Digicom 3100FTX User Manual

PRODUCT

DATA SHEET

FPO

The 3100FTX is the latest addition to
Digi’s FastPort®Family of
multiprotocol print servers. The Digi
FTX Print Servers allow multiple
users on Ethernet and Fast Ethernet
networks to share two, three or four
printers* or plotters even if they are
working in different operating
environments. This makes them an
ideal print sharing solution for large
corporations with Novell®LANs,
companies with multiuser UNIX

®

systems and organizations with
distributed sites that are based on
mixed protocols.

The 3100FTX supports a full range
of networking environments including
UNIX, Novell NetWare®, Apple

®

EtherTalk and NetBEUI (SMB-NBT).
For added flexibility, it’s equipped
with an autosensing 10/100 Mbps
network port that automatically
senses the speed of the incoming
signal and adjusts accordingly. This
allows you to plug it directly into
your Fast Ethernet network, or use it
in a standard Ethernet environment

until you’re ready to migrate to Fast Ethernet
technology.

Designed for ease of use, the 3100FTX print
server features FastManage

®

Windows®-based
SNMP Manager for easy set up and
configuration. FastManage provides a graphical
display of all Digi SNMP-enabled devices and
text display of other vendors’ products.

In UNIX–IP environments, Telnet support is also
available for alternate set up and configuration.
In Windows Peer-to-Peer Networking
environments, Digi’s unique discovery and
configuration method allows the use of standard
Windows printer methods with no additional
host software required.

Most important, the 3100FTX is from Digi
International, the company that developed the
first multiprotocol print servers and has been
selected as "Best of Breed" by major
multinational printer vendors. The
3100FTX is backed by years of
proven performance, an
industry-leading five-year
warranty, expert telephone
technical support and a 30­day money-back guarantee.

Multiport Multiprotocol Enterprise Print
Server For Fast Ethernet Networks

> Allows two, three or

four printers* and

plotters to be shared

in multiprotocol

environments

> A cost-effective

alternative to purchasing

printers for each

environment

> Maximizes your

investment in printers

> Easy to manage with

Windows-based SNMP

manager for easy network

manageability

> Ideal for corporations

migrating to Fast Ethernet

technology

* Number of printers depends on model: 3100=2, 3200=3, 3310=4

Fast Ethernet Print Server

Features/Specifications

91000889
A1/199

Multiprotocol 10/100

MIL-3100FTX - 1P-1S
MIL-3200FTX - 2P-1S
MIL-3310FTX - 3P-1S

International

MIL-3100FTXIN - 1P-1S
MIL-3200FTXIN - 2P-1S
MIL-3310FTXIN - 3P-1S

MODEL/PART
NUMBERS

© 1998 Digi International Inc. All rights reserved.
Digi, Digi International, the Digi logo, FastPort and Fast Manage are either trademarks or
registered trademarks of Digi International Inc. in the United States and other countries. All
other product names or brand names are trademarks of their respective holders.

DIGI SERVICE
AND SUPPORT

You can purchase with
confidence knowing that Digi is
here to support you with expert
technical support, a strong five­year warranty and a 30-day
money-back guarantee.

FEATURES

> Supports up to four printers* or

plotters

> Autosensing 10/100 Mbps network

port for operation in 10BASE-T or

100BASE-TX environment

> Supports simultaneous printing

from UNIX, Novell, OS/2, Windows
(3.x, NT, 95 and 97), and Apple
platforms

> Three fast parallel ports support

today’s high speed printers

> One serial port with speeds up to

38.4 Kbps

> Handles up to 24 servers and 32

queues

> FastManage Windows-based SNMP

Manager
> Automatic Flash upgrades via TFTP
> Digi’s Advanced Configuration Tool

(ACT) for NetWare
> Supports "Plug and Print"

installation on EtherTalk and

Windows

THIRD PARTY TCP/IP COMPATIBILITY

> Adobe TranScripts
> Chameleon NetManage
> PC/NFS
> TGV Multinet
> Sun NewSprint
> Wollongong WIN/TCP
> FTP PC/TCP
> Line Printer Daemon (lpd) support for

21 Unix platforms

Call your Digi respresentative for a
complete listing

REGULATORY APPROVALS

> FCC Class A
> UL 1950
> EN60950
> CSA 22 No. 950
> CE Mark
> EN55022 Class B
> EN50082-1

SHIPPING DIMENSIONS

> Height: 8 in. (20.3 cm)
> Width: 4 in. (10.2 cm)
> Length: 13 in. (33.0 cm)
> Weight: 3.8 lbs. (1.7 kg)

SOFTWARE LAN INTERFACE

> TCP/IP: Supports ARP, BOOTP,

RARP, ICMP, DHCP, lpd, and Telnet
> IPX: For Novell NetWare and NDS
> EtherTalk: Full Apple Talk

implementation for the Apple

LaserWriter; supports ARB, ATP,

DDP, NBP, PAP, AARP, and ELAP
> NetBEUI (SMB-NBF): Windows for

Workgroups, Windows 95,

Windows NT, and SMB
> HP DCL/LLC: Windows NT

SOFTWARE COMPATIBILITY

> Novell NetWare, 2.x, 3.x, 4.x

(Bindery and NDS)

TCP/IP Host Software

> Solaris, Solaris 2.x
> Pyramid
> Sequent
> SCO Unix
> SunOS
> NCR/AT&T
> HP/UX
> Data General AviiON
> OS/2 Lpr/Lpd host software

Call your Digi respresentative for a
complete listing

ENVIRONMENTAL

> Operating temperature:

0ºC to 50ºC (32ºF to 122ºF)

> Storage temperature:

-20ºC to 70ºC (-4ºF to 158ºF)

> Relative humidity: 5% to 90%

(non-condensing)

> Altitude: 0 to 3660 m

(0 to 12,000 Feet)

POWER REQUIREMENTS

> External Switching 100V - 220V

power adapter (included)

> 1.5A @ 5VAC maximum

DIMENSIONS

> Height: 5.3 in. (13.3 cm)
> Width: 1.3 in. (3.2 cm)
> Length: 8.8 in. (22.2 cm)
> Weight: 2 lbs. (.9 kg)

Digi International

11001 Bren Road E.
Minnetonka, MN 55343
U.S.A.

http://www.dgii.com

Customer Support
and Technical Support:

North America:
800-344-4273
612-912-3456
support fax:

612-912-4958

Europe:
([phone]

Hong Kong:
([phone]

Australia:
([phone]

e-mail:

[e-mail]
