NS9215
Hardware Reference
90000847_C
Release date: 10 April 2008
©2008 Digi International Inc.
Printed in the United States of America. All rights reserved.
Digi, Digi International, the Digi logo, a Digi International Company, ConnectCore, NET+, NET+OS and
NET+Works are trademarks or registered trademarks of Digi International, Inc. in the United States and
other countries worldwide. All other trademarks are the property of their respective owners.
Information in this document is subject to change without notice and does not represent a commitment
on the part of Digi International.
Digi provides this document “as is,” without warranty of any kind, either expressed or implied, includ ing,
but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Digi may
make improvements and/or changes in this manual or in the product(s) and/or the program(s) described
in this manual at any time.
This product could include technical inaccuracies or typographical errors. Changes are made periodically
to the information herein; these changes may be incorporated in new editions of the publication.
Contents
Chapter 1: Pinout (265) ..................................................... 27
The Legend .............................................................................. 27
Memory bus interface................... ....... ....... ........ ....... ............... ....... ... 28
Ethernet interface MAC....................................................................... 30
General purpose I/O (GPIO) ................................................................. 31
System clock ................................................................................... 43
System clock drawing.................................................................. 44
RTC clock and battery backup drawing ............................................. 45
System mode................................................................................... 45
System reset ................................................................................... 47
JTAG Test....................................................................................... 48
ADC ............................................... ............................................... 49
POR and battery-backed logic............................................................... 50
Power and ground ............................................................................. 51
Chapter 2: I/O Control Module ...........................................53
System memory bus I/O control...................................................... 53
Control and Status registers ................................................................. 53
Register address map .................................................................. 53
GPIO Configuration registers ................................................................ 55
GPIO configuration options............................................................ 55
GPIO Configuration Register #0 ...................................................... 56
GPIO Configuration Register #1 ...................................................... 56
GPIO Configuration Register #2 ...................................................... 57
GPIO Configuration Register #3 ...................................................... 57
GPIO Configuration Register #4 ...................................................... 58
GPIO Configuration Register #5 ...................................................... 58
GPIO Configuration Register #6 ...................................................... 59
GPIO Configuration Register #7 ...................................................... 59
GPIO Configuration Register #8 ...................................................... 60
GPIO Configuration Register #9 ...................................................... 60
GPIO Configuration Register #10 ..................................................... 61
GPIO Configuration Register #11 ..................................................... 61
GPIO Configuration Register #12 ..................................................... 62
GPIO Configuration Register #13 ..................................................... 62
GPIO Configuration Register #14 ..................................................... 63
5
GPIO Configuration Register #15 .....................................................63
GPIO Configuration Register #16 .....................................................64
GPIO Configuration Register #17 .....................................................64
GPIO Configuration Register #18 .....................................................65
GPIO Configuration Register #19 .....................................................65
GPIO Configuration Register #20 .....................................................66
GPIO Configuration Register #21 .....................................................66
GPIO Configuration Register #22 .....................................................67
GPIO Configuration Register #23 .....................................................67
GPIO Configuration Register #24 .....................................................68
GPIO Configuration Register #25 .....................................................68
GPIO Configuration Register #26 .....................................................69
GPIO Control registers ........................................................................ 70
GPIO Control Register #0 .............................................................. 70
GPIO Control Register #1 .............................................................. 71
GPIO Control Register #2 .............................................................. 72
GPIO Control Register #3 .............................................................. 73
GPIO Status registers.......................................................................... 74
GPIO Status Register #1................................................................ 74
GPIO Status Register #2................................................................ 75
GPIO Status Register #3................................................................ 76
Memory Bus Configuration register ......................................................... 76
Chapter 3: Working with the CPU ....................................... 81
About the processor.................................................................... 81
Arm926EJ-S process block diagram ..................................................82
Instruction sets ................................................................................82
ARM instruction set.....................................................................82
Thumb instruction set.................................................................. 82
Java instruction set .................................................................... 83
System control processor (CP15) registers................................................. 83
ARM926EJ-S system addresses ........................................................ 83
Address manipulation example....................................................... 83
Accessing CP15 registers............................................................... 83
Terms and abbreviations .... .............. ........ ....... ....... ........ ....... ....... 84
Register summary.......................................................................85
R0: ID code and cache type status registers ..............................................86
R0: ID code .............................................................................. 86
R0: Cache type register................................................................ 86
Cache type register and field description ..........................................87
Dsize and Isize fields...................................................................87
R1: Control register ...........................................................................88
Control register ......................................................................... 89
Bit functionality.........................................................................89
6 Hardware Reference NS9215
ICache and DCache behavior..........................................................90
R2: Translation Table Base register.........................................................91
Register format..........................................................................91
R3:Domain Access Control register..........................................................91
Register format..........................................................................91
Access permissions and instructions .................................................91
R4 register ......................................................................................92
R5: Fault Status registers............................................ ....... ........ ....... ...92
Access instructions......................................................................92
Register format..........................................................................92
Register bits .............................................................................92
Status and domain fields...............................................................93
R6: Fault Address register....................................................................93
Access instructions......................................................................93
R7:Cache Operations register................................................................94
Write instruction........................................................................94
Cache functions .........................................................................94
Cache operation functions.............................................................95
Modified virtual address format (MVA) ..............................................96
Set/Way format .........................................................................96
Set/Way example .......................................................................96
Test and clean DCache instructions..................................................96
Test, clean, and invalidate DCache instruction....................................97
R8:TLB Operations register...................................................................97
TLB operations ..........................................................................97
TLB operation instructions ............................................................97
Modified virtual address format (MVA) ..............................................98
R9: Cache Lockdown register ................................................................98
Cache ways...............................................................................98
Instruction or data lockdown register ...............................................99
Access instructions......................................................................99
Modifying the Cache Lockdown register.............................................99
Register format..........................................................................99
Cache Lockdown register L bits.......................................................99
Lockdown cache: Specific loading of addresses into a cache-way ............ 100
Cache unlock procedure ............................................................. 101
R10:TLB Lockdown register ................................................................ 101
Register format........................................................................ 101
P bit..................................................................................... 101
Invalidate operation.................................................................. 101
Programming instructions............................................................ 102
Sample code sequence............................................... ........ ....... . 102
R11 and R12 registers ................................................ ....... ........ ....... . 102
R13:Process ID register ..................................................................... 102
FCSE PID register........................................ ....... ....... ........ ....... . 103
. . . . .
www.digiembedded.com 7
Access instructions ....................................................................103
Register format ........................................................................103
Performing a fast context switch ...................................................103
Context ID register ....................................................................104
Access instructions ....................................................................104
Register format ........................................................................104
R14 register....................................................................................104
R15: Test and debug register...............................................................104
Jazelle(Java) ..................................................................................104
DSP..............................................................................................105
MemoryManagement Unit (MMU)...........................................................105
MMU Features ..........................................................................105
Access permissions and domains ....................................................106
Translated entries.....................................................................106
MMU program accessible registers ..................................................107
Address translation....................................................................107
Translation table base ................................................................108
TTB register format ...................................................................108
Table walk process ....................................................................109
First-level fetch........................................................................109
First-level fetch concatenation and address ......................................110
First-level descriptor..................................................................110
Page table descriptors ................................................................110
First-level descriptor bit assignments: Priority encoding of fault status .....111
First-level descriptor bit assignments: Interpreting first level descriptor bits
[1:0]..................................................................................111
Section descriptor .....................................................................111
Section descriptor format ............................................................111
Section descriptor bit description...................................................112
Coarse page table descriptor ........................................................112
Coarse page table descriptor format...............................................112
Coarse page table descriptor bit description......................................112
Fine page table descriptor ...........................................................112
Fine page table descriptor format..................................................113
Fine page table descriptor bit description.........................................113
Translating section references ......................................................113
Second-level descriptor...............................................................114
Second-level descriptor format .....................................................114
Second-level descriptor pages.......................................................114
Second-level descriptor bit assignments...........................................115
Second-level descriptor least significant bits .....................................115
Translation sequence for large page references...... ....... ........ ....... ......116
Translating sequence for small page references .................................117
Translation sequence for tiny page references ...................................118
Subpages ................................................................................118
8 Hardware Reference NS9215
MMU faults and CPU aborts................................................................. 119
Alignment fault checking ............................................................ 119
Fault Address and Fault Status registers .......................................... 119
Priority encoding table............................................................... 120
Fault Address register (FAR)......................................................... 120
FAR values for multi-word transfers ............................................... 120
Compatibility issues .................................................................. 121
Domain access control ...................................................................... 121
Specifying access permissions....................................................... 121
Interpreting access permission bits ................................................ 121
Fault checking sequence.................................................................... 122
Alignment faults....................................................................... 123
Translation faults ..................................................................... 124
Domain faults.......................................................................... 124
Permission faults...................................................................... 124
External aborts............................................................................... 125
Enabling and disabling the MMU........................................................... 125
Enabling the MMU..................................................................... 125
Disabling the MMU .................................................................... 1 26
TLB structure................................................................................. 126
Caches and write buffer .................................................................... 127
Cache features ........................................................................ 127
Write buffer............................................................................ 128
Enabling the caches .................................................................. 128
ICache I and M bit settings .......................................................... 129
ICache page table C bit settings.................................................... 129
R1 register C and M bits for DCache ............................................... 129
DCache page table C and B settings ............................................... 129
Cache MVA and Set/Way formats ......................................................... 130
Generic, virtually indexed, virtually addressed cache.......................... 131
ARM926EJ-S cache format ........................................................... 132
ARM926EJ-S cache associativity .................................................... 132
Set/way/word format for ARM926EJ-S caches ................................... 132
Noncachable instruction fetches .......................................................... 133
Self-modifying code .................................................................. 133
AHB behavior .......................................................................... 134
Instruction Memory Barrier.......................................................... 134
IMB operation.......................................................................... 134
Sample IMB sequences ............................................................... 135
. . . . .
Chapter 4: System Control Module ....................................137
Features ................................................................................ 137
Bus interconnection ......................................................................... 137
System bus arbiter........................................................................... 138
www.digiembedded.com 9
High speed bus system................................................................138
High-speed bus arbiters...............................................................138
How the bus arbiter works ...........................................................138
Ownership...............................................................................139
Locked bus sequence..................................................................139
Relinquishing the bus .................................................................139
SPLIT transfers .........................................................................140
Arbiter configuration example.......................................................140
Address decoding.............................................................................141
Programmable timers........................................................................142
Software watchdog timer ............................................................142
General purpose timers/counters..........................................................143
Source clock frequency...............................................................143
GPTC characteristics............................... .............. ........ ....... ......143
Control field............................................................................143
16-bit mode options...................................................................144
Basic PWM function ..........................................................................144
Functional block diagram.............................................................144
Enhanced PWM function.....................................................................145
Sample enhanced PWM waveform ..................................................145
Quadrature decoder function...............................................................145
How the quadrature decoder/counter works ............................................146
Provides input signals.................................................................146
Monitors how far the encoder has moved..........................................147
Digital filter ............................................................................147
Testing signals..................................................... ........ ....... ......147
Timer support ..........................................................................147
Interrupt controller ..........................................................................148
FIQ interrupts ..........................................................................148
IRQ interrupts ..........................................................................148
32-vector interrupt controller.......................................................148
IRQ characteristics ....................................................................149
Interrupt sources ......................................................................149
Vectored interrupt controller (VIC) flow..................................................151
Configurable system attributes.............................................................151
PLL configuration.............................................................................151
PLL configuration and control system block diagram ............................152
Bootstrap initialization ......................................................................152
Configuring the powerup settings...................................................152
System configuration registers .............................................................154
Register address map .................................................................154
General Arbiter Control register ...........................................................158
BRC0, BRC1, BRC2, and BRC3 registers ...................................................158
Channel allocation.....................................................................159
AHB Error Detect Status 1...................................................................159
10 Hardware Reference NS9215
AHB Error Detect Status 2 .................................................................. 160
AHB Error Monitoring Configuration register ............................................ 161
Timer Master Control register ............................................................. 162
Timer 0–4 Control registers................................................................. 164
Timer 5 Control register .................................................................... 166
Timer 6–9 Control registers................................................................. 168
Timer 6–9 High registers .................................................................... 170
Timer 6–9 Low registers..................................................................... 171
Timer 6–9 High and Low Step registers................................................... 172
Timer 6–9 Reload Step registers........................................................... 172
Timer 0-9 Reload Count and Compare register ......................................... 173
Timer 0-9 Read and Capture register..................................................... 174
Interrupt Vector Address Register Level 31–0 ........................................... 175
Int (Interrupt) Config (Configuration) 31–0 registers................................... 175
Individual register mapping ......................................................... 175
ISADDR register............................................................................... 176
Interrupt Status Active...................................................................... 177
Interrupt Status Raw ........................................................................ 178
Software Watchdog Configuration ........................................................ 178
Software Watchdog Timer.................................................................. 179
Clock Configuration register ............................................................... 180
Module Reset register....................................................................... 182
Miscellaneous System Configuration and Status register .............................. 184
PLL Configuration register...... ........ ....... ....... ........ ....... ....... ........ ....... . 186
PLL frequency formula............................................................... 186
Active Interrupt Level ID Status register................................................. 187
Power Management.......................................................................... 187
AHB Bus Activity Status ..................................................................... 190
System Memory Chip Select 0 Dynamic Memory Base and Mask registers........... 190
System Memory Chip Select 1 Dynamic Memory Base and Mask registers........... 191
System Memory Chip Select 2 Dynamic Memory Base and Mask registers........... 192
System Memory Chip Select 3 Dynamic Memory Base and Mask registers........... 193
System Memory Chip Select 0 Static Memory Base and Mask registers.............. 194
System Memory Chip Select 1 Static Memory Base and Mask registers.............. 195
System Memory Chip Select 2 Static Memory Base and Mask registers.............. 196
System Memory Chip Select 3 Static Memory Base and Mask registers.............. 197
Gen ID register ............................................................................... 198
External Interrupt 0–3 Control register................................................... 199
RTC Module Control register ............................................................... 200
. . . . .
Chapter 5: Memory Controller .......................................... 203
Features ................................................................................ 203
Low-power operation................................................................ ....... . 204
Low-power SDRAM deep-sleep mode............................................... 204
www.digiembedded.com 11
Low-power SDRAM partial array refresh ...........................................204
Memory map...................................................................................205
Power-on reset memory map ........................................................205
Chip select 1 memory configuration................................................205
Example: Boot from flash, SRAM mapped after boot ............................205
Example: Boot from flash, SDRAM remapped after boot ........................206
Static memory controller....................................................................207
Write protection.......................................................................208
Extended wait transfers ..............................................................208
Memory mapped peripherals.........................................................209
Static memory initialization ................................................................209
Access sequencing and memory width .............................................209
Wait state generation.................................................................209
Programmable enable.................................................................210
Static memory read control.................................................................210
Output enable programmable delay................................................210
ROM, SRAM, and Flash ................................................................210
Static memory read: Timing and parameters ............................................211
External memory read transfer with zero wait states ...........................211
External memory read transfer with two wait states............................211
External memory read transfer with two output enable delay states.........212
External memory read transfers with zero wait states..........................212
Burst of zero wait states with fixed length........................................213
Burst of two wait states with fixed length ........................................213
Asynchronous page mode read .............................................................214
Asynchronous page mode read: Timing and parameters ...............................214
External memory page mode read transfer .......................................214
External memory 32-bit burst read from 8-bit memory .........................215
Static memory write control................................................................216
Write enable programming delay ...................................................216
SRAM.....................................................................................216
Static memory Write: Timing and parameters...........................................216
External memory write transfer with zero wait states ..........................216
External memory write transfer with two wait states...........................217
External memory write transfer with two write enable delay states .........217
Two external memory write transfers with zero wait states ...................218
Flash memory ..........................................................................218
Bus turnaround................................................................................219
Bus turnaround: Timing and parameters..................................................219
Read followed by write with no turnaround.......................................219
Write followed by a read with no turnaround.....................................220
Read followed by a write with two turnaround cycles...........................220
Byte lane control .............................................................................221
Address connectivity.........................................................................222
Memory banks constructed from 8-bit or non-byte-partitioned memory devices
12 Hardware Reference NS9215
222
Memory banks constructed from 16-or 32-bit memory devices................ 223
Dynamic memory controller................................................................ 225
Write protection ...................................................................... 225
Access sequencing and memory width............................. ........ ....... . 225
SDRAM Initialization ................................................................. ....... . 225
Left-shift value table: 32-bit wide data bus SDRAM (RBC) ..................... 226
Left-shift value table: 32-bit wide data bus SDRAM (BRC) ..................... 227
Left-shift value table: 16-bit wide data bus SDRAM (RBC) ..................... 227
Left-shift value table: 16-bit wide data bus SDRAM (BRC) ..................... 228
SDRAM address and data bus interconnect .............................................. 228
32-bit wide configuration............................................................ 228
32-bit wide configuration............................................................ 229
Registers ...................................................................................... 230
Register map........................................................................... 230
Reset values ........................................................................... 232
Control register .............................................................................. 232
Status register................................................................................ 234
Configuration register....................................................................... 234
Dynamic Memory Control register......................................................... 235
Dynamic Memory Refresh Timer register................................................. 236
Register................................................................................. 237
Dynamic Memory Read Configuration register .......................................... 237
Dynamic Memory Precharge Command Period register................................ 238
Dynamic Memory Active to Precharge Command Period register .................... 239
Dynamic Memory Self-refresh Exit Time register ....................................... 240
Dynamic Memory Last Data Out to Active Time register .............................. 240
Dynamic Memory Data-in to Active Command Time register ......................... 241
Dynamic Memory Write Recovery Time register ........................................ 242
Dynamic Memory Active to Active Command Period register......... ........ ....... . 243
Dynamic Memory Auto Refresh Period register ......................................... 243
Dynamic Memory Exit Self-refresh register.............................................. 244
Dynamic Memory Active Bank A to Active Bank B Time register ..................... 245
Dynamic Memory Load Mode register to Active Command Time register........... 246
Static Memory Extended Wait register ................................................... 247
Example ................................................................................ 247
Dynamic Memory Configuration 0–3 registers ........................................... 247
Address mapping for the Dynamic Memory Configuration registers........... 249
Chip select and memory devices ................................................... 250
Dynamic Memory RAS and CAS Delay 0–3 registers ..................................... 250
StaticMemory Configuration 0–3 registers................................................ 251
StaticMemory Write Enable Delay 0–3 registers......................................... 254
Static Memory Output Enable Delay 0–3 registers ...................................... 255
Static Memory Read Delay 0–3 registers.................................................. 256
StaticMemory Page Mode Read Delay 0–3 registers..................................... 256
. . . . .
