DFI NB78-BL, NB78-BC User Manual

NB78-BC

NB78-BL

Rev. A+

System Board Users Manual

Carte Mère Manuel Pour Utilisateur

System-Platine Benutzerhandbuch Manual del Usuario de Placas Base

935-NB7801-000

64300230

This publication contains information that is protected by copyright. No part of it may be reproduced in any form or by any means or used to make any transformation/adaptation without the prior written permission from the copyright holders.

This publication is provided for informational purposes only. The manufacturer makes no representations or warranties with respect to the contents or use of this manual and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. The user will assume the entire risk of the use or the results of the use of this document. Fur ther, the manufacturer reserves the right to revise this publication and make changes to its contents at any time, without obligation to notify any person or entity of such revisions or changes.

Trademarks

Windows® 98 SE, Windows® ME, Windows® 2000, Windows NT

4.0 and Windows® XP are registered trademarks of Microsoft Corporation. Intel® and Pentium® 4 are registered trademarks of Intel Corporation. Award is a registered trademark of Award Software, Inc. Other trademarks and registered trademarks of products appearing in this manual are the properties of their respective holders.

Caution

To avoid damage to the system:  Use the correct AC input voltage range.

To reduce the risk of electric shock:  Unplug the power cord before removing the system chassis

cover for installation or ser vicing. After installation or servicing, cover the system chassis before plugging the power cord.

Battery:  Danger of explosion if battery incorrectly replaced.  Replace only with the same or equivalent type recommend by

the manufacturer.

 Dispose of used batteries according to the battery

manufacturers instructions.

Joystick or MIDI port:  Do not use any joystick or MIDI device that requires more than

10A current at 5V DC . There is a risk of fire for devices that exceed this limit.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to tr y to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and the receiver.  Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

 Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

2. Shielded interface cables must be used in order to comply with the emission limits.



Guide

Quick Setup

Quick Setup Guide

Table of Contents

Chapter 1

Quick Setup Guide.............................................

Chapter 2

English......................................................................

Chapter 3

Français (French).................................................

Chapter 4

Deutsch (German)................................................

Chapter 5

Español (Spanish)..................................................

Important:

This users manual is for the NB78-BC and NB78-BL system boards. The only difference between these boards is the NB78-BL system board supports onboard LAN

Quick Setup Guide

Chapter 1 - Quick Setup Guide

Table of Contents

1.1 System Board Layout..................................................................................................

1.2 Jumpers.....................................................................................................................................



Guide

Quick Setup

1.3 Real Panel I/O Ports ...............................................................................................

1.4 I/O Connectors...............................................................................................................

1.5 Award BIOS Setup Utility.......................................................................................

Note:

The users manual in the provided CD contains detailed information about the system board. If, in some cases, some information doesnt match those shown in this manual, this manual should always be regarded as the most updated version.



Quick Setup Guide

1.1 System Board Layout

Guide

Quick Setup

Mouse

USB 1

USB 2

COM 1 (CN6)

COM 2 (CN2)

Line

out

(CN3)

Line

(CN4)

Mic

(CN5)

Game/MIDI (CN9)

IrDA (J3)

I/O

chip

BIOS

Front audio (J1)

AC’97

CN1

CN7

Parallel (CN8)

CD-in (J5)

S/PDIF-out (J4)

CPU fan (J8)

+12V power

(ATXP1)

CPU FSB select (JP1)

PCI Slot 1

PCI Slot 2

PCI Slot 3

PCI Slot 4

PCI Slot 5

PCI Slot 6

Wake-On-LAN

AGP Slot

IDE 1 (J10)

IDE 2 (J11)

FDD (J12)

(J9)

Intel

845PE

MCH

Second fan (J15)

DDR 1

Socket 478

DIMM Standby

USB 5/6

USB 3/4

(JUSB1)

(JUSB2)

Power LED

Intel

ICH4

Clear CMOS

Chassis fan

(J14)

G-SW

SPEAKER

G-LED

DDR 2

AT X

power

(PL1)

(JP2)

Battery

RESET

ATX-SW

HD-LED

PWR-LED

J16

NB78-BC

Quick Setup Guide



Mouse

USB 1

USB 2

Line

out

(CN3)

Line

(CN4)

Mic

(CN5)

Game/MIDI (CN9)

IrDA (J3)

chip

BIOS

Front audio (J1)

AC’97

CN1

LAN

CPU fan (J8)

CN7

COM 1 (CN6)

Parallel (CN8)

COM 2 (CN2)

Realtek

RTL8100

I/O

CD-in (J5)

S/PDIF-out (J4)

+12V power

(ATXP1)

