Digianswer A S BTP2M100 Users Manual

Compatible with Timeport™ 270c Digital Wireless Phones Bluetooth Specification 1.0B Compliant

™

Welcome

Welcome to Motorola’s “connected” world of Bluetooth™ personal area wireless networking. The Motorola Bluetooth Phone Module makes wireless connection simple and quick.

With the Bluetooth Phone Module, you can quickly and securely transmit data or audio between your Motorola Timeport™ 270c wireless phone and other Bluetooth devices such as headsets or notebook computers. (Other Bluetooth devices must be purchased separately.) The Bluetooth technology makes all connections quickly and

All Motorola wireless products are designed and manufactured to meet Motorola’s rigorous speciﬁcations and world-class quality standards. During development, our testing team took the Motorola Bluetooth Phone Module through rigorous durability tests including temperature, humidity, shock, dust, vibration, and drop tests—and it worked perfectly.

We are conﬁdent that you will ﬁnd your Bluetooth Phone Module to be a convenient and secure way to exchange data and audio. Thank you for choosing a Motorola Bluetooth product!

without any cables

Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein

are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. The BLUETOOTH trademarks are owned by their proprietor and used by Motorola, Inc., under license. T rueSync is a trademark of Starﬁsh, Inc., a wholly owned subsidiary of Motorola, Inc. All other product or service names are the property of their respective owners.

Contents

Safety and General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

What Is Bluetooth Wireless Technology? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

How Can I Use My Bluetooth Phone Module? . . . . . . . . . . . . . . . . . . . . . . . . . 7

The Basic Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Attaching the Module to Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Attaching the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Verifying Module Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Introducing Devices to Each Other . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Introducing Your Phone to a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Introducing a Headset to Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Linking with a PC or Data Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Responding to Link Requests from Data Devices . . . . . . . . . . . . . . . . . . . . . . . 19

Linking with a Bluetooth Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Responding to Link Requests from a Bluetooth Headset . . . . . . . . . . . . . . . . . 21

Re-establishing a Headset Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Managing Multiple Handsfree Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

If You Lose Your Bluetooth Connection

During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using the Headset Bluetooth Control Button . . . . . . . . . . . . . . . . . . . . . . . . . 25

Ending a Bluetooth Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Ending a Connection with a Bluetooth Headset . . . . . . . . . . . . . . . . . . . . . . . 26

Ending a Connection with a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Customization Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Naming Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Turning Voice Dial On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Maintaining Your Device List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Reviewing Your Device List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.

Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC rules and with RSS-210 / RSS139 of the Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any i nterference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).

CanadaCompliance (Industry Canada)

To prevent radio interference t o the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment that is installed outdoors is subject to licensing.

In French: Pour empêcher un brouillage radioélectrique au service faisant l'objet d'une licence, cet appareil doit être utilisé à l'interieur et loin des fenêtres afin de founir un écran de blindage maximal. Au cas aù un installation en plain air, le materiel doit faire l'objet d'une licence.

Safety and General Information

European Union (EU) and EFTA

This equipment complies with the R&TTE directive 1999/5/EC and has been provided with the CE mark accordingly.

ElectromagneticInterference/Compatibility

Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic compatibility.

Facilities

To avoid electromagnetic interferenceand/or compatibility conflicts, turn off your phone in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment thatis sensitiveto external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

Safety and General Information

Medical Devices

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker. These recommendations are consistent with the independent research by, and recommendations of, Wireless Technology Research.

Persons with pacemakers should:

• ALWAYS keep the phone and Bluetooth phone module more than six inches (15 centimeters) from your pacemaker when the phone is turned ON.

• NOT carry the phone and Bluetooth phone module in the breast pocket.

• use the ear opposite the pacemaker to minimize the potential for interference.

• turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Safety and General Information

Introduction

What Is Bluetooth Wireless Technology?

