BRUSHLESS CORDLESS 13 mm DRILL/DRIVER, DCD991 BRUSHLESS CORDLESS 13 mm DRILL/DRIVER/ HAMMERDRILL, DCD996

ENGLISH

Congratulations!

You have chosen a product development and innovation make most reliable partners for professional power toolusers.

tool. Years of experience, thorough

one of the

Technical Data

DCD991 DCD996 Voltage V Type 1/10 1/10 Battery type Li-Ion Li-Ion Power output W 820 820 No load speed Drill, Driver/Hammer

1st gear min-10–450 0–450/500 2nd gear 0–1300 0–1300/1500 3rd gear 0–2000 0–2000/2250

Impact rate

1st gear min 2nd gear – 0–25500 3rd gear – 0–38250

Max. torque (hard/soft)

hard Nm 95 95

soft Nm 66 66 Chuck capacity mm 1.5–13 1.5–13 Maximum drilling capcity

Wood mm 55 55

Metal 15 15

Masonry – 13 Weight (without battery pack) kg 1.5 1.6

Noise values and vibration values (triax vector sum) according to EN60745:

LPA (emission sound pressure

level) LWA (sound power level) dB(A) 86 108 K (uncertainty for the given

sound level)

Drilling into metal

Vibration emission value a Uncertainty K = m/s21.5 1.5

Impact drilling

Vibration emission value a Uncertainty K = m/s

dB(A) 75 97

dB(A) 3 3

= m/s2<2.5 <2.5

h,D

= m/s

h,ID

-1

18 18

– 0–8600

– 15.0 – 3.9

DCD991 DCD996

Screwdriving

Vibration emission value ah = m/s2<2.5 <2.5 Uncertainty K = m/s21.5 1.5

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN60745 and may be used to compare one tool with another. It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level represents the main applications of the tool. However if



the tool is used for different applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over the total workingperiod.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running but not actually doing the job. This may significantly reduce the exposure level over the total workingperiod.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of workpatterns.

Battery pack DCB181 DCB182 Battery type Li-Ion Li-Ion Voltage V Capacity Ah 1.5 4.0 Weight kg 0.35 0.61

Battery pack DCB183/B DCB184/B DCB185 Battery type Li-Ion Li-Ion Li-Ion Voltage V Capacity Ah 2.0 5.0 1.3 Weight kg 0.40/0.45 0.62/0.67 0.35

Battery pack DCB546 Battery type Li-Ion Voltage V Capacity Ah 6.0/2.0 Weight kg 1.05

18 18

18 18 18

18/54

Page 6

ENGLISH

DeWALT

Charger DCB107 Mains voltage V Battery type 10.8/14.4/18 Li-Ion Approx. charging time of

battery packs

Weight kg 0.29

Charger DCB112 Mains voltage V Battery type 10.8/14.4/18 Li-Ion Approx. charging time of

battery packs

Weight kg 0.36

Charger DCB113 Mains voltage V Battery type 10.8/14.4/18 Li-Ion Approx. charging time of

battery packs

Weight kg 0.4

Charger DCB115 Mains voltage V Battery type 10.8/14.4/18 Li-Ion Approx. charging time of

battery packs

Weight kg 0.5

Charger DCB118 Mains voltage V Battery type 18/54 Li-Ion Approx. charging time of

battery packs

Weight kg 0,66

The DCB107, DCB112, DCB113 and DCB115 chargers accept

10.8V, 14.4V, 18V Li-Ion XR and XRFLEXVOLTTM battery packs (DCB123, DCB127, DCB141, DCB142, DCB143, DCB144, DCB145, DCB181, DCB182, DCB183, DCB183B, DCB184, DCB184B, DCB185 and DCB546) batterypacks.

The DCB118 charger accepts 18V Li-Ion XR and XRFLEXVOLTTM battery packs (DCB181, DCB182, DCB183, DCB183B, DCB184, DCB184B, DCB185 and DCB546).

Fuses: Europe 230V tools 10 Amperes. mains U.K. & Ireland 230V tools 3 Amperes. in plugs

min 60 (1.3 Ah) 70 (1.5 Ah) 90 (2.0 Ah)

140 (3.0 Ah) 185 (4.0 Ah) 240 (5.0 Ah)

min 40 (1.3 Ah) 45 (1.5 Ah) 60 (2.0 Ah)

90 (3.0 Ah) 120 (4.0 Ah) 150 (5.0 Ah)

min 30 (1.3 Ah) 35 (1.5 Ah) 50 (2.0 Ah)

70 (3.0 Ah) 100 (4.0 Ah) 120 (5.0 Ah)

min 22 (1.3 Ah) 22 (1.5 Ah) 30 (2.0 Ah)

45 (3.0 Ah) 60 (4.0 Ah) 75 (5.0 Ah)

min 22 (1.3 Ah) 22 (1.5 Ah) 30 (2.0 Ah)

45 (3.0 Ah) 60 (4.0 Ah) 75 (5.0 Ah)

230

60 (6.0 Ah)

EC-Declaration of Conformity

Machinery Directive

Drill/Driver/Hammerdrill DCD991, DCD996

declares that these products described under

Technical Data are in compliance with: 2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-1:2010, EN60745-2-2:2010.

These products also comply with Directive 2014/30/EU and 2011/65/EU. For more information, please contact the following address or refer to the back of themanual.