CPU FSB select (JP1)

AGP Slot

PCI Slot 1

PCI Slot 2

PCI Slot 3

PCI Slot 4

PCI Slot 5

PCI Slot 6

Wake-On-LAN

Intel

845PE

MCH

IDE 1 (J10)

IDE 2 (J11)

FDD (J12)

(J9)

Second fan (J15)

DDR 1

Socket 478

DIMM Standby

USB 3/4

USB 5/6

(JUSB1)

(JUSB2)

Power LED

Intel

ICH4

Clear CMOS

Chassis fan

(J14)

G-SW

SPEAKER

G-LED

DDR 2

AT X

power

(PL1)

(JP2)

Battery

RESET

ATX-SW

HD-LED

PWR-LED

Guide

Quick Setup

J16

NB78-BL

(Supports onboard LAN)

Note:

The illustrations on the following pages are based on the system board that supports onboard LAN.



Guide

Quick Setup Guide

1.2 Jumpers

1.2.1 Clear CMOS Data - JP2

Quick Setup

Clear CMOS

(JP2)

1.2.2 CPUs Front Side Bus - JP1

CPU FSB select

(JP1)

12 3

1-2 On: Auto

(default)

2-3 On: 100MHz

1-2 On: Normal (default)

2-3 On: Clear CMOS Data

All Off: 133MHz

Important:

Overclocking may result in the processors or systems instability and is not guaranteed to provide better system performance.

1.3 Rear Panel I/O Ports

Quick Setup Guide



PS/2

Mouse

PS/2

K/B

PS/2

Mouse

PS/2

K/B

RJ45 LAN

USB 2/1 COM 1

ATX Double Deck Ports on NB78-BL

USB 2

USB 1

COM 1 COM 2

ATX Double Deck Ports on NB78-BC

Parallel GAME/MIDI

COM 2

Parallel

Line-

Line-inMic-

out

GAME/MIDI

Line-

Line-inMic-

out

Guide

Quick Setup



Quick Setup Guide

1.3.1 PS/2 Mouse and PS/2 Keyboard Ports

Guide

Quick Setup

PS/2 Mouse

CN1

PS/2 Keyboard

Make sure to turn off your computer prior to connecting or disconnecting a mouse or keyboard. Failure to do so may damage the system board.

1.3.2 Universal Serial Bus Ports and LAN Port

RJ45 LAN

USB 2 USB 1

CN7

Additional USB Ports (USB 3 to USB 6)

1 5V_Dul 2 5V_Dul 3 Data- 4 Data5 Data+ 6 Data+ 7 Ground 8 Ground

9 Key 10 OC-

2 1

USB 3/4

(JUSB1)

Important:

Only the NB78-BL system board supports onboard LAN.

USB 5/6

(JUSB2)

1.3.3 Serial Ports

Quick Setup Guide



COM 1

Serial Port

1.3.4 Parallel Port

Parallel Port

COM 2

Serial Port

CN6

CN2

CN8

Guide

Quick Setup



Guide

Quick Setup

Quick Setup Guide

1.3.5 Audio Jacks and Game/MIDI ports

Game Port

Line-out

Line-in

Mic-in

CN9

2 1

Front audio

(J1)

Front Audio (J1)

1 Mic+ 2 Ground 3 Vbias 4 AuD_Vcc (Avcc) 5 AuD_R_Out 6 N. C. 7 N. C. 8 Key

9 AuD_L_Out 10 N. C.

1.4 I/O Connectors

1.4.1 CD-in Internal Audio Connectors

Quick Setup Guide



CD-in

1 Left audio channel 2 Ground 3 Ground 4 Right audio channel

1.4.2 S/PDIF-out Connector

1 AVDD5 2 N. C. 3 SPDIF 4 Ground

3 2 1

CD-in

(J5)

Guide

Quick Setup

1234

S/PDIF-out

(J4)



Guide

Quick Setup

Quick Setup Guide

1.4.3 Floppy & IDE Disk Drive Connector

IDE 1 (J10)

IDE 2 (J11)

FDD (J12)

2 1

If you encountered problems while using an ATAPI CD-ROM drive that is set in Master mode, please set the CD-ROM drive to Slave mode. Some ATAPI CD-ROMs may not be recognized and cannot be used if incorrectly set in Master mode.

1.4.4 IrDA Connector

1 VCC 2 N. C. 3 IRRX 4 Ground 5 IRTX

1234

IrDA (J3)

The sequence of the pin functions on some IrDA cable may be reversed from the pin function defined on the system board. Make sure to connect the cable to the IrDA connector according to their pin functions.

