DESCRIPTION
Michelangelo LAN
The ADSL Router for the Internet Access with
single or multiple users account.
The ADSL and LAN technologies togheter to get
the maximum performance.
Using the accounts offered by the IPs and
Michelangelo LAN, you will be able to surf the Internet
at a supersonic speed: 150 times faster than a V.90
analog modem and 130 times faster than an ISDN
modem.
You don’t need to connect several times at a day to
send/receive e-mails, your Internet connection will be
always on and the telephone line always free for faxes
and calls.
You can download images, video and audio files in a
few seconds. The subscriber’s fee doesn’t depend on
connection time and on data traffic.
Note: Most of ADSL Internet accounts offer
640Kbps (downstream) and 128Kbps(upstream).
Code: 8E4087
l Asymmetric data speed
l ADSL interface: RJ11 connector
l Network Interface: Ethernet 10BT at
10MB
l ADSL interface: ANSI T1.413 Issue 2,
ITU-T G.992.1 (G.dmt), ITU-T G.992.2
(G.Lite)
l Downstream maximum speed: 8Mbps
(full rate), 1,5Mbps (G.Lite)
l Upstream maximum speed: 640Kbps
(full rate), 512Kbps (G.Lite)
l Flash upgradable
l NAT and NAT Export supported
l Supported protocols:
RFC-2364 (PPP over ATM)
RFC-1577 (IP over ATM)
RFC-1483 (Bridged and Routed Ethernet
over ATM), RFC-2516 (PPP over
Ethernet)
l Power Supply: 12Vac through external
power supply 220Vac
l Connectors:
- 1 RJ45 - 10BT
- 1 RJ11-ADSL
- 1 serial 9 pin RS232 (configuration port)
l Led: Power, ADSL transmission and
reception, ADSL connection (LINK),
Ethernet transmission and reception
l CE Mark
ADSL/HDSL
The maximum performance with the latest xDSL technologies
up to 8 Mbps. Solutions for point-to-point (HSDL) and
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. All other brands, products and trademarks are property of their respective owners.
For further information: international@digicom.it or http://www.digicom.it
Internet (ADSL) applications.
Michelangelo LAN 14.09.2001
