ADSL/HDSL
For further information: international@digicom.it or http://www.digicom.it
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. All other brands, products and trademarks are property of their respective owners.
l RJ45 10/100 Mbps Autosensing LAN
port
l 10 Mbps WAN port
l 4 Leds: LAN Link, LAN Activity, WAN
Link, WAN Activity
l Web based configuration via Browser
l TCP/IP and DHCP Server Support
l PPPoE RFC 2516 Support
l NAT, NAT Exports, Exposed Computer
Support
l Virtual Servers, Security Groups, Access
Control Support
Michelangelo Gateway 14.09.2001
The maximum performance with the latest xDSL technologies
up to 8 Mbps. Solutions for point-to-point (HSDL) and
Internet (ADSL) applications.
DESCRIPTION
Share the ADSL high rate with all the computers of
your LAN.
Michelangelo Gateway is the ideal solution to surf the
Internet with all the computers of your office using a
single Internet account and saving up the cost of the
Internet service over ADSL.
Easy to install, you can set it up using a common
browser.
It has a 10BaseT (WAN) Ethernet port to be
connected to the ADSL modem and 1 10/100 Fast
Ethernet port for the LAN connection.
Michelangelo Gateway has several advanced
functions for a network efficient and optimized
management:
DHCP server for the automatic assignment of IP
addresses, NAT Router for the account sharing,
PPPoE (PPP over Ethernet) for ADSL connection (or
direct connection to the ISP), Security Groups, Access
Control, Virtual Servers and Exposed Computer.
It complies with any platform supporting TCP/IP
protocol.
Michelangelo Gateway
Code: 8E4088