1.4.5 Fan Connector

Quick Setup Guide



CPU fan

(J8)

CPU Fan

1 Ground 2 Power 3N. C.

Chassis Fan

1 Ground 2 Power 3N. C.

Second fan

(J15)

Chassis fan

(J14)

Second Fan

1 Ground 2 Power 3N. C.

Guide

Quick Setup



Guide

Quick Setup

Quick Setup Guide

1.4.6 Wake-On-LAN Connector

1WOL 2 Ground 3 +5VSB

Wake-On-LAN

(J9)

The 5VSB power source of your power supply must support ≥720mA.

1.4.7 DIMM Standby Power LED

DIMM Standby Power LED

If the DIMM Standby Power LED is lighted, you must power-off the system then turn off the power supplys switch or unplug the power cord prior to installing any memory modules.

1.4.8 Power Connectors

Quick Setup Guide



+12V power

(ATXP1)

ATX Main Power Connector

1 2 3 4 5 6 7 8 9

Function

3.3V

3.3V Ground +5V Ground +5V Ground PW-OK 5VSB +12V

11 12 13 14 15 16 17 18 19 20

Function

3.3V

-12V Ground PS-ON Ground Ground Ground

-5V +5V +5V

Guide

Quick Setup

(PL1)

ATX po we r

+12V Power Connector

2 3 4

Function

Ground Ground +12V +12V



Guide

Quick Setup

Quick Setup Guide

1.4.9 Front Panel Connectors

HD-LED

RESET

SPEAKER

Front panel

connectors (J16)

G-SW

G-LED

ATX-SW

If a system did not boot-up and the Power/Standby LED did not light after it was powered-on, it may indicate that the CPU or memory module was not installed properly. Please make sure they are properly inserted into their corresponding socket.

PWR-LED

1 2

HD-LED

(Primary/Secondary IDE LED)

G-LED

(Green LED)

ATX-SW

(ATX power switch)

G-SW

(Green switch)

RESET

(Reset switch)

SPEAKER

(Speaker connector)

PWR-LED

(Power/Standby LED)

Pin Assignment

HDD LED Power

HDD

Green LED Power

Ground

PWRBT+

PWRBT-

Ground

SMI

Ground

H/W Reset

Speaker Data

N. C.

Ground

Speaker Power

LED Power (+)

LED Power (-) or Standby Signal

1.5 Award BIOS Setup Utility

1.5.1 Main Menu

Quick Setup Guide



Phoenix - AwardBIOS CMOS Setup Utility

Standard CMOS Features

Advanced BIOS Features

Advanced Chipset Features

Integrated Peripherals

Power Management Setup

PnP/PCI Configurations

CPU Frequency Control

: Quit

Esc F10

: Save & Exit Setup

Time, Date, Hard Disk Type...

1.5.2 Standard CMOS Features

Phoenix - AwardBIOS CMOS Setup Utility

Standard CMOS Features

Date (mm:dd:yy) Time (hh:mm:ss)

IDE Primary Master

IDE Primary Slave

IDE Secondary Master

IDE Secondary Slave Drive A

Drive B Video

Halt On Base Memory

Extended Memory Total Memory

Tue, Aug 6 2002 4 : 35 : 5

Press Enter None Press Enter None Press Enter None Press Enter None

1.44M, 3.5 in. None

EGA/VGA All, But Keyboard

640K 129024K 130048K

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

↑↓→←

: Select Item

Menu Level Change the day, month,

year and century

Guide

Quick Setup

Item Help

↑↓→← Move

Enter:Select

F5:Previous Values

+/-/PU/PD:Value

F6:Fail-Safe Defaults F7:Optimized Defaults

F10:Save

ESC:Exit

F1:General Help

The settings on the screen are for reference only. Your version may not be identical to this one.



Guide

Quick Setup

Quick Setup Guide

1.5.3 Advanced BIOS Features

Phoenix - AwardBIOS CMOS Setup Utility

Advanced BIOS Features

BIOS Flash Protect Virus Warning CPU L1 & L2 Cache Quick Power On Self Test First Boot Device Second Boot Device Third Boot Device Boot Other Device Swap Floppy Drive Boot Up Floppy Seek Boot Up NumLock Status Typematic Rate Setting

Typematic Rate (Chars/Sec)

Typematic Delay (Msec)

Security Option APIC Mode MPS Version Control For OS OS Select For DRAM > 64MB HDD S.M.A.R.T. Capability Full Screen Logo Show Small Logo (EPA) Show

↑↓→← Move

F5:Previous Values

Disabled Disabled Enabled Fast Floppy CDROM HDD-0 Enabled Disabled Enabled On Disabled

6 250

Setup Disabled

1.4 Non-OS2 Disabled Enabled Enabled

+/-/PU/PD:Value F10:Save ESC:Exit

F6:Fail-Safe Defaults F7:Optimized Defaults

The screen above list all the fields available in the Advanced BIOS Features submenu, for ease of reference in this manual. In the actual CMOS setup, you have to use the scroll bar to view the fields. The settings on the screen are for reference only. Your version may not be identical to this one.

