DeWalt DC835KAR, DC825KAR User Manual

DC820
DC822
DC825
DC827
DC830
DC832
DC835
DC837
DC840

www .

.eu

DC845

Copyright DEWALT

2

Figure 1

c

d

Figure 2

g

a

h

i

h

b

i

j

k

l

Figure 3

A

B

1

Figure 4

Figure 5

Figure 6

d

c

f

e

m

2

ENGLISH

DC820, DC822, DC825, DC827, DC830, DC832, DC835,
DC837, DC840, DC845
CORDLESS IMPACT WRENCHES/DRIVERS

Congratulations!

You have chosen a DEWALT tool. Years of experience, thorough product development and innovation make
DEWALT one of the most reliable partners for professional power tool users.

Technical Data

DC820 DC822 DC825 DC827 DC830 DC832 DC835 DC837 DC840 DC845

Voltage VDC 18 18 18 18 14.4 14.4 14.4 14.4 12 12
Type 11 11 11 11 11 11 11 11 11 11
Battery Type NiCd/NiMH – NiCd/NiMH – NiCd/NiMH – NiCd/NiMH – NiCd/NiMH NiCd/NiMH

– Li-Ion – Li-Ion – Li-Ion – Li-Ion – –
No-load speed min
Impact min
Max. torque Nm 195 195 150 150 180 180 140 140 160 130
Tool holder 1/2" 1/2" 1/4" 1/4" 1/2" 1/2" 1/4" 1/4" 1/2" 1/4"

Square Square Hex Hex Square Square Hex Hex Square Hex
Max. bolt size mm M16 M16 M12 M12 M16 M16 M12 M12 M16 M12
Weight (without

battery pack) kg 0.98 0.96 0.98 0.96 0.96 0.96 0.96 0.96 0.96 0.96

DC820 DC822 DC825 DC827 DC830 DC832 DC835 DC837 DC840 DC845

LPA

(sound pressure)

K

(sound pressure

PA

uncertainty)

LWA

(sound power)

K

(sound power

WA

uncertainty)

-1

0–2400 0–2400 0–2400 0–2400 0–2400 0–2400 0–2400 0–2400 0–2400 0–2400

-1

2700 2700 2700 2700 2700 2700 2700 2700 2700 2700

dB(A) 91 91 90 90 91 91 90 90 91 90

dB(A) 3 3 3 3 3 3 3 3 3 3

dB(A) 102 102 101 101 102 102 101 101 102 101

dB(A) 3 3 3 3 3 3 3 3 3 3

Vibration total values (triax vector sum) determined according to EN 60745:
Vibration

emission value m/s² 9.7 9.7 13.7 13.7 9.7 9.7 13.7 13.7 9.7 13.7
Uncertainty K m/s² 2.3 2.3 5.3 5.3 2.3 2.3 5.3 5.3 2.3 5.3

The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN 60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.

WARNING: The declared vibration

emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission
may differ. This may significantly
increase the exposure level over the
total working period.

An estimation of the level of exposure to

vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
working period.

Identify additional safety measures to

protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.

3

ENGLISH

Battery pack DE9180 DE9181 DE9503 DE9140 DE9502 DE9501 DE9141

Battery type Li-Ion Li-Ion NiMH Li-Ion NiMH NiMH Li-Ion
Voltage VDC 18 18 18 14.4 14.4 12 14.4
Capacity Ah 2.0 1.1 2.6 2.0 2.6 2.6 1.1
Weight kg 0.68 0.45 1.0 0.58 0.86 0.69 0.40

Charger DE9130 DE9135

Mains voltage V
Battery type NiCd/NiMH NiCd/NiMH/Li-Ion
Approx. charging time min 30 40

(2.0 Ah battery packs) (2.0 Ah battery packs)
Weight kg 0.52 0.52

Fuses:

Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 3 Amperes, in plugs

230 230

AC

Defi nitions: Safety Guidelines

The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.

DANGER: Indicates an imminently

NOTICE: Indicates a practice not

Denotes risk of electric shock.

Denotes risk of fire.

hazardous situation which, if not avoided,
will result in death or serious injury.

WARNING: Indicates a potentially

hazardous situation which, if not
avoided, could result in death or
serious injury.

CAUTION: Indicates a potentially

hazardous situation which, if not
avoided, may result in minor or

moderate injury.

related to personal injury which, if
not avoided, may result in property
damage.

