Dezurik 3–36 PEF User Manual

DeZURIK 3–36" PEF
D10453
February 2019
100% PORT ECCENTRIC PLUG VALVES
Instruction
DeZURIK
3-36" PEF 100% Port Eccentric Plug Valves*

Instructions

These instructions provide information about PEF 100% Port Eccentric Plug Valves. They are for use by personnel who are responsible for installation, operation and maintenance of PEF 100% Port Eccentric Plug Valves.

Safety Messages

All safety messages in the instructions are flagged with an exclamation symbol and the word Caution, Warning or Danger. These messages indicate procedures that must be followed exactly to avoid equipment damage, personal injury or death.
Safety label(s) on the product indicate hazards that can cause equipment damage, personal injury or death. If a safety label becomes difficult to see or read, or if a label has been removed, please contact DeZURIK for replacement label(s).
Personnel involved in the installation or maintenance of valves should be constantly alert to potential emission of pipeline material and take appropriate safety precautions. Always wear suitable protection when dealing with hazardous pipeline materials. Handle valves, which have been removed from service with suitable protection for any potential pipeline material in the valve.

Inspection

Your PEF 100% Port Eccentric Plug Valve has been packaged to provide protection during shipment, however, it can be damaged in transport. Carefully inspect the unit for damage upon arrival and file a claim with the carrier if damage is apparent.

Parts

Recommended spare parts are listed on the assembly drawing. These parts should be stocked to minimize downtime.
Order parts from your local DeZURIK sales representative, or directly from DeZURIK. When ordering parts, please include the 7-digit part number and 4-digit revision number (example: 9999999R000) located on the data plate attached to the valve assembly. Also include the part name, the assembly drawing number, the balloon number and the quantity stated on the assembly drawing.

DeZURIK Service

DeZURIK service personnel are available to install, maintain and repair all DeZURIK products. DeZURIK also offers customized training programs and consultation services.
For more information, contact your local DeZURIK sales representative or visit our website at www.dezurik.com.
* Patent Applied For
D10453 © 2019 DeZURIK, Inc.
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Table of Contents

Description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Handling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Required Tools - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Fusion/Powder Coated Valves - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ­Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Liquids without Suspended Solids and Clean Gases - - - - - - - - - - - - - - - - - - - - - - - - - 5 Liquids with Suspended Solids and Dirty Gases - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 Actuator Stop Adjustments Closed Position - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Lubrication - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ­ Packing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Plug Journals - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 Thrust Washers and O-rings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 Packing Adju s tment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ­ 3 – 8" Lever and Nut Operated Valves - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 All Other Actuators - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 Parts Identification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11 Packing Replacement Replace packing with Actuator Removed - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
4
9
10
Replace Packing without Removing Actuator - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ­Disassembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15 Reassembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17 Removing Valve from Pipeline - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18 Field Test - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ­Valve Exercising - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19 Emergency Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19 Predict Wear of Parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19 Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
February 2019 Page 3 D10453
14
19
19
DeZURIK
paint from cracking or chipping.
3- -- 36" PEF 100% Port Eccentric Plug Valves

Description

The 3– 36” PEF 100% Port Eccentric Plug Valves have welded nickel seats that provide excellent resistance to corrosion and damage, and prolong the life of the resilient plug facing. The valve rotates 90 degrees from full open to full closed. Clockwise rotation of the valve stem closes the valve.
If an actuator other than a DeZURIK is to be mounted, the actuator must be capable of seating and unseating the plug and maintaining the valve plug position with flow in the pipeline.
This valve is a pressure vessel. Failure to release pipeline pressure may result in personal injury and/or flow system damage. Completely release pipeline pressure before removing the actuator from the valve or removing the valve from the pipeline.

Handling

Lifting the valve improperly may damage it. Do not fasten lifting devices to the actuator, plug or thr ough the seat opening in the body. Lift the valve with body, or fastened to bolts or
rods through bolt holes in the flanges.
slings, chains or cables fastened around the valve

Required Tools

This valve is assembled using only metric fasteners. To service this valve, you should have a full set of combination wrenches, Allen wrenches, a large flat tipped screwdriver, a flat pry bar, a pin punch and a dead blow hammer.
Note: You may want to machine a shaft to aid you in removing the lower bearing from the body. See “Disassembly” section.

