Page 1
FH625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Touchscreen
_________________________________________________________________________________________________
Specifications
Alarm Type: Audio/Visual
Ambient Operating RH Conditions : 0 to 95% RH non-condensing (Logger Only)
Ambient Operating Temperature Conditions: 0 to 122F (-17 to 50C)
Battery Backup: 12 Hrs (Re-chargeable batteries included; Hardwired)
Cable Details: USB - Male Series A plug to 5 pin Male Series B mini plug.
Calibration Options: N100 , N300, N400, & N520
Channels: CH1: Temperature (F/C), CH2: Humidity
Data Capacity: 32,000 (16,000 per channel)
Dew Point Accuracy: +/-3.6F from 30 to 95% RH (Calculated) (+/-2C from 30 to 95% RH (Calculated))
Dimensions: 1.4 x 8.5 x 6.9in (3.5 x 21.6 x 17.5cm)
Display Dimensions Height: 5
Display Dimensions Width: 6.4
Display Type: Touchscreen
Display Update Rate: Varies with logging interval
Displays Min/Max: Yes
Download Type: USB / Flash Card
Flash Card Option: SD Card (2GB or less)
Humidity Accuracy: +/-2% RH from 0 to 60% (+/-3% RH from 60 to 95%)
Humidity Range: 0-95% RH non-condensing
IP Rating: 21
Key Features: Touchscreen, multiple screen views, on-screen zoom and scroll, software optional, user customizable
sample rate, temperature scales and unit of measure
Minimum Software Version Required: 17.2.0
Mounting Options: Mounting Bracket (Included)
Power Cord: 6 ft
Power Source: 120 to 240 VAC, 12 VDC (INTL adapters available)
Remote Probe Dimensions : Houses thermistor and RH sensor in polycarbonate plastic; 2.12" x 1.2" x .5"
Remote Sensor Length: Single 10 ft extension cable available (without sacrificing accuracy)
Remote Sensor Type: 1 Field Replaceable Digital Temperature/RH Sensor
Required Software: A016, A026, N525 (all optional)
Response Time: 1 Minute to 63% of Full Scale
Sample Interval: User Selectable via Time Scale (See Product Manual for more details)
Temperature Accuracy: +/-0.8F from 20 to 122F 1.8F Remaining (+/-0.45C from -6 to 50C 1C Remaining)
Temperature Range: -40 to 185F (-40 to 85C)
Unit Weight: 1.15 lbs
User Calibration with SW400: Yes
Warranty: 12-Month Limited
Page 2
FH625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories FH625
Replaceable Temperature/Humidity Sensor
Angled Temperature/Humidity Replaceable Sensor
Software
DicksonWare Software with USB Cable
Secure Software
DicksonWare Secure Software with USB Cable
Sensor Dust Filter
Sensor Dust Filter - prolong the life of your sensor.
Probe Extension Cable
10' Extension Probe for Angled Pre-Calibrated Sensor
Calibration Software
Logger Calibration Software
Page 3
FH625
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories FH625
Page 4
Page 5
Memory Card
Removable Flash Memory Card
Certificate of Validation
Certificate of Validation
Card Reader Kit
Includes USB Reader and Flash Memory Card
AC Adapter
AC Adapter
Universal Plug Kit for AC Adapter
Set of Three International Power Plugs for AC Adapter
Page 6
Page 7
AC Adapter Extension Cable
10' Power Extension for AC Adapter
_________________________________________________________________________________________________
Page 8
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
N400 3-Point Ultima NIST A2LA Accredited Calibration