EC-Declaration of Conformity

MACHINERY DIRECTIVE

DC820, DC822, DC825, DC827, DC830, DC832, DC835,
DC837, DC840, DC845

DEWALT declares that these products described
under Technical data are in compliance with:
2006/42/EC, EN 60745-1, EN 60745-2-2.

These products also comply with Directive
2004/108/EC. For more information, please contact
D

EWALT at the following address or refer to the

back of the manual.

The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf of

EWALT.

D

Horst Grossmann
Vice President Engineering and Product
Development
DEWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany

01.10.2009

4

ENGLISH

WARNING: To reduce the risk of injury,

read the instruction manual.

General Power Tool Safety Warnings

WARNING! Read all safety warnings

and all instructions. Failure to follow

the warnings and instructions may result
in electric shock, fire and/or serious
injury.

SAVE ALL WARNINGS AND INSTRUCTIONS

FOR FUTURE REFERENCE

The term “power tool" in the warnings refers to your
mains-operated (corded) power tool or battery­operated (cordless) power tool.

1) WORK AREA SAFETY

a) Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive

atmospheres, such as in the presence of
flammable liquids, gases or dust. Power

tools create sparks which may ignite the dust
or fumes.

c) Keep children and bystanders away while

operating a power tool. Distractions can
cause you to lose control.

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet.

Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs

and matching outlets will reduce risk of
electric shock.

b) Avoid body contact with earthed or

grounded surfaces such as pipes,
radiators, ranges and refrigerators. There

is an increased risk of electric shock if your
body is earthed or grounded.

c) Do not expose power tools to rain or wet

conditions. Water entering a power tool will
increase the risk of electric shock.

d) Do not abuse the cord. Never use the

cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase the
risk of electric shock.

e) When operating a power tool outdoors,

use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use

reduces the risk of electric shock.

f) If operating a power tool in a damp

location is unavoidable, use a residual
current device (RCD) protected supply.

Use of an RCD reduces the risk of electric
shock.

3) PERSONAL SAFETY

a) Stay alert, watch what you are doing and

use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of

inattention while operating power tools may
result in serious personal injury.

b) Use personal protective equipment.

Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.

c) Prevent unintentional starting. Ensure

the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger

on the switch or energising power tools that
have the switch on invites accidents.

d) Remove any adjusting key or wrench

before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in personal
injury.

e) Do not overreach. Keep proper

footing and balance at all times. This
enables better control of the power tool in
unexpected situations.

f) Dress properly. Do not wear loose

clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair

can be caught in moving parts.

g) If devices are provided for the connection

of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce

dust-related hazards.

4) POWER TOOL USE AND CARE

a) Do not force the power tool. Use the

correct power tool for your application.

The correct power tool will do the job
better and safer at the rate for which it
was designed.

b) Do not use the power tool if the switch

does not turn it on and off. Any power
tool that cannot be controlled with the switch
is dangerous and must be repaired.

c) Disconnect the plug from the power

source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive safety

measures reduce the risk of starting the
power tool accidentally.

5

ENGLISH

d) Store idle power tools out of the reach

of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.

Power tools are dangerous in the hands of
untrained users.

e) Maintain power tools. Check for

misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by

poorly maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.

g) Use the power tool, accessories and

tool bits etc., in accordance with these
instructions taking into account the
working conditions and the work to
be performed. Use of the power tool for

operations different from those intended
could result in a hazardous situation.

5) BATTERY TOOL USE AND CARE

a) Recharge only with the charger specified

by the manufacturer. A charger that is

suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.

b) Use power tools only with specifically

designated battery packs. Use of any other
battery packs may create a risk of
injury and fire.

c) When battery pack is not in use, keep it

away from other metal objects like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.

Shorting the battery terminals together may
cause burns or a fire.

d) Under abusive conditions, liquid may be

ejected from the battery, avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the

battery may cause irritation or burns.

6) SERVICE

a) Have your power tool serviced by a

qualified repair person using only identical
replacement parts. This will ensure that the

safety of the power tool is maintained.

ADDITIONAL SPECIFIC SAFETY RULES

Safety Instructions for All
Impact Drills

• Wear ear protectors with impact drills.

Exposure to noise can cause hearing loss.

• Use auxiliary handles supplied with the tool.

Loss of control can cause personal injury.

• Hold power tools by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a “live"

wire will make exposed metal parts of the tool
“live" and shock the operator.