The undersigned is responsible for compilation of the technical file and makes this declaration on behalf of

Markus Rompel Director Engineering

, Richard-Klinger-Straße 11,

D-65510, Idstein, Germany

29.02.2016

WARNING: To reduce the risk of injury, read the instruction manual.

Definitions: Safety Guidelines

The definitions below describe the level of severity for each signal word. Please read the manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or



seriousinjury. WARNING: Indicates a potentially hazardous situation

which, if not avoided, could result in death or



seriousinjury. CAUTION: Indicates a potentially hazardous situation

which, if not avoided, may result in minor or



moderateinjury. NOTICE: Indicates a practice not related to

personal injury which, if not avoided, may result in propertydamage.

Denotes risk of electricshock.



Denotes risk offire.



General Power Tool Safety Warnings

WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and



instructions may result in electric shock, fire and/or seriousinjury.

Page 7

SAVE ALL WARNINGS AND INSTRUCTIONS

FOR FUTURE REFERENCE

The term “power tool” in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) powertool.

1) Work area safety

a ) Keep work area clean and well lit. Cluttered or dark

areas inviteaccidents.

b ) Do not operate power tools in explosive

atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which

may ignite the dust orfumes.

c ) Keep children and bystanders away while operating

a power tool. Distractions can cause you to losecontrol.

2) Electrical safety

a ) Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electricshock.

b ) Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if

your body is earthed orgrounded.

c ) Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of electricshock.

d ) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of

electricshock.

e ) When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electricshock.

f ) If operating a power tool in a damp location is

unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of

electricshock.

3) Personal safety

a ) Stay alert, watch what you are doing and use

common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment

of inattention while operating power tools may result in serious personalinjury.

b ) Use personal protective equipment. Always wear

eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personalinjuries.

c ) Prevent unintentional starting. Ensure the switch

is in the off position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the

ENGLISH

switch or energising power tools that have the switch on invitesaccidents.

d ) Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personalinjury.

e ) Do not overreach. Keep proper footing and balance

at all times. This enables better control of the power tool in unexpectedsituations.

f ) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair

can be caught in movingparts.

g ) If devices are provided for the connection of dust

extraction and collection facilities, ensure these are connected and properly used. Use of dust collection

can reduce dust-relatedhazards.

4) Power tool use and care

a ) Do not force the power tool. Use the correct power

tool for your application. The correct power tool

will do the job better and safer at the rate for which it wasdesigned.

b ) Do not use the power tool if the switch does not turn

it on and off. Any power tool that cannot be controlled with the switch is dangerous and must berepaired.

c ) Disconnect the plug from the power source and/or

the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the

risk of starting the power toolaccidentally.

d ) Store idle power tools out of the reach of children

and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrainedusers.

e ) Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly

maintained powertools.

f ) Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges are less likely to bind and are easier tocontrol.

g ) Use the power tool, accessories and tool bits etc.,

in accordance with these instructions taking into account the working conditions and the work to be performed. Use of the power tool for operations different

from those intended could result in a hazardoussituation.

5) Battery tool use and care

a ) Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type

of battery pack may create a risk of fire when used with another batterypack.

Page 8

ENGLISH

DeWALT

b ) Use power tools only with specifically designated

battery packs. Use of any other battery packs may create

a risk of injury andfire.

c ) When battery pack is not in use, keep it away from

other metal objects like paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another.

Shorting the battery terminals together may cause burns or afire.

d ) Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid

ejected from the battery may cause irritation orburns.

6) Service

a ) Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool ismaintained.

Additional Specific Safety Rules for Drills/ Drivers/Hammerdrills

• Wear ear protectors when impact drilling. Exposure to

noise can cause hearing loss.

• Use auxiliary handles, if supplied with the tool. Loss of

control can cause personal injury.

• Hold power tool by insulated gripping surfaces when

performing an operation where the cutting tool or the fastener may contact hidden wiring. Cutting accessory or

fasteners contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.

• Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control.

• Wear ear protectors when hammering for extended periods of time. Prolonged exposure to high intensity noise can cause hearing loss. Temporary hearing loss or serious ear drum damage may result from high sound levels generated by hammerdrilling.

• Wear safety goggles or other eye protection. Hammering and drilling operations cause chips to fly. Flying particles can cause permanent eye damage.

• Hammer bits and tools get hot during operation. Wear gloves when touching them.

Residual Risks

The following risks are inherent to the use of percussion drills:

• Injuries caused by touching the rotating parts or hot parts of the tool.

In spite of the application of the relevant safety regulations and the implementation of safety devices, certain residual risks cannot be avoided. These are:

• Impairment of hearing.

• Risk of squeezing fingers when changing accessories.

• Health hazards caused by breathing dust developed when working in wood.

• Risk of personal injury due to flying particles.

• Risk of personal injury due to prolonged use.

Electrical Safety

The electric motor has been designed for one voltage only. Always check that the battery pack voltage corresponds to the voltage on the rating plate. Also make sure that the voltage of your charger corresponds to that of yourmains.

Your accordance with EN60335; therefore no earth wire isrequired.

If the supply cord is damaged, it must be replaced by a specially prepared cord available through the serviceorganisation.

Mains Plug Replacement (U.K. & Ireland Only)

If a new mains plug needs to be fitted:

• Safely dispose of the oldplug.

• Connect the brown lead to the live terminal in theplug.

• Connect the blue lead to the neutralterminal.

