PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Although every precaution has been taken to eliminate sharp edges always take
care when handling metal components.
INSTRUCTION MANUAL
Models: DEF978265
Contemporary Gas Heater
1
SAFETY INSTRUCTIONS
Do not: Attempt to use the heater in high rise ats, basements, bathrooms or bedrooms.
Do not: Use any other gas except Butane or Propane.
Do not: Attempt to clean the heater until it is turned o and fully cooled.
Do not: Use naked ame to detect suspected gas leaks.
Do not: Allow children or pets to play near the heater.
Do not: Twist the exible gas hose.
Do not: Touch the glass panel or front and sides of the unit while the heater is operating.
Warning:
Never attempt to light the unit if the hose is loose or damaged in any way. Also never attempt to
light the unit if you have reason to believe that the unit may be leaking gas. In the event of a
gas leak turn o the gas supply at the cylinder and have the unit fully checked by a competent
person in accordance with the instructions enclosed. We recommend servicing once a year.
Should you need to change the gas bottle, conrm that the gas supply is turned o at the
cylinder and that there are no sources of ignition near before proceeding.
Do: Place heater on a at, level and solid surface at all times.
Do: Leak test the unit after long periods of storage.
Do: Wait for 3 minutes before relighting, if the burner ame becomes extinguished during use.
Do: Ensure that all naked ames are extinguished before tting a new cylinder.
Do: Store gas cylinders outdoor, above ground level in a safe and secure environment.
Do: Make sure that the gas supply at the gas cylinder is turned o after use.
Do: Ensure that servicing of the unit is carried out by a competent person in accordance with the instructions enclosed.
Do: Allow the unit to cool down for one hour before touching the front or sides.
Always: Follow any safety instructions supplied with gas cylinders.
Always: Keep unit well away from glass doors and windows to ensure no possibility of heat build up and damage.
Always: We recommend servicing once a year or after a prolonged period of non-use.
Always: Ensure that there is no blockage of airow. For example sooting and poor burning can be caused by dirt,
insects, cobwebs, blocking the airow to/in the burner.
Cleaning: Abrasive cleaners are not to be used. Clean unit with a damp cloth when fully cooled.
This unit is designed for use with a 7kg or 15kg (UK) and 13kg cylinder (Eire)
Fit Glass Panel in place as shown. Secure in
position with xings as shown.
Fit back door onto the brackets as indicated above.
NOTE:
Door can be adjusted to t either a big or small gas
cylinder.
NOTE:
When tting gas regulator to the cylinder ensure
that the regulator is in the o position.
To t battery unscrew ignition button and place
battery in housing. Ret ignition button securely.
Remove the glass panel and
place the coals in position as shown above.
ASSEMBLY INSTRUCTIONS - IN 3 EASY STEPS
If you require any further assistance please do not hesitate to contact us directly
on our helpline: 00 353 1 823 9200
2
USER INSTRUCTIONS
Read these instructions before using the appliance.
When lighting for the rst time, burn outdoors for 4 hours minimum to cure the synthetic coals.
(The coals give o an odour when curing.)
The appliance must be installed and used in accordance with the regulations, which are currently in force.
The heater should be positioned on a level surface. Only use in a well ventilated area.
The minimum room size when using this appliance is 64 cubic metres with a minimum ventilation of 80 cm squared area.
To t a Butane Gas Regulator:
Attach regulator to end of hose and secure with hose clip.
Note: for ease of tting hose, lubricate ribbed nipple of regulator with a soap solution.
To t a Butane Gas Cylinder:
(Ensure that the area is free from any unprotected combustible material or substance
1. The changing and connection of LPG cylinders must be undertaken in a ame free atmosphere
2. Attach the regulator to the new cylinder. Ensure that the hose is not twisted or damaged in any way.
3. Use gas cylinders with a gas capacity of 7-15kgs.
4. In order to remove the regulator you must ensure that the regulator is in the “o” position.
Before lighting:
1. Inspect the hose assembly. If the hose is cut or shows signs of excessive wear, or is leaking it must be replaced prior to
operation of the heater
2. Ensure the heater is positioned with a minimum clearance above and beside of 0.6metres from ammable materials
both vertically and horizontally.
