Diamond Multimedia TVW650USB Specification Sheet
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU TVW650USB
BRAND TVW650
February 4, 2011 - 6:25 am
ENG APVD - LK 2008-01-31
MRKTG APVD - LL 2008-01-31
SKU TVW650USB
SYSTEM BUILDER SKU
PRODUCT AMD ATI TV Wonder HD 650 Combo USB
PRODUCT DETAILED DESCRIPTION The ATI TV Wonder™ HD 650 Combo USB TV tuner loads your system with a complete set of media abilities,
transforming your PC or notebook into the ultimate entertainment system. The tuner is flexible enough to be used with
either your laptop or desktop PC, and is a great complement for watching TV in Windows® Media Center. Attach an
amplified high definition antenna or your analog TV cable2and you can watch, pause, or record high definition TV on your
PC. Even analog TV is made brilliant by the advanced 3D Comb Filter that produces a high-end television and video
content experience with true-to-life images. The Motion Adaptive 3D Comb Filter, Edge Enhancement and Noise
Reduction work together to produce an ultra sharp, pure image that rivals high-end TV sets.Your ATI TV Wonder™ 650 is
a high-speed USB device that lets you enjoy over the air digital (ATSC) TV broadcasts on your laptop or PC computer.
You can also receive analog (NTSC) broadcasts by connecting your home\'s TV cable line or external antenna to your ATI
TV Wonder™ 650.
TV Wonder Parental Control Notice
PRODUCT FEATURES Two built-in tuners offering combo tuning for:
●
Over-the-air Digital TV / HDTV (ATSC)
●
Over-the-air / Cable Analog TV (NTSC)
●
Clear-QAM (unscrambled) Digital HD Cable
●
FM Radio
ATI Theater™ Video Processing Technology
●
Hardware MPEG-2 compression
●
Motion Adaptive 3D Comb Filter
●
Automatic Color Control
●
Automatic Gain Control
●
Noise Reduction
●
Edge Enhancement
ATI Catalyst Media Center™ featuring:
●
Full PVR and time shifting functionality
●
DVD Playback Software
●
DVD Authoring Software
●
ATI Theater™ Video Converter
AMD LIVE!™ CD featuring AMD LIVE! On Demand
PRODUCT SPECIFICATIONS
●
USB 2.0 Interface
●
F-Type Coax input for Analog TV / FM Radio
●
F-Type Coax input for HDTV (ATSC or ClearQAM)
●
S-video input
●
Stereo audio input
●
Composite video input
SYSTEM REQUIREMENT
EXTERNAL POWER REQUIREMENT
CPU 2.0 Ghz or faster
CPU SPEED Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
MEMORY 512MB
HARD DISK 480MB available hard disk space
SYSTEM BUS 1 USB 2.0 & 1 USB for IR Remote
SLOT N/A
CHASSIS
MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
INTERNET ACCESS YES
USB YES
CD DVD YES
POWER SUPPLY
OPERATING SYSTEM WINXP WINXP64 WINVISTA32 WINVISTA64 MCE
FORM FACTOR
DIMENSIONS [PRODUCT] : 11.6875 X 8.9375 X 2.875 inches [RETAIL BOX] : 11.6875 X 8.9375 X 2.875 inches [S BUILDER] :
WEIGHT [PRODUCT WEIGHT] : .5 LBS [PRODUCT WITH CONTENT WEIGHT] : 2.5 LBS
UPC
RETAIL PACKAGE UPC : 757448005950
PACKAGE CONTENT
●
DIAMOND TV WONDER HD 650 COMBO USB
●
QUICK START GUIDE
●
INSTALL CD
●
AMD LIVE CD
●
USB EXTENSION CABLE
●
DIAMOND WARRANTY CARD
PRODUCT WEBPAGE http://www.diamondmm.com/TVW650USB.php
