ENGLISH

CORDLESS COMPACT 13 mm (1/2") DRILL/DRIVER
DCD730, DCD780
CORDLESS COMPACT 13 mm (1/2") DRILL/DRIVER/
HAMMERDRILL
DCD735, DCD785

Congratulations!

You have chosen a DEWALT tool. Years of experience, thorough product development and innovation make
DEWALT one of the most reliable partners for professional power tool users.

Technical Data

DCD730 DCD735 DCD780 DCD785

Voltage VDC 14.4 14.4 18 18
Type 10 10 10 10
Battery Type Li-Ion Li-Ion Li-Ion Li-Ion
Power output W 300 300 350 350
No-load speed

1st gear min-1 0–550 0–550 0–600 0–600
2nd gear min-1 0–1900 0–1900 0–2000 0–2000

Impact rate
1st gear min-1 – 0–9350 – 0–10200
2nd gear min-1 – 0–32300 – 0–34000

Max. torque (hard/soft) Nm 57/20 57/20 60/23 60/23
Chuck capacity mm 13 13 13 13
Maximum drilling capacity

Wood mm 35 35 38 38
Metal mm 13 13 13 13
Masonry mm – 13 – 13

Weight (without battery pack) kg 1.2 1.24 1.2 1.24

LPA (sound pressure) dB(A)
KPA (sound pressure uncertainty) dB(A)
LWA (sound power) dB(A)
KWA (sound power uncertainty) dB(A)

Vibration total values (triax vector sum) determined according to EN 60745:

Vibration emission value a
Drilling into metal
a

Vibration emission value a
Drilling into concrete
a

=

h,D

Uncertainty K = m/s²

=

h,ID

Uncertainty K = m/s²

h

m/s²

h

m/s²

– 15.0 – 15.0

74 89 74 89

3 3 3 3

85 100 85 100

3 3 3 3

3.0 3.5 3.0 3.5

1.5 1.5 1.5 1.5

– 3.3 – 3.3

33

ENGLISH

Vibration emission value a
Screwdriving
a

=

h,ID

Uncertainty K = m/s²

The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN 60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.

WARNING: The declared vibration

emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase the

h

m/s²

< 2.5 2.5 < 2.5 2.5

1.5 1.5 1.5 1.5

An estimation of the level of exposure to

vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
working period.

Identify additional safety measures to

protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,

organisation of work patterns.
exposure level over the total working
period.

Battery pack DCB140 DCB141 DCB142 DCB180 DCB181 DCB182

Battery type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion
Voltage VDC 14.4 14.4 14.4 18 18 18
Capacity Ah 3.0 1.5 4.0 3.0 1.5 4.0
Weight kg 0.53 0.30 0.54 0.64 0.35 0.61

Charger DCB105

Mains voltage VAC 230 V
Battery type Li-Ion
Approx. charging time min 30 55 70

(1.5 Ah battery packs) (3.0 Ah battery packs) (4.0 Ah battery packs)
Weight kg 0.49

Fuses

Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 3 Amperes, in plugs

Defi nitions: Safety Guidelines

The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.

DANGER: Indicates an imminently

34

hazardous situation which, if not avoided,
will result in death or serious injury.

WARNING: Indicates a potentially

hazardous situation which, if not
avoided, could result in death or
serious injury.

CAUTION: Indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

NOTICE: Indicates a practice not

related to personal injury which, if

not avoided, may result in property

damage.

Denotes risk of electric shock.

Denotes risk of fire.
