ENT25
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Ethernet Temperature Data Logger
_________________________________________________________________________________________________
Specifications
Alarm Type: Phone Call, SMS Text, Email, Audible
Ambient Operating RH Conditions : 0-95% RH non-condensing (Logger only)
Ambient Operating Temperature Conditions: -22 to 122F (-30 to 50C)
Approvals: RoHS, CE
Battery Backup: 4 AA Batteries
Battery Life (Avg): 72 hours
Cable Details: CAT5e Ethernet
Cable Length: 6ft
Calibration Options: N100 , N300, N400, & N520
Channels: CH1: Temperature
Data Capacity: 32,000 (Backup)
Digital Display: Yes
Dimensions: 1.7 x 4.25 x 4.25in
Download Type: Ethernet (Automatic)
Enclosure: Black; ABS Plastic Clam Shell
IP Rating: 21
Included Accessories: Ethernet Cable, AC Adapter, 1-RTD Probe, 4 AA Batteries
Mounting Options: Free Standing or Wall Mount (With Keyhole)
Note on Alarm Type: Alarms can be created for scenarios where the readings are outside a given range, communication
has been lost, or the batteries are low. All paid accounts are eligible to receive email and SMS text alarm notifications.
PC Requirements: DicksonOne.com can be accessed from any Windows, Mac, or Linux PC/Laptop using Google
Chrome, FireFox, Safari, or Internet Explorer 9. WiFi loggers need a Windows PC with .Net 4.0 or newer for initial
configuration. WiFi loggers are compatible with WEP, WPA, and WPA2 Personal security protocols.
Power Cord: 6 ft
Power Source: 120 to 240 VAC, 12 VDC (INTL fittings available)
Power Source Input: AC 100-240 0.5V 60/50 Hz
Power Source Output: DC 9V, 1A
Power Status Indicator: Red/Green/Blue (RGB) LED
Remote Sensor Length: 6 ft
Remote Sensor Type: 1 Platinum RTD Probe (Hard-Wired)
Response Time: 30 Seconds to 63% of Full Scale
Sample Interval: User Selectable from: 60 seconds, 90 seconds, 2 minutes, 5 minutes, 10 minutes, 30 minutes, 1 hour
Software Options: All DicksonOne Data Loggers must be connected to a DicksonOne subscription to function correctly
Storage Conditions: -22 to 122F (-30 to 50C)
Storage Conditions RH: 0-95% RH non-condensing
Temperature Accuracy: +/-0.5F from -148 to 350F (+/-0.3C from -100 to 176C)
Temperature Range: -148 to 350F (-100 to 176C)
Temperature Sensor Type: Field Replaceable with RTD
Unit Weight: 3 lbs
Units/Pkg: 1
Page 2
ENT25
Phone: 1-800-757-3747 | Fax: 1-800-676-0498 | Email: dicksoncsr@dicksondata.com | For calls outside the US please call: 1-630-543-3747
_________________________________________________________________________________________________
Accessories ENT25
Replaceable Sensor
Platinum RTD Replaceable Temperature Sensor
DicksonOne IQOQ Validation Package
DicksonOne IQOQ Validation Package
Certificate of Validation
Certificate of Validation
Page 3
Page 4
Glycol Bottle
Bottle of Propylene Glycol Solution - dampen temperature swings.
AC Adapter
AC Adapter
Universal Plug Kit for AC Adapter
Set of Three International Power Plugs for AC Adapter
_________________________________________________________________________________________________
Page 5
Calibrations
N100 1-Point NIST Traceable Calibration
N300 3-Point NIST Traceable Calibration