www.digiembedded.com 13
Static Memory Write Delay 0–3 registers..................................................257
StaticMemory Turn Round Delay 0–3 registers ...........................................258
Chapter 6: Ethernet Communication Module ...................... 261
Features.................................................................................261
Common acronyms ....................................................................261
Ethernet communications module ..................................................262
Ethernet MAC..................................................................................262
MAC module block diagram ..........................................................263
MAC module features .................................................................263
PHY interface mappings ..............................................................264
Station address logic (SAL)..................................................................264
MAC receiver ...........................................................................265
Statistics module .............................................................................265
Ethernet front-end module .................................................................266
Ethernet front-end module (EFE) ...................................................266
Receive packet processor ............................................................266
Transmit packet processor ...........................................................267
Receive packet processor ...................................................................267
Power down mode.....................................................................267
Transferring a frame to system memory...........................................268
Receive buffer descriptor format ...................................................268
Receive buffer descriptor format description.....................................268
Receive buffer descriptor field definitions........................................269
Transmit packet processor..................................................................269
Transmit buffer descriptor format..................................................270
Transmit buffer descriptor field definitions.......................................270
Transmitting a frame..................................................................271
Frame transmitted successfully .....................................................272
Frame transmitted unsuccessfully ..................................................272
Transmitting a frame to the Ethernet MAC........................................272
Ethernet underrun.....................................................................272
Ethernet slave interface.....................................................................273
Interrupts ......................................................................................273
Interrupt sources ......................................................................273
Status bits...............................................................................274
Resets ..........................................................................................274
Multicast address filtering ..................................................................275
Filter entries ...........................................................................275
Multicast address filter registers....................................................275
Multicast address filtering example 1 ..............................................275
Multicast address filtering example 2 ..............................................276
Notes ....................................................................................276
Clock synchronization........................................................................276
14 Hardware Reference NS9215
Writing to other registers............................................................ 276
Ethernet Control and Status registers .................................................... 277
Register address filter................................................................ 277
Ethernet General Control Register #1 .................................................... 279
Ethernet General Control Register #2 .................................................... 282
Ethernet General Status register.......................................................... 283
Ethernet Transmit Status register......................................................... 284
Ethernet Receive Status register.................................................. ....... . 286
MAC Configuration Register #1............................................................. 288
MAC Configuration Register #2............................................................. 289
PAD operation table for transmit frames.......................................... 291
Back-to-Back Inter-Packet-Gap register.................................................. 291
Non Back-to-Back Inter-Packet-Gap register ............................................ 292
Collision Window/Retry register........................................................... 293
Maximum Frame register ................................................................... 294
MII Management Configuration register .................................................. 295
Clocks field settings .................................................................. 296
MII Management Command register....................................................... 296
MII Management Address register ......................................................... 297
MII Management Write Data register...................................................... 298
MII Management Read Data register ...................................................... 298
MII Management Indicators register....................................................... 299
Station Address registers ................................................................... 300
Station Address Filter register............................................................. 301
RegisterHash Tables......................................................................... 302
HT1...................................................................................... 302
HT2...................................................................................... 303
Statistics registers ........................................................................... 303
Combined transmit and receive statistics counters address map ............. 303
Receive statistics counters address map.......................................... 304
Receive byte counter (A060 069C) ................................................. 304
Receive packet counter (A060 06A0) .............................................. 304
Receive FCS error counter (A060 06A4) ........................................... 305
Receive multicast packet counter (A060 06A8) .................................. 305
Receive broadcast packet counter (A060 06AC) ................................. 305
Receive control frame packet counter (A060 06B0)............................. 305
Receive PAUSE frame packet counter (A060 06B4).............................. 305
Receive unknown OPCODE packet counter (A060 06B8) ........................ 305
Receive alignment error counter (A060 06BC) ................................... 306
Receive code error counter (A060 06C4).......................................... 306
Receive carrier sense error counter (A060 06C8)................................ 306
Receive undersize packet counter (A060 06CC).................................. 306
Receive oversize packet counter (A060 06D0).................................... 306
Receive fragments counter (A060 06D4) .......................................... 306
Receive jabber counter (A060 06D8)............................................... 307
. . . . .
www.digiembedded.com 15
Transmit statistics counters address map .........................................307
Transmit byte counter (A060 06E0).................................................307
Transmit packet counter (A060 06E4)..............................................308
Transmit multicast packet counter (A060 06E8)..................................308
Transmit broadcast packet counter (A060 06EC) .................................308
Transmit deferral packet counter (A060 06F4) ...................................308
Transmit excessive deferral packet counter (A060 06F8) .......................308
Transmit single collision packet counter (A060 06FC) ...........................308
Transmit multiple collision packet counter (A060 0700) ........................309
Transmit late collision packet counter (A060 0704)..............................309
Transmit excessive collision packet counter (A060 0708).......................309
Transmit total collision packet counter (A060 070C) ............................309
Transmit jabber frame counter (A060 0718) ......................................309
Transmit FCS error counter (A060 071C)...........................................309
Transmit oversize frame counter (A060 0724) ....................................310
Transmit undersize frame counter (A060 0728)...................................310
Transmit fragment counter (A060 072C)...........................................310
General Statistics registers address map ..........................................310
Carry Register 1........................................................................310
Carry Register 2........................................................................311
Carry Register 1 Mask register.......................................................312
Carry Register 2 Mask register.......................................................314
RX_A Buffer Descriptor Pointer register ..................................................315
RX_B Buffer Descriptor Pointer register ..................................................315
RX_C Buffer Descriptor Pointer register ..................................................316
RX_D Buffer Descriptor Pointer register ..................................................316
Ethernet Interrupt Status register .........................................................317
Ethernet Interrupt Enable register.........................................................319
TX Buffer Descriptor Pointer register .....................................................320
Transmit Recover Buffer Descriptor Pointer register ...................................321
TX Error Buffer Descriptor Pointer register ..............................................321
TX Stall Buffer Descriptor Pointer register ...............................................322
RX_A Buffer Descriptor Pointer Offset register..........................................323
RX_B Buffer Descriptor Pointer Offset register ..........................................324
RX_C Buffer Descriptor Pointer Offset register..........................................324
RX_D Buffer Descriptor Pointer Offset register..........................................325
Transmit Buffer Descriptor Pointer Offset register .....................................325
RX Free Buffer register ......................................................................326
Multicast Address Filter registers ..........................................................327
Multicast Low Address Filter Register #0...........................................327
Multicast Low Address Filter Register #1...........................................327
Multicast Low Address Filter Register #2...........................................327
Multicast Low Address Filter Register #3...........................................327
Multicast Low Address Filter Register #4...........................................327
Multicast Low Address Filter Register #5...........................................327
16 Hardware Reference NS9215
Multicast Low Address Filter Register #6.......................................... 328
Multicast Low Address Filter Register #7.......................................... 328
Multicast High Address Filter Register #0 ......................................... 328
Multicast High Address Filter Register #1 ......................................... 328
Multicast High Address Filter Register #2 ......................................... 328
Multicast High Address Filter Register #3 ......................................... 328
Multicast High Address Filter Register #4 ......................................... 328
Multicast High Address Filter Register #5 ......................................... 328
Multicast High Address Filter Register #6 ......................................... 329
Multicast High Address Filter Register #7 ......................................... 329
Multicast Address Mask registers .......................................................... 329
Multicast Low Address Mask Register #0........................................... 329
Multicast Low Address Mask Register #1........................................... 329
Multicast Low Address Mask Register #2........................................... 329
Multicast Low Address Mask Register #3........................................... 329
Multicast Low Address Mask Register #4........................................... 330
Multicast Low Address Mask Register #5........................................... 330
Multicast Low Address Mask Register #6........................................... 330
Multicast Low Address Mask Register #7........................................... 330
Multicast High Address Mask Register #0.......................................... 330
Multicast High Address Mask Register #1.......................................... 330
Multicast High Address Mask Register #2.......................................... 330
Multicast High Address Mask Register #3.......................................... 330
Multicast High Address Mask Register #4.......................................... 330
Multicast High Address Mask Register #5.......................................... 331
Multicast High Address Mask Register #6.......................................... 331
Multicast High Address Mask Register #7.......................................... 331
Multicast Address Filter Enable register.................................................. 331
TX Buffer Descriptor RAM................................................................... 332
Offset+0 ................................................................................ 332
Offset+4 ................................................................................ 333
Offset+8 ................................................................................ 333
Offset+C................................................................................ 333
RX FIFO RAM .................................................................................. 333
Sample hash table code............................... ........ ....... ....... ........ ....... . 334
. . . . .
Chapter 7: External DMA ................................................339
DMA transfers...... ........ ....... ........ ....... ....... ........ ....... ....... ............... . 339
Initiating DMA transfers.............................................................. 339
Processor-initiated.................................................................... 339
External peripheral-initiated........................................................ 339
DMA buffer descriptor.... ....... ........ ....... ....... ........ ....... ....... ............... . 340
DMA buffer descriptor diagram ..................................................... 340
Source address [pointer]............................................................ . 340
www.digiembedded.com 17
Buffer length ................................ ........ ....... ....... ........ ....... ......340
Destination address [pointer]........................................... ....... ......340
Status....................................................................................341
Wrap (W) bit........... ........ ....... ....... ........ ....... ....... ........ ....... ......341
Interrupt (I) bit.........................................................................341
Last (L) bit..............................................................................341
Full (F) bit ..............................................................................341
Descriptor list processing.............................................................. ......341
Peripheral DMA read access.................................................................342
Determining the width of PDEN .....................................................342
Equation variables.....................................................................342
Peripheral DMA single read access..................................................343
Peripheral DMA burst read access...................................................343
Peripheral DMA write access................................................................343
Determining the width of PDEN .....................................................344
Peripheral DMA single write access.................................................344
Peripheral DMA burst write access..................................................344
Peripheral REQ and DONE signaling........................................................344
REQ signal...............................................................................344
DONE signal.............................................................................345
Special circumstances.................................................................345
Static RAM chip select configuration ......................................................345
Static ram chip select configuration................................................345
Control and Status registers ................................................................346
Register address map .................................................................346
DMA Buffer Descriptor Pointer..............................................................346
DMA Control register.........................................................................347
DMA Status and Interrupt Enable register ................................................350
DMA Peripheral Chip Select register.......................................................352
Chapter 8: AES Data Encryption/Decryption Module ........... 355
18 Hardware Reference NS9215
Features.................................................................................355
Block diagram ..........................................................................356
Data blocks .............................................................................356
AES DMA buffer descriptor ..................................................................356
AES buffer descriptor diagram.......................................................357
Source address [pointer] .............................................................357
Source buffer length ..................................................................357
Destination buffer length........................................ ........ ....... ......357
Destination address [pointer]........................................... ....... ......357
AES control .............................................................................357
AES op code.............................................................................358
WRAP (W) bit...........................................................................358
Interrupt (I) bit.........................................................................358
Last (L) bit ............................................................................. 358
Full (F) bit.............................................................................. 358
Decryption .................................................................................... 359
ECB processing ............................................................................... 359
Processing flow diagram ............................................................. 359
CBC, CFB, OFB, and CTR processing ...................................................... 360
Processing flow diagram ............................................................. 360
CCM mode..................................................................................... 360
Nonce buffer........................................................................... 361
Processing flow........................................................................ 361
Chapter 9: I/O Hub Module .............................................. 363
Block diagram ......................................................................... 364
AHB slave interface.................................................................. . 364
DMA controller ............................................................................... 364
Servicing RX and FIFOs ............................................................... 364
Buffer descriptors..................................................................... 365
Source address [pointer]............................................................ . 365
Buffer length........................................................................... 365
Control[15] – W........................................................................ 365
Control[14] – I ......................................................................... 365
Control[13] – L......................................................................... 365
Control[12] – F......................................................................... 365
Control[11:0] .......................................................................... 366
Status[15:0]............................................................................ 366
Transmit DMA example...................................................................... 367
Process.................................................................................. 367
Visual example ........................................................................ 368
Control and status register address maps................................................ 368
UART A register address map ....................................................... 369
UART B register address map ....................................................... 369
UART C register address map ....................................................... 370
UART D register address map ....................................................... 370
SPI register address map............................................................. 371
AD register address map............................................................. 371
Reserved................................................................................ 371
I2C register address map............................................................. 371
Reserved................................................................................ 371
RTC register address map............................................................ 372
IO Hardware Assist register address map (0) ..................................... 372
IO Hardware Assist register address map (1) ..................................... 372
IO register address map (0) ......................................................... 372
IO register address map (1) ......................................................... 372
[Module] Interrupt and FIFO Status register............................................. 372
. . . . .
www.digiembedded.com 19
[Module] DMA RX Control....................................................................375
[Module] DMA RX Buffer Descriptor Pointer ..............................................376
[Module] RX Interrupt Configuration register ............................................377
[Module] Direct Mode RX Status FIFO......................................................378
[Module] Direct Mode RX Data FIFO .......................................................379
[Module] DMA TX Control....................................................................380
[Module] DMA TX Buffer Descriptor Pointer ..............................................381
[Module] TX Interrupt Configuration register ............................................381
[Module] Direct Mode TX Data FIFO .......................................................382
[Module] Direct Mode TX Data Last FIFO..................................................383
Chapter 10: Serial Control Module: UART ......................... 385
Features.................................................................................385
UART module structure...............................................................386
Normal mode operation .....................................................................386
Example configuration................................................................386
Baud rate generator..........................................................................387
Baud rates ..............................................................................387
Hardware-based flow control...............................................................388
Character-based flow control (XON/XOFF)...............................................388
Example configuration................................................................388
Forced character transmission .............................................................388
Force character transmission procedure...........................................389
Collecting feedback ...................................................................389
ARM wakeup on character recognition....................................................389
Example configuration................................................................389
Wrapper Control and Status registers .....................................................390
Register address map .................................................................390
Wrapper Configuration register ............................................................391
Interrupt Enable register....................................................................393
Interrupt Status register.....................................................................395
Receive Character GAP Control register ..................................................398
Receive Buffer GAP Control register ......................................................399
Receive Character Match Control register................................................399
Receive Character-Based Flow Control register .........................................400
Force Transmit Character Control register...............................................402
ARM Wakeup Control register...............................................................403
Transmit Byte Count .........................................................................404
UART Receive Buffer.........................................................................405
UART Transmit Buffer........................................................................405
UART Baud Rate Divisor LSB ................................................................406
UART Baud Rate Divisor MSB................................................................406
UART Interrupt Enable register.............................................................407
UART Interrupt Identification register ....................................................408
20 Hardware Reference NS9215
UART FIFO Control register................................................................. 409
UART Line Control register................................................................. 409
UART Modem Control register ............................................................. 411
UART Line Status register .................................................................. 411
UART Modem Status register............................................................... 412
Chapter 11: Serial Control Module: HDLC ......................... 415
HDLC module structure .............................................................. 415
Receive and transmit operations.......................................................... 415
Receive operation..................................................................... 416
Transmit operation ................................................................... 416
Transmitter underflow ............................................................... 416
Clocking ............ ........................................................................... 416
Bits............................................................................................. 416
Last byte bit pattern table .......................................................... 417
Data encoding ................................................................................ 417
Encoding examples ................................................................... 417
Digital phase-locked-loop (DPLL) operation: Encoding ................................ 418
Transitions ............................................................................. 418
DPLL-tracked bit cell boundaries................................................... 419
NRZ and NRZI data encoding ........................................................ 419
Biphase data encoding ............................................................... 419
DPLL operation: Adjustment ranges and output clocks................................ 419
NRZ and NRZI encoding .............................................................. 420
Biphase-Level encoding.............................................................. 420
Biphase-Mark and Biphase-Space encoding ....................................... 421
IRDA-compliant encode .............................................................. 421
Normal mode operation..................................................................... 421
Example configuration ............................................................... 421
Wrapper and HDLC Control and Status registers........................................ 422
Register address map................................................................. 422
Wrapper Configuration register............................................................ 422
Interrupt Enable register ................................................................... 424
Interrupt Status register.................................................................... 425
HDLC Data Register 1........................................................................ 427
HDLC Data Register 2........................................................................ 427
HDLC Data register 3 ........................................................................ 428
HDLC Control Register 1 ...................................... ....... ............... ....... . 429
HDLC Control Register 2 ...................................... ....... ............... ....... . 429
HDLC Clock Divider Low .................................................................... 430
HDLC Clock Divider High.................................................................... 431
. . . . .