1.5.4 Advanced Chipset Features

Item Help

Menu Level Allows you to choose

the VIRUS warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep

F1:General HelpEnter:Select

Phoenix - AwardBIOS CMOS Setup Utility

Advanced Chipset Features

DRAM Timing Selectable

CAS Latency Time

Active to Precharge Delay

DRAM RAS# to CAS# Delay

DRAM RAS# Precharge

Memory Enhancement Memory Frequency For System BIOS Cacheable Video BIOS Cacheable Delayed Transaction AGP Aperture Size (MB) AGP 4X Mode

↑↓→← Move

F5:Previous Values

By SPD

3 7 3 3

Disabled Auto Disabled Disabled Enabled 64 Enabled

+/-/PU/PD:Value

F6:Fail-Safe Defaults F7:Optimized Defaults

F10:Save

ESC:Exit

Item Help

Menu Level

F1:General HelpEnter:Select

The settings on the screen are for reference only. Your version may not be identical to this one.

1.5.5 Integrated Peripherals

Phoenix - AwardBIOS CMOS Setup Utility

Integrated Peripherals

INTEL OnChip IDE Device

INTEL OnChip PCI Device

Onboard Super IO Device USB Controller USB Keyboard Support Init Display First

Press Enter Press Enter Press Enter USB 2.0 Disabled Disabled AGP

Quick Setup Guide

Item Help

Menu Level



Guide

Quick Setup

↑↓→← Move

F5:Previous Values

+/-/PU/PD:Value

F6:Fail-Safe Defaults F7:Optimized Defaults

F10:Save

ESC:Exit

The settings on the screen are for reference only. Your version may not be identical to this one.

1.5.6 Power Management Setup

Phoenix - AwardBIOS CMOS Setup Utility

Power Management Setup

ACPI Function ACPI Suspend Type Power Management Video Off Method Video Off In Suspend Suspend Mode HDD Power Down Soft-Off By PWR-BTTN PWR Lost Resume State

PM Wake Up Events

↑↓→← Move

F5:Previous Values

The settings on the screen are for reference only. Your version may not be identical to this one.

Enabled S1(POS) User Define V/H SYNC+Blank Yes Disabled Disabled Instant-Off Keep Off Press Enter

+/-/PU/PD:Value

F6:Fail-Safe Defaults F7:Optimized Defaults

F10:Save

Menu Level

ESC:Exit

F1:General HelpEnter:Select

Item Help

F1:General HelpEnter:Select



Guide

Quick Setup

Quick Setup Guide

1.5.7 PnP/PCI Configurations

Phoenix - AwardBIOS CMOS Setup Utility

PnP/PCI Configurations

Reset Configuration Data Resources Controlled By

IRQ Resources

PCI/VGA Palette Snoop

* PCI IRQ Assignment *

Slot 1,5 Onboard LAN/Slot 2,6 Slot 3 Slot 4

Disabled Auto(ESCD)

Press Enter

Disabled

Auto Auto Auto Auto

Item Help

Menu Level Default is Disabled.

Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the OS cannot boot.

↑↓→← Move

F5:Previous Values

+/-/PU/PD:Value

F6:Fail-Safe Defaults F7:Optimized Defaults

F10:Save

ESC:Exit

The settings on the screen are for reference only. Your version may not be identical to this one.

1.5.8 CPU Frequency Control

CPU Clock Ratio Auto Detect PCI Clk Spread Spectrum Modulated Clock By Slight Adjust PCI/AGP Clock Adjust

↑↓→← Move

Enter:Select

F5:Previous Values

The settings on the screen are for reference only. Your version may not be identical to this one.

CPU Frequency Control

X 8 Enabled Enabled 100MHz Auto

+/-/PU/PD:Value F10:Save

F6:Fail-Safe Defaults

Menu Level

F7:Optimized Defaults

F1:General HelpEnter:Select

Item Help

F1:General HelpESC:Exit

Chapter 2 - English

Table of Contents

English

2.1 Features and Specifications.....................................................................................

2.2 Supported Softwares...................................................................................................

2.3 Troubleshooting.................................................................................................................

