This guide provides information about the Digi NS9210 Processor Module embedded
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
core module.
. . . . .
Conventions used in this guide
This table describes the typographic conventions used in this guide:
This convention Is used for
italic type Emphasis, new terms, variables, and document titles.
monospaced type Filenames, pathnames, and code examples.
Digi information
Related documentation
Documentation updates
Customer support To get help with a question or technical problem with this product, or to make
For additional documentation, see the Documentation folder under the Digi JumpStart kit Start menu tab.
Be aware that if you see differences between the documentation you received in your package and the documentation on the web site, the web site content is the latest version.
comments and recommendations about our products or documentation, u se the following contact information:
To contact Digi International by Use
United States telephone: 1 877 912 3444
International telephone: 1 952 912 3444
Address: Digi International
11001 Bren Road East
Minnetonka, MN 55343 U.S.A
Web site: www.digiembedded.com
www.digiembedded.com 7
8 ConnectCore 9P 9215 Hardware Reference
About the Module
CHAPTER 1
The NS9210 Processor Module is part of the ConnectCore embedded core
processor module family. Built on leading Digi technology, the network-enabled ConnectCore 9P family provides a modular and scalable core processor solution that significantly minimizes hardware and software design risk. This module combines superior performance and a complete set of integrated peripherals and component connectivity options in a compact and versatile form factor.
The NS9210 Processor Module is built around the NS9215 processor with a powerful ARM926EJ-S core. For further information about the NS9215, see the NS9215 Hardware Reference available through your Digi JumpStart Kit. The embedded module offers 8MB SDRAM and can support a maximum of 64MB SDRAM. The module has also 4MB NOR flash and can support up to a maximum of 16MB NOR flash, a single high speed serial peripheral interface (SPI) module, an I2C interface, UARTs, programmable flexible interface modules (FIMs), ADC, 16-bit data/17-bit address bus (buffered), and 64 shared GPIO signals for application-specific usage.
9
Chapter 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Features and functionality
32-bit NET+ARM (ARM926EJ-S) RISC processor NS9215 @ 150MHz ARM9 core with memory management unit (MMU) 4K data cache/4K instruction cache 8MB SDRAM (can support a maximum of 64MB SDRAM) 4MB NOR Flash (can support a maximum of 16MB NOR flash) 10 general purpose timers; NS9210 Processor Module supports 7 as
timer/counters and one quadrature decoder
64 GPIOs signals with up to five different multiplexing schemes (all are on
connector X2)
Two 80-pin connectors Up to four UARTs One SPI channel, multiplexed on different plac es Integrated 10/100Mbps Ethernet MAC/PHY
2
I
C interface
JTAG signals available on module connector 8 ADC (analog to digital converter) inputs 2x flexible interface modules (FIMs) running at max. 300 MHz, integrated in
NS9215 processor
2 LEDs (LE1: green, and LE2:orange) available on module 16-bit data and 17-bit address buses, both are buffered Single +3.3V power supply
Module variant The NS9210 Processor Module is currently available in standard variants below.
Product numbers: Features
CC-9P-V502-C 150 MHz CPU speed, 8MB SDRAM, 4 MB NOR flash, RTC, 10/100 Mbps
Ethernet
CC-9P-V501-C 150 MHz CPU speed, 8MB SDRAM, 2MB NOR flash, RTC, 10/100 Mbps
Ethernet
29
Module pinout
The module has two 80 pins connectors, X1 and X2. The next tables describe each pin, its properties, and its use on the development board.
10 NS9210 Processor Module Hardware Reference
Pinout legend: Type
X1 pinout
. . . . .
I Input
O Output
I/O Input or output
PPower
X1 pin number
1 P GND GND
2 P GND GND
3 I RSTIN# RSTIN# 10k pull-up on module
4 O PWRGOOD PWRGOOD Output of the reset controller
5 O RSTOUT# RSTOUT# Output of logical AND function
6 I TCK TCK JTAG - 10k pull-up on module
7 I TMS TMS JTAG - 10k pull-up on module
8 I TDI TDI JTAG - 10k pull-up on module
9 O TDO TDO JTAG - 10k pull-up on module
10 I TRST# TRST# JTAG - 2k2 pull-up on module
11 O RTCK RTCK JTAG - Optional
Type Module functionality Usage on
Development board
Comments
push pull with 470R current limiting resistor
between NS9215 RESET_DONE and NS9215 RESET_OUT#
12 I CONF2/OCD_EN# CONF2/OCD_EN# 10k pull-up on module
13 I LITTLE# / BIG
ENDIAN
14 I Reserved
(WLAN_DISABLE#)
15 I SOFT_CONF0 SOFT_CONF0 2k2 series resistor on module
16 I SOFT_CONF1 SOFT_CONF1 2k2 series resistor on module
17 I SOFT_CONF2 SOFT_CONF2 2k2 series resistor on module
18 I SOFT_CONF3 SOFT_CONF3 2k2 series resistor on module
19 O Reserved
(WLAN_LED#)
www.digiembedded.com 11
LITTLE# / BIG ENDIAN
Reserved (WLAN_DISABLE#)
Reserved (WLAN_LED#)
2k2 series resistor on module
Low active WLAN Disable signal
Active low signal coming from Piper chip. This signal comes directly from the Piper chip without series resistor.
Chapter 1
X1 pin number
Type Module functionality Usa ge on
Development board
Comments
20 P GND GND
21 I/O D0 D0 Buffered Data - only active when
either CS0# or CS2# is active
NS9215 D[31:16]
22 I/O D1 D1
23 I/O D2 D2
24 I/O D3 D3
25 I/O D4 D4
26 I/O D5 D5
27 I/O D6 D6
28 I/O D7 D7
29 I/O D8 D8
30 I/O D9 D9
31 I/O D10 D10
32 I/O D11 D11
33 I/O D12 D12
34 I/O D13 D13
35 I/O D14 D14
36 I/O D15 D15
37 P GND GND
38 O AO AO Buffered Address always active
39 O A1 A1
40 O A2 A2
41 O A3 A3
42 O A4 A4
43 O A5 A5
44 O A6 A6
45 O A7 A7
46 O A8 A8
47 O A9 A9
48 O A10 A10
49 O A11 A11
50 O A12 A12
12 NS9210 Processor Module Hardware Reference
. . . . .
X1 pin number
51 O A13 A13
52 O A14 A14
53 O A15 A15
54 O A16 A16
55 O GND GND
56 O EXT_OE# EXT_OE#
57 O EXT_WE# EXT_WE#
58 O CSO# CSO#
59 O CS2# CS2#
60 O BLE# BLE# NS9215 BE2#
61 O BHE# BHE# NS9215 BE3#
62 I EXT_WAIT# EXT_WAIT# 10k pull-up on module
63 O BCLK BCLK Connected over a 22R resistor to
64 P GND GND
Type Module functionality Usage on
Development board
Comments
NS9215 CLK_OUT1 pin
65 I ETH_TPIN ETH_TPIN
66 O ETH_ACTIVITY# ETH_ACTIVITY# Low active signal with 330R
resistor on module
67 I ETH_TPIP ETH_TPIP
68 O ETH_LINK# ETH_LINK Low active signal with 330R
resistor on module
69 O ETH_TPON ETH_TPON
70 O ETH_TROP ETH_TROP
71 P GND GND
72 P Reserved (USB_VBUS) Reserved (USB_VBUS)
73 I Reserved (USB_OC#) Reserved (USB_OC#)
74 I/O Reserved (USB_P) Reserved (USB_P)
75 I/O Reserved (USB_N) Reserved (USB_N)
76 O Reserved
(USB_PWREN#)
77 I Reserved
(USB_OTG_ID)
Reserved (USB_PWREN#)
Reserved (USB_OTG_ID)
www.digiembedded.com 13
Chapter 1
X1 pin number
Type Module functionality Usa ge on
Development board
Comments
78 P VRTC VRTC Backup Battery for RTC, for 3V
cell.
Can be left floating, if RTC backup not needed.
79 P VLIO VLIO Mobile: Power from Li-Ion
Battery (2.5V-5.5V)
Non-Mobile: connected to 3.3V
80 P GND GND
14 NS9210 Processor Module Hardware Reference
X2 pinout
. . . . .
X2 pin number
1 P GND
2 P GND
3 I/O DCDA#/
4I/OCTSA#/
5I/ODSRA#/
6 I/O RXDA/
Type Module functionality Usage on
DMA0_DONE/
PIC_0_GEN_IO[0]
GPIO0/
SPI_EN (dup)
EIRQ0/
PIC_0_GEN_IO[1]
GPIO1/
-reserved-
EIRQ1/
PIC_0_GEN_IO[2]
GPIO2/
-reserved-
DMA0_PDEN/
PIC_0_GEN_IO[3]
GPIO3/
SPI_RX (dup)
Comments
Development board
7I/ORIA#/
EIRQ2/
Timer6_in/
GPIO4
SPI_CLK (dup)/
8 I/O RTSA#/ RS485CTLA
EIRQ3/
Timer6_Out/
GPIO5/
SPI_CLK (dup)/
9 I/O DTRA#/ TXCLKA
DMA0_REQ/
Timer7_In/
GPIO6/
PIC_DBG_DATA_OUT
www.digiembedded.com 15
Chapter 1
X2 pin number
Type Module functionality Usage on
10 I/O TXDA/
Timer8_In/
Timer7_Out/
GPIO7/
SPI_TX (dup)
11 I/O DCDC#/
DMA1_DONE/
Timer8_Out/
GPIO8/
SPIB_EN (dup)/
12 I/O CTSC#/
I2C_SCK/
EIRQ0 (dup)/
GPIO9/
PIC_DBG_DATA_IN
13 I/O DSRC#/
QDCI/
EIRQ1 (dup)
GPIO10/
PIC_DBG_CLK
Comments
Development board
14 I/O RXDC/
DMA1_DP/
EIRQ2 (dup)/
GPIO11/
SPI_RXboot
15 I/O RIC#/ RXCLKC
I2C_SDA/
RST_DONE/
GPIO12/
SPI_CLK (dup)
16 I/O RTSC#/
QDCQ/
Ext Timer Event Out Ch 9/
GPIO13/
SPI_CLKboot
17 I/O DTRC#/ TXCLKC
DMA1_REQ/
PIC_0_CAN_RXD
GPIO14/
SPI_TXDboot
When booting, NS9215 RIC# signal is default configured as Output, RST_DONE. To avoid input/output conflicts, put a series resistor on this signal if necessary.