Chapter 12: Serial Control Module: SPI .............................433
Features ................................................................................ 433
www.digiembedded.com 21
SPI module structure..................................................................434
SPI controller..................................................................................434
Simple parallel/serial data conversion.............................................434
Full duplex operation .................................................................434
SPI clocking modes ...........................................................................435
Timing modes ..........................................................................435
Clocking mode diagrams..............................................................435
SPI clock generation..........................................................................436
Clock generation samples ............................................................436
In SPI master mode....................................................................436
In SPI slave mode ......................................................................436
System boot-over-SPI operation............................................................436
Available strapping options ..........................................................437
EEPROM/FLASH header ...............................................................437
Header format .........................................................................437
Time to completion ...................................................................438
SPI Control and Status registers............................................................439
Register address map .................................................................439
SPI Configuration register...................................................................439
Clock Generation register...................................................................440
Register programming steps .........................................................441
Interrupt Enable register....................................................................441
Interrupt Status register.....................................................................442
SPI timing characteristics ...................................................................443
SPI master timing diagram ...........................................................444
SPI slave timing parameters .........................................................444
SPI slave timing diagram..............................................................445
Chapter 13: I2C Master/Slave Interface ............................. 447
22 Hardware Reference NS9215
Overview................................................................................447
Physical I2C bus............................. ....... ........ ....... ....... ........ ....... ......447
Multi-master bus.......................................................................448
I2C external addresses.......................................................................448
I2C command interface......................................................................449
Locked interrupt driven mode.......................................................449
Master module and slave module commands......................................449
Bus arbitration .........................................................................449
I2C registers...................................................................................450
Register address map .................................................................450
Command Transmit Data register..........................................................450
Register .................................................................................450
Register bit assignment...............................................................451
Status Receive Data register................................................................451
Register .................................................................................451
Register bit assignment .............................................................. 451
Master Address register..................................................................... 452
Register................................................................................. 452
Register bit assignment .............................................................. 453
Slave Address register....................................................................... 453
Register................................................................................. 453
Register bit assignment .............................................................. 453
Configuration register....................................................................... 454
Timing parameter for fast-mode ................................................... 454
Register................................................................................. 454
Register bit assignment .............................................................. 454
Interrupt Codes .............................................................................. 455
Master/slave interrupt codes ....................................................... 455
Software driver............................................................................... 456
I2C master software driver.......................................................... 456
I2C slave high level driver ........................................................... 456
Flow charts ................................................................................... 457
Master module (normal mode, 16-bit)............................................. 457
Slave module (normal mode, 16-bit)............................................... 458
. . . . .
Chapter 14: Real Time Clock Module ................................. 459
RTC functionality ..................................................................... 459
RTC configuration and status registers................................................... 460
Register address map................................................................. 460
RTC General Control register .............................................................. 460
12/24 Hour register.......................................................................... 461
Time register ................................................................................. 462
Calendar register ............................................................................ 463
Time Alarm register ......................................................................... 464
Calendar Alarm register .................................................................... 465
Alarm Enable register ....................................................................... 465
Event Flags register ......................................................................... 466
Interrupt Enable register ................................................................... 468
Interrupt Disable register................................................................... 469
Interrupt Enable Status register........................................................... 470
General Status register ..................................................................... 4 71
Chapter 15: Analog-to-Digital Converter (ADC) Module ....... 473
Features ................................................................................ 473
ADC module structure................................................................ 473
ADC control block..................................................................... 474
ADC DMA procedure ......................................................................... 474
ADC control and status registers .......................................................... 475
Register address map................................................................. 475
www.digiembedded.com 23
ADC Configuration register............................................................ ......475
ADC Clock Configuration register ..........................................................477
ADC Output Registers 0-7 ...................................................................477
Chapter 16: Timing ........................................................ 479
Electrical characteristics....................................................................479
Absolute maximum ratings...........................................................479
Recommended operating conditions................................................480
Power dissipation......................................................................480
DC electrical characteristics................................................................481
Inputs....................................................................................481
Ouputs...................................................................................482
Reset and edge sensitive input timing requirements ...................................482
...........................................................................................483
Memory Timing................................................................................484
SDRAM burst read (16-bit)............................................................485
SDRAM burst read (16 bit), CAS latency = 3 .......................................486
SDRAM burst write (16 bit) ...........................................................487
SDRAM burst read (32 bit)............................................................488
SDRAM burst read (32 bit), CAS latency = 3 .......................................489
SDRAM burst write (32-bit)...........................................................490
SDRAM load mode......................................................................491
SDRAM refresh mode ..................................................................492
Clock enable timing ...................................................................493
Values in SRAM timing diagrams.....................................................494
Static RAM read cycles with 0 wait states .........................................495
Static RAM asynchronous page mode read, WTPG = 1 ...........................496
Static RAM read cycle with configurable wait states ............................497
Static RAM sequential write cycles .................................................498
Static RAM write cycle................................................................499
Static write cycle with configurable wait states .................................500
Slow peripheral acknowledge timing ...............................................501
Slow peripheral acknowledge read .................................................502
Slow peripheral acknowledge write ................................................502
Ethernet timing ........................................................................503
Ethernet MII timing....................................................................503
2
I
C timing ...............................................................................504
SPI Timing...............................................................................505
SPI master mode 0 and 1: 2-byte transfer.........................................507
SPI master mode2 and 3: 2-byte transfer..........................................507
SPI slave mode 0 and 1: 2-byte transfer ...........................................508
SPI slave mode 2 and 3: 2-byte transfer ...........................................508
Reset and hardware strapping timing .....................................................509
JTAG timing ...................................................................................510
24 Hardware Reference NS9215
Clock timing .................................................................................. 511
System PLL reference clock timing................................................. 511
Chapter 17: Packaging ..................................................... 513
Package........................................................................................ 513
Processor Dimensions ....................................................................... 514
Chapter 18: Change log ................................................... 517
Revision B ..................................................................................... 517
Revision C..................................................................................... 517
. . . . .
www.digiembedded.com 25
26 Hardware Reference NS9215
Pinout (265)
CHAPTER 1
The NS9215 offers a connection to a 10/100 Ethernet network, as well as a
glueless connection to SDRAM, PC100 DIMM, flash, EEPROM, and SRAM memories,
and an external bus expansion module. It includes four multi-function serial ports,
one I2C channel, 12-bit Analog to Digital converter, battery backed real time clock
and an AES data encryption/decryption module. The NS215 provides up to 108
general purpose I/O (GPIO) pins and configurable power management with sleep
mode.
The Legend
Heading Description
Pin Pin number assigned for a specific I/O signal
Signal Pin name for each I/O signal. Some signals have multiple function modes and are
identified accordingly. The mode is configured through firmware using one or more
configuration registers.
_n is the signal name indicates that this signal is active is active low.
U/D U or D indicates whether the pin has an internal pullup resistor or a pulldown resistor:
U Pullup (input current source)
D Pulldown (input current sink)
If no value is listed, that pin has neither an internal pullup nor pulldown resistor.
I/O The type of signal: input (I), output (O), input/output (I/O), or power (P).
OD (mA) The output drive of an output buffer. The NS9215 uses one of two drivers:
2 mA
4 mA
27
PINOUT (265)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Memory bus interface
Memory bus interface
Pin Signal U/D I/O OD Description
B9 clk_out[0] O 4 SDRAM bus clock
A15 clk_out[1] O 4 SDRAM bus clock
P12 addr[27] / gpio_a[3]
T14 addr[26] / gpio_a[2]
U15 addr[25] / gpio_a[1]
R12 addr[24] / gpio_a[0]
T13 addr[23] U I/O 4 Address bus, Boot width [0]
U14 addr[22] O 4 Address bus
a
a.
a.
a.
U I/O 4 Address bus, Endian
U I/O 4 Address bus, SPI boot
U I/O 4 Address bus
U I/O 4 Address bus, Boot width [1]
T12 addr[21] O 4 Address bus
U13 addr[20] O 4 Address bus,
R11 addr[19] U I/O 4 Address bus, GENID 10
T11 addr[18] U I/O 4 Address bus, GENID 9
U12 addr[17] U I/O 4 Address bus, GENID 8
T10 addr[16] U I/O 4 Address bus, GENID 7
R9 addr[15] U I/O 4 Address bus, GENID 6
U11 addr[14] U I/O 4 Address bus, GENID 5
U10 addr[13] U I/O 4 Address bus, GENID 4
T9 addr[12] U I/O 4 Address bus, GENID 3
U9 addr[11] U I/O 4 Address bus, GENID 2
U8 addr[10] U I/O 4 Address bus, GENID 1
T8 addr[9] U I/O 4 Address bus, GENID 0
U7 addr[8] U I/O 4 Address bus
T7 addr[7] U I/O 4 Address bus, PLL bypass
U6 addr[6] U I/O 4 Address bus, PLL OD [1]
T6 addr[5] U I/O 4 Address bus, PLL OD [0]
U5 addr[4] U I/O 4 Address bus, PLL NR[4]
M2 addr[3] U I/O 4 Address bus, PLL NR[3]
N1 addr[2] U I/O 4 Address bus, PLL NR[2]
L2 addr[1] U I/O 4 Address bus, PLL NR[1]
28 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
M1 addr[0] U I/O 4 Address bus, PLL NR[0]
L1 data[31] U I/O 4 Data bus
K2 data[30] U I/O 4 Data bus
K1 data[29] U I/O 4 Data bus
J1 data[28] U I/O 4 Data bus
J2 data[27] U I/O 4 Data bus
H1 data[26] U I/O 4 Data bus
G1 data[25] U I/O 4 Data bus
J3 data[24] U I/O 4 Data bus
H2 data[23] U I/O 4 Data bus
F1 data[22] U I/O 4 Data bus
G2 data[21] U I/O 4 Data bus
PINOUT (265)
Memory bus interface
. . . . .
H3 data[20] U I/O 4 Data bus
E1 data[19] U I/O 4 Data bus
F2 data[18] U I/O 4 Data bus
D1 data[17] U I/O 4 Data bus
E2 data[16] U I/O 4 Data bus
H4 data[15] / gpio[31]
G3 data[14] / gpio[30] U I/O 4 Data bus
G4 data[13] / gpio[29] U I/O 4 Data bus
G5 data[12] / gpio[28] U I/O 4 Data bus
F3 data[11] / gpio[27] U I/O 4 Data bus
F4 data[10] / gpio[26] U I/O 4 Data bus
F5 data[9] / gpio[25] U I/O 4 Data bus
C1 data[8] / gpio[24] U I/O 4 Data bus
E4 data[7] / gpio[23] U I/O 4 Data bus
D2 data[6] / gpio[22] U I/O 4 Data bus
E3 data[5] / gpio[21] U I/O 4 Data bus
B1 data[4] / gpio[20] U I/O 4 Data bus
b
U I/O 4 Data bus
D4 data[3] / gpio[19] U I/O 4 Data bus
C2 data[2] / gpio[18] U I/O 4 Data bus
B2 data[1] / gpio[17] U I/O 4 Data bus
D3 data[0] / gpio[16] U I/O 4 Data bus
www.digiembedded.com 29
PINOUT (265)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet interface MAC
Pin Signal U/D I/O OD Description
A10 data_mask[3] O 4 byte_enable data[31:24}
B11 data_mask[2] O 4 Byte enable data[23:16]
B10 data_mask[1] O 4 Byte enable data[15:08]
A11 data_mask[0] O 4 Byte enable data {07:00]
A9 ns_ta_strb I Slow peripheral transfer acknowledge
A6 rw_n O 4 Transfer direction
B7 clk_en[3] O 4 SDRAM clock enable
D7 clk_en[2] O 4 SDRAM clock enable
A7 clk_en[1] O 4 SDRAM clock enable
B8 clk_en[0] O 4 SDRAM clock enable
B4 cs[7] O 4 Chip select 7, dy_cs3
A3 cs[6] O 4 Chip select 6, st_cs3
A4 cs[5] O 4 Chip select 5, dy_cs2
C5 cs[4] O 4 Chip select 4, st_cs2
B5 cs[3] O 4 Chip select 3, dy_cs1
B6 cs[2] O 4 Chip select 2, st_cs1 (Flash boot)
D6 cs[1] O 4 Chip select 1, dy_cs0 (Boot sdram)
C6 cs[0] O 4 Chip select 0, st_cs0
C4 ras_n O 4 SDRAM RAS
A2 cas_n O 4 SDRAM CAS
C7 we_n O 4 SDRAM write enable
B3 ap10 O 4 SDRAM A10(AP)
A8 st_oe_n O 4 Static output enable
a. addr [27:24] reset to gpio mode. These address lines cannot be used for boot.
b. gpio[31:16] reset to memory data bus data [15:0].
Ethernet interface MAC
Pin Signal U/D I/O OD Description
A12 mdc / gpio[32] U I/O 2 MII clock
D11 mdio / gpio[35] U I/O 2 MII data
B12 tx_clk / gpio[33] U I/O 2 TX clock
A16 txd[3] / gpio[47] U I/O 2 TX data 3
30 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin Signal U/D I/O OD Description
D12 txd[2] / gpio[46] U I/O 2 TX data 2
C12 txd[1] / gpio[45] U I/O 2 TX data 1
B13 txd[0] / gpio[44] U I/O 2 TX data 0
B15 tx_er / gpio[43] U I/O 2 TX code err
B14 tx_en / gpio[42] U I/O 2 TX enable
C14 col / gpio[48] U I/O 2 Collision
C13 crs / gpio[49] U I/O 2 Carrier sense
A14 rx_clk / gpio[34] U I/O 2 RX clock
E17 rxd[3] / gpio[41] U I/O 2 RX data 3
D16 rxd[2] / gpio[40] U I/O 2 RX data 2
B17 rxd[1] / gpio[39] U I/O 2 RX data 1
D13 rxd[0] / gpio[38] U I/O 2 RX data 0
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
C17 rx_er / gpio[37] U I/O 2 RX error
D17 rx_dv / gpio[36] U I/O 2 RX data valid
General purpose I/O (GPIO)
Some signals are multiplexed to two or more GPIOs, to maximize the number of
possible applications. These duplicate signals are marked as (dup) in the
Descriptions column in the table. Selecting the primary GPIO pin and the
duplicate GPIO pin for the same function is not recommended. If both the
primary GPIO pin and duplicate GPIO pin are programmed for the same
function, however, the primary GPIO pin has precedence and will be used.
The I
2
C module must be held in reset until the GPIO assigned to I2C has been
configured.
www.digiembedded.com 31
PINOUT (265)
General purpose I/O (GPIO)
Note:
All GPIOs except 12 and 16 to 31 are reset to mode 3, input. GPIO 12 is reset
to mode 2, reset_done. GPIO 16 to 31 are reset to mode 0, external memory
data 15:0.