• Use clamps or other practical way to secure
and support the workpiece to a stable
platform. Holding the work by hand or against

your body is unstable and may lead to loss of
control.

• Wear safety goggles or other eye protection.
Hammering and drilling operations cause
chips to fly. Flying particles can cause

permanent eye damage.

• Bits, sockets and tools get hot during
operation. Wear gloves when touching them.

• Do not operate this tool for long periods of
time. Vibration caused by tool action may be

harmful to your hands and arms. Use gloves
to provide extra cushion and limit exposure by
taking frequent rest periods.

Residual Risks

In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:

– Impairment of hearing

– Risk of personal injury due flying particles.

– Risk of burns due to accessories becoming hot

during operation.

– Risk of personal injury due to prolonged use.

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual

before use.

Wear ear protection.

6

ENGLISH

Wear eye protection.

IPM Impact per minute.

DATE CODE POSITION

The Date Code, which also includes the year of
manufacture, is printed into the housing surface that
forms the mounting joint between tool and battery.

Example:

2011 XX XX

Year of Manufacture

Important Safety Instructions for All
Battery Chargers

SAVE THESE INSTRUCTIONS: This manual
contains important safety and operating instruc tions
for the DE9130/DE9135 battery chargers.

• Before using charger, read all instructions and
cautionary markings on charger, battery pack,
and product using battery pack.

DANGER: Electrocution hazard.

230 volts are present at charging
terminals. Do not probe with conductive
objects. Electric shock or electrocution
may result.

WARNING: Shock hazard. Do not allow

any liquid to get inside charger. Electric
shock may result.

CAUTION: Burn hazard. To reduce

the risk of injury, charge only DEWALT
rechargeable batteries. Other types of
batteries may burst causing personal
injury and damage.

CAUTION: Under certain conditions,

with the charger plugged in to the
power supply, the exposed charging
contacts inside the charger can be
shorted by foreign material. Foreign
materials of a conductive nature such
as, but not limited to, steel wool,
aluminum foil, or any buildup of metallic
particles should be kept away from
charger cavities. Always unplug the
charger from the power supply when
there is no battery pack in the cavity.
Unplug charger before attempting to
clean.

• DO NOT attempt to charge the battery pack
with any chargers other than the ones in
this manual. The charger and battery pack are

specifically designed to work together.

• These chargers are not intended for
any uses other than charging D
rechargeable batteries. Any other uses

may result in risk of fire, electric shock or
electrocution.

• Do not expose charger to rain or snow.

• Pull by plug rather than cord when
disconnecting charger. This will reduce risk of

damage to electric plug and cord.

• Make sure that cord is located so that it
will not be stepped on, tripped over, or
otherwise subjected to damage or stress.

• Do not use an extension cord unless it
is absolutely necessary. Use of improper

extension cord could result in risk of fire, electric
shock, or electrocution.

• An extension cord must have adequate wire
size (AWG or American Wire Gauge) for
safety. The smaller the gauge number of the

wire, the greater the capacity of the cable, that
is 16 gauge has more capacity than 18 gauge.
When using more than one extension to make
up the total length, be sure each individual
extension contains at least the minimum wire
size.

• Do not place any object on top of charger
or place the charger on a soft surface that
might block the ventilation slots and result
in excessive internal heat. Place the charger

in a position away from any heat source. The
charger is ventilated through slots in the top and
the bottom of the housing.

• Do not operate charger with damaged cord
or plug — have them replaced immediately.

• Do not operate charger if it has received
a sharp blow, been dropped, or otherwise
damaged in any way. Take it to an authorized

service center.

• Do not disassemble charger; take it to an
authorized service center when service or
repair is required. Incorrect reassembly may

result in a risk of electric shock, electrocution or
fire.

• Disconnect the charger from the outlet
before attempting any cleaning. This will
reduce the risk of electric shock. Removing

the battery pack will not reduce this risk.

• NEVER attempt to connect 2 chargers together.

• The charger is designed to operate on
standard 230V household electrical power.
Do not attempt to use it on any other
voltage. This does not apply to the vehicular

charger.

EWALT

7

ENGLISH

SAVE THESE INSTRUCTIONS

Chargers

The DE9130 charger accepts 7.2–18 V NiCd and
NiMH batteries.

The DE9135 charger accepts 7.2–18 V NiCd, NiMH
or Li-Ion batteries.

These chargers require no adjustment and are
designed to be as easy as possible to operate.