16 NS9210 Processor Module Hardware Reference
. . . . .
X2 pin number
18 I/O TXDC/
19 I/O DCDB# (dup)/
20 I/O CTSB# (dup)/
21 I/O DSRB# (dup)/
22 I/O RXDB (dup)/
Type Module functionality Usage on
Timer9_In/
PIC_0_CAN_TXD
GPIO15/
SPI_ENboot
PIC_0_BUS_1[8]
PIC_1_BUS_1[8]
GPIO51/
PIC_0_BUS_1[9]
PIC_1_BUS_1[9]
GPIO52/
PIC_0_BUS_1[10]
PIC_1_BUS_1[10]
GPIO53/
PIC_0_BUS_1[11]
PIC_1_BUS_1[11]
GPIO54/
Comments
Development board
23 I/O RIB# (dup)/
PIC_0_BUS_1[12]
PIC_1_BUS_1[12]
GPIO55/
24 I/O RTSB# (dup) / RS485CTLB (dup) /
PIC_0_BUS_1[13]
PIC_1_BUS_1[13]
GPIO56/
25 I/O TXCLKB (dup)/ DTRB# (dup) /
PIC_0_BUS_1[14]
PIC_1_BUS_1[14]
GPIO57/
26 I/O TXDB (dup)/
PIC_0_BUS_1[15]
PIC_1_BUS_1[15]
GPIO58/
www.digiembedded.com 17
Chapter 1
X2 pin number
Type Module functionality Usage on
27 I/O DCDD# (dup) /
PIC_0_BUS_1[16]
PIC_1_BUS_1[16]
GPIO59/
28 I/O CTSD# (dup)/
PIC_0_BUS_1[17]
PIC_1_BUS_1[17]
GPIO60/
29 I/O DSRD# (dup)/
PIC_0_BUS_1[18]
PIC_1_BUS_1[18]
GPIO61/
30 I/O RXDD (dup)/
PIC_0_BUS_1[19]
PIC_1_BUS_1[19]
GPIO62/
31 I/O RID# (dup)/
PIC_0_BUS_1[20]
PIC_1_BUS_1[20]
GPIO63/
Comments
Development board
32 I/O RTSD# (dup) / RS485CTLD(dup) /
PIC_0_BUS_1[21]
PIC_1_BUS_1[21]
GPIO64/
33 I/O TXCLKD (dup) / DTRD# (dup) /
PIC_0_BUS_1[22]
PIC_1_BUS_1[22]
GPIO65
34 I/O TXDD (dup) /
PIC_0_BUS_1[23]
PIC_1_BUS_1[23]
GPIO66
35 I/O PIC_0_CLK[I]
PIC_0_CLK[0]
EIRQ3 (dup)/
GPIO67
36 I/O PIC_0_GEN_IO[0]
PIC_1_GEN_IO[0]
PIC_1_CAN_RXD
GPIO68
18 NS9210 Processor Module Hardware Reference
. . . . .
X2 pin number
37 I/O PIC_0_GEN_IO[1]
38 I/O PIC_0_GEN_IO[2]
39 I/O PIC_0_GEN_IO[3]
40 I/O PIC_0_GEN_IO[4]
41 I/O PIC_0_GEN_IO[5]
Type Module functionality Usage on
PIC_1_GEN_IO[1]
PIC_1_CAN_TXD
GPIO69
PIC_1_GEN_IO[2]
PWM0/
GPIO70
PIC_1_GEN_IO[3]
PWM1/
GPIO71
PIC_1_GEN_IO[4]
PWM2/
GPIO72
PIC_1_GEN_IO[5]
PWM3/
GPIO73
Comments
Development board
42 I/O PIC_0_GEN_IO[6]
PIC_1_GEN_IO[6]
Timer0_In/
GPIO74
43 I/O PIC_0_GEN_IO[7]
PIC_1_GEN_IO[7]
Timer1_In/
GPIO75
44 I/O PIC_0_CTL_IO[0]
PIC_1_CTL_IO[0]
Timer2_In/
GPIO76
45 I/O PIC_0_CTL_IO[1]
PIC_1_CTL_IO[1]
Timer3_In/
GPIO77
46 I/O PIC_0_CTL_IO[2]
PIC_1_CTL_IO[2]
Timer4_In/
GPIO78
www.digiembedded.com 19
Chapter 1
X2 pin number
Type Module functionality Usage on
47 I/O PIC_0_CTL_IO[3]
PIC_1_CTL_IO[3]
Timer5_In/
GPIO79
48 I/O PIC_0_BUS_0[0]
PIC_1_BUS_0[0]
Timer6_In (dup)/
GPIO80
49 I/O PIC_0_BUS_0[1]
PIC_1_BUS_0[1]
Timer7_In (dup)/
GPIO81
50 I/O PIC_0_BUS_0[2]
PIC_1_BUS_0[2]
Timer8_In (dup)/
GPIO82
51 I/O PIC_0_BUS_0[3]
PIC_1_BUS_0[3]
Timer9_In (dup)/
GPIO83
Comments
Development board
52 I/O PIC_0_BUS_0[4]
PIC_1_BUS_0[4]
Timer0_Out/
GPIO84
53 I/O PIC_0_BUS_0[5]
PIC_1_BUS_0[5]
Timer1_Out/
GPIO85
54 I/O PIC_0_BUS_0[6]
PIC_1_BUS_0[6]
Timer2_Out/
GPIO86
55 I/O PIC_0_BUS_0[7]
PIC_1_BUS_0[7]
Timer3_Out/
GPIO87
56 I/O PIC_0_BUS_0[13]/
PIC_1_BUS_0[13]/
Timer9_Out (dup)/
GPIO93
20 NS9210 Processor Module Hardware Reference
. . . . .
X2 pin number
57 I/O PIC_0_BUS_0[14]/
58 I/O PIC_0_BUS_0[15]/
59 I/O PIC_0_BUS_1[0]/
60 I/O PIC_0_BUS_1[1]/
61 I/O PIC_0_BUS_1[2]/
Type Module functionality Usage on
PIC_1_BUS_0[14]/
QDCI (dup)/
GPIO94
PIC_1_BUS_0[15]/
QDCQ (dup)/
GPIO95
PIC_1_BUS_1[0]/
PIC_0_CAN_RXD
GPIO96
PIC_1_BUS_1[1]/
PIC_0_CAN_TXD
GPIO97
PIC_1_BUS_1[2]/
PIC_1_CAN_RXD
GPIO98
Comments
Development board
62 I/O PIC_0_BUS_1[3]/
PIC_1_BUS_1[3]/
PIC_1_CAN_TXD
GPIO99
63 I/O PIC_0_BUS_1[4]/
PIC_1_BUS_1[4]/
PWM4/
GPIO100
64 I/O PIC_0_BUS_1[5]/
PIC_1_BUS_1[5]/
EIRQ3/
GPIO101
65 I/O PIC_0_BUS_1[6]/
PIC_1_BUS_1[6]/
I2C_SCL (dup)/
GPIO102
66 I/O PIC_0_BUS_1[7]/
PIC_1_BUS_1[7]/
I2C_SDA (dup)/
GPIO103
4k7 pull-up on module
4k7 pull-up on module
www.digiembedded.com 21
Chapter 1
X2 pin number
Type Module functionality Usage on
Development board
Comments
67 I VIN0_ADC
68 I VIN1_ADC
69 I VIN2_ADC
70 I VIN3_ADC
71 I VIN4_ADC
72 I VIN5_ADC
73 I VIN6_ADC
74 I VIN7_ADC
75 P VSS_ADC Connected on module to AGND
through 0
resistor
76 P VREF_ADC 100nF decoupling capacitor
between VREF_ADC and VSS_ADC
77 P 3.3V
78 P 3.3V
79 P GND
80 P GND
22 NS9210 Processor Module Hardware Reference
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration pins — CPU
None of the 64 GPIO pins on connector X2 disturb CPU boot strap functions. The boot strap functions are controlled by address signals; the user can not disturb boot strap functions from outside, if the module configuration signals, described below, are correctly configured.
. . . . .
Default module CPU configuration
The user has access to six configuration signals:
LITTLE#/BIG_ ENDIAN which allows the user to select the endianess of the
module
OCD_EN# which allows the user to activate on-chip debugging SW_CONF [3:0] which are reserved for the user; the user software can read out
these signals through the GEN ID register
(@ 0xA090_0210).
www.digiembedded.com 23
Chapter 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration pins — Module
The NS9210 Processor Module supports the following JTAG signals: TCK, TMS, TDI, TDO, TRST#, and RTCK. Selection can be made between ARM debug mode and boundary scan mode with the signal OCD_EN#.