3. Ensure that the glass panel is closed securely.
To Light Heater:
1. Fit battery type AA provided into ignition button. See Fig.1
2. Turn on heater at gas cylinder regulator
3. Turn the control knob to the position and hold down for 5 seconds to ensure all air in the
hose is expelled.
4. Push control dial down and turn
to ame position and at the same time press the sparker
button to light the pilot. If there is no spark check the battery type AA is correctly tted. (the
pilot ame can be viewed at the right hand side of the coal bed)
5. If pilot does not light turn control dial to o position. Wait one minute and repeat step 3.
Do not continuously hold down the control knob as you may cause a build up of gas.
6. Once the pilot is lit hold down the control dial for at least 10 seconds until the main burner lights. Operate the re
between the
high and
low ame settings as required.
7. If the pilot and main burner do not stay lit on releasing the control knob, turn the control knob to the ignition position
and repeat steps 3 to 4.
8. The is a pilot setting only.
To Turn O Heater:
1. Turn the control knob to position.
2. Turn o the gas at the cylinder regulator valve.
NOTE: The pilot light will remain alight until the cylinder regulator is turned o.
3. Disconnect the regulator from the cylinder when the heater is not in use.
Important: Read all the instruction Manual before using this appliance . This appliance must be installed in
accordance with such regulations as are in force. Installation to be carried out by a competent person.
Warning:
Do not use in leisure vehicles such as caravans and auto caravans.
In the event of a gas leak. ie. If you smell gas, turn o the cylinder valve. Disconnect the cylinder, take it
outdoors and contact a competent service technician.
Do not position the appliance close to walls, furniture, hangings, net curtains, bed linen and other inammable materials
as this would result in the risk of re. The guard (glass door) on this appliance is to prevent risk of re or injury from burns
and no part of it should be permanently removed. IT DOES NOT GIVE FULL PROTECTION FOR YOUNG CHILDREN OR
THE INFIRM. For the full protection of young children or the inrm, we recommend a reguard conforming
to BS 8423 be tted.
Fig.1
Unscrew ignition button to t
battery 1.5V type AA
3
Stove Back Door Glass Panel Synthetic Coals Flexible Gas
Hose & Regulator
HOW TO ORDER
Parts orders may be placed by
contacting us directly at:
00353 1 823 9200
by post at:
MCL, Unit 5,
Northern Cross Business Park,
North Road, Finglas, Dublin 11, Ireland
Or by emailing us at
info@mcl.ie
Please include the following details:
• Model Name
• Serial Number
• Kilowatt Rating
• Month and Year of Purchase
• Name and Location of Retailer
• Your Name, Address and Contact
Number
GUARANTEE
This ueless gas stove is made to an exacting quality standard and is covered by the following guarantee.
The product is fully guaranteed for 2 years, regarding proper use. THIS GUARANTEE DOES NOT AFFECT YOUR STATUTORY RIGHTS IN ANY WAY
TECHNICAL & SERVICING INFORMATION
This appliance is designed for indoor use only using Butane gas at a supply
pressure of 28-30 millibar and must be serviced by a fully qualied and competent
registered engineer in accordance with the instructions included. Please read
all accompanying documentation carefully.
Technical Specications:
Overall height: 670 millimetres approximately
Overall width: 375 millimetres approximately
Heat input: 3.0kW (Gross)
Gas consumption: 215 grams per hour at maximum setting
Gas category: I3+
Gas type & Supply pressure: Butane 28-30 mbar and Propane 37 mbar
Injector size: 0.83 mm
Regulator type: 28 mbar
Regulator Outlet pressure: 28 mbar
Cylinder sizes: 11.4kg cylinder (Eire) and 15kg or 7kg cylinder (U.K)
Hose BS3212 length 40 cm
Destination Countries GB & IE
The product is fully guaranteed for two years regarding proper use.
This guarantee does not aect your statutory rights. For servicing contact your
local gas supplier. Servicing to be carried out by a qualied and competent
registered engineer every 1000 hours of use.
For help on this product and our range of products see our website www.mcl.ie or
contact us direct on our Helpline 00353 1 823 9200
Helpline hours are 9am to 5pm Monday to Friday.
Parts List
0086
4
5