Charging Procedure (fi g. 2)

DANGER: Electrocution hazard.

230 volts present at charging terminals.
Do not probe with conductive objects.
Danger of electric shock or
electrocution.

1. Plug the charger (j) into an appropriate outlet
before inserting battery pack.

2. Insert the battery pack (h) into the charger.
The red (charging) light will blink continuously
indicating that the charging process has started.

3. The completion of charge will be indicated by
the red light remaining ON continuously. The
pack is fully charged and may be used at this
time or left in the charger.

NOTE: To ensure maximum performance and life of
NiCd, NiMH and Li-Ion batteries, charge the battery
for a minimum of 10 hours before first use.

Charging Process

Refer the table below for the state of charge of the
battery pack.

State of charge

charging – – – – – –
fully charged –––––––––––
hot/cold pack delay ––– – ––– –
replace battery pack •••••••••••
problem •• •• •• ••

Automatic Refresh

The automatic refresh mode will equalise or balance
the individual cells in the battery pack at its peak
capacity. Battery packs should be refreshed weekly
or whenever the pack no longer delivers the same
amount of work.

To refresh your battery pack, place the battery in the
charger as usual. Leave the battery pack for at least
10 hours in the charger.

Hot/Cold Pack Delay

When the charger detects a battery that is too hot
or too cold, it automatically starts a Hot/Cold Pack
Delay, suspending charging until the battery has
reached an appropriate temperature. The charger
then automatically switches to the pack charging
mode. This feature ensures maximum battery life.

LI-ION BATTERY PACKS ONLY

Li-Ion batteries are designed with an Electronic
Protection System that will protect the battery
against overloading, overheating or deep discharge.

The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place the
Li-Ion battery on the charger until it is fully charged.

Important Safety Instructions for All
Battery Packs

When ordering replacement battery packs, be sure
to include catalog number and voltage. Consult the
chart at the end for compatibility of chargers and
battery packs.

The battery pack is not fully charged out of the
carton. Before using the battery pack and charger,
read the safety instructions below. Then follow
charging procedures outlined.

READ ALL INSTRUCTIONS

• Do not charge or use battery in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting

or removing the battery from the charger may
ignite the dust or fumes.

• Charge the battery packs only in D
chargers.

• DO NOT splash or immerse in water or other
liquids.

• Do not store or use the tool and battery
pack in locations where the temperature
may reach or exceed 40 ˚C (105 °F) (such as
outside sheds or metal buildings in summer).

DANGER: Never attempt to open the

battery pack for any reason. If battery
pack case is cracked or damaged,
do not insert into charger. Do not
crush, drop or damage battery pack.
Do not use a battery pack or charger
that has received a sharp blow, been
dropped, run over or damaged in any
way (i.e., pierced with a nail, hit with a
hammer, stepped on). Electric shock
or electrocution may result. Damaged
battery packs should be returned to
service centre for recycling.

EWALT

8

ENGLISH

CAUTION: When not in use, place

tool on its side on a stable surface
where it will not cause a tripping or
falling hazard. Some tools with large

battery packs will stand upright on the
battery pack but may be easily knocked
over.

SPECIFIC SAFETY INSTRUCTIONS FOR NICKEL CADMIUM
(NiCd) OR NICKEL METAL HYDRIDE (NiMH)

• Do not incinerate the battery pack even if it
is severely damaged or is completely worn
out. The battery pack can explode in a fire.

• A small leakage of liquid from the battery
pack cells may occur under extreme usage
or temperature conditions. This does not

indicate a failure.

However, if the outer seal is broken:

a. and the battery liquid gets on your skin,

immediately wash with soap and water for
several minutes.

b. and the battery liquid gets into your eyes,

flush them with clean water for a minimum
of 10 minutes and seek immediate medical
attention. (Medical note: The liquid is
25-35% solution of potassium hydroxide.)

SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION
(LI-ION)

• Do not incinerate the battery pack even if it
is severely damaged or is completely worn
out. The battery pack can explode in a fire.

Toxic fumes and materials are created when
lithium ion battery packs are burned.

• If battery contents come into contact with
the skin, immediately wash area with mild
soap and water. If battery liquid gets into the

eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte
is composed of a mixture of liquid organic
carbonates and lithium salts.

• Contents of opened battery cells may cause
respiratory irritation. Provide fresh air. If

symptoms persists, seek medical attention.