Identification of the module
Module pin configuration
In order to make it easier for software to recognize a module and especially a hardware variant of the module, a specific bit field made of 4-bits has been reserved on the module. This bit field can be read out through GEN ID register and correspond to A[12:9]. These configuration signals use the internal CPU pull-up resistor and can be pulled down through external population option 2k2 resistors.
In the same way, 3 bits have been available on the module to identify the SDRAM configuration scheme. This bits correspond to A[19:17]. It is impossible for the user to disturb either the variant specific or SDRAM configuration specific bits from outside.
The NS9210 Processor Module has also available 4-bit for platform identification. This bit field can be read out through GEN ID register and correspond to A[16:13]. Configuration of these signals is done through the SW_CONF pins. SW_CONF0 is connected to A13 through a 2k2 series resistor, and so on for the further SW_CONF pins. So this bit can be set high by leaving the corresponding SW_CONF pin unconnected and set low by connecting the correspon ding SW_CONF pin directl y low. The user can benefit from these pins to support application or platform specific software configurations.
Signal name Function PU/PD Comment
LITTLE#/BIG_ ENDIAN
OCD_EN# JTAG / Boundary scan function
SW_CONF0 User-defined software
24 NS9210 Processor Module Hardware Reference
Set module endianess. 0 module boots in little endian mode. 1 module boots in big endian mode.
select
0 ARM debug mode,
1 Boundary scan mode,
configuration pin; can be read in GEN_ID register bit 4, default high
BISTEN# set to high
BISTEN# set to low
PU Signal LITTLE#/BIG_ENDIAN
is connected to GPIO_A3/A27 through a 2k2 series resistor.
PU 10K
Connected to A13 through a 2k2 series resistor.
Read bit 4 of GEN ID register (@ 0xA0900210).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signal name Function PU/PD Comment
. . . . .
SW_CONF1 User-defined software
configuration pin; can be read in GEN ID register bit 5, default high
SW_CONF2 User-defined software
configuration pin; can be read in GEN ID register bit 6, default high
SW_CONF3 User-defined software
configuration pin; can be read in GEN ID register bit 7, default high
Connected to A14 through a 2k2 series resistor.Read bit 5 of GEN ID register (@ 0xA0900210).
Connected to A15 through a 2k2 series resistor. Read bit 6 of GEN ID register (@ 0xA0900210).
Connected to A16 through a 2k2 series resistor. Read bit 7 of GEN ID register (@ 0xA0900210).
Clock generation
Clock frequencies Hardware strapping determines the initial powerup PLL settings. The table below
summarizes the default clock frequencies for the NS9210 Processor Module:
Hardware strapping:
"PLL reference clock divider setting:
A[4:0] = 0x1D (0b11101)
NR = 5
"PLL output divider setting:
A[6:5] = 0x3 (0b11)
OD = 0
"PLL bypass setting:
A[7] = 0x1 (0b1)
Normal operation
PLL frequency formula:
PLL Vco = (RefClk / NR+1) * (NF+1)
ClkOut = PLL Vco / (OD+1)
RefClk (Crystal) = 29.4912MHz
NF = 0x3C (reset value - can only be changed by software).
PLL Vco = (29.4912 / 6) * 61 = 299.8272 MHz
ClkOut = 299.8272 MHz
Resulting clock settings:
PIC clock = 299.8272 MHz
www.digiembedded.com 25
Chapter 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CPU clock = 299.8272 MHz / 2 = 149.9136 MHz
AHB clock = 149.9136 MHz / 2 = 74.9568 MHz
Changing the CPU speed
After powerup, software can change the PLL settings by writing to the PLL configuration register (@ 0xA090_0188)
Important: When PLL parameters are changed, a reset is provided for the PLL to
stabilize. Applications using this feature need to
be aware the SDRAM contents will be
lost. See reset behavior in the table below.
Reset Behavior RESET
_n pin
SPI boot YES YES YES YES
Strapping PLL YES NO NO NO
Other strappings (Endianess) YES NO NO NO
GPIO configuration YES NO NO NO
Other (ASIC) registers YES YES YES YES
SDRAM keeps its contents NO YES NO YES
SRESET _n pin
PLL Config Reg. Update
Watchdog Time-Out Reset
Boot process
The NS9210 Processor Module boots directly from NOR flash. The start-up code is located at address 0x00000000 during the boot process. When the system is booted, the SDRAM is remapped to address 0x00000000 and Nor Flash to 0x50000000 by modifying the address map in the AHB decoder.
26 NS9210 Processor Module Hardware Reference
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chip selects
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chip select memory map
. . . . .
The module has eight chip selects: four for dynamic memory and four for static memory. Each chip select has a 256MB range.
Name CPU
Sig. name
SDM_CS0# CS1# D6 0x00000000–
SDM_CS1# CS3# B5 0x10000000–
SDM_CS2# CS5# A4 0x20000000–
SDM_CS3# CS7# B4 0x30000000–
EXT_CS0# CS0# C6 0x40000000–
INT_CS1# CS2# B6 0x50000000–
EXT_CS2# CS4# C5 0x60000000–
INT_CS3# CS6# A3 0x70000000–
Pin Address range Size
0x0FFFFFFF
0x1FFFFFFF
0x2FFFFFFF
0x3FFFFFFF
0x4FFFFFFF
0x5FFFFFFFF
0x6FFFFFFFF
0x7FFFFFFF
Usage Comments
[Mb]
256 SDRAM bank 0 First bank on module
256 not used
256 not used
256 not used
256 external, CS0#
256 NOR-Flash Program memory on
module
256 external, CS2#
256 internal, CS3# Reserved for internal usage
SDRAM banks
The module provides connection to 1 SDRAM chip, connected to CS1# (SDM_CS0#). The other SDRAM chip selects are not used.
The standard module has one of these SDRAM onboard: 1Mx16x4-banks. A13 is the highest address connected. BA0 and BA1 are connected to A21 and A22, respectively.
Multiplexed GPIO pins
The 64 GPIOs pins available on the module connec tor are multiplexed with other functions like:
www.digiembedded.com 27
Chapter 1
UART SPI Ethernet DMA
2
I Timers and interrupt inputs Memory bus data
C port
Pin notes
GPIO [15:0] allow five multiplex modes. GPIO [103:16] and GPIO_A [3:0] have four multiplex modes. Using a pin as GPIO means always to give up other functionalities. Some
functions are duplicated to enhance the chance to use them without giving up other vital functions.
Using original and (dup) functions in parallel is not recommended. Default function of GPIOs after CPU power up is function 03, except GPIO12
(function 02-reset_done) and GPIO [31:16] (function 00 - DATA[15:0]).
GPIO multiplex table
Port name, Function 03
GPIO0 DCDA# DMA0_DONE PIC_0_GEN_IO[0] SPI_EN# (dup) DCDA# / SPI_EN#
Alternate function 00Alternate function 01Alternate
In the GPIO multiplex table below,
the default function is written bold, # means low active signal, (dup) means function is available multiple times.
Alternate
function 02
function 04 (only GPIO00...GPIO15)
On module, default used as
GPIO1 CTSA# EIRQ0 PIC_0_GEN_IO[1] Reserved CTSA#
GPIO2 DSRA# EIRQ1 PIC_0_GEN_IO[2] Reserved DSRA#
GPIO3 RXDA# DMA0_PDEN PIC_0_GEN_IO[3] SPI_RXD (dup) RXDA / SPI_RXD
GPIO4 RIA# EIRQ2 Timer6_In SPI_CLK (dup) RIA# / SPI_CLK
GPIO5 RTSA# / 485CTLA EIRQ3 Timer6_Out SPI_CLK (dup) RTSA#
GPIO6 TXCLKA / DTRA# DMA0_REQ Timer7_In PIC_DBG_DATA_OUT DTRA#
GPIO7 TXDA Timer8_In Timer7_Out SPI_TXD (dup) TXDA / SPI_TXD
GPIO8 DCDC# / TXCLKC DMA1_DONE Timer8_Out SPI_EN# (dup) DCDC#
GPIO9 CTSC# I2C_SCL EIRQ0 (dup) PIC_DBG_DATA_IN CTSC#
GPIO10 DSRC# QDCI EIRQ1 (dup) PIC_DBG_CLK DSRC#
28 NS9210 Processor Module Hardware Reference
. . . . .