Fusion/Powder Coated Valves

Valves with fusion/powder coated exterior paint require flat washers to be installed under the flange nuts when installing the valve to the pipeline flange to prevent the
D10453 Page 4 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Installation

The type of materials carried in the pipeline and the location of the valve determine the correct installation procedure.
Rust Veto may be removed with the use of Houghton Kleensol #4 or petroleum solvent.

Liquids without Suspended Sol ids and Clean Gases

1. Before installation, remove foreign material such as weld spatter, oil, grease, and dirt from the pipeline.
2. Prepare pipe ends and install valves in accordance with the pipe manufacture’s instructions for the joint used.
Note: See Figure 1 for proper valve orientation.
Do not deflect the pipe-valve joint. Minimize bending stresses in the valve end connection with pipe loading.
3. Ensure the valve and flanges are concentric to ensure proper flange sealing.
4. Tighten the flange bolts or studs in a crisscross pattern.
February 2019 Page 5 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Installation (Continued)
Figure 1—Liquids without Suspended Solids and Clean Gases
D10453 Page 6 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Installation (Continued)

Liquids with Suspended Solids and Dirty Gases

If the pipeline carries suspended solids such as paper stock of 2 percent or higher consistency, mining slurry, or raw sewage:
1. Before installation, remove foreign material such as weld spatter, oil, grease, and dirt from the pipeline.
2. Prepare pipe ends and install valves in accordance with the pipe manufacture’s instructions for the joint used.
Note: See Figure 2 for proper valve orientation.
a. In HORIZONTAL pipelines, install the valve so that the plug is horizontal and rotates upward as
the valve opens.
b. For V
ERTICAL pipelines, install the valve with the end marked “SEAT” at top of valve.
Do not deflect the pipe-valve joint. Minimize bending stresses in the valve end connection with pipe loading.
3. Ensure the valve and flanges are concentric to ensure proper flange sealing.
4. Tighten the flange bolts or studs in a crisscross pattern.
February 2019 Page 7 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Installation (Continued)
Figure 2—Liquids with Suspended Solids and Dirty Gases
D10453 Page 8 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Actuator Stop Adjustments

Closed Position

Because of the eccentric action of this valve, the closed position of the valve is dependent upon the pressure drop expected when the valve is closed. To adjust the valve closed position, follow these steps:
This valve is a pressure vessel. The bonnet will blow off the valve if the bonnet bolts are removed with pressure in the valve and pipeline media can be haz ardous.
Completely release pressure before disassembling the valve.
1. Relieve pipeline pressure.
Moving parts from accidental operation of power actuator can cause personal injury or equipment damage.
Disconnect and lock out power to actuator before servicing.
2. If the actuator is powered, disconnect and lock out the pneumatic, hydraulic, or electrical power to prevent accidental operation of the actuator.
3. Back off the actuator closed position stop as described in the Actuator Instructions.
4. Close the valve with the torque specified in the Actuator Instructions.
Note: This torque is the amount required to seat the plug for a given pressure drop across the valve. To avoid excessive plug and seat wear caused by over torquing, use the actual pressure drop across the valve when determining correct closing torque.
5. After the valve has been closed using the correct amount of torque, set the actuator closed position stop to limit actuator travel at this position.

Lubrication

This valve does not require routine maintenance lubrication, except for special application. If the valve is disassembled, lubricate the packing and the plug journals as follows:

Packing

Packing lubrication requirements are dependent upon the packing material.
PTFE PACKING: Requires no lubrication.
A
LL PACKING OTHER THAN PTFE:
Apply a light coat to the inside and outside diameters of the packing rings using one of these lubricants.
- Lubriplate Clearplex-2 (recommended)
- Amoco FG (alternate)
- Mobilgrease FM 101 (alternate)
- Petro-Canada Purity FG 2 (a lterna te)
- Phillips Philube PF (alternate)
Note: Ensure lubricant is compatible with flow media. February 2019 Page 9 D10453
DeZURIK
Table A: Actuating Torque
3- -- 36" PEF 100% Port Eccentric Plug Valves
Lubrication (Continued)

Plug Journals

Plug journal lubrication is dependent upon the materials used in construction of the valve.
CAST IRON VALVES: Lubricate the journals on the plug using one of these lubricants.
- Lubriplate Clearplex-2 (recommended)
- Amoco FG (alternate)
- Mobilgrease FM 101 (alternate)
- Petro-Canada Purity FG 2 (alternate)
- Phillips Philube PF (alternate)
Note: Ensure lubricant is compatible with flow media.