WARNING: No connection is to be made to the earthterminal.



Follow the fitting instructions supplied with good quality plugs. Recommended fuse: 3A.

Using an Extension Cable

An extension cord should not be used unless absolutely necessary. Use an approved extension cable suitable for the power input of your charger (see Technical Data). The minimum conductor size is 1mm2; the maximum length is30m.

When using a cable reel, always unwind the cablecompletely.

SAVE THESE INSTRUCTIONS

charger is double insulated in

Chargers

chargers require no adjustment and are designed to be

as easy as possible tooperate.

Important Safety Instructions for All Battery Chargers

SAVE THESE INSTRUCTIONS: This manual contains important safety and operating instructions for compatible battery chargers (refer to TechnicalData).

• Before using charger, read all instructions and cautionary markings on charger, battery pack, and product using batterypack.

WARNING: Shock hazard. Do not allow any liquid to get inside charger. Electric shock mayresult.



WARNING: We recommend the use of a residual current device with a residual current rating of 30mA orless.



CAUTION: Burn hazard. To reduce the risk of injury, charge only



batteries may burst causing personal injury anddamage.

rechargeable batteries. Other types of

Page 9

CAUTION: Children should be supervised to ensure that

DeWALT

they do not play with theappliance.



NOTICE: Under certain conditions, with the charger plugged into the power supply, the exposed charging contacts inside the charger can be shorted by foreign material. Foreign materials of a conductive nature such as, but not limited to, steel wool, aluminum foil or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the power supply when there is no battery pack in the cavity. Unplug charger before attempting to clean

• DO NOT attempt to charge the battery pack with any chargers other than the ones in this manual. The charger and battery pack are specifically designed to worktogether.

• These chargers are not intended for any uses other than

charging

may result in risk of fire, electric shock orelectrocution.

• Do not expose charger to rain orsnow.

• Pull by plug rather than cord when disconnecting charger. This will reduce risk ofdamage to electric plug andcord.

• Make sure that cord is located so that it will not be

stepped on, tripped over, or otherwise subjected to damage orstress.

• Do not use an extension cord unless it is absolutely necessary. Use of improper extension cord could result in risk

of fire,electric shock, orelectrocution.

• Do not place any object on top of charger or place

the charger on a soft surface that might block the ventilation slots and result in excessive internal heat.

Place the charger in a position away from any heat source. The charger is ventilated through slots in the top and the bottom of thehousing.

• Do not operate charger with damaged cord or plug— have them replacedimmediately.

• Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way. Take it to an authorised servicecentre.

• Do not disassemble charger; take it to an authorised service centre when service or repair is required. Incorrect reassembly may result in a risk of electric shock, electrocution orfire.

• In case of damaged power supply cord the supply cord must be replaced immediately by the manufacturer, its service agent or similar qualified person to prevent anyhazard.

• Disconnect the charger from the outlet before

attempting any cleaning. This will reduce the risk of electric shock. Removing the battery pack will not reduce

thisrisk.

• NEVER attempt to connect two chargerstogether.

• The charger is designed to operate on standard

230V household electrical power. Do not attempt to use it on any other voltage. This does not apply to the

vehicularcharger.

rechargeable batteries. Any other uses

ENGLISH

Charging a Battery (Fig. B)

1. Plug the charger into an appropriate outlet before inserting battery pack.

2. Insert the battery pack battery pack is fully seated in the charger. The red (charging) light will blink repeatedly indicating that the charging process has started.

3. The completion of charge will be indicated by the red light remaining ON continuously. The battery pack is fully charged and may be used at this time or left in the charger. To remove the battery pack from the charger, push the battery release button

NOTE: To ensure maximum performance and life of lithium-ion battery packs, charge the battery pack fully before first use.

8

into the charger, making sure the

9

on the battery pack.

Charger Operation

Refer to the indicators below for the charge status of the battery pack.

Charge Indicators

Charging

Fully Charged

Hot/Cold Pack Delay*

* The red light will continue to blink, but a yellow indicator light

will be illuminated during this operation. Once the battery pack has reached an appropriate temperature, the yellow light will turn off and the charger will resume the charging procedure.

The compatible charger(s) will not charge a faulty battery pack. The charger will indicate faulty battery by refusing to light or by displaying problem pack or charger blink pattern.

NOTE: This could also mean a problem with a charger. If the charger indicates a problem, take the charger and battery

pack to be tested at an authorised service centre.

Hot/Cold Pack Delay

When the charger detects a battery pack that is too hot or too cold, it automatically starts a Hot/Cold Pack Delay, suspending charging until the battery pack has reached an appropriate temperature. The charger then automatically switches to the pack charging mode. This feature ensures maximum battery pack life.

A cold battery pack will charge at a slower rate than a warm battery pack. The battery pack will charge at that slower rate throughout the entire charging cycle and will not return to maximum charge rate even if the battery pack warms.

The DCB118 charger is equipped with an internal fan designed to cool the battery pack. The fan will turn on automatically when the battery pack needs to be cooled. Never operate the charger if the fan does not operate properly or if ventilation slots are blocked. Do not permit foreign objects to enter the interior of the charger.

Page 10

ENGLISH

DeWALT

Electronic Protection System

XR Li-Ion tools are designed with an Electronic Protection System that will protect the battery pack against overloading, overheating or deep discharge.