Pin Signal U/D I/O OD Description
K15 gpio[0] U I/O 2 0 DCD UART A
1 Ext DMA Done Ch 0
2 PIC_0_GEN_IO[0](I/O)
3 gpio[0]
4 SPI EN (dup)
K17 gpio[1] U I/O 2 0 CTS UART A
1E x t I n t 0
2 PIC_0_GEN_IO[1](I/O)
3 gpio[1]
4 Reserved
J17 gpio[2] U I/O 2 0 DSR UART A
1 Ext Int 1
2 PIC_0_GEN_IO[2](I/O)
3 gpio[2]
4 Reserved
J16 gpio[3] U I/O 2 0 RXD UART A
1 Ext DMA Pden Ch 0
2 PIC_0_GEN_IO[3](I/O)
3 gpio[3]
4 SPI RXD (dup)
H17 gpio[4] U I/O 2 0 RI UART A
1E x t I n t C h 2
2 Ext Timer Event In Ch 6
3 gpio[4]
4 SPI CLK (dup)
H13 gpio[5] U I/O 2 0 RTS / RS485 Control UART A
1E x t I n t C h 3
2 Ext Timer Event Out Ch 6
3 gpio[5]
4 SPI CLK (dup)
H14 gpio[6] U I/O 2 0 TXC / DTR UART A
1 Ext DMA Req Ch 0
2 Ext Timer Event In Ch 7
3 gpio[6]
4 PIC_DBG_DATA_OUT(O)
G14 gpio[7] U I/O 2 0 TXD UART A
1 Ext Timer Event In Ch 8
2 Ext Timer Event Out Ch 7
3 gpio[7]
4 SPI TXD (dup)
32 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
G17 gpio[8] U I/O 2 0 DCD / TXC UART C
1 Ext DMA Done Ch 1
2 Ext Timer Event Out Ch 8
3 gpio[8]
4 SPI EN (dup)
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
G15 gpio[9] U I/O 4 0 CTS UART C
G16 gpio[10] U I/O 2 0 DSR UART C
F13 gpio[11] U I/O 2 0 RXD UART C
F17 gpio[12] U I/O 4 0 RXC / RI UART C
F15 gpio[13] U I/O 2 0 RXC / RTS / RS485 Control UART C
2
C SCL
1I
2 Ext Int Ch 0 (dup)
3 gpio[9]
4 PIC_DBG_DATA_IN(I)
1 QDC 1
2 Ext Int Ch 1 (dup)
3 gpio[10]
4 PIC_DBG_CLK(O)
1 Ext DMA Pden Ch 1
2 Ext Int Ch 2 (dup)
3 gpio[11]
4 SPI RXD (boot)
2
a
C SDA
1I
2 reset_done
3 gpio[12]
4 SPI CLK (dup)
1 QDC Q
2 Ext Timer Event Out Ch 9
3 gpio[13]
4 SPI CLK (boot)
E14 gpio[14] U I/O 2 0 TXC / DTR UART C
1 DMA Req Ch 1
2 PIC_0_CAN_RXD(I)
3 gpio[14]
4 SPI TXD (boot)
D14 gpio[15] U I/O 2 0 TXD UART C
1 Ext Timer Event In Ch 9
2 PIC_0_CAN_TXD(O)
3 gpio[15]
4 SPI EN (boot)
www.digiembedded.com 33
PINOUT (265)
General purpose I/O (GPIO)
Pin Signal U/D I/O OD Description
D3 gpio[16] U I/O 4 0 data[0]
1 DCD UART B
2 Ext Int Ch 0 (dup)
3 gpio[16]
B2 gpio[17] U I/O 4 0 data[1]
1C T S U A R T B
2 Ext Int Ch 1 (dup)
3 gpio[17]
C2 gpio[18] U I/O 4 0 data[2]
1D S R U A R T B
2 Ext Int Ch 2 (dup)
3 gpio[18]
D4 gpio[19] U I/O 4 0 data[3]
1R X D U A R T B
2 EXT INT CH 3 (dup)
3 gpio[19]
B1 gpio[20] U I/O 4 0 data[4]
1R I U A R T B
2 Ext DMA Done Ch 0 (dup)
3 gpio[20]
E3 gpio[21] U I/O 4 0 data[5]
1 RTS / RS485 Control UART B
2 Ext DMA Pden Ch 0 (dup)
3 gpio[21]
D2 gpio[22] U I/O 4 0 data[6]
1 TXC / DTR UART B
2 Ext DMA Done Ch 1 (dup)
3 gpio[22]
E4 gpio[23] U I/O 4 0 data[7]
1T X D U A R T B
2 PIC_1_CAN_RXD(I)
3 gpio[23]
C1 gpio[24] U I/O 4 0 data[8]
1 DCD UART D
2 PIC_1_CAN_TXD(O)
3 gpio[24]
F5 gpio[25] U I/O 4 0 data[9]
1C T S U A R T D
2 reset_done (dup)
3 gpio[25]
34 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
F4 gpio[26] U I/O 4 0 data[10]
1D S R U A R T D
2 PIC_1_GEN_IO[0](I/O)
3 gpio[26]
F3 gpio[27] U I/O 4 0 data[11]
1R X D U A R T D
2 PIC_1_GEN_IO[1](I/O)
3 gpio[27]
G5 gpio[28] U I/O 4 0 data[12]
1 RI UART D
2 PIC_1_GEN_IO[2](I/O)
3 gpio[28]
G4 gpio[29] U I/O 4 0 data[13]
1 RTS / RS485 Control UART D
2 PIC_1_GEN_IO[3](I/O)
3 gpio[29]
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
G3 gpio[30] U I/O 4 0 data[14]
1 TXC / DTR UART D
2 Reserved
3 gpio[30]
H4 gpio[31] U I/O 4 0 data[15]
1T X D U A R T D
2 Reserved
3 gpio[31]
A12 gpio[32] U I/O 2 0 Ethernet MII MDC
1 PIC_0_GEN_IO[0](I/O)(dup)
2 Reserved
3 gpio[32]
B12 gpio[33] U I/O 2 0 Ethernet MII TXC
1 PIC_0_GEN_IO[1](I/O)(dup)
2 Reserved
3 gpio[33]
A14 gpio[34] U I/O 2 0 Ethernet MII RXC
1 PIC_0_GEN_IO[2](I/O)(dup)
2 Reserved
3 gpio[34]
D11 gpio[35] U I/O 2 0 Ethernet MII MDIO
1 PIC_0_GEN_IO[3](I/O)(dup)
2 Reserved
3 gpio[35]
www.digiembedded.com 35
PINOUT (265)
General purpose I/O (GPIO)
Pin Signal U/D I/O OD Description
D17 gpio[36] U I/O 2 0 Ethernet MII RX DV
1 PIC_0_GEN_IO[4](I/O)(dup)
2 Reserved
3 gpio[36]
C17 gpio[37] U I/O 2 0 Ethernet MII RX ER
1 PIC_0_GEN_IO[5](I/O)(dup)
2 Reserved
3 gpio[37]
D13 gpio[38] U I/O 2 0 Ethernet MII RXD[0]
1 PIC_0_GEN_IO[6](I/O)(dup)
2 Reserved
3 gpio[38]
B17 gpio[39] U I/O 2 0 Ethernet MII RXD[1]
1 PIC_0_GEN_IO[7](I/O)(dup)
2 Reserved
3 gpio[39]
D16 gpio[40] U I/O 2 0 Ethernet MII RXD [2]
1 PIC_1_GEN_IO[0](I/O)(dup)
2 Reserved
3 gpio[40]
E17 gpio[41] U I/O 2 0 Ethernet MII RXD[3]
1 PIC_1_GEN_IO[1](I/O)(dup)
2 Reserved
3 gpio[41]
B14 gpio[42] U I/O 2 0 Ethernet MII TX EN
1 PIC_1_GEN_IO[2](I/O)(dup)
2 Reserved
3 gpio[42]
B15 gpio[43] U I/O 2 0 Ethernet MII TX ER
1 PIC_1_GEN_IO[3](I/O)(dup)
2 Reserved
3 gpio[43]
B13 gpio[44] U I/O 2 ) Ethernet MII TXD[0]
1 PIC_1_GEN_IO[4](I/O)(dup)
2 Reserved
3 gpio[44]
C12 gpio[45] U I/O 2 0 Ethernet MII TXD[1]
1 PIC_1_GEN_IO[5](I/O)(dup)
2 Reserved
3 gpio[45]
36 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
D12 gpio[46] U I/O 2 0 Ethernet MII TXD[2]
1 PIC_1_GEN_IO[6](I/O)(dup)
2 Reserved
3 gpio[46]
A16 gpio[47] U I/O 2 0 Ethernet MII TXD[3]
1 PIC_1_GEN_IO[7](I/O)(dup)
2 Reserved
3 gpio[47]
C14 gpio[48] U I/O 2 0 Ethernet MII COL
1 Reserved
2 Reserved
3 gpio[48]
C13 gpio[49] U I/O 2 0 Ethernet MII CRS
1 Reserved
2 Reserved
3 gpio[49]
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
C11 gpio[50] U I/O 2 0 Ethernet MII PHY Int
1 PIC_1_CLK(I)
2 PIC_1_CLK(O)
3 gpio[50]
E10 gpio[51] U I/O 2 0 DCD UART B (dup)
1 PIC_0_BUS_1[8](I/O)
2 PIC_1_BUS_1[8](I/O)
3 gpio[51]
D10 gpio[52] U I/O 2 0 CTS UART B (dup)
1 PIC_0_BUS_1[9](I/O)
2 PIC_1_BUS_1[9](I/O)
3 gpio[52]
C10 gpio[53] U I/O 2 0 DSR UART B (dup)
1 PIC_0_BUS_1[10](I/O)
2 PIC_1_BUS_1[10](I/O)
3 gpio[53]
C9 gpio[54] U I/O 2 0 RXD UART B (dup)
1 PIC_0_BUS_1[11](I/O)
2 PIC_1_BUS_1[11](I/O)
3 gpio[54]
H5 gpio[55] U I/O 2 0 RI UART B (dup)
1 PIC_0_BUS_1[12](I/O)
2 PIC_1_BUS_1[12](I/O)
3 gpio[55]
www.digiembedded.com 37
PINOUT (265)
General purpose I/O (GPIO)
Pin Signal U/D I/O OD Description
J4 gpio[56] U I/O 2 0 RTS/RS485 Control UART B (dup)
1 PIC_0_BUS_1[13](I/O)
2 PIC_1_BUS_1[13](I/O)
3 gpio[56]
K3 gpio[57] U I/O 2 0 TXC/DTR UART B (dup)
1 PIC_0_BUS_1[14](I/O)
2 PIC_1_BUS_1[14](I/O)
3 gpio[57]
K4 gpio[58] U I/O 2 0 TXD UART B (dup)
1 PIC_0_BUS_1[15](I/O)
2 PIC_1_BUS_1[15](I/O)
3 gpio[58]
K5 gpio[59] U I/O 2 0 DCD UART D (dup)
1 PIC_0_BUS_1[16](I/O)
2 PIC_1_BUS_1[16](I/O)
3 gpio[59]
R6 gpio[60] U I/O 2 0 CTS UART D (dup)
1 PIC_0_BUS_1[17](I/O)
2 PIC_1_BUS_1[17](I/O)
3 gpio[60]
P6 gpio[61] U I/O 2 0 DSR UART D (dup)
1 PIC_0_BUS_1[18](I/O)
2 PIC_1_BUS_1[18](I/O)
3 gpio[61]
R7 gpio[62] U I/O 2 0 RXD UART D (dup)
1 PIC_0_BUS_1[19](I/O)
2 PIC_1_BUS_1[19](I/O)
3 gpio[62]
P7 gpio[63] U I/O 2 0 RI UART D (dup)
1 PIC_0_BUS_1[20](I/O)
2 PIC_1_BUS_1[20](I/O)
3 gpio[63]
R8 gpio[64] U I/O 2 0 RTS/R5485 Control UART D (dup)
1 PIC_0_BUS_1[21](I/O)
2 PIC_1_BUS_1[21](I/O)
3 gpio[64]
P8 gpio[65] U I/O 2 0 TXC/DTR UART D (dup)
1 PIC_0_BUS_1[22](I/O)
2 PIC_1_BUS_1[22](I/O)
3 gpio[65]
38 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
N8 gpio[66] U I/O 2 0 TXD UART D (dup)
1 PIC_0_BUS_1[23](I/O)
2 PIC_1_BUS_1[23](I/O)
3 gpio[66]
P9 gpio[67] U I/O 2 0 PIC_0_CLK(I)
1 PIC_0_CLK(O)
2 Ext Int Ch 3 (dup)
3 gpio[67]
R10 gpio[68] U I/O 2 0 PIC_0_GEN_IO[0](I/O)(dup)
1 PIC_1_GEN_IO[0](I/O)
2 PIC_1_CAN_RXD(I)(dup)
3 gpio[68]
P10 gpio[69] U I/O 2 0 PIC_0_GEN_IO[1](I/O)(dup)
1 PIC_1_GEN_IO[1](I/O)
2 PIC_1_CAN_TXD(O)(dup)
3 gpio[69]
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
N10 gpio[70] U I/O 2 0 PIC_0_GEN_IO[2](I/O)(dup)
1 PIC_1_GEN_IO[2](I/O)
2P W M C h 0
3 gpio[70]
P11 gpio[71] U I/O 2 0 PIC_0_GEN_IO[3](I/O)(dup)
1 PIC_1_GEN_IO[3](I/O)
2P W M C h 1
3 gpio[71]
N12 gpio[72] U I/O 2 0 PIC_0_GEN_IO[4](I/O)
1 PIC_1_GEN_IO[4](I/O)
2P W M C h 2
3 gpio[72]
R13 gpio[73] U I/O 2 0 PIC_0_GEN_IO[5](I/O)
1 PIC_1_GEN_IO[5](I/O)
2P W M C h 3
3 gpio[73]
P13 gpio[74] U I/O 2 0 PIC_0_GEN_IO[6](I/O)
1 PIC_0_GEN_IO[6](I/O)
2 Ext Timer Event In Ch 0
3 gpio[74]
U16 gpio[75] U I/O 2 0 PIC_0_GEN_IO[7](I/O)
1 PIC_1_GEN_IO[7](I/O)
2 Ext Timer Event in Ch 1
3 gpio[75]
www.digiembedded.com 39
PINOUT (265)
General purpose I/O (GPIO)
Pin Signal U/D I/O OD Description
T15 gpio[76] U I/O 2 0 PIC_0_CTL_IO[0](I/O)
1 PIC_1_CTL_IO[0](I/O)
2 Ext Timer Event in Ch 2
3 gpio[76]
T16 gpio[77] U I/O 2 0 PIC_0_CTL_IO[1](I/O)
1 PIC_1_CTL_IO[1](I/O)
2 Ext Timer Event in Ch 3
3 gpio[77]
R14 gpio[78] U I.O 2 0 PIC_0_CTL_IO[2](I/O)
1 PIC_1_CTL_IO[2](I/O)
2 Ext Timer Event in Ch 4
3 gpio[78]
P14 gpio[79] U I/O 2 0 PIC_0_CTL_IO[3](I/O)
1 PIC_1_CTL_IO[3](I/O)
2 Ext Timer Event in Ch 5
3 gpio[79]
R17 gpio[80] U I/O 2 0 PIC_0_BUS_0[0](I/O)
1 PIC_1_BUS_0[0](I/O)
2 Ext Timer Event in Ch 6 (dup)
3 gpio[80]
P17 gpio[81] U I/O 2 0 PIC_0_BUS_0[1](I/O)
1 PIC_1_BUS_0[1](I/O)
2 Ext Timer Event in Ch 7(dup)
3 gpio[81]
N16 gpio[82] U I/O 2 0 PIC_0_BUS_0[2](I/O)
1 PIC_1_BUS_0[2](I/O)
2 Ext Timer Event in Ch 8 (dup)
3 gpio[82]
N17 gpio[83] U I/O 2 0 PIC_0_BUS_0[3](I/O)
1 PIC_1_BUS_0[3](I/O)
2 Ext Timer Event in Ch 9 (dup)
3 gpio[83]
M17 gpio[84] U I/O 2 0 PIC_0_BUS_0[4](I/O)
1 PIC_1_BUS_0[4](I/O)
2 Ext Timer Event Out Ch 0
3 gpio[84]
L15 gpio[85] U I/O 2 0 PIC_0_BUS_0[5](I/O)
1 PIC_1_BUS_0[5](I/O)
2 Ext Timer Event Out Ch 1
3 gpio[85]
40 Hardware Reference NS9215
Pin Signal U/D I/O OD Description
K13 gpio[86] U I/O 2 0 PIC_0_BUS_0[6](I/O)
1 PIC_1_BUS_0[6](I/O)
2 Ext Timer Event Out Ch 2
3 gpio[86]
K16 gpio[87] U I/O 2 0 PIC_0_BUS_0[7](I/O)
1 PIC_1_BUS_0[7](I/O)
2 Ext Timer Event Out Ch 3
3 gpio[87]
K14 gpio[88] U I/O 2 0 PIC_0_BUS_0[8](I/O)
1 PIC_1_BUS_0[8](I/O)
2 Ext Timer Event Out Ch 4
3 gpio[88]
J14 gpio[89] U I/O 2 0 PIC_0_BUS_0[9](I/O)
1 PIC_1_BUS_0[9](I/O)
2 Ext Timer Event Out Ch 5
3 gpio[89]
PINOUT (265)
General purpose I/O (GPIO)
. . . . .
H16 gpio[90] U I/O 2 0 PIC_0_BUS_0[10](I/O)
1 PIC_1_BUS_0[10](I/O)
2 Ext Timer Event Out Ch 6
3 gpio[90]
H15 gpio[91] U I/O 2 0 PIC_0_BUS_0[11](I/O)
1 PIC_1_BUS_0[11](I/O)
2 Ext Timer Event Out Ch 7
3 gpio[91]
F14 gpio[92] U I/O 2 0 PIC_0_BUS_0[12](I/O)
1 PIC_1_BUS_0[12](I/O)
2 Ext Timer Event Out Ch 8
3 gpio[92]
F16 gpio[93] U I/O 2 0 PIC_0_BUS_0[13](I/O)
1 PIC_1_BUS_0[13](I/O)
2 Ext Timer Event Out Ch 9
3 gpio[92]
E15 gpio[94] U I/O 2 0 PIC_0_BUS_0[14](I/O)
1 PIC_1_BUS_0[14](I/O)
2 QDC I (dup)
3 gpio[94]
E16 gpio[95] U I/O 2 0 PIC_0_BUS_0[15](I/O)
1 PIC_1_BUS_0[15](I/O)
2 QDC Q (dup)
3 gpio[95]
www.digiembedded.com 41
PINOUT (265)
General purpose I/O (GPIO)
Pin Signal U/D I/O OD Description
C16 gpio[96] U I/O 2 0 PIC_0_BUS_1[0](I/O)
1 PIC_1_BUS_1[0](I/O)
2 PIC_0_CAN_RXD(I)(dup)
3 gpio[96]
B16 gpio[97] U I/O 2 0 PIC_0_BUS_1[1](I/O)
1 PIC_1_BUS_1[1](I/O)
2 PIC_0_CAN_TXD(O)(dup)
3 gpio97
D15 gpio[98] U I/O 2 0 PIC_0_BUS_1[2](I/O)
1 PIC_1_BUS_1[2](I/O)
2 PIC_1_CAN_RXD(I)(dup)
3 gpio[98]
E8 gpio[99] U I/O 2 0 PIC_0_BUS_1[3](I/O)
1 PIC_1_BUS_1[3](I/O)
2 PIC_1_CAN_TXD(O)(dup)
3 gpio[99]
D8 gpio[100] U I/O 2 0 PIC_0_BUS_1[4](I/O)
1 PIC_1_BUS_1[4](I/O)
2P W M C h 4
3 gpio[100]
C8 gpio[101] U I/O 2 0 PIC_0_BUS_1[5](I/O)
1 PIC_1_BUS_1[5](I/O)
2 Ext Int Ch 3 (dup)
3 gpio[101]
E6 gpio[102] U I/O 4 0 PIC_0_BUS_1[6](I/O)
1 PIC_1_BUS_1[6](I/O)
2
C SCL (dup)
2I
3 gpio[102]
D5 gpio[103] U I/O 4 0 PIC_0_BUS_1[7](I/O)
1 PIC_1_BUS_1[7](I/O)
2
C SDA (dup)
2I
3 gpio[103]
R12 gpio_a[0] U I/O 4 0 addr[24]
2
C SCL (dup)
1I
2 Ext Int Ch 0 (dup)
3 gpio_a[0], Boot width[1]
U15 gpio_a[1] U I/O 4 0 addr[25]
2
C SDA (dup)
1I
2 Ext Int Ch 1(dup)
3 Ext Int Ch 0]
42 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin Signal U/D I/O OD Description
T14 gpio_a[2] U I/O 4 0 addr[26]
1 Reserved 1 cs0_we_n
2 Ext Int Ch 2 (dup)
3 gpio_a[2], SPI boot
P12 gpio_a[3] U I/O 4 0 addr[27]
1 Reserved 1 cs0_oe_n
2 UART ref clock
3 gpio_a[3], Endian
a. There is a possible conflict when gpio12 is used as the I2C_SDA signal. in this case the I2C_SDA signal is driven low
while in reset, then driven active high after end of reset, until software configures this pin for the I2C function.
System clock
Pin Signal U/D I/O OD Description
PINOUT (265)
System clock
. . . . .