Thrust Washers and O-rings

Apply a light coat to all surfaces of thrust washers and O-rings using one of these lubricants.
- Lubriplate Clearplex-2 (recommended)
- Phillips Philube PF (alternate)
- Mobilgrease FM 101 (alternate)
- Amoco FG (alternate) Note: Ensure lubricant is compatible with flow media.

Packing Adj ustment

The stem seal tightening procedure is dependent upon the type of actuator on the valve. If a packing leak should occur, tighten the packing as follows:

3” – 8" Lever and Nut Operated Valves

Valve Size
in mm ft lbs Nm
3 & 4 100 28 37 5 & 6 125-150 60 81
8 200 104 141
Actuating Torque
Standard Packing

All Other Actuators

Tighten the gland nuts evenly only until the leak stops.
Note: Do not continue tightening after leak stops. If packing leak cannot be stopped by tightening the gland nuts, the packing must be replaced.
D10453 Page 10 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Figure 3—Parts Identification
February 2019 Page 11 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Packing Replacement

Replacing Packing with Actuator Removed

To replace the packing without removing actuator, see the “ Replacing Packing Without Removing Actuator” section.
See Figure 3 for parts identification.
1. Discontinue pipeline flow and relieve pipeline pressure.
2. Scribe the actuator and valve bonnet for alignment when reassembling.
Moving parts from accidental operation of power actuator can cause personal injury or equipment damage. Disconnect and lock out power to actuator before servicing.
3. If the actuator is powered, disconnect and lock out the pneumatic, hydraulic, or electrical power to prevent accidental operation of the actuator.
When an eccentric valve is mounted in a vertical pipeline—or mounted in a horizontal pipeline with the plug stem horizontal—gravity can cause the plug to swing to a lower position in the valve body when the actuator is removed. Place the plug in the lowest position before removing the actuator.
4. Remove the actuator from the valve. See Actuator Instructions.
5. Remove the actuator adaptor from the valve.
6. Remove the gland nuts (A13), then slide the gland (A11) off the plug shaft (A3).
7. Pull the packing (A9) out of the bonnet (A6).
8. For valves with gear actuators, lubricate the new packing (A9), then install it one ring at a time in the sequence shown in Figure 4.
Figure 4 - Correct Packing Installation Sequence
D10453 Page 12 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Packing Replacement (Continued)
Note: 3 - 8” lever and nut operated valves have a friction cone (A21) and standard packing
(A9). Before installing the gland (A11), set the friction cone on top of the packing. Do not lubricate the outside of the friction cone or the inside of the gland. See Figure 5.
9. Slide the gland (A11) down the plug shaft (A3) and over the studs (A12). If the valve has a friction cone (A21), bring the gland nuts (A13) under the gland up finger tight.
Figure 5—Friction Cone Adjustment
10. Adjust gland nuts (A13).
3 - 8” L Turn gland nuts (A13) onto the studs (A12) until they touch the gland (A11).
Note: This is a preliminary adjustment, it will be necessary to adjust the gland nuts (A13) after the valve is pressurized. See "Packing Adjustment" section.
11. Fasten the adaptor (when used) to the valve, lining up the scribe marks made during disassembly.
12. Install the actuator as described in the Actuator Instructions.
13. If the actuator is a powered actuator, reconnect power to the actuator.
EVER AND NUT OPERATED VALVES ONLY:
February 2019 Page 13 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Packing Replacement (Continued)

Replacing Packing Without Re m ov ing Act ua t or

Note: Lever and nut operated valves require that the actuator be removed before packing can
be replaced. See “Replacing Packing with Actuator Removed” section to replace the packing in these valves.
1. This process can be done with or without pressure in the pipeline.
Caustic, toxic, or hot material in the pipeline can cause personal injury or death if leakage occurs. Confirm that the material is not harmful.
2. Ensure that the material in the pipeline will not cause injury if leakage occurs.
3. Remove the gland nuts (A13) from the studs (A12), and slide the gland (A11) up the stem of the plug (A3).
4. Remove the studs (A12) from the bonnet (A6).
5. Cut and completely remove all of the old packing (A9) from the packing chamber in the bonnet (A6).
6. Cut each new packing ring (A9) radially in one place with a razor-sharp knife.
7. Place each new packing ring (A9)—one at a time with the joints staggered—around the plug stem (A3) and into position in the packing chamber.
8. Replace the studs (A12) in the bonnet (A6).
9. Push the packing rings (A9) down into position with the gland (A11), and replace the gland nuts (A13) on the studs (A12).
10. Turn the gland nuts (A13) onto the studs (A12) until they touch the gland (A11), then one more turn.
11. Restore the pipeline pressure if it was relieved, and check for packing leakage. If leakage occurs, tighten each packing nut just enough to stop the leakage. Excessive tightening will cause reduced packing life and higher valve operating torque.
D10453 Page 14 February 2019
3- -- 36" PEF 100% Port Eccentric Plug Valves