Port name, Function 03
GPIO11 RXDC# DMA1_PDEN EIRQ2 (dup) SPI_RXD (boot) RXDC
GPIO12 RXCLKC / RIC# I2C_SDA RESET_DONE SPI_CLK (dup) RIC#
GPIO13 RXCLKC / RTSC#
GPIO14 TXCLKC / DTRC# DMA1_REQ PIC_0_CAN_RXD SPI_TXD (boot) TXCLKC
GPIO15 TXDC Timer9_In PIC_0_CAN_TXD SPI_EN# (boot) TXDC
GPIO16 D0 DCDB# EIRQ0 (dup) Reserved for upper data
GPIO17 D1 CTSB# EIRQ1 (dup) Reserved for upper data
GPIO18 D2 DSRB# EIRQ2 (dup) Reserved for upper data
GPIO19 D3 RXDB EIRQ3 (dup) Reserved for upper data
GPIO20 D4 RIB# DMA0_DONE (dup) Reserved for upper data
Alternate function 00Alternate function 01Alternate
function 02
QDCQ Reserved SPI_CLK (boot) RXCLKC / RTSC#
/485CTLC
Alternate function 04 (only GPIO00...GPIO15)
On module, default used as
1
lines
lines
lines
lines
lines
GPIO21 D5 RTSB# / 485CTLB DMA0_PDEN (dup) Reserved for upper data
lines
GPIO22 D6 TXCLKB / DTRB# DMA1_DONE (dup) Reserved for upper data
lines
GPIO23 D7 TXDB PIC_1_CAN_RXD Reserved for upper data
lines
GPIO24 D8 DCDD# PIC_1_CAN_TXD Reserved for upper data
lines
GPIO25 D9 CTSD# RESET_DONE (dup) Reserved for upper data
lines
GPIO26 D10 DSRD# PIC_1_GEN_IO[0] Reserved for upper data
lines
GPIO27 D11 RXDD PIC_1_GEN_IO[1] Reserved for upper data
lines
GPIO28 D12 RID# PIC_1_GEN_IO[2] Reserved for upper data
lines
GPIO29 D13 RTSD# / 485CTLD PIC_1_GEN_IO[3] Reserved for upper data
lines
GPIO30 D14 TXCLKD / DTRD# Reserved Reserved for upper data
lines
www.digiembedded.com 29
Chapter 1
Port name, Function 03
GPIO31 D15 TXDD Reserved Reserved for upper data
GPIO32 MII_MDC PIC_0_GEN_IO[0] Reserved MII Interface
GPIO33 MII_TXC PIC_0_GEN_IO[1] Reserved MII Interface
GPIO34 MII_RXC PIC_0_GEN_IO[2] Reserved MII Interface
GPIO35 MII_MDIO PIC_0_GEN_IO[3] Reserved MII Interface
GPIO36 MII_RXDV PIC_0_GEN_IO[4] Reserved MII Interface
GPIO37 MII_RXER PIC_0_GEN_IO[5] Reserved MII Interface
GPIO38 MII_RXD0 PIC_0_GEN_IO[6] Reserved MII Interface
GPIO39 MII_RXD1 PIC_0_GEN_IO[7] Reserved MII Interface
GPIO40 MII_RXD2 PIC_1_GEN_IO[0] Reserved MII Interface
GPIO41 MII_RXD3 PIC_1_GEN_IO[1] Reserved MII Interface
GPIO42 MII_TXEN PIC_1_GEN_IO[2] Reserved MII Interface
GPIO43 MII_TXER PIC_1_GEN_IO[3] Reserved MII Interface
Alternate function 00Alternate function 01Alternate
function 02
Alternate function 04 (only GPIO00...GPIO15)
On module, default used as
lines
GPIO44 MII_TXD0 PIC_1_GEN_IO[4] Reserved MII Interface
GPIO45 MII_TXD1 PIC_1_GEN_IO[5] Reserved MII Interface
GPIO46 MII_TXD2 PIC_1_GEN_IO[6] Reserved MII Interface
GPIO47 MII_TXD3 PIC_1_GEN_IO[7] Reserved MII Interface
GPIO48 MII_COL Reserved Reserved MII Interface
GPIO49 MII_CRS Reserved Reserved MII Interface
GPIO50 MII_PHY_Int PIC_1_CLK (I) PIC_1_CLK(0) MII Interface
GPIO51 DCDB# (dup) PIC_0_BUS_1[8] PIC_1_BUS_1[8] DCDB#
GPIO52 CTSB# (dup) PIC_0_BUS_1[9] PIC_1_BUS_1[9] CTSB#
GPIO53 DSRB# (dup) PIC_0_BUS_1[10] PIC_1_BUS_1[10] DSRB#
GPIO54 RXDB (dup) PIC_0_BUS_1[11] PIC_1_BUS_1[11] RXDB
GPIO55 RIB# (dup) PIC_0_BUS_1[12] PIC_1_BUS_1[12] RIB#
GPIO56 RTSB# / 485CTLB
(dup)
GPIO57 TXCLKB (dup) /
DTRB# (dup)
GPIO58 TXDB (dup) PIC_0_BUS_1[15] PIC_1_BUS_1[15] TXDB
PIC_0_BUS_1[13] PIC_1_BUS_1[13] RTSB#
PIC_0_BUS_1[14] PIC_1_BUS_1[14] DTRB#
GPIO59 DCDD# (dup) PIC_0_BUS_1[16] PIC_1_BUS_1[16] DCDD#
GPIO60 CTSD# (dup) PIC_0_BUS_1[17] PIC_1_BUS_1[17] CTSD#
30 NS9210 Processor Module Hardware Reference
. . . . .
Port name, Function 03
GPIO61 DSRD# (dup) PIC_0_BUS_1[18] PIC_1_BUS_1[18] DSRD#
GPIO62 RXDD (dup) PIC_0_BUS_1[19] PIC_1_BUS_1[19] RXDD
GPIO63 RID# (dup) PIC_0_BUS_1[20] PIC_1_BUS_1[20] RID#
GPIO64 RTSD# / 485CTLD
GPIO65 TXCLKD (dup) /
GPIO66 TXDD (dup) PIC_0_BUS_1[23] PIC_1_BUS_1[23] TXDD
GPIO67 PIC_0_CLK (I) PIC_0_CLK (O) EIRQ3 (dup) PIC_0_CLK
GPIO68 PIC_0_GEN_IO[0] PIC_1_GEN_IO[0] PIC_1_CAN_RXD PIC_0_GEN_IO[0]
GPIO69 PIC_0_GEN_IO[1] PIC_1_GEN_IO[1] PIC_1_CAN_TXD PIC_0_GEN_IO[1]
GPIO70 PIC_0_GEN_IO[2] PIC_1_GEN_IO[2] PWM0 PIC_0_GEN_IO[2]
GPIO71 PIC_0_GEN_IO[3] PIC_1_GEN_IO[3] PWM1 PIC_0_GEN_IO[3]
GPIO72 PIC_0_GEN_IO[4] PIC_1_GEN_IO[4] PWM2 PIC_0_GEN_IO[4]
Alternate function 00Alternate function 01Alternate
function 02
PIC_0_BUS_1[21] PIC_1_BUS_1[21] RTSD#
(dup)
PIC_0_BUS_1[22] PIC_1_BUS_1[22] DTRD#
DTRD# (dup)
Alternate function 04 (only GPIO00...GPIO15)
On module, default used as
GPIO73 PIC_0_GEN_IO[5] PIC_1_GEN_IO[5] PWM3 PIC_0_GEN_IO[5]
GPIO74 PIC_0_GEN_IO[6] PIC_1_GEN_IO[6] Timer0_In PIC_0_GEN_IO[6]
GPIO75 PIC_0_GEN_IO[7] PIC_1_GEN_IO[7] Timer1_In PIC_0_GEN_IO[7]
GPIO76 PIC_0_CTL_IO[0] PIC_1_CTL_IO[0] Timer2_In PIC_0_CTL_IO[0]
GPIO77 PIC_0_CTL_IO[1] PIC_1_CTL_IO[1] Timer3_In PIC_0_CTL_IO[1]
GPIO78 PIC_0_CTL_IO[2] PIC_1_CTL_IO[2] Timer4_In PIC_0_CTL_IO[2]
GPIO79 PIC_0_CTL_IO[3] PIC_1_CTL_IO[3] Timer5_In PIC_0_CTL_IO[3]
GPIO80 PIC_0_BUS_0[0] PIC_1_BUS_0[0] Timer6_In (dup) Timer6_In
GPIO81 PIC_0_BUS_0[1] PIC_1_BUS_0[1] Timer7_In (dup) Timer7_In
GPIO82 PIC_0_BUS_0[2] PIC_1_BUS_0[2] Timer8_In (dup) Timer8_In
GPIO83 PIC_0_BUS_0[3] PIC_1_BUS_0[3] Timer9_In (dup) Timer9_In
GPIO84 PIC_0_BUS_0[4] PIC_1_BUS_0[4] Timer0_Out Timer0_Out
GPIO85 PIC_0_BUS_0[5] PIC_1_BUS_0[5] Timer1_Out Timer1_Out
GPIO86 PIC_0_BUS_0[6] PIC_1_BUS_0[6] Timer2_Out Timer2_Out
GPIO87 PIC_0_BUS_0[7] PIC_1_BUS_0[7] Timer3_Out Timer3_Out
GPIO88 PIC_0_BUS_0[8] PIC_1_BUS_0[8] Timer4_Out Reserved for module
LEDs
GPIO89 PIC_0_BUS_0[9] PIC_1_BUS_0[9] Timer5_Out Reserved for module
LEDs
www.digiembedded.com 31
Chapter 1
Port name, Function 03
GPIO90 PIC_0_BUS_0[10] PIC_1_BUS_0[10] Timer6_Out (dup) GPIO reserved on
GPIO91 PIC_0_BUS_0[11] PIC_1_BUS_0[11] Timer7_Out (dup) Reserved NAND_R/B#
GPIO92 PIC_0_BUS_0[12] PIC_1_BUS_0[12] Timer8_Out (dup) GPIO reserved on
GPIO93 PIC_0_BUS_0[13] PIC_1_BUS_0[13] Timer9_Out (dup) Timer9_Out
GPIO94 PIC_0_BUS_0[14] PIC_1_BUS_0[14] QDCI (dup) QDCI
GPIO95 PIC_0_BUS_0[15] PIC_1_BUS_0[15] QDCQ (dup) QDCQ
GPIO96 PIC_0_BUS_1[0] PIC_1_BUS_1[0] PIC_0_CAN_RXD PIC_0_CAN_RXD
GPIO97 PIC_0_BUS_1[1] PIC_1_BUS_1[1] PIC_0_CAN_TXD PIC_0_CAN_TXD
GPIO98 PIC_0_BUS_1[2] PIC_1_BUS_1[2] PIC_1_CAN_RXD PIC_1_CAN_RXD
GPIO99 PIC_0_BUS_1[3] PIC_1_BUS_1[3] PIC_1_CAN_TXD PIC_1_CAN_TXD
GPIO100 PIC_0_BUS_1[4] PIC_1_BUS_1[4] PWM4 PWM4
GPIO101 PIC_0_BUS_1[5] PIC_1_BUS_1[5] EIRQ3 EIRQ3
Alternate function 00Alternate function 01Alternate
function 02
Alternate function 04 (only GPIO00...GPIO15)
On module, default used as
module
module
GPIO102 PIC_0_BUS_1[6] PIC_1_BUS_1[6] I2C_SCL (dup) I2C_SCL
GPIO103 PIC_0_BUS_1[7] PIC_1_BUS_1[7] I2C_SDA (dup) I2C_SDA
GPIO_A0 A24 I2C_SCL dupe EIRQ0 (dup) Reserved EIRQ0 - Piper
GPIO_A1 A25 I2C_SDA dupe EIRQ1 (dup) Reserved EIRQ1 - USB
GPIO_A2 A26 CS0_WE# EIRQ2 (dup) GPIO reserved on
module
GPIO_A3 A27 CS0_OE# UART_REFCLK Little/Big Endian
1
Put a series resistor on the baseboard in this case to avoid input/output conflict between RESET_DONE (output/boot
default) and RIC# (input/configuration default).