L16 x1_sys_osc I System oscillator circuit in
L17 x2_sys_osc O System oscillator circuit out
M15 sys_pll_dvdd P PLL clean power
M16 sys_pll_dvss P PLL clean ground
P2 x1_rtc_osc I RTC oscillator circuit in (32.768 KHz)
R2 x2_rtc_osc O RTC oscillator circuit out
www.digiembedded.com 43
System clock
drawing
PINOUT (265)
System clock
44 Hardware Reference NS9215
RTC clock and
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
battery backup
drawing
PINOUT (265)
System mode
. . . . .
System mode
Note: If RTC battery backup is not used, the following connection changes can be
made.
N3, M4 bat_vdd_reg tie to 1.8V
32.788kHz crystal load capacitors tie to N3, M4 (1.8V)
N4 bat_vdd tie to 3.3V
R1 aux_comp tie to ground
Pin Signal U/D I/O OD Description
M13 sys_mode_2 I test mode pins
M14 sys_mode_1 I test mode pins
L14 sys_mode_0 I test mode pins
v
www.digiembedded.com 45
PINOUT (265)
System mode
sys_mode_2 sys_mode_1 sys_mode_0 Description
0 0 0 manufacturing test
0 0 1 manufacturing test
0 1 0 manufacturing test
0 1 1 normal operation, boundary scan enabled, POR disabled
1 0 0 normal operation, boundary scan enabled, POR enabled
1 0 1 board test mode, all outputs tristated
1 1 0 normal operation, ARM debug enabled, POR disabled
1 1 1 normal operation, ARM debug enabled, POR enabled
46 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System reset
POR
trips when
voltage on L3
drops below
2.74V/2.97V
POR disable
(as encoded on mode pins)
NS9215 C ore
NS9215
reset_out_n
reset_done
reset_ n
sreset_n
De finition s
reset_n – hardware reset input buffer with pull-up resistor
sreset_n – soft reset input buffer with pull-up resistor, does not reset the PLL
reset_out_n – hardware reset to NS9215 core and output buffer, resets all logic in NS9215 core including PLL
reset_done – reflects the state of the ARM926 reset, for any type of reset event
PINOUT (265)
System reset
. . . . .
Pin Signal U/D I/O OD Description
E12 reset_n U I System reset
A5 reset_out_n O 2 System reset output
A13 reset_done O 2 Reset done
D9 sreset_n U I Soft system reset
RESET_n
pin
SPI YES YES YES YES
BootStrapping PL YES NO NO NO
Other Strappings
(Endianess
GPIO Configuration YES NO NO NO
Other (ASIC) Registers YES YES YES YEs
Y E SN ON ON O
SRESET_n
pin
PLL Config
Reg.
Update
Watchdog
Time-Out
Reset
www.digiembedded.com 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JTAG Test
PINOUT (265)
JTAG Test
Pin Signal U/D I/O OD Description
N14 tdi U I Test data in
N15 tdo O 2 Test data out
T17 tms U I Test mode select
R16 trst_n U I Test mode reset. For normal operation, this pin
is tied to ground or pulled down.
P15 tck I Test mode clock
P16 rtck O 2 Test mode return clock
48 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ADC
PINOUT (265)
ADC
. . . . .
Pin Signal U/D I/O OD Description
P4 agnd_ref_adc Analog reference ground
P5 VREF_adc Analog reference voltage (3.3max
T2 vss_adc ADC_VSS
N6 vdd_adc ADC VDD (3.3V)
R4 vin0_adc I ADC input 0
T3 vin1_adc I ADC input 1
R5 vin2_adc I ADC input 2
U2 vin3_adc I ADC input 3
T4 vin4_adc I ADC input 4
U3 vin5_adc I ADC input 5
T5 vin6_adc I ADC input 6
U4 vin7_adc I ADC input 7
If the ADC feature is not used, the inputs must be terminated as shown below:
P4 agnd_ref_adc tie to ground
P5 VREF_adc tie to ground
T2 vss_adc tie to ground
N6 vdd_adc tie to 3.3V
R4 vin0_adc tie to ground
T3 vin1_adc tie to ground
R5 vin2_adc tie to ground
U2 vin3_adc tie to ground
T4 vin4_adc tie to ground
U3 vin5_adc tie to ground
T5 vin6_adc tie to ground
U4 vin7_adc tie to ground
www.digiembedded.com 49
PINOUT (265)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POR and battery-backed logic
POR and battery-backed logic
Pin Signal U/D I/O OD Description
M3 por_gnd_reg POR reference ground
N2 por_vss POR VSS
P1 por_vdd POR VDD (3.3V)
L3 por_reference POR reference trip voltage (2.74V min /
T1 por_early_reference POR early power loss voltage (1.19V min /
N4 bat_vdd Battery VDD (3.0V)
R1 aux_comp Auxiliary analog comparator input (trip point
N3, M4 bat_vdd_reg Battery regulated core VDD (1.8V)
P3 por_bypass U I POR bypass, pull low to disable POR
2.97V max)
1.28V max)
2.4V min / 2.5V max)
L4 por_test POR analog test pin, leave unconnected
The POR will generate keep reset_out_n low between 75ms and 300ms after 3.3V
reaches the POR reference trip voltage threshold. The POR reference trip voltage is
between 2.74V and 2.97V, with hysteresis between 50mV and 80mV.
If the POR feature is not used, and the RTC is used, the inputs must be terminated
as shown below.
M3 por_gnd_reg tie to ground
N2 por_vss tie to ground
P1 por_vdd tie to 3.3V
L3 por_reference tie to 3.3V
T1 por_early_reference tie to ground
P3 por_bypass tie to 1.8V
E12 reset_n tie to system reset (remains active low 40 ms Min. after 3.3V & 1.8V are valid)
A5 reset_out_n leave open
M13,
M14,
L14
sys_mode [2.0] POR disabled (See System mode table & JTAG drawing following JTAG Test
table)
50 Hardware Reference NS9215
If the RTC feature is not used, the inputs must be terminated as shown below.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
N4 Bat_vdd tie to 3.3V
R1 aux_comp tie to ground
N3, M4 bat_vdd_reg tie to ground
P2 x1_rtc_osc tie to ground
R2 x2_rtc_osc leave open
If the RTC feature is used, see RTC clock and battery backup drawing on page 45.
Power and ground
Pin Signal
E7, E11, G7, G11, G13, L5, L7, L11, L13, N7, N11 Core VCC (1.8V)
PINOUT (265)
Power and ground
. . . . .
A1. A17. C3, C15, E5, E9, E13, J5, J13, J15, N5, N9, N13, R3, R15, U1, U17 I/O VCC (3.3V)
G8, G9, G10, H7, H8, H9, H10, H11, J7, J8, J9, J10, J11, K7, K8, K9, K10,
K11, L8, L9, L10, M5
GND
www.digiembedded.com 51
PINOUT (265)
Power and ground
52 Hardware Reference NS9215
I/O Control Module
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHAPTER 2
The NS9215 ASIC contains 108 pins that are designated as general purpose I/O
(GPIO).
The first 16 GPIO can be configured to serve one of five functions.
The remaining GPIO can be configured to serve one of four functions.
All signals set to a disabled peripheral are held in the inactive state. The I/O control
module contains the control register and multiplexing logic required to accomplish
this task.
System memory
bus I/O control
The registers in this section control these system memory I/O configuration options:
System chip select options, used to select which chip select is output
Upper address option
Control and Status registers
The I/O control module configuration registers are located at base address
0xA090_2000.
Register address
map
Address Description Access Reset value
A090_2000 GPIO Configuration Register #0 R/W 0x18181818
A090_2004 GPIO Configuration Register #1 R/W 0x18181818
A090_2008 GPIO Configuration Register #2 R/W 0x18181818
53
I/O CONTROL MODULE
Control and Status registers
Address Description Access Reset value
A090_200C GPIO Configuration Register #3 R/W 0x18181810
A090_2010 GPIO Configuration Register #4 R/W 0x00000000
A090_2014 GPIO Configuration Register #5 R/W 0x00000000
A090_2018 GPIO Configuration Register #6 R/W 0x00000000
A090_201C GPIO Configuration Register #7 R/W 0x00000000
A090_2020 GPIO Configuration Register #8 R/W 0x18181818
A090_2024 GPIO Configuration Register #9 R/W 0x18181818
A090_2028 GPIO Configuration Register #10 R/W 0x18181818
A090_202C GPIO Configuration Register #11 R/W 0x18181818
A090_2030 GPIO Configuration Register #12 R/W 0x18181818
A090_2034 GPIO Configuration Register #13 R/W 0x18181818
A090_2038 GPIO Configuration Register #14 R/W 0x18181818
A090_203C GPIO Configuration Register #15 R/W 0x18181818
A090_2040 GPIO Configuration Register #16 R/W 0x18181818
A090_2044 GPIO Configuration Register #17 R/W 0x18181818
A090_2048 GPIO Configuration Register #18 R/W 0x18181818
A090_204C GPIO Configuration Register #19 R/W 0x18181818
A090_2050 GPIO Configuration Register #20 R/W 0x18181818
A090_2054 GPIO Configuration Register #21 R/W 0x18181818
A090_2058 GPIO Configuration Register #22 R/W 0x18181818
A090_205C GPIO Configuration Register #23 R/W 0x18181818
A090_2060 GPIO Configuration Register #24 R/W 0x18181818
A090_2064 GPIO Configuration Register #25 R/W 0x18181818
A090_2068 GPIO Configuration Register #26 R/W 0x18181818
A090_206C GPIO Control Register #0 R/W 0x00000000
A090_2070 GPIO Control Register #1 R/W 0x00000000
A090_2074 GPIO Control Register #2 R/W 0x00000000
A090_2078 GPIO Control Register #3 R/W 0x00000000
A090_207C GPIO Status Register #0 R Undefined
A090_2080 GPIO Status Register #1 R Undefined
A090_2084 GPIO Status Register #2 R Undefined
A090_2088 GPIO Status Register #3 R Undefined
1
1
1
1
54 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Address Description Access Reset value
A090_208C Memory Bus Configuration register R/W 007D6344
1 The reset values for all the status bits are undefined because they depend on the state of the GPIO
pins to NS9215.
GPIO Configuration registers
GPIO Configuration registers #0 through #26 contain the configuration information
for each of the 108 GPIO pins. Each GPIO pin can have up to four functions.
Configure each pin for the function and direction needed, using the configuration
options shown below.
I/O CONTROL MODULE
GPIO Configuration registers
. . . . .
GPIO
configuration
options
Each GPIO configuration section is set up the same way. This table shows the settings
using bits D07:00; the same settings apply to the corresponding bits in D15:08,
D23:D16, and D31:24.
Bit(s) Mnemonic Description
D07:06 Reserved N/A
D05:03 FUNC Use these bits to select the function you want to use. For a definition of each
function, see “General purpose I/O (GPIO)” on page 31.
000 Function #0
001 Function #1
010 Function #2
011 Function #3
100 Function #4 (applicable only for GPIO 0–15)
D02 DIR Controls the pin direction when the FUNC field is configured for GPIO
mode, function #3.
0 Input
1 Output
All GPIO pins reset to the input state.
Note: The pin direction is controlled by the selected function in modes
#0 through #2.
D01 INV Controls the inversion function of the GPIO pin.
0 Disables the inversion function
1 Enables the inversion function
This bit applies to all functional modes.
D00 PUDIS Controls the GPIO pin pullup resistor operation.
0 Enables the pullup
1 Disables the pullup
Note: The pullup cannot be disabled on GPIO[9], GPIO[12], and on
GPIO_A[0] and GPIO_A[1].
www.digiembedded.com 55
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO3 GPIO2
GPIO1
GPIO0
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO7 GPIO6
GPIO5
GPIO4
GPIO Configuration registers
GPIO
Configuration
Register #0
GPIO
Configuration
Register #1
Address: A090_2000
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO3 0x18 GPIO[3] configuration
D23:16 R/W GPIO2 0x18 GPIO[2] configuration
D15:08 R/W GPIO1 0x18 GPIO[1] configuration
D07:00 R/W GPIO0 0x18 GPIO[0] configuration
Address: A090_2004
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO7 0x18 GPIO[7] configuration
D23:16 R/W GPIO6 0x18 GPIO[6] configuration
D15:08 R/W GPIO5 0x18 GPIO[5] configuration
D07:00 R/W GPIO4 0x18 GPIO[4] configuration
56 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO11 GPIO10
GPIO9
GPIO8
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GP IO15 GPIO 1 4
GPIO13
GPIO12
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #2
GPIO
Configuration
Register #3
Address: A090_2008
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO11 0x18 GPIO[11] configuration
D23:16 R/W GPIO10 0x18 GPIO[10] configuration
D15:08 R/W GPIO9 0x18 GPIO[9] configuration
D07:00 R/W GPIO8 0x18 GPIO[8] configuration
Address: A090_200C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO15 0x18 GPIO[15] configuration
D23:16 R/W GPIO14 0x18 GPIO[14 configuration
D15:08 R/W GPIO13 0x18 GPIO[13] configuration
D07:00 R/W GPIO12 0x10 GPIO[12] configuration
www.digiembedded.com 57
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO19 GPIO18
GPIO17
GPIO16
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO23 GPIO22
GPIO21
GPIO20
GPIO Configuration registers
GPIO
Configuration
Register #4
GPIO
Configuration
Register #5
Address: A090_2010
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO19 0x00 GPIO[19] configuration
D23:16 R/W GPIO18 0x00 GPIO[18] configuration
D15:08 R/W GPIO17 0x00 GPIO[17] configuration
D07:00 R/W GPIO16 0x00 GPIO[16] configuration
Address: A090_2014
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO23 0x00 GPIO[23] configuration
D23:16 R/W GPIO22 0x00 GPIO[22] configuration
D15:08 R/W GPIO21 0x00 GPIO[21] configuration
D07:00 R/W GPIO20 0x00 GPIO[20] configuration
58 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO27 GPIO26
GPIO25
GPIO24
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO39 G PIO38
GPIO37
GPIO36
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #6
GPIO
Configuration
Register #7
Address: A090_2018
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO27 0x00 GPIO[27] configuration
D23:16 R/W GPIO26 0x00 GPIO[26] configuration
D15:08 R/W GPIO25 0x00 GPIO[25] configuration
D07:00 R/W GPIO24 0x00 GPIO[24] configuration
Address: A090_201C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO31 0x00 GPIO[31] configuration
D23:16 R/W GPIO30 0x00 GPIO[30] configuration
D15:08 R/W GPIO29 0x00 GPIO[29] configuration
D07:00 R/W GPIO28 0x00 GPIO[28] configuration
www.digiembedded.com 59
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GP IO35 GP IO 3 4
GPIO33
GPIO32
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
G P IO39 GP IO38
GPIO37
GPIO36
GPIO Configuration registers
GPIO
Configuration
Register #8
GPIO
Configuration
Register #9
Address: A090_2020
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO35 0x18 GPIO[35] configuration
D23:16 R/W GPIO34 0x18 GPIO[34] configuration
D15:08 R/W GPIO33 0x18 GPIO[33] configuration
D07:00 R/W GPIO32 0x18 GPIO[32] configuration
Address: A090_2024
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO39 0x18 GPIO[39] configuration
D23:16 R/W GPIO38 0x18 GPIO[38] configuration
D15:08 R/W GPIO37 0x18 GPIO[37] configuration
D07:00 R/W GPIO36 0x18 GPIO[36] configuration
60 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
G P IO 43 GPIO42
GPIO41
GPIO40
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO47 GPIO46
GPIO45
GPIO44
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #10
GPIO
Configuration
Register #11
Address: A090_2028
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO43 0x18 GPIO[43] configuration
D23:16 R/W GPIO42 0x18 GPIO[42] configuration
D15:08 R/W GPIO41 0x18 GPIO[41] configuration
D07:00 R/W GPIO40 0x18 GPIO[40] configuration
Address: A090_202C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO47 0x18 GPIO[47] configuration
D23:16 R/W GPIO46 0x18 GPIO[46] configuration
D15:08 R/W GPIO45 0x18 GPIO[45] configuration
D07:00 R/W GPIO44 0x18 GPIO[44] configuration
www.digiembedded.com 61
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO51 GPIO50
GPIO49
GPIO48
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO55 GPIO54
GPIO53
GPIO52
GPIO Configuration registers
GPIO
Configuration
Register #12
GPIO
Configuration
Register #13
Address: A090_2030
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO51 0x18 GPIO[51] configuration
D23:16 R/W GPIO50 0x18 GPIO[50] configuration
D15:08 R/W GPIO49 0x18 GPIO[49] configuration
D07:00 R/W GPIO48 0x18 GPIO[48] configuration
Address: A090_2034
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO55 0x18 GPIO[55] configuration
D23:16 R/W GPIO54 0x18 GPIO[54] configuration
D15:08 R/W GPIO53 0x18 GPIO[53] configuration
D07:00 R/W GPIO52 0x18 GPIO[52] configuration
62 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO59 GPIO 5 8
GPIO57
GPIO56
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO63 GPIO62
GPIO61
GPIO60
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #14
GPIO
Configuration
Register #15
Address: A090_2038
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO59 0x18 GPIO[59] configuration
D23:16 R/W GPIO58 0x18 GPIO[58] configuration
D15:08 R/W GPIO57 0x18 GPIO[57] configuration
D07:00 R/W GPIO56 0x18 GPIO[56] configuration
Address: A090_203C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO63 0x18 GPIO[63] configuration
D23:16 R/W GPIO62 0x18 GPIO[62] configuration
D15:08 R/W GPIO61 0x18 GPIO[61] configuration
D07:00 R/W GPIO60 0x18 GPIO[60] configuration
www.digiembedded.com 63
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO67 GPIO66
GPIO65
GPIO64
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO71 GPIO70
GPIO69
GPIO68
GPIO Configuration registers
GPIO
Configuration
Register #16
GPIO
Configuration
Register #17
Address: A090_2040
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO67 0x18 GPIO[67] configuration
D23:16 R/W GPIO66 0x18 GPIO[66] configuration
D15:08 R/W GPIO65 0x18 GPIO[65] configuration
D07:00 R/W GPIO64 0x18 GPIO[64] configuration
Address: A090_2044
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO71 0x18 GPIO[71] configuration
D23:16 R/W GPIO70 0x18 GPIO[70] configuration
D15:08 R/W GPIO69 0x18 GPIO[69] configuration
D07:00 R/W GPIO68 0x18 GPIO[68] configuration
64 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
G P IO75 GPIO7 4
GPIO73
GPIO72
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO79 GPIO78
GPIO77
GPIO76
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #18
GPIO
Configuration
Register #19
Address: A090_2048
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO75 0x18 GPIO[75] configuration
D23:16 R/W GPIO74 0x18 GPIO[74] configuration
D15:08 R/W GPIO73 0x18 GPIO[73] configuration
D07:00 R/W GPIO72 0x18 GPIO[72] configuration
Address: A090_204C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO79 0x18 GPIO[79] configuration
D23:16 R/W GPIO78 0x18 GPIO[78] configuration
D15:08 R/W GPIO77 0x18 GPIO[77] configuration
D07:00 R/W GPIO76 0x18 GPIO[76] configuration
www.digiembedded.com 65
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO83 GPIO82
GPIO81
GPIO80
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO87 GPIO86
GPIO85
GPIO84
GPIO Configuration registers
GPIO
Configuration
Register #20
GPIO
Configuration
Register #21
Address: A090_2050
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO83 0x18 GPIO[83] configuration
D23:16 R/W GPIO82 0x18 GPIO[82] configuration
D15:08 R/W GPIO81 0x18 GPIO[81] configuration
D07:00 R/W GPIO80 0x18 GPIO[80] configuration
Address: A090_2054
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO87 0x18 GPIO[87] configuration
D23:16 R/W GPIO86 0x18 GPIO[86] configuration
D15:08 R/W GPIO85 0x18 GPIO[85] configuration
D07:00 R/W GPIO84 0x18 GPIO[84] configuration
66 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
G P IO91 G P IO90
GPIO89
GPIO88
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO95 GPIO94
GPIO93
GPIO92
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #22
GPIO
Configuration
Register #23
Address: A090_2058
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO91 0x18 GPIO[91] configuration
D23:16 R/W GPIO90 0x18 GPIO[90] configuration
D15:08 R/W GPIO89 0x18 GPIO[89] configuration
D07:00 R/W GPIO88 0x18 GPIO[88] configuration
Address: A090_205C
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO95 0x18 GPIO[95] configuration
D23:16 R/W GPIO94 0x18 GPIO[94] configuration
D15:08 R/W GPIO93 0x18 GPIO[93] configuration
D07:00 R/W GPIO92 0x18 GPIO[92] configuration
www.digiembedded.com 67
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
G P IO99 GPIO98
GPIO97
GPIO96
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO103 GPIO102
GPIO101
GPIO100
GPIO Configuration registers
GPIO
Configuration
Register #24
GPIO
Configuration
Register #25
Address: A090_2060
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO99 0x18 GPIO[99] configuration
D23:16 R/W GPIO98 0x18 GPIO[98] configuration
D15:08 R/W GPIO97 0x18 GPIO[97] configuration
D07:00 R/W GPIO96 0x18 GPIO[96] configuration
Address: A090_2064
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO103 0x18 GPIO[103] configuration
D23:16 R/W GPIO102 0x18 GPIO[102] configuration
D15:08 R/W GPIO101 0x18 GPIO[101] configuration
D07:00 R/W GPIO100 0x18 GPIO[100] configuration
68 Hardware Reference NS9215
I/O CONTROL MODULE
1 31 21 11 09876543210 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO_A3 GPIO_A2
GPIO_A1
GPIO_A0
GPIO Configuration registers
. . . . .