Bluetooth

Bluetooth devices communicate without wires, using built-in radio transceivers that operate on a globally available radio frequency to ensure worldwide compatibility. Y our Bluetooth Phone Module can communicate with other Bluetooth devices within a range of approximately 10 meters (33 feet).

wireless technology propels you into a new dimension in connectivity.

How Can I Use My Bluetooth Phone Module?

When you attach the Bluetooth module, your Motorola Timeport™ 270c

wireless phone can connect with compatible devices

Establish Wireless Links with Your Personal Computer

• Use dial-up networking to access the Internet so you can surf the Web, check email, and other Internet services.

• Synchronize Bluetooth devices. F or example , you can synchronize the datebooks on your phone and PC.

• Use your computer’s fax software to send fax messages.

Connect with a Bluetooth Headset for Hands Free Phone Use

• Handle incoming and outgoing calls with the headset Bluetooth control button.

• Use voice control to make calls.

with no cables or connectors

Introduction

The Basic Steps

Step 1: Install and Set Up Bluetooth Devices

Attach the Bluetooth Module to Your Wireless Phone

See “Attaching the Module to Your Phone” on page 10 of this guide.

If Connecting with a Personal Computer

Do This Where to Find Instructions

Install the PC accessory card in the computer.

Install the PC accessory card drivers and application software.

If you want to use fax services, you need to install the fax software and then conﬁgure it to use the Bluetooth modem.

If you want to use Dial-up Networking services, you need to set up a new connection, or edit an existing connection, to use the Bluetooth modem.

PC accessory card installation guide

fax software installation/user guide

PC accessory card installation guide

Introduction

If Connecting with a Bluetooth Headset

Charge the headset (if required) and prepare the headset for use according to the instructions in the headset user’s guide.

Step 2: Introduce Devices to Each Other

Before you can connect two Bluetooth devices for the ﬁrst time, you must introduce them to each other through a process called same devices can bypass this introduction process (because they already recognize each other) and connect immediately.

To introduce your Bluetooth phone module and a personal computer,

instructions in “Introducing Your Phone to a PC” on page 12.

To introduce your Bluetooth phone module and a Bluetooth headset,

instructions in “Introducing a Headset to Your Phone” on page 15.

Step 3: Link with Bluetooth Devices

bonding

. For future connections, these

follow the

To connect with a PC or other data devices,

PC or Data Device” on page 18.

To connect with a Bluetooth headset,

Bluetooth Headset” on page 20.

follow the instructions in “Linking with a

Attaching the Module to Your Phone

Attaching the Module

Step

Turn off your phone.

Disconnect any cables from the bottom of the phone.

Note: If you intend to establish a connection

between the phone and a Bluetooth headset, you must also disconnect any wired headsets from the phone.

If necessary, remove the battery door by pressing down the battery door release latch, then sliding the door down and off.

Release latch

Attaching the Module to Your Phone

Step

Attach the Bluetooth module to the phone, sliding it up until it clicks into place.

Note: The Bluetooth module uses a small

amount of battery power whenever it is attached and the phone is powered on.

Verifying Module Attachment

Step

Turn on your phone.

Press

Settings

Verify that your phone now displays the Bluetooth Link option. If you do not see the Bluetooth Link option, refer to “Troubleshooting” on

page 34.

Connection

Introducing Devices to Each Other

Introducing Your Phone to a PC

Your Bluetooth-enabled PC must connect. T he ﬁrst time that these two devices connect, they

Bonding

is a process through which the phone and PC exchange identifying information. For future connections, these same devices can bypass this process (because they already recognize each other) and connect immediately. (See the instructions in “Linking with a PC or Data Device” on page 18.)

Note: Whenever one of the following steps directs you to perform a function on your PC, refer to the PC accessory card software user’s guide for instructions.

To set up your phone for connection to a PC:

Action Result

Make sure you have installed the Bluetooth PC card in the PC and loaded the Bluetooth PC software. (See the PC accessory card installation and software user’s guides for instructions.)

discover

your phone before they can

bond