External interrupts
The NS9210 Processor Module provides access to four external interrupts signals, which are multiplexed with other functions on the GPIO pins. Ever y interrupt is multiplexed to two or three different GPIO pins. These duplicate signals are marked as (dup) in the GPIO table.
External interrupt GPIO multiplexing Other functions,
1st position
EIRQ0 GPIO1
GPIO9
X2.4
X2.12
Comments
EIRQ1 GPIO2
32 NS9210 Processor Module Hardware Reference
GPIO10
X2.5
X2.13
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interfaces
10/100 Mbps Ethernet port
External interrupt GPIO multiplexing Other functions,
1st position
EIRQ2 GPIO4
GPIO11
EIRQ3 GPIO5
GPIO67
GPIO101
X2.7
X2.14
X2.8
X2.35
X2.64
Comments
EIRQ3# is used on the development board to implement I²C I/O expander interrupt functionality.
The NS9215 10/100 Mbps Ethernet MAC allows a glueless connection of a 3.3V MII PHY chip that generates the physical Ethernet signals.
The module has a MII PHY chip (ICS ICS1893BKILFT) in a 56-pin QFN package on board. By default, the module does not have a transformer or Ethernet connector; the base board must provide these parts. However, it's possible to populate a specific RJ45 connector with magnetics on the module. The appropriate RJ-45 is Midcom MIC2412A­5108W-LF3.
A PHY clock of 25 MHz is generated in the PHY chip with a 25 MHz crystal. GPIO90 is controlling the PHY RESET# signal. This GPIO has a 2k2 pu ll-down resistor
to GND populated on the module. GPIO90 must be asserted high before PHY can be used. When not used, the PHY can be put in low-power mode by asserting GPIO90 low.
The PHY address on the MII bus is 0x7 (0b00111). The module does not only provide access to the Ethernet signals coming out of the
PHY, but supports also two status LEDs: ETH_ACTIVITY# and ETH_LINK#.
UART The module provides up to four UART ports with all handshake signals, used in
asynchronous mode:
Port A = GPIOO through GPIO7 Port B = GPIO51 through GPIO58 Port C = GPIO8 through GPIO15 Port D = GPIO59 through GPIO66
The module supports baud rates up to 1.8432 Mbps in asynchronous mode. Each UART has a 64-byte TX and RX FIFO available.
SPI The module provides one SPI port which can be used in either master or slave mode.
www.digiembedded.com 33
Chapter 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master: 33.33 Mbps Slave: 7.50 Mbps
The SPI module is made of four signals: RXD, TXD, CLK and CS#
I2C bus The I2C bus is completely free on the module - no EEPROM and no RTC - since the RTC
is in the processor. The I²C clock is max 400kHz. I2C signals are provided on the module with 4k7 pull-up resistors.
RTC The RTC is integrated in the processor and has its own 32.768 KHz clock crystal.
When powered by VBAT, RTC unit will function until VBAT (X1.78) reaches a
threshold of 2.3 - 2.4V - then the internal unit switches off.
The battery current without +3.3V power applied is up to 40µA. The current is
used to power the RTC, 32.768kHz oscillator and 64-byte internal RAM.
When the development board ships from the factory the battery is disabled. T o
enable the battery, place a jumper on the development board at J2.
Power
Power supply The module has +3.3V and VLIO supply pins.
VLIO can be connected either to a Li-Ion battery (2.5V - 5.5V) in a mobile application, or it can be connected directly to +3.3V. Connecting VLIO to a battery causes efficiency to be gained without an additional voltage regulator.
Internal voltage The internal 1.8V core voltage is generated through a high-efficiency synchronous
step-down converter, which uses VLIO as input voltage. The core voltage regulator can provide up to 600mA.
34 NS9210 Processor Module Hardware Reference
About the Development Board
CHAPTER 2
The NS9210 Processor Module Development board supports the NS9210 Processor
Module. This chapter describes the components of the de velopment board and explains how to configure the board for your requirements.
The development board has two 4x20 pin connectors that are 1:1 copies of the module pins.
What’s on the development board?
RJ-45 Ethernet connector 2 x RP-SMA antenna connectors (reserved for future use) Four serial interface connectors:
1 x UART B MEI (RS232/RS4xx) with status LEDs on SUB-D 9-pin connector (X6) 1 x UART D RS232 with status LEDs, on SUB-D 9-pin connector (X3) 1 x UART C with TTL levels shared with HDLC signals on 10-pin header (X5) 1 x UART A with TTL levels shared with SPI signals on 10-pin header (X4)
ADC, SPI, and I2C headers JTAG connector Peripheral application header Including access to 16-bit data/10-bit address bus signals Headers with 1:1 copies of the module pins (X1/X2) Two user pushbuttons, two user LEDs, wake-up button Eight-position configuration dip switches
Four each for hardware/software configuration
GPIO screw-flange connector
35
Chapter 2
+9/30VDC power supply Current measurement option Development board + Module, and module alone 3.3V coincell battery with socket PoE connectors for optional application kit (IEEE 802.3 af) Prototyping area (15 x 28 holes) with +3.3V and GND connections
36 NS9210 Processor Module Hardware Reference
The development board
. . . . .
www.digiembedded.com 37
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User interface
The NS9210 Processor Module Development board implements two user buttons and two user LEDs in addition to those provided on the module.
The user LEDs on the development board can be enabled or disabled by correctly setting jumper J5&6.
The table below shows which NS9215 GPIO is available for implementing the user interface.
Signal name GPIO used Comments
USER_BUTTON1 GPIO81 10k pull-up to +3.3V on the
USER_LED1# GPIO82
USER_BUTTON2 GPIO84 10k pull-up to +3.3V on the
development board
development board
USER_LED2# GPIO85
38 NS9210 Processor Module Hardware Reference
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switches and pushbuttons
Power Switch, S2
Configuration switch, S4
Reset button
S3
Serial Port B
(MEI)
configuration
switch S1
Wake Up button
S8
User Button 1
S6
User Button 2
S7
. . . . .
Reset control, S3 The reset pushbutton, S3, resets the module. On the module, RSTOUT# and
PWRGOOD are produced for peripherals. A pushbutton allows manual reset by connecting RSTIN# to ground. The reset controller is located on the NS9210 P rocessor Module.
Power switch, S2 The development board has an ON/OFF switch, S2. The power switch S2 can switch
both 9V-30V input power supply and 12V coming out of the P oE mod ule. Howeve r, if a power plug is connected in the DC power jack, the PoE module is disabled.
www.digiembedded.com 39
Chapter 2
User pushbuttons, S6 and S7
Legend for multi­pin switches
Module configuration switches, S4
Use the user pushbuttons to interact with the applications running on the NS9210 Processor Modu le . Use these module signals to implement the pushbuttons:
Signal name Switch
(pushbutton)
USER_PUSH_BUTTON_1 S6 GPIO81
USER_PUSH_BUTTON_2 S7 GPIO84
GPIO used
Switches 1 and 4 are multi-pin switches. In the description tables for these switches, the pin is designated as S[switch number].[pin number]. For example, pin 1 in switch 4 is specified as S4.1.
Use S4 to configure the module:
Switch pin Function
S4.1 On = Little endian
Off = Big endian
S4.2 Not used
S4.3 On = ARM Debug
Off = Boundary Scan
Wake-up button, S8
S4.4 Not used
S4.5 – S4.8 Not defined. Software configuration signals, which can be available for user
specific configuration.
The wake-up pushbutton, S8, generates an external interrupt to the module's NS9215 processor using the EIRQ2 signal.
40 NS9210 Processor Module Hardware Reference
. . . . .
Serial Port B MEI configuration switches, S1
Use S1 to configure the line interface for serial port B MEI:
Switch pin Function Comments
S1.1 On = RS232 transceiver enabled
RS422/RS485 transceivers disabled
Off = RS232 transceiver disabled
RS422/RS485 transceivers enabled
S1.2 On = Auto Power Down enabled
Off = Auto Power Down disabled
S1.3 On = 2-wire interface (RS422/RS485)
Off = 4-wire interface (RS422)
S1.4 On = Termination on
Off = No termination
Auto Power Down is not supported on this board. This signal is only accessible to permit the user to completely disabled the MEI interface for using the signals for other purposes. To disable the MEI interface, go in RS232 mode (S1.1 = ON) and activate the Auto Power Down feature (S1.2 = ON) - be sure that no cable is connected to connector X3.
www.digiembedded.com 41
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Jumper J2
Serial Port D
transceiver
Jumper J1
User LED1
Jumper J5
User LED2
Jumper J4
WLAN Jumper J3
Jumpers
42 NS9210 Processor Module Hardware Reference
Jumper functions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . .
Jump er
J1 Enable transceiver This jumper allows to disable the console RS232 transceiver. Connection made =
J2 Battery enable Supplies the real time clock with 3V from the battery (lithium coin cell battery,
J3 WLAN_DISABLE# Reserved for future use.
J4 USER_LED2# Enables User LED2 (LE6) to show the status of this signal (lit if low). Connection made = User
J5 USER_LED1# Enables User LED1 (LE5) to show the status of this signal (lit if low). Connection made = User
Name If connection made Default
console active
Connection not made =
G1) even if the board is switched off. This is for keeping time in the RTC.
Disables the WiFi unit on the module.
Backup battery disabled
Connection made = WLAN disabled
LED2 enabled
LED1 enabled
Battery and Battery Holder
Battery Holder Battery
Coin-Cell Holder for CR2477 Battery, THT
Keystone 1025-7
Ettinger 15.61.252
Lithium coin cell, CR2477, 24mm, 950mAh
Panasonic CR2477
Renata CR2477N
www.digiembedded.com 43
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power LED +3.3V, LE4Power LED 9-30V, LE3
WLAN LED LE7
Serial Port D
status LEDs
Serial Port B
status (MEI)
LEDs
User LED2,
LE6
User LED1,
LE5
LEDs
WLAN LED LE7 Reserved for future use.
Power LEDs, LE3 and LE4
User LEDs, LE5 and LE6
The power LEDs are all red LEDs. These po wer supplies must be pre s ent and cannot be switched.
LE3 ON indicates the +9VDC / +30VDC power is present. LE4 ON indicates the +3.3VDC power is present.
The user LEDs are controlled through applications running on the NS9210 Processor Module, if J5 and J4 are set. Use these module signals to implement the LEDs:
44 NS9210 Processor Module Hardware Reference
Signal name LED GPIO used
USER_LED1# LE5 GPIO82
USER_LED2# LE6 GPIO85
. . . . .
Serial status LEDs
Sta t us L E Ds Serial Port D LEDs
Sta t us L E Ds Serial Port B LEDs
The development board has two sets of serial port LEDs — four for serial port D and eight for serial port B. The LEDs are connected to the TTL side of the RS232 or RS422/485 transceivers.
Green means corresponding signal high. Red means corresponding signal low. The intensity and color of the LED will change when the voltage is switching.
LED reference Function
RED GREEN
LE60 LE45 CTSD#/GPIO60
LE61 LE46 RTSD#/GPIO64
LE62 LE47 RXDD/GPIO62
LE63 LE48 TXDD/GPIO66
LED reference Function
RED GREEN
LE64 LE49 DCDB#/GPIO51
LE65 LE50 RIB#/GPIO55
LE66 LE51 DSRB#/GPIO53
LE67 LE52 DTRB#/GPIO57
LE68 LE53 CTSB#/GPIO52
LE69 LE54 RTSB#/GPIO56
LE70 LE55 RXDB/GPIO54
LE71 LE56 TXDB/GPIO58
www.digiembedded.com 45
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Port D
(RS232),
X3
Serial
Port B
(MEI) X6
Serial Port A
TTL X4
Serial Port C
TTL, X5
Serial UART ports
The development board supports the four serial ports available on the NS9210 Processor Module.
Serial port D, RS232
The serial (UART) port D connecto r, X3, is a DSUB9 male connector
the standard console
. This asynchronous serial port is DTE and requires a null-modem
and is also used as
cable to connect to a computer serial port.
46 NS9210 Processor Module Hardware Reference
The serial port D interface corresponds to NS9215 UART port D. The line driver is enabled or disabled using the
jumper J1.
Serial port D pins are allocated as shown:
Pin Function Defaults to
1 DCD# GPIO59
2 RXD GPIO62
3 TXD GPIO66
4DTR# GPIO65
5GND
6 DSR# GPIO61
7RTS# GPIO64
8CTS# GPIO60
9 RIB# GPIO63
By default, Serial D signals are configured to their respective GPIO signals. It is the responsibility of the driver to configure them properly.
. . . . .
Serial port A TTL interface
The serial (UART) port A interface is a TTL interface connected to a 2x5 pin, 0.1” connector, X4. The connector supports only TTL level.
The serial port A interface corresponds to NS9215 UART port A. Serial port A pins are allocated as shown:
Pin Function Defaults to Comment
1 DCDA#/SPI_EN# GPIO0 Can be programmed as SPI enable to X4
2DSRA# GPIO2
3 RXDA/SPI_RXD GPIO3 Can be programmed as SPI receive data to X4
4 RTSA#/SPI_CLK GPIO5 Can be programmed as SPI clock to X4
5 TXDA/SPI_TXD GPIO7 Can be programmed as SPI transmit data to X4
6CTSA# GPIO1
7DTRA# GPIO6
8 RIA#/EIRQ2 GPIO4 This signal is default configured to support the wake-
up button on the development board.
9GND
10 3.3V
By default, Serial A signals are configured to their respective GPIO signals. It is the responsibility of the driver to configure them properly.
Serial Port A must not be connected if SPI or WakeUp functionality is used.
www.digiembedded.com 47
Chapter 2
Serial port C TTL interface
The serial (UART) port C interface is a TTL interface connected to a 2x5 pin, 0.1” connector, X5. The connector supports only TTL level.
The serial port C interface corresponds to the NS9215 UART port C. The signals are shared with the
HDLC interface.
Serial port C pins are allocated as shown:
Pin Function Defaults to
1 DCDC#/TXCLKC GPIO8.
2DSRC# GPIO10.
3 RXDC# GPIO11
4 RTSC#/RXCLKC GPIO13
5 TXDC GPIO15
6CTSC# GPIO9
7 DTRC#/TXCLKC GPIO14
8 RIC#/RXCLKC/GPIO 12 RESET_DONE See note
9 GND
10 3.3V
Note: By using GPIO12 as RIC#, be sure to populate a series resistor on the baseboard. This is necessary to avoid conflict between the default configuration of the GPIO when booting (RESET_DONE / output) and the chosen configuration once booted (RIC# / input).
By default, Serial C signals are configured to their respective GPIO signals, except for GPIO12. It is the responsibility of the driver to configure them properly.
48 NS9210 Processor Module Hardware Reference
. . . . .
Serial port B, MEI interface
The serial (UART) port B connector, X6, is a DSUB9 male connector. This asynchronous serial port is DTE and requires a null-modem cable to connect to a computer serial port.
The serial port B MEI (Multiple Electrical Interface) interface corresponds to NS9215 UART port B. The line drivers are configured using switch S1.
Note that all pins on S1 contribute to the line driver settings for this port. Serial port B pins are allocated as shown:
Pin RS232
function
1DCD# GPIO51CTS- n/a
2 RXD GPIO54 RX+ GPIO54
3 TXD GPIO58 TX+ GPIO58
4 DTR# GPIO57 RTS- n/a
5 GND GND
6 DSR# GPIO53 RX- n/a
7 RTS# GPIO56 RTS+ GPIO56
8 CTS# GPIO52 CTS+ GPIO52
RS232 default
RS485 function
RS485 default
9 RI# GPIO55 TX- n/a
By default, Serial B signals are configured to their respective GPIO signals. It is the responsibility of the driver to configure them properly.
www.digiembedded.com 49
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I2C d ig i ta l I/ Os, X 4 4I2C header, X15
I2C interface
I2C header The I²C interface has only one device connected to the bus on the development
board - an I/O expander (see next paragraph). Otherwise, additional I²C devices (like EEPROMs) can be connected to the module by using I²C header X15. The pinning of this header is provided below.
Pin Signal
1 I2C_SDA/GPIO103
2 +3.3V
3 I2C_SCL/GPIO102
4 GND
2
C digital I/O
I expansion
50 NS9210 Processor Module Hardware Reference
The development board provides a 3.81mm (1.50") green terminal block, X44, for additional digital I/Os. The I
and provides an open drain
2
C I/O port chip is on-chip ESD-protected, 5V tolerant,
interrupt output.
The I/O expander is a Philips PCA9554D at I2C address 0x20 / 0x21. The pins are allocated as shown:
Pin Signal
1IO_0
2IO_1
3IO_2
4IO_3
5IO_4
6IO_5
7IO_6
8IO_7
9GND
. . . . .
www.digiembedded.com 51
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPI header, X8
SPI interface
The development board provides access to the SPI interface on the module using the SPI connector, X8. The SPI interface on the development board is shared with UART_A (NS9215 port A). Because the module’s SPI interface is shared with a UART interface, you cannot use both simultaneously.
Note: The default configuration of UART port A is to support GPIOs. To move from GPIO to UART or SPI, you need to configure the software properly.
52 NS9210 Processor Module Hardware Reference
Pin allocation SPI connector pins are allocated as shown:
Pin Signal
1 +3.3V
2 TXDA/SPI_TXD/GPIO7
3 RXDA/SPI_RXD/GPIO3
4 RTSA#/SPI_CLK/GPIO5
5 DCDA#/SPI_EN#/GPIO0
6GND
. . . . .
www.digiembedded.com 53
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current Measurement Option (CMO) +3.3V development board and
module, R80
Current Measurement Optio n (CMO)
+3.3V VLIO
for 1.8V core,
module o nly,
R81
Current Measurement Optio n (C MO )
+3.3V for
module only
R94
Current Measurement Option
The Current Measurement Option uses 0.025R ohm series resistors to measure the current. The NS9210 Processor Module Development board allows to measure:
the current used by the development board and module (through R80), and the current used by the internal NS9215 1.8V core generated from VLIO using a
high-efficiency synchronous step-down converter (through R81)
54 NS9210 Processor Module Hardware Reference
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JTAG Multi-Ice connector X13
How the CMO works
To measure the load current used on different power supplies, measure DC volt age across the sense (CMO) resistor. The value of the resistor is 0.025 the current using this equation:
where
I = current in Amps
U = measured voltage in Volts
R = 0.025 Ohms
JTAG interface
R ± 1%. Calculate
I = U/R
www.digiembedded.com 55
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard JTAG ARM connector, X13
The standard JTAG ARM connector is a 20-pin header and can be used to connect development tools such as Digi’s JTAG Link, ARM’s Multi-ICE, Abatron BDI2000, and others.
