DeVilbiss FAC752-2, FA752-2 User Manual

OWNERS MANUAL FOR

PERMANENTLY LUBRICATED

AIR COMPRESSOR

MODEL NO.

FA752-2

FAC752-2

(For Home Use Only)

SPECIFICATION CHART

Model No.

Horsepower
SCFM @ 40 psig
SCFM @ 90 psig
Bore
Stroke
Volt/Hertz/Phase
Minimum Branch Circuit Requirement
*Fuse Type
Tank Size

*A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same
rating as the branch circuit the air compressor is operated on. If the air compressor
is connected to a circuit protected by fuses, use quick acting fuses.

SAFETY GUIDELINES - DEFINITIONS

This manual contains information
that is important for you to know
and understand. This information
relates to protecting YOUR

SAFETY and PREVENTING
EQUIPMENT PROBLEMS. To

help you recognize this informa­tion, we use symbols to the right.
Please read the manual and pay
attention to these sections.

FA752-2

3/4

3.0

2.2
1 3/4"
1 1/4"

120/60/1

15 AMPS

Quick Acting

2 Gallon

URGENT SAFETY INFORMATION - A HAZARD
THAT WILL CAUSE SERIOUS INJURY OR LOSS
OF LIFE.

IMPORTANT SAFETY INFORMATION - A
HAZARD THAT MIGHT CAUSE SERIOUS
INJURY OR LOSS OF LIFE.

FAC752-2

----

3.0

2.2
1 3/4"
1 1/4"

120/60/1

15 AMPS

Quick Acting

2 Gallon

Information for preventing damage to
equipment.

Information that you should pay special
attention to.

MGP-FA752-4 10/7/97

TABLE OF CONTENTS

Page

SAFETY GUIDELINES .......................... Cover Page

WARRANTY STATEMENT .................................. 3

WARNING CHART ............................................. 4-5

GLOSSARY ........................................................ 5

DUTY CYCLE .................................................... 5

DESCRIPTION OF OPERATION ....................... 6

INSTALLATION AND BREAK-IN

PROCEDURES ................................................ 6-7

Location of Air Compressor ........................ 6

Page

Extension Cords ......................................... 6

Grounding Instructions ................................ 6-7

Air Hose ...................................................... 7

OPERATING PROCEDURES ............................. 7

STORAGE ........................................................... 8

AIR COMPRESSOR

DIAGRAM AND PARTS LIST ............................ 9

TROUBLESHOOTING GUIDE ........................... 10

HOW TO ORDER REPAIR PARTS ........ Back Cover

2 — ENG

LIMITED WARRANTY

ONE YEAR FROM DATE OF PURCHASE

All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship
and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products
covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and
generators used in consumer applications (i.e., personal residential household usage only).

Air compressors, *air tools, accessories, service parts, pressure washers, and generators used in commercial
applications (income producing) are covered by a 90 day warranty.

DeVilbiss Air Power will repair or replace, at DeVilbiss's option, products or components which have failed within the
warranty period. Repair or replacement, and service calls on 60 and 80 gallon air compressors, will be handled by
Authorized Warranty Service Centers and will be scheduled and serviced according to the normal work flow and
business hours at the service center location, and depending on the availability of replacement parts.

All decisions of DeVilbiss Air Power Company with regard to this policy shall be final.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

RESPONSIBILITY OF ORIGINAL PURCHASER (Initial User):

❏ Retain original cash register sales receipt as proof of purchase for warranty work.
❏ Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s).
❏ Deliver or ship the product to the nearest DeVilbiss Air Power Authorized Warranty Service Center.

Freight costs, if any, must be paid by the purchaser.

❏ Air compressors with 60 and 80 gallon tanks only will be inspected at the site of installation. Contact the nearest

Authorized Warranty Service Center, that provides on-site service calls, for service call arrangement.

❏ If the purchaser does not receive satisfactory results from the Authorized Warranty Service Center, the purchaser

should contact DeVilbiss Air Power Company.

THIS WARRANTY DOES NOT COVER:

❏ Merchandise sold as reconditioned, floor models and/or display models. Any damaged or incomplete equipment

sold "as is".

❏ Merchandise used as "rental" equipment.
❏ Merchandise that has become inoperative because of ordinary wear, misuse, freeze damage, use of improper

chemicals, negligence, accident, improper and/or unauthorized repair or alterations including failure to operate
the product in accordance with the instructions provided in the Owners Manual (s) supplied with the product.
*Air Tools: O-Rings and driver blades are considered ordinary wear parts, therefore, they are warranted for a
period of 45 days from the date of purchase.

❏ An air compressor that pumps air more than 50% during a one hour period is considered misuse because

the air compressor is undersized for the required air demand. Maximum compressor pumping time per hour is
30 minutes.

❏ Merchandise sold by DeVilbiss Air Power which has been manufactured by and identified as the product of

another company. The product manufacturer's warranty will apply.

❏ Repair and transportation costs of merchandise determined not to be defective.
❏ Cost associated with assembly, required oil, adjustments or other installation and start-up cost.
❏ ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM

ANY DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

❏ IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE LIMITED TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitations may not apply to you.