GPIO
Configuration
Register #26
Address: A090_2068
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO_A3 0x18 GPIO_A[3] configuration
D23:16 R/W GPIO_A2 0x18 GPIO_A[2] configuration
D15:08 R/W GPIO_A1 0x18 GPIO_A[1] configuration
D07:00 R/W GPIO_A0 0x18 GPIO_A[0] configuration
www.digiembedded.com 69
I/O CONTROL MODULE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GPIO Control re gisters
GPIO Control registers
GPIO Control Registers #0 through #3 contain the control information for each of the
108 GPIO pins. When a GPIO pin is configured as a GPIO output, the corresponding
bit in GPIO Control Registers #0 through #3 is driven out the GPIO pin. In all
configurations, the CPU has read/write access to these registers.
GPIO Control
Register #0
Address: A090_206C
Bit(s) Access Mnemonic Reset Description
D00 R/W GPIO0 0 GPIO[0] control bit
D01 R/W GPIO1 0 GPIO[1] control bit
D02 R/W GPIO2 0 GPIO[2] control bit
D03 R/W GPIO3 0 GPIO[3] control bit
D04 R/W GPIO4 0 GPIO[4] control bit
D05 R/W GPIO5 0 GPIO[5] control bit
D06 R/W GPIO6 0 GPIO[6] control bit
D07 R/W GPIO7 0 GPIO[7] control bit
D08 R/W GPIO8 0 GPIO[8] control bit
D09 R/W GPIO9 0 GPIO[9] control bit
D10 R/W GPIO10 0 GPIO[10] control bit
D11 R/W GPIO11 0 GPIO[11] control bit
D12 R/W GPIO12 0 GPIO[12] control bit
D13 R/W GPIO13 0 GPIO[13] control bit
D14 R/W GPIO14 0 GPIO[14] control bit
D15 R/W GPIO15 0 GPIO[15] control bit
D16 R/W GPIO16 0 GPIO[16] control bit
D17 R/W GPIO17 0 GPIO[17] control bit
D18 R/W GPIO18 0 GPIO[18] control bit
D19 R/W GPIO19 0 GPIO[19] control bit
D20 R/W GPIO20 0 GPIO[20] control bit
D21 R/W GPIO21 0 GPIO[21] control bit
D22 R/W GPIO22 0 GPIO[22] control bit
D23 R/W GPIO23 0 GPIO[23] control bit
D24 R/W GPIO24 0 GPIO[24] control bit
70 Hardware Reference NS9215
I/O CONTROL MODULE
Bit(s) Access Mnemonic Reset Description
D25 R/W GPIO25 0 GPIO[25] control bit
D26 R/W GPIO26 0 GPIO[26] control bit
D27 R/W GPIO27 0 GPIO[27] control bit
D28 R/W GPIO28 0 GPIO[28] control bit
D29 R/W GPIO29 0 GPIO[29] control bit
D30 R/W GPIO30 0 GPIO[30] control bit
D31 R/W GPIO31 0 GPIO[31] control bit
GPIO Control registers
. . . . .
GPIO Control
Register #1
Address: A090_2070
Bit(s) Access Mnemonic Reset Description
D00 R/W GPIO32 0 GPIO[32] control bit
D01 R/W GPIO33 0 GPIO[33] control bit
D02 R/W GPIO34 0 GPIO[34] control bit
D03 R/W GPIO35 0 GPIO[35] control bit
D04 R/W GPIO36 0 GPIO[36] control bit
D05 R/W GPIO37 0 GPIO[37] control bit
D06 R/W GPIO38 0 GPIO[38] control bit
D07 R/W GPIO39 0 GPIO[39] control bit
D08 R/W GPIO40 0 GPIO[40] control bit
D09 R/W GPIO41 0 GPIO[41] control bit
D10 R/W GPIO42 0 GPIO[42] control bit
D11 R/W GPIO43 0 GPIO[43] control bit
D12 R/W GPIO44 0 GPIO[44] control bit
D13 R/W GPIO45 0 GPIO[45] control bit
D14 R/W GPIO46 0 GPIO[46] control bit
D15 R/W GPIO47 0 GPIO[47] control bit
D16 R/W GPIO48 0 GPIO[48] control bit
D17 R/W GPIO49 0 GPIO[49] control bit
D18 R/W GPIO50 0 GPIO[50] control bit
D19 R/W GPIO51 0 GPIO[51] control bit
D20 R/W GPIO52 0 GPIO[52] control bit
D21 R/W GPIO53 0 GPIO[53] control bit
www.digiembedded.com 71
I/O CONTROL MODULE
GPIO Control re gisters
Bit(s) Access Mnemonic Reset Description
D22 R/W GPIO54 0 GPIO[54] control bit
D23 R/W GPIO55 0 GPIO[55] control bit
D24 R/W GPIO56 0 GPIO[56] control bit
D25 R/W GPIO57 0 GPIO[57] control bit
D26 R/W GPIO58 0 GPIO[58] control bit
D27 R/W GPIO59 0 GPIO[59] control bit
D28 R/W GPIO60 0 GPIO[60] control bit
D29 R/W GPIO61 0 GPIO[61] control bit
D30 R/W GPIO62 0 GPIO[62] control bit
D31 R/W GPIO63 0 GPIO[63] control bit
GPIO Control
Register #2
Address: A090_2074
Bit(s) Access Mnemonic Reset Description
D00 R/W GPIO64 0 GPIO[64] control bit
D01 R/W GPIO65 0 GPIO[65] control bit
D02 R/W GPIO66 0 GPIO[66] control bit
D03 R/W GPIO67 0 GPIO[67] control bit
D04 R/W GPIO68 0 GPIO[68] control bit
D05 R/W GPIO69 0 GPIO[69] control bit
D06 R/W GPIO70 0 GPIO[70] control bit
D07 R/W GPIO71 0 GPIO[71] control bit
D08 R/W GPIO72 0 GPIO[72] control bit
D09 R/W GPIO73 0 GPIO[73] control bit
D10 R/W GPIO74 0 GPIO[74] control bit
D11 R/W GPIO75 0 GPIO[75] control bit
D12 R/W GPIO76 0 GPIO[76] control bit
D13 R/W GPIO77 0 GPIO[77] control bit
D14 R/W GPIO78 0 GPIO[78] control bit
D15 R/W GPIO79 0 GPIO[79] control bit
D16 R/W GPIO80 0 GPIO[80] control bit
D17 R/W GPIO81 0 GPIO[81] control bit
D18 R/W GPIO82 0 GPIO[82] control bit
72 Hardware Reference NS9215
I/O CONTROL MODULE
Bit(s) Access Mnemonic Reset Description
D19 R/W GPIO83 0 GPIO[83] control bit
D20 R/W GPIO84 0 GPIO[84] control bit
D21 R/W GPIO85 0 GPIO[85] control bit
D22 R/W GPIO86 0 GPIO[86] control bit
D23 R/W GPIO87 0 GPIO[87] control bit
D24 R/W GPIO88 0 GPIO[88] control bit
D25 R/W GPIO89 0 GPIO[89] control bit
D26 R/W GPIO90 0 GPIO[90] control bit
D27 R/W GPIO91 0 GPIO[91] control bit
D28 R/W GPIO92 0 GPIO[92] control bit
D29 R/W GPIO93 0 GPIO[93] control bit
D30 R/W GPIO94 0 GPIO[94] control bit
GPIO Control registers
. . . . .
GPIO Control
Register #3
D31 R/W GPIO95 0 GPIO[95] control bit
Address: A090_2078
Bit(s) Access Mnemonic Reset Description
D00 R/W GPIO96 0 GPIO[96] control bit
D01 R/W GPIO97 0 GPIO[97] control bit
D02 R/W GPIO98 0 GPIO[98] control bit
D03 R/W GPIO99 0 GPIO[99] control bit
D04 R/W GPIO100 0 GPIO[100] control bit
D05 R/W GPIO101 0 GPIO[101] control bit
D06 R/W GPIO102 0 GPIO[102] control bit
D07 R/W GPIO103 0 GPIO[103] control bit
D08 R/W GPIO_A0 0 GPIO_A[0] control bit
D09 R/W GPIO_A1 0 GPIO_A[1] control bit
D10 R/W GPIO_A2 0 GPIO_A[2] control bit
D11 R/W GPIO_A3 0 GPIO_A[3] control bit
D31:12 N/A Reserved N/A N/A
www.digiembedded.com 73
I/O CONTROL MODULE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GPIO Status registers
GPIO Status registers
GPIO Status Registers #0 through #3 contain the status information for each of the
108 GPIO pins. In all configurations, the value on the GPIO input pin is brought to
the status register and the CPU has read-only access to the register.
GPIO Status
Register #1
Address: A090_2080
Bit(s) Access Mnemonic Reset Description
D00 R GPIO32 Undefined GPIO[32] status bit
D01 R GPIO33 Undefined GPIO[33] status bit
D02 R GPIO34 Undefined GPIO[34] status bit
D03 R GPIO35 Undefined GPIO[35] status bit
D04 R GPIO36 Undefined GPIO[36] status bit
D05 R GPIO37 Undefined GPIO[37] status bit
D06 R GPIO38 Undefined GPIO[38] status bit
D07 R GPIO39 Undefined GPIO[39] status bit
D08 R GPIO40 Undefined GPIO[40] status bit
D09 R GPIO41 Undefined GPIO[41] status bit
D10 R GPIO42 Undefined GPIO[42] status bit
D11 R GPIO43 Undefined GPIO[43] status bit
D12 R GPIO44 Undefined GPIO[44] status bit
D13 R GPIO45 Undefined GPIO[45] status bit
D14 R GPIO46 Undefined GPIO[46] status bit
D15 R GPIO47 Undefined GPIO[47] status bit
D16 R GPIO48 Undefined GPIO[48] status bit
D17 R GPIO49 Undefined GPIO[49] status bit
D18 R GPIO50 Undefined GPIO[50] status bit
D19 R GPIO51 Undefined GPIO[51] status bit
D20 R GPIO52 Undefined GPIO[52] status bit
D21 R GPIO53 Undefined GPIO[3] status bit
D22 R GPIO54 Undefined GPIO[54] status bit
D23 R GPIO55 Undefined GPIO[55] status bit
D24 R GPIO56 Undefined GPIO[56] status bit
D25 R GPIO57 Undefined GPIO[57] status bit
74 Hardware Reference NS9215
I/O CONTROL MODULE
GPIO Status registers
Bit(s) Access Mnemonic Reset Description
D26 R GPIO58 Undefined GPIO[58] status bit
D27 R GPIO59 Undefined GPIO[59] status bit
D28 R GPIO60 Undefined GPIO[60] status bit
D29 R GPIO61 Undefined GPIO[61] status bit
D30 R GPIO62 Undefined GPIO[62] status bit
D31 R GPIO63 Undefined GPIO[63] status bit
. . . . .
GPIO Status
Register #2
Address: A090_2084
Bit(s) Access Mnemonic Reset Description
D00 R GPIO64 Undefined GPIO[64] status bit
D01 R GPIO65 Undefined GPIO[65] status bit
D02 R GPIO66 Undefined GPIO[66] status bit
D03 R GPIO67 Undefined GPIO[67] status bit
D04 R GPIO68 Undefined GPIO[68] status bit
D05 R GPIO69 Undefined GPIO[69] status bit
D06 R GPIO70 Undefined GPIO[70] status bit
D07 R GPIO71 Undefined GPIO[71] status bit
D08 R GPIO72 Undefined GPIO[72] status bit
D09 R GPIO73 Undefined GPIO[73] status bit
D10 R GPIO74 Undefined GPIO[74] status bit
D11 R GPIO75 Undefined GPIO[75] status bit
D12 R GPIO76 Undefined GPIO[76] status bit
D13 R GPIO77 Undefined GPIO[77] status bit
D14 R GPIO78 Undefined GPIO[78] status bit
D15 R GPIO79 Undefined GPIO[79] status bit
D16 R GPIO80 Undefined GPIO[80] status bit
D17 R GPIO81 Undefined GPIO[81] status bit
D18 R GPIO82 Undefined GPIO[82] status bit
D19 R GPIO83 Undefined GPIO[83] status bit
D20 R GPIO84 Undefined GPIO[84] status bit
D21 R GPIO85 Undefined GPIO[85] status bit
D22 R GPIO86 Undefined GPIO[86] status bit
www.digiembedded.com 75
I/O CONTROL MODULE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Memory Bus Configuration register
Bit(s) Access Mnemonic Reset Description
D23 R GPIO87 Undefined GPIO[87] status bit
D24 R GPIO88 Undefined GPIO[88] status bit
D25 R GPIO89 Undefined GPIO[89] status bit
D26 R GPIO90 Undefined GPIO[90] status bit
D27 R GPIO91 Undefined GPIO[91] status bit
D28 R GPIO92 Undefined GPIO[92] status bit
D29 R GPIO93 Undefined GPIO[93] status bit
D30 R GPIO94 Undefined GPIO[94] status bit
D31 R GPIO95 Undefined GPIO[95] status bit
GPIO Status
Register #3
Address: A090_2088
Bit(s) Access Mnemonic Reset Description
D00 R GPIO96 Undefined GPIO[96] status bit
D01 R GPIO97 Undefined GPIO[97] status bit
D02 R GPIO98 Undefined GPIO[98] status bit
D03 R GPIO99 Undefined GPIO[99] status bit
D04 R GPIO100 Undefined GPIO[100] status bit
D05 R GPIO101 Undefined GPIO[101] status bit
D06 R GPIO102 Undefined GPIO[102] status bit
D07 R GPIO103 Undefined GPIO[103] status bit
D08 R GPIO_A0 Undefined GPIO_A[0] status bit
D09 R GPIO_A1 Undefined GPIO_A[1] status bit
D10 R GPIO_A2 Undefined GPIO_A[2] status bit
D11 R GPIO_A3 Undefined GPIO_A[3] status bit
D31:12 N/A Reserved N/A N/A
Memory Bus Configuration register
The Memory Bus Configuration register controls chip select and upper address
options.