WARNING: Burn hazard. Battery liquid

may be flammable if exposed to spark
or flame.

Battery Cap (fi g. 3)

A protective battery cap is supplied to cover the
contacts of a detached battery pack. Without the
protective cap in place, loose metal objects could
short circuit the contacts, causing a fire hazard and
damaging the battery pack.

1. Take off the protective battery cap before
placing the battery pack in the charger
or tool (fig. 3A).

2. Place the protective cap over the contacts
immediately after removing the battery pack
from the charger or tool (fig. 3B).

WARNING: Make sure the protective

battery cap is in place before storing or
carrying a detached battery pack.

Battery Pack

BATTERY TYPE

The DC820, DC822, DC825 and DC827 operate on
18 volt battery packs.

The DC830, DC832, DC835 and DC837 operate on

14.4 volt battery packs.

The DC840 and DC845 operate on 12 volt battery
packs.

Storage Recommendations

1. The best storage place is one that is cool and
dry away from direct sunlight and excess heat
or cold. For optimum battery performance and
life, store battery packs at room temperature
when not in use.

2. For long storage, it is recommended to store a
fully charged battery pack in a cool, dry place
out of the charger for optimal results.

NOTE: Battery packs should not be stored
completely depleted of charge. The battery pack will
need to be recharged before use.

Labels on Charger and Battery Pack

In addition to the pictographs used in this manual,
the labels on the charger and the battery pack show
the following pictographs:

Read instruction manual

before use.

Battery charging.

Battery charged.

Battery defective.

Hot/cold pack delay.

Do not probe with conductive objects.

9

ENGLISH

Do not charge damaged battery packs.

Use only with DEWALT battery packs,

others may burst, causing personal injury
and damage.

Do not expose to water.

Have defective cords replaced

immediately.

Charge only between 4 °C and 40 °C.

Discard the battery pack with due care for

the environment.

Do not incinerate the battery pack

NiMH, NiCd+ and Li-Ion.

Charges NiMH and NiCd

battery packs.

Charges Li-Ion battery packs.

See technical data for charging time.

Package Contents

The package contains:

1 Cordless Impact Driver/Wrench

2 Battery packs

1 Charger

1 Instruction manual

1 Exploded drawing
NOTE: Battery packs and chargers are not included

with N-models.

• Check for damage to the tool, parts or
accessories which may have occurred during
transport.

• Take the time to thoroughly read and
understand this manual prior to operation.

Description (fi g. 1–5)

WARNING: Never modify the power

tool or any part of it. Damage or
personal injury could result.

INTENDED USE

These heavy-duty impact wrenches/drivers are
designed for professional impact screwdriving
applications.

The impact function makes this tool particularly
useful for driving fasteners in wood, metal and
concrete.

DO NOT use under wet conditions or in presence of
flammable liquids or gases.

These impact wrenches/drivers are professional
power tools. DO NOT let children come into
contact with the tool. Supervision is required when
inexperienced operators use this tool.

a. Trigger switch

b. Forward/reverse button

c. Sleeve

d. 1/4" hex quick-release chuck

e. Detent pin

f. Anvil

g. Worklight

h. Battery pack

i. Battery release buttons

Electrical Safety

The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.

Your DEWALT charger is double insulated

in accordance with EN 60335; therefore
no earth wire is required.

WARNING: 115 V units have to

be operated via a fail-safe isolating
transformer with an earth screen
between the primary and secondary
winding.

If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DEWALT service organisation.

Mains Plug Replacement
(U.K. & Ireland Only)

If a new mains plug needs to be fitted:

• Safely dispose of the old plug.

• Connect the brown lead to the live terminal in
the plug.

• Connect the blue lead to the neutral terminal.

10

ENGLISH

WARNING: No connection is to be

made to the earth terminal.

Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.

Using an Extension Cable

An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm2; the maximum length is 30 m.

When using a cable reel, always unwind the cable
completely.

ASSEMBLY AND ADJUSTMENTS

WARNING: Prior to assembly and

adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.

WARNING: Use only DEWALT battery

packs and chargers.

Inserting and Removing the
Battery Pack from the Tool (fi g. 2)

WARNING: To reduce the risk of

serious personal injury, turn tool off
and disconnect battery pack before

making any adjustments or removing/
installing attachments or accessories.
An accidental start-up can cause injury.

NOTE: Make sure your battery pack is fully charged.

TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE

1. Align the base of the tool with the notch inside

the tool’s handle (Fig. 2).

