Page 1
WFT22
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
WiFi Vaccine Temperature Data Logger
_________________________________________________________________________________________________
Specifications
Alarm Type: Phone Call, SMS Text, Email, Audible
Ambient Operating RH Conditions : 0-95% RH non-condensing (Logger only)
Ambient Operating Temperature Conditions: -22 to 122F (-30 to 50C)
Antenna Type: External
Approvals: RoHS, FCC Part 15 Compliance, CE
Battery Backup: 4 AA Batteries
Battery Life (Avg): 72 hours
Calibration Options: N100 , N300, N400, & N520
Channels: CH1: Temperature, CH2: Temperature
Data Capacity: 32,000 (16,000 per channel); Backup
Digital Display: Yes
Dimensions: 1.7 x 4.25 x 4.25in
Download Type: Wireless
Enclosure: Black; ABS Plastic Clam Shell
IP Rating: 21
Included Accessories: USB Cable, AC Adapter, 2-Probe with Glycol Bottle, 4 AA Batteries
Mounting Options: Free Standing or Wall Mount (With Keyhole)
Note on Alarm Type: Alarms can be created for scenarios where the readings are outside a given range, communication
has been lost, or the batteries are low. All paid accounts are eligible to receive email and SMS text alarm notifications.
PC Requirements: Minimum of 2 GB RAM; Windows XP (with service pack 3) and Windows 7; 2 available USB ports
Power Cord: 6 ft
Power Source: 120 to 240 VAC, 12 VDC (INTL fittings available)
Power Source Input: AC 100-240 0.5V 60/50 Hz
Power Source Output: DC 9V, 1A
Power Status Indicator: Red/Green/Blue (RGB) LED
Radio Frequency: 2.4 GHZ
Remote Sensor Length: 6 ft (up to 3 extension cables can be added without sacrificing accuracy)
Response Time: 30 Seconds to 63% of Full Scale
Sample Interval: User Selectable from: 60 seconds, 90 seconds, 2 minutes, 5 minutes, 10 minutes, 30 minutes, 1 hour
Software Options: All DicksonOne Data Loggers must be connected to a DicksonOne subscription to function correctly.
Storage Conditions: -22 to 158F (-30 to 70C)
Storage Conditions RH: 0-95% RH non-condensing
Temperature Accuracy: +/-0.9F from -58 to 68F (+/-0.5C from -50 to 20C); +/-1.2F from 69 to 122F (+/-0.7F from 21 to
50C)
Temperature Accuracy (Remainder of Range): +/-2F (+/-1C)
Temperature Range: -58 to 158F (-50 to 70C)
Temperature Sensor Type: Field Replaceable Thermistor hard wired to PBC, submersible tip sealed in leak-proof glycol
bottle Glycol will freeze at -55F
Unit Weight: 3 lbs
Units/Pkg: 1
Page 2
WFT22
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories WFT22
Replaceable Sensor
Dual Thermistor Replaceable Temperature Sensor
DicksonOne IQOQ Validation Package
DicksonOne IQOQ Validation Package
Certificate of Validation
Certificate of Validation
Page 3
Page 4
Glycol Bottle
Bottle of Propylene Glycol Solution - dampen temperature swings.
AC Adapter
AC Adapter
Universal Plug Kit for AC Adapter
Set of Three International Power Plugs for AC Adapter
_________________________________________________________________________________________________
Page 5
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
N400 3-Point Ultima NIST A2LA Accredited Calibration