Disassembly

See Figure 3 for parts identification.
This valve is a pressure vessel. The bonnet will blow off the valve if the bonnet bolts are removed with pressure in the valve and pipeline media can be hazardous. Completely release pressure before disassembling the valve.
Follow these steps to disassemble valve:
1. Relieve pipeline pressure and close the valve.
Moving parts from accidental operation of power actuator can cause personal injury or equipment damage.
Disconnect and lock out power to actuator before servicing.
DeZURIK
2. If the actuator is powered, disconnect and lock out the pneumatic, hydraulic, or electrical power to prevent accidental operation of the actuator.
3. Close the valve.
4. Remove the valve from the pipeline (if desired).
Note: The valve can be disassembled while still in the pipeline. To remove valve from pipeline, see
“Removing Valve from Pipeline” section.
When an eccentric valve is mounted in a vertical pipeline—or mounted in a horizontal pipeline with the plug stem horizontal—gravity can cause the plug to swing to a lower position in the valve body when the actuator is removed.
Place the plug in the lowest position before removing the actuator.
5. Remove actuator from valve—see Actuator Instructions.
6. Scribe a line on the body (A1), bonnet (A6) and plug stem (A3) to help align these parts during reassembly.
7. Remove the screws (A8) that hold the bonnet (A6) in place, then pry the bonnet loose from the body (A1).
Note: Note the location of WARNING TAG (A14) on bonnet (A6) and do not misplace tag. This tag must be attached to the valve at reassembly.
8. Remove the plug (A3) from the body (A1).
9. Remove the gland nuts (A13) and gland (A11) from the bonnet (A6).
10. Remove the packing (A9) from the bonnet (A6).
February 2019 Page 15 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Disassembly (Continued)
11. Reaching through the packing chamber in the bonnet (A6), drive the bearing (A7) out of the bonnet using a hammer and pin punch.
12. Remove the bearing (A2) from the body (A1).
For 3” - 20” valves, the bearing (A2) can be chiseled out; or, it can be hydraulically forced out. See Figure 6.
For 24” - 36” valves, the bearing (A2) can be driven out of the body (A1) using a hammer and pin punch. First remove the screws (A18) and journal cover (A17) from the body. Remove the old o-ring (16) from the journal cover.
To hydraulically force the bearing (A2) out of 3” - 20” valve body:
1. Fill the interior diameter of the bearing (A2) with water.
2. Pound a shaft with the same outside diameter as the lower journal of the valve plug into the bearing (A2).
Figure 6—Hydraulically Removing the Lower Bearing in the Valve Body
D10453 Page 16 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Reassembly

