and height to the GOAL Required efficiency (GR) to the current Waypoint. Multiflight logger 3D recorder (flight data and GPS) with Autostart, Autostop and Playback 100.000 data points flight recorder Over 1000 flight recorder hours with 1 data point per minute to 20 hours with 1 data point per second Up to 250 recordable flights. Compatible with mostly of the competition software programs. Automatic FAI cylinder turn point and Start Pylon validation (visual and acoustic). 186 Competition Waypoints + 186 User Waypoints 12 Routes with 20 Waypoints on each Route. Optimized navigation management with shortest task’s way indications Controlled air spaces (CTR) management prearrangement Optional GSM module for telephone sim Inertial platform with 3 axis gyroscopes, accelerometers and magnetometers Three axis Gmeter Three axis magnetic compass
16.3.4 GENERAL SPECIFICATIONS
High resolution, gray scale, graphic LCD display 320x240 pixel Upgradeable Software via internet PC Connection Ready for installation of the optional Pitot tube and sensor kit Integrated Bluetooth module vx.0+EDR - SPP profile High speed telemetry output Input for external power supply Integrated battery charger Integrated rechargeable lithium battery Battery life 30 hours Dimensions (H x L x D) 156mm x 93mm x 19mm Weight (with battery) 180g The Digifly instruments are supplied with protective case, rechargeable internal lithium battery, wall adapter
charger (110-220V ca 50-60Hz) and USB cable
Three years warranty.
Page 45
16.4 MAIN SET UP MENU PARAMETERS
n Name Description Range Default Units
1 CTRS display contrast 1 - 99 28 % 2 LANG language selection USR/UK/ITA/ESP/DEU/FRA/CZE/HUN/PLN/GRK/TRK 3 RECM recorder mode selection OFF/ALW/AUT AUT ---­4 R.DS meters variation start autorecorder 0.1 – 5 0.5 m/s 5 R.TI seconds variation start autorecorder 1 - 30 3 sec 6 RECR recorder rate 1 - 60 3 sec 7 UTCO time zone difference -15/+15 2 ore 8 HOUR time setting: hour 0 - 23 ---- ore 9 MIN time setting: minutes 0 - 59 ---- min 10 DAY time setting: day 1 – 31 ---- days 11 MONT time setting: month 1 – 12 ---- months 12 YEAR time setting: year 0 – 99 ---- years 13 BARX graphic altimeter scale limit x axis 0.4 - 4 1.0 min 14 BARY graphic altimeter scale limit y axis 3 - 3000 30 mt 15 U-AL altimeter units MT/FT MT ---­16 U-SP speed units KMH/MPH KMH ---­17 PILO pilot’s name 6 letter ABCDEF ---­18 GTYP glider type 6 letter ABCDEF ---­19 GID glider id 6 letter ABCDEF ----
16.5 VARIOMETER SETUP PARAMETERS
n Name Description Range Default Units
1 V.UP acoustic vario lift setting 0 - 2.00 0.10 m/s 2 V.PT acoustic vario pre-thermal setting 0 - 1.50 0.50 m/s 3 V.DN acoustic vario sink setting 0 - 25.00 3.00 m/s 4 PROF acoustic vario profiles FAS/STD/SFT/US1/US2/MAN MAN ---­5 STYL rythm style tone in lift 0 - 2 1 ---­6 MODH frequency modulation in lift 1 - 30 4 ---­7 PITC tone rhythm in lift 1 - 8 4 ---­8 UPHZ base frequency in lift 500 - 1400 700 Hz
9 DWHZ base frequency in sink 350 - 1000 600 Hz 10 FLT1 filter 1 0 - 100 80 % 11 FLT2 filter 2 24 - 96 72 12 FLT3 filter 3 0 - 100 0 % 13 RVAR acoustic vario sensitivity 0 - 48 0 ---­14 INTE integrator vario delay 0 - 60 10 sec 15 THEV thermal detect vario thres. 0 - 5 0.5 m/s 16 THET thermal detect time thres. 1 - 30 10 sec 17 TEC total energy compensation 0 - 100 0 % 18 SIMV vario simulator ON/OFF/FULL OFF ---­19 AUTV automatic acoustic vario OFF/ON OFF ----
Page 46
16.6 ADV-SETUP PARAMETERS MENU (ADVANCED SETUP)
The following is a list of parameters that can be adjusted. For each parameter you can see the range of values, the factory setting (default) and the unit of measure.
n Name Description Range Default Unit
1 PITO pitot tube habilitation ON/OFF OFF ---­2 KMAG magnetic compass calibration 0 – 100 % 100 km/h 3 KIAS anemometer calibration 0 – 100 % 100 % 4 KBAR barometer calibration +/- 20.0 0.0 mB 5 GCAL AHRS calibration MAN/AUT AUT 6 GPOS AHRS spacial position LEFT/CENT/RIGHT CENT 7 EFF real time medium glide ratio 1 - 30 3 sec 8 EFFA medium glide r.for HW calc. 1 - 100 15 sec 9 POLA active polar OFF/P1/P2/P3 OFF ---­10-11-12 P1-A P1-B P1-C polar 1 coefficient xxx ---­13-14-15 P2-A P2-B P2-C polar 2 coefficient xxx ---­16-17-18 P3-A P3-B P3-C polar 3 coefficient xxx ---­19 MCRA McCready average time 0.2 - 30 10.0 min 20 MCRE McCready equiv average time 0.1 – 3 0.4 sec 21 IFLY intelliflight mode ON/OFF OFF ---­22 WSEN wind calculator sensibility 3 – 15 5 ---­23 CORD GPS coordinates’ type lat lon DMM/DMS/UTM DMS ---­24 TELE telemetry output habilitation OFF/CAR/FL1/FL2 OFF ---­25 BLUT bluetooth enable OFF/ON OFF ----
16.7 RESTORE FACTORY SETTINGS (DEFAULT PARAMETERS)
To restore the factory settings (default parameters) and default screen setups, turn on the instrument pressing
at the same time the keys and until the message “FACTORY SET?” appears.
If you want to confirm press the key it will appear the message “SETUP RESET”. Otherwise, press the key
to quit the restore.
16.8 RESET
In case of a system crash, to reset the instrument, press at the same time the arrow key and the power on
key for over 4 seconds.
Air User Manual R52a