2. Slide the battery pack firmly into the handle until
you hear the lock snap into place.

TO REMOVE THE BATTERY PACK FROM THE TOOL

1. Press the battery release buttons (i) and firmly
pull the battery pack out of the tool handle.

2. Insert battery pack into the charger as
described in the charger section of this manual.

Belt Hook (Optional Accessory)
(fi g. 1)

WARNING: To reduce the risk of

serious personal injury, DO NOT

suspend tool overhead or suspend
objects from the belt hook. ONLY hang
tool’s belt hook from a work belt.

Your tool may be equipped with a belt hook (k). The
belt hook allows the tool to be suspended from the
tool belt to allow hands-free work.

The belt hook can be be attached to either side
of the tool to accommodate left- or right- handed
users. If the hook is not desired at all, it can be
removed from the tool.

To move belt hook, remove the screw (l) that holds
the belt hook in place then reassemble on the
opposite side. Always tighten the fastening screw
to 0.6-0.8 Nm of torque when installing the belt
hook onto the machine.

WARNING: To reduce the risk of

serious personal injury, ensure the

screw (l) holding the belt hook is secure.

OPERATION

Instructions for Use

WARNING: Always observe the safety

WARNING: To reduce the risk

instructions and applicable regulations.

of serious personal injury, turn
tool off and disconnect tool from
power source before making any
adjustments or removing/installing
attachments or accessories.

Proper Hand Position (fi g. 6)

WARNING: To reduce the risk of

WARNING: To reduce the risk of

Proper hand position requires one hand on the main
handle (m), as shown.

serious personal injury, ALWAYS use
proper hand position as shown.

serious personal injury, ALWAYS hold
securely in anticipation of a sudden
reaction.

Variable Speed Trigger Switch
(fi g. 1)

To turn the tool on, squeeze the trigger switch (a).

To turn the tool off, release the trigger switch.

Your tool is equipped with a brake. The chuck will
stop as soon as the trigger switch is fully released.

Use lower speeds for starting holes without a
center punch, drilling in metals or plastics, or driving
screws. For maximum tool life, use variable speed
only for starting holes or fasteners.

NOTE: Continuous use in variable speed range is
not recommended. It may damage the switch and
should be avoided.

11

ENGLISH

Forward/Reverse Control Button
(fi g. 1)

A forward/reverse control button (b) determines the
direction of the tool and also serves as a lock off
button.

To select forward rotation, release the trigger
switch and depress the forward/reverse control
button on the right side of the tool.

To select reverse, depress the forward/reverse
control button on the left side of the tool.

The center position of the control button locks the
tool in the OFF position. When changing the position
of the control button, be sure the trigger is released.

NOTE: The first time the tool is run after changing
the direction of rotation, you may hear a click on
start up. This is normal and does not indicate a
problem.

Worklight (fi g. 1)

There is a worklight (g) located just above the trigger
switch (a). The worklight will be activated when the
trigger switch is squeezed.

NOTE: The worklight is for lighting the immediate
work surface and is not intended to be used as a
flashlight.

Quick-Release Chuck (fi g. 4)

DC825, DC827, DC835, DC837, DC845

NOTE: The chuck accepts 1/4" hex accessories
only.

Place the switch in the locked off (center) position or
remove battery pack before changing accessories.

To install an accessory, pull the chuck collar (c)
away from the front of the tool, insert the accessory
and release the collar. The accessory is locked in
place.

To remove an accessory, pull the chuck collar
away from the front of the tool. Remove the
accessory and release the collar.

Anvil With Detent Pin (fi g. 5)

DC820, DC822, DC830, DC832, DC840

Place the switch in the locked off (center) position or
remove battery pack before changing accessories.

To install a socket on the anvil, align the hole in
the side of the socket with the detent pin (e) on the
anvil (f). Press the socket on until the detent pin
engages in the hole. Depression of detent pin may
be necessary to aid installation of socket.

CAUTION: Use only impact sockets.

Non-impact sockets may break and
cause a hazardous condition. Inspect
sock et prior to use to ensure that it
con tains no cracks.

To remove a socket, depress the detent pin
through the hole and pull the socket off.