The tool will automatically turn off if the Electronic Protection System engages. If this occurs, place the lithium-ion battery pack on the charger until it is fully charged.

Wall Mounting

These chargers are designed to be wall mountable or to sit upright on a table or work surface. If wall mounting, locate the charger within reach of an electrical outlet, and away from a corner or other obstructions which may impede air flow. Use the back of the charger as a template for the location of the mounting screws on the wall. Mount the charger securely using drywall screws (purchased separately) at least 25.4mm long with a screw head diameter of 7–9mm, screwed into wood to an optimal depth leaving approximately 5.5mm of the screw exposed. Align the slots on the back of the charger with the exposed screws and fully engage them in the slots.

Charger Cleaning Instructions

WARNING: Shock hazard. Disconnect the charger from the AC outlet before cleaning. Dirt and grease



may be removed from the exterior of the charger using a cloth or soft non-metallic brush. Do not use water or any cleaning solutions. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid.

Battery Packs

Important Safety Instructions for All Battery Packs

When ordering replacement battery packs, be sure to include catalog number and voltage.

The battery pack is not fully charged out of the carton. Before using the battery pack and charger, read the safety instructions below. Then follow charging procedures outlined.

READ ALL INSTRUCTIONS

• Do not charge or use battery in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Inserting or removing the battery from the charger may

ignite the dust or fumes.

• Never force battery pack into charger. Do not modify

battery pack in any way to fit into a non-compatible charger as battery pack may rupture causing serious personal injury.

• Charge the battery packs only in

• DO NOT splash or immerse in water or other liquids.

• Do not store or use the tool and battery pack in

locations where the temperature may reach or exceed 40 ˚C (104 ˚F) (such as outside sheds or metal buildings in summer).

• Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can

explode in a fire. Toxic fumes and materials are created when lithium-ion battery packs are burned.

chargers.

• If battery contents come into contact with the skin, immediately wash area with mild soap and water. If battery liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases. If medical attention is needed, the battery electrolyte is composed of a mixture of liquid organic carbonates and lithium salts.

• Contents of opened battery cells may cause respiratory irritation. Provide fresh air. If symptoms persists, seek medical attention.

WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame.



WARNING: Never attempt to open the battery pack for any reason. If battery pack case is cracked or damaged,



do not insert into charger. Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has received a sharp blow, been dropped, run over or damaged in any way (i.e., pierced with a nail, hit with a hammer, stepped on). Electric shock or electrocution may result. Damaged battery packs should be returned to service centre for recycling.

WARNING: Fire hazard. Do not store or carry the battery pack so that metal objects can contact



exposed battery terminals. For example, do not place the battery pack in aprons, pockets, tool boxes, product kit boxes, drawers, etc., with loose nails, screws, keys, etc.

CAUTION: When not in use, place tool on its side on a stable surface where it will not cause a tripping



or falling hazard. Some tools with large battery packs will stand upright on the battery pack but may be easily knocked over.

Transportation

WARNING: Fire hazard. Transporting batteries can possibly cause fire if the battery terminals inadvertently



come in contact with conductive materials. When transporting batteries, make sure that the battery terminals are protected and well insulated from materials that could contact them and cause a short circuit.

batteries comply with all applicable shipping regulations as prescribed by industry and legal standards which include UN Recommendations on the Transport of Dangerous Goods; International Air Transport Association (IATA) Dangerous Goods Regulations, International Maritime Dangerous Goods (IMDG) Regulations, and the European Agreement Concerning The International Carriage of Dangerous Goods by Road (ADR). Lithium-ion cells and batteries have been tested to section 38.3 of the UN Recommendations on the Transport of Dangerous Goods Manual of Tests and Criteria.

In most instances, shipping a excepted from being classified as a fully regulated Class 9 Hazardous Material. In general, only shipments containing a lithium-ion battery with an energy rating greater than 100 Watt Hours (Wh) will require being shipped as fully regulated Class 9. All lithium-ion batteries have the Watt Hour rating marked on the pack. Furthermore, due to regulation complexities, does not recommend air shipping lithium-ion battery packs alone regardless of Watt Hour rating. Shipments of tools with

battery pack will be

Page 11

batteries (combo kits) can be air shipped as excepted if the Watt

DeWALT

Hour rating of the battery pack is no greater than 100 Whr. Regardless of whether a shipment is considered excepted

or fully regulated, it is the shipper's responsibility to consult the latest regulations for packaging, labeling/marking and documentation requirements.

The information provided in this section of the manual is provided in good faith and believed to be accurate at the time the document was created. However, no warranty, expressed or implied, is given. It is the buyer’s responsibility to ensure that its activities comply with the applicable regulations.

Transporting the FLEXVOLTTM Battery

The

Transport. Use Mode: When the FLEXVOLTTM battery stands alone or is in

a the FLEXVOLTTM battery is in a 54V or a 108V (two 54V batteries) product, it will operate as a 54V battery.

Transport Mode: When the cap is attached to the FLEXVOLTTM battery, the battery is in Transport mode. Keep the cap for shipping.

When in Transport mode, strings of cells are electrically disconnected within the pack resulting in 3 batteries with a lower Watt hour (Wh) rating as compared to 1 battery with a higher Watt hour rating. This increased quantity of 3 batteries with the lower Watt hour rating can exempt the pack from certain shipping regulations that are imposed upon the higher Watt hour batteries.