Address: A090_208C
76 Hardware Reference NS9215
I/O CONTROL MODULE
Memory Bus Configuration register
Bit(s) Access Mnemonic Reset Description
D02:00 R/W CS0 0x4 Controls which system memory chip select is
routed to CS0
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3
100 st_cs_0 (default)
101 st_cs_1
110 st_cs_2
111 st_cs_3
D05:03 R/W CS1 0x0 Controls which system memory chip select is
routed to CS1
000 dy_cs_0 (default)
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3
100 st_cs_0
101 st_cs_1
110 st_cs_2
111 st_cs_3
. . . . .
D08:06 R/W CS2 0x5 Controls which system memory chip select is
routed to CS2
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3
100 st_cs_0
101 st_cs_1 (default)
110 st_cs_2
111 st_cs_3
D11:09 R/W CS3 0x1 Controls which system memory chip select is
routed to CS3
000 dy_cs_0
001 dy_cs_1 (default)
010 dy_cs_2
011 dy_cs_3
100 st_cs_0
101 st_cs_1
110 st_cs_2
111 st_cs_3
www.digiembedded.com 77
I/O CONTROL MODULE
Memory Bus Configuration register
Bit(s) Access Mnemonic Reset Description
D14:12 R/W CS4 0x6 Controls which system memory chip select is
routed to CS4
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3
100 st_cs_0
101 st_cs_1
110 st_cs_2 (default)
111 st_cs_3
D17:15 R/W CS5 0x2 Controls which system memory chip select is
routed to CS5
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2 (default)
011 dy_cs_3
100 st_cs_0
101 st_cs_1
110 st_cs_2
111 st_cs_3
D20:18 R/W CS6 0x7 Controls which system memory chip select is
routed to CS6
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3
100 st_cs_0
101 st_cs_1
110 st_cs_2
111 st_cs_3 (default)
D23:21 R/W CS7 0x3 Controls which system memory chip select is
routed to CS7
000 dy_cs_0
001 dy_cs_1
010 dy_cs_2
011 dy_cs_3 (default)
100 st_cs_0
101 st_cs_1
110 st_cs_2
111 st_cs_3
D24 R/W DHPUDIS 0x0 High data bus pullup control
0 Enable pullup resistors on data[31:16]
1 Disable pullup resistors on data[31:16]
Note: Bits 15:00 are output and controlled
through GPIO
78 Hardware Reference NS9215
I/O CONTROL MODULE
Memory Bus Configuration register
Bit(s) Access Mnemonic Reset Description
D25 R/W APUDIS 0x0 Address bus pullup control
(Applicable only to address associated with
hardware strapping)
0 Enable pullup resistors
1 Disable pullup resistors
Note: Bits 27:24 are output and controlled
through GPIO
D31:26 N/A Reserved N/A N/A
. . . . .
www.digiembedded.com 79
I/O CONTROL MODULE
Memory Bus Configuration register
80 Hardware Reference NS9215
Working with the CPU
CHAPTER 3
This processor core is based on the ARM926EJ-S processor. The ARM926EJ-S
processor belongs to the ARM9 family of general-purpose microprocessors. The
ARM926EJ-S processor is targeted at multi-tasking applications in which full memory
management, high performance, low die size, and low power are important.
About the
processor
The ARM926EJ-S processor supports the 32-bit ARM and 16-bit Thumb instructions
sets, allowing you to trade off between high performance and high code density.
The processor includes features for efficient execution of Java byte codes,
providing Java performance similar to JIT but without the associated overhead.
The ARM926EJ-S supports the ARM debug architecture, and includes logic to assist in
both hardware and software debug. The processor has a Harvard-cached
architecture and provides a complete high-performance processor subsystem,
including:
ARM926EJ-S integer core
Memory Management Unit (MMU) (see "MemoryManagement Unit (MMU),"
beginning on page 105, for information)
Separate instruction and data AMBA AHB bus interfaces
81
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DEXT
Write buffer
DCACHE
Cache
PA
TAGRAM
writeback
write
buffer
MMU
TLB
ARM926EJ-S
IROUTE
DROUTE
FCSE
WDATA RDATA
INSTR
ICACHE
IEXT
Bus
interface
unit
Data
AHB
interface
Instruction
AHB
interface
AHB
AHB
DA
IA
DMVA
IMVA
Instruction sets
Arm926EJ-S
process block
diagram
This drawing shows the main blocks in the ARM926EJ-S processor.
Instruction sets
The processor executes three instruction sets:
32-bit ARM instruction set
16-bit Thumb instruction set
8-bit Java instruction set
ARM instruction
set
Thumb
instruction set
82 Hardware Reference NS9215
The ARM instruction set allows a program to achieve maximum performance with
the minimum number of instructions. The majority of instructions are executed in a
single cycle.
The Thumb instruction set is simpler than the ARM instruction set, and offers
increased code density for code that does not require maximum performance. Code
can switch between ARM and Thumb instruction sets on any procedure call.
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System control processor (CP15) registers
. . . . .
Java instruction
set
In Java state, the processor core executes a majority of Java bytecodes naturally.
Bytecodes are decoded in two states, compared to a single decode stage when in
ARM/Thumb mode. See “Jazelle(Java)” on page 104 for more information about
Java.
System control processor (CP15) registers
The system control processor (CP15) registers configure and control most of the
options in the ARM926EJ-S processor. Access the CP15 registers using only the MRC
and MCR instructions in a privileged mode; the instructions are provided in the
explanation of each applicable register. Using other instructions, or MRC and MCR in
unprivileged mode, results in an UNDEFINED instruction exception.
ARM926EJ-S
system addresses
The ARM926EJ-S has three distinct types of addresses:
In the ARM926EJ-S domain: Virtual address (VA)
In the Cache and MMU domain: Modified virtual address (MVA)
In the AMBA domain: Physical address (PA)
Address
manipulation
example
Accessing CP15
registers
This is an example of the address manipulation that occurs when the ARM926EJ-S
core requests an instruction:
1 The ARM926EJ-S core issues the virtual address of the instruction.
2 The virtual address is translated using the FCSE PID (fast context switch
extension process ID) value to the modified virtual address. The instruction
cache (ICache) and memory management unit (MMU) find the modified virtual
address (see “R13:Process ID register” on page 102).
3 If the protection check carried out by the MMU on the modified virtual address
does not abort and the modified virtual address tag is in the ICache, the
instruction data is returned to the ARM926EJ-S core.
If the protection check carried out by the MMU on the modified virtual
address does not abort but the cache misses (the MVA tag is not in the
cache), the MMU translates the modified virtual address to produce the
physical address. This address is given to the AMBA bus interface to perform
an external access.
Use only
registers. Figure 1 shows the MRC and MCR instruction bit pattern.
MRC and MCR instructions, only i n privileged mode, to access CP15
www.digiembedded.com 83
WORKING WITH THE CPU
Cond
1110 1111 1 L
Opcode
_1
Opcode
_2
CRn CRm Rd
31 28 27 26 25 24 23 21 20 19 16 15 12 11 10 9 8 7 5 4 3 0
System control processor (CP15) registers
Figure 1: CP15 MRC and MCR bit pattern
The mnemonics for these instructions are:
MCR{cond} p15,opcode_1,Rd,CRn,CRm,opcode_2
MRC{cond} p15,opcode_1,Rd,CRn,CRm,opcode_2
If you try to read from a write-only register or write to a read-only register, you will
UNPREDICTABLE results. In all instructions that access CP15:
have
The opcode_1 field SHOULD BE ZERO , except when the values specified are used
to select the operations you want. Using other values results in unpredictable
behavior.
The opcode_2 and CRm fields SHOULD BE ZERO , except when the values specified
are used to select the behavior you want. Using other values results in
unpredictable behavior.
Te rm s an d
abbreviations
This table lists the terms and abbreviations used in the CP15 registers and
explanations.
Term Abbreviation Description
UNPREDICTABLE UNP For reads:
The data returned when reading from this location is
unpredictable, and can have any value.
For writes:
Writing to this location causes unpredictable
behavior, or an unpredictable change in device
configuration.
UNDEFINED UND An instruction that accesses CP15 in the manner
indicated takes the
exception.
SHOULD BE ZERO SBZ When writing to this field, all bits of the field
SHOULD BE ZERO.
SHOULD BE ONE SBO When writing to this location, all bits in this field
SHOULD BE ONE.
SHOULD BE ZERO or
PRESERVED
SBZP When writing to this location, all bits of this field
SHOULD BE ZERO or PRESERVED by writing the
same value that has been read previously from the
same field.
UNDEFINED instruction
84 Hardware Reference NS9215
WORKING WITH THE CPU
System control processor (CP15) registers
. . . . .
Note:
In all cases, reading from or writing any data values to any CP15 registers,
including those fields specified as
BE ZERO,
does not cause any physical damage to the chip.
Register summary CP15 uses 16 registers.
Register locatio ns 0, 5, and 13 each provide access to more than one register.
The register accessed depends on the value of the
MRC/MCR instructions (see “Accessing CP15 registers” on page 83).
Register location 9 provides access to more than one register. The register
accessed depends on the value of the
on page 83).
Register Reads Writes
0 ID code (based on
0 Cache type (based on opcode_2 value) Unpredictable
1 Control Control
2 Translation table base Translation table base
3 Domain access control Domain access control
UNPREDICTABLE, SHOULD BE ONE, or SHOULD
opcode_2 field in the CP15
CRm field (see “Accessing CP15 registers”
opcode_2 value) Unpredictable
4 Reserved Reserved
5 Data fault status (based on opcode_2 value) Data fault status (based on opcode_2 value)
6 Instruction fault status (based on opcode_2
value)
7 Cache operations Cache operations
8 Unpredictable TLB
9 Cache lockdown (based on
10 TLB lockdown TLB lockdown
11 and 12 Reserved Reserved
13 FCSE PID (based on
FCSE = Fast context switch extension
PID = Process identifier
13 Context ID (based on
14 Reserved Reserved
15 Test configuration Test configuration
CRm value) Cache lockdown
opcode_2 value)
opcode_2 value) Context ID (based on opcode_2 value)
Instruction fault status (based on opcode_2
value)
FCSE PID (based on opcode_2 value)
FCSE = Fast context switch extension
PID = Process identifier
All CP15 register bits that are defined and contain state are set to 0 by reset, with
these exceptions:
The V bit is set to 0 at reset if the VINITHI signal is low, and set to 1 if the
VINITHI signal is high.
www.digiembedded.com 85
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R0: ID code and cache type status registers
The B bit is set to 0 at reset if the BIGENDINIT signal is low, and set to 1 if the
BIGENDINIT signal is high.
R0: ID code and cache type status registers
Register R0 access the ID register, and cache type register. Reading from R0 returns
the device ID, and the cache type, depending on the
opcode_2=0 ID value
opcode_2=1 instruction and data cache type
The
CRm field SHOULD BE ZERO when reading from these registers. This table shows
the instructions you can use to read register R0.
Function Instruction
opcode_2 value:
Read ID code
Read cache type
Writing to register R0 is
MRC p15,0,Rd,c0,c0,{0, 3-7}
MRC p15,0,Rd,c0,c0,1
UNPREDICTABLE.
R0: ID code R0: ID code is a read-only register that returns the 32-bit device ID code. You can
access the ID code register by reading CP15 register R0 with the opcode_2 field set to
any value other than 1 or 2. Note this example:
MRC p15, 0, Rd, c0, c0, {0, 3-7}; returns ID
This is the contents of the ID code register.
Bits Function Value
[31:24] ASCII code of implementer trademark 0x41
[23:20] Specification revision 0x0
[19:16] Architecture (ARMv5TEJ) 0x6
[15:4] Part number 0x926
[3:0] Layout revision 0x0
R0: Cache type
regist e r
R0: Cache type is a read-only register that contains information about the size and
architecture of the instruction cache (ICache) and data cache (DCache) enabling
operating systems to establish how to perform operations such as cache cleaning
and lockdown. See “Cache features” on page 127 for more information about
cache.
86 Hardware Reference NS9215
Cache type
Ctype
0S
Dsize
31 28 25 24 23 12
00
Isize
11 10 9 6 5 3 2 1 0
00 Siz e M Assoc Len
register and field
description
WORKING WITH THE CPU
R0: ID code and cache type status registers
. . . . .
You can access the cache type register by reading CP15 register R0 with the opcode_2
field set to 1. Note this example:
MRC p15, 0, Rd, c0, c0, 1; returns cache details
Field Description
Ctype Determines the cache type, and specifies whether the cache supports lockdown and how it is
cleaned. Ctype encoding is shown below; all unused values are reserved.
Value: 0b1110
Method: Writeback
Cache cleaning: Register 7 operations (see “R7:Cache Operations register” on page 94)
Cache lockdown: Format C (see “R9: Cache Lockdown register” on page 98)
Dsize and Isize
fields
S bit Specifies whether the cache is a unified cache (S=0) or separate ICache and DCache (S=1).
Will always report separate ICache and DCache for this processor.
Dsize Specifies the size, line length, and associativity of the DCache.
Isize Species the size, length and associativity of the ICache.
The Dsize and Isize fields in the cache type register have the same format, as
shown:
The field contains these bits:
www.digiembedded.com 87
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R1: Control register
Field Description
Size Determines the cache size in conjunction with the M bit.
The M bit is 0 for DCache and ICache.
The size field is bits [21:18] for the DCache and bits [9:6] for the ICache.
The minimum size of each cache is 4 KB; the maximum size is 128 KB.
Cache size encoding with M=0:
Size field Cache size
0b0011 4 KB
0b0100 8 KB
Note: The processor always reports 4KB for DCache and 8KB for ICache.
Assoc Determines the cache associativity in conjunction with the M bit.
The M bit is 0 for both DCache and ICache.
The assoc field is bits [17:15 for the DCache and bits [5:3] for the ICache.
Cache associativity with encoding:
Assoc field Associativity
0b010 4-way
Other values Reserved
M bit Multiplier bit. Determines the cache size and cache associativity values in conjunction with
Len Determines the line length of the cache.
R1: Control register
Register R1 is the control register for the ARM926EJ-S processor. This register
specifies the configuration used to enable and disable the caches and MMU (memory
management unit). It is recommended that you access this register using a readmodify-write sequence.
For both reading and writing, the CRm and opcode_2 fields SHOULD BE ZERO . Use these
instructions to read and write this register:
MRC p15, 0, Rd, c1, c0, 0; read control register
MCR p15, Rd, c1, c0, 0; write control register
All defined control bits are set to zero on reset except the V bit and B bit.
the size and assoc fields.
Note: This field must be set to 0 for the ARM926EJ-S processor.
The len field is bits [13:12] for the DCache and bits [1:0] for the ICache.
Line length encoding:
Len field Cache line length
10 8 words (32 bytes)
Other values Reserved
The V bit is set to zero at reset if the VINITHI signal is low.
The B bit is set to zero at reset if the BIGENDINIT signal is low, and set to one if
BIGENDINIT signal is high.
the
88 Hardware Reference NS9215
Control register
1 31 19 16 15 12 11 10 9 8 7 3 0 2 18 17 14 13 6
S
B
Z
SBZ
S
B
O
S
B
O
L4R
R
VI
SBZ
RSB
SBO
CAM
Bit functionality
WORKING WITH THE CPU
R1: Control register
. . . . .
Bits Name Function
[31:19] N/A Reserved:
When read, returns an UNPREDICTABLE value.
When written, SHOULD BE ZERO , or a value read from bits
[31:19] on the same processor.
Use a read-modify-write sequence when modifying this
register to provide the greatest future compatibility.
[18] N/A Reserved, SBO. Read = 1, write =1.
[17] N/A Reserved, SBZ. read = 0, write = 0.
[16] N/A Reserved, SBO. Read = 1, write = 1.
[15] L4 Determines whether the T is set when load instructions change
the PC.
0 Loads to PC set the T bit
1 Loads to PC do not set the T bit
[14] RR bit Replacement strategy for ICache and DCache
0 Random replacement
1 Round-robin replacement
[13] V bit Location of exception vectors
0 Normal exception vectors selected; address range=
to 0x0000 001C
0000
0x0000
1 High exception vectors selected; address range=0xFFFF
to 0xFFFF 001C
0000
Set to the value of VINITHI on reset.
[12] I bit ICache enable/disable
0 ICache disabled
1 ICache enabled
[11:10] N/A
SHOULD BE ZERO
[9] R bit ROM protection
Modifies the ROM protection system.
[8] S bit System protection
Modifies the MMU protection system. See
"MemoryManagement Unit (MMU)," beginning on page 105.
[7] B bit Endianness
0 Little endian operation
1 Big endian operation
Set to the value of
www.digiembedded.com 89
BIGENDINIT on reset.
WORKING WITH THE CPU
R1: Control register
Bits Name Function
[6:3] N/A Reserved. SHOULD BE ONE.
[2] C bit DCache enable/disable
0 Cache disabled
1 Cache enabled
[1] A bit Alignment fault enable/disable
0 Data address alignment fault checking disabled
1 Data address alignment fault checking enabled
[0] M bit MMU enable/disable
0D i s a b l e d
1 Enabled
ICache and
DCache behavior
The M, C, I, and RR bits directly affect ICache and DCache behavior, as shown:
Cache MMU Behavior
ICache disabled Enabled or disabled All instruction fetches are from external memory (AHB).
ICache enabled Disabled All instruction fetches are cachable, with no protection
checking. All addresses are flat-mapped; that is:
VA=MVA=PA.
ICache enabled Enabled Instruction fetches are cachable or noncachable, and
protection checks are performed. All addresses are
remapped from VA to PA, depending on the MMU page
table entry; that is, VA translated to MVA, MVA
remapped to PA.
DCache disabled Enabled or disabled All data accesses are to external memory (AHB).
DCache enabled Disabled All data accesses are noncachable nonbufferable. All
addresses are flat-mapped; that is, VA=MVA=PA.
DCache enabled Enabled All data accesses are cachable or noncachable, and
protection checks are performed. All addresses are
remapped from VA to PA, depending on the MMU page
table entry; that is, VA translated to MVA, MVA
remapped to PA.