Pin Signal Pin Signal
1 +3.3V 2 +3.3V
3TRST# 4GND
5 TDI 6 GND
7TMS 8GND
9 TCK 10 GND
11 RTCK (optional) 12 GND
13 TDO 14 GND
15 SRESET# 16 GND
17 No connect 18 GND
19 No connect 20 GND
PoE module connectors - IEEE802.3af
The development board has two PoE module connectors, X9 and X26. The PoE module is an optional accessory item that can be plugged on the development board through the two connectors:
X9, input connector: Provides access to the PoE signals coming from the
Ethernet interface.
X26, output connector: Provides the output power supply from the PoE
module.
56 NS9210 Processor Module Hardware Reference
. . . . .
PoE header,
X9
PoE header,
X26
Power Jack, X24
Jump Start development board
PoE module
The PoE module Plug in the PoE module at a right angle to the development board, as shown in this
drawing:
www.digiembedded.com 57
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X9 This is how the PoE input connector pins are allocated:
Pin Signal
1 POE_TX_CT
2 POE_RX_CT
3 POE_RJ45_4/5
4 POE_RJ45_7/8
X26 This is how the PoE output connector pins are allocated:
Pin Signal
1 +12V_PoE
2 +12V_PoE
3 GND
4 GND
5 PoE_GND
6 PoE_GND
POE_GND The develop ment board provides access to POE_GND allowing it to be turned off
when power is provided through Power Jack X26.4 and X26.5.
Power Jack, X24 The power jack is a barrel connector with 9-30VDC operating range. The power jack
is labeled X24 on the development board. This figure schematically represents the power jack’s polarity.
Ethernet interface
The module provides the 10/100 Ethernet PHY chip. The development board provides the 1:1 transformer and Ethernet connector.
The Ethernet connector is an 8-wire RJ-45 jack, labeled
X19, on the development
board. The connector has eight interface pins, as well as two integrated LEDs that provide link status and network activity information.
58 NS9210 Processor Module Hardware Reference
. . . . .
Ethernet RJ-45, X19
RJ-45 pin
RJ-45 connector pins are configured as shown:
allocation, X19
Pin Signal 802.3af End-Span (mode A) 802.3af Mid-Span (Mode B) Description
1 TXD+ Negative V
2TXD- Negative V
3 RXD+ Positive V
Port
Port
Port
4 EPWR+ Positive V
5 EPWR+ Positive V
6 RXD- Positive V
Port
7 EPWR+ Negative V
8 EPWR+ Negative V
Port
Port
Port
Port
Transmit data +
Transmit data -
Receive data +
Power from switch +
Power from switch +
Receive data -
Power from switch -
Power from switch -
www.digiembedded.com 59
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Peripheral Application Header, X33
LEDs The RJ-45 connector has two LEDs located near the outer lower corners of the
connector. These LEDs are not programmable.
LED Description
Yellow Network activity (speed): Flashing when network traffic detected; Off when no network
traffic detected.
Green Network link: On indicates an active network link; Off indicates that no network link is
present.
Peripheral (expansion) headers
60 NS9210 Processor Module Hardware Reference
The development board provides one, 2x25-pin, 0.10” (2.54mm) pitch header for supporting application-specific daughter cards/expansion boards:
X33, Peripheral application header. Provides access to an 16-bit data bus, 10-
2
bit address bus, and control signals (such as CE#, IRQ#, WE#), as well as I
C and power (+3.3V). Using these signals, you can connect Digi-specific extension modules or your own daughter card to the module’s address/data bus.
. . . . .
Peripheral application header, X33
Peripheral application pins are allocated as shown:
Pin Signal Pin Signal
1GND 2BDO
3BD1 4BD2
5BD3 6GND
7BD4 8BD5
9BD6 10BD7
11 GND 12 BD8
13 BD9 14 BD10
15 BD11 16 GND
17 BD12 18 BD13
19 BD14 20 BD15
21 GND 22 * 8-bit / 16-bit#
GND selects 16-bit data bus
23 GND 24 +3.3V
25 +3.3V 26 BA0
27 BA1 28 BA2
29 BA3 30 GND
31 BA4 32 BA5
33 BA6 34 BA7
35 GND 36 BA8
37 BA9 38 GND
39 EXT_CSO# 40 I2C_SDA/GPIO103
41 EXT_WE# 42 EXT_OE#
43 I2C_SCL/GPIO102 44 EIRQ3/GPIO101
45 +3.3V 46 +3.3V
47 GPIO86 48 GPIO87
49 EXT_CLK 50 GND
www.digiembedded.com 61
Chapter 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module
connector,
X1
Module
connector,
X2
Test
connector,
X20, X21
Test
Connector,
X10, X11
Module and test connectors
The NS9210 Processor Module plugs into the module connectors X1 and X2 on the development board.
Module connectors
See “Module pinout” on page 12 for related information.
Test connectors The development board provides two 4x20 pin test connectors, labeled X10/X11 and
X20/X21. These connectors are 1:1 copies of the module pins and are used for measurement or test purposes.
X10 and X11 correspond to module connector X1. X20 and X21 correspond to module connector X2.
62 NS9210 Processor Module Hardware Reference
X10 pinout
. . . . .
X10 pin Signal X10 pin Signal
A1 GND B1 GND
A2 RSTOUT# B2 TCK
A3 TDO B3 TRST#
A4 LITTLE#/BIG_ENDIAN B4 WLAN_DISABLE#
A5 SW_CONF2 B5 SW_CONF3
A6 BD0 B6 BD1
A7 BD4 B7 BD5
A8 BD8 B8 BD9
A9 BD12 B9 BD13
A10 GND B10 BA0
A11 BA3 B11 BA4
A12 BA7 B12 BA8
A13 BA11 B13 BA12
X11 pinout
A14 BA15 B14 BA16
A15 EXT_WE# B15 EXT_CS0#
A16 BE3# B16 EXT_WAIT#
A17 (ETH_TPIN) NC B17 NC (ETH_ACTIVITY#)
A18 (ETH_TPON) NC B18 NC (ETH_TPOP)
A19 Reserved* B19 Reserved*
A20 Reserved* B20 VBAT
*USB signals are reserved for future use.
X11 pin Signal X11 pin Signal
C1 RSTIN# D1 SRESET#
C2 TMS D2 TDI
C3 RTCK D3 OCD_EN#
C4 SW_CONF0 D4 SW_CONF1
C5 (WLAN_LED#) Reserved D5 GND
C6 BD2 D6 BD3
C7 BD6 D7 BD7
C8 BD10 D8 BD11
C9 BD14 D9 BD15
www.digiembedded.com 63
Chapter 2
X11 pin Signal X11 pin Signal
C10 BA1 D10 BA2
C11 BA5 D11 BA6
C12 BA9 D12 BA10
C13 BA13 D13 BA14
C14 GND D14 EXT_OE#
C15 EXT_CS2# D15 BE2#
C16 EXT_CLK D16 GND
C17 (ETH_TPIP) NC D17 NC (ETH_LINK#)
C18 GND D18 Reserved*
C19 Reserved* D19 Reserved*
C20 3.3V D20 GND
*USB signals are reserved for future use.
X20 pinout
X20 pin Signal X20 pin Signal
A1 GND B1 GND
A2 DSRA#/GPIO2 B2 RXDA/SPI_RXD/GPIO3
A3 DTRA#/GPIO6 B3 TXDA/SPI_TXD/GPIO7
A4 DSRC#/GPIO10 B4 RXDC/GPIO11
A5 DTRC#/TXCLKC/GPIO14 B5 TXDC/GPIO15
A6 DSRB#/GPIO53 B6 RXDB/GPIO54
A7 DTRB#/GPIO57 B7 TXDB/GPIO58
A8 DSRD#/GPIO61 B8 RXDD/GPIO62
A9 DTRD#/GPIO65 B9 TXDD/GPIO66
A10 GPIO69 B10 GPIO70
A11 GPIO73 B11 GPIO74
A12 GPIO77 B12 GPIO78
A13 USER_BUTTON1#/GPIO81 B13 USER_LED1#/GPIO82
A14 USER_LED2#/GPIO85 B14 GPIO86
A15 GPIO94 B15 GPIO95
A16 CAN1_RXD/GPIO98 B16 CAN1_TXD/GPIO99
A17 I2C_SCL/GPIO102 B17 12C_SDA/GPIO103
A18 ADC_IN2 B18 ADC_IN3
64 NS9210 Processor Module Hardware Reference
X21 pinout
. . . . .