For example, the Transport Wh rating might indicate 3x36 Wh, meaning 3 batteries of 36 Wh each. The Use Wh rating might indicate 108Wh (1battery implied).

FLEXVOLTTM battery has two modes: Use and

18V product, it will operate as an 18V battery. When

Example of Use and Transport Label Marking

Storage Recommendations

1. The best storage place is one that is cool and dry away from direct sunlight and excess heat or cold. For optimum battery performance and life, store battery packs at room temperature when not in use.

2. For long storage, it is recommended to store a fully charged battery pack in a cool, dry place out of the charger for optimal results.

NOTE: Battery packs should not be stored completely depleted of charge. The battery pack will need to be recharged before use.

Labels on Charger and Battery Pack

In addition to the pictographs used in this manual, the labels on the charger and the battery pack may show the following pictographs:

ENGLISH

Read instruction manual before use.

See Technical Data for charging time.

Do not probe with conductive objects.

Do not charge damaged battery packs.

Do not expose to water.

Have defective cords replaced immediately.

Charge only between 4 ˚C and 40 ˚C.

Only for indoor use.

Discard the battery pack with due care for the environment.

Charge

than the designated

other dangerous situations.

Do not incinerate the battery pack.

USE (without transport cap). Example: Wh rating indicates 108 Wh (1 battery with 108 Wh).

TRANSPORT (with built-in transport cap). Example: Wh rating indicates 3 x 36 Wh (3batteries of 36 Wh).

battery packs only with designated

chargers. Charging battery packs other

charger may make them burst or lead to

batteries with a

Battery Type

The DCD991 and DCD996 operate on a 18V Li-Ion XR and XRFLEXVOLTTM battery packs

These battery packs may be used: DCB181, DCB182, DCB183, DCB183B, DCB184, DCB184B, DCB185, DCB546. Refer to Technical Data for moreinformation.

Package Contents

The package contains: 1 Brushless cordless drill/driver (DCD991) 1 Brushless cordless hammerdrill (DCD996) 1 Li-Ion battery packs (M1, P1, T1) 2 Li-Ion battery packs (M2, P2, T2) 3 Li-Ion battery packs (M3, P3, T3) 1 Tool Connect™ App instruction manual

Page 12

ENGLISH

DeWALT

1 Kitbox 1 Charger 1 Side handle 1 Instruction manual NOTE: Battery packs, chargers and kitboxes are not included

with N-models. Battery packs and chargers are not included with NT models. Bmodels include Bluetooth® battery packs.

NOTE: The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth®, SIG, Inc. and any use of such marks by trade names are those of their respective owners.

• Check for damage to the tool, parts or accessories which may have occurred duringtransport.

• Take the time to thoroughly read and understand this manual prior tooperation.

is under license. Other trademarks and

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual before use.

Date Code Position

The date code, which also includes the year of manufacture, is printed into thehousing.

Example:

2016 XX XX

Year of Manufacture

Description (Fig. A, B)

WARNING: Never modify the power tool or any part of it. Damage or personal injury couldresult.



Trigger switch

Forward/reverse control button

Worklight

Chuck

Torque adjustment collar

Gear shifter

Side handle

Battery pack

Battery release button

Belt hook

Mounting screw

Magnetic bit holder

Worklight switch

Low worklight mode

Medium worklight mode

Spotlight mode

Fuel gauge

Main handle

Intended Use

These drills drivers/hammerdrills are designed for professional drilling, percussion drilling and screwdriving applications. This

tool is compatible with Bluetooth® Battery Technology and with the App instruction manual for more information.

DO NOT use under wet conditions or in the presence of flammable liquids orgases.

These drills/drivers/hammerdrills are professional power tools. DO NOT let children come into contact with the tool.

Supervision is required when inexperienced operators use thistool.

• Young children and the infirm. This appliance is not

• This product is not intended for use by persons (including

Tool Connect™ App. Please see your Tool Connect™

intended for use by young children or infirm persons without supervision.

children) suffering from diminished physical, sensory or mental abilities; lack of experience, knowledge or skills unless they are supervised by a person responsible for their safety. Children should never be left alone with thisproduct.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack



before making any adjustments or removing/ installing attachments or accessories. An accidental

start-up can causeinjury.

WARNING: Use only



battery packs andchargers.

Inserting and Removing the Battery Pack from the Tool (Fig. B)

NOTE: Make sure your battery pack

To Install the Battery Pack into the Tool Handle

1. Align the battery pack handle (Fig. B).

2. Slide it into the handle until the battery pack is firmly seated in the tool and ensure that you hear the lock snap intoplace.

To Remove the Battery Pack from the Tool

1. Press the release button out of the toolhandle.

2. Insert battery pack into the charger as described in the charger section of thismanual.

Fuel Gauge Battery Packs (Fig. B)

Some consists of three green LED lights that indicate the level of charge remaining in the batterypack.

To actuate the fuel gauge, press and hold the fuel gauge button

17

. A combination of the three green LED lights will illuminate

designating the level of charge left. When the level of charge in the battery is below the usable limit, the fuel gauge will not illuminate and the battery will need to berecharged.

NOTE: The fuel gauge is only an indication of the charge left on the battery pack. It does not indicate tool functionality and is subject to variation based on product components, temperature and end-userapplication.

battery packs include a fuel gauge which

8

is fullycharged.