Usage

Your impact tool generates the following output
torque:

Cat # Ft.-Lbs. In.-Lbs. Nm

DC820 145 1740 195
DC822 145 1740 195
DC825 111 1330 150
DC827 111 1330 150
DC830 135 1620 180
DC832 135 1620 180
DC835 103 1240 140
DC837 103 1240 140

DC840 120 1440 160

DC845 96 1150 130

CAUTION: Ensure fastener and/or

system will withstand the level of torque
generated by the tool. Excessive torque
may cause breakage and possible
personal injury.

1. Place the socket on the fastener head. Keep
the tool pointed straight at the fastener.

2. Press switch to start operation. Always check
torque with a torque wrench, as the fastening
torque is affected by many factors including the
following:

• Voltage: Low voltage, due to a nearly

discharged battery, will reduce fastening
torque.

• Socket size: Failure to use the correct

socket size will cause a reduction in fastening
torque.

• Bolt Size: Larger bolt diameters generally

require higher fastening torque. Fastening
torque will also vary according to length,
grade, and torque coefficient.

• Bolt: Ensure that all threads are free of rust

and other debris to allow proper fastening
torque

• Material: The type of material and surface

finish of the material will affect fastening
torque.

12

ENGLISH

• Fastening Time: Longer fasten ing time

results in increased fastening torque.
Using a longer fastening time than recom­mended could cause the fasteners to be
overstressed, stripped or damaged.

MAINTENANCE

Your DEWALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.

WARNING: To reduce the risk of

serious personal injury, turn tool off
and disconnect battery pack before

making any adjustments or removing/
installing attachments or accessories.
An accidental start-up can cause injury.

Lubrication

Your power tool requires no additional lubrication.

Cleaning

WARNING: Blow dirt and dust out of

the main housing with dry air as often as
dirt is seen collecting in and around the
air vents. Wear approved eye protection
and approved dust mask when
performing this procedure.

WARNING: Never use solvents or

other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.

CHARGER CLEANING INSTRUCTIONS

WARNING: Shock hazard. Disconnect

the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the charger
using a cloth or soft non-metallic brush.
Do not use water or any cleaning
solutions.

Optional Accessories

WARNING: Since accessories, other

Consult your dealer for further information on the
appropriate accessories.

than those offered by D
not been tested with this product, use
of such accessories with this tool could
be hazardous. To reduce the risk of
injury, only D
accessories should be used with this
product.

EWALT, recommended

EWALT, have

Protecting the Environment

Separate collection. This product must

not be disposed of with normal
household waste.

Should you find one day that your DEWALT product
needs replacement, or if it is of no further use to you,
do not dispose of it with household waste. Make this
product available for separate collection.

Separate collection of used products

and packaging allows materials to be
recycled and used again. Re-use of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw materials.

Local regulations may provide for separate collection
of electrical products from the household, at
municipal waste sites or by the retailer when you
purchase a new product.

DEWALT provides a facility for the collection and
recycling of DEWALT products once they have
reached the end of their working life. To take
advantage of this service please return your product
to any authorised repair agent who will collect them
on our behalf.

You can check the location of your nearest
authorised repair agent by contacting your local
DEWALT office at the address indicated in this
manual. Alternatively, a list of authorised DEWALT
repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com.

13

ENGLISH

Rechargeable Battery Pack

This long life battery pack must be recharged when
it fails to produce sufficient power on jobs which
were easily done before. At the end of its technical
life, discard it with due care for our environment:

• Run the battery pack down completely, then
remove it from the tool.

• Li-Ion, NiCd and NiMH cells are recyclable. Take
them to your dealer or a local recycling station.
The collected battery packs will be recycled or
disposed of properly.

GUARANTEE

DEWALT is confident of the quality of its
products and offers an outstanding guarantee
for professional users of the product. This
guarantee statement is in addition to and in
no way prejudices your contractual rights as a
professional user or your statutory rights as a
private non-professional user. The guarantee
is valid within the territories of the Member
States of the European Union and the
European Free Trade Area.

• 30 DAY NO RISK SATISFACTION GUARANTEE •

If you are not completely satisfied with the
performance of your D
return it within 30 days, complete with all
original components, as purchased, to
the point of purchase, for a full refund or
exchange. The product must have been
subject to fair wear and tear and proof of
purchase must be produced.

• ONE YEAR FREE SERVICE CONTRACT •

If you need maintenance or service for your

EWALT tool, in the 12 months following

D
purchase, you are entitled to one service free
of charge. It will be undertaken free of charge
at an authorised DEWALT repair agent. Proof
of purchase must be produced. Includes
labour. Excludes accessories and spare parts
unless failed under warranty.

