Diamond Multimedia MSPBT300 User Manual

1. On/off: in OFF position, switch to "MP3" , MP3 playback is ready.

2. Music play: Insert TF card in TF card port as shown below.
Music begins to play. The orange light flashes followed by short click " ". For last
song, long press " " for the volume down, Short click " " for the next
song, long press " " for the volume up; Short click " " for pause.
Short click again " " for resuming music play

2

TF Card Mark

TF Card

TF

TF

/V-

/V+

/V+

Interface and slot diagram:

(1) Last song/volume down

(2) Play/pause (3) Speakers and mobile phone call switching

(4) Answer call (5) Next song/volume up (6) TF card port

(7) Audio input (8) Micro USB input (9) Headphone

(10) Bluetooth (11) Power switch (12) MP3

Playing Music with TF Card

/V-

10 11

12

1

/v-

/v+

MSPBT300

User Manual

1. Short click " " sign, and turn the conversation to your mobile phone,
Short click " " again, and return to Bluetooth speakers, if you want to hang up,
short click " " key.

1. You can simultaneously answer calls while listening to music by simply short clicking
the “ ” symbol. Listen to calls using the speaker.

1. On/off: in shutdown mode, switch to " " bluetooth symbol, blue light will flash,
Bluetooth connection ready.

2. Speaker and bluetooth:
A.Iphone mobile interface, for example

3 4





Equipment connection successful please put a tick "media opti ons", the
music can be played

/v-

/v+

/v-

/v+

Bluetooth operation

Click " Settings " Click " universal " Click : " Bluetooth "

Slide the right slider

open bluetooth

search to "MSPBT300"

equipment

click "disconnected"

connection finish

Note: 1. Can also be used with iPod/iPad. Basic operation shown above.

2. Also supports SONY, SAMSUNG, NOKIA, HTC and other smartphones.

* When the Bluetooth connection fails or mobile phone can't find Bluetooth devices, long click " "
this button for 15 seconds until the blue light stays on, then turn off and restart.

Bluetooth speakers operation

Bluetooth speaker phone

Calling

Clicking the above symbol can answer the phone

Switching between Bluetooth speakers and iPhone

MSPBT300 MSPBT300

5 6

USB

Micro USB

USB cable

1. From the "MP3" position, connect a micro USB cable from a computer to the speaker.

2. USB card read function: You can use the TF card to add/delete files from your computer.

3. USB charging function: connect the USB line, speaker starts to charge.

AUX Line

ipod

iphone

computer

AUX audio input

1. Use the AUX audio input to play music from your iPod, iPhone, MP3 player or computer

2. Short click "play/pause" for muting. If you want to switch to TF card mode or radio,
you must remove the AUX audio line first .

Bluetooth Speaker Sound source

Headphone operation

1. Insert the headset to headphone jack, and adjust volume to a comfortable level.

iPod, iPad and iPhone are registered trademarks of Apple Inc.