8

with the rails inside the tool’s

9

and firmly pull the battery pack

Page 13

Variable Speed Switch (Fig. A)

To turn the tool on, squeeze the trigger switch tool off, release the trigger switch. Your tool is equipped with a brake. The chuck will stop as soon as the trigger switch is fullyreleased.

NOTE: Continuous use in variable speed range is not recommended. It may damage the switch and should beavoided.

1

. To turn the

Side Handle (Fig. A)

WARNING: To reduce the risk of personal injury, ALWAYS operate the tool with the side handle properly installed.



Failure to do so may result in the side handle slipping during tool operation and subsequent loss of control. Hold tool with both hands to maximize control.

The side handle be rotated 360˚ to permit right- or left-hand use. Side handle must be tightened sufficiently to resist the twisting action of the tool if the accessory binds or stalls. Be sure to grip the side handle at the far end to control the tool during astall.

If model is not equipped with side handle, grip drill with one hand on the handle and one hand on the battery pack.

NOTE: Side handle comes equipped on all models.

7

clamps to the front of the gear case and may

Forward/Reverse Control Button (Fig. A)

A forward/reverse control button the tool and also serves as a lock off button.

To select forward rotation, release the trigger switch and depress the for ward/re verse control button on the right side of the tool.

To select reverse, release the trigger switch and depress the forward/reverse control button on the left side of the tool.

The center position of the control button locks the tool in the off position. When changing the position of the control button, be sure the trigger is released.

NOTE: The first time the tool is run after changing the direction of rotation, you may hear a click on start up. This is normal and does not indicate a problem.

2

determines the direction of

Torque Adjustment Collar/Electronic Clutch (Fig. C–E)

Your tool has an electronic adjustable torque screwdriver mechanism for driving and removing a wide array of fasteners. Circling the torque adjustment collar numbers are used to set the clutch to deliver a torque range. The higher the number on the collar, the higher the torque and the larger the fastener which can be driven. To select any of the numbers, rotate until the desired number aligns with the arrow.

5

are numbers. These

Three-Speed Gearing (Fig. A, C–E)

The three-speed feature of your tool allows you to shift gears for greater versatility. To select speed 1 (highest torque setting), turn the tool off and permit it to stop. Slide the gear shifter all the way forward. Speed 2 (middle torque and speed setting) is in the middle position. Speed 3 (highest speed setting) is to the rear.

6

ENGLISH

NOTE: Do not change gears when the tool is running. Always

allow the drill to come to a complete stop before changing gears. If you have trouble changing gears, make sure that the gear shifter is engaged in one of the three speed settings.

If the speed shifter becomes stuck or is difficult to select the desired gear, pull the trigger switch select the gear.

1

to rotate the motor. Then

Keyless Single Sleeve Chuck (Fig. F–H)

WARNING: Do not attempt to tighten drill bits (or any other accessory) by gripping the front part of the



chuck and turning the tool on. Damage to the chuck and personal injury may result. Always lock off trigger switch and disconnect tool from power source when changingacces sories.

WARNING: Always ensure the bit is secure before starting the tool. A loose bit may eject from tool causing possible



personal injury.

Your tool features a keyless chuck with one rotating sleeve for one-handed operation of the chuck. To insert a drill bit or other accessory, follow these steps.

1. Turn off tool and disconnect tool from power source.

2. Grasp the black sleeve of the chuck use the other hand to secure the tool as shown in FigureF. Rotate the sleeve counterclockwise (as viewed from the front) far enough to accept the desired accessory.

3. Insert the accessory about 19 mm into the chuck (Fig.G). Tighten securely by rotating the chuck sleeve clockwise with one hand while holding the tool with the other hand (Fig.H). Continue to rotate the chuck sleeve until several ratchet clicks are heard to ensure full gripping power.

To release the accessory, repeat Steps 1 and 2 above. Be sure to tighten chuck with one hand on the chuck sleeve and

one hand holding the tool for maximum tightness.

4

with one hand and

LED Worklight (Fig. A)

The LED worklight the foot of the tool. The worklight is activated when the trigger switch is depressed. The low modes can be changed by moving the switch on the foot of the tool. If the trigger switch remains depressed, the worklight will remain on in all modes.

When on low automatically turn off 20 seconds after the trigger switch isreleased.

3

and its worklight switch

14

and medium

, medium

15

settings, the beam will

Spotlight Mode

The high setting run for 20 minutes after the trigger switch is released. Two minutes before the spotlight will shut off, it will flash twice and then dim. To avoid the spotlight shutting off, lightly tap the trigger switch.



16

is the spotlight mode. The spotlight will

WARNING: While using the worklight in medium or spotlight mode, do not stare at the light or place the drill in a position which may cause anyone to stare into the light. Serious eye injury could result.

13

are located on

15

and spotlight

16

Page 14

ENGLISH

CAUTION: When using the tool as a spotlight, be sure it is secured on a stable surface where it will not cause a



tripping or falling hazard. CAUTION: Remove all accessories from the chuck before

using the drill as a spotlight. Personal injury or property



damage could result.

Low Battery Warning

When in spotlight mode and the battery is nearing complete discharge, the spotlight will flash twice and then dim. After two minutes, the battery will be completely discharged and the drill will immediately shut down. At this point, replace with a charged battery.

WARNING: To reduce the risk of injury, always have a back-up battery or secondary lighting available if the



situation warrants it.

