TC700
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Touchscreen Hand-Held Indicator
_________________________________________________________________________________________________
Specifications
Ambient Operating Temperature Conditions: 0 to 122F (-18 to 50C)
Approvals: CE
Cable Length: 5ft (5ft)
Calibration Point/s Checked: N100, N300, N400
Digital Display: Transflexive Display
Dimensions: 5.7 x 2.7 x 1inch (14.4 x 6.8 x 2.7cm)
Display Resolution: 0.1° resolution to 999.9; 1°resolution above 1000
Display Update Rate: 1 per second
Power Source: 9V battery
Response Time: 10 seconds for full scale
Temperature Accuracy: +/-1.8F from -22 to 122F 3.8F (+/-1C from -30 to 50C 2.1C)
Temperature Range: -200 to 1999F (-128 to 1093C)
Temperature Sensor Type: K-Thermocouple
Page 2
TC700
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories TC700
Page 3
Page 4
Temperature Probe
6" (15cm) High Temperature Immersion Probe
_________________________________________________________________________________________________
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
N400 3-Point Ultima NIST A2LA Accredited Calibration