See Figure 3 for parts identification.
1. Push a new bearing (A2) into the body (A1), then lubricate the bearing as described in the "Lubrication" section.
2. For 24” - 36” valves, place a new o-ring (A16) in the groove of the journal cover (A17). Fasten the journal cover to the body (A1) with screws (A18).
3. Place a Teflon thrust washer (A4) on the top and bottom shoulder of the plug shaft (A3).
4. Place the plug (A3) into the body (A1) so the lower journal slides into the bearing (A2). Turn the plug so it is almost closed.
5. If necessary, push a new bearing (A7) into the bonnet (A6), then lubricate the bearing. See "Lubrication" section.
6. For 3” – 20” valves, place an o-ring (A5) in the bonnet (A6). For 24” - 36” valves, place an o-ring (A5) into the o-ring groove of the body (A1).
7. Place bonnet (A6) on body (A1), align witness marks, then fasten bonnet in place with screws (A8).
This valve is a pressure vessel and has been supplied with a WARNING TAG from the factory.
Secure WARNING TAG (A14) to bonnet (A6) with one of the bonnet screws (A8) at the location noted during disassembly.
8. Turn the plug (A3) to the closed position. See "Actuator Stop Adjustments" section.
9. For valves with low friction packing, lubricate the new packing (A9), then install it one ring at a time. See Figure 4.
Note: 3 - 8” valves use a friction cone (A21) with a wrenching nut or hand lever actuator, and standard
packing. Before installing the gland (A11), set the friction cone on top of the packing (A9). Do not lubricate the outside of the friction cone or the inside of the gland. (See Figure 5.)
10. Slide the gland (A11) down the plug shaft (A3) and over the studs (A12). If the valve has a friction cone (A21), bring the gland nuts (A13) under the gland up finger tight.
11. Adjust gland nuts (A13). 3 – 8" L
Turn packing gland nuts (A13) onto the studs (A12) until they contact the gland (A11). It will be necessary to adjust the gland nuts after the valve is pressurized; see the "Packing Adjustment" section.
pressurized. See "Packing Adjustment" section.
Note: This is a preliminary adjustment, it will be necessary to adjust the gland nuts (A13) after the valve is
EVER AND NUT OPERATED VALVES ONLY:
February 2019 Page 17 D10453
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves
Reassembly (Continued)
12. Install the actuator—see Actuator Instructions.
13. After actuator is mounted, and shaft key is assembled in keyseat, secure shaft key by staking with a center-punch on the end of the shaft. Stake on both sides of the shaft as shown in Figure 7.
Note: Do not deform the outside diameter of the shaft.
14. After pipeline flow is restored, check the packing for leakage.
Note: If packing leaks, tighten the gland nuts (A13) only
enough to stop the leak. Over tightening the packing will cause premature packing failure and higher valve operating torque.
15. If the actuator is a powered actuator, reconnect power to the actuator.
Figure 7 – Shaft Key Staking

Removing Valve from Pipeline

To remove the entire valve assembly from the pipeline, follow these steps.
This valve is a pressure vessel. The bonnet will blow off the valve if the bonnet bolts are removed with pressure in the valve and pipeline media can be hazardous.
Completely release pressure before disassembling the valve.
1. Relieve pipeline pressure and drain portion of system where valve is located.
2. Close the valve.
Moving parts from accidental operation of power actuator can cause personal injury or equipment damage. Disconnect and lock out power to actuator before servicing.
3. If the actuator is powered, disconnect and lock out the pneumatic, hydraulic, or electrical power to prevent accidental operation of the actuator.
4. Support the valve assembly, then remove the flange bolts.
5. Remove the valve from the pipeline.
D10453 Page 18 February 2019
DeZURIK
3- -- 36" PEF 100% Port Eccentric Plug Valves

Field Test

Stroke the valve between the fully open and fully closed positions to verify that the valve and actuator are functioning properly. Prior to any field pressure test above the valve design pressure, contact DeZURIK.
Test pressures above valve design pressure can cause leakage, permanent or structural failure to the valve and personal injury.

Valve Exercising

Each valve should be operated through a full cycle and returned to its normal operating position on a time schedule that is designed to prevent a buildup of media deposits that could render the valve inoperable or prevent a tight shutoff.
The interval of time between exercising valves in critical applications or valves subjected to severe operating conditions, should be shorter than valves in less critical installations. The time period for valve exercising should be based on local experience.

Emergency Operation

Operate the valve as under normal conditions, taking care to bring the plug to the position required by the particular emergency condition
.

Predicted Wear of Parts

Length of service for parts subject to wear is dependent on service conditions.

Troubleshooting

Symptom Possible Cause Corrective Action
Packing is loose.
Packing Leaks.
Packing is worn.
Object is wedged between plug and seat.
Valve does not close.
Actuator closed position is out of adjustment.
Plug is worn or damaged.
Valve leaks when closed
Rubber on plug is torn.
Adjust Packing. (See “Packing Adjustment” section.)
Replace Packing. (See “Packing Replacement” section.)
Open the valve completely to flush object. If this doesn’t work, remove valve from the pipeline or drop
one section of adjacent pipe. (See “Removing Valve from Pipeline”
section.) Adjust the closed position
stop as described in the Actuator instructions.
Replace plug. (See “Disassembly” section.)
February 2019 Page 19 D10453
Loading...