Belt Hook and Magnetic Bit Holder (Fig. A)

WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack



before making any adjustments or removing/ installing attachments or accessories.

WARNING: To reduce the risk of serious personal injury, DO NOT suspend tool overhead or suspend



objects from the belt hook. ONLY hang tool’s belt hook from a work belt.

WARNING: To reduce the risk of serious personal injury, ensure the screw holding the belt hook is secure.



CAUTION: To reduce the risk of personal injury or damage, DO NOT use the belt hook to hang the drill



while using as a spotlight.

IMPORTANT: When attaching or replacing the belt hook or magnetic bit holder, use only the screw sure to securely tighten the screw.

The belt hook attached to either side of the tool using only the screw provided, to accommodate left- or right- handed users. If the hook or magnetic bit holder is not desired at all, it can be removed from the tool.

To move belt hook or magnetic bit holder, remove the screw

11

that holds it in place then reassemble on the opposite side.

Be sure to securely tighten the screw.

10

and magnetic bit holder

11

that is provided. Be

12

can be be

11

OPERATION

Instructions for Use

WARNING: Always observe the safety instructions and applicableregulations.



WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack



before making any adjustments or removing/ installing attachments or accessories. An accidental

start-up can causeinjury.

Proper Hand Position (Fig. I)

WARNING: To reduce the risk of serious personal injury, ALWAYS use proper hand position as shown infigureI.



WARNING: To reduce the risk of serious personal injury, ALWAYS hold securely in anticipation of a



suddenreaction.

Proper hand position requires one hand on the main handle

18

, with the other hand on the side handle

7

Drill Operation (Fig. D)

WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect tool from power



source before making any adjustments or removing/ installing attachments or accessories.

WARNING: TO REDUCE THE RISK OF PERSONAL INJURY, ALWAYS ensure workpiece is anchored or



clamped firmly. If drilling thin material, use a wood “backup” block to prevent damage to the material.

1. Select the desired speed/torque range using the gear shifter to match the speed and torque to the planned operation. Set the torque adjustment collar

2. For Wood, use twist bits, spade bits, power auger bits or hole saws. For Metal, use high-speed steel twist drill bits or hole saws. Use a cutting lubricant when drilling metals. The exceptions are cast iron and brass which should be drilleddry.

3. Always apply pressure in a straight line with the bit. Use enough pressure to keep the drill bit biting, but do not push hard enough to stall the motor or deflect the bit.

4. Hold tool firmly with both hands to control the twisting action of the drill.

5. IF DRILL STALLS, it is usually because it is being overloaded. RELEASE TRIGGER IMMEDIATELY, remove drill bit from work, and determine cause of stalling. DO NOT

CLICK TRIGGER OFF AND ON IN AN ATTEMPT TO START A STALLED DRILL – THIS CAN DAMAGE THE DRILL.

6. Keep the motor running when pulling the bit back out of a drilled hole. This will help prevent jamming.

5

to the drill symbol.

Screwdriver Operation (Fig. C)

1. Select the desired speed/torque range using the threespeed gear shifter torque adjustment collar gear shifter to speed 2 or 3. This ensures effective control over the fastener allowing the screw to be seated correctly and set to specification. Speed 1 will provide the same clutching torque as speeds 2 and 3. However, for optimum performance of the electronic clutch, speeds 2 and 3 arepreferred. NOTE: Use the lowest torque setting (1) first and increase the number through to the highest setting (11) to seat the fastener at the desired depth. The lower the number, the lower the torque output.

2. Reset the torque adjustment collar number setting for the torque desired. Make a few practice runs in scrap or unseen areas to determine the proper position of the torque adjustment collar.

NOTE: The torque adjustment collar may be set to any number at any time.

6

on the top of the tool. If using the

5

, initially set the three-speed

5

to the appropriate

Page 15

Hammerdrill Operation (Fig. E)

DeWALT

1. Select the desired speed/torque range using the gear shifter to match the speed and torque to the planned operation. Set the torque adjustment collar

2. Select the high speed 3 setting by sliding the gear shifter back (away form the chuck).

3. When drilling, use just enough force on the hammer to keep it from bouncing excessively. Prolonged and too much force on the hammer will cause slower drilling speeds and potential overheating.

4. Drill straight, keeping the bit at a right angle to the work. Do not exert side pressure on the bit when drilling as this will cause clogging of the bit flutes and a slower drilling speed.

5. When drilling deep holes, if the hammer speed starts to drop off, pull the bit partially out of the hole with the tool still running to help clear debris from the hole.

6. For masonry, use carbide-tipped bits or masonry bits. A smooth, even flow of dust indicates the proper drilling rate.

5

to the hammer symbol.

MAINTENANCE

Your over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regularcleaning.

The charger and battery pack are notserviceable.

power tool has been designed to operate

WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack



before making any adjustments or removing/ installing attachments or accessories. An accidental

start-up can causeinjury.

Consult your dealer for further information on the appropriateaccessories.

Protecting the Environment

6

Separate collection. Products and batteries marked with this symbol must not be disposed of with normal household waste.

Products and batteries contain materials that can be recovered or recycled reducing the demand for raw materials. Please recycle electrical products and batteries according to local provisions. Further information is available at www.2helpU.com.

Rechargeable Battery Pack

This long life battery pack must be recharged when it fails to produce sufficient power on jobs which were easily done before. At the end of its technical life, discard it with due care for our environment:

• Run the battery pack down completely, then remove it from

the tool.