DeVilbiss Air Power Company

213 Industrial Drive • Jackson, TN 38301-9615 • Telephone: [phone] , Ext. 2 • FAX: [phone]

Form: SP-100-E - 4/25/96

3 — ENG

IMPORTANT SAFETY INSTRUCTIONS

• SAVE THESE INSTRUCTIONS •

IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT
IN SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL
WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT.

HAZARD

RISK OF BURSTING

RISK OF

EXPLOSION OR FIRE

WHAT CAN HAPPEN

ATTACHMENTS & ACCESSORIES

EXCEEDING THE PRESSURE RATING OF AIR
TOOLS, SPRAY GUNS, AIR OPERATED

ACCESSORIES, TIRES AND OTHER
INFLATABLES CAN CAUSE THEM TO EX-
PLODE OR FLY APART, AND COULD RESULT
IN SERIOUS INJURY.

USE OF

AIR HOSE COULD PRODUCE EXCESSIVE
SYSTEM PRESSURE AND CAUSE
DAMAGES TO THE COMPRESSOR AND
HOSE FAILURE WHICH COULD RESULT IN
SERIOUS INJURY.

IT IS NORMAL FOR ELECTRICAL
CONTACTS WITHIN THE MOTOR AND PRES-
SURE SWITCH TO SPARK.

IF ELECTRICAL SPARKS FROM COMPRES-
SOR COME INTO CONTACT WITH
FLAMMABLE VAPORS, THEY MAY IGNITE,
CAUSING FIRE OR EXPLOSION.

RESTRICTING ANY OF THE COMPRESSOR
VENTILATION OPENINGS WILL CAUSE SERI­OUS OVERHEATING AND COULD CAUSE
FIRE.

UNATTENDED OPERATION OF THIS PROD­UCT COULD RESULT IN PERSONAL INJURY
OR PROPERTY DAMAGE.

UNAUTHORIZED REPLACEMENT

HOW TO PREVENT IT

FOLLOW THE EQUIPMENT MANUFACTUR­ERS RECOMMENDATION AND NEVER EX­CEED THE MAXIMUM ALLOWABLE PRES­SURE RATING OF ATTACHMENTS.

USE COMPRESSOR TO INFLATE SMALL
LOW-PRESSURE OBJECTS SUCH AS
CHILDREN’S TOYS, FOOTBALLS,
BASKETBALLS. ETC.

HOSE IS PERMANENTLY ATTACHED TO
THE COMPRESSOR AND SHOULD ONLY BE
REPLACED BY AUTHORIZED SERVICE
CENTER PERSONNEL USING CERTIFIED
REPLACEMENT PARTS.

ALWAYS OPERATE THE COMPRESSOR IN A
WELL VENTILATED AREA FREE OF COM-

BUSTIBLE MATERIALS, GASOLINE OR
SOLVENT VAPORS.

IF SPRAYING FLAMMABLE MATERIALS,

LOCATE COMPRESSOR AT LEAST 20 FEET
AWAY FROM SPRAY AREA. AN ADDITIONAL

LENGTH OF HOSE MAY BE REQUIRED.

STORE FLAMMABLE MATERIALS IN A
SECURE LOCATION AWAY FROM COM­PRESSOR.

NEVER PLACE OBJECTS AGAINST OR ON
TOP OF COMPRESSOR. OPERATE COM­PRESSOR IN AN OPEN AREA AT LEAST 12
INCHES AWAY FROM ANY WALL OR
OBSTRUCTION THAT WOULD RESTRICT

THE FLOW OF FRESH AIR TO THE VENTILA­TION OPENINGS.

NEVER

RISK OF

ELECTRICAL SHOCK

YOUR AIR COMPRESSOR IS POWERED BY
ELECTRICITY. LIKE ANY OTHER ELECTRI-
CALLY POWERED DEVICE, IF IT IS NOT USED
PROPERLY IT MAY CAUSE ELECTRIC
SHOCK.

REPAIRS ATTEMPTED BY UNQUALIFIED
PERSONNEL CAN RESULT IN SERIOUS
INJURY OR DEATH BY ELECTROCUTION.

ELECTRICAL GROUNDING: FAILURE TO
PROVIDE ADEQUATE GROUNDING TO THIS
PRODUCT COULD RESULT IN SERIOUS
INJURY OR DEATH FROM ELECTROCU­TION. SEE GROUNDING INSTRUCTIONS.

4 — ENG

ALWAYS REMAIN IN ATTENDANCE WITH
THE PRODUCT WHEN IT IS OPERATING.
UNPLUG COMPRESSOR WHENEVER IS NOT
BEING USED.

NEVER OPERATE THE COMPRESSOR OUT­DOORS WHEN IT IS RAINING OR IN WET
CONDITIONS

ANY ELECTRICAL WIRING OR REPAIRS
REQUIRE ON THIS PRODUCT SHOULD BE

PERFORMED BY AUTHORIZED SERVICE
CENTER PERSONNEL. IN ACCORDANCE

WITH NATIONAL AND LOCAL ELECTRICAL
CODES.

MAKE CERTAIN THAT THE ELECTRICAL
CIRCUIT TO WHICH THE COMPRESSOR IS
CONNECTED PROVIDES PROPER ELECTRI­CAL GROUNDING, CORRECT VOLTAGE
AND ADEQUATE FUSE PROTECTION.
