Page 1
FT625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Touchscreen
_________________________________________________________________________________________________
Specifications
Alarm Type: Audio/Visual
Ambient Operating RH Conditions : 0 to 95% RH non-condensing (Logger Only)
Ambient Operating Temperature Conditions: 0 to 122F (-18 to 50C)
Battery Backup: 12 Hrs (Re-chargeable batteries included; Hardwired)
Cable Details: USB - Male Series A plug to 5 pin Male Series B mini plug.
Calibration Options: N100 , N300, N400, & N520
Channels: CH1: Temperature; CH1: Temperature (F/C)
Data Capacity: 32,000
Dimensions: 1.4 x 8.5 x 6.9in (3.5 x 21.6 x 17.5cm)
Display Dimensions Height: 5
Display Dimensions Width: 6.4
Display Type: Touchscreen
Display Update Rate: Varies with logging interval
Displays Min/Max: Yes
Download Type: USB / Flash Card
Flash Card Option: SD Card (2GB or less)
IP Rating: 21
Key Features: Touchscreen, multiple screen views, on-screen zoom and scroll, software optional, user customizable
sample rate, temperature scales and unit of measure
Minimum Software Version Required: 17.2.0
Mounting Options: Mounting Bracket (Included)
Power Cord: 6 ft
Power Source: 120 to 240 VAC, 12 VDC (INTL adapters available)
Probe Cable: .110 inch diameter (cord only); .190 inch (probe tip only)
Probe Tip Length: 4inches
Remote Sensor Length: 10 ft (single 10 ft extension cable available without sacrificing accuracy)
Remote Sensor Type: Field Replaceable with 1 Thermistor
Required Software: A016, A026, N525 (all optional)
Response Time: 1 Minute to 63% of Full Scale
Sample Interval: User Selectable via Time Scale (See Product Manual for more details)
Temperature Accuracy: +/-0.8F from -20 to 176F 1.2F (+/-0.44C from -28 to 80C 0.7C)
Temperature Range: -40 to 300F (-40 to 149C)
Unit Weight: 1.15 lbs
User Calibration with SW400: Yes
Warranty: 12-Month Limited
Page 2
FT625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories FT625
Replaceable Sensor
Stainless Steal Thermistor Replaceable Temperature Sensor
Software
DicksonWare Software with USB Cable
Secure Software
DicksonWare Secure Software with USB Cable
Calibration Software
Logger Calibration Software
Page 3
Page 4
Memory Card
Removable Flash Memory Card
Card Reader Kit
Includes USB Reader and Flash Memory Card
Page 5
FT625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories FT625
AC Adapter
AC Adapter
Universal Plug Kit for AC Adapter
Set of Three International Power Plugs for AC Adapter
Page 6
Page 7
AC Adapter Extension Cable
10' Power Extension for AC Adapter
_________________________________________________________________________________________________
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
N400 3-Point Ultima NIST A2LA Accredited Calibration