• ONE YEAR FULL WARRANTY •

EWALT product becomes defective

If your D
due to faulty materials or workmanship
within 12 months from the date of purchase,
DEWALT guarantees to replace all defective
parts free of charge or – at our discretion –
replace the unit free of charge provided that:

• The product has not been misused;

• The product has been subject to fair
wear and tear;

• Repairs have not been attempted by
unauthorised persons;

• Proof of purchase is produced;

• The product is returned complete with all
original components.

If you wish to make a claim, contact your
seller or check the location of your nearest
authorised DEWALT repair agent in the
DEWALT catalogue or contact your DEWALT
office at the address indicated in this manual.
A list of authorised DEWALT repair agents and
full details of our after-sales service is available
on the Internet at: www.2helpU.com.

EWALT tool, simply

14

151617

Belgique et Black & Decker - DEWALT Dutch Tel: [phone] Fax: [phone]
Luxembourg Nieuwlandlaan 7, IZ Aarschot B156 French Tel: [phone] Fax: [phone]
België en B-3200 Aarschot www.dewalt.be
Luxemburg

Danmark D

EWALT Tlf: 70201511

Sluseholmen 2-4 Fax: [phone]
2450 København SV www.dewalt.dk

Deutschland D

EWALT Tel: [phone]

Richard Klinger Str. 11 Fax: [phone]
65510 Idstein www.dewalt.de

Ελλάς Black & Decker (Ελλάς) Α.Ε. Τηλ : 30 210 8981-616 www.dewalt.gr

Στράβωνος 7 & Βουλιαγμένης 159 Service: 30 210 8981-616
Γλυφάδα 16674, Αθήνα Φαξ: 30 210 8983-570

España DEWALT Tel: [phone]
Parque de Negocios “Mas Blau” Fax: [phone]
Edificio Muntadas, c/Bergadá, 1, Of. A6 www.dewalt.es
08820 El Prat de Llobregat (Barcelona)

France D

EWALT Tel: [phone]

5, allée des hêtres Fax: [phone]
BP 30084, 69579 Limonest Cedex www.dewalt.fr

Schweiz D

EWALT Tel: 01 - 730 67 47

Suisse In der Luberzen 40 Fax: 01 - 730 70 67
Svizzera 8902 Urdorf www.dewalt.ch

Ireland D

EWALT Tel: [phone]

Calpe House Rock Hill Fax: [phone]
Black Rock, Co. Dublin www.dewalt.ie

Italia D

EWALT Tel: [phone]

c/o Energypark Building 03 sud, Via Monza 7/A, Fax: [phone]
20871 Vimercate (MB), IT www.dewalt.it

Nederlands Black & Decker - D

EWALT Tel: [phone]

Joulehof 12 Fax: [phone]
4600 AB Bergen Op Zoom www.dewalt.nl

Norge D

EWALT Tel: [phone]

Postboks 4613, Nydalen Fax: [phone]
0405 Oslo www.dewalt.no

Österreich D

EWALT Tel: 01 - 66116 - 0

Werkzeug Vertriebsges m.b.H Fax: 01 - 66116 - 14
Oberlaaerstrasse 248 www.dewalt.at
A-1230 Wien

Portugal D

EWALT Tel: [phone]

Centro de Escritórios de Sintra Avenida Almirante Fax: [phone]
Gago Coutinho, 132/134, Edifício 142710-418 Sintra www.dewalt.pt
2710-418 Lisboa

Suomi D

EWALT Puh: 010 400 430

Tekniikantie 12 Faksi: 0800 411 340
02150 Espoo, Finland www.dewalt.fi

Sverige D

EWALT Tel: [phone]

Box 94 Fax: [phone]
431 22 Mölndal www.dewalt.se

Türkiye

KALE Hırdavat ve Makina A.Ş. Tel: [phone]

Defterdar Mah. Savaklar Cad. No:15 Faks: 0212 533 10 05
Edirnekapı / Eyüp / İSTANBUL 34050 TÜRKİYE www.dewalt.com.tr

United D

EWALT Tel: [phone] www.dewalt.co.uk

Kingdom 210 Bath Road; Slough, Berks SL1 3YD Fax: [phone]
Middle East D

EWALT Tel: [phone]

Africa P.O. Box - 17164, Fax: [phone]
Jebel Ali (South Zone), Dubai, UAE www.dewalt.ae

N110986 09/11
