High Temperature Process Logger
Page 2
Page 3
_________________________________________________________________________________________________
Specifications
Approvals: CE
Battery Life (Avg): 9 months (at 1 Minute Sample Rate, Ambient Temperature)
Cable Details: USB - Male Series A plug to 5 pin Male Series B mini plug
Calibration Options: N100, N300, N400, N520
Channels: CH1: Temperature
Data Capacity: 32,512 Sample Points
Dimensions with Flat Cap: 2.1” x 3.0” DIA (5.4 x 7.7cm)
Dimensions with Handled Cap: 2.75” x 3.0” DIA (7.0 x 7.7cm)
Download Time: 1 Minute (Approximate)
Download Type: USB
Enclosure: FDA Compliant Glass Filled PBT
IP Rating: 67
Included Accessories: Tadiran Battery and Quick Start Guide (Software not included)
PC Requirements: Microsoft Windows XP or higher, 1 free USB root hub, and CD Drive
Power Source: High Energy Lithium Tadiran Battery 2/3 AA (User Replaceable) TLH-5944
Response Time: 15 Minutes to move 63% of Full Scale
Sample Interval: User Selectable (from 1 second to 24 hour intervals, in 1 second increments)
Software Options: A016, A026
Temperature Accuracy: +/-1.8F from -22 to 122F 3.8F (+/-1C from -30 to 50C 2.1C)
Temperature Range: -40 to 257F (-40 to 125C)
Temperature Range Note: Probe Temperature Range = -300 to 2000F (-184 to 1093C) (Standard Bead Wire: Max 500F)
Temperature Sensor Type: K-Thermocouple
Unit Weight: .75lb (12oz)
Units/Pkg: 1
Warranty: 12-Month Limited
Page 4
HT350
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories HT350
Software
DicksonWare Software with USB Cable
Secure Software
DicksonWare Secure Software with USB Cable
Certificate of Validation
Certificate of Validation
Battery TLH-5955
Tadiran TLH-5955 Ht200/220/225
Probe Extension
K-Thermocouple 10' (3m) Extension Cable
Page 5
Page 6
Temperature Probe
6" (15cm) High Temperature Immersion Probe
Page 7
HT350
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories HT350
Shielded Immersion Probe
15' (4.5m) Shielded Thermocouple with 4" (10cm) stainless steel tip
Piercing Probe
4" (10cm) Thermocouple Handled Piercing Probe
_________________________________________________________________________________________________
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
N400 3-Point Ultima NIST A2LA Accredited Calibration