Package Checklist

The system board package contains the following items:

þ The system board þ A users manual þ One IDE cable for ATA/33, ATA/66 or ATA/100 IDE drives þ One 34-pin floppy disk drive cable þ One Main Board Utility CD

If any of these items are missing or damaged, please contact your dealer or sales representative for assistance.

English

Note:

English

2.1 Features and Specifications

2.1.1 Features

Chipset

 Intel® 845PE chipset

- Intel® 845PE Graphics Memory Controller Hub (MCH)

- Intel® 82801DB I/O Controller Hub (ICH4)

Processor

The system board is equipped with Socket 478 for installing a Pentium® 4 process or Celeron® processor.

 Intel® Pentium® 4 processor (478-pin)

- 533MHz system data bus - supports up to 2.53 GHz CPU

speed

- 400MHz system data bus - supports up to 2.4 GHz CPU speed

 Intel® Celeron® processor (478-pin)

- 400MHz system data bus - supports up to 1.8 GHz CPU speed

System Memory

 Two 184-pin DDR SDRAM DIMM sockets  2.5V unbuffered PC1600 (DDR200) / PC2100 (DDR266) /

PC2700 (DDR333) DDR SDRAM DIMM

 Supports maximum of 2GB system memory using 64Mbit,

128Mbit, 256Mbit or 512Mbit technology

- Double-sided x16 DDR SDRAM DIMM is not suppor ted

Density

Density Width

Single/Double

184-pin DDR

SS/DS

64/128MB

64 Mbit

X16

SS/DS

32MB/NA

128 Mbit

SS/DS

128/256MB

X16

SS/DS

64MB/NA

256 Mbit

SS/DS

256/512MB

X16

SS/DS

128MB/NA

512 Mbit

SS/DS

512/1024MB

X16

SS/DS

256MB/NA

English

Expansion Slots

The system board is equipped with 1 AGP slot and 6 PCI slots.

Important:

Most PCI cards today are in Master mode and can be installed anywhere between PCI slot 1 and PCI slot 5. DO NOT install Master mode PCI cards onto PCI slot 6 because this slot only supports Slave mode.

The AGP slot only supports 1.5V AGP 4x (1066MB/sec. bandwidth) add-in cards. AGP is an interface designed to support high performance 3D graphics cards for 3D graphics applications. It handles large amounts of graphics data with the following features:

 Pipelined memory read and write operations that hide memory

access latency.

 Demultiplexing of address and data on the bus for nearly 100

percent efficiency.

Onboard Audio Features

 16-bit stereo full-duplex codec with independent variable sam-

pling rate  High quality differential CD input  True stereo line level outputs  2-channel audio output

English

Onboard LAN Features (NB78-BL only)

 Uses Realtek RTL8100 fast ethernet controller  Integrated IEEE 802.3 10BASE-T and 100BASE-TX compatible

PHY  32-bit PCI master interface  Integrated power management functions  Full duplex support at both 10 and 100 Mbps  Supports IEEE 802.3u auto-negotiation  Supports wire for management

Compatibility

 PCI 2.2 and AC 97 compliant  Intel AGP version 2.0

English

Rear Panel I/O Ports (PC 99 color-coded connectors)

 2 USB 2.0/1.1 ports  1 RJ45 LAN port (NB78-BL only)  2 NS16C550A-compatible DB-9 serial port  1 DB-25 parallel port  1 mini-DIN-6 PS/2 mouse port  1 mini-DIN-6 PS/2 keyboard port  1 game/MIDI por t  3 audio jacks: line-out, line-in and mic-in

I/O Connectors

English

 2 connector for 4 additional external USB 2.0/1.1 ports  1 CD-in internal audio connectors  1 S/PDIF-out connector  1 connector for IrDA interface  2 IDE connectors  1 floppy drive interface supports up to two 2.88MB floppy

drives  2 ATX power supply connectors  1 Wake-On-LAN connector  CPU fan, chassis fan and second fan connectors

PCI Bus Master IDE Controller

 Two PCI IDE interfaces suppor t up to four IDE devices  Supports ATA/33, ATA/66 and ATA/100 hard drives  PIO Mode 4 Enhanced IDE (data transfer rate up to 14MB/sec.)  Bus mastering reduces CPU utilization during disk transfer  Supports ATAPI CD-ROM, LS-120 and ZIP

S/PDIF

The system board is equipped with the S/PDIF (Sony/Philips Digital Interface) digital audio interface. S/PDIF is a standard audio file transfer format that transfers digital audio signals to a device without having to be converted first to an analog format. This prevents the quality of the audio signal from degrading whenever it is converted to analog.

+ 59 hidden pages