If either the DCache or ICache is disabled, the contents of that cache are not
accessed. If the cache subsequently is re-enabled, the contents will not have
changed. To guarantee that memory coherency is maintained, the DCache must be
cleaned of dirty data before it is disabled.
90 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R2: Translation Table Base register
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31 0 14 13
Translation table base
UNP/SBZ
31 0 14 13 12 11 10 9 8 7 6 5 4 3 2 1 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15
Register R2 is the Translation Table Base register (TTBR), for the base address of the
first-level translation table.
Reading from R2 returns the pointer to the currently active first-level
translation table in bits [31:14] and an
Writing to R2 updates the pointer to the first-level translation table from the
value in bits[31:14] of the written value. Bits [13:0]
Use these instructions to access the Translation Table Base register:
MRC p15, 0, Rd, c2, c0, 0; read TTBR
MCR p15, 0, Rd, c2, c0, 0; write TTBR
The CRm and opcode_2 fields SHOULD BE ZERO when writing to R2.
Register format
WORKING WITH THE CPU
R2: Translation Table Base register
. . . . .
UNPREDICTABLE value in bits [13:0].
SHOULD BE ZERO.
R3:Domain Access Control register
Register R3 is the Domain Access Control register and consists of 16 two-bit fields.
Reading from R3 returns the value of the Domain Access Control register.
Writing to R3 writes the value of the Domain Access Control register.
Register format
Access
permissions and
instructions
Each two-bit field defines the access permissions for one of the 16 domains
(D15–D0):
00 No access: Any access generates a domain fault
01 Client: Accesses are checked against the access permission bits in the section or page descriptor
10 Reserved: Currently behaves like no access mode (00)
11 Manager: Accesses are not checked against the access permission bits, so a permission fault
cannot be generated.
Use these instructions to access the Domain Access Control register:
MRC p15, 0, Rd, c3, c0, 0; read domain access permissions
MCR p15, 0, Rd, c3, c0, 0; write domain access permissions
www.digiembedded.com 91
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31 0 987 43
0
UNP/SBZ Domain Status
R4 register
R4 register
Accessing (reading or writing) this register causes UNPREDICTABLE behavior.
R5: Fault Status registers
Register R5 accesses the Fault Status registers (FSRs). The Fault Status registers
contain the source of the last instruction or data fault. The instruction-side FSR is
intended for debug purposes only.
The FSR is updated for alignment faults and for external aborts that occur while the
MMU is disabled. The FSR accessed is determined by the opcode_2 value:
opcode_2=0 Data Fault Status register (DFSR)
opcode_2=1 Instruction Fault Status register (IFSR)
Access
instructions
Register format
Register bits
See "MemoryManagement Unit (MMU)," beginning on page 105, for the fault type
encoding.
Access the FSRs using these instructions:
MRC p15, 0, Rd, c5, c0, 0; read DFSR
MCR p15, 0, Rd, c5, c0, 0; write DFSR
MRC p15, 0, Rd, c5, c0, 1; read IFSR
MCR p15, 0, Rd, c5, c0, 1; write IFSR
Bits Description
[31:9]
[8] Always reads as zero. Writes are ignored.
[7:4] Specifies which of the 16 domains (D15–D0) was being accessed when a data fault
UNPREDICTABLE/SHOULD BE ZERO
occurred.
[3:0] Type of fault generated. (See "MemoryManagement Unit (MMU)," beginning on page
105.)
92 Hardware Reference NS9215
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R6: Fault Address register
. . . . .
Status and
domain fields
This table shows the encodings u sed for the status field in the Fault Status register,
and indicates whether the domain field contains valid information. Se e “MMU faults
and CPU aborts” on page 119 for information about MMU aborts in Fault Address and
Fault Status registers.
Priority Source Size Status Domain
Highest Alignment N/A
External abort on translation First level
Second level
Translation Section page
Domain Section page
Permission Section page
Lowest External abort Section page
0b00x1
0b1100
0b1110
0b0101
0b0111
0b1001
0b1011
0b1101
0b1111
0b1000
0b1010
Invalid
Invalid
Valid
Invalid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
R6: Fault Address register
Register R6 accesses the Fault Address register (FAR). The Fault Address register
contains the modified virtual address of the access attempted when a data abort
occurred. This register is updated only for data aborts, not for prefetch aborts; it is
updated also for alignment faults and external aborts that occur while the MMU is
disabled.
Writing R6 sets the Fault Address register to the value of the data written. This is
useful for debugging, to restore the value of a Fault Address register to a previous
state.
CRm and opcode_2 fields SHOULD BE ZERO when reading or writing R6.
The
Access
instructions
Use these instructions to access the Fault Address register:
MRC p15, 0, Rd, c6, c0, 0; read FAR
MCR p15, 0, Rd, c6, c0, 0; write FAR
www.digiembedded.com 93
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R7:Cache Operations register
R7:Cache Operations register
Register R7 controls the caches and write buffer. The function of each cache
operation is selected by the
writes to CP15 R7. Writing other
Reading from R7 is UNPREDICTABLE, with the exception of the two test and clean
operations (see “Cache operation functions” on page 95 and “Test and clean
DCache instructions” on page 96).
Write instruction Use this instruction to write to the Cache Operations register:
MCR p15, opcode_1, Rd, CRn, CRm, opcode_2
Cache functions This table describes the cache functions provided by register R7.
Function Description
Invalidate cache Invalidates all cache data, including any dirty data.
opcode_2 and CRm fields in the MCR instruction that
opcode_2 or CRm values is UNPREDICTABLE.
Invalidate single entry using either index or
modified virtual address
Clean single data entry using either index or
modified virtual address
Clean and invalidate single data entry using
wither index or modified virtual address.
Test and clean DCache Tests a number of cache lines, and cleans one of them if
Test, clean, and invalidate DCache Tests a number of cache lines, and cleans one of them if
Prefetch ICache line Performs an ICache lookup of the specified modified
Invalidates a single cache line, discarding any dirty data.
Writes the specified DCache line to main memory if the
line is marked valid and dirty. The line is marked as not
dirty, and the valid bit is unchanged.
Writes the specified DCache line to main memory if the
line is marked valid and dirty. The line is marked not valid.
any are dirty. Returns the overall dirty state of the cache in
bit 30. (See “Test and clean DCache instructions” on
page 96).
any are dirty. When the entire cache has been tested and
cleaned, it is invalidated. (See “Test and clean DCache
instructions” on page 96).
virtual address. If the cache misses and the region is
cachable, a linefill is performed.
94 Hardware Reference NS9215
WORKING WITH THE CPU
R7:Cache Operations register
Function Description
Drain write buffer Acts as an explicit memory barrier. This instruction drains
the contents of the write buffers of all memory stores
occurring in program order before the instruction is
completed. No instructions occurring in program order
after this instruction are executed until the instruction
completes.
Use this instruction when timing of specific stores to the
level two memory system has to be controlled (for
example, when a store to an interrupt acknowledge
location has to complete before interrupts are enabled).
Wait for interrupt Drains the contents of the write buffers, puts the processor
into low-power state, and stops the processor from
executing further instructions until an interrupt (or debug
request) occurs. When an interrupt does occur, the
MCR
instruction completes, and the IRQ or FIRQ handler is
entered as normal.
The return link in
of the
MCR instruction plus eight, so the typical instruction
used for interrupt return
instruction following the
R14_irq or R14_fiq contains the address
(SUBS PC,R14,#4) returns to the
MCR.
. . . . .
Cache operation
functions
This table lists the cache operation functions and associated data and instruction
formats for R7.
Function/operation Data format Instruction
Invalidate ICache and DCache SBZ
Invalidate ICache SBZ
Invalidate ICache single entry (MVA) MVA
Invalidate ICache single entry (set/way) Set/Way
Prefetch ICache line (MVA) MVA
Invalidate DCache SBZ
Invalidate DCache single entry (MVA) MVA
Invalidate DCache single entry (set/way) Set/Way
Clean DCache single entry (MVA) MVA
Clean DCache single entry (set/way) Set/Way
Test and clean DCache N/A
Clean and invalidate DCache entry (MVA) MVA
Clean and invalidate DCache entry (set/way) Set/Way
MCR p15, 0, Rd, c7, c7, 0
MCR p15, 0, Rd, c7, c5, 0
MCR p15, 0, Rd, c7, c5, 1
MCR p15, 0, Rd, c7, c5, 2
MCR p15, 0, Rd, c7, c13, 1
MCR p15, 0, Rd, c7, c6, 0
MCR p15, 0, Rd, c7, c6, 1
MCR p15, 0, Rd, c7, c6, 2
MCR p15, 0, Rd, c7, c10, 1
MCR p15, 0, Rd, c7, C10, 2
MRC p15, 0, Rd, c7, c10, 3
MCR p15, 0, Rd, c7, c14, 1
MCR p15, 0, Rd, c7, c14, 2
Test, clean, and invalidate DCache N/A
www.digiembedded.com 95
MRC p15, 0, Rd, c7, c14, 3
WORKING WITH THE CPU
31 0 S+4 4
SBZ Set(=index) Word
Tag
21 5 S+5
31 0 S+4 4
SBZ Set(=index) Word
SBZ
21 5 S+5
Way
32-A 31-A
R7:Cache Operations register
Function/operation Data format Instruction
Drain write buffer SBZ
Wait for interrupt SBZ
Modified virtual
This is the modified virtual address format for
address format
(MVA)
The tag, set, and word fields define the MVA.
For all cache operations, the word field SHOULD BE ZERO .
Set/Way format This is the Set/Way format for
A and S are the base-two logarithms of the associativity and the number of
sets.
MCR p15, 0, Rd, c7, c10, 4
MCR p15, 0, Rd, c7, c0, 4
Rd for the CP15 R7 MCR operations.
Rd for the CP15 R7 MCR operations.
The set, way, and word files define the format.
For all of the cache operations, word SHOULD BE ZERO .
Set/Way example For example, a 16 KB cache, 4-way set associative, 8-word line results in the
following:
A = log
S = log
associativity = log24 = 2
2
NSETS where
2
NSETS = cache size in bytes/associativity/line length in bytes:
NSETS = 16384/4/32 = 128
Te st and cl ean
DCache
instructions
Result: S = log
The test and clean DCache instruction provides an efficient way to clean the entire
DCache, using a simple loop. The test and clean DCache instruction tests a number
of lines in the DCache to determine whether any of them are dirty. If any dirty lines
128 = 7
2
are found, one of those lines is cleaned. The test and clean DCache instructi on also
returns the status of the entire DCache in bit 30.
96 Hardware Reference NS9215
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R8:TLB Operations register
. . . . .
Note:
The test and clean DCache instruction MRC p15, 0, r15, c7, c10, 3 is a special
encoding that uses
using this instruction, however. This
code flags.
If the cache contains any dirty lines, bit 30 is set to 0. If the cache contains no dirty
lines, bit 30 is set to 1. Use the following loop to clean the entire cache:
tc_loop: MRC p15, 0, r15, c7, c10, 3; test and clean
Test, clean, and
invalidate DCache
instruction
The test, clean, and invalidate DCache instruction is the same as the test and clean
DCache instruction except that when the entire cache has been cleaned, it is
invalidated. Use the following loop to test, clean, and invalidate the entire DCache:
tci_loop: MRC p15, 0, r15, c7, c14, 3; test clean and invalidate
R8:TLB Operations register
Register R8 is a write-only register that controls the translation lookaside buffer
(TLB). There is a single TLB used to hold entries for both data and instructions. The
TLB is divided into two parts:
r15 as a destination operand. The PC is not changed by
MRC instruction also sets the condition
BNE tc_loop
BNE tci_loop
Set-associative
Fully-associative
The fully-associative part (also referred to as the lockdown part of the TLB) stores
entries to be locked down. Entries held in the lockdown part of the register are
preserved during an invalidate-TLB operation. Entries can be removed from the
lockdown TLB using an invalidate TLB single entry operation.
TLB operations There are six TLB operations; the function to be performed is selected by the
opcode_2 and CRm fields in the MCR instruction used to write register R8. Writing
opcode_2 or CRm values is UNPREDICTABLE. Reading from this register is
other
UNPREDICTABLE.
TLB operation
Use these instruction to perform TLB operations.
instructions
Operation Data Instruction
Invalidate set-associative TLB SBZ
Invalidate single entry SBZ
Invalidate set-associative TLB SBZ
MCR p15, 0, Rd, c8, c7, 0
MCR p15, 0, Rd, c8, c7. 1
MCR p15, 0, Rd, c8, c5, 0
Invalidate single entry MVA
www.digiembedded.com 97
MCR p15, 0, Rd, c8, c5, 1
WORKING WITH THE CPU
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31 0 9
SBZ
Modified virtual address
10
R9: Cache Lockdown register
Operation Data Instruction
Modified virtual
address format
(MVA)
Invalidate set-associative TLB SBZ
Invalidate single entry MVA
The invalidate TLB operations invalidate all the unpreserved entries in the
MCR p15, 0, Rd, c8, c6, 0
MCR p15, 0, Rd, c8, c6, 1
TLB.
The invalidate TLB single entry operations invalidate any TLB entry
corresponding to the modified virtual address given in
Rd, regardless of its
preserved state. See "R10:TLB Lockdown register," beginning on page 101, for
an explanation of how to preserve TLB entries.
This is the modified virtual address format used for invalid TLB single entry
operations.
Note:
If either small or large pages are used, and these pages contain subpage
access permissions that are different, you must use four invalidate TLB single
entry operations, with the MVA set to each subpage, to invalidate all
information related to that page held in a TLB.
R9: Cache Lockdown register
Register R9 access the cache lockdown registers. Access this register using CRm = 0 .
Cache ways The Cache Lockdown register uses a cache-way-based locking scheme (format C)
that allows you to control each cache way independently.
These registers allow you to control which cache-ways of the four-way cache are
used for the allocation on a linefill. When the registers are defined, subsequent
linefills are placed only in the specified target cache way. This gives you some
control over the cache pollution cause by particular applications, and provides a
traditional lockdown operation for locking critical code into the cache.
A locking bit for each cache way determines whether the normal cache allocation is
allowed to access that cache way (see “Cache Lockdown register L bits” on
page 99). A maximum of three cache ways of the four-way associative cache can be
locked, ensuring that normal cache line replacement is performed.
Note:
98 Hardware Reference NS9215
If no cache ways have the L bit set to 0, cache way 3 is used for all linefills.
WORKING WITH THE CPU
31 0 3
SBZ/UNP
15 4 16
SB0
L bits
(cache ways
0 to 3)
R9: Cache Lockdown register
. . . . .
Instruction or
data lockdown
regi s t e r
Access
instructions
Modifying the
Cache Lockdown
regi s t e r
The first four bits of this register determine the L bit for the associated cache way.
The opcode_2 field of the MRC or MCR instruction determines whether the
instruction or data lockdown register is accessed:
opcode_2=0 Selects the DCache Lockdown register, or the Unified
Cache Lockdown register if a unified cache is
implemented. The ARM926EJ-S processor has separate
DCache and ICache.
opcode_2=1 Selects the ICache Lockdown register.
Use these instructions to access the CacheLockdown register.
Function Data Instruction
Read DCache Lockdown register L bits
Write DCache Lockdown register L bits
Read ICache Lockdown register L bits
Write ICache Lockdown register L bits
MRC p15, 0, Rd, c9, c0, 0
MCR p15, 0, Rd, c9, c0, 0
MRC p15, 0, Rd, c9, c0, 1
MCR p15, 0, Rd, c9, c0, 1
You must modify the Cache Lockdown register using a modify-read-write sequence;
for example:
MRC p15, 0, Rn, c9, c0, 1;
ORR Rn, Rn, 0x01;
MCR p15, 0, Rn, c9, c0, 1;
This sequence sets the L bit to 1 for way 0 of the ICache.
Register format This is the format for the Cache Lockdown register.
Cache Lockdown
register L bits
www.digiembedded.com 99
This table shows the format of the Cache Lockdown register L bits. All cache ways
are available for allocation from reset.
Bits 4-way associative Notes
[31:16] UNP/SBZ Reserved
[15:4] 0xFFF SBO
WORKING WITH THE CPU
R9: Cache Lockdown register
Bits 4-way associative Notes
[3] L bit for way 3 Bits [3:0] are the L bits for each cache way:
[2] L bit for way 2
[1] L bit for way 1
[0] L bit for way 0
0 Allocation to the cache way is determined by the standard
replacement algorithm (reset state)
1 No allocation is performed to this way
Lockdown cache:
Specific loading of
addresses into a
cache-way
Use this procedure to lockdown cache. The procedure to lock down code and data
into way i of cache, with N ways, using format C, makes it impossible to allocate to
any cache way other than the target cache way:
1 Ensure that no processor exceptions can occur during the execution of this
procedure; for example, disable interrupts. If this is not possible, all code and
data used by any exception handlers must be treated as code and data as in
Steps 2 and 3.
2 If an ICache way is being locked down, be sure that all the code executed by
the lockdown procedure is in an uncachable area of memory or in an already
locked cache way.
3 If a DCache way is being locked down, be sure that all data used by the
lockdown procedure is in an uncachable area of memory or is in an already
locked cache way.
4 Ensure that the data/instructions that are to be locked down are in a cachable
area of memory.
5 Be sure that the data/instructions that are to be locked down are not already in
the cache. Use the Cache Operations register (R7) clean and/or invalidate
functions to ensure this.
6 Write these settings to the Cache Lockdown register (R9), to enable allocation
to the target cache way:
CRm = 0
Set L == 0 for bit i
Set L == 1 for all other bits
7 For each of the cache lines to be locked down in cache way i:
–
– If an ICache is being locked down, use the Cache Operations register (R7) MCR
100 Hardware Reference NS9215
If a DCache is being locked down, use an LDR instruction to load a word from
the memory cache line to ensure that the memory cache line is loaded into the
cache.
prefetch ICache line
(<CRm>==c13, <opcode2>==1) to fetch the memory cache line
into the cache.