• Li-Ion cells are recyclable. Take them to your dealer or a

local recycling station. The collected battery packs will be recycled or disposed of properly.

ENGLISH

Lubrication

Your power tool requires no additionallubrication.

Cleaning

WARNING: Blow dirt and dust out of the main housing with dry air as often as dirt is seen collecting in and around



the air vents. Wear approved eye protection and approved dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool. These



chemicals may weaken the materials used in these parts. Use a cloth dampened only with water and mild soap. Never let any liquid get inside the tool; never immerse any part of the tool into aliquid.

Optional Accessories

WARNING: Since accessories, other than those offered by



of such accessories with this tool could be hazardous. To reduce the risk of injury, only accessories should be used with thisproduct.

, have not been tested with this product, use

recommended

Page 16

Belgique et Luxembourg België en Luxemburg

DeWALT - Belgium BVBA Egide Walschaertsstraat 16 2800 Mechelen

Tel: NL 32 15 47 37 63 Tel: FR 32 15 47 37 64 Fax: 32 15 47 37 99

www.dewalt.be enduser.BE@SBDinc.com

Danmark DeWALT (Stanley Black&Decker AS)

Roskildevej 22 2620 Albertslund

Tel: 70 20 15 10 Fax: 70 22 49 10

www.dewalt.dk kundeservice.dk@sbdinc.com

Deutschland DeWALT

Richard Klinger Str. 11 65510 Idstein

Tel: 06126-21-0 Fax: 06126-21-2770

www.dewalt.de infodwge@sbdinc.com

Ελλάς DeWALT (Ελλάς) Α.Ε.

EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7 & Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος

Τηλ: 00302108981616 Φαξ: 00302108983570

www.dewalt.gr Greece.Service@sbdinc.com

España DeWALT Ibérica, S.C.A.

Parc de Negocios “Mas Blau” Edificio Muntadas, c/Bergadá, 1, Of. A6 08820 El Prat de Llobregat (Barcelona)

Tel: 934 797 400 Fax: 934 797 419

www.dewalt.es respuesta.postventa@sbdinc.com

France DeWALT

5, allée des Hêtres BP 60105, 69579 Limonest Cedex

Tel: 04 72 20 39 20 Fax: 04 72 20 39 00

www.dewalt.fr scufr@sbdinc.com

Schweiz Suisse Svizzera

DeWALT In der Luberzen 42 8902 Urdorf

Tel: 044 - 755 60 70 Fax: 044 - 730 70 67

www.dewalt.ch service@rofoag.ch

Ireland DeWALT

Building 4500, Kinsale Road Cork Airport Business Park Cork, Ireland

Tel: 00353-2781800 Fax: 01278 1811

www.dewalt.ie Sales.ireland@sbdinc.com

Italia DeWALT

via Energypark 6 20871 Vimercate (MB), IT

Tel: 800-014353 39 039-9590200 Fax: 39 039-9590311

www.dewalt.it

Nederlands DeWALT

Netherlands BVPostbus 83, 6120 AB BORN

Tel: 31 164 283 063 Fax: 31 164 283 200

www.dewalt.nl

Norge DeWALT

Postboks 4613 0405 Oslo, Norge

Tel: 45 25 13 00 Fax: 45 25 08 00

www.dewalt.no kundeservice.no@sbdinc.com

Österreich DeWALT

Werkzeug Vertriebsges m.b.H Oberlaaerstrasse 248, A-1230 Wien

Tel: 01 - 66116 - 0 Fax: 01 - 66116 - 614

www.dewalt.at service.austria@sbdinc.com

Portugal DeWALT

Ed. D Dinis, Quina da Fonte Rua dos Malhoes 2 2A 2º Esq. Oeiras e S. Juliao da Barra, paço de Arcos e Caxias 2770 071 Paço de Arcos

Tel: +351 214667500 Fax: +351214667580

www.dewalt.pt resposta.posvenda@sbdinc.com

Suomi DeWALT

PL47 00521 Helsinki, Suomi

Puh: 010 400 4333 Faksi: 0800 411 340

www.dewalt.fi asiakaspalvelu.fi@sbdinc.com

Sverige DeWALT

BOX 94 43122 Mölndal Sverige

Tel: 031 68 61 60 Fax: 031 68 60 08

www.dewalt.se kundservice.se@sbdinc.com

Türkiye KALE Hırdavat ve Makina A.Ş.

Defterdar Mah. Savaklar Cad. No:15 Edirnekapı / Eyüp / İSTANBUL 34050 TÜRKİYE

Tel: 0212 533 52 55 Faks: 0212 533 10 05

www.dewalt.com.tr

United Kingdom

DeWALT, 210 Bath Road; Slough, Berks SL1 3YD

Tel: 01753-567055 Fax: 01753-572112

www.dewalt.co.uk emeaservice@sbdinc.com

Australia DeWALT

810 Whitehorse Road Box Hill VIC 3103 Australia

Tel: Aust 1800 338 002 Tel: NZ 0800 339 258

www.dewalt.com.au www.dewalt.co.nz

Middle East Africa DeWALT

P.O. Box - 17164, Jebel Ali Free Zone (South), Dubai, UAE

Tel: 971 4 812 7400 Fax: 971 4 2822765

www.dewalt.ae Service.MEA@sbdinc.com

N490636

09/16
