NETWORKING
For further information: international@digicom.it or http://www.digicom.it
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. All other brands, products and trademarks are property of their respective owners.
Ports
l 16 RJ 45 10BaseT/100BaseTx (MDI-X)
l 1 RJ45 10/100 Uplink port (MDI)
selectable via switch
Dual Speed Module and Internal Switch
l Internal full-duplex switch for 10/100
Mbps groups interconnection
l Store and Forward technology for
internal switch
l Separate repeater modules for Ethernet
and Fast Ethernet
l CSMA/CD access method
l Full speed filtering and forwarding rate
l Table memory for 1740 addresses
l 1MByte Buffer Memory
l IEEE 802.3 and IEEE 802.3u compliant
Led Indicators
l Power
l Link
l Activity
l Collisions
l 10Mbps/100Mbps
l Use
Mechanical Features
l Metal case
l Desktop
l 19” rack mountable using included
mount kit
l 220 VAC power supply
l 20Watt consumption
Size and Weight
l 273 x 166 x 430 mm.
l 1,5 Kg.
Environmental
l Operating temperature 0 to 50°C
l Humidity 5% to 95% non condensing
l CE mark
Dual Speed Hub16 05.03.2003
The Networking solutions for fast and performing LANs.
DESCRIPTION
Your LAN is 10Mbps based? You need more
speed?
You’d like to add new Fast Ethernet 100Mbps
machines?
You’d like to protect your current hardware
investments?
Get all this at the same time!
Use the Dual Speed Hub 16
All ports are 10/100Mbps Autosensing.
Speed and mode are automatically detected and
selected.
Every 10 Mbps computer will communicate with each
100Mbps computer thanks to the internal full-duplex
switch.
One port can be switched to act as an Uplink port
providing easy and direct connection to other hubs or
switches on the network.
Just Plug & Play. No configuration nedeed.
Network activity and status of each port shown by led
indicators on the front panel.
Dual Speed Hub 16
Code: 8E4077
Server
Printer
Dual Speed Hub
PC
PC