X20 pin Signal X20 pin Signal
A19 ADC_IN6 B19 ADC_IN7
A20 +3.3V B20 +3.3V
X21 pin Signal X21 pin Signal
C1 DCDA#/SPI_EN/GPIO0 D1 CTSA#/GPIO1
C2 RIA#/EIRO2/GPIO4 D2 RTSA#/SPI_CLK/GPIO5
C3 DCDC#/TXCLKC/GPIO8 D3 CTSC#/GPIO9
C4 RIC#/RXCLKC/GPIO12 D4 RTSC#/RCLKC/GPIO13
C5 DCDB#/GPIO51 D5 CTSB#/GPIO52
C6 RIB#/GPIO55 D6 RTSB#/GPIO56
C7 DCDD#/GPIO59 D7 CTSD#/GPIO60
C8 RID#/GPIO63 D8 RTSD#/GPIO64
C9 GPIO67 D9 GPIO68
C10 GPIO71 D10 GPIO72
C11 GPIO75 D11 GPIO76
C12 GPIO79 D12 GPIO80
C13 GPIO83 D13 USER_BUTTON2#/GPIO84
C14 GPIO87 D14 GPIO93
C15 CAN0_RXD/GPIO96 D15 CAN0_TXD/GPIO97
C16 GPIO100 D16 EIR03#/GPIO101
C17 ADC_IN0 D17 ADC_IN1
C18 ADC_IN4 D18 ADC_IN5
C19 AGND_ADC D19 VREF_ADC
C20 GND D20 GND
www.digiembedded.com 65
Chapter 2
66 NS9210 Processor Module Hardware Reference
Appendix A:Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
This appendix provides NS9210 Processor Module and elec trical specifications, as
well as module and development board mechanical specifications.
Environmental specifications
The module board assembly meets all functional requirements when operating in this environment:
Operating temperature: -40°C to +85°C Storage temperature: -40°C to +125°C Relative humi dity: 5% to 95%, non-condensing Altitude: 0 to 12,000 feet
Mechanical specifications
The module size is 50 x 50mm. Two board-to-board connectors are used on the module. The distance between the
module and the base board depends on the counterpart on the base board. The minimum distance is 5mm.
The height of the parts mounted on the bottom side of the module should not exceed 2.5mm. The height of the parts mounted on the top side of the module should not exceed 4.1mm.
Safety statements
To avoid contact with electrical current:
Never install electrical wiring during an electrical storm.
67
A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use a screwdriver and other tools with insulated handles. Wear safety glasses or goggles. Installation of inside wiring may bring you close to electrical wire, conduit,
terminals and other electrical facilities. Extre me caution must be used to avoid electrical shock from such facilities. Avoid contact with all such facilities.
Protectors and grounding wire placed by the service provider must not be
connected to, removed, or modified by the customer.
Do not touch or move the antenna(s) while the unit is transmitting or receiving. Do not hold any component containing a radio such that the antenna is very
close to or touching any exposed parts of the body, especially the face or eyes, while transmitting.
Do not operate a portable transmitter near unshielded blasting caps or in an
explosive environment unless it is a type especially qualified for such use.
Any external communications wiring you may install needs to be constructed to
all relevant electrical codes. In the United States, this is the National Electrical Code Article 800. Contact a licensed electrician for details.
Power requirements
Parameter Limits
Input voltage (Vcc) 3.3V±5% (3.00V to 3.60V)
Input current 554mA max
Input low voltage 0.0V <V
Input high voltage 0.7*Vcc <V
Output low voltage 0.0V <V
Output high voltage Vcc-0.4V <V
IL
IH
OL
OH
<0.3*Vcc
<Vcc
<0.4V
<Vcc
68 NS9210 Processor Module Hardware Reference
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical module current / power measurements
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The following illustrates typical power consumption when all clocks are active and the ethernet is connected to a 100Mb network.
With FIMs (DRPIC) enabled
With FIMs (DRPIC) disabled
1
VLIO is supplying the core voltage regulator. This value is reached when all clocks are on. This typ-
ical measurement was made with VLIO set to 3.3V. VLIO can vary between 2.5V to 5.0V.
2
This value is reached when Ethernet is activated. This typical measurement was made with +3.3V set
to 3.3V. +3.3V can vary between 3.1V to 3.6V.
3
FIM is the Flexible Interface Module.
4
DRPIC is a High performance 8-bit RISC Microcontroller.
3, 4
3, 4
1
VLIO
1.27 (384mA @ 3..3V) .561W (170mA @ 3.3V) 1.83W
.904W (274mA @ 3.3V) .561W (170mA @ 3.3V) 1.47W
+3.3V
2
Total Power
Typical power save module / JumpStart board current /
. . . . .
power consumption measurements
The following table illustrates typical power consumption using various NS9215 power management mechanisms. These measurements were taken with all NS9215 I/O clocks disabled except UART B, UART D, Ethernet MAC, I/O Hub, and the Memory Clock0 and the ethernet connected to a 100Mb network, using a standard module plugged into a JumpStart Kit board, with nominal voltage applied:
Module and Dev Baoard
Normal operational mode
Full clock scaling mode
Sleep mode
5
1
This measurement was taken from the R80 current sense resistor (0.025 ohm) on the JumpStart Kit
development board.
2
This measurement represents only the current of the VLIO and +3.3V inputs to the module, measured from the two current sense resistors R81 and R94 (0.025 ohm) located on the JumpStart Kit develop­ment board.
3
This is the default power consumption mode when entering applicationStart(), as measured with the napsave sample application. The value of the NS9215 Clock Configuration register (A090017C) is 02012015 hexadecimal.
4
This measurement was produced by selecting the "Clock Scale" menu option in the napsave sample application.
5
This measurement was produced by selecting the "Deep Sleep/Wakeup with an External IRQ" menu option in the napsave sample application.
3
4
1.63W (496mA) 1.45W (443mA)
.879W (267mA) .683W (208mA)
.346W (105mA) .151W (46mA)
1
Module only
2
www.digiembedded.com 69
A
Module, top view
Note:
Measurements are in millimeters.
Module, side view
Note:
Measurements are in millimeters.
70 NS9210 Processor Module Hardware Reference
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Layout recommendation
BOTTOM View
TOP View
2x Ӆ2.20
3.00 44.00
50.00
3.0044.00
50.00
X1 X2
29.50
2.50
3.75
1.40
41.00
6.00
max 2.2mm
max 3mm
13.55
X3
SIDE View
41.00
12
79 80 8079
1
2
Below are the mechanical dimensions of the standard NS9210 Processor Module. The layout of the NS9210 Processor Module JumpStart board is consistent with the
recommendations from Berg/FCI for the mating connector (Berg/FCI 61083­084409LF). There is a 41mm separation between the two module connectors. Drawing number 61083 on the FCI web page: www.fciconnect.com shows the manufacturer recommended layout.
. . . . .
www.digiembedded.com 71
A
Device Berg/FCI connector
NS9210 Processor Module 61082-081409LF
NS9210 Processor Module JumpStart board
(mating connector on the base board)
72 NS9210 Processor Module Hardware Reference
61083-084409LF
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reset and edge sensitive input timing requirements
negative edge input
t
F
max = 500nsec
V
IN
= 2.0V to 0 .8V
t
F
reset_ n or p o s itive e d g e in p ut
t
R
max = 500nsec
V
IN
= 0.8V to 2 .0V
t
R
The critical timing requirement is the rise and fall time of the input. If the rise time is too slow for the reset input, the hardware strapping options may be registered incorrectly. If the rise time of a positive-edge-triggered external interrupt is too slow, then an interrupt may be detected on both the rising and falling edge of the input signal.
A maximum rise and fall time must be met to ensure that reset and edge sensitive inputs are handled correctly. With Digi processors, the maximum is 500 nanoseconds as shown:
. . . . .
www.digiembedded.com 73
On the NS9210 Processor Module JumpStart there was a measurement of 220ns rise time and 10ns fall time.
A
74 NS9210 Processor Module Hardware Reference
Appendix B:Certifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The NS9210 Processor Module product complies with the standards cited in this
section.
FCC Part 15 Class B
Radio Frequency Interface (RFI) (FCC 15.105)
The NS9210 Processor Module has been tested and found to comply with the limits for Class B digital devices pursuant to Part 15 Subpart B, of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communication s. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outl et on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Labeling Requirements (FCC 15.19)
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
75
B
If the FCC ID is not visible when installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module FCC ID. THis exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: MCQ-50M1355/ IC: 1846A­50M1355”.
Modifications (FCC 15.21)
Changes or modifications to this equipment not expressly approved by Digi may void the user’s authority to operate this equipment.
Industry Canada
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les limites applicables aux appareils numeriques de la class B prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des Communications du Canada.
76 NS9210 Processor Module Hardware Reference
Declaration of Conformity
(In accordance with FCC Dockets 96-208 and 95-19)
Manufacturer’s Name: Digi International Corporate Headquarters: 11001 Bren Road East
Manufacturing Headquarters: 10000 West 76th Street
Digi International declares, that the product:
Product Name NS9210 Processor Module Model Numbers: FS-3029
. . . . .
Minnetonka MN 55343
Eden Prairie MN 55344
FS-3038
to which this declaration relates, meets the requirements specified by the Federal Communications Comm ission as detailed in the following specifications:
Part 15, Subpart B, for Class B equipment FCC Docket 96-208 as it applies to Class B personal Personal computers and peripherals
The product listed above has been tested at an External Test Laboratory certified per FCC rules and has been found to meet the FCC, Part 15, Class B, Emission Limits. Documentation is on file and available from the Digi International Homologation Department.
www.digiembedded.com 77
B
International EMC Standards
The NS9210 Processor Module meets the following standards:
Standards NS9210 Processor Mod ule
Emissions FCC Part 15 Subpart B
Immunity EN 55022
Safety UL 60950-1
ICES-003
EN 55024
CSA C22.2, No. 60950-1
EN60950-1
78 NS9210 Processor Module Hardware Reference
80 ConnectCore 9P 9215 Hardware Reference
Loading...
